A wellbalanced finite volume scheme for the Euler equations with gravitation
The exact preservation of hydrostatic equilibrium with arbitrary entropy stratification
Seminar for Applied Mathematics (SAM), Department of
Mathematics,
ETH Zürich,
8092
Zürich,
Switzerland
email:
roger.kaeppeli@sam.math.ethz.ch
Received: 24 November 2015
Accepted: 27 December 2015
Context. Many problems in astrophysics feature flows which are close to hydrostatic equilibrium. However, standard numerical schemes for compressible hydrodynamics may be deficient in approximating this stationary state, where the pressure gradient is nearly balanced by gravitational forces.
Aims. We aim to develop a secondorder wellbalanced scheme for the Euler equations. The scheme is designed to mimic a discrete version of the hydrostatic balance. It therefore can resolve a discrete hydrostatic equilibrium exactly (up to machine precision) and propagate perturbations, on top of this equilibrium, very accurately.
Methods. A local secondorder hydrostatic equilibrium preserving pressure reconstruction is developed. Combined with a standard central gravitational source term discretization and numerical fluxes that resolve stationary contact discontinuities exactly, the wellbalanced property is achieved.
Results. The resulting wellbalanced scheme is robust and simple enough to be very easily implemented within any existing computer code that solves time explicitly or implicitly the compressible hydrodynamics equations. We demonstrate the performance of the wellbalanced scheme for several astrophysically relevant applications: wave propagation in stellar atmospheres, a toy model for corecollapse supernovae, convection in carbon shell burning, and a realistic protoneutron star.
Key words: hydrodynamics / methods: numerical / convection / stars: interiors / stars: neutron
© ESO, 2016
1. Introduction
Many interesting astrophysical phenomena can be modeled by the Euler equations with gravitational source terms. They express the conservation of mass, momentum, and total energy, as given by Here, ρ is the mass density, ν the velocity, and , where the total energy is the sum of internal and kinetic energy. The pressure p is related to the specific internal energy and the density through an equation of state p = p(ρ,e).
The source terms on the righthand side of the momentum and energy equations model the effect of the gravitational forces on the fluid. They are proportional to the gradient of the gravitational potential φ, which can either be a given function or in the case of selfgravity, it can be determined by the Poisson equation(4)In many situations one has to deal with flows close to hydrostatic equilibrium (5)Here, the interest relies in robust and accurate resolution of flows close to hydrostatic equilibrium. The numerical approximation of near steady flows is challenging for standard finite volume schemes because they do not necessarily satisfy a discrete equivalent of the balance of pressure gradient and gravitational forces, represented by Eq. (5). As a result, equilibrium states are not preserved exactly but are approximated with an error proportional to the truncation error. If one is interested in the simulation of small perturbations on top of the equilibrium, the numerical resolution has to be increased to the point that the truncation errors do not obscure the phenomena of interest. This need in resolution may become prohibitively large (especially in multiple dimensions).
Many remedies have been proposed to overcome the aforementioned difficulties. The simplest solution consists of subtracting the (assumed known) stationary state at each time step. In this way the truncation errors are exactly canceled (see, e.g., Dedner et al. 2001). However, this requires that the stationary state is known a priori. Another approach in the finite volume methodology is to introduce the effect of gravity into the Riemann solver. The idea is that the Riemann solver should recognize pressure differences induced by gravity and prevent the propagation of resulting waves. Perhaps, the earliest approach of this type, was already presented in the original description of the piecewise parabolic method of Colella & Woodward (1984): the influence of the gravity source term was incorporated into the characteristic evolution step. For Rusanov or local LaxFriedrichs type Riemann solvers, Käppeli et al. (2011) have subtracted the gradients induced by gravity in the dissipative flux terms. Yet another strategy for finite volume schemes is to introduce a subgrid model which incorporates the stationary state into the reconstruction process, see, e.g., Freytag et al. (2012), Mellema et al. (1991), Zingale et al. (2002).
Greenberg & Leroux (1996) introduced the concept of a wellbalanced scheme, i.e., a scheme which satisfies exactly a discrete equivalent of an underlying stationary state. Many wellbalanced schemes have been designed, especially for the shallow water equations with nontrivial bottom topography, see, e.g., Lefloch & Thanh (2003), LeVeque (1998), Audusse et al. (2004) and references therein.
Wellbalanced schemes for certain classes of hydrostatic equilibrium have been presented by LeVeque (1998, 2011), Botta et al. (2004), Fuchs et al. (2010), Xing & Shu (2013), Desveaux et al. (2014), Käppeli & Mishra (2014), Chandrashekar & Klingenberg (2015), Li & Xing (2015). However, Eq. (5) only specifies a mechanical equilibrium. All the afore mentioned wellbalanced schemes need to assume a certain thermal equilibrium in order to uniquely determine the stationary state. For instance, Käppeli & Mishra (2014) have designed a wellbalanced scheme under the further assumption of isentropic (isothermal) conditions. Then Eq. (5) can be explicitly integrated to h + φ = const. (g + φ = const.), where h is the specific enthalpy (g the Gibbs free energy). These expressions can then be used to build a wellbalanced scheme for the isentropic (isothermal) case.
In this paper, we design wellbalanced first and secondorder accurate finite volume schemes for approximating the Euler equations with gravitation without any assumption of a thermal equilibrium. The main ingredient of our scheme is the use of a straightforward discretization of hydrostatic equilibrium Eq. (5) as basis for the pressure reconstruction. The schemes are wellbalanced for any consistent Riemann solver capable of resolving a stationary contact discontinuity. Moreover, the scheme allows for any explicit or implicit time integration.
The rest of the paper is organized as follows: the wellbalanced finite volume scheme is presented in Sect. 2. Numerical results are presented in Sect. 3 and discussion and conclusions are provided in Sect. 4.
2. Numerical method
2.1. Onedimensional Cartesian case
We first consider the Euler equations with gravitation (1)−(3)in one space dimension and write them in the compact form: (6)with (7)where u, F and S are the vectors of conserved variables, fluxes and source terms. Moreover, we denote the primitive variables by w = [ ρ,ν_{x},p ] ^{T}. The system is closed by an equation of state (EoS) p = p(ρ,e) which relates the pressure p to density ρ and specific internal energy e (or any other related thermodynamic quantity such as temperature or specific entropy). The form of the EoS does not matter for the methods presented. Several types of EoSs are employed in the applications described later in the paper, including ideal, hybrid (polytropic and ideal) and tabulated EoSs.
For the numerical approximation of Eq. (6), the spatial domain is discretized by cells or finite volumes I_{i} = [ x_{i−1 / 2},x_{i + 1 / 2} ] of regular size Δx = x_{i + 1 / 2} − x_{i−1 / 2}. Varying cell sizes can easily be accommodated for (see Appendix A). By integrating Eq. (6)over a cell I_{i} we obtain a semidiscrete finite volume scheme for the evolution of the cellaveraged conserved variables u_{i}(8)where F_{i + 1 / 2,j} is the numerical flux at cell interface and S_{i} is the gravity source term.
The numerical flux is obtained by solving (approximately) the Riemann problem at cell interfaces (9)where the w_{i + 1 / 2 −} and w_{i + 1 / 2 +} are the cell interface extrapolated primitive variables. The only requirement on the numerical flux for the hydrostatic equilibrium preserving scheme elaborated below is, that it is capable of resolving stationary contact discontinuities, i.e., (10)where ρ_{L} (ρ_{R}) is the density on the left (right) side of the contact discontinuity and p the constant pressure. For example the HLLC (Toro et al. 1994) and Roe (Roe 1981) approximate Riemann solvers have this property. In the following, we use the HLLC Riemann solver with wave speed estimates according to Batten et al. (1997).
The gravitational source term is evaluated by standard spatially secondorder accurate centered differences (11)where the φ_{i} are the cellcentered values of the gravitational potential. This is a common choice in astrophysical simulations. Moreover, note that the above expression is exact for a linear gravitational potential, i.e., a constant gravitational acceleration.
The cell interface extrapolated values of the primitive variables w_{i−1 / 2 +} and w_{i + 1 / 2 −} are obtained by a reconstruction procedure from the cellaveraged conserved variables. The simplest reconstruction assumes a piecewise constant distribution of the conserved variables within the cell. This results in Godunov’s (Godunov 1959) method, which is firstorder accurate in space. Spatial accuracy is increased by higherorder nonoscillatory polynomial reconstructions (Laney 1998; LeVeque 2002; Toro 1997). Prominent choices are piecewise linear (e.g., MUSCL van Leer 1979) and piecewise parabolic (PPM, Colella & Woodward 1984) reconstructions.
However, standard reconstructions will not preserve a discrete hydrostatic equilibrium. In the next section, we present a novel reconstruction which can preserve a discrete hydrostatic equilibrium up to machine precision, i.e., a wellbalanced reconstruction.
A fully discrete scheme is obtained by choosing an integrator for the system of ordinary differential Eq. (8). This is discussed in Sect. 2.2.
2.1.1. Wellbalanced local hydrostatic pressure reconstruction
A standard finite volume scheme (8)may not preserve a discrete equivalent of a hydrostatic equilibrium (12)This deficiency is most obvious for a firstorder scheme. The piecewise constant reconstruction is indeed incompatible with the pressure stratification induced by gravity. The pressure difference at cell interfaces is interpreted as a propagating wave by the Riemann solver. Hence, the equilibrium is destroyed.
Higherorder reconstructions, such as piecewise linear (e.g., MUSCL), parabolic (e.g., PPM) or polynomials of even higher degree, will reduce the pressure difference at the cell interface and therefore improve the situation. However, the pressure profile resulting from gravitational stratification is in general not a simple polynomial function. Hence, the pressure jump at cell interfaces will be proportional to the reconstruction’s truncation error. Piecewise polynomial reconstructions are thus inappropriate to represent a hydrostatic equilibrium.
In the following we construct a finite volume scheme that exactly (or up to machine precision) preserves a discrete version of hydrostatic equilibrium Eq. (12). We reconstruct the equilibrium pressure within the ith cell according the hydrostatic equilibrium as follows (13)To evaluate explicitly the above integral, we need to find a reconstruction of the density and the gradient of the gravitational potential. We assume a constant density distribution within the cell, i.e., (14)Similarly, we assume the gravitational potential to be piecewise linear, i.e, linear over each staggered cell I_{i + 1 / 2} = [ x_{i},x_{i + 1} ](15)This results in a piecewise constant distribution of (∂φ/∂x)_{i + 1 / 2} over I_{i + 1 / 2}.
Now the hydrostatic pressure reconstruction (13)can be explicitly evaluated and at cell interfaces we obtain (16)
Note that this reconstruction is consistent with the central discretization of the momentum source term (11), i.e., (17)Consider now the reconstructed pressure at the left side of the interface p_{0,i}(x_{i + 1 / 2}), i.e., extrapolated from cell i, and at the right side of the interface p_{0,i + 1}(x_{i + 1 / 2}), i.e., extrapolated from cell i + 1. If we have pressure equilibrium at the interface, i.e., p_{0,i}(x_{i + 1 / 2}) = p_{0,i + 1}(x_{i + 1 / 2}), we find that (18)holds. This is the discrete hydrostatic equilibrium, which is preserved by our hydrostatic pressure reconstruction. As can be shown easily (by Taylor expansions), Eq. (18)is a spatially secondorder accurate approximation of Eq. (12).
It should be noted that Eq. (12)represents only a mechanical equilibrium. No thermal equilibrium is implied and the hydrostatic equilibrium may be physically unstable to convection, for instance. Similarly, the discrete hydrostatic equilibrium (18), which is preserved by our reconstruction, represents only a mechanical equilibrium. No assumption is made on a thermal equilibrium; that is, no explicit temperature or entropy profile has to be assumed for the hydrostatic reconstruction. Therefore, our reconstruction preserves discrete hydrostatic equilibria with arbitrary temperature or entropy stratification. This represents a substantial generalization of the reconstruction advocated by Käppeli & Mishra (2014).
2.1.2. Firstorder scheme
It is now straightforward to assemble a spatially firstorder accurate wellbalanced scheme. The density and velocity are reconstructed in a piecewise constant manner (the corresponding cell averages are used). The pressure is reconstructed with the hydrostatic reconstruction. In summary, the cell interface extrapolated variables read (19)where the p_{0,i}(x_{i ± 1 / 2}) are given by Eq. (16).
Suppose we are given initial data fulfilling the discrete equilibrium (18)and ν_{x} = 0. It is then easy to check, that the semidiscrete finite volume scheme (8)with the above reconstruction of the primitive variables, a numerical flux with property (10)and the source term discretization (11)leads to , (20)i.e., the discrete hydrostatic initial data is preserved exactly (or up to machine precision). Thus, the scheme is wellbalanced.
2.1.3. Secondorder scheme
Although the scheme derived in the previous section is capable to resolve a spatially secondorder accurate discrete hydrostatic equilibrium (Eq. (18)), any perturbation on top of the equilibrium is only resolved with spatial firstorder accuracy. Therefore a higherorder extension is desirable for practical applications. In the following, we design a spatially secondorder accurate extension of our wellbalanced scheme.
Spatial secondorder accuracy is achieved with a piecewise linear reconstruction of the primitive variables. A standard nonoscillatory piecewise linear reconstruction for some state variable q is given by (21)where Dq_{i} denotes a (limited) slope. A simple choice for the slope is the socalled generalized minmod limiter (see, e.g., Kurganov & Tadmor 2000) (22)where the minmod function is defined by (23)For θ = 1 (θ = 2), this yields the traditional minmod (monotonized centered) limiter. In all numerical experiments presented below we set θ = 2. Applying the standard reconstruction (21)and (22)to density, velocity and pressure results in spatially secondorder accurate interface values.
However, a standard piecewise linear reconstruction of the pressure will not preserve the discrete hydrostatic equilibrium (18). To design an equilibrium preserving pressure reconstruction within the ith cell p_{i}(x), we decompose it into an equilibrium p_{0,i}(x) and a perturbation p_{1,i}(x) part (Botta et al. 2004; Käppeli & Mishra 2014): (24)We stress that the perturbation part is not assumed to be small. The equilibrium pressure reconstruction p_{0,i}(x) is simply given by Eq. (13). Note that no special equilibrium preserving reconstruction needs to be applied to the density, on account of the assumed piecewise constant equilibrium distribution (14).
The data for the reconstruction of the pressure perturbation p_{1,i}(x) is obtained by extrapolating the equilibrium pressure reconstruction p_{0,i}(x) of the ith cell to the neighboring cells i − 1 and i + 1: (25)where the equilibrium pressure reconstruction p_{0,i}(x) is given by Eq. (13): (26)Note that p_{1,i}(x_{i}) = p_{i} − p_{0,i}(x_{i}) = 0 holds, i.e., the equilibrium reconstruction equals the cell average p_{i} at the cell center. Now, a piecewise linear reconstruction (21)and (22)can be applied to the pressure perturbation in a straightforward manner. The reconstruction is sketched in Fig. 1.
In summary, the cell interface extrapolated variables read (27)where p_{0,i}(x_{i ± 1 / 2}) is given by Eq. (16).
Note that if we are given data fulfilling the discrete hydrostatic equilibrium (18), then the reconstruction preserves the equilibrium exactly (or up to machine precision) since in this case the pressure perturbation vanishes by design, i.e., p_{1,i}(x) = 0. Hence, the scheme is still wellbalanced. But now, thanks to the piecewise linear reconstruction of the equilibrium perturbation, the scheme is also spatially secondorder accurate for perturbations of the equilibrium.
Fig. 1
Piecewise linear wellbalanced reconstruction of the pressure. The pressure profile (black line) within the ith cell is decomposed into an equilibrium (blue line) and a perturbation part p(x) = p_{0,i}(x) + p_{1,i}(x). The equilibrium pressure p_{0,i}(x) is simply given by Eq. (13). The point values of the perturbation are then computed at neighboring cell centers x_{i ± 1} by extrapolation of the equilibrium pressure reconstruction p_{0,i}(x_{i ± 1}). A piecewise linear monotonicity preserving reconstruction can then be applied to the pressure perturbation data, i.e., p_{1,i}(x_{i ± 1}) = p_{i ± 1} − p_{0,i}(x_{i ± 1}) and p_{1,i}(x_{i}) = 0.

