Issue
A&A
Volume 579, July 2015



Article Number  A49
Number of page(s)  19
Section  Stellar structure and evolution
DOI  https://doi.org/10.1051/00046361/201526019
Published online  26 June 2015
Testing eccentricity pumping mechanisms to model eccentric longperiod sdB binaries with MESA^{⋆}
^{1}
Instituut voor Sterrenkunde, KU Leuven,
Celestijnenlaan 200D,
3001
Leuven,
Belgium
email: joris.vos@ster.kuleuven.be
^{2}
ArgelanderInstitut für Astronomie, Universität Bonn Auf dem Hügel
71, 53121
Bonn,
Germany
Received:
4
March
2015
Accepted:
12
May
2015
Context. Hot subdwarfB stars in longperiod binaries are found to be on eccentric orbits, even though current binaryevolution theory predicts these objects to be circularised before the onset of Rochelobe overflow (RLOF).
Aims. We aim to find binaryevolution mechanisms that can explain these eccentric longperiod orbits, and reproduce the currently observed periodeccentricity diagram.
Methods. Three different processes are considered; tidallyenhanced wind massloss, phasedependent RLOF on eccentric orbits and the interaction between a circumbinary disk and the binary. The binary module of the stellarevolution code Modules for Experiments in Stellar Astrophysics (MESA) is extended to include the eccentricitypumping processes. The effects of different input parameters on the final period and eccentricity of a binaryevolution model are tested with MESA.
Results. The end products of models with only tidallyenhanced wind massloss can indeed be eccentric, but these models need to lose too much mass, and invariably end up with a helium white dwarf that is too light to ignite helium. Within the tested parameter space, no sdBs in eccentric systems are formed. Phasedependent RLOF can reintroduce eccentricity during RLOF, and could help to populate the shortperiod part of the periodeccentricity diagram. When phasedependent RLOF is combined with eccentricity pumping via a circumbinary disk, the higher eccentricities can be reached as well. A remaining problem is that these models favour a distribution of higher eccentricities at lower periods, while the observed systems show the opposite.
Conclusions. The models presented here are potentially capable of explaining the periodeccentricity distribution of longperiod sdB binaries, but further theoretical work on the physical mechanisms is necessary.
Key words: binaries: general / stars: evolution / subdwarfs / methods: numerical
Appendix A is available in electronic form at http://www.aanda.org
© ESO, 2015
1. Introduction
Hot subdwarfB (sdB) stars are coreheliumburning stars with a very thin hydrogen envelope (M_{H}< 0.02 M_{⊙}), and a mass close to the coreheliumflash mass ~0.47 M_{⊙} (Saffer et al. 1994; Brassard et al. 2001). These hot subdwarfs are found in all galactic populations, and they are the main source for the UVupturn in earlytype galaxies (Green et al. 1986; Greggio & Renzini 1990; Brown et al. 1997). Furthermore, their photospheric chemical composition is governed by diffusion processes causing strong Hedepletion and other chemical peculiarities (Heber 1998). The formation of these extremehorizontalbranch objects is still puzzling. To form an sdB star, its progenitor needs to lose its hydrogen envelope almost completely before reaching the tip of the redgiant branch (RGB), so that the core ignites while the remaining hydrogen envelope is not massive enough to sustain hydrogenshell burning. A variety of possible formation channels have been proposed. Currently, there is a consensus that sdB stars are only formed in binaries. Several evolutionary channels have been proposed where binaryinteraction physics plays a major role. Close binary systems can be formed in a commonenvelope (CE) ejection channel (Paczynski 1976), while stable Rochelobe overflow (RLOF) can produce wide sdB binaries (Han et al. 2000, 2002). An alternative formation channel forming a single sdB star is the double whitedwarf (WD) merger, where a pair of white dwarfs spiral in to form a single sdB star (Webbink 1984). The possibility of forming a single sdB after a merger with a substellar object has also been proposed (Soker 2015), but not modelled. This channel could produce sdBs with a narrow mass distribution unlike the WD mergers.
Han et al. (2002, 2003) addressed these three binaryformation mechanisms, and performed binarypopulationsynthesis (BPS) studies for two kinds of CEejection channels, two possible stable RLOF channels and the WDmerger channel. The CEejection channels produce close binaries with periods of P_{orb} = 0.1−10 d, and mainsequence (MS) or whitedwarf (WD) companions. The sdB binaries formed through stable RLOF have orbital periods ranging from 10 to 500 days, and MS companions. Chen et al. (2013) revisited the RLOF models of Han et al. (2003) with more sophisticated treatment of angularmomentum loss. When including atmospheric RLOF, these revised models can reach orbital periods as long as ~1600 d. Finally, The WDmerger channel can lead to single sdB stars with a higher mass, up to 0.65 M_{⊙}. A detailed review of hot subdwarf stars is given by Heber (2009).
Many observational studies have focused on shortperiod sdB binaries (Koen et al. 1998; Maxted et al. 2000, 2001; Heber et al. 2002; MoralesRueda et al. 2003; Napiwotzki et al. 2004; Copperwheat et al. 2011), and over 100 of these systems are currently known (Geier et al. 2011, Appendix A). These observed shortperiod sdB binaries correspond very well with the results of BPS studies. Currently, only nine longperiod sdB binaries are known (Green et al. 2001; Østensen & Van Winckel 2011, 2012; Deca et al. 2012; Barlow et al. 2012; Vos et al. 2012, 2013, 2014). Even though this is a small sample, their periodeccentricity distribution does not comply with the prediction of evolution models. All current models predict circular orbits, while seven out of nine observed systems have a significantly eccentric orbit.
This eccentricity problem is not entirely new, and a few possible solutions have been proposed, although none have been applied to the case of sdB binaries. There are three potential mechanisms that can create eccentric orbits described in the literature. Soker (2000) based on theoretical work of Eggleton (2006) proposed the mechanism of tidallyenhanced wind massloss to allow the eccentricity of the orbit to increase. In this framework, the wind massloss is increased due to the tidal influence of a companion in an eccentric orbit, and the effect is present before the system comes into contact. It reduces the tidal forces by keeping the sdB progenitor within its Roche lobe, while the phasedependent wind massloss can increase the eccentricity. This mechanism is also known as companion reinforced attrition process (CRAP). Siess et al. (2014) used this mechanism to successfully explain the orbit of the highly eccentric HeWD binary IP Eri.
A second possible mechanism is that of phasedependent mass loss during RLOF. Similar to the phasedependent mass loss in the CRAP mechanism, a varying massloss rate in a binary that is larger during periastron than apastron, can increase the eccentricity of the orbit. The difference with the previous mechanism is that it is active during RLOF. This mechanism was used by Bonačić Marinović et al. (2008), who used a model with enhanced mass loss from the asymptotic giant branch (AGB) star due to tidal interactions and a smooth transition between the wind mass loss and the RLOF mass loss regimes to explain the eccentric population of postAGB binaries.
The third method of increasing the eccentricity of binaries is by interaction of the binary with a circumbinary (CB) disk. The motivation to include this process in the context of sdB stars, is the observational finding that stable CB disks are commonly observed around evolved postAGB binaries (e.g. de Ruyter et al. 2006; Hillen et al. 2014, and references therein). The longevity of these disks are corroborated by the strong processing of the dust grains as attested by the infrared spectral dustemission features (e.g. Gielen et al. 2008, 2011) and the millimetre continuum fluxes that indicate the presence of large grains (de Ruyter et al. 2005), while interferometric techniques are needed to resolve them (see e.g. Hillen et al. 2014, and references therein). The Keplerian rotation has, so far, only been spatially resolved in two objects (Bujarrabal et al. 2005, 2015). Recent surveys of the Large and Small Magellanic Clouds (van Aarle et al. 2011; Kamath et al. 2014) show that a significant fraction of postAGB stars show the distinctive nearIR excess indicative of a stable disk. One of the results of Kamath et al. (2014, 2015) is that a significant population of postRGB stars were identified with circumstellar dust likely in a disk as well. The disk evolution will determine the infrared life time of the systems and hence the detectability. While there is ample observational evidence that disks are common in evolved binaries, we assume here that disks were also present during the RGB evolution of the sdB progenitor. Dermine et al. (2013) explored the eccentricitypumping mechanisms of CB disks in postAGB binaries, based on theoretical work and smoothparticlehydrodynamic (SPH) simulations of Artymowicz & Lubow (1994) and Lubow & Artymowicz (1996). An issue with the results of Dermine et al. (2013) is that there was a mismatch between the disk mass distributions used to derive different parts of the interaction mechanisms.
In this article we will explore these three methods to find formation channels that can explain the eccentricity of sdB binaries, using the stellar/binary evolution code MESA. In the case of CB disks that are formed during RLOF, the eccentricity pumping effect of the disk is combined with the effect of phasedependent RLOF. We do not aim to perform a binarypopulationsynthesis study, but to explore in a limited number of initial conditions, the efficiency of the different processes. Our aim is to describe the effect of the model parameters on the final period and eccentricity of the binary, and to discover which areas in the periodeccentricity diagram can be covered by the three methods.
An overview of the currently known systems is given in Sect. 2. The MESA evolution code is explained in Sect. 3. The modelling methodology is explained in Sect. 4. While the different models are presented in Sects. 5–7 for respectively the CRAP models, phasedependent RLOF models and models containing a CB disk. The obtained periodeccentricity distribution is discussed in Sect. 8, and a summary and conclusion is given in Sect. 9. A detailed overview of the binary physics used in MESA is given in Appendix A.
2. Observed periodeccentricity diagram
There are currently two wide sdB binaries with circular orbits and seven significantly eccentric systems covered in the literature. The first observed longperiod sdB binary was PG 1018−047 with a period of 760 ± 6 days and an unclear eccentricity (Deca et al. 2012). Based on new observations Deca et al. (in prep.) revised this to a period of 759 ± 3 days and an eccentricity of 0.05 ± 0.01. Barlow et al. (2012) published the orbits of two sdB systems, PG 1701+359 and PG 1449+653, the first circular and the second with an eccentricity of 0.11 ± 0.04. There is one extra circular system known, PG 1104+243 (Vos et al. 2012). Furthermore, five eccentric systems were observed with the Mercator telescope (Vos et al. 2013, 2014) using the HERMES spectrograph (Raskin et al. 2011). All known orbits are given in Table 1, while the resulting periodeccentricity diagram is shown in Fig. 1. Even though it is based on published data, this distribution has not been shown this clearly before.
Fig. 1 Observed periodeccentricity diagram of all known longperiod sdB binaries. There is a clear trend visible of higher eccentricities at higher orbital periods. See also Table 1.

