The coronal energy input from magnetic braiding
^{1} Department of Mathematical Sciences, Durham University, Durham, DH1 3LE, UK
email: anthony.yeates@durham.ac.uk
^{2} Space Sciences Laboratory, University of California, Berkeley, CA 94720, USA
^{3} School of Mathematics and Statistics, Newcastle University, Newcastle Upon Tyne, NE1 7RU, UK
Received: 18 December 2013
Accepted: 14 March 2014
We estimate the energy input into the solar corona from photospheric footpoint motions, using observations of a plage region by the Hinode Solar Optical Telescope. Assuming a perfectly ideal coronal evolution, two alternative lower bounds for the Poynting flux are computed based on field line footpoint trajectories, without requiring horizontal magnetic field data. When applied to the observed velocities, a bound based solely on displacements between the two footpoints of each field line is tighter than a bound based on relative twist between field lines. Depending on the assumed length of coronal magnetic field lines, the higher bound is found to be reasonably tight compared with a Poynting flux estimate using an available vector magnetogram. It is also close to the energy input required to explain conductive and radiative losses in the active region corona. Based on similar analysis of a numerical convection simulation, we suggest that observations with higher spatial resolution are likely to bring the bound based on relative twist closer to the first bound, but not to increase the first bound substantially. Finally, we put an approximate upper bound on the magnetic energy by constructing a hypothetical “unrelaxed” magnetic field with the correct field line connectivity.
Key words: Sun: corona / Sun: granulation / Sun: magnetic fields / Sun: photosphere
© ESO, 2014
1. Introduction
One of the central questions in solar physics is how the Sun’s magnetic field transmits energy through the photosphere to maintain coronal temperatures in excess of a million kelvin. Currently, two broad classes of mechanism are favored: wave heating and magnetic reconnection (see, for example, the reviews by Klimchuk 2006; Reale 2010; Parnell & De Moortel 2012). Here we focus on heating by magnetic reconnection, and in particular on the magnetic braiding scenario (Parker 1972, 1983). Parker proposed that convective motions in the photosphere will shuffle the footpoints of coronal magnetic field lines, causing the field lines to become entangled, or braided. Crucially, this will lead to locally intense magnetic gradients in the corona, allowing energy to be released in many small reconnection events, now known as “nanoflares” (Parker 1988). The heating of the atmosphere is suggested to result from this continual energy release. Rather than braiding of flux tubes around one another, it is also possible for photospheric motions to inject energy by twisting individual flux tube footpoints (Sturrock & Uchida 1981; Zirker 1993), although this may be less efficient than braiding (Berger 1991). Recent studies indicate that the particular braiding pattern may have a significant effect on the resultant heating in the corona (Berger & AsgariTarghi 2009; WilmotSmith et al. 2011).
Coronal heating mechanisms must account for combined conductive and radiative losses from the active region corona of about 10^{7} erg cm^{2} s^{1} (Withbroe & Noyes 1977). To determine whether the rate of energy input by photospheric braiding motions is sufficient to supply this, consider the rate of change of magnetic energy $\mathit{W}\mathrm{=}{\mathrm{\int}}_{\mathit{V}}\frac{{\mathit{B}}^{\mathrm{2}}}{\mathrm{8}\mathit{\pi}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}$(1)in a coronal volume V, which is given by $\frac{\mathrm{d}\mathit{W}}{\mathrm{d}\mathit{t}}\mathrm{=}\mathrm{}\frac{\mathrm{1}}{\mathrm{4}\mathit{\pi}}{\mathrm{\int}}_{\mathit{V}}{E}\mathrm{\xb7}\mathrm{\nabla}\mathrm{\times}{B}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\mathrm{}\frac{\mathrm{1}}{\mathrm{4}\mathit{\pi}}{\mathrm{\U0010ff49}}_{\mathit{\partial V}}{E}\mathrm{\times}{B}\mathrm{\xb7}{n}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}\mathit{.}$(2)The first term on the righthand side of (2)represents the volume dissipation of magnetic energy in the corona, while the second is the Poynting flux through the boundary of V. We are interested in the Poynting flux through the photospheric boundary S_{0}, which may be written $\begin{array}{ccc}\frac{\mathrm{1}}{\mathrm{4}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{E}\mathrm{\times}{B}\mathrm{\xb7}{{e}}_{\mathit{z}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}& \mathrm{=}& \frac{\mathrm{1}}{\mathrm{4}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\mathit{v}}_{\mathit{z}}\mathrm{(}{\mathit{B}}_{\mathit{x}}^{\mathrm{2}}\mathrm{+}{\mathit{B}}_{\mathit{y}}^{\mathrm{2}}\mathrm{)}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}\\ & & \end{array}$(3)where we have assumed an ideal Ohm’s law E = −v × B. Determining this quantity from observations requires both vector velocity and vector magnetic field data, which remain challenging to obtain at high cadence and high resolution. Our bounds assume v_{z} = 0, so can not be applied to regions with significant flux emergence. The idea is to estimate the last term in (3)from just v_{x}, v_{y} and B_{z}, without needing to know B_{x} or B_{y}.
Our bounds assume that the coronal magnetic field evolves ideally during the braiding motions, without dissipation. As a result, if we were to move the photospheric footpoints for longer and longer times, we would accumulate more and more energy in the corona. Previous studies have used numerical magnetohydrodynamic (MHD) simulations (e.g., Mikić et al. 1989; Hendrix et al. 1996; Galsgaard & Nordlund 1996; Gudiksen & Nordlund 2002; Bingert & Peter 2011) or reducedMHD simulations (Rappazzo et al. 2008) driven by photospheric footpoint motions to determine the level at which the energy input saturates. These models suggest that the braiding process leads to heating rates comparable to that of Withbroe & Noyes (1977), although the simulations necessarily have coronal dissipation orders of magnitude too high. Our approach is intended to complement these studies by estimating the energy input by a perfectly ideal evolution.
Parker (1983) made the simple estimate that dW/dt ≈ 10^{7} erg cm^{2} s^{1} by the following argument. Start with a vertical magnetic field of strength B = 100 G between z = 0 and z = h = 100 Mm. If we displace the footpoint of a flux tube through distance vt, then the tube will gain a transverse flux density B_{h} = Bvt/h. The displacement does work against the magnetic stress BB_{h}/ (4π), so the power input will be dW/ dt = vBB_{h}/ (4π) = v^{2}B^{2}t/ (4πh). Using the speed v = 0.4 km s^{1} suggested by brightpoint observations (Smithson 1973), and an assumed time of t = 1 day for the energy buildup, a Poynting flux of 10^{7} erg cm^{2} s^{1} is obtained. Importantly, this is comparable to the input required to balance the coronal losses, lending support to the braiding scenario.
Subsequent studies have estimated the Poynting flux due to photospheric motions using various assumptions about the average properties of photospheric flows (van Ballegooijen 1986; Berger 1991, 1993; Zirker & Cleveland 1993, and the MHD models cited above). The aim of this paper is to make quantitative estimates of the Poynting flux for a specific dataset of observed photospheric velocities. We start from two rigorous lower bounds on W for a given sequence v_{x}(x,y,t), v_{y}(x,y,t) derived by Aly (2013)^{1}. The first bound (Sect. 2.1) is based, like Parker’s estimate, on the net displacement between the two footpoints of each field line. The second bound (Sect. 2.2) is more sophisticated and based on the relative twisting between pairs of field lines. It draws on the wellestablished idea that entanglement of magnetic field lines puts a lower bound on the energy of a magnetic field (Taylor 1974; Moffatt 1985; Freedman & He 1991). Our work builds on that of Berger (1993), who derived a lower bound for the energy of a braided magnetic field in terms of relative winding between field lines. Here, we remove his assumption that B has a uniform vertical component, and modify the bound slightly so that it is computable solely from a sequence of photospheric velocities.
