A new model for gravitational potential perturbations in disks of spiral galaxies. An application to our Galaxy
Instituto de Astronomia, Geofísica e Ciências Atmosféricas, Universidade de São Paulo, Cidade Universitária, São Paulo, SP, Brazil
email: tjunqueira@astro.iag.usp.br
Received: 6 June 2012
Accepted: 12 December 2012
Aims. We propose a new, more realistic description of the perturbed gravitational potential of spiral galaxies, with spiral arms having Gaussianshaped groove profiles. The aim is to reach a selfconsistent description of the spiral structure, that is, one in which an initial potential perturbation generates, by means of the stellar orbits, spiral arms with a profile similar to that of the imposed perturbation. Selfconsistency is a condition for having longlived structures.
Methods. Using the new perturbed potential, we investigate the stable stellar orbits in galactic disks for galaxies with no bar or with only a weak bar. The model is applied to our Galaxy by making use of the axisymmetric component of the potential computed from the Galactic rotation curve, in addition to other input parameters similar to those of our Galaxy. The influence of the bulge mass on the stellar orbits in the inner regions of a disk is also investigated.
Results. The new description offers the advantage of easy control of the parameters of the Gaussian profile of its potential. We compute the density contrast between arm and interarm regions. We find a range of values for the perturbation amplitude from 400 to 800 km^{2} s^{2} kpc^{1}, which implies an approximate maximum ratio of the tangential force to the axisymmetric force between 3% and 6%. Good selfconsistency of arm shapes is obtained between the Inner Lindblad resonance (ILR) and the 4:1 resonance. Near the 4:1 resonance the response density starts to deviate from the imposed logarithmic spiral form. This creates bifurcations that appear as short arms. Therefore the deviation from a perfect logarithmic spiral in galaxies can be understood as a natural effect of the 4:1 resonance. Beyond the 4:1 resonance we find closed orbits that have similarities with the arms observed in our Galaxy. In regions near the center, elongated stellar orbits appear naturally, in the presence of a massive bulge, without imposing any barshaped potential, but only extending the spiral perturbation a little inward of the ILR. This suggests that a bar is formed with a halfsize ~3 kpc by a mechanism similar to that of the spiral arms.
Conclusions. The potential energy perturbation that we adopted represents an important step in the direction of selfconsistency, compared to previous sine function descriptions of the potential. In addition, our model produces a realistic description of the spiral structure, which is able to explain several details that were not yet understood.
Key words: Galaxy: kinematics and dynamics / Galaxy: structure / galaxies: spiral / galaxies: bulges
© ESO, 2013
1. Introduction
Despite its historical merit, the spiral structure theory, proposed by Lin & Shu (1964), has wellknown limitations. For instance, Lin & Shu add gas and star into a single component, when their dynamics differ in response to the same potential; stars, for example, are not affected by pressure gradients. Additionally, real arms are not tightly wound, as assumed in that theory, and the physical properties of the disk (densities, velocity perturbations) do not have a sineshaped dependence in azimuth, as argued in the present paper. Around the same time, Toomre (1964), in an opposing point of view, argued that since the largest fraction of matter in the disk is in the form of stars, one can, in a first approximation, neglect the gas and work with stellar dynamics. He devoted much of his attention to understanding why an excess of stars in a given region does not grow without limit, due to the excess of gravitational attraction. Regardless, his model for the arms focused more on stellar dynamics, considering them as regions with stellar excess of stars that rotate with velocity that does not diverge from the velocity of the disk matter.
Kalnajs (1972) proposed an innovative way of understanding the spiral structure, which was focused solely on stellar dynamics. He showed that by introducing some degree of organization to the closed stellar orbits, we can generate regions where these orbits are crowded. Such an organization is achieved by rotating orbits of increasing size by a given angle, relative to previous ones. These regions of high stellar densities look like logarithmic spirals and rotate with the required pattern speed to transform the usually open orbits into closed ones. Furthermore, such an organization of stellar orbits can be achieved via galactic collisions (Gerber & Lamb 1994). The great advantage of the Kalnajs model in comparison to Toomre’s is that the former’s spiral structure is not disrupted by differential rotation; in other words, it can be long lived. It is important to note that the search for stable or quasistationary solutions has traditionally been the aim of dynamical models of disks. This is still a legitimate concern, given that the nearinfrared morphology of several grand design galaxies reveals the existence of an underlying twoarm structure constituted mainly of old stars (Grosbøl & Patsis 1998; Block & Wainscoat 1991; Rix & Rieke 1993; Rix & Zaritsky 1994; Block et al. 1994). Also, Lépine et al. (2011b) argued that, based on the metallicity gradient, the present spiral structure of Galaxy has an age of at least several billion years.
The Kalnajs model is the most promising one, as it gives a correct understanding of the nature of the arms as regions where stellar orbits are crowded. However, Kalnajs’ model is only a first approximation, since it makes use of stellar orbits associated with an axisymmetric potential. In order to reach selfconsistency, one must introduce the effect of the perturbations of the potential on the stellar orbits. The perturbations produce changes in the shapes of the orbits, which in turn change the regions where the orbits are crowded and generate a new perturbation. If at the end of this cycle we obtain approximately the same density distribution as at the end of the starting one, we say that the model is selfconsistent, and that the structure will be long lived. Selfconsistent models, or at least approximately selfconsistent models in terms of arm shapes, were constructed by Contopoulos & Grosbøl (1986, 1988) and Patsis et al. (1991) for large spiral galaxies, and by Amaral & Lepine (1996, hereafter A&L) and Pichardo et al. (2003) for the special case of our Galaxy. In the works of Contopoulos and collaborators and of A&L, the classical expression for the perturbation Φ_{1} was used in a frame of reference rotating with constant velocity Ω_{p}: (1)with some diversity in the amplitude ζ_{0}, the behavior of the amplitude with radius (here represented by R e^{ − εsR}), the number of arms (m), and the pitch angle i. A property of this expression is that if we fix the radius R, the variation of the potential as a function of the azimuthal angle is a sine function. In the work of Pichardo et al. (2003), the perturbing potential is represented as a superposition of a large number of oblate spheroids, with their centers distributed along the locii of the spiral arms. This approach does not give access to a simple analytical expression for the perturbation.