Open with DEXTER
2.2. Time integration
The temporal domain is discretized into time steps Δt^{n} = t^{n + 1} − t^{n} where the superscript n labels the different time levels. The system of ordinary differential equations (ODE) (8)can then be integrated in time with a suitable explicit or implicit integrator (see, e.g., Gottlieb et al. 2001).
For instance, a fully discrete firstorder scheme results with the simple explicit Euler time integration (28)where L stands for the right hand side of Eq. (8)with the gravitational source term Eq. (11)and the spatially firstorder hydrostatic reconstruction Eq. (19).
For full secondorder accuracy, we use the secondorder strong stability preserving (SSP) RungeKutta time stepping (Gottlieb et al. 2001)
where now the spatially secondorder hydrostatic equilibrium reconstruction Eq. (27)is used.
We emphasize, that implicit time integrators could also be used. Though, for our convenience, we only present results computed with the above explicit time integrators.
2.3. Multidimensional extension
We now describe the extension of the above schemes for hydrostatic equilibrium to the multidimensional case. Unfortunately, the resulting scheme is only exact, i.e., wellbalanced, if the direction of the gravitational force is exactly aligned with one coordinate axis or the fluid has constant density. However, as we demonstrate in Sect. 3.4, the scheme also considerably improves the preservation of hydrostatic equilibrium in this suboptimal case.
For the sake of simplicity of presentation, we treat the twodimensional Cartesian case explicitly and the extension to other geometries and three dimensions is analogous. The twodimensional Euler equations with gravity in Cartesian coordinates are given by (30)with (31)and (32)The primitive variables are given by w = [ ρ,ν_{x},ν_{y},p ] ^{T}.
Space is discretized into cells or finite volumes I_{i,j} = [ x_{i−1 / 2},x_{i + 1 / 2} ] × [ y_{j−1 / 2},y_{j + 1 / 2} ] of uniform (for simplicity) size Δx = x_{i + 1 / 2}−x_{i−1 / 2} and Δy = y_{j + 1 / 2} − y_{j−1 / 2}. By integrating (30)over a cell I_{i,j} we obtain a semidiscrete scheme for the evolution of the cellaveraged conserved quantities u_{i,j}(33)where F_{i + 1 / 2,j} = ℱ(w_{i + 1 / 2 − ,j},w_{i + 1 / 2 + ,j}) and are the numerical fluxes in the respective direction and S_{i,j} is the gravity source term. The w_{i + 1 / 2 ± ,j} and w_{i,j + 1 / 2 ±} are the cell interface extrapolated primitive variables.
The discrete gravitational source term is evaluated by standard spatially secondoder accurate centered differences: (34)The hydrostatic reconstruction of Sects. 2.1.1–2.1.3 can then by applied in x and ydirection independently: (35)and (36)where the density and the velocity are reconstructed piecewise linearly in a standard way.
As in the onedimensional case, the pressure reconstruction proceeds in two steps. First the equilibrium pressure is reconstructed to cell interfaces p_{0,i,j}(x_{i ∓ 1 / 2},y_{j}) and p_{0,i,j}(x_{i},y_{j ∓ 1 / 2}) by applying Eq. (16)in a straightforward dimensionbydimension manner (37)The equilibrium perturbations at cell interface p_{1,i,j}(x_{i ∓ 1 / 2},y_{j}) and p_{1,i,j}(x_{i},y_{j ∓ 1 / 2}) are also obtained by applying the procedure outlined in Sect. 2.1.3 in a dimensionbydimension manner.
It follows from a simple calculation (analogue to the derivation of Eq. (18)), that the twodimensional equilibrium preserved by the hydrostatic reconstruction would be At first sight, the latter two expressions seem to be suitable discretizations of hydrostatic equilibrium (5)in two dimensions. However, it turns out that this is only true if a discrete curl operator applied to the righthandside of the above equations vanishes, i.e., the integrability condition for (5)is fulfilled in a discrete sense. This is in general not the case and therefore our scheme is in general not mathematically wellbalanced in the multidimensional case. However, we repeat that the scheme is wellbalanced if the direction of the gravitational force is exactly aligned with a coordinate axis.
3. Numerical tests
In this section we present a series of numerical experiments to demonstrate the applicability and performance of the proposed wellbalanced scheme. For comparison, we also present results obtained with a standard (unbalanced) base scheme, i.e., without hydrostatic reconstruction. Moreover, given the limited resolution and utility of firstorder schemes, only results obtained with the secondorder schemes are shown.
To specify a timescale on which a model reacts to perturbations of its hydrostatic equilibrium, we set the sound crossing time as (38)where c_{s} is the speed of sound and the integral has to be taken over the extent of the stationary state of interest.
In some test cases, we also quantify the accuracy of the numerically obtained solutions by computing the errors as (39)with ∥ . ∥ _{1} denotes the L_{1}norm. Here q is a selected quantity of interest (e.g., density, pressure, ...) and q^{ref} is a reference solution, i.e., the stationary state to be maintained discretely or an interpolated numerically obtained reference solution on a very fine mesh.
In all simulations presented below, we have employed a CFL number of C_{CFL} = 0.9.
3.1. Hydrostatic atmospheres
As a first numerical experiment, we consider the very simple setting of a onedimensional hydrostatic atmosphere in a constant gravitational field (40)where g is the constant gravitational acceleration. Then, the gravitational potential is a simple linear function φ(x) = gx. This type of setup is relevant for the simulation of wave propagation in stellar atmospheres (e.g., Bogdan et al. 2003; Fuchs et al. 2010).
To explicitly integrate (40)an assumption on a thermodynamic variable (e.g., entropy or temperature) profile has to be made. We consider two idealized cases: isentropic and isothermal profiles. Note that we use the scheme proposed in this paper. This has to be contrasted with the scheme of Käppeli & Mishra (2014), which could handle either the isentropic or the isothermal case at a time. Arbitrary entropy/temperature stratifications are considered in the astrophysical applications below.
For this example, we assume a monoatomic ideal gas EoS (41)where we set R = 1, c_{v} = 3R/ 2 and γ = 5 / 3.
The computational domain is set to [ 0,L ], where L = 2, and is uniformly discretized by N cells, i.e., we set the cell size Δx = L/N, the cell interfaces x_{i + 1 / 2} = Δxi, i = 0,...,N, and the cell centers x_{i} = (x_{i−1 / 2} + x_{i + 1 / 2}) / 2, i = 1,...,N. We choose N = 32,64,128,256,512,1024,2048 for the resolution, respectively.
The density and pressure are then initialized by solving the discrete hydrostatic equilibrium (42)numerically with a NewtonRaphson method. Here Θ is assumed to be given and stands for either specific entropy s or temperature T.
The boundaries are treated as follows. As demanded by a secondorder scheme, we specify two ghost cells at each end of the physical domain. For the density ρ, velocity ν_{x} and the thermodynamic variable Θ we apply very simple transmissive boundary conditions with zeroorder extrapolation: (43)where q = ρ,ν_{x},Θ. The pressure is extrapolated according the discrete hydrostatic equilibrium, i.e., by numerically solving Eq. (42)for the ghost cells starting from the pressure of the last cell of the physical domain.
For the isentropic atmosphere, we set the density and pressure to ρ_{0} = 1 and p_{0} = 1 at the base, i.e., at x = 0. This results in an entropy , which is put over the whole domain. The hydrostatic atmosphere is then initialized by solving numerically Eq. (42)with the EoS (41)and s_{0}. The resulting isentropic atmosphere has a sound crossing time of τ_{sound} ≈ 4.4.
Similarly for the isothermal atmosphere, we set the density and pressure to ρ_{0} = 1 and p_{0} = 1 at the base. This yields a temperature of T_{0} = p/Rρ = 1 over the whole domain. The hydrostatic atmosphere is then initialized numerically. The resulting isothermal atmosphere has a sound crossing time of τ_{sound} ≈ 3.2.
3.1.1. Wellbalanced property
We begin by numerically verifying the wellbalancing properties of the scheme. To this end we evolve the isentropic and isothermal atmospheres with the wellbalanced and a standard secondorder scheme for two sound crossing times, i.e., t_{f} = 2τ_{sound}. At the end of the simulation, we compute the L_{1}norm of the difference (39)between the initial and the final state. This reflects how well a discrete hydrostatic state can be preserved by the corresponding scheme.
The results for the isentropic and isothermal atmospheres are shown in Fig. 2 for the pressure. The results for the density are similar and are not displayed. From the figure it is clear that the wellbalanced scheme is able to maintain the discrete equilibrium up to machine precision. The standard scheme is not able to preserve the discrete hydrostatic equilibrium exactly. The committed error is proportional to the scheme’s truncation error, which scales as a certain power l of the mesh width Δx^{l}.
From the figure, it appears that the standard scheme converges to the discrete hydrostatic atmosphere, i.e., the initial state, with roughly the third power of the mesh width. At first sight, this superconvergence may seem surprising since the schemes are only of secondorder accuracy. However, such a superconvergence has been observed before and has been attributed to the fact that the base scheme may be asymptotically high order, i.e, it has a higher order of accuracy at a steady state, compared to its designed order of accuracy, see Fjordholm et al. (2011).
Fig. 2
L_{1}norm of the difference between the initial and final pressure for the isentropic (solid and dashed blue lines) and isothermal (solid and dashed red lines) atmospheres. The solid and dashed lines represent the simulation performed with the standard and the wellbalanced (WB) schemes, respectively. The apparent thirdorder superconvergence of the standard scheme is explained in the text.