The observational application of the bounds derived in Sect. 2 is presented in Sect. 3. It is important to note that, although our lower bounds for W are strict for the chosen Cartesian domain, they depend on the assumed height h of the domain. Moreover, the real coronal magnetic field from a specific photospheric region will likely fill a different shape of domain, and this will also influence the true magnetic energy. However, the lack of definitive methods for coronal magnetic field extrapolation prevents us from accounting for the precise volume. In view of these uncertainties, we find it useful to compare in Sect. 4 with two alternative Poynting flux estimates: one obtained with a vector magnetogram, and a hypothetical magnetic field reconstruction having the correct field line connectivity. In addition, to account for possible limitations of our velocity observations, we apply the technique to horizontal velocities taken from a numerical convection simulation. Conclusions are given in Sect. 5.
Fig. 1 Notation for a magnetic field B in a cylindrical domain V.
2. Lower bounds for the Poynting flux
For the convenience of the reader, this section presents the derivation of the two energy bounds given by Aly (2013). To obtain strict lower bounds for the magnetic energy W, we consider a magnetic field B(x,y,z) in a cylindrical domain V of base S_{0} ⊂ { (x,y,0) }, upper boundary S_{h} ⊂ { (x,y,h) } and height h> 0 (Fig. 1). Denote the vertical surface by S. We define 2R_{0} to be the diameter of S_{0} (i.e., the largest distance between two points on the boundary ∂S_{0}), and  S_{0}  to be the area of S_{0}. For the applications in this Paper, we will take the crosssection S_{z} to be rectangular, but the two bounds we derive in this section apply more generally.
Our energy bounds will further assume that B is the result of a continuous deformation of the initial uniform field B_{0} = B_{0}e_{z}, with B_{0}> 0 constant. This deformation is given by a onetoone orientation preserving mapping, which we denote $\overline{){r}}$. It transports a plasma element from r_{0} = (x_{0},y_{0},z_{0}) ∈ V to $\overline{){r}}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)}\mathrm{=}(\overline{){R}}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)}\mathit{,}\overline{)\mathit{z}}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)})\mathrm{\in}\mathit{V}$. Note that capital $\overline{){R}}$ denotes the $\overline{)\mathit{x}}$ and $\overline{)\mathit{y}}$ components only. Also, $\overline{){r}}$ maps each of the boundaries S_{0},S_{h},S to itself. We can write B in terms of the initial field B_{0} and the mapping as ${B}(\overline{){r}}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)})\mathrm{=}\frac{{\mathit{B}}_{\mathrm{0}}}{\mathit{J}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)}}\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\mathrm{\left(}{{r}}_{\mathrm{0}}\mathrm{\right)}\mathit{.}$(4)Here J is the determinant of ${\mathrm{\nabla}}_{\mathrm{0}}\overline{){r}}$, and we have used that B is a pseudovector (∇_{0} denotes the gradient with respect to the initial point r_{0}). From Eq. (4), we can then write the magnetic energy (1)as $\mathit{W}\mathrm{=}{\mathrm{\int}}_{\mathit{V}}\frac{{\mathit{B}}_{\mathrm{0}}^{\mathrm{2}}}{\mathrm{8}\mathit{\pi J}}{\left\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\right}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}{\mathit{x}}_{\mathrm{0}}\mathit{.}$(5)Throughout this paper, W_{0} denotes the energy of the initial uniform field, ${\mathit{W}}_{\mathrm{0}}\mathrm{=}\frac{{\mathit{B}}_{\mathrm{0}}^{\mathrm{2}}\mathrm{\left}\mathit{V}\mathrm{\right}}{\mathrm{8}\mathit{\pi}}\mathit{,}$(6)where  V  is the volume of V.
2.1. First lower bound
A first lower bound for the free energy may be derived using only the footpoint connectivity of field lines (Aly 2013). In particular, if R_{0} is the footpoint of a given field line in B_{0} (the footpoints on both S_{0} and S_{h} are the same since the field line is vertical), then let ξ(R_{0}) denote the horizontal distance between the corresponding footpoints after the deformation: $\begin{array}{ccc}{\xi}\mathrm{\left(}{{R}}_{\mathrm{0}}\mathrm{\right)}& \mathrm{=}& \overline{){R}}\mathrm{\left(}{{R}}_{\mathrm{0}}\mathit{,h}\mathrm{\right)}\mathrm{}\overline{){R}}\mathrm{\left(}{{R}}_{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}\mathit{,}\\ & \mathrm{=}& \overline{){r}}\mathrm{\left(}{{R}}_{\mathrm{0}}\mathit{,h}\mathrm{\right)}\mathrm{}\mathit{h}{{e}}_{\mathit{z}}\mathrm{}\overline{){r}}\mathrm{\left(}{{R}}_{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}\mathit{,}\\ & \mathrm{=}& \end{array}$The quantity we wish to bound is $\begin{array}{ccc}\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}& \mathrm{=}& \frac{\mathrm{1}}{\mathrm{\left}\mathit{V}\mathrm{\right}}{\mathrm{\int}}_{\mathit{V}}\frac{\mathrm{1}}{\mathit{J}}{\left\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\right}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}{\mathit{x}}_{\mathrm{0}}\\ & \mathrm{=}& \frac{\mathrm{1}}{\mathrm{}\mathit{V}{\mathrm{}}^{\mathrm{2}}}\left({\mathrm{\int}}_{\mathit{V}}\frac{\mathrm{1}}{\mathit{J}}{\left\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\right}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}{\mathit{x}}_{\mathrm{0}}\right)\left({\mathrm{\int}}_{\mathit{V}}\mathit{J}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}{\mathit{x}}_{\mathrm{0}}\right)\mathit{.}\end{array}$(10)Applying the CauchySchwarz inequality gives $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}\frac{\mathrm{1}}{\mathrm{}\mathit{V}{\mathrm{}}^{\mathrm{2}}}{\left({\mathrm{\int}}_{\mathit{V}}\left\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\right\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}{\mathit{x}}_{\mathrm{0}}\right)}^{\mathrm{2}}\mathrm{\ge}\frac{\mathrm{1}}{\mathrm{}\mathit{V}{\mathrm{}}^{\mathrm{2}}}{\left({\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}\left{\mathrm{\int}}_{\mathrm{0}}^{\mathit{h}}\frac{\mathit{\partial}\overline{){r}}}{\mathit{\partial}{\mathit{z}}_{\mathrm{0}}}\hspace{0.17em}\mathrm{d}{\mathit{z}}_{\mathrm{0}}\right\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}{\mathit{x}}_{\mathrm{0}}\right)}^{\mathrm{2}}\mathit{,}$(11)in which substitution of (9)leads to the bound $\begin{array}{ccc}\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}{\left[{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\left(\mathrm{1}\mathrm{+}{\left\frac{{\xi}}{\mathit{h}}\right}^{\mathrm{2}}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}\frac{{\mathrm{d}}^{\mathrm{2}}{\mathit{x}}_{\mathrm{0}}}{\mathrm{\left}{\mathit{S}}_{\mathrm{0}}\mathrm{\right}}\right]}^{\mathrm{2}}\mathrm{\xb7}& & \end{array}$(12)This bound for the free energy depends only on the horizontal distances between endpoints of each field line, as well as the height h of the domain.
2.2. Second lower bound
Aly (2013) derived a second lower bound for W/W_{0} in terms of the relative twist of pairs of field lines. This is a generalisation of a bound derived by Berger (1993) under the much more restrictive condition that B_{z} = B_{0} for all time. For completeness we present here the derivation of the new bound, where we shall assume only that B_{z}> 0 everywhere in V. It will be convenient to decompose B into horizontal and vertical components B = b_{⊥} + B_{z}e_{z}, and to further decompose B_{z} = B_{0} + b_{z}, where the constant B_{0} is the initial field.