Open with DEXTER
Observed periods and eccentricities of all known longperiod sdB binaries.
Of the systems with the shortest periods, two have a circular orbit (PG 1104+243, PG 1701+359) and one has a slightly eccentric orbit (PG 1018+243). Models should thus account for both circular and eccentric systems. Furthermore, there is a clear trend detected in Fig. 1 in which the eccentricity increases with increasing orbital period, ranging from e = 0.05 at P = ~750 d to e = 0.25 at P = ~1350 d.
3. MESA
Modules for Experiments in Stellar Astrophysics (MESA)^{1} is an opensource stateoftheart 1D stellarevolution code, which amongst others, includes a binary module to compute evolutionary tracks of binary stars. The stellarevolution modules of MESA are extensively described in the two instrument papers: Paxton et al. (2011, 2013). In this article we have used version 7211 of MESA. A reason to work with this evolution code is the availability as open source. Moreover, the code calculates stellar models of lowmass stars through the helium flash.
The binary module of MESA is under continuous development. We started from version 7211 and extended it with several physical processes necessary for this research. The most important of which are:

accretion of the mass lost in stellar winds. To calculate the accretion rates, the BondiHoyle formalism as described in Hurley et al. (2002) is used.

tidallyenhanced mass loss. Wind mass loss can be enhanced by the tidal influence of the companion star. The CRAP mechanism of Tout & Eggleton (1988) is used to calculate this.

phasedependent mass loss during RLOF or phasedependent mass loss through stellar winds can possibly increase the eccentricity of the orbit. The formalism of Soker (2000) and Eggleton (2006) is used to determine the change in eccentricity due to mass lost to infinity and mass accreted by the companion.

circumbinary disks. Due to Lindblad resonances, CB diskbinary interactions can change the orbital period and eccentricity. The formalism of Artymowicz & Lubow (1994) and Lubow & Artymowicz (1996) is used to calculate the CB diskbinary interaction.
A list of the processes implemented in the binary module is given in Appendix A. We limited ourselves to listing the physical processes. For the exact software implementation, we refer the reader to the opensource code, and future instrument papers. Most of the binary additions summarised above, will be added to MESA in the future. Until then, a copy of the binary module used here will be made available^{2}.
As an example of binary tracks leading to postRGB evolution, the evolutionary tracks in the HertzsprungRussell (HR) diagram for a late hot flasher and an early hot flasher are shown in panels B and C of Fig. 2.
In this article we will refer to the sdB progenitor as the masslosing star or donor star, using the subscript d. The companion is also called the accretor, even when it won’t accrete mass, using subscript a.
Fig. 2 HR diagram of the evolution of the sdB progenitor for different values of the initial period. The location of the He ignition is indicated with a red square. Panel A) P = 600 d, the donor star loses too much mass to ignite He and ends up as a cooling white dwarf (M_{d} = 0.448 M_{⊙}). Panel B) P = 650 d, a late He flasher (M_{d} = 0.456 M_{⊙}). Panel C) P = 750 d, an early He flasher (M_{d} = 0.466 M_{⊙}). Panel D) P = 800 d, The core is too massive, and the donor ignites He on the tip of the RGB (M_{d} = 0.929 M_{⊙}). See Sect. 6 for discussion.