Open with DEXTER
3.1.2. Wave propagation
Next we test the ability of the wellbalanced and the standard schemes to propagate waves on top of the hydrostatic atmospheres. For brevity, only the results for the isentropic atmosphere are shown. The results for the isothermal atmosphere are analog. We impose a periodic velocity perturbation at the bottom of the atmosphere where m = −1,0 is the boundary cell index. The amplitude A is varied in order to compare the ability of the schemes for the propagation of small (A = 10^{8}), intermediate (A = 10^{6}) and large (A = 10^{1}) waves. The simulation is stopped at t_{f} = 1.8, shortly before the waves reach the upper boundary.
The errors in velocity for the standard and wellbalanced schemes are shown in Fig. 3. The errors were computed on the basis of a reference solution obtained with the wellbalanced scheme at high resolution (N = 8192).
For the small amplitude A = 10^{8} case, we observe the superiority of the wellbalanced (dashed blue) versus the standard (solid blue) scheme, i.e., the error is orders of magnitude smaller. The wellbalanced scheme shows a rough secondorder convergence. Although way off, the standard schemes seems to show thirdorder convergence. However, this is related to the superconvergence already mentioned in Sect. 3.1.1. Figure 4 shows the velocity profile for the standard (solid red) and the wellbalanced (dashed red) schemes for N = 512, together with the reference solution (solid blue). The wellbalanced scheme is able to resolve the wave pattern very accurately. On the other hand, the standard scheme shows spurious deviations because of its inability to properly resolve the hydrostatic background.
Fig. 3
L_{1}norm error between the numerical and reference (N = 8192) velocity for the isentropic atmosphere. The blue, red and green line correspond to the wave amplitudes A = 10^{8},10^{6},10^{1}, respectively. The solid and dashed lines represent the simulation performed with the standard and the wellbalanced (WB) schemes, respectively.