The relative twist $\mathit{\phi}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}$ of two field lines R^{z}, ${\begin{array}{c}{\mathrm{\U0010ff65}}_{}\\ {R}\end{array}}^{\mathit{z}}$, rooted at two points R^{0}, ${\begin{array}{c}{\mathrm{\U0010ff65}}_{}\\ {R}\end{array}}^{\mathrm{0}}$ on S_{0}, is defined as the net angle swept out by the vector ${{X}}^{\mathit{z}}\mathrm{=}{\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {R}\end{array}}^{\mathit{z}}\mathrm{}{{R}}^{\mathit{z}}$ as z goes from 0 to h. This may be expressed as $\mathit{\phi}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}\mathrm{=}{\mathrm{\int}}_{\mathrm{0}}^{\mathit{h}}\frac{\mathit{\partial}{\mathit{\varphi}}^{\mathit{z}}}{\mathit{\partial z}}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}\hspace{0.17em}\mathrm{d}\mathit{z,}$(13)where $\mathrm{tan}{\mathit{\varphi}}^{\mathit{z}}\mathrm{=}\frac{{{X}}^{\mathit{z}}\mathrm{\xb7}{{e}}_{\mathit{y}}}{{{X}}^{\mathit{z}}\mathrm{\xb7}{{e}}_{\mathit{x}}}\mathrm{\xb7}$(14)Since R^{z} and ${\begin{array}{c}{\mathrm{\U0010ff65}}_{}\\ {R}\end{array}}^{\mathit{z}}$ are magnetic field lines, we can write (after some algebra) $\frac{\mathit{\partial}{\mathit{\varphi}}^{\mathit{z}}}{\mathit{\partial z}}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}\mathrm{=}\left[\left(\frac{{{b}}_{\mathrm{\perp}}}{{\mathit{B}}_{\mathit{z}}}\right)\mathrm{\left(}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}\mathrm{}\left(\frac{{{b}}_{\mathrm{\perp}}}{{\mathit{B}}_{\mathit{z}}}\right)\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}\right]\mathrm{\xb7}\left(\frac{\begin{array}{c}\mathrm{\U0010ff62}\\ {u}\end{array}}{{\mathit{X}}^{\mathit{z}}}\right)\mathit{,}$(15)where $\begin{array}{c}{}^{\mathrm{\U0010ff62}}\\ {u}\end{array}\mathrm{=}{{e}}_{\mathit{z}}\mathrm{\times}{{X}}^{\mathit{z}}\mathit{/}{\mathit{X}}^{\mathit{z}}$ (e.g., Berger 1993). For any pair of field lines, $\mathit{\phi}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}$ is invariant under any ideal deformation that fixes the endpoints: it is a topological quantity. Our energy bound will be expressed in terms of the average twist over all pairs of field lines, namely ${\mathit{w}}^{\mathrm{\ast}}\mathrm{=}\frac{\mathrm{1}}{\mathrm{16}\mathit{\pi}{\mathit{R}}_{\mathrm{0}}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}\mathrm{\times}{\mathit{S}}_{\mathrm{0}}}\mathit{\phi}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}{\mathit{B}}_{\mathit{z}}\mathrm{\left(}{{R}}^{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}{\mathit{B}}_{\mathit{z}}\mathrm{\left(}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}\mathrm{\U0010ff65}\\ \mathit{x}\end{array}\mathit{.}$(16)This differs slightly from Berger (1993) who took the absolute value inside the φintegral (13). (In that case φ is no longer a topological invariant, and the bound is more restrictive, being geometrical rather than topological in character.) With no absolute value sign, (16)would give the relative magnetic helicity, for an appropriate reference field (Berger 1986). The quantity w^{∗} can be measured from photospheric observations if one knows the initial photospheric distribution of B_{z} and the subsequent pattern of footpoint motions: this is the basis of our computations in Sect. 3.
To bound W/W_{0} in terms of w^{∗}, we start by substituting (13)and (15)into (16). Applying the triangle inequality and relabelling one of the terms, we get $\begin{array}{ccc}{\mathit{w}}^{\mathrm{\ast}}& \mathrm{\le}& \frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}{\mathit{R}}_{\mathrm{0}}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}\mathrm{\times}{\mathit{S}}_{\mathrm{0}}}\left({\mathrm{\int}}_{\mathrm{0}}^{\mathit{h}}\left\left(\frac{{{b}}_{\mathrm{\perp}}}{{\mathit{B}}_{\mathit{z}}}\right)\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}\mathrm{\xb7}\left(\frac{\begin{array}{c}\mathrm{\U0010ff62}\\ {u}\end{array}}{{\mathit{X}}^{\mathit{z}}}\right)\right\hspace{0.17em}\mathrm{d}\mathit{z}\right)\\ & & \u2001\u2001\u2001\u2001\u2001\u2001\mathrm{\times}{\mathit{B}}_{\mathit{z}}\mathrm{\left(}{{R}}^{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}{\mathit{B}}_{\mathit{z}}\mathrm{\left(}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathrm{0}}\mathit{,}\mathrm{0}\mathrm{\right)}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}\mathrm{\U0010ff65}\\ \mathit{x}\end{array}\mathit{.}\end{array}$(17)Writing the horizontal integrals over S_{z} instead of S_{0} introduces a factor B_{z}(R^{z},z) /B_{z}(R^{0},0) for each integral, giving ${\mathit{w}}^{\mathrm{\ast}}\mathrm{\le}\frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}{\mathit{R}}_{\mathrm{0}}}{\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}\left({\mathrm{\int}}_{{\mathit{S}}_{\mathit{z}}}\frac{\mathrm{}{\begin{array}{c}\mathrm{\U0010ff62}\\ {b}\end{array}}_{\mathrm{\perp}}\mathrm{\xb7}\begin{array}{c}\mathrm{\U0010ff62}\\ {u}\end{array}\mathrm{}}{{\mathit{X}}^{\mathit{z}}}{\mathit{B}}_{\mathit{z}}\mathrm{\left(}{\begin{array}{c}\mathrm{\U0010ff65}\\ {R}\end{array}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}\mathrm{\U0010ff65}\\ \mathit{x}\end{array}\right)\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x,}$(18)where ${\begin{array}{c}{}^{\mathrm{\U0010ff62}}\\ {b}\end{array}}_{\mathrm{\perp}}\mathrm{=}{{b}}_{\mathrm{\perp}}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}\mathit{/}\mathrm{\left}{{b}}_{\mathrm{\perp}}\mathrm{\right(}{{R}}^{\mathit{z}}\mathit{,z}\mathrm{\left)}\mathrm{\right}$. Since w^{∗} ≥ 0 it follows that  w^{∗}  = w^{∗}, and the triangle inequality gives $\begin{array}{ccc}\mathrm{8}\mathit{\pi}{\mathit{R}}_{\mathrm{0}}\mathrm{\left}{\mathit{w}}^{\mathrm{\ast}}\mathrm{\right}& \mathrm{\le}& {\mathit{B}}_{\mathrm{0}}{\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}\left({\mathrm{\int}}_{{\mathit{S}}_{\mathit{z}}}\frac{\mathrm{}{\begin{array}{c}\mathrm{\U0010ff62}\\ {b}\end{array}}_{\mathrm{\perp}}\mathrm{\xb7}\begin{array}{c}\mathrm{\U0010ff62}\\ {u}\end{array}\mathrm{}}{{\mathit{X}}^{\mathit{z}}}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}\mathrm{\U0010ff65}\\ \mathit{x}\end{array}\right)\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\\ & & \end{array}$(19)where $\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {\mathit{b}}_{\mathit{z}}\end{array}\mathrm{=}{\mathit{b}}_{\mathit{z}}\mathrm{\left(}{\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {R}\end{array}}^{\mathit{z}}\mathit{,z}\mathrm{\right)}$. Our task is then to bound the two integrals in (19)in terms of the energy W/W_{0}.