One motivation for this work is that it has become evident that the traditional description of the potential perturbation in terms of a sine function in the azimuthal direction is not satisfactory. It is simple to estimate the stellar density in a region where the orbits are crowded and to compare it with the average field, as well as to perceive that the perturbations are much better described as narrow grooves or channels in the gravitational potential with an approximately Gaussian profile. We present an analytical description of the perturbing potential, which is realistic when compared to observations and produces better selfconsistency compared to other models. Strictly speaking, we give priority to the analysis of one aspect of selfconsistency, which corresponds to the shape of the arms or equivalently to the position of the density maxima in the plane of the galaxy and to their profiles. We employ the expression “selfconsistency of arm shape” to describe our results, although several authors that we mentioned above simply refer to “selfconsistency” for similar analyses. Other advantages related to the expression proposed in this work for the perturbation are 1) avoiding fluctuations between positive and negative values for the potential (as produced by a sinusoidal function) over the whole disk for the whole range of parameters; 2) controlling the arminterarm contrast and; 3) dealing of the thickness of the spiral arms.
The focus in this work is on normal galaxies in which the structure is dominated by spiral arms, not by a bar. Naturally, many galaxies present a weak bar in their center, with an extended region of spiral arms beyond the end of the bar. The present model can be useful to interpret their structure.
In addition to the motivations mentioned above, there has been considerable improvement in recent years in the knowledge of the structure of our Galaxy and, in particular, of its rotation curve and pattern speed (discussed, respectively, in Sects. 4.1 and 6.1). Therefore it is worth constructing a model that is adequate for comparisons with observations and other models. We are conscious that a number of authors consider that our Galaxy has a strong bar, so that our model would not be applicable, but in any case, the comparison with observations may give us clues to this question. Other models that we have already mentioned (A&L, Pichardo et al.; Contopoulos & Grosbøl) use the same hypothesis of spiraldominated structure and are directly comparable.
The organization of this paper is as follows. In Sect. 2.1, we review the classical model for the spiral arms. In Sect. 2.2, we present our new model for the spiral arms discuss the required parameters. In Sect. 3, we deduce the relation between the density contrast and the perturbation amplitude. We constrain the perturbation amplitude to a range of values by means of observational evidence for the density contrast. In Sect. 4 and subsections, we compute the axisymmetric potential for two different rotation curves. First, we use a realistic rotation curve, which is obtained by fitting the data of the Galaxy. The second model uses a “flat” rotation curve that is modeled by two axisymmetric components (bulge + disk) with different bulgetodisk ratios in order to better understand the effect of the bulge component on the stellar orbits. In Sect. 5.1, we present the equations of motion and the integration scheme, and in Sect. 5.2, we derive the density response. In Sect. 6, we discuss the adopted corotation radius and the angular velocity of the spiral pattern. The main results are presented in this section, discussed separately for different ranges of radii: between the Inner Lindblad Resonance (ILR) and the 4:1 resonance, beyond the 4:1 resonance, and the connection between the bulge and the inner stellar orbits. In Sect. 7, we give our conclusions.
2. The spiral arms
2.1. The classical model
The surface density of a zerothickness disk can be represented mathematically as the sum of an axisymmetric or unperturbed surface density Σ_{0}(R), and a perturbed surface density Σ_{1}(R,ϕ), which represents the spiral pattern in a frame that rotates at angular speed Ω_{p}. The azimuthal coordinate at the rotating frame of reference is ϕ = θ − Ω_{p}t, where θ is the angle at the inertial frame. As usual, the physical surface density is given by the real part of the following equation (see Binney & Tremaine 2008): (2)where f_{m}(R) is the shape function, which describes the spiral, and Σ_{s} is a varying function of radius that gives the amplitude of the spiral pattern. From Σ_{1}, as described by Eq. (2), we derive the potential Φ_{d}, using Gauss’ law, and obtain (3)where (4)In the above expression, k is the wavenumber and G the Gravitational constant. Using Eqs. (3) and (4), we get (5)This is a wellknown result, found by Lin et al. (1969) and derived from the WKB theory (see also Appendix B).
2.2. The new potential for the spiral arms
Before we begin, it is important to clarify what we understand by spiral arms. The model we adopt is based on the idea of Kalnajs (1972) of stellar orbits of successively increasing radii in the disk, organized in such a way that they get close together in some regions, thus presenting excesses of stellar density.
Traditionally, the perturbed surface density has been described by Eq. (2). This approach, however, is not realistic. The brightness profiles observed in galactic disks in circles around the center are not sine functions, nor are the density profiles obtained theoretically from the crowding of stellar orbits. The surface density we consider to be realistic is given by a density excess that follows a logarithmic spiral, with a Gaussian profile in the transversal direction. The potential that produces this kind of density has the form (6)where ζ_{0} is the perturbation amplitude, the scale length of the spiral, σ the width of the Gaussian profile in the galactocentric azimuthal direction, the wavenumber, and f_{m}(R) the shape function. The scalelength of the disk and of the spiral are not necessarily the same. This question is discussed in Sect. 3. The shape function is (7)where m is the number of arms, i is the pitch angle, R_{i} is the point where the spiral crosses the coordinate x = 0, and γ is only a phase angle.
Fig. 1 Azimuthal density profile at different radii for m = 2, i = 14°, and σ = 4.7 kpc. Here we set Σ_{s0} = 1, since we only want to show how the density profile varies with the azimuthal angle.

Open with DEXTER
Solving Poisson’s equation using Eq. (6), with the assumption of zerothickness disk and of tightly wound spiral arms (TWA) in the plane z = 0 we have (8)where Σ_{s0} is associated with the perturbation amplitude (see Appendix B for more details) by the equation (9)The azimuthal profile corresponding to Eq. (8) is illustrated in Fig. 1. We emphasize that σ is the halfwidth of the spiral arms in directions of galactocentric circles (see deduction in Appendix A). Because all these circles cross the logarithmic arms with the same angle i, the true width in a direction perpendicular to the arms is given by σ_{ ⊥ }(10)This parameter allows us to reproduce arms of different widths, as shown in Fig. 2.
Fig. 2 Map of the perturbing potential in the plane of the galaxy. The colors represent the values of Φ_{1}(R,ϕ) in arbitrary units. The picture on the left is the potential with σ = 2.5 kpc and on the right σ = 4.7 kpc. For i = 14° we have on the left σ_{ ⊥ } = 0.6 kpc and on the right σ_{ ⊥ } = 1.1 kpc.