Open with DEXTER
For the large amplitude (A = 10^{1}) case, the standard and the wellbalanced schemes do equally well. Both show a rate of convergence close to one. This has to be expected, because the large amplitude waves quickly steepen into sawtooth waves, propagating up the atmosphere. The velocity profile for both schemes and the reference solution are shown in Fig. 4. This case shows, that the wellbalanced reconstruction does not destroy the shockcapturing properties of the base scheme.
The intermediate amplitude (A = 10^{6}) case is interesting. At low resolutions (≤128), the wellbalanced scheme is clearly superior. In this regime, the standard scheme shows superconvergence with roughly order three. This is the regime, where the committed error is dominated by the hydrostatic atmosphere, while the wave pattern is totally unresolved. At higher resolutions (>128), the committed error is dominated by the wave pattern and the expected secondorder accuracy is recovered. The wellbalanced scheme shows a rate of convergence of roughly two over the full resolution range.
Fig. 4
Velocity profile for the small (left) and large (right) amplitude waves running down the isentropic atmosphere. The solid/dashed red lines are the solutions obtained with the standard/wellbalanced scheme with N = 512, respectively. In solid blue is also shown a reference solution obtained with the wellbalanced scheme and N = 8192.

Open with DEXTER
Characteristic data for the toy corecollapse model.
3.2. Toy model of corecollapse
We consider a toy model of corecollapse supernova from Janka et al. (1993). This test simulates in spherical symmetry the collapse, bounce, evolution of the induced shock waves and formation of a protoneutron star (PNS) for a simplified model of a stellar core and EoS. The forming PNS is nearly in hydrostatic equilibrium as it evolves very slowly on a timescale, very much longer compared to the hydrostatic timescale (Gρ)^{− 1 / 2}. Since the PNS is the result of a very dynamic process, it is interesting to investigate how accurately the wellbalanced scheme captures the resulting near equilibrium state. Moreover, the problem also tests the robustness of the scheme with nonideal EoS and strong shocks. Note that the gravitational potential is dictated by selfgravity in this test.
The initial configuration is an equilibrium polytrope with polytropic index n = 3 (corresponding to a polytropic γ = 4 / 3), polytropic constant K = 4.897 × 10^{14} (in cgs units) and a central density ρ_{c} = 10^{10}g / cm^{3}. This corresponds to a total mass of M ≈ 1.44 M_{⊙} and a radius R ≈ 1.54 × 10^{3} km.
The EoS is simple, analytic and consists of a purely polytropic part and a thermal part. The total pressure and internal energy density are given by where the subscripts refer to the respective part.
The polytropic part is given by (46)The nuclear density parameter ρ_{nuc} marks the separation from the low density (i.e., subnuclear) regime with polytropic constant K_{1} and exponent γ_{1} and the high density (i.e., supranuclear) regime with polytropic constant K_{2} and exponent γ_{2}. The polytropic internal energy density is given by (47)where E_{1}, E_{2} and E_{3} are constants. The constants follow from requiring continuity of pressure and internal energy at ρ_{nuc} once the parameters ρ_{nuc}, K_{1}, γ_{1} and γ_{2} have been fixed: For the polytropic constant we have used K_{1} = 4.897 × 10^{14}cgs, i.e., the same value as for computing the equilibrium polytrope. For the subnuclear density regime we set the polytropic exponent to γ_{1} = 1.325. This is slightly smaller than the equilibrium configuration and leads to the collapse of the polytrope. For supranuclear densities we set the polytropic exponent to γ_{2} = 2.5. This mimics the stiffening of the EoS due to repulsive nuclear forces and nucleon degeneracy.
The thermal pressure p_{th} is related to the thermal internal energy density (ρe)_{th} through an ideal gas relation with ratio of specific heats γ_{th}(48)The thermal internal energy density is computed by subtracting the polytropic internal energy density from the total one (49)We use the value γ_{th} = 1.5 corresponding to a mixture of relativistic and nonrelativistic gases. For further details we refer to Janka et al. (1993).
The polytrope is then set up on the radial domain [ 0,1.5 × 10^{3} ]km and discretized by N = 128,256,512,1024,8192 cells with an exponentially growing cell spacing Δr_{i} = a^{i − 1}Δr_{1}, i = 2,...,N. Here a ≥ 1 is the grid scaling parameter and Δr_{1} the size of the first cell. See Table 1 for their resolution dependent values. For the inner boundary we use reflective conditions. On the outer boundary we use zerothorder extrapolation. This avoids the use of an artificial atmosphere (the polytrope has a finite radius), but allows for matter in or outflow. However, we stop the simulation before any significant matter outflow due to the explosion takes place.
We then evolved numerically the polytrope with the standard and the new wellbalanced secondorder schemes for all the resolutions from t = 0 up to t = 110ms. The polytrope starts to collapse due to the pressure deficit stemming from the lowering of the EoS’s polytropic exponent from 4 / 3 to 1.325. This collapse goes on until the central density exceeds ρ_{nuc}, where the EoS stiffens. This allows the socalled inner core, i.e., the inner part that collapses subsonically, to progressively halt the collapse and, eventually, to find a new equilibrium configuration, i.e., the PNS. Starting at the center of the inner core, where the density is largest, successive mass shells are gradually stopped. Pressure waves move out in radius and accumulate near the sonic point, i.e., the point where the collapse velocity equals the sound velocity, where they steepen into a shock wave. Due to its inertia, the inner core overshoots its equilibrium and rebounds behind the shock wave. This is the socalled core bounce. In the following we define the time of bounce as the time when the average density within the innermost 2km reaches its maximum.
Fig. 5
Central density as a function of time for the standard (left panel) and the wellbalanced (right panel) scheme. In both panels the (blue) dashed, (red) dashdotted, (green) dotted and the (black) solid line represent the simulation with N = 128,256,512,8192, respectively.