The first integral in (19)– which we denote I_{1} – is similar to Eq. (10) of Berger (1993) and may be bounded in a similar way. In particular, let $\mathit{I}\mathrm{\left(}{{R}}^{\mathit{z}}\mathrm{\right)}\mathrm{=}\mathrm{(}\mathrm{1}\mathit{/}{\mathit{R}}_{\mathrm{0}}\mathrm{)}{{}^{\mathrm{\int}}\mathit{S}_{\mathit{z}}}_{}\mathrm{}{\begin{array}{c}{}^{\mathrm{\U0010ff62}}\\ {b}\end{array}}_{\mathrm{\perp}}\mathrm{\xb7}\begin{array}{c}{}^{\mathrm{\U0010ff62}}\\ {u}\end{array}\mathrm{}\mathit{/}{\mathit{X}}^{\mathit{z}}\hspace{0.17em}\mathrm{d}\begin{array}{c}{}^{\mathrm{\U0010ff65}}\\ \mathit{x}\end{array}$. Then the maximum value of I(R^{z}) over all possible ${\begin{array}{c}{\mathrm{\U0010ff62}}^{}\\ {b}\end{array}}_{\mathrm{\perp}}$, which we denote m(R^{z}), is a function depending only on the geometry of S_{0}. For example, if S_{0} is a disk, then one can show (by explicit but tedious calculation) that $\mathit{m}\mathrm{\left(}{{R}}^{\mathit{z}}\mathrm{\right)}\mathrm{=}\mathrm{2}\sqrt{\mathrm{1}\mathrm{}{\left(\frac{{\mathit{R}}^{\mathit{z}}}{{\mathit{R}}_{\mathrm{0}}}\right)}^{\mathrm{2}}}\mathrm{+}\mathrm{2}\frac{{\mathit{R}}_{\mathrm{0}}}{{\mathit{R}}^{\mathit{z}}}\mathrm{arcsin}\left(\frac{{\mathit{R}}^{\mathit{z}}}{{\mathit{R}}_{\mathrm{0}}}\right)\mathrm{\xb7}$(20)(Note that an incorrect expression is given in Berger 1993.) We then have ${\mathit{I}}_{\mathrm{1}}\mathrm{\le}{\mathit{R}}_{\mathrm{0}}{\mathit{B}}_{\mathrm{0}}{\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}\mathit{m}\mathrm{\left(}{{R}}^{\mathit{z}}\mathrm{\right)}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\mathit{.}$(21)Defining ${\mathit{\mu}}^{\mathrm{2}}\mathrm{=}\mathrm{}{\mathit{S}}_{\mathrm{0}}{\mathrm{}}^{1}{{}^{\mathrm{\int}}\mathit{S}_{\mathit{z}}}_{}{\mathit{m}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}$, and applying the CauchySchwarz inequality, we obtain ${\mathit{I}}_{\mathrm{1}}\mathrm{\le}\sqrt{\mathrm{\left}\mathit{V}\mathrm{\right}}{\mathit{R}}_{\mathrm{0}}{\mathit{B}}_{\mathrm{0}}\mathit{\mu}{\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}^{\mathrm{2}}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}\mathit{.}$(22)A numerical integration shows that (for the disk) μ^{2} ≈ 13.137.
Now we look for a bound of the second integral in (19), which we denote I_{2}. The CauchySchwarz inequality yields ${\mathit{I}}_{\mathrm{2}}\mathrm{\le}{\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}{\left({\mathrm{\int}}_{\mathit{V}}{\left[{\mathrm{\int}}_{{\mathit{S}}_{\mathit{z}}}\frac{\mathrm{\left}\begin{array}{c}\mathrm{\U0010ff65}\\ {\mathit{b}}_{\mathit{z}}\end{array}\mathrm{\right}}{{\mathit{X}}^{\mathit{z}}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}\mathrm{\U0010ff65}\\ \mathit{x}\end{array}\right]}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}\mathit{.}$(23)Applying CauchySchwarz again to the $\begin{array}{c}{\mathrm{\U0010ff65}}^{}\\ \mathit{x}\end{array}$integral, we obtain ${\mathit{I}}_{\mathrm{2}}\mathrm{\le}{\mathit{R}}_{\mathrm{0}}\mathit{\nu}{\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}{\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathit{z}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}\mathit{,}$(24)where ${\mathit{\nu}}^{\mathrm{2}}\mathrm{=}{\mathit{R}}_{\mathrm{0}}^{2}{{}^{\mathrm{\int}}}_{{\mathit{S}}_{\mathit{z}}\mathrm{\times}{\mathit{S}}_{\mathit{z}}}\mathrm{(}{\mathit{X}}^{\mathit{z}}{\mathrm{)}}^{2}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\begin{array}{c}{}^{\mathrm{\U0010ff65}}\\ \mathit{x}\end{array}\hspace{0.17em}{\mathrm{d}}^{\mathrm{2}}\mathit{x}$ is another geometric constant. For any domain S_{0}, we have ν ≤ 2π (with equality when S_{0} is a disk).
We may now use (22)and (24)in (19)to find $\mathrm{\left(}\mathrm{8}\mathit{\pi}{\mathit{R}}_{\mathrm{0}}{\mathrm{)}}^{\mathrm{2}}\mathrm{\right(}{\mathit{w}}^{\mathrm{\ast}}{\mathrm{)}}^{\mathrm{2}}\mathrm{\le}{\mathit{R}}_{\mathrm{0}}^{\mathrm{2}}\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathrm{\perp}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right){\left[\sqrt{\mathrm{\left}\mathit{V}\mathrm{\right}}{\mathit{B}}_{\mathrm{0}}\mathit{\mu}\mathrm{+}\mathit{\nu}{\left({\mathrm{\int}}_{\mathit{V}}{\mathit{b}}_{\mathit{z}}^{\mathrm{2}}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}\right)}^{\mathrm{1}\mathit{/}\mathrm{2}}\right]}^{\mathrm{2}}\mathit{.}$(25)This may be rearranged to yield the inequality $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}\mathrm{1}\mathrm{+}\mathit{s}\mathrm{+}\frac{\mathrm{(}{\mathit{w}}^{\mathrm{\ast}}\mathit{/}{\mathit{W}}_{\mathrm{0}}{\mathrm{)}}^{\mathrm{2}}}{\mathrm{(}\mathit{\mu}\mathrm{+}\mathit{\nu}\sqrt{\mathit{s}}{\mathrm{)}}^{\mathrm{2}}}\mathit{,}$(26)where $\mathit{s}\mathrm{=}\mathrm{(}\mathrm{1}\mathit{/}{\mathit{W}}_{\mathrm{0}}\mathrm{)}{{}^{\mathrm{\int}}}_{\mathit{V}}{\mathit{b}}_{\mathit{z}}^{\mathrm{2}}\mathit{/}\mathrm{\left(}\mathrm{8}\mathit{\pi}\mathrm{\right)}\hspace{0.17em}{\mathrm{d}}^{\mathrm{3}}\mathit{x}$. Under the additional assumption that b_{z} = 0, inequality (26)would reduce to $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}\mathrm{1}\mathrm{+}\frac{\mathrm{1}}{{\mathit{\mu}}^{\mathrm{2}}}{\left(\frac{{\mathit{w}}^{\mathrm{\ast}}}{{\mathit{W}}_{\mathrm{0}}}\right)}^{\mathrm{2}}\mathit{,}$(27)which is equivalent to the bound of Berger (1993). In general, we allow for any distribution of b_{z}, and our bound is $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}\underset{\mathit{s}\hspace{0.17em}\mathrm{\ge}\hspace{0.17em}\mathrm{0}}{\mathrm{min}}\left\{\mathrm{1}\mathrm{+}\mathit{s}\mathrm{+}\frac{\mathrm{(}{\mathit{w}}^{\mathrm{\ast}}\mathit{/}{\mathit{W}}_{\mathrm{0}}{\mathrm{)}}^{\mathrm{2}}}{\mathrm{(}\mathit{\mu}\mathrm{+}\mathit{\nu}\sqrt{\mathit{s}}{\mathrm{)}}^{\mathrm{2}}}\right\}\mathrm{\xb7}$(28)If w^{∗} = 0 then the minimum occurs at s = 0. Otherwise, let $\mathit{x}\mathrm{=}\sqrt{\mathit{s}}$ so that our function becomes g(x) = 1 + x^{2} + a^{2}/ (b + cx)^{2}, where b,c> 0. A minimum must satisfy ${\mathit{c}}^{\mathrm{3}}{\mathit{x}}^{\mathrm{4}}\mathrm{+}\mathrm{3}\mathit{b}{\mathit{c}}^{\mathrm{2}}{\mathit{x}}^{\mathrm{3}}\mathrm{+}\mathrm{3}{\mathit{b}}^{\mathrm{2}}\mathit{c}{\mathit{x}}^{\mathrm{2}}\mathrm{+}{\mathit{b}}^{\mathrm{3}}\mathit{x}\mathrm{}{\mathit{a}}^{\mathrm{2}}\mathit{c}\mathrm{=}\mathrm{0}\mathit{,}$(29)and applying Descartes’ rule of signs shows that there is exactly one root for positive x (and hence s). This root gives the minimum value in (28).