Open with DEXTER
3.1. Stellar input parameters
As the main focus of this contribution is the study of binaryevolution processes, we will use standard parameters for the evolution of the individual stellar components. These include a standard atmospheric boundary condition at an optical depth of τ = 2/3, a mixinglength parameter of α_{MLT} = 2 and default opacity tables (OPAL type i). For the sdB progenitor we used an extended version of the standard nuclear networks to include all reactions for hydrogen and helium burning (pp_cno_extras_o18_ne22.net). The initial composition is X = 0.68, Y = 0.30 and Z = 0.02. Furthermore we used a Reimers wind on the RGB with η_{reimers} = 0.7 (Reimers 1975), and a Blöcker wind scheme on the postEHB with η_{blocker} = 0.5 (Blocker 1995). All models are calculated from the premain sequence till the WDcooling curve, with the RGB taking the longest computation time. The sdBs resulting from these standard settings do not completely reproduce the observed effective temperature or surface gravity. This has been reported before, for example by Østensen et al. (2012), Østensen (2014). We are aware of the discrepancy, but solving this is beyond the scope of this article.
4. Modelling methodology
The focus of this article is the effect of the different eccentricitypumping mechanisms on the evolution. Three methods are investigated in the following sections. Tidallyenhanced wind massloss is considered separately from the other two mechanisms. The main argument is that tidallyenhance wind massloss increases the wind mass loss so that the donor star never fills its Roche lobe. In Sect. 6 the effects of firstly phasedependent RLOF alone, and secondly phasedependent RLOF in combination with a CB disk are described (Sect. 7). As the CB disk is created from mass lost during RLOF, the eccentricitypumping effects of phasedependent RLOF will also be present when the CB diskbinary interaction starts. We do not consider the CB diskbinary interactions separately, but assume the disk is formed by mass lost in the previous phase. For the phasedependent RLOF models and the CBdisk models, a default model is used to show the evolution of several binary parameters. After which the effect of initial binary parameters and method dependent parameters are discussed. The complete range in period an eccentricity that can be covered using any of the eccentricitypumping mechanisms is discussed separately.
In the case of phasedependent RLOF, and the CB diskbinary interaction models, tidal forces will have circularised the orbit before the onset of RLOF. However, if the eccentricity is zero, the eccentricitypumping effect of phasedependent mass loss and CB diskbinary interactions will be zero as well. Therefore, we impose a lower limit on the eccentricity of 0.001. This lower limit is chosen small enough to be reasonable. This minimum eccentricity is applied in all models, also those with only tidallyenhanced wind massloss. Thus if we refer to circularised models, this effectively means models that reached the minimum eccentricity of e = 0.001.
For each eccentricitypumping method a substantial number of models with varying initial parameters and processdepending parameters are calculated. The processdependent parameters and their ranges are discussed in the separate sections. The initial binary parameters (period, eccentricity and mass of both components) are determined based on the type of systems that we want to produce. We are focusing on the longperiod sdB binaries, thus initial orbital periods vary between 500 and 900 days. The sdB progenitor mass varies between 1.0 and 1.5 M_{⊙}. While the initial companion mass varies between 0.8 and 1.45 M_{⊙}, and is always lower than the sdBprogenitor mass. Apart for the tidallyenhanced wind massloss models, all models circularise completely before the eccentricitypumping mechanisms become effective. Changing the initial eccentricity for these models then only affects the initial orbital momentum of the binary, thus changing e_{i} has a similar effect as changing the initial period.
Only a small subsection of this parameter space will result in binaries containing an sdB component. In the discussion of the effect of the processdepending parameters, only the models containing an sdB component are used. The selection criteria for sdBs are based on the stellar mass at He ignition, which has to be below 0.55 M_{⊙}. And the absence of a hydrogen burning shell. In our models, there is a clear mass gap between the sdB models, and the models that ignite He on the RGB. The latter having final masses of M_{d} ≳ 0.7 M_{⊙}, while the sdB models have final masses of M_{d} ≲ 0.49 M_{⊙}. Models that don’t ignite He are obviously not sdBs either.
5. Tidallyenhanced wind massloss
Siess et al. (2014) has modelled the longperiod eccentric system IP Eri by using tidallyenhanced wind massloss in combination with the eccentricitypumping effect of phasedependent mass loss. By increasing the wind mass loss, the radius of the donor can be kept small in comparison to its Rochelobe, thus the tidal forces that circularise the system are weaker. By using the mechanism of Tout & Eggleton (1988), the wind mass loss depends on the orbital phase, with it being stronger at periastron than apastron. This difference between the mass lost at periastron and apastron can increase the orbital eccentricity, depending on the mass ratio of the system and the fraction of the wind mass loss that is accreted by the companion.
The enhancedwindmassloss model depends on only one parameter, B_{wind}, which Tout & Eggleton (1988) estimate at B_{wind} = 10^{4} to explain the mass inversion in the preRLOF system ZHer. The windmassloss rate in function of the orbital phase θ is: (1)where R is the stellar radius and R_{L}(θ) is the Rochelobe radius at phase θ. A detailed description of the wind mass loss and accretion fractions in MESA is given in Appendix A.3. The strength of the eccentricity pumping will depend on the massloss rate, and the fraction that is accreted by the companion. We follow the model proposed by Soker (2000) to calculate the change in eccentricity: (2)where M_{d} and M_{a} are the donor and accretor mass, Ṁ_{∞} is the mass lost at phase θ to infinity, Ṁ_{acc} is the mass lost at phase θ accreted by the companion and e is the eccentricity. Mass lost to infinity increases the eccentricity. Mass that is accreted, drives a change in eccentricity that is positive only if the donor mass is lower than the accretor mass. See Appendix A.4 for a detailed description of this mechanism.
Fig. 3 Eccentricity in function of donor mass for models with different values for windenhancement parameter B_{wind}: 100 (solid blue), 5000 (dashed red) and 10 000 (dotdashed green). The initial period is 600 days, and the initial donor and companion masses are 1.2 + 0.8 M_{⊙}. For discussion see Sect. 5.