Open with DEXTER
Fig. 6
Density as a function of radius for the standard and wellbalanced schemes with N = 256 (left panel) and N = 512 (right panel). In both panels the (black) solid, (blue) dashed and the (red) dashdotted line represent the reference solution (the wellbalanced with N = 8192 in both panels), the solutions computed with standard and the wellbalanced scheme, respectively. For both resolution, the wellbalanced solutions are indistinguishable from the reference.

Open with DEXTER
The bounce of the inner core generates outward directed velocities at and somewhat below the shock. An explosion shock is born. Schematically, the explosion shock is launched and energized by the rebounding inner core “piston” thereby gravitationally unbinding a substantial amount of mass. With the chosen parameters, the toy model of corecollapse always results in a formidable explosion.
In Table 1 we have compiled the time and the density at bounce for the standard and wellbalanced schemes. The simulations with N = 8192, giving a central resolution of 25m, serve as references. Regarding the time of bounce, we observe that all the simulations give results that differs from each other only by a few tenths of ms. Similarly, the bounce density is also somewhat scattered around 3.6 × 10^{14}g / cm^{3}. But nevertheless, we observe a slight trend that the wellbalanced scheme seems to bounce slightly later.
The PNS is slowly evolving towards an equilibrium. Its hydrostatic timescale, i.e., the typical time in which an equilibrium reacts to perturbations, is very short ms. Here we define as the average density over the region where ρ ≥ ρ_{nuc}. A measure of how well a numerical scheme can resolve this nearequilibrium is given by the evolution of the central density. In Fig. 5 we show the central density as a function of time. The reference solutions (solid black lines) show that after the bounce and a few following oscillations, the central density remains nearly constant. From the figure we observe that the standard scheme has difficulties to maintain the central density at low resolutions N< 512. Even for N = 512 a slight drift is visible. On the other hand, the wellbalanced scheme resolves the equilibrium pretty well at all resolutions. The final central density is presented in Table 1. We note that the wellbalanced scheme with N = 128 slightly overestimates the final central density. For N> 128 the wellbalanced scheme is very close to the one of the reference solution. However, the standard scheme seems to need a resolution of at least N = 1024 in order to be close to the reference final central density.
Fig. 7
Energies and total energy conservation as a function of time from the standard (left) and wellbalanced (right) scheme with N = 512. In both panels, the solid (blue) line is the internal energy E_{int}, the dashed (green) line is the kinetic energy E_{kin}, the dashdotted (red) line is minus the gravitational energy −E_{grav} and the dotted (black) line is the total energy conservation ΔE.

Open with DEXTER
Integrated quantities for the toy corecollapse model at final time.
In Fig. 6 we show the density profile at final time t = 110. At this time the main shock wave, initiated during core bounce, is very close to the outer boundary. The flow below 100km is nearly hydrostatic with Mach numbers M_{S}< 0.01 at r = 100km and M_{S}< 0.001 below r = 50km. In between r = 100km and the main shock wave there are some secondary shock waves, initiated through postbounce oscillations of the PNS, running up the polytrope. In the left (right) panel are shown the solutions obtained with the standard and wellbalanced scheme with N = 256 (N = 512). In both panels the solution obtained with the wellbalanced scheme and N = 8192 serves as a reference. We note that in both panels the solutions from the wellbalanced scheme are indistinguishable from the reference solution. On the other hand, the solutions from the standard scheme gives a very inaccurate density profile for N = 256. Even for N = 512 there are still some visible deviations in the region 10 ≤ r ≤ 100km. Note that in this region the density varies by roughly four orders of magnitude. The wellbalanced scheme has no problems with these steep density variations.
In Table 2 we have compiled some integrated quantities at final time. There, E_{int}, E_{kin} and E_{grav} are the internal, kinetic and gravitational energy integrated of the whole domain, respectively. The error in total energy conservation is given by ΔE(t) = E_{tot}(t) − E_{tot}(0), where the total energy is E_{tot} = E_{int} + E_{kin} + E_{grav}. We observe that the wellbalanced scheme for N ≥ 256 results in internal and gravitational energies that lie within a few 0.1% from the reference values. Even for N = 128 the error is of the order of only ≈1−2%. On the other hand, for N = 128,256,512 the standard scheme deviates by more than 49%,16% and 4%, respectively. We note that it takes a resolution of N ≥ 1024 for the standard scheme to be as accurate as the wellbalanced scheme with N = 256. The internal and gravitational energies are captured so well by the wellbalanced scheme, because the energies are dominated by matter nearly in hydrostatic equilibrium, i.e., the PNS.
For the kinetic energy the differences between the standard and the wellbalanced scheme are less pronounced for resolutions N ≥ 512. Both schemes show errors of roughly ≈1%. But for N = 128,256 the wellbalanced scheme shows significantly less deviation from the reference value.
The superior performance of the wellbalanced scheme is also reflected in the error of total energy conservation. Again we attribute this to the fact that a large part of matter is in near hydrostatic equilibrium, which is very well captured by the wellbalanced scheme.
In Fig. 7 we display the internal, kinetic and gravitational energy and total energy conservation error as a function of time for both schemes at N = 512. We note especially that the energy conservation error grows steadily after bounce (t>t_{b}) for the standard scheme. The wellbalanced scheme shows a roughly constant total energy error.
We have also computed the total explosion energy and ejected mass for both schemes and all resolutions. We define the total explosion energy as the weighted energy integral over the computational domain (50)where e_{tot} = e + v^{2}/ 2 + φ is the total specific energy and the weighting function is (51)Similarly we define the total ejected mass as (52)These numbers for all the simulations at final time are given in Table 2. There we see that the two schemes do roughly equally well.
Fig. 8
Spherically averaged profiles at initial time of the stellar convection simulation. Left panel: density (solid line) and pressure (dashed line). Right panel: temperature (solid line) and specific entropy (dashed line). The dotted lines represent the original profiles from the onedimensional stellar evolution code. The red region is where the energy source term is nonzero.

Open with DEXTER
3.3. Threedimensional stellar convection
Next we consider a simplified model for convective carbon shell burning in a massive star. In recent years, the multidimensional simulation of certain phases of stellar evolution has attracted considerable attention, see, e.g., Arnett & Meakin (2011), Brun & Palacios (2009), Meakin & Arnett (2007, 2006), Viallet et al. (2011), Woodward et al. (2013) and references therein. As the convective motions are realized on top of a hydrostatic state, we believe that wellbalanced schemes are ideally suited for simulating such configurations. However, given the numerical focus of this paper we apply considerable simplifications to the physical modeling for the sake of presentation.
We consider a 20 M_{⊙} star with Z = 0.02 metallicity stemming from a stellar evolution NuGrid data set (Pignatari et al. 2013; Pignatari 2014, priv. comm.). Carbon shell burning ignites when the star is ~8.9 × 10^{6} yr from the zeroage main sequence and lasts for ~15 yr. Around that time, the star shows the typical onion skin structure. The carbon shell overlies an oxygenneon core and underlies helium and hydrogen burning shells.
As the computational domain we choose a spherical wedge embedded in the equatorial plane. The radial extent is set to r ∈ [ 5′000,40′000 ] km, which encompasses the convective carbon burning region and parts of the stably stratified oxygenneon core below and carbon shell above. In azimuthal and polar direction we set ϕ ∈ [ 0,π/ 3 ] rad and θ ∈ [ π/ 3,2π/ 3 ] rad, respectively. The boundaries in radial direction are reflecting, i.e., solid wall boundary conditions, and the azimuthal and polar directions are periodic.
We use the stellar EoS thoroughly described in Timmes & Swesty (2000), which includes contributions of (photon) radiation, nuclei, electrons and positrons. The radiation is treated as a blackbody in local thermodynamic equilibrium and the nuclei are modeled by an ideal gas. The electrons and positrons are treated in a tabular manner together with a thermodynamically consistent interpolation procedure. We use the publicly available version of this EoS, Timmes (2013).
Fig. 9
Spherically averaged profiles at the end of the simulation for the resolution N_{r} = 128. In each panel, the black lines are the initial profiles, the blue lines were computed with the standard scheme and the red lines with the wellbalanced scheme. Left panel: density (solid lines) and pressure (dashed lines) profiles. Right panel: temperature (solid lines) and specific entropy (dashed lines) profiles. Note that the initial profiles are nearly indistinguishable from the wellbalanced profiles at final time.