2.3. Simple example
To compare the two lower bounds (12)and (28), it is instructive to look at a simple example before considering the observed data. We take S_{0} to be a disk, and apply a largescale twist to the initial field B_{0} = B_{0}e_{z} by solving the ideal MHD induction equation with the specified velocity v = v_{0}rf(z)e_{φ}. Here (r,φ,z) are standard cylindrical coordinates. The resulting magnetic field is B(r,z,t) = v_{0}B_{0}rf′(z)te_{φ} + B_{0}e_{z}. For illustration we choose f(z) = z^{2} + sinz (Fig. 2). The exact magnetic energy of this field is $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{=}\mathrm{1}\mathrm{+}\frac{{\mathit{v}}_{\mathrm{0}}^{\mathrm{2}}{\mathit{R}}_{\mathrm{0}}^{\mathrm{2}}{\mathit{t}}^{\mathrm{2}}}{\mathrm{2}\mathit{h}}\left(\frac{\mathrm{4}{\mathit{h}}^{\mathrm{3}}}{\mathrm{3}}\mathrm{+}\mathrm{4}\mathit{h}\mathrm{sin}\mathit{h}\mathrm{+}\mathrm{4}\mathrm{cos}\mathit{h}\mathrm{}\mathrm{4}\mathrm{+}\frac{\mathit{h}}{\mathrm{2}}\mathrm{+}\frac{\mathrm{sin}\mathit{h}\mathrm{cos}\mathit{h}}{\mathrm{2}}\right)\mathit{,}$(30)which increases quadratically with time. The first lower bound (12)may be computed explicitly, giving $\frac{\mathit{W}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{\ge}{\left(\frac{{\mathit{h}}^{\mathrm{2}}}{{\mathit{R}}_{\mathrm{0}}^{\mathrm{2}}{\mathit{G}}^{\mathrm{2}}}\left[\frac{\mathrm{2}}{\mathrm{3}}{\left(\mathrm{1}\mathrm{+}\frac{{\mathit{G}}^{\mathrm{2}}{\mathit{R}}_{\mathrm{0}}^{\mathrm{2}}}{{\mathit{h}}^{\mathrm{2}}}\right)}^{\mathrm{3}\mathit{/}\mathrm{2}}\mathrm{}\frac{\mathrm{2}}{\mathrm{3}}\right]\right)}^{\mathrm{2}}\mathit{,}$(31)where G(t) = 2sin[(f(h) − f(0))v_{0}t/ 2]. Notice that G, and hence the bound, is a periodic function of t (as seen in Fig. 2). This reflects the limitation that the bound cannot detect net rotations of field lines, as it depends only on the endpoints.
Fig. 2 Comparison of the exact energy W/W_{0} and three different bounds for the analytical magnetic field in Sect. 2.3, with h = 1, R_{0} = 1, v_{0} = 1. The two upper panels show field lines at t = 1 and t = 3 respectively.
For the second lower bound (28), we find explicitly that $\frac{{\mathit{w}}^{\mathrm{\ast}}}{{\mathit{W}}_{\mathrm{0}}}\mathrm{=}\frac{\mathit{\pi}{\mathit{R}}_{\mathrm{0}}\mathrm{\left}\mathrm{\right(}\mathit{f}\mathrm{\left(}\mathit{h}\mathrm{\right)}\mathrm{}\mathit{f}\mathrm{\left(}\mathrm{0}\mathrm{\right)}\mathrm{\left)}{\mathit{v}}_{\mathrm{0}}\mathit{t}\mathrm{\right}}{\mathrm{2}\mathit{h}}\mathit{,}$(32)and the bound (28)is readily evaluated numerically. Comparing this with the first bound (Fig. 2), we see that (32)is not periodic, and increases monotonically in time as the field lines become more and more twisted. For t> 2.5, this gives a better estimate of the true energy than the first bound, although it is not tight. In fact, Berger’s bound (27)gives a much better estimate for t> 0.5, since the true field maintains constant B_{z} = B_{0}. This additional information will not be available from the observational data, so we need to allow for the field reaching a lower energy by adopting varying B_{z} in the corona. We remark that this is a rather extreme example, with a largescale twist filling the whole of V, and that for small t the first bound (28)is actually tightest, as seen from the inset in Fig. 2. We also find the first bound to be tightest in the observed data, described in the next section.
3. Observational results
3.1. Data reduction
We use the same velocity data as Yeates et al. (2012), derived by local correlation tracking in lineofsight magnetograms. As in that paper, we focus on a unipolar plage region of size 12.4 Mm × 12.4 Mm (approximately 17′′ × 17′′), near active region 10930 but away from the sunspots (Fig. 3). The original Stokes V/I maps were taken by Hinode/Narrowband Filter Imager (NFI) observations in Fe I 6302 Å (Tsuneta et al. 2008), and the sequence runs from 14:00 UT on 12 December to 02:58 UT on 13 December 2006, at a cadence of ~121 s. The lineofsight magnetic field strength was empirically calibrated (following Isobe et al. 2007), and the velocity field was extracted from the magnetograms using Fourier local correlation tracking (FLCT; Welsch et al. 2004; Fisher & Welsch 2008). Full details of the procedure, including its optimisation, are given in Welsch et al. (2012). As in Yeates et al. (2012), highfrequency noise in the velocity field was removed with minimal disturbance to the wellresolved regions by applying a lowpass spatial filter in Fourier space. The result is a timesequence of horizontal photospheric velocities v_{x}, v_{y}, at horizontal resolution of approximately 230 km. Note that the mean flow speed in these observations is of the order 0.1 km s^{1}, rather slower than reported speeds for granular flows (~ 1 km s^{1}, Rieutord & Rincon 2010). This underestimate may be a combined effect of the observational resolution and the correlation tracking (Welsch et al. 2007). However, it may also reflect either slower motion of magnetic features compared to the underlying plasma velocity, or inhibition of the convective flow by strong magnetic fields in our plage region.
Fig. 3 Lineofsight magnetogram showing the location of the observed plage region (black box) in the Hinode/NFI field of view, away from the main sunspots of active region 10930.
Fig. 4 Trajectories of the observed velocity field (upper panel) and the two lower bounds calculated for a similar set of 900 trajectories (lower panel). The vertical axis shows (W − W_{0}) /W_{0} on a logscale. Thin lines show the slope of linear fits for t> 6 h.