Open with DEXTER
Fig. 3 Radial force due to the spiral arm in the direction ϕ = 0. The circles in red represent the radial force due to our potential, while the crosses in green represent the radial force associated with the classical sine function perturbation. Here, positive values of the force mean that a star would be pushed outward and negatives values that it would be pulled inward with respect to the galactic center. In this figure, the number of arms is m = 2, the pitch angle i = 14°, ε_{s} = 0.4 kpc^{1}, and for our model the arm width σ = 4.7 kpc.

Open with DEXTER
Figure 3 plots the radial force produced by the spiral arms in our model (red circles, which are very similar to Pichardo et al. 2003) compared with the classical model (green crosses, derived from Eq. (3)) as a function of Galactocentric distance R. In both cases the perturbation amplitude was set to be equal to one, since we just want to see how the force profile varies and are not interested in absolute values. The first thing we can notice in Fig. 3 is that for the classical model the radial force is stronger for the same perturbation amplitude, mainly in inner regions. Thus, the perturbation amplitude in the classical case would be lower than in our model. This is due to the fact that a sinusoidal potential varies between positive and negative values and that the force, proportional to the variations of potential, is stronger than in a case where the potential ground level is equal to zero. Another difference between the two models occurs around 9 kpc, where, in the classical model, the force becomes positive while in our model the force slowly tends to zero, but it is still negative. This happens because a star in that region feels the effect of the last piece of the arm, as we can see in Fig. 2 in the x direction, so that it would be pulled inwards.
3. Relation between density contrast and perturbation amplitude
Following Antoja et al. (2011) we take as a measure of the density contrast (11)where Σ_{d} is the axisymmetric surface density and Σ_{s0} is the maximum density of the spiral arms. This relation is valid under the assumption of a masstolight ratio of the order of 1 when A_{2} is measured in the infrared bands (Kent 1992). Antoja et al. (2011) collected in the literature the estimations of Galactic and extragalactic density contrasts, and found them to be in the range 0.13 ≤ A_{2} ≤ 0.23. Therefore, an average value would be about A_{2} = 0.18.
Adopted spiral arms properties.
The maximum density of the spiral arms is given by Eq. (9). We refer to the maximum at a certain radius, not a maximum over the whole disk. To simplify the analysis, we assume that the axisymmetric surface density has an exponential behavior (Eq. (12)). Galactic disks are often represented by exponential density laws and, depending on the value of ε_{d}, can explain relatively flat rotation curves. We know that such an exponential law will not generate an exact fit to the rotation curve, given by Eq. (17), but it simplifies the analysis and gives us a good hint about the value of the perturbation amplitude (12)Therefore the density contrast is (13)The density contrast depends not only on the perturbation amplitude ζ_{0}, but also on σ, which describes the arms width. In our model, we can set σ as a constant or a function of radius. If we assume that the scale length is the same for both components (ε_{d} = ε_{s}, which is a reasonable assumption because we do not want the amplitude of the spiral to drop too fast outwards) and compute the value of σ_{0} using the density of the solar neighborhood, Σ_{d}(R_{0}) = 49 M_{⊙} pc^{2} (see Binney & Tremaine 2008, Table 1.1), for R_{0} = 7.5 kpc and kpc we get σ_{0} = 984 M_{⊙} pc^{2}. Then, using the values from Table 1 for the number of arms and the pitch angle, Eq. (13) reduces to (14)Since we have used, up to now, parameters of the spiral structure that are based on studies of our Galaxy, we shall estimate the contrast for a galactocentric distance of about 5 kpc, which in our model is about midway between the ILR and corotation, as discussed in Sect. 6. Numerically we have R ≈ σ, so that Eq. (14) becomes (15)A plot of the density contrast based on this equation is shown in Fig. 4. Comparing the values of A_{2} from the literature, as discussed above, with this figure, we find a range of amplitudes of the perturbation between 400 to 800 km^{2} s^{2} kpc^{1}, which is compatible with the range of density contrasts of Table 1. Taking an average value A_{2} = 0.18 gives us ζ_{0} = 600 km^{2} s^{2} kpc^{1}.
Fig. 4 Density contrast Σ_{s0}/Σ_{d} as a function of perturbation amplitude for the Milk Way.

Open with DEXTER
This is an estimate for R ≈ 5 kpc. However as we can see from Eq. (14), the density contrast increases with radius. Kendall et al. (2011) and Elmegreen et al. (2011) showed many galaxies with a growth of density contrast with radius. If we adopt ε_{d} = ε_{s}, the density contrast varies as the square of the radius, which seems a little too fast in many cases. This problem can be attenuated in two ways: 1) the scale length of the spiral and of the disk may be slightly different (ε_{d} < ε_{s}), which will produce an exponential decrease; 2) the arms width may increase with radius, producing a density contrast with moderate increase, closer to the results of Kendall et al. For a specific galaxy, it would be possible to check the azimuthal density profile and its variation with radius and to adjust the parameters to match the observations. One merit of our model is that it facilitates such adjustments.
4. The axisymmetric component
The main dynamical information of a spiral galaxy is derived from its observed rotation curve. In fact, the rotation curve gives us the radial gradient of the potential, since we can compute Φ_{0}(R) by integrating Eq. (16): (16)where V_{rot} is the rotation curve.
4.1. The rotation curve of the Galaxy
To contribute to a deep understanding of the spiral structure of any given galaxy, we must make the effort of introducing the real parameters, such as the dimension of the components, the rotation curve, and the pattern rotation speed. Although there may be controversies concerning some of these parameters, we chose to illustrate our model of spiral perturbation by applying it to our Galaxy. However, we also used a simplified analytical expression for the rotation curve, introduced in the next subsection, with the aim of reaching qualitatively a general understanding of the effect of the the mass of the bulge on the inner orbits.
The “real” rotation curve of the Galaxy that we have adopted (Fig. 5) is quite flat, except for a local minimum at about 8.8 kpc. The existence of this dip in the curve is revealed, for instance, by the study of the epicycle frequency in the galactic disk (Lépine et al. 2008). This is confirmed in a recent work by Sofue et al. (2009), which makes use of different data sets, including data on masers with precise distances measured by parallax, to trace the curve. The rotation curves presented in these two papers are quite similar, except for minor scaling factors due to the adopted galactic parameters, the solar distance from the Galactic centers R_{0}, and the solar velocity V_{0}. The curve is conveniently fitted by two exponentials and a Gaussian (17)The first two components contain terms in (1/R) and (1/R)^{2} inside the exponential function, which produce a decrease of their contribution towards small radii. The last (Gaussian) term represents the local dip. The interpretation of a similar curve, except for the dip, in terms of components of the Galaxy is given by Lépine & Leroy (2000) and is different from that of Sofue et al. (2009). The pattern speed is discussed in Sect. 6.1.