Open with DEXTER
Fig. 10
Spherically averaged kinetic energy as a function of time. The left panel was computed with the standard scheme and the right one with the wellbalanced scheme, both with radial resolution N_{r} = 128.

Open with DEXTER
Instead of solving a suitable nuclear reaction network for carbon burning, we impose a constant energy release in a region at the base of the carbon shell where q = 2 × 10^{11} erg/g/s. We note that this heating rate is much stronger (~100 times) than with a nuclear reaction network. We nevertheless evolve as passively advected scalars the abundances of H^{1}, He^{4}, C^{12}, O^{16}, Ne^{20} and Si^{28} to get the pressure contributions from nuclei correctly, i.e., in addition to Eqs. (1)−(3), we evolve the following equations where i = H,He,C,O,Ne,Si. The mass fractions fulfill the constraint that their sum is equal to one. When evolving the above equations discretely this constraint is usually violated. Wellbalancing does not help to fulfill the constraint and special methods such as the Consistent Multifluid Advection (CMA) by Plewa & Müller (1999) would have to be used. But since we are not performing a detailed chemical evolution, we have ignored the constraint on the mass fractions. However, our wellbalanced scheme could be combined with the CMA method in a straightforward manner. We further ignore the effects of radiative diffusion, which may be justified by the high opacity and our short simulation time (~1 h of physical time).
We numerically evolve the threedimensional equations of hydrodynamics in spherical coordinates with a source term ρϵ added to the right handside of the energy Eq. (3). For the radial direction we have chosen two resolutions N_{r} = 64 128 corresponding to uniform cell sizes of Δr ≈ 547, 273 km, respectively. The azimuthal and polar directions are discretized by N_{ϕ} = N_{θ} = 64 cells, which corresponds to an angular cell extent of Δϕ = Δθ = π/ 192 ≈ 1.636 × 10^{2} rad.
The initial conditions are built by putting into discrete hydrostatic equilibrium the profiles from the onedimensional stellar evolution simulation. To this end, we solve for the pressure in Eq. (18)using the Timmes EoS and assuming the density, entropy, composition and gravitational potential from the stellar evolution profile. The result of this discrete hydrostatic integration is shown in Fig. 8 for the N_{r} = 128 radial resolution. In the left panel are displayed the density (solid line) and the pressure (dashed line). The right panel of the same figure displays the temperature (solid line) together with specific entropy (dashed line). In both panels, the dotted lines represent the respective quantity from the onedimensional stellar evolution profile. The region where the entropy is flat is the convective carbon burning region. The stably stratified regions below and above are the oxygenneon core and the inactive parts of the carbon shell, respectively. We observe that our initial conditions and the original stellar evolution simulation profiles are not exactly identical. However, given the change in EoS and the simplified physical modeling, we think that our initial conditions still reflect the conditions from the stellar evolution simulation, quite well. Moreover, the region where the heating source term is nonzero (mimicking nuclear burning) is shown in red. We also add a random velocity perturbation in the region r ∈ [ 1.2,2.2 ] × 10^{4} km of size 10^{3} with respect to the local sound speed. Note that we do not incorporate selfgravity and the spherically symmetric gravitational potential is left unchanged during the simulations. Since the gravity force is then exactly aligned with the radial axis, the wellbalanced pressure reconstruction is mathematically wellbalanced even in this threedimensional setting.
We then evolved the setup with the standard and the wellbalanced schemes at the two radial resolutions for 3600 s of physical time. This is indeed just a tiny fraction of the duration of the carbon shell burning phase, but nevertheless long enough to show the improvements due to the wellbalanced reconstruction. In Fig. 9 we show the spherically averaged density/pressure (left panel) and the temperature/specific entropy (right panel) at final time for the high radial resolution N_{r} = 128 (the N_{r} = 64 simulation shows the same trends and is not shown for brevity). In both panels, the blue lines stem from the standard scheme and the red ones from the wellbalanced scheme. As reference, the black lines show the initial profiles. From the left panel we observe that the wellbalanced scheme is able to maintain the hydrostatic structure very well. It is only at the composition interface between the core and the carbon shell and at the top of the carbon shell that the density/pressure slightly differs from the initial profile. The same applies to the temperature/specific entropy profiles in the right panel. The standard scheme on the other hand shows very strong deviations, especially near the boundaries. Especially the temperature and the specific entropy show some spurious features. We want to stress that the same boundary conditions have been applied to the simulations with the standard and wellbalanced schemes^{1}.
In Fig. 10 we show the spherically averaged kinetic energy as a function of radius and time for the N_{r} = 128 radial resolution. On the left (right) is shown the simulation with the standard (wellbalanced) scheme. Focusing on the wellbalanced results (right panel), we see a violent onset of convection which is triggered by the initial velocity perturbations and the initially slightly negative gradient in specific entropy. These violent initial motions flatten the entropy gradient and then settle down, reaching a steady state after roughly 1000 s. After 1500 s most of the kinetic energy is contained in the convective carbon shell, i.e., the region where the specific entropy is flat. Below the carbon shell no sizable motions are present as is expected due to the absence of convection there. Above the convective region, some wave motions are present. These waves are triggered by convective plumes overshooting into the stably stratified layers. The same applies for the wellbalanced simulation with N_{r} = 64 radial resolution (not shown).
Fig. 11
Density, temperature, electron abundance and radial velocity profiles. The black lines represent polaraveraged profiles of the innermost 250 km of a sophisticated axisymmetric simulation at time t = 250 ms post bounce. These profiles are then put into hydrostatic equilibrium and used to initialize the threedimensional simulation of the PNS. The red dots show a scatter plot of all the cells in the threedimensional domain for the resolution N = 50. Note that the red dots degenerate almost everywhere to a red line.

Open with DEXTER
The situation is very different in the left panel of Fig. 10 showing the results from the standard scheme. There, most of the kinetic energy is near the lower boundary. We attribute this again to the lack of the standard scheme to resolve (a discrete) hydrostatic equilibrium. This problem may be ameliorated by using much higher numerical resolution, which, however, is extremely costly in computational resources (especially in the threedimensional case considered here).
We observe that wellbalancing greatly improves the simulation of convective phenomena inside the evolved star considered here. Although our physical model was highly simplified, we believe that wellbalancing confers many advantages in more physically refined models.
3.4. Threedimensional protoneutron star
As a final test, we simulate the hydrostatic evolution of a PNS in threedimensional Cartesian coordinates. As mentioned in Sect. 2.3, the proposed scheme is only wellbalanced if gravity forces are aligned with one coordinate axis. This is indeed not the case here. Hence, this test assesses the performance of the scheme under suboptimal conditions.
We obtain the PNS profile from a sophisticated axisymmetric Newtonian simulation of the collapsing core of a 15 M_{⊙} progenitor. The simulation used the LattimerSwesty EoS with nuclear compressibility K = 220 MeV (LS220) and an advanced spectral leakage scheme for the approximate neutrino transport treatment. For details we refer to Perego et al. (2015). Figure 11 shows the innermost 250 km of the averaged (in polar direction) density, temperature, electron abundance and radial velocity profiles at t = 250 ms after bounce. At this time the supernova shock wave is between 110 and 170 km, which is visible in the radial velocity panel. This disparity is due to shock oscillations caused by the standing accretion shock instability. Below ≈100 km, matter is subsonically accreting onto the PNS and underneath ≈50 km, matter is nearly in hydrostatic equilibrium.
Fig. 12
Maximum density as a function of time for resolutions Δx = Δy = Δz = 2,1,0.5 km represented by the solid, dashed and dotted lines, respectively. The blue lines have been obtained with the wellbalanced scheme, while the red ones with the standard scheme. The right panel shows a closeup to distinguish the wellbalanced computations.