3.2. Lower bounds on the Poynting flux
We now use (12)and (28)to put lower bounds on the Poynting flux resulting from our observed sequence of photospheric velocities. Recall that (12)and (28)bound the magnetic energy W/W_{0} of a final magnetic field B(x,y,z) that has been generated by ideal deformation of an initially uniform field B_{0}e_{z}. But we do not need to know the precise deformation: in fact we need only the endpoint connectivity of field lines for (12), and the relative twist of each pair of field lines for (28). Both of these quantities can be computed by knowing only the sequence of footpoint motions on S_{0} and on S_{h}. In this paper, we shall assume that the footpoints on S_{0} remain fixed, while those on S_{h} move according to the observed timesequence of v_{x}, v_{y}. (On average, this likely means that we will underestimate the Poynting flux compared to the real corona where field lines are undergoing largely uncorrelated footpoint motions at either end.)
To match the observed region, it is convenient to take S_{0} (and hence every crosssection S_{z}) to be a square of side L, rather than a disk. Hence ${\mathit{R}}_{\mathrm{0}}\mathrm{=}\mathit{L}\mathit{/}\sqrt{\mathrm{2}}$. For a square, the geometric constants μ, ν used in the second lower bound (Sect. 2.2) may be taken to be μ^{2} = 14.146 and ν = 2π. Both are upper bounds – the former uses the fact that m(R^{z}) in (21)is bounded above by its value for a disk of radius $\mathit{L}\mathit{/}\sqrt{\mathrm{2}}$ (m^{2} is then integrated over the square). The height h of the domain is not constrained by the observations – we shall consider its effect below.
Under these assumptions, we have computed the bounds (12)and (28)numerically by integrating trajectories of the observed velocity field (Fig. 4). This allows us to compute both ξ and $\mathit{\phi}\mathrm{\left(}{{R}}^{\mathit{z}}\mathit{,}{\begin{array}{c}{}_{\mathrm{\U0010ff65}}\\ {R}\end{array}}^{\mathit{z}}\mathrm{\right)}$, as required for the bounds. We also need B_{z} on S_{0} to compute w^{∗}, but we simply have B_{z}  _{S0} = B_{0}. There is one complication: our bounds assume that field lines are confined within V at all times. To prevent violation of this constraint on the side boundary, we artificially set the normal velocity to zero on the side boundaries so that trajectories do not leave (or enter) V. This likely has the effect of reducing the estimated energy a little.
The resulting bounds on the free energy are shown in Fig. 4 as a function of time. The quantity plotted is (W − W_{0}) /W_{0}, so as to facilitate showing both bounds on the same logarithmic scale. The most noticeable result is that the first bound is approximately 100 times larger than the second bound. This reflects the fact that most trajectories seem to have small relative twist.
To calculate the Poynting flux implied by our energy bounds, we notice that, from about t = 6 h onwards, W/W_{0} grows approximately linearly in time. A linear fit gives this linear growth rate s, which then gives the Poynting flux $\frac{\mathrm{d}\mathit{W}}{\mathrm{d}\mathit{t}}\mathrm{=}{\mathit{W}}_{\mathrm{0}}\mathit{s}\mathrm{=}\frac{{\mathit{L}}^{\mathrm{2}}\mathit{h}{\mathit{B}}_{\mathrm{0}}^{\mathrm{2}}\mathit{s}}{\mathrm{8}\mathit{\pi}}$(33)for our assumed ideal evolution. A numerical estimate requires values for L, h and B_{0}. Here L ≈ 12 Mm is fixed by the region of observation, and we take B_{0} = 350 G (close to the observed mean value of lineofsight magnetic field in the region). Figure 5 shows the two estimates expressed as Poynting flux per unit area, L^{2}dW/ dt, and verifies that the estimates converge as more and more trajectories are used for the calculation with h = L.
Fig. 5 Convergence of the numerical estimates of the bounds as the number n of field lines in the calculation is increased. The units of Poynting flux (per unit area) are erg cm^{2} s^{1}, and we have taken B_{0} = 350 G, h = L.
Although the Poynting flux with h = L for the first bound is approximately 8 × 10^{7} erg cm^{2} s^{1}, close to the required rate to heat the corona, it should be noted that this estimate goes down if the height h of the domain is increased (think of this as the length of the coronal loop). In fact, the Poynting fluxes from both bounds decrease like h^{1} (as did Parker’s original simple estimate). This is shown in Fig. 6. For a more realistic domain height of h = 8L( ≈ 100 Mm), the largest lower bound gives only ≈10^{6} erg cm^{2} s^{1}. To understand why the energy bounds scale like h^{1}, consider a magnetic field B = B_{⊥}(x,y,z) + B_{z}(x,y,z)e_{z} in a domain 0 <z< 1, where B_{⊥} denotes the horizontal components. This has energy $\mathit{W}\mathrm{=}\frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\mathrm{\int}}_{\mathrm{0}}^{\mathrm{1}}({\mathit{B}}_{\mathrm{\perp}}^{\mathrm{2}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}\mathrm{+}{\mathit{B}}_{\mathit{z}}^{\mathrm{2}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)})\hspace{0.17em}\mathrm{d}\mathit{z}\mathrm{d}\mathit{x}\mathrm{d}\mathit{y}\mathit{.}$(34)The stretched field B′ = h^{1}B_{⊥}(x,y,z/h) + B_{z}(x,y,z/h)e_{z} has the same field line connectivity in the domain 0 <z<h (Aly & Amari 2010), and the new energy is $\begin{array}{ccc}{\mathit{W}}^{\mathrm{\prime}}& \mathrm{=}& \frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\mathrm{\int}}_{\mathrm{0}}^{\mathit{h}}\left(\frac{\mathrm{1}}{{\mathit{h}}^{\mathrm{2}}}{\mathit{B}}_{\mathrm{\perp}}^{\mathrm{2}}\mathrm{(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathit{/}\mathit{h}\mathrm{)}\mathrm{+}{\mathit{B}}_{\mathit{z}}^{\mathrm{2}}\mathrm{(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathit{/}\mathit{h}\mathrm{)}\right)\mathrm{d}{\mathit{z}}^{\mathrm{\prime}}\mathrm{d}\mathit{x}\mathrm{d}\mathit{y,}\\ & \mathrm{=}& \frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\mathrm{\int}}_{\mathrm{0}}^{\mathrm{1}}\left(\frac{\mathrm{1}}{\mathit{h}}{\mathit{B}}_{\mathrm{\perp}}^{\mathrm{2}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}\mathrm{+}\mathit{h}{\mathit{B}}_{\mathit{z}}^{\mathrm{2}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}\right)\hspace{0.17em}\mathrm{d}\mathit{z}\mathrm{d}\mathit{x}\mathrm{d}\mathit{y}\mathit{.}\end{array}$Now if B_{z} ≈ B_{0} (i.e., the field has a strong vertical component), then the second term in the integrand is essentially W_{0} for the new field. So W − W_{0} is essentially the B_{⊥} term, leading to dW/ dt ~ h^{1}. Thus the scaling with h^{1} is not an inaccuracy of our energy bounds, but rather arises because it is possible to reduce the free energy of a magnetic field by stretching the domain.
Fig. 6 Dependence of each of the bounds on domain size h, shown on a log–log scale. The units of Poynting flux (per unit area) are erg cm^{2} s^{1}, and we have taken B_{0} = 350 G. Both lines have slope − 1.
4. Comparisons
To get some idea of the tightness of our lower bounds on the Poynting flux, we now consider three independent energy estimates. The first is a direct calculation of the Poynting flux from a vector magnetogram (Sect. 4.1) and the second is a reconstructed magnetic field with the correct fieldline connectivity (Sect. 4.2). The third (Sect. 4.3) is not based on the observations at all, but repeats the calculation for a sequence of velocities from a numerical convection simulation.