Open with DEXTER
In Fig. 3, the eccentricity as a function of the mass of the donor star is plotted for a binary model with initial period of 600 days, a donor mass and companion mass of 1.2 and 0.8 M_{⊙}, and different values of B_{wind}: 100, 5000 and 10 000. As it can be seen, this method can result in a significant final eccentricity of the orbit after the RGB evolution of the primary, if the enhancement parameter is sufficiently large. For the system shown in Fig. 3, the circularisation is overcome when B_{wind} ≳ 5000, while an sdB star is only formed when 10 ≲ B_{wind} ≲ 100. The maximum windmassloss rates in these systems are: Ṁ_{wind,max} = 10^{6.5}, 10^{6.2}, 10^{6.0} M_{⊙} yr^{1} for the systems with respectively B_{wind} = 100, 5000 and 10 000. For comparison, the windmassloss rate for the same system without enhancement would be Ṁ_{wind,max} = 10^{6.8} M_{⊙} yr^{1}.
When comparing all calculated models, we find that the amount of mass that the donor needs to lose to maintain an eccentric orbit is so high that the final core mass is too low for He ignition. The donor star will then end its life as a cooling HeWD on an eccentric orbit. To reach a final donor mass high enough to ignite He, the mass loss has to be lower so that the system completely circularises on the RGB. Therefore, the sdB binaries formed in this channel are all circularised. The final mass of the donor changes with the initial parameters of the system, like orbital period, donor and accretor mass, and wind accretion fraction, but none of the combinations of initial binary parameters resulted in an eccentric system containing an sdB companion. Siess et al. (2014) gives a good overview of the effect of the initial binary parameters and the windenhancement parameter on the final parameters of the binary system.
We conclude that in the parameter regime considered here, the progenitors of sdBs do not evolve with a strong enhanced mass loss on the RGB. To form an sdB by tidallyenhanced wind massloss, the enhancement of the wind needs to be small, so essentially no eccentricity pumping occurs. Furthermore, if there is a significant enhanced wind massloss, the sdB progenitor will lose its hydrogen envelope in a stellar wind, and will not undergo RLOF during its later evolution.
6. Phasedependent RLOF
When there is no strong enhanced wind mass loss during the RGB, the sdB progenitor will eventually fill its Rochelobe and start RLOF. If this mass loss happens on a slightly eccentric orbit, the massloss rate will not be constant over the orbit, and the mass loss can have an eccentricitypumping effect. The strength of the eccentricity pumping will depend on the massloss rate, and the fraction that is accreted by the companion, in the same way as in the tidallyenhancedmassloss mechanism.
6.1. Model and input parameters
In this section we will describe behaviour of the mass lost from the donor star in our study of phasedependent RLOF. This mass can be accreted by the companion star, or is lost from the system to infinity. To describe the mass lost from the system to infinity, the method of Tauris & van den Heuvel (2006) is used. A detailed description of that mechanism is given in Appendix A.2. The total mass loss from the system is subdivided in three fractions: from around the donor star (α), which carries the angular momentum of the donor; mass transferred to the vicinity of the companion through the inner Lagrange point, and lost from around the companion as a fast wind (β). This lost mass carries the angular momentum of the companion star; And through the outer Lagrange point (δ) which is modelled as a CB toroid with radius 1.25 times the binary separation (R_{toroid} = γ^{2}a, γ = 1.12, based on Pennington 1985). The actual fraction of the mass loss accreted by the companion is defined by the aforementioned fractions as: ϵ = 1−α − β − δ.
The default system has an initial period of 700 days, initial eccentricity of 0.3, an sdB progenitor mass of 1.2 M_{⊙} and a companion mass of 1.0 M_{⊙}. The companion star will be on the MS during the relevant part of the evolution, thus the radiative dissipation mechanism for the tidal energy is assumed. The sdB progenitor will be on the RGB when the tidal forces are strongest, and the dissipation mechanism is that of a convective star. Dissipation becomes radiative when the envelope is completely lost. A maximum value for the RLOF massloss rate is set at 10^{2} M_{⊙} yr^{1}, the massloss fractions are α = β = 0.35, δ = 0.30 and the location of the outer Lagrange point is R_{L2} = 1.25 a, thus γ = 1.12. The accretion fraction onto the companion star is zero in this default model. These parameters are summarised in Table 2. Only the parameters mentioned in the text are changed.
As it is not known when exactly a common envelope would start to form we assume that RLOF is stable in our models. To this end, we have capped the massloss rate during RLOF at 10^{2} M_{⊙} yr^{1} and applied an adhoc upper limit on the Rochelobe overfilling of max(R/R_{L}) = 1.25, meaning that models in which the donor star radius exceeds 1.25 ·R_{L} are discarded. The latter limit is also imposed as our physical model breaks down at high Rochelobe overfilling. It is still possible that in these circumstances a CE would form during RLOF. However, Nelemans et al. (2000) argues that if a CE would form during unstable RLOF in systems with a long orbital period, the CE would corotate with the binary, and there would be no friction between the binary and the CE, and consequently no spiralin phase. Furthermore, based on BPS studies, Clausen et al. (2012) finds that the existence of longperiod sdB systems with MS components indicates that RLOF at the tip of the RGB is stable or, otherwise, that a CE phase without spiralin does exist.
Standard parameters of the binary models.
6.2. Parameter study
6.2.1. Eccentricity evolution
The evolution of the default model is plotted in Fig. 4. There are three events indicated on the figure, a: ė_{ml}>ė_{tidal}, b: ė_{ml}<ė_{tidal} and c: log (ė_{tidal}) < − 15. Where ė_{ml} is the eccentricity pumping of the mass loss in phasedependent RLOF and ė_{tidal} is the circularisation due to stellar tides. These events indicate two phases in the periodeccentricity evolution of the binary. The time scale between these phases differs on the figure, and within one phase the time scale is linear. Underneath the figure the duration of each phase is given.

Phase a–b:
the sdB progenitor is closeto completely filling its Rochelobe(R/R_{L} = 0.97), and the mass loss rate reached 10^{3.7} M_{⊙} yr^{1}, at which point the eccentricitypumping forces are more effective than the tidal forces. Due to the increasing massloss rate, the eccentricity pumping stays stronger than the tidal forces, even though the latter increase due to further Rochelobe overfilling (maxR/R_{L} = 1.09). The eccentricity starts increasing, and reaches a value of 0.061 by the end of this phase, an increase by a factor 60 compared to the assumed minimum eccentricity. During the massloss phase the period increases as well, from 847 to 945 days. When the star starts shrinking again, the massloss rate decreases as well as the Rochelobefilling factor, until event “b”, when the tidal forces again become higher than the eccentricity pumping (Ṁ = 10^{5.1} M_{⊙} yr^{1}, R/R_{L} = 0.85). This phase of strong mass loss only takes 415 years.