Open with DEXTER
The initial conditions are produced by putting into hydrostatic equilibrium the averaged (in polar direction) profiles from the axisymmetric simulation. To this end, we integrate the hydrostatic equilibrium Eq. (12)using the LS220 EoS and assuming the temperature, electron abundance and gravitational potential averaged (in polar direction) profiles from the axisymmetric simulation. The velocity is simply set to zero. These hydrostatic profiles are then mapped to our threedimensional Cartesian domain D = [ −50,50 ] ^{3} km^{3}. The red dots in Fig. 11 represent a scatter plot of the hydrostatic profiles in D. As apparent from the figure, the hydrostatic integration has barely any influence on the density structure, i.e., the configuration is indeed very close to hydrostatic equilibrium.
The threedimensional hydrostatic PNS is then evolved with the wellbalanced and the standard schemes for ≈40 ms, corresponding to twenty sound crossing times, and three different resolutions N = N_{x} = N_{y} = N_{z} = 50,100,200. The resolutions correspond to cell sizes of Δx = Δy = Δz = 2,1,0.5 km, respectively. The boundary conditions are treated in the same manner as in the hydrostatic atmospheres case, i.e., Eq. (43), but applied in a directionbydirection manner.
As a first measure on how well the numerical schemes are able to resolve the hydrostatic equilibrium, we look at the temporal evolution of the maximum density. In Fig. 12 we show the evolution of the maximum density for the different schemes and resolutions (solid, dashed and dotted blue/red lines for the resolution N = 50,100,200 and wellbalanced/ standard scheme, respectively). From the left panel of the figure it is apparent, that the standard scheme (red lines) has enormous problems to keep the density close to the initial value. Even the highest resolution with 500 m mesh size (dotted red line) shows a steady decrease by more than 1% in the maximum density. On the other hand, the wellbalanced schemes are able to hold the maximum density very well. In the right panel of Fig. 12 a closeup on the wellbalanced simulation is shown. We observe that the wellbalanced scheme is able to keep the maximum density within ≈0.2% at all resolutions.
Fig. 13
Density, temperature, electron abundance and specific entropy profiles. The solid black lines are the initial profiles and the blue/red dots are the profiles at final time for the wellbalanced/standard scheme with resolution N = 100, i.e., Δx = Δy = Δz = 1 km. Note that the wellbalanced results are nearly indistinguishable from the initial profiles.

Open with DEXTER
In Fig. 13 we show the density, temperature, electron abundance and specific entropy profiles at final time for the wellbalanced/standard (blue/red dots) with resolution N = 100, i.e., Δx = Δy = Δz = 1 km. As a reference the initial profiles (solid black lines) are also shown. We observe that the wellbalanced scheme is nearly indistinguishable from the reference black lines, which implies that the hydrostatic equilibrium is resolved very well. The standard scheme shows large spurious deviations. As a matter of fact, the wellbalanced scheme maintains the hydrostatic equilibrium.
Hence, we conclude that the wellbalanced scheme considerably improves the resolution of general multidimensional equilibria, even thought, it is not mathematically wellbalanced in the threedimensional test case presented here.
4. Conclusion
We have presented a secondorder wellbalanced scheme for hydrostatic equilibrium without any assumption of a thermal equilibrium. The scheme relies on a pressure reconstruction which is consistent with a spatially secondorder accurate discrete version of the underlying hydrostatic equilibrium. Given this discrete reconstruction no assumption has to be made concerning the thermal profile, such as isothermal or isentropic, of the equilibrium. The wellbalanced reconstruction is extremely simple and computationally efficient, since it is only (very) marginally more expensive than any (limited) piecewise linear reconstruction in primitive variables. The gravitational source terms are discretized with standard central differences. Therefore the scheme can be integrated in existing codes with minimal effort. Moreover, it can be implemented within both explicit and implicit time stepping schemes.
We have presented several test cases of astrophysical interest. The onedimensional tests confirm that the scheme is indeed wellbalanced and that the numerical resolution of systems close to hydrostatic equilibrium is greatly improved, particularly at coarse grid resolutions. Results for wave propagation in a hydrostatic atmosphere has shown a significant gain in accuracy with the wellbalanced scheme, i.e., several orders of magnitude for small amplitude waves. At larger wave amplitudes, the wellbalanced scheme does as well as the standard scheme. Moreover, the wellbalanced reconstruction does not deteriorate the robustness of the Godunovtype base scheme. As seen in the toy corecollapse model, the wellbalanced scheme works even when regions close to hydrostatic equilibrium and highly dynamic regions with strong shocks coexist in the simulation domain.
The two multidimensional test cases show the same gain in accuracy and even more so, in the computational efficiency, on account of using the wellbalanced reconstruction. The simulation of convective carbon shell burning has demonstrated the drastic improvement with which the wellbalanced scheme can evolve convection within a stellar environment. Even in the suboptimal case, when gravitational forces are not perfectly aligned with one grid axis, making the reconstruction not exactly wellbalanced, the wellbalanced scheme greatly increases the accuracy. This was shown in the hydrostatic protoneutron star test. The tremendous gain in computational efficiency of the wellbalanced scheme, comes from the fact that numerical resolution has only to be invested for approximating the physical phenomena of interest, rather than resolving the hydrostatic equilibrium.
Acknowledgments
The authors were supported in part by ERC STG. N 306279, SPARCCLE. The authors thank M. Pignatari and R. Hirschi for discussions concerning the simulation of stellar convection inside massive stars. Moreover we thank M. Pignatari for providing us with a profile from a NuGrid data set. R.K. also thanks the Swiss High Performance and High Productivity (HP2C) initiative under project “Supernova”. The authors acknowledge the computational resources provided by the Swiss Super Computing Center (CSCS), under the allocation grant s414, and the BRUTUS and EULER clusters of ETHZ.
References
 Arnett, W. D., & Meakin, C. 2011, ApJ, 733, 78 [NASA ADS] [CrossRef] [Google Scholar]
 Audusse, E., Bouchut, F., Bristeau, M.O., Klein, R., & Perthame, B. 2004, SIAM J. Sci. Comput., 25, 2050 [CrossRef] [MathSciNet] [Google Scholar]
 Batten, P., Clarke, N., Lambert, C., & Causon, D. M. 1997, SIAM J. Sci. Comput., 18, 1553 [CrossRef] [Google Scholar]
 Bogdan, T. J., Carlsson, M., Hansteen, V. H., et al. 2003, ApJ, 599, 626 [NASA ADS] [CrossRef] [Google Scholar]
 Botta, N., Klein, R., Langenberg, S., & Lützenkirchen, S. 2004, J. Comput. Phys., 196, 539 [NASA ADS] [CrossRef] [Google Scholar]
 Brun, A. S., & Palacios, A. 2009, ApJ, 702, 1078 [NASA ADS] [CrossRef] [Google Scholar]
 Chandrashekar, P., & Klingenberg, C. 2015, SIAM J. Sci. Comput., 37, 82 [CrossRef] [Google Scholar]
 Colella, P., & Woodward, P. R. 1984, J. Comput. Phys., 54, 174 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Dedner, A., Kröner, D., Sofronov, I., & Wesenberg, M. 2001, J. Comput. Phys., 171, 448 [NASA ADS] [CrossRef] [Google Scholar]
 Desveaux, V., Zenk, M., Berthon, C., & Klingenberg, C. 2014, Springer Proceedings in Mathematics & Statistics, 77, 217 [CrossRef] [Google Scholar]
 Fjordholm, U. S., Mishra, S., & Tadmor, E. 2011, J. Comput. Phys., 230, 5587 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Freytag, B., Steffen, M., Ludwig, H.G., et al. 2012, J. Comput. Phys., 231, 919 [NASA ADS] [CrossRef] [Google Scholar]
 Fuchs, F., McMurry, A., Mishra, S., Risebro, N., & Waagan, K. 2010, J. Comput. Phys., 229, 4033 [NASA ADS] [CrossRef] [Google Scholar]
 Godunov, S. K. 1959, Mat. Sb. (N.S.), 47 (89), 271 [Google Scholar]
 Gottlieb, S., Shu, C.W., & Tadmor, E. 2001, SIAM Rev., 43, 89 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Greenberg, J., & Leroux, A. 1996, SIAM J. Num. Anal., 33, 1 [CrossRef] [EDP Sciences] [MathSciNet] [Google Scholar]
 Janka, H.T., Zwerger, T., & Moenchmeyer, R. 1993, A&A, 268, 360 [NASA ADS] [Google Scholar]
 Käppeli, R., & Mishra, S. 2014, J. Comput. Phys., 259, 199 [NASA ADS] [CrossRef] [Google Scholar]
 Käppeli, R., Whitehouse, S. C., Scheidegger, S., Pen, U.L., & Liebendörfer, M. 2011, ApJS, 195, 20 [NASA ADS] [CrossRef] [Google Scholar]
 Kurganov, A., & Tadmor, E. 2000, J. Comput. Phys., 160, 241 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Laney, C. B. 1998, Computational Gasdynamics (Cambridge University Press) [Google Scholar]
 Lefloch, P. G., & Thanh, M. D. 2003, Commun. Math. Sci., 1, 763 [CrossRef] [MathSciNet] [Google Scholar]
 LeVeque, R. J. 1998, J. Comput. Phys., 146, 346 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 LeVeque, R. J. 2002, Finite Volume Methods for Hyperbolic Problems, Cambridge Texts in Applied Mathematics, 1st edn. (Cambridge University Press) [Google Scholar]
 LeVeque, R. 2011, J. Sci. Comput., 48, 209 [CrossRef] [Google Scholar]
 Li, G., & Xing, Y. 2015, J. Sci. Comput., DOI: 10.1007/s1091501500935 [Google Scholar]
 Meakin, C. A., & Arnett, D. 2006, ApJ, 637, L53 [NASA ADS] [CrossRef] [Google Scholar]
 Meakin, C. A., & Arnett, D. 2007, ApJ, 667, 448 [NASA ADS] [CrossRef] [Google Scholar]
 Mellema, G., Eulderink, F., & Icke, V. 1991, A&A, 252, 718 [NASA ADS] [Google Scholar]
 Perego, A., Cabezón, R., & Käppeli, R. 2015, ArXiv eprints [arXiv:1511.08519] [Google Scholar]
 Pignatari, M., Herwig, F., Hirschi, R., et al. 2013, ApJS, submitted [arXiv:1307.6961] [Google Scholar]
 Plewa, T., & Müller, E. 1999, A&A, 342, 179 [NASA ADS] [Google Scholar]
 Roe, P. L. 1981, J. Comput. Phys., 43, 357 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Timmes, F. X. 2013, http://cococubed.asu.edu/code_pages/eos.shtml [Google Scholar]
 Timmes, F. X., & Swesty, F. D. 2000, ApJS, 126, 501 [NASA ADS] [CrossRef] [Google Scholar]
 Toro, E. F. 1997, Riemann Solvers and Numerical Methods for Fluid Dynamics. A Practical Introduction (SpringerVerlag GmbH) [Google Scholar]
 Toro, E. F., Spruce, M., & Speares, W. 1994, Shock Waves, 4, 25 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 van Leer, B. 1979, J. Comput. Phys., 32, 101 [NASA ADS] [CrossRef] [Google Scholar]
 Viallet, M., Baraffe, I., & Walder, R. 2011, A&A, 531, A86 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Woodward, P. R., Herwig, F., & Lin, P.H. 2013, ApJ, submitted [arXiv:1307.3821] [Google Scholar]
 Xing, Y., & Shu, C.W. 2013, J. Sci. Comput., 54, 645 [CrossRef] [Google Scholar]
 Zingale, M., Dursi, L. J., ZuHone, J., et al. 2002, ApJS, 143, 539 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Nonuniform mesh
Here we list a few expressions for the case of a nonuniform mesh. Only onedimensional expressions are given and the multidimensional ones follow easily. The gravity source (11)then reads (A.1)where the gradient of the gravitational potential is computed as (A.2)with the weights given by (A.3)\newpageThe discrete hydrostatic pressure reconstruction to cell interfaces reads (A.4)The hydrostatic equilibrium, which is preserved by this reconstruction, follows then immediately as in Sect. 2.1.1.
All Tables
All Figures
Fig. 1
Piecewise linear wellbalanced reconstruction of the pressure. The pressure profile (black line) within the ith cell is decomposed into an equilibrium (blue line) and a perturbation part p(x) = p_{0,i}(x) + p_{1,i}(x). The equilibrium pressure p_{0,i}(x) is simply given by Eq. (13). The point values of the perturbation are then computed at neighboring cell centers x_{i ± 1} by extrapolation of the equilibrium pressure reconstruction p_{0,i}(x_{i ± 1}). A piecewise linear monotonicity preserving reconstruction can then be applied to the pressure perturbation data, i.e., p_{1,i}(x_{i ± 1}) = p_{i ± 1} − p_{0,i}(x_{i ± 1}) and p_{1,i}(x_{i}) = 0.