4.1. Vector magnetogram
By combining a vector magnetogram with our measurements of v_{x} and v_{y}, we may evaluate the last term in Eq. ((3)) directly, subject to combined uncertainties in the velocity and magnetogram measurements (notably the 180° ambiguity). This term represents the dominant contribution to the photospheric Poynting flux when B is primarily vertical, as we expect in our unipolar plage region. To obtain B_{x} and B_{y}, we extracted a subregion from a vector magnetogram analyzed by Schrijver et al. (2008), taken around 21:04 on 2006 December 12 by Hinode/SP (SpectroPolarimeter; Tsuneta et al. 2008). The data were coregistered with the NFI lineofsight magnetic field from which v_{x} and v_{y} were extracted, then interpolated to the same resolution. The vertical magnetic field B_{z} from SP, and the computed Poynting flux density are shown in Fig. 7. Although there are regions of both positive and negative Poynting flux density, the (signed) average Poynting flux per unit area in this region is 1.67 × 10^{7} erg cm^{2} s^{1}.
Fig. 7 Vector magnetogram measurements at 21:04 on 2006 December 12. The upper panel shows B_{z} from Hinode/SP and the lower panel shows the Poyntingflux density − B_{z}(v_{x}B_{x} + v_{y}B_{y})/(4π) using the Hinode/SP B_{x}, B_{y} and the velocity observations from Sect. 3.
4.2. Topological field reconstruction
Another estimate of the energy can be obtained by taking the observed trajectories (Fig. 4) and assuming them to be the field lines of a magnetic field. Given B_{z} on one boundary, this uniquely defines a magnetic field with the correct fieldline connectivity (Yeates et al. 2012), whose energy we can calculate for a given choice of h. In contrast with our lower bounds, this is likely to be an overestimate of the true energy in the coronal field, since the trajectories are not very smooth: the real magnetic field might be expected to relax to remove such fluctuations on the faster Alfvén timescale. (On the other hand, we are neglecting the additional energy that may result from motions at the opposite footpoints.)
To define the magnetic field, let ${{B}}^{\mathit{T}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}\mathrm{=}\mathit{\lambda}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}({\mathit{v}}_{\mathit{x}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}{{e}}_{\mathit{x}}\mathrm{+}{\mathit{v}}_{\mathit{y}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}{{e}}_{\mathit{y}}\mathrm{+}{{e}}_{\mathit{z}})\mathit{,}$(37)where v(x,y,t) is the observed photospheric velocity sequence. In this way, the z coordinate in the resulting magnetic field corresponds to time in the observed velocity field, and the magnetic field lines have the same topology as the footpoint trajectories. The function λ(x,y,z) is uniquely determined by the condition that ∇·B = 0 along with its distribution λ(x,y,0) = B_{0} on S_{0} (see Yeates et al. 2012). However, the height h of the domain is then equal to T (the maximum time in the observations). We can stretch the magnetic field to a domain of height h while preserving the fieldline connectivity using the same idea as in Sect. 3.2. In particular, define z′ = zh/T and $\begin{array}{ccc}{{B}}^{\mathit{h}}\mathrm{\left(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathrm{\right)}& \mathrm{=}& \frac{\mathit{T}}{\mathit{h}}[{\mathit{B}}_{\mathit{x}}^{\mathit{T}}\mathrm{(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathit{T}\mathit{/}\mathit{h}\mathrm{)}{{e}}_{\mathit{x}}\mathrm{+}{\mathit{B}}_{\mathit{y}}^{\mathit{T}}\mathrm{(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathit{T}\mathit{/}\mathit{h}\mathrm{)}{{e}}_{\mathit{y}}]\\ & & \u2001\mathrm{+}\hspace{0.17em}{\mathit{B}}_{\mathit{z}}^{\mathit{T}}\mathrm{(}\mathit{x,y,}{\mathit{z}}^{\mathrm{\prime}}\mathit{T}\mathit{/}\mathit{h}\mathrm{)}{{e}}_{\mathit{z}}\mathit{.}\end{array}$(38)In terms of B^{T}, the energy of B^{h} may be written $\begin{array}{ccc}{\mathit{W}}^{\mathit{h}}& \mathrm{=}& \int {\mathit{S}}_{\mathrm{0}}{\mathrm{\int}}_{\mathrm{0}}^{\mathit{h}}\frac{\mathrm{(}{{B}}^{\mathit{h}}{\mathrm{)}}^{\mathrm{2}}}{\mathrm{8}\mathit{\pi}}\hspace{0.17em}\mathrm{d}{\mathit{z}}^{\mathrm{\prime}}\mathrm{d}\mathit{x}\mathrm{d}\mathit{y,}\\ & \mathrm{=}& \frac{\mathrm{1}}{\mathrm{8}\mathit{\pi}}{\mathrm{\int}}_{{\mathit{S}}_{\mathrm{0}}}{\mathrm{\int}}_{\mathrm{0}}^{\mathit{T}}[\frac{\mathit{T}}{\mathit{h}}\mathrm{\left(}{\mathit{B}}_{\mathit{x}}^{\mathit{T}}{\mathrm{)}}^{\mathrm{2}}\mathrm{\right(}\mathit{x,y,z}\mathrm{)}\mathrm{+}\frac{\mathit{T}}{\mathit{h}}\mathrm{(}{\mathit{B}}_{\mathit{y}}^{\mathit{T}}{\mathrm{)}}^{\mathrm{2}}\mathrm{\left(}\mathit{x,y,z}\mathrm{\right)}\\ & & \end{array}$Since λ(x,y,0) = B_{0}, it follows from Eq. (40)that the relative free energy (W^{h} − W_{0}) /W_{0} is independent of B_{0}. Evaluating this for our observed v, we find that the relative free energy is effectively independent of h providing that h is large enough (Fig. 8).
Fig. 8 Energy estimate from the field reconstruction in Sect. 4.2. The upper panel shows the relative free energy as a function of T (for two assumed domain sizes h = L and h = 5L). The lower panel shows the Poynting flux (per unit area) in a domain h = L assuming the fit at^{b} shown by the dotdashed line in the upper panel.
Unlike the lower bounds, the timedependence of the relative free energy is now superlinear: approximating by a numerical fit with constant exponent (for h = 5L) gives W^{h}/W_{0} ~ t^{1.5}. Notice that this leads to a Poynting flux that increases with time like dW_{h}/dt ~ W_{0}t^{0.5}. This is shown in Fig. 8 for h = L (note that dW/dt scales linearly with h following W_{0}). At t = 12 h, this puts an upper bound of about 3.5 × 10^{8} erg cm^{2} s^{1} on the Poynting flux.
4.3. Numerical convection simulations
As described above, our velocity observations have a rather lower mean speed than expected for granular flows. By comparing with a simple twodimensional model of convection, Yeates et al. (2012) found that the field line mapping changed significantly if the speed of the photospheric flows was increased. To study the possible change to our Poynting flux estimate that would arise from betterresolved flows, we have also calculated the energy bounds using photospheric velocities taken from a numerical convection simulation (Bushby et al. 2012).
The horizontal velocities v_{x}(x,y,t), v_{y}(x,y,t) have been extracted from the upper boundary of a threedimensional simulation of hydrodynamic convection in a Cartesian slab 0 ≤ x ≤ 10d, 0 ≤ y ≤ 10d, 0 ≤ z ≤ d, heated from below. Details of the simulations, which are fully compressible, may be found in Bushby et al. (2012). Here, the results are dimensionalized by taking d = 1.5 Mm and assuming the time scale t_{0} = 5 min (the convective turnover time in the simulation is approximately 3t_{0}). In these units, the mean velocity is $\mathrm{\u27e8}\mathrm{(}{\mathit{v}}_{\mathit{x}}^{\mathrm{2}}\mathrm{+}{\mathit{v}}_{\mathit{y}}^{\mathrm{2}}{\mathrm{)}}^{\mathrm{1}\mathit{/}\mathrm{2}}\mathrm{\u27e9}\mathrm{\approx}\mathrm{1.7}\hspace{0.17em}\mathrm{km}\hspace{0.17em}{\mathrm{s}}^{1}$, comparable to observed granular velocities (Rieutord & Rincon 2010). To prevent particles leaving V, we artificially taper v_{x} and v_{y} to zero on the side boundaries.