Phase b–c:
when the RLOF diminishes, the tidal forces take over, and the binary starts circularising again for another 16700 years. During this phase the sdB progenitor is contracting, thus the tidal forces are weakening. The eccentricity diminishes from 0.061 to 0.051, while the period slightly increases to 950 days. For this system, the eccentricity increased by roughly a factor 50. The evolution is plotted to the point where ė_{tidal}< 10^{15}, after which there is no more significant change in eccentricity or period.
Fig. 4 Time evolution of several binary properties during the RLOF phase. Three different events are indicated on the Xaxes, a: ė_{ml}>ė_{tidal}, b: ė_{ml}<ė_{tidal} and c: log (ė_{tidal}) < − 15. The time scale differs between the phases, but is linear withing each phase. The duration of each phase is shown under the figure. Panel A) the change in angular momentum. Panel B) mass loss through RLOF. Panel C) the tidal forces (blue) and eccentricity pumping due to mass loss (red). Panel D) the orbital eccentricity. Panel E) the orbital period. See Sect. 6.2.1 for discussion.

Open with DEXTER
6.2.2. Effect of initial period and companion mass
The effect of the initial period and companion mass is plotted in Fig. 6A. With increasing initial period, the final period of the sdB binary will increase as well, while at the same time the eccentricity decreases. A similar effect is visible when increasing the companion mass. The closer the companion mass is to the donor mass of 1.2 M_{⊙}, the larger the final orbital period, and the lower the eccentricity. We first discuss the effect of the initial binary parameters, as they clearly illustrate the effect of the orbital period on the eccentricity pumping force that is also essential in the discussion of the process dependent parameters.
Fig. 5 Comparison of three models with different values for the companion mass: 0.8 M_{⊙} (solid blue), 1.0 M_{⊙} (dashed red) and 1.15 M_{⊙} (dotdashed green). Panel A) the Rochelobe overfilling factor. Panel B) the mass loss rate during RLOF in M_{⊙} yr^{1}. Panel C) the tidal forces in log(s^{1}). Panel D) the eccentricity pumping forces in log(s^{1}). Panel E) net change in eccentricity per second. Panel F) mass ratio. Panel G) the eccentricity. Panel H) the orbital period in days. See Sect. 6 for discussion.

Open with DEXTER
To explain these effects, the evolution of several parameters for models with different companion masses of 0.8, 1.0 and 1.15 M_{⊙} are shown in Fig. 5. These parameters are plotted in function of the donor mass instead of time, so that the different models can be more easily compared. The connection between eccentricity and orbital period is found in the change in massloss rate during RLOF. If the period of the system increases, the Rochelobe overfilling is lower, varying from R/R_{L}< 1.16 for the M_{a} = 0.8 M_{⊙} system to R/R_{L}< 1.09 and 1.07 for M_{a} = 1.0 and 1.15 M_{⊙} respectively. This lower overfilling of the Roche lobe leads to a lower massloss rate and a shorter total time during which mass is lost at the maximum rate. For the models described here, the maximum massloss rate is the same, but the time during which it is sustained differs from roughly 25 years for the 0.8 M_{⊙} companion to 20 years for the 1.0 M_{⊙} companion and 15 years for the 1.15 M_{⊙} companion. The difference in time scale seems small, but is significant when the massloss rate is 10^{2} M_{⊙} yr^{1}. This diminishes the total eccentricity pumping force, even though the time during which it overpowers the tidal forces is longer for the 1.15 M_{⊙} model (~380 yr) than for the 0.8 M_{⊙} model (~200 yr). Due to the lower Rochelobe overfilling, the tidal forces will also decrease with increasing orbital period, with a factor 10 difference between the 0.8 M_{⊙} model and the 1.15 M_{⊙} model. Even so, there is a net effect of lower eccentricity enhancement for the model with the heaviest companion.
In Fig. 6 only the period and mass range of models that resulted in an sdB binary are shown. For a system with a specified donor and accretor mass, the effect of the initial period on the final mass is important. If the orbital period is too short, the mass loss will be too strong, and the donor star will lose too much mass to ignite helium, ending up on the HeWD cooling track. The lower limit on helium ignition in MESA is around 0.45 M_{⊙}, slightly depending on composition. If the initial orbital period is too high, the massloss rate during RLOF will be too low, and the donor will ignite helium on the RGB and hence no sdB is created. In Fig. 2 the HR diagram of four models with a donor and companion mass of 1.2 + 1.0 M_{⊙} and initial periods of 600, 650, 750 and 800 days are shown. The system with the lowest orbital period (panel A) ends up with a donor star mass of 0.448 M_{⊙}, this is just under the Heignition limit, and the donor star ends its evolution as a He white dwarf. The system with the 650 days initial period (panel B) ends with a donor star of 0.456 M_{⊙} and ignites helium on the HeWD cooling track, which is called a late hot flasher. With an even higher period of 750 days, the final donor mass is 0.465 M_{⊙}, and the donor ignites helium shortly after departing of the RGB, during the evolution at constant luminosity, an early hot flasher. If the period is increased further, to 800 days, the donor will be too massive, and will ignite helium on the RGB when it still has a total mass of 0.929 M_{⊙}, after which mass loss is stopped until the donor finishes coreHe burning and enters the AGB phase.
Fig. 6 Effect of the initial and mass loss parameters of the RLOF models on the final period and eccentricity of the orbit. Panel A) Models with different initial periods (indicated by the black arrows) and different companion masses: M_{a} = 0.8 (blue stars), M_{a} = 1.0 (red dots) and M_{a} = 1.15 (green squares). Panel B) Models with different mass loss fractions α and β, for two companion masses: 1.0 M_{⊙} (red circles) and 1.15 M_{⊙} (blue squares). The black arrow indicates decreasing α and increasing β, δ is constant at 0.2. The sum of the mass loss fractions is unity for each model. Panel C) Models with different mass loss fractions δ: 0.1, 0.2 and 0.3, with γ = 1.12 (red squares) and different values for γ: 0.9, 1.0, 1.2 and 1.3 with δ = 0.3 (blue dots). These models don’t have accretion, thus α = β = (1 − δ) / 2. Panel D) The effect of the accreted fraction for two companion masses and accretion fractions of 0%, 10% and 20%. M_{a} = 1.0 M_{⊙} (red circles) and M_{a} = 1.15 M_{⊙} (blue squares). See Sects. 6.2.2 and 6.2.3 for discussion.