Open with DEXTER
In the text
Fig. 2
L_{1}norm of the difference between the initial and final pressure for the isentropic (solid and dashed blue lines) and isothermal (solid and dashed red lines) atmospheres. The solid and dashed lines represent the simulation performed with the standard and the wellbalanced (WB) schemes, respectively. The apparent thirdorder superconvergence of the standard scheme is explained in the text.

Open with DEXTER
In the text
Fig. 3
L_{1}norm error between the numerical and reference (N = 8192) velocity for the isentropic atmosphere. The blue, red and green line correspond to the wave amplitudes A = 10^{8},10^{6},10^{1}, respectively. The solid and dashed lines represent the simulation performed with the standard and the wellbalanced (WB) schemes, respectively.

Open with DEXTER
In the text
Fig. 4
Velocity profile for the small (left) and large (right) amplitude waves running down the isentropic atmosphere. The solid/dashed red lines are the solutions obtained with the standard/wellbalanced scheme with N = 512, respectively. In solid blue is also shown a reference solution obtained with the wellbalanced scheme and N = 8192.

Open with DEXTER
In the text
Fig. 5
Central density as a function of time for the standard (left panel) and the wellbalanced (right panel) scheme. In both panels the (blue) dashed, (red) dashdotted, (green) dotted and the (black) solid line represent the simulation with N = 128,256,512,8192, respectively.

Open with DEXTER
In the text
Fig. 6
Density as a function of radius for the standard and wellbalanced schemes with N = 256 (left panel) and N = 512 (right panel). In both panels the (black) solid, (blue) dashed and the (red) dashdotted line represent the reference solution (the wellbalanced with N = 8192 in both panels), the solutions computed with standard and the wellbalanced scheme, respectively. For both resolution, the wellbalanced solutions are indistinguishable from the reference.

Open with DEXTER
In the text
Fig. 7
Energies and total energy conservation as a function of time from the standard (left) and wellbalanced (right) scheme with N = 512. In both panels, the solid (blue) line is the internal energy E_{int}, the dashed (green) line is the kinetic energy E_{kin}, the dashdotted (red) line is minus the gravitational energy −E_{grav} and the dotted (black) line is the total energy conservation ΔE.

Open with DEXTER
In the text
Fig. 8
Spherically averaged profiles at initial time of the stellar convection simulation. Left panel: density (solid line) and pressure (dashed line). Right panel: temperature (solid line) and specific entropy (dashed line). The dotted lines represent the original profiles from the onedimensional stellar evolution code. The red region is where the energy source term is nonzero.

Open with DEXTER
In the text
Fig. 9
Spherically averaged profiles at the end of the simulation for the resolution N_{r} = 128. In each panel, the black lines are the initial profiles, the blue lines were computed with the standard scheme and the red lines with the wellbalanced scheme. Left panel: density (solid lines) and pressure (dashed lines) profiles. Right panel: temperature (solid lines) and specific entropy (dashed lines) profiles. Note that the initial profiles are nearly indistinguishable from the wellbalanced profiles at final time.

Open with DEXTER
In the text
Fig. 10
Spherically averaged kinetic energy as a function of time. The left panel was computed with the standard scheme and the right one with the wellbalanced scheme, both with radial resolution N_{r} = 128.

Open with DEXTER
In the text
Fig. 11
Density, temperature, electron abundance and radial velocity profiles. The black lines represent polaraveraged profiles of the innermost 250 km of a sophisticated axisymmetric simulation at time t = 250 ms post bounce. These profiles are then put into hydrostatic equilibrium and used to initialize the threedimensional simulation of the PNS. The red dots show a scatter plot of all the cells in the threedimensional domain for the resolution N = 50. Note that the red dots degenerate almost everywhere to a red line.

Open with DEXTER
In the text
Fig. 12
Maximum density as a function of time for resolutions Δx = Δy = Δz = 2,1,0.5 km represented by the solid, dashed and dotted lines, respectively. The blue lines have been obtained with the wellbalanced scheme, while the red ones with the standard scheme. The right panel shows a closeup to distinguish the wellbalanced computations.

Open with DEXTER
In the text
Fig. 13
Density, temperature, electron abundance and specific entropy profiles. The solid black lines are the initial profiles and the blue/red dots are the profiles at final time for the wellbalanced/standard scheme with resolution N = 100, i.e., Δx = Δy = Δz = 1 km. Note that the wellbalanced results are nearly indistinguishable from the initial profiles.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