Figure 9 shows a typical set of trajectories. Although the domain is similar in size, the trajectories are rather different to those of the observed data (Fig. 4). In particular, the faster speed and compressible nature of the flow lead to rapid clumping of trajectories at a small number of locations. But, as with the observed velocities, we find that W/W_{0} increases approximately linearly in time.
Fig. 9 Trajectories of the velocity field from the numerical convection simulation, seen from two different angles.
Estimates of the Poynting flux (for h = L and B_{0} = 350 G) are shown in Fig. 10. As before, both bounds scale like h^{1} as the domain height is increased. For the first bound, we find approximately 1 × 10^{7} erg cm^{2} s^{1}. This is only slightly larger than the value calculated for the observed velocity. On the other hand, the second bound is now much closer to the first, at approximately 0.7 × 10^{7} erg cm^{2} s^{1}. To explore this difference, we have repeated the calculation for the simulation with varying degrees of smoothing applied to the velocity field before calculating the trajectories. Figure 11 shows the effect on the bounds of applying a lowpass filter of the form $\mathit{G}\mathrm{\left(}\mathit{\omega}\mathrm{\right)}\mathrm{=}\frac{\mathrm{1}}{\mathrm{1}\mathrm{+}\mathrm{(}\mathit{\omega}\mathit{/}{\mathit{\omega}}_{\mathrm{c}}{\mathrm{)}}^{\mathrm{4}}}$(41)in frequency space, where ω is the spatial frequency and ω_{c} is the cutoff. Notice that the first bound is rather insensitive to the filtering out of highfrequency information in the velocity field. On the other hand, the second bound starts to decay for a cutoff frequency as high as 128 (the spatial resolution is 256^{2}). Thus it appears that the second bound requires smallerscale fluctuations in the velocity to measure relative twisting between trajectories. By contrast, the first bound yields similar results even for a rather coarsely averaged velocity field. This finding is consistent with the behaviour of the two bounds for the observations, where the mean flow speed is lower and the velocity is smoother.
Fig. 10 Computed energy bounds for the velocity data taken from the numerical convection simulation. The upper panel shows the convergence of the Poynting flux (per unit area) as the number of trajectories used for the calculation is increased (with h = L, B_{0} = 350 G). The lower panel shows that this estimate scales like h^{1}, as for the observed velocities. Units are erg cm^{2} s^{1}.
Fig. 11 Effect of applying a lowpass spatial filter to the velocities from the numerical convection simulation. The horizontal axis shows the cutoff frequency ω_{c} of the filter. The solid line shows the mean flow speed $\mathrm{\u27e8}\sqrt{{\mathit{v}}_{\mathit{x}}^{\mathrm{2}}\mathrm{+}{\mathit{v}}_{\mathit{y}}^{\mathrm{2}}}\mathrm{\u27e9}$ (right axis), while the two lines with symbols show the two bounds for the Poynting flux in erg cm^{2} s^{1} (left axis). Here we took h = L, B_{0} = 350 G.
5. Conclusions
In this Paper we have computed two alternative lower bounds for the magnetic energy injected into the solar corona by photospheric footpoint motions, assuming a perfectly ideal coronal evolution. The first bound is based on the displacement between the two footpoints of each field line, and the second bound is based on the relative pairwise twisting of field lines. The advantage of these bounds is that they do not require observations of horizontal magnetic field components in the photosphere, only the initial vertical magnetic field and a sequence of horizontal velocities. We have computed the bounds for an observed sequence of photospheric velocities derived from correlation tracking in Hinode/NFI lineofsight magnetograms.
For the observed data, we find that the first lower bound is approximately 100 times larger than the second. If the height h of the domain is assumed equal to its horizontal extent L ≈ 12 Mm, then the first bound gives a Poynting flux of 10^{7} erg cm^{2} s^{1}, which is roughly equal to the observed coronal heating rate. However, it is probably more realistic to take a longer domain, say h = 8L, in which case the estimated Poynting flux is approximately 10^{6} erg cm^{2} s^{1}. A possible reason for this shortfall, compared with Parker’s simple estimate of 10^{7} erg cm^{2} s^{1} (Parker 1983), is the slower flow speeds in our observations. However, when we compute the bounds for a numerical convection simulation with faster flows (Sect. 4.3), the first bound is only slightly increased. On the other hand, the simulations do suggest that smoothing of the observed velocity field – mainly due to resolution limits of the observations – could be responsible for the discrepancy between the second bound and the first. This indicates that braiding of flux ropes may be a more important source of energy than the observations suggest. On the other hand, both cases show a roughly linear increase in energy with time. Berger (1991) suggests that such a linear increase is expected if energy is injected mainly by translations of individual flux tubes, and that if energy were mainly injected by entanglement of multiple tubes, a quadratic increase would be expected (as in our simple example in Sect. 2.3).
We have also put a (nonrigorous) upper bound on the magnetic energy by constructing a magnetic field whose field lines are effectively the footpoint trajectories (Sect. 4.2). At the end of the 12 h dataset, this gives a Poynting flux of 3.5 × 10^{8} erg cm^{2} s^{1}, essentially independent of h. At one particular time during our observations, we were able to compare these estimates against a Poynting flux estimate using horizontal magnetic field components from a Hinode/SP vector magnetogram. Reassuringly, the estimate of 1.67 × 10^{7} erg cm^{2} s^{1} falls between our lower and upper bounds.
Our assumption of a Cartesian domain, and the lack of information on motions at the opposite end of the field lines, mean that our quantitative estimates can only be taken as indicative. And even if the coronal domain were truly Cartesian, there is no guarantee that our lower energy bounds are tight, in the sense of being attainable by relaxation of the magnetic field without allowing reconnection. However, any more detailed estimate would require a model (or observations) of the threedimensional evolution of the magnetic field in the coronal volume. Such a model would also be required in order to determine when the energy input saturates due to nonideal dynamics in the corona. It is encouraging that MHD models, which do include this saturation effect – albeit at the expense of an artificially high nonideal dissipation in the corona – find heating rates comparable to our estimated Poynting flux.
Whilst chosen to match the observed average vertical magnetic field, our assumption of an initially uniform field at the start of the footpoint motions does not account for the concentration of magnetic footpoints in intergranular lanes. Since vorticity is known to peak in the intergranular lanes (Wang et al. 1995), this might affect the injected energy. However, the estimated Poynting flux in the simulations – where the concentration of footpoints is clearly evident – is comparable to the observations even after concentration has taken place. Such concentration of field line footpoints must be accompanied by an expansion of flux tubes as they pass through the chromosphere to fill the corona. This expansion will not in itself change the connectivity of field lines, but it is likely to impact on the pattern of energy release in the corona (van Ballegooijen et al. 1998). Since our study concerns only the buildup of energy, this and other aspects of the energy release remain for further investigation.
Acknowledgments
We are indebted to JeanJacques Aly for sharing prepublication details of his energy bounds, and to the Royal Astronomical Society for a grant enabling the summer project of F.B. A.R.Y. was supported by STFC consortium grant ST/K001043/1 to the universities of Dundee and Durham, and thanks E. DeLuca whose question motivated this investigation. Hinode is a Japanese mission developed and launched by ISAS/JAXA, with NAOJ as domestic partner and NASA and STFC (UK) as international partners. It is operated by these agencies in cooperation with ESA and NSC (Norway).