Open with DEXTER
6.2.3. Effect of massloss fractions and accretion
The different ways to lose mass to infinity will change the final orbital parameters of the system. These parameters mainly influence the amount of angular momentum that is removed from the system with the lost mass. The effect of these massloss fractions and the location of the outer Lagrange point is shown in Figs. 6B and 6C. In Fig. 6B, models for two different companion masses 1.0 and 1.15 M_{⊙} at a constant δ = 0.2 are plotted, while changing the fractions of mass lost around the donor (α) and companion (β). There is no accretion in these models (α + β + δ = 1). When most mass is lost from around the donor the resulting period will be lower than when the mass is lost from around the companion star. This is easily explained by Eq. (A.21). The mass that is lost from around the donor star will thus carry more angular momentum with it, which will result in a shorter orbital period. This change in period will influence the change in eccentricity by altering the massloss rates during RLOF, similar as was explained in Sect. 6.2.2. From a certain threshold period that depends on the initial and massloss parameters, the eccentricity pumping is smaller than the tidal forces, and the orbits stay circularised. The effect of these two massloss parameters on the period is large, of the order of several hundred days. By changing from most mass lost around the donor to most mass lost around the companion, the final period can double.
By increasing the fraction of mass that is lost through the outer Lagrange point (δ), more angular momentum is lost than if that mass was lost from around either of the binary components. The decrease in final period with increasing δ then follows directly from Eq. (A.21). Increasing the size of the CB toroid representing the location of the outer Lagrange point (γ) has the same effect, for exactly the same reason. Figire 6C shows the effect of changing δ and γ. The models with varying δ have no accretion, thus α = β = (1 − δ)/2. The increase in the eccentricity with increasing δ and γ is directly related to the decrease in the orbital period, and thus a higher massloss rate. The two models on Fig. 6C with γ values of 1.2 and 1.3 result in binaries with very high Rochelobeoverfilling factors (R/R_{L}> 1.6). We note that our description breaks down at high Rochelobeoverfilling values, and the models in Fig. 6C with high values for γ suffer from extrapolation. The effect of γ is only given as an indication, as we keep it at 1.12 to represent the expected location of the outer Lagrange point. By changing δ by only a small amount, the final period can again change drastically, of the order of hundreds of days. Similar to the α and β fractions, there is a certain threshold for δ under which the orbit will stay circularised. The exact threshold value depends on the other parameters.
The effect of the massloss fraction accreted onto the companion (ϵ) is shown in panel D of Fig. 6. By increasing the accreted fraction, the eccentricity increases while the orbital period stays more or less constant. By accreting a certain fraction of the mass loss, the size of the Rochelobes will differ between the models. Higher accretion leads to slightly higher Rochelobe overfilling, and a slightly higher eccentricity pumping. The period during which the eccentricitypumping forces are stronger than the tidal forces also increases with increasing accretion rates. By increasing the accretion, the final eccentricity can almost be doubled, while the period remains constant.
7. Circumbinary disks
The models with phasedependent RLOF can indeed explain a certain part of the periodeccentricity diagram, but have problems in the highperiod higheccentricity range, and cannot reproduce the circular systems. Circumbinary disks could potentially explain the highperiod, higheccentricity systems as they add extra eccentricitypumping forces on top of those from phasedependent RLOF.
7.1. Model and input parameters
Circumbinary disks can form around binaries during the RLOF phase, if part of the mass can leave the system through the outer Lagrange points and form a Keplerian disk around the binary. The CB diskbinary resonant and nonresonant interactions have been described by Goldreich & Tremaine (1979) and Artymowicz & Lubow (1994), by using a linearperturbation theory. The effect of the CB diskbinary resonances on the orbital parameters has been the subject of many studies. In MESA we follow the approach outlined by Artymowicz & Lubow (1994) and Lubow & Artymowicz (1996).
The effect of the disk on the binary separation is given by: (3)where J_{D} is the angular momentum of the disk and J_{B} the orbital angular momentum of the binary. l and m are integer numbers indicating the resonance with the strongest contribution and τ_{v} is the viscous evolution time scale (where , see Eq. (A.45)). The change in eccentricity depends on the change in binary separation as: (4)for small eccentricities (e< 0.2), and decreases with 1 /e for higher eccentricities. The derivation and implementation of these equations is given in Appendix A.6.
The CB disk is described by its maximum mass (M_{disk}), the mass distribution, the inner and outer radius, relative thickness near the inner rim (H/R), the viscosity of the matter (α_{D}) and the total life time of the disk (τ). In our model, the disk is formed by matter lost from the binary through the outer Lagrange point, and the disk itself loses mass at a rate determined by its life time. The mass in the disk is not constant, and only the maximum disk mass is a defined input parameter. The model of Artymowicz & Lubow (1994) is only valid for a thin disk. Thus, H/R = 0.1 is assumed. The inner radius of the disk is determined based on SPH simulations, and the dustcondensation radius of the binary (see Eqs. (A.52)–(A.54)). Based on observations and the assumed surface density behaviour, the outer radius of the disk is fixed at 250 AU (see also Appendix A.6).
Maximum mass, life time, viscosity and distribution, are input parameters in the model. Based on observations of postAGB disks (Gielen et al. 2011; Hillen et al. 2014, 2015), following parameter ranges are assumed. The total disk mass can vary between 10^{4} and 10^{2} M_{⊙}. Disk life times after the end of RLOF range from 10^{4} to 10^{5} years. The viscosity ranges from α_{D} = 0.001− 0.1, with the more likely range being α_{D} ≤ 0.01. The surface mass distribution decreases with increasing distance from the centre: σ(r) ~ r^{D}, where −2 ≤ D ≤ −1. In the default model given in Table 2, a maximum disk mass of 10^{2} M_{⊙}, a life time of 10^{5} years, a viscosity of 0.01 and a surface distribution of σ(r) ~ r^{1} are chosen.
7.2. Parameter study
Fig. 7 Time evolution of several binary properties during the life time of the CB disk. Four different events are indicated on the xaxes. a: ė_{disk}>ė_{tidal}, b: ė_{ml}>ė_{tidal}, c: ė_{ml}<ė_{tidal} and d: ė_{disk}<ė_{tidal}. The time scale differs between the phases, but is linear within each phase. The duration of each phase is shown under the figure. Panel A) the mass in the CB disk as a percentage of the maximum CB disk mass (0.01 M_{⊙}). Panel B) the change in angular momentum due to mass loss (red dashed line) and the CB disk – binary interaction (green dashed dotted line). Panel C) the tidal forces (blue full line), eccentricity pumping due to mass loss (red dashed line) and eccentricity pumping through CB disk – binary interactions (green dashed dotted line). Panel D) the eccentricity. Panel E) the orbital period. See Sect. 7 for discussion.

Open with DEXTER
7.2.1. Eccentricity evolution
In Fig. 7 the evolution of the CB disk mass, the period and eccentricity, the change in angular momentum and the change in eccentricity are plotted in function of time. The model that is shown has the same parameters as the model shown in Fig. 4, with the addition of a CB disk with a life time of 10^{5} yr. These parameters are also given in Table 2. Four different events are indicated on the figure. a: ė_{disk} > ė_{tidal}, b: ė_{ml} > ė_{tidal}, c: ė_{ml} < ė_{tidal} and d: ė_{disk} < ė_{tidal}. These events define three different phases in the periodeccentricity evolution of the binary. On the figure, the time of each phase is linear, but the time scales between phases differ. The duration of each phase is plotted under the figure.