Fig. 5 Rotation curve of the Galaxy. The red line is the rotation curve fitted using Clemens’ data (black dots), and the blue line is the pattern speed Ω_{p} × R corresponding to an angular velocity Ω_{p} = 23 km s^{1} kpc^{1}. The corotation radius is at 8.4 kpc. We adopted R_{0} = 7.5 kpc and V_{0} = 210 km s^{1}.

Open with DEXTER
Fig. 6 Axisymmetrical potential as a function of the galactocentric radius R.

Open with DEXTER
Figure 6 shows the axisymmetric potential that results from the integration of Eq. (16). We used the trapezium rule with adaptive step to solve the integral, and we fixed the potential as equal to Φ_{0}(100) = 0 at R = 100 kpc in order to set the arbitrary constant.
4.2. A model of a flat rotation curve with a bulge
Many galaxies have a flat rotation curve, but some of them present a peak in the inner part. For instance, as seen in Fig. 5, a peak for our Galaxy appears at a radius smaller than 2 kpc, with a maximum around 300 pc. The nature of the peak is a subject of debate. Some authors consider that it is not due to rotation, like Burton & Liszt (1993), who believe that there is a strong velocity component of gas outflow from the central regions of the Galaxy. Others consider that an important departure from axisymmetric, like a triaxial bulge according to Gerhard & Vietri (1986), is required to explain the peak. To perform a first approximation analysis on the effects of the presence of a bulge on the stellar orbits in the inner regions of a galaxy, we adopt the hypothesis that the bulge is axisymmetric, as it seems to be, at least approximately, in most spiral galaxies (MéndezAbreu et al. 2010). Also in axisymmetric bulges, one can find elliptical orbits in their central regions. Then, even a very small perturbation could give rise to an oval structure. Since in this part of the work we are not interested in solving the specific case of our Galaxy, but want to have a more general idea of the effect of a bulge, we do not use the observed rotation curve of our Galaxy. Instead, we use a simpler one from which the potential is obtained analytically, thus avoiding numerical integrations. For this study we adopt the model for the rotation curve given by Contopoulos & Grosbøl (1986), in which the presence of the peak is modeled by two axisymmetric components (bulge + disk): (18)Here and are the scale length for the bulge and disk components, respectively. The relative importance of the two components is given by the bulge fraction f_{b}.
We analyzed the inner stellar orbits obtained with rotation curves with different values of f_{b}, that is, with different importance of the bulge. The results are discussed later, in Sect. 6.
5. Stellar orbits
5.1. The integration scheme
Once we know the two components of the potential, Φ_{0}(R) and Φ_{1}(R,ϕ), we can derive the equations of motion governed by them. Figure 7 illustrates the angles and angular velocities used in the equations. When the Galactic plane is represented, the motion of stars and the pattern speed are shown clockwise, which corresponds to negative values of angular velocities.
Fig. 7 Scheme of the Galactic plane. The yellow dot represents a star rotating with speed in a frame of reference (dashed line) corotating with the spiral arms at the angular velocity Ω_{p}.

Open with DEXTER
The Hamiltonian for such a system is given by (19)where p_{r} and J_{1} are the linear and angular momentum per mass unit, respectively. It is important to note that J_{1} is measured with respect to the inertial frame. The equations of motion are The equations above were integrated using the 6th order implicit RungeKuttaGauss (RKG; see SanzSerna & Calvo 1994, for more details), with a fixed time step dt = 10^{1} Myrs. To find the stable periodic orbits, we applied the method of Poincaré’s surface of section (Poincaré 1892). The Poincaré section was fixed where the orbits cross the axis ϕ = 0°. The periodic orbits trapped around circular orbits are represented by a sequence of points in the phasespace (R,p_{r}), lying on a curve called an invariant curve.
In practice, what we do is to compute the energy of a circular orbit using Eq. (19). Thus this equation becomes (24)This expression has no perturbation terms. The angular momentum per mass unit is given by J_{0} = RV_{rot}, and Φ_{0}(R) is the galactic potential. For each radius, we have a value of energy h, then we come back to the Eq. (19) with H = h. Thus, we have to find the initial conditions (R,p_{r},J_{1},ϕ) that will close the orbit for a given h. The last variable can be fixed at ϕ = 0, and the angular momentum J_{1} is found solving Eq. (19) for a given R and p_{r}. Therefore, we only have to deal with the pair of variables (R,p_{r}). The pair that gives us a stable periodic orbit is found at the center of the island in the Poincaré section.
The families of periodic orbits that we obtained (starting from energies equivalent to circular orbits spaced 0.2 kpc apart, from 3 up to 8 kpc) are shown in Fig. 8. The inner part from 2 up to 3 kpc was avoided here; we discuss this region in Sect. 6.4.
Fig. 8 Series of closed orbits in the plane of the Galaxy obtained using the rotation curve of Eq. (17). The spirals indicated in green represent the imposed perturbation; they coincide with the response density (red dots) up to 4:1 resonance. The red circle is the corotation radius (R_{cor} = 8.4 kpc). The perturbation amplitude is ζ_{0} = 600 km^{2} s^{2} kpc^{1}. The yellow dot shows the Sun position.

Open with DEXTER
5.2. Response density
The response density is computed by considering the conservation of flux between two successive orbits in the perturbed and unperturbed cases (Contopoulos & Grosbøl 1986). In our case we consider a series of circular orbits spaced at 0.2 kpc. We can imagine in each orbit a large number of stars equally spaced in the unperturbed case. The area S of an angular sector, which is between two neighboring orbits and two successive stars in each orbit, is transformed into S′ when the perturbation is introduced. The two areas contain the same mass, so that the density is proportional to 1/S′. There are two reasons for the change in distance between neighboring stars. In the radial direction, it is because the orbits approach or recede one from the other. In the azimuthal direction, it is because the stars travel at different angular velocities along the orbit. Due to the conservation of angular momentum, the stars move more slowly when they are at larger galactic radius, and get closer to one another, since the flux is conserved. This is easy to take into account, since the spacing between stars is . The response density can be written as (25)where Σ_{c} is the density, R_{c} is the radius, and ΔR_{c} is the spacing between two successive orbits, all of them in the unperturbed case, while the same quantities in the denominator refer to the perturbed situation. The quantity Δt is the time spent by a star to move from ϕ to θ + Δϕ, while T is the period. In practice, what we do is to divide the circles in N sectors, thus making it possible to find the positions R and the time for each angle, defined by iΔθ (i = 1...N). Therefore we can find the time Δt spent by the star to move between two adjacent sectors.