[Phase a–b:] mass lost from atmospheric RLOF is filling the CB disk, and the disk – binary interactions are strong enough to overcome the tidal forces, thus eccentricity starts to increase. The mass in the disk continues to grow while the donor star continues to expand, eventually filling and overfilling its Rochelobe. The tidal forces continue to increase as well, and when the CB disk reaches its maximum mass after roughly 6100 years, the tidal forces again overtake the diskbinary interaction. By this time the eccentricity of the system reached 0.016 and the period decreased from 878 to 852 days. The change in eccentricity is solely due to the diskbinary interactions, but the loss of angular momentum from the binary is caused mainly by the mass loss. During the remaining ~1000 years when ė_{disk} < ė_{tidal}, there is a negligible amount of circularisation.

[Phase b–c:] the disk reached its maximum mass, and is maintained by RLOF. Due to phasedependent mass loss, the eccentricity continues to increase. What happens in this phase is very similar to what is shown in Fig. 4. However, because the binary has a higher eccentricity than that in the model without a disk, the eccentricity pumping due to mass loss is stronger. This leads to an eccentricity of 0.146, a tenfold increase. The orbital period first decreases and then increases again, reaching 880 days. This whole phase lasts only 310 years.

[Phase c–d:] RLOF has ended, and the mass in the CB disk starts to decrease linearly. The CB diskbinary interactions continue to increase the eccentricity, while at the same time angular momentum is transported from the binary to the CB disk, thus decreasing the orbital period again. The effect of the CB diskbinary interactions diminishes due to a decrease in disk mass while simultaneously, the resonances that are responsible for the eccentricity pumping become less effective at higher eccentricities. When the disk is completely dissipated, the binary has an eccentricity of 0.245 and a period of 855 days.
We note that the transport of angular momentum from the binary to the disk will continue to take place as long as the disk lives, contrary to the change in eccentricity that has an upper limit of e ~ 0.7. However, no models we have tried reach this eccentricity limit.
Fig. 8 Effect of the CB disk and binary parameters on the final period and eccentricity of the orbit. All models are plotted for 5 different disk life times τ = 1 × 10^{4}, 2.5 × 10^{4}, 5 × 10^{4}, 7.5 × 10^{4} and 1 × 10^{5} years. Panel A) Models with two different maximum disk masses: 10^{2} M_{⊙} (blue squares) and 10^{3}M_{⊙} (red circles). Panel B) Models with a different disk viscosities: α_{D} = 0.1 (blue squares) and 0.01 (red circles). Panel C) Models with two different disk surface mass distributions: σ(r) ~ r^{2} (blue squares) and σ(r) ~ r^{1} (red circles). Panel D) Models with three different values for mass loss parameter δ: 0.1 (blue squares), 0.2 (red circles) and 0.3 (green stars). Panel E) Models with three different initial orbital periods: P_{i} = 600 d (blue squares), 650 d (red circles) and 700 d (green stars). Panel F) Models for three different companion masses: M_{a} = 0.8 M_{⊙} (red circles), 1.0 M_{⊙} (blue squares) and 1.15 M_{⊙} (green stars). See Sects. 7.2.2 and 7.2.3 for discussion.

Open with DEXTER
7.2.2. Effect of disk properties
There are four parameters in the CB disk model that can influence the CB diskbinary interactions: the maximum mass in the disk, the life time of the disk, the viscosity parameter and the assumed distribution of the mass with radius. Next to the disk parameters, the rate at which mass is fed to the disk is determined by massloss fraction δ. The effect of these five parameters is shown in Fig. 8 panels A, B, C and D. For each of maximum disk mass, viscosity, mass distribution and δ, models with five different disk life times are shown. These life times can also be interpreted as the evolution in the periodeccentricity diagram after the end of RLOF. Based on the equations that govern the CB diskbinary interaction given in Sect. A.6 the effect of each parameter can be easily explained. When the disk survives longer, the interaction with the binary will last longer, and the increase in eccentricity/decrease in period will be stronger.
By increasing the maximum disk mass as shown in panel A, the final eccentricity will be higher, while the final period will be slightly lower. The massloss rates during RLOF are high enough that there is very little difference in time to fill a disk of 0.001 M_{⊙} or 0.01 M_{⊙}. An increased disk mass will lead to a higher angular momentum of the disk, and, according to Eq. (A.44), to a higher change in binary separation and eccentricity.
The viscosity of the disk (α_{D}) shown in panel B, also has a linear effect on the change in binary separation and eccentricity (see Eq. (A.45)). A higher viscosity will lead to a higher final eccentricity and lower period.
The effect of the mass distribution in the disk is plotted in panel C. The mass distribution will determine the mass fraction that resides close to the inner rim of the disk, where it has the strongest effect on the binary. Normally a radial mass distribution of r^{1} is chosen, which takes into account that the disk is not just flat, but also has a specific thickness that varies with the radius. A distribution of r^{2} assumes that the thickness of the disk is more constant with radius. Under that assumption, there will be more mass closer to the inner rim, and the CB diskbinary interactions will be stronger, again leading to a higher eccentricity and lower period.
The rate at which mass is fed to the CBdisk is defined by massloss parameter δ. The effect of changing this parameter is shown in panel D. As the disk will reach its maximum mass earlier, the eccentricitypumping effect of the disk will slightly increase with increasing δ. However, the main effect of this parameter is a change in orbital period. As discussed in Sect. 6.2.3, increasing δ will decrease the orbital period because more angular momentum is lost. This results in higher eccentricities reached during the RLOF phase.
7.2.3. Effect of binary properties
In panels E and F of Fig. 8, the effect of several binary parameters is shown. These are also discussed in the Sect. 6.2.2 and are shown here, to indicate how strong their influence on the distribution in the periodeccentricity plane can be. It is especially the range in period space that is altered by changing initial parameters such as companion mass and initial period. Where the diskbinary interactions have an influence of roughly five per cent on the final period, changing the initial binary parameters can result in a change of several 100 days. The main influence of the CB disk is then in reaching higher eccentricities. Where the phasedependent RLOF models could reach eccentricities of maximum 0.15, the models containing a CB disk can reach eccentricities of maximum 0.34.
8. Periodeccentricity distribution
By varying the initial binary parameters described in Sect. 4 and the modeldependent parameters described in Sects. 6 and 7, a significant area of the periodeccentricity diagram can be covered. In Fig. 9, both the region covered by models with only phasedependent RLOF (red shade with solid border) and that covered by models including a CB disk (green shade with dashed border) is plotted on top of the observed systems (blue circles). The parameter ranges used to obtain this distribution are given in Table 3. As the models with only tidallyenhanced wind massloss cannot produce eccentric sdB binaries, they are not shown here. We see that by including eccentricitypumping processes during the evolution, we are able to form models with sdB primaries at wide eccentric orbits.
Fig. 9 Approximate region of the periodeccentricity diagram that can be explained by the RLOF models (red shaded region with solid border) and models containing a CB disk (green shaded region with dashed border). The observed systems are plotted in blue dots.