Since we are interested in the position of maximum response density for each orbit, Eq. (25) reduces to (26)As the values of Σ_{c}, R_{c}, ΔR_{c}, and T do not change in a given circle, they can be ignored in Eq. (25). Thus the position of maximum density is the sector where Eq. (26) reaches its maximum value.
We are interested in the position of maximum response density for each orbit. The position of the density maxima is shown in Fig. 8.
6. Results
6.1. A model for our Galaxy
Throughout this work, we have adopted the parameters that appeared to us to correspond to our Galaxy, like those presented in Table 1, and the rotation curve. In the next sections, we present both general results, which are valid in principle for other spiral galaxies, and specific results, which depend on the exact choice of parameters. One of the most important choices when we apply a model to a galaxy is that of the pattern speed, or equivalently, if the rotation curve is known, of the corotation radius.
In the last few decades, many papers have pointed to a corotation radius of the Galaxy situated close to the orbit of the Sun (Marochnik et al. 1972; Creze & Mennessier 1973; Mishurov & Zenina 1999, among others). An additional argument is that the classical theory of spiral arms tells us that the arms exist between the Inner and Outer Lindblad resonances and that the corotation falls roughly midway between these resonances. The data from the literature collected by Scarano & Lépine (2013) supports the theory, showing that the corotation occurs about midway between extremities of the region where the arms are seen. In our Galaxy, the spiral arms extend from about 3 kpc to 13 kpc (e.g., Russeil 2003), which would situate the corotation at about 8 kpc. Recently, a few direct methods allowed the decrease of the uncertainty on the corotation radius to a few hundred parsecs. One example is the determination of the pattern speed by integrating the orbits of open clusters back to their birthplaces. As shown by Dias & Lépine (2005), the result, R_{CR} = (1.06 ± 0.08)R_{sun}, does not have any strong dependence on the adopted rotation curve. A second direct observation is the position of the ringshaped HI void at corotation (Amôres et al. 2009), and a third one the position of the squareshaped spiral arm associated with the 4:1 resonance (Lépine et al. 2011a). The existence of a gap in the distribution of open clusters and of Cepheids, along with a step in the metallicity distribution, is naturally explained in terms of the corotation resonance (Lépine et al. 2011b). What we call a direct method is one that does not involve any complex model with uncertain parameters and therefore generates robust results. This is not the case of nbody simulations, or chemical evolution models. Based on the results above, we adopt R_{CR} = 8.4 ± 0.2 kpc; accordingly, with Eq. (17), we find Ω_{p} = 23 km s^{1} kpc^{1}.
In the present work, we have not investigated the spiral structure beyond corotation, a task left for future work. As we discuss in the next sections, there is a change in the nature of the arms at the 4:1 resonance. Only between the ILR and that resonance are the arms explained by the crowding of stellar orbits.
There are models of the spiral structure that are in conflict with the corotation radius that we advocate. For instance, model of the inner Galaxy by Dehnen (2000) suggests that the radius of the Outer Lindblad Resonance (OLR) of the Galactic bar lies in the vicinity of the Sun. His model does not belong to the category of direct methods, as we defined above, since it is a simulation and by nature, based on many approximations and uncertain parameters. The author does not claim that he presents a precise determination of the OLR of the bar and suggests that this radius is ≈ 6–9 kpc. A recent review of pattern speeds in the Galaxy is given by Gerhard (2011). He recognizes that the pattern speed of the spiral structure is about 25 km s^{1} kpc^{1}, but favors the idea that the bar rotates at a higher velocity. The review does not mention the work of Ibata & Gilmore (1995), who determined the rotation speed of the bulge, which was found to be the same that we adopt for the spiral arms. In a study of the morphology of bars in spiral galaxies, Elmegreen & Elmegreen (1985) concluded that in latetype spirals the bar may extend only to the ILR. This is the hypothesis that we adopt to compare our model with the Galaxy, based on the fact that the solar neighborhood contains spiral arms only.
6.2. The structure between the ILR and the 4:1 resonance
Many studies of selfconsistency have been performed (Contopoulos & Grosbøl 1988; Patsis et al. 1991; Amaral & Lepine 1997; Pichardo et al. 2003; Martos et al. 2004; Antoja et al. 2011). Contopoulos & Grosbøl (1986) already studied the response density and concluded that strong spirals do not exist beyond the 4:1 inner resonance. This result was confirmed by the other works and also by the present work. In Fig. 8 we show the locii of maximum response density of our model. It can be seen that there is a very good selfconsistency of the shape of the spiral arms in the region inside the 4:1 resonance. This selfconsistency is particularly satisfactory in the case of our model, since a potential perturbation with a Gaussian profile generates a very similar response density and response potential. The fact that two wellbehaved logarithmic spiral arms extend about the 4:1 resonance is a robust result, which was encountered by the various works mentioned above, although they use a variety of axisymmetric potentials and perturbation potentials. It also corresponds to an observed characteristic of spiral arms, since Elmegreen & Elmegreen (1995) observed that most spiral galaxies have two prominent symmetric arms in their inner regions, inside approximately 0.5 R_{25}, where R_{25} was defined by them as the radius for which the surface brightness is 25 mag arcsec^{2}. These authors suggest that the termination of these arms could coincide with corotation. This robust structure, with a similar aspect in many spiral galaxies, is possibly the one that is able to determine the pattern speed. That the pattern speeds are found to have a distribution concentrated around 24 km s^{1} kpc^{1} (Scarano & Lépine 2013), in other words, they are not arbitrary.
We would like to call attention to an interesting effect. One can see that the maximum response density starts to be out of phase with respect to the logarithmic spiral perturbation near the 4:1 resonance. This suggests that the deviation from a perfect logarithmic spiral in galaxies can be understood naturally as an effect of the 4:1 resonance. A consequence of this is the appearance of bifurcations. They happen because when the response density starts to be out of phase with the imposed density, part of the matter remains following the imposed density. This results in a weaker piece of arm. In galaxies with a structure similar to that of the Milky Way, the appearance of bifurcations is possibly associated with the 4:1 resonance, rather than with the corotation. This is not a new result, since it was already discovered from a theoretical approach, for instance, by Patsis et al. (1994) and Patsis et al. (1997). This is also a robust result because it does not depend on the details of a given rotation curve. Observationally, the work of Elmegreen & Elmegreen (1995) also states that bifurcations start at the end of the two prominent symmetric arms.
6.3. Beyond the 4:1 resonance
In our model, there is a clear change in the nature of the arms beyond the 4:1 resonance. There are no more arms produced by the concentration of stellar orbits, but only discrete resonant orbits. How could a resonant orbit behave like a spiral arm? This may happen if stars are captured within resonances, similarly to asteroids in the Solar system, for which the trapping mechanism was described by Goldreich (1965). For instance, in the asteroid belt, the 3:2, 4:3, and 1:1 resonances with Jupiter are populated by clumps of asteroids. Similarly, the stars captured within resonances could produce a local increase of density and turn it into a kind of arm. If this model is correct, when applied to our Galaxy, it would predict that some of the arms seen in the solar neighborhood have the form of resonant orbits.
Direct evidence of an arm with the shape of a 4:1 resonant stellar orbit was found by Lépine et al. (2011a) using as tracers molecular CS sources, Cepheids with a period longer than six days, and open clusters with ages less than 30 Myr. The map obtained in that paper is reproduced in Fig. 9. Here, the same symbol has been used for all the kinds of tracers, since we are only interested in the general structure. It must be remembered that nowadays only in the Solar neighborhood we can have a detailed description of the spiral structure, since interstellar extinction does not allow open clusters and Cepheids to be observed at more than a few kpc.
Fig. 9 Plot of the observed arm structure of the Galaxy in the solar neighbourhood. The Sun is at the center of the figure, and the distances on the two axes are relative to the Sun. The Galactic center is downward and outside the figure. Different kinds of objects have been added to better trace the structure, all of them shown with a same symbol (gray dots): Cepheids, open clusters, CS sources (see text for details). Curve a, in brown, represents a stellar orbit at the 4:1 resonance, and curve b an orbit at the 6:1 resonance. Curve c is not identified in terms of resonances, since it is a linear fit to the observed points. The other lines (two in red, one in green) are logarithmic spirals fitted to the data.

Open with DEXTER
Figure 9 can be seen as a zoom of the upper part of Fig. 8, in the region around the Sun. One can observe the presence of a structure with an angle of about 90° (labeled “a” and brown in the figure), which was identified by Lépine et al. (2011a) with the 4:1 resonance. The argument was not only the fit presented in this figure, but also much more the points observed along a straight portion of about 7 kpc in length, in addition to the fact that the resonance is exactly where it is predicted to be, based on the known pattern speed. Now, we also present a fit of an orbit at the 6:1 resonance to many of the observed points (curve with label “b”, in blue). This greatly resembles a predicted structure in Fig. 8, which passes close to the corner of the arm at the 4:1 resonance and close to the Sun, in addition to presenting an acute corner in the second quadrant of the Galaxy.
Stable periodic orbits attract around them quasiperiodic orbits, as indicated by the contours of the islands in the Poincaré’s surface of section. It seems that in the region of the disk discussed here, quasiperiodic orbits are trapped around the stable periodic orbits of the 4:1 and 6:1 families, with very small deviations from the periodic orbits themselves. As a result the quasiperiodic orbits could be considered as building a “thick periodic orbit” structure. These arms, which are composed of similar quasiperiodic orbits, would have very small dispersions of velocities.
Finally, one can see in Fig. 8, just below the corner of the 4:1 resonance, an orbit that crosses it in two points. This resembles the armlike structure with label C in Fig. 9. We consider that this observed structure is probably real, due to the large number of tracers that fall on it. This suggests an interesting concept. Since resonant orbits can cross each other, it is also possible to have armlike structures which correspond to them crossing each other. This contrasts with the classical view of spiral arms, in which no such intersections exist.
Of course, the interpretation we give of some local structures may not seem convincing. One possible argument against it is that the resonant orbits do not seem to be uniformly populated by stars all around them. However, the mechanism of the capture of stars by resonances deserves deeper study to determine if some regions of the orbits should present a larger population. The solar neighborhood is rich in structures that have not been explained by any model. One could argue that they are not explainable because they are due to stochastic events. The idea that we propose here, that some of these structures correspond to resonant orbits, can be verified, since at each point of such an orbit we have a particular velocity of the stars that are trapped into it. However, this is not the scope of the present paper. We did not make any adjustment of the parameters of the model in order to fit observed structures. Parameters like V_{0} (which affects the rotation curve), the exact depth and location of the local minimum in the rotation curve, Ω_{p}, and the width, depth, and pitch angle of the imposed perturbation could all have been submitted to minor variations. Our experience is that this is a lengthy task, with minor variations of the structures produced and some redundancy (different combinations can give similar results). The comparison with the observed data is difficult in part due to its poor quality. Besides, some fitted models may look better in one region of the galactic plane but worse in another. So, we also leave this task for future work.
Like the previous works on selfconsistent spiral structure, we did not extend the calculation of stable orbits beyond the corotation radius. We expect to see resonant orbits as well, but the comparisons with real arms will be even more difficult because the distances and shapes of the external arms of our Galaxy are poorly known. What is known, from an observational point of view, is that the spiral arms show strong departures from logarithmic spirals in the external regions of galaxies. In most cases, the arms look more like a sequence of straight segments that roughly follow a spiral path (e.g., Chernin 1999).
Fig. 10 Rotation curves and corresponding inner orbits for different strengths of the bulge. At the top are the rotation curves for different values of f_{b} (see text). From left to right, the parameter f_{b} is 3.2, 2.2, 1.2, and 0, respectively. Below are the orbits associated with each rotation curve. The blue line is the bulge contribution, the green line is the disk contribution, and the red line is the bulge + disk contribution.

Open with DEXTER
6.4. The bulge and the bar
About 50% of spiral galaxies have a bar, either strong or weak, and there are both kinematic and photometric evidences that the Milky Way has a bar (Binney & Tremaine 2008, Sect. 6.5). Shen et al. (2010) argue that the Galactic bulge is a part of the disk and suggest that the bulge (in reality, a boxy pseudobulge) of the Milky Way is an edgeon, buckled bar that evolved from a cold, massive disk.
Fig. 11 Poincaré diagrams and their respective families (x_{1},x_{2}) of perturbed periodic orbits (see Contopoulos 1975, for details). In both cases we set the energy at R_{c} = 2.2 kpc, and the perturbation parameters are the same as Table 1. The only difference is the bulge fraction f_{b}; at the top we have f_{b} = 3.2 and below we have f_{b} = 0.