Open with DEXTER
Parameter ranges used to determine the periodeccentricity distribution of the phasedependent RLOF models and the CBdisk models.
From Fig. 9, we can conclude that the region covered by the models with phasedependent RLOF does not correspond with the observations. The effect of most parameters is to reduce the orbital period, while increasing the eccentricity, leading to an eccentricity pumping effect that is most efficient at short periods. At high orbital periods, the eccentricity pumping is too weak to overcome the circularisation, leading to circular orbits at periods over ~1250 days. It is thus possible to recreate the shortperiod systems with moderate eccentricity, but the highly eccentric longperiod systems cannot be reached. Another discrepancy is that the circular systems at orbital periods around 750 days cannot be reproduced either, when the eccentricitypumping effects are active. The only way to model these circular systems at low orbital periods is by turning off all eccentricitypumping mechanisms.
The models including a CB disk have a larger coverage than the models with only phasedependent RLOF. However, even the disk models cannot completely reproduce the observed systems. They suffer the same problems as the models with only phasedependent RLOF. Again, the effect of almost all parameters is to increase the eccentricity at the cost of lowering the orbital period. Even though higher periods and eccentricities can be reached, the system with the highest orbital period and eccentricity can still not be covered.
The periodeccentricity distribution of the two eccentricity pumping models seems to indicate that there is a trend of higher eccentricities at lower periods, opposite to the observed trend of higher eccentricities at higher periods. This is under the assumption that the methoddepending parameters might vary independent of each other and the initial binary parameters. However, it is not unreasonable that for example the massloss fractions (α, β and δ) depend on other binary properties like the mass ratio. Such a dependence between different parameters might indeed reproduce the observed periodeccentricity trend, but the models presented here can not prove nor disprove any such dependence.
9. Summary and conclusions
The goal of this article was to test if three eccentricitypumping mechanisms proposed in the literature, could recreate the observed periodeccentricity distribution of longperiod binaries containing a hot subdwarf B star. The three proposed mechanisms are: 1. tidallyenhanced wind massloss, 2. eccentricity pumping through phasedependent RLOF and 3. the interaction between the binary and a CB disk formed during RLOF combined with phasedependent RLOF. The tidallyenhanced wind massloss method is not combined with any of the two other methods, as the point of the enhanced wind is to prevent the donor star from filling its Roche lobe, and in that way reducing the tidal forces. This would be counterproductive in the context of phasedependent RLOF.
In this work we attempted to describe the effects of model parameters on the relationship between final period and eccentricity. Further work must be done in order to combine these models with realistic distributions of starting parameters in a binarypopulationsynthesis context.
Creating eccentric orbits with a tidallyenhancedmassloss mechanism is based on two processes. By increasing the wind mass loss, the radius of the donor star is kept well within its Roche lobe, thus reducing the tidal forces and maintaining the initial eccentricity of the orbit. The tidallyincreased wind massloss depends on the orbital phase. This phasedependent mass loss will further increase the eccentricity. The models calculated with MESA indeed lead to binaries on an eccentric orbit. However, the amount of mass that the donor star needs to lose is so large that the final mass of the donor star is lower than the minimum core mass necessary to ignite helium. All eccentric binaries formed through this channel end up as HeWDs, while all sdB stars ended on a circularised orbit as the windenhancement parameter needs to be very low.
The phasedependent RLOF mechanism is based on the same principle as the phasedependent wind mass loss. By assuming a minimal eccentricity, the massloss rate will be higher during periastron than during apastron, and the eccentricity may increase. This method can create eccentric sdB binaries over a reasonable periodeccentricity range. The maximum eccentricity tends to be around 0.15, while the period range for eccentric sdBs is 600 to 1200 days. sdB binaries with longer orbital period, reaching ~1600 days can be formed but are circularised within our parameter range. This mechanism can explain the observed systems with moderate eccentricities (0.05 <e< 0.15) on shorter orbital periods (P< 1100 d). Neither the systems with higher eccentricities, nor the circularised lowperiod systems can be formed this way.
Adding CB disks to the models with phasedependent RLOF does further increase the eccentricity of the produced binaries due to resonances between the binary and the CB disk. This binaryCB disk interaction increases the eccentricity while slightly decreasing the orbital period. These models can reach eccentricities up to 0.35 when assuming reasonable values for the disk parameters, and could potentially reach far higher eccentricities if more extreme values for maximum disk mass or surface mass distribution would be adopted. The disk model can reproduce most of the observed sdB binaries, except the circular shortperiod systems.
When the models are compared to the observed sample, it is clear that phasedependent RLOF in combination with CB disks can cover a significant part of the periodeccentricity diagram. However, there remain conflicts. The circular systems at short periods can not be formed, as well at the system with the higher period and eccentricity. Part of the discrepancy between the observed and modelled periodeccentricity diagram can be explained by insufficiently accurate models, while it is also possible that certain areas of the periodeccentricity diagram have not yet been populated due to a lack of observations.
The observed trend of higher eccentricities at higher orbital periods does not follow directly from the methoddepending parameters in the presented models. In our future research we will investigate whether certain parameters are dependent on the initial or current configuration of the binary. Such a dependence could potentially result in the observed periodeccentricity trend. However, the models presented here can neither prove nor disprove any such trend.
All three tested eccentricitypumping mechanism are derived under certain assumptions, such as isotropic mass loss for eccentricity pumping through phasedependent mass loss, or the approximation of a thin disk for the CB diskbinary interactions. Furthermore, values for several input parameters, for example the mass loss fractions (α, β and γ), are badly constrained or currently unknown, and are also likely to be functions of the system parameters such as mass ratio and companion mass rather than constants. While stable Keplerian disks are likely common in other evolved binary systems (see introduction), they are not yet documented around sdB wide binaries. We advocate here a specific search for circumstellar matter around wide sdB binaries.
In this article we have shown that we are able to form binary models with an sdB primary at wide eccentric orbits by eccentricity pumping of phasedependent RLOF and CB disks. Tidallyenhanced wind massloss is unlikely to contribute to the formation of eccentric sdBs. Small discrepancies between the observed systems and the theoretical models remain, and will need to be addressed in future work.
MESA is available on: http://mesa.sourceforge.net/
The binary module is available on: http://ster.kuleuven.be/~jorisv/MESA_binary.tar.gz