Open with DEXTER
In this section, we analyze the connection between the spherical central bulge and the inner stellar orbits. Figure 10 shows the rotation curves from Eq. (18). The scale lengths for the disk and the bulge are fixed at kpc^{1} and kpc^{1}, V_{max} = 220 km s^{1}. The parameter f_{b}, defined in Eq. (18) as “the bulge fraction”, is equivalent to a measure of the “bulge strength”, since the disk component is kept constant (only the bulge is varied), or even to a measure of the bulge density, since its scale size is kept constant. We will refer to it as the bulge strength. We varied f_{b} from 3.2 down to 0. Below each rotation curve in Fig. 10, we show the family of perturbed periodic orbits trapped around unperturbed periodic orbits from R_{c} = 2 up to 4 kpc; see Sect. 5.1 for more details. For a given energy h, which correspond to a radius R_{c}, we may have more then one periodic orbit. The family of periodic orbits lies at the center of the island in the Poincaré diagram. We call it family x_{1} if the center of the island lies at R ≤ R_{c}, and family x_{2} if R ≥ R_{c}, (see Contopoulos 1975).
The parameters for the spiral perturbation are the same as given in Table 1. The orbits in the inner region, almost perpendicular to the more external orbits, belong in Fig. 10, to the family x_{2} of periodic orbit. They are more prominent where we have a strong central bulge (f_{b} = 3.2); as the bulge weakens, the families of orbits x_{2} disappear, as we can see in Fig. 11. In the case where f_{b} ≠ 0, we have two families of stable orbits (x_{1},x_{2}). In Fig. 10, we plot the orbits corresponding to families for which we have only small deviations from R_{c} and those with a realistic distribution of velocities. As we can see in Fig. 11 on top, the family x_{1} has a large deviation from R_{c} with a velocity in the order of p_{r} ≈ − 150 km s^{1} generating a very eccentric orbit, while the family x_{2} is close to R_{c} with p_{r} ≈ 20 km s^{1}; thus, we expect that it would be the favorite family to populate this region. It is clear that strong bulges favor the x_{2} family in the inner regions of the Galaxy, while without a bulge we have only the family x_{1}.
A visual inspection of the orbits associated with different rotation curves shows elongated stellar orbits in the inner regions of the disk for rotation curves with the presence of a peak near the center, suggesting the formation of a bar with a halfsize ~3 kpc. This model shows the existence of a correlation between the formation of a bar and the magnitude of the central bulge. The peak in the rotation curve becomes visible when f_{b} is relatively large (3.2 or 2.2). A strong bulge generates a prominent velocity peak in the rotation curve and modifies the inner stellar orbits. In other words, the strength of the bulge has an influence on the existence of a bar. This bar appears as a consequence of the same potential perturbation that we introduced for the spiral arms, so that the bar and the spiral arms have the same rotation velocity. The type of bar that we are discussing here corresponds to what is understood as a weak bar. In principle, this would seem to be more compatible with the model of spiral arms presented in this work, in which no effect of a bar is taken into account in the large “spiral” region that we described. A bar is weak if it generates only a small fraction of the total gravitational field around it. In such systems, the stellar orbits can be described by the epicyclic theory plus a weak driving force due to the periodic motion of the bar. In our Galaxy, the mass associated with the spherical bulge is much larger than that associated to the bar, as deduced from infrared luminosity (e.g., Lépine & Leroy 2000). One can even expect that at a distance of the order of 1 kpc from the center, outside the bulge but under its strong influence, the potential is Keplerian, with a dominant mass at the center. In such a potential, the orbits are elliptic, with the center of the Galaxy at one focus of the ellipse, like the orbits of comets in the solar system. In epicycle theory, these are 1:1 orbits. Two families of such orbits aligned along a straight line, one on each side of the bulge, would be in part responsible for the bar. The alignment of such elongated, onesided orbits with the inner extremity of the spiral arms would occur naturally, since stars travel slowly when they are at the apogalactic parts of their orbits and this facilitates synchronization. Of course, we are not presenting here a complete model of a weak bar, but only arguing that the existence of a weak bar in our Galaxy should not be rejected. If we consider that the origin of the spiral structure is related to the interaction with an external galaxy, it is more logical to think that the bar is induced by the spiral structure, and not vice versa. An interesting possibility is that since the only imposed perturbation here is that of the spiral arms, our results support the idea that a pseudobulge could have evolved from a perturbed disk (Shen et al. 2010).
We must add to the list of similarities between our model and the real Galaxy the agreement, in Fig. 8, between the orientation of the elongated inner orbits, where the spiral arms seem to begin, with respect to the Sun. This is very similar with the observed angle between the Sun and the extremities of the bar (see, e.g., Lépine et al. 2011a).
7. Conclusions
We have presented a new description of the spiral structure of galaxies, based on the interpretation of the arms as regions where the stellar orbits of successive radii come close together, producing large stellar densities. In other words, the arms are seen as grooves in the potential energy distribution. Such an approach is not new (e.g., Contopoulos & Grosbøl 1986; Amaral & Lepine 1997). The innovation is that the potential energy perturbation that we have adopted is itself like a groove that follows a logarithmic spiral, with a Gaussian profile in the direction perpendicular to the arms. This represents an important step in the direction of selfconsistency, since this potential perturbation generates, by means of the stellar orbits, spiral arms with a similar profile. In previous classical models, the potential perturbation was represented by a sine function (or a sum of two sine functions, if four arms are presented) in the azimuthal direction, but the response potential resembled the groovelike one of the present work, so that the selfconsistency was poorer. One of the classical models (Pichardo et al. 2003) does not use a sine function for the imposed potential, but its complexity does not allow an easy check of selfconsistency.
A new parameter appears in our description, allowing us to control the width of the arms. We found a relation between the density contrast between the arm and interarm region, and the perturbation amplitude, under the assumption of an exponential disk.
We confirm the conclusion of previous works that the 4:1 inner resonance is a fundamental structure of the disk and that similar strong arms do not appear beyond this resonance. This result is supported by observations, since it is known that most spiral galaxies have two symmetric prominent arms in their inner regions (Elmegreen & Elmegreen 1995).
The model is applied to our Galaxy, using a description of the axisymmetric potential similar to that derived from the observed rotation curve, along with the known pattern rotation speed and pitch angle. The range of values for the perturbation amplitude compatible with observational evidences of the contrast density is 400–800 km^{2} s^{2} kpc^{1}. Using a density contrast of about 20%, an accepted average value, the perturbation amplitude ζ_{0}, is equal to 600 km^{2} s^{2} kpc^{1}. It is found that the orbits in the region between the 4:1 resonance and corotation do not reinforce spiral arms like in the inner regions, but only features similar in shape with the periodic orbits existing in this region. If the model can validly explain the spiral arms in the solar neighborhood, then the dynamics in that region is determined by the motion of stars in quasiperiodic orbits.
Interestingly, a number of observed structures are very similar to the predicted resonant orbits. The similarities of the model with the Galaxy include the orientation of the bar, the size and orientation of the 4:1 resonance orbits as revealed by Lépine et al. (2011a), and possibly a resonant orbit with outward peaks or “corners” and inverted curvature between the corners, situated close to the Sun.
The idea that the spiral structure can be selfconsistent (a certain perturbing potential gives rise to stellar orbits that reproduce this perturbation) points towards a longlived structure. This view is in conflict with some recent interpretation of the spiral arms as transient features (e.g., Sellwood 2011), but consistent with the argument that the spiral structure must be long lived based on the observation of the metallicity step at corotation (Lépine et al. 2011b).
Another interesting result of the present model is that a bar naturally appears, without imposing any special condition except that the spiral perturbation potential extends a little inwards of the ILR. We can see elongated orbits in the central regions of the Galaxy, which we identify as being a weak bar. We found a correlation between the presence of the elongated central orbits and the mass of the bulge. The bulge of our Galaxy is a relatively massive one, as revealed by the peak in the rotation curve near the center, and consequently can generate a weak bar, according to this model. This bar would have the same pattern speed of the spiral arms.
We are conscious that there are many works in the literature that are in conflict with our results. They propose, for instance, different corotation radii and different values for the pattern speed, the existence of several pattern speeds in our Galaxy, or that the arms are transient structures. Another idea is that the bar rotates with a different speed relative to the spiral arms. There is also a fashionable artistic view of the spiral structure offered by a NASA site, often reproduced in scientific works, which presents the Galaxy as a perfect logarithmic spiral up to large radii. Such a structure could not be a transient one. Still others consider that swing amplification underlies the basic physics of the spiral arms. To the many contradictory ways of understanding the Galactic structure, our group of research adds one more possibility. We see the arms as relatively longlived grooves in the gravitational potential of the disk, whose shape is primarily determined by the stellar orbits and not by shock waves in the interstellar medium. The spiral structure is selfconsistent in terms of arm shapes in the range of radius between the inner Lindblad resonance and the 4:1 resonance, so that this region is probably the one that guarantees the stability of the whole structure and imposes its pattern speed. Outside this region, many observed structures have shapes coinciding with predicted orbits at resonances. Since our model predicts the existence of resonant orbits with reverse curvature between corners pointing outward (as in our Fig. 8), it is not surprising to observe structures with similar characteristics in our Galaxy. Similarly, it is not too surprising to find armlike structures crossing each other. The expected response of the gas of the disk is to get trapped into the grooves and to flow along them.
Acknowledgments
The work was supported by the Conselho Nacional de Desenvolvimento Científico e Tecnológico. We thank Dr. P. Grosbøl for many helpful comments and to the anonymous referee for useful comments. We also thank Vinicius C. Busti for many useful comments.
References
 Allen, C., & Santillan, A. 1991, Rev. Mex. Astron. Astrofis., 22, 255 [NASA ADS] [Google Scholar]
 Amaral, L. H., & Lepine, J. 1996, Rev. Mex. Astron. Astrofis. Conf. Ser., 4, 121 [NASA ADS] [Google Scholar]
 Amaral, L. H., & Lepine, J. R. D. 1997, MNRAS, 286, 885 [NASA ADS] [CrossRef] [Google Scholar]
 Amôres, E. B., Lépine, J. R. D., & Mishurov, Y. N. 2009, MNRAS, 400, 1768 [NASA ADS] [CrossRef] [Google Scholar]
 Antoja, T., Figueras, F., RomeroGómez, M., et al. 2011, MNRAS, 418, 1423 [NASA ADS] [CrossRef] [Google Scholar]
 Benjamin, R. A., Churchwell, E., Babler, B. L., et al. 2005, ApJ, 630, 149 [NASA ADS] [CrossRef] [Google Scholar]
 Binney, J., & Tremaine, S. 2008, Galactic Dynamics, 2nd edn., eds. J. Binney, & S. Tremaine (Princeton, NJ USA: Princeton University Press) [Google Scholar]
 Block, D. L., & Wainscoat, R. J. 1991, Nature, 353, 48 [NASA ADS] [CrossRef] [Google Scholar]
 Block, D. L., Bertin, G., Stockton, A., et al. 1994, A&A, 288, 365 [NASA ADS] [Google Scholar]
 Burton, W. B., & Liszt, H. S. 1993, A&A, 274, 765 [NASA ADS] [Google Scholar]
 Chernin, A. D. 1999, MNRAS, 308, 321 [NASA ADS] [CrossRef] [Google Scholar]
 Contopoulos, G. 1975, ApJ, 201, 566 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Contopoulos, G., & Grosbøl, P. 1986, A&A, 155, 11 [NASA ADS] [Google Scholar]
 Contopoulos, G., & Grosbøl, P. 1988, A&A, 197, 83 [NASA ADS] [Google Scholar]
 Creze, M., & Mennessier, M. O. 1973, A&A, 27, 281 [NASA ADS] [Google Scholar]
 Dehnen, W. 2000, AJ, 119, 800 [NASA ADS] [CrossRef] [Google Scholar]
 Dias, W. S., & Lépine, J. R. D. 2005, ApJ, 629, 825 [NASA ADS] [CrossRef] [Google Scholar]
 Drimmel, R., & Spergel, D. N. 2001, ApJ, 556, 181 [NASA ADS] [CrossRef] [Google Scholar]
 Elmegreen, D. M., & Elmegreen, B. G. 1985, ApJ, 288, 438 [NASA ADS] [CrossRef] [Google Scholar]
 Elmegreen, D. M., & Elmegreen, B. G. 1995, ApJ, 445, 591 [NASA ADS] [CrossRef] [Google Scholar]
 Elmegreen, D. M., Elmegreen, B. G., Yau, A., et al. 2011, ApJ, 737, 32 [NASA ADS] [CrossRef] [Google Scholar]
 Gerber, R. A., & Lamb, S. A. 1994, ApJ, 431, 604 [NASA ADS] [CrossRef] [Google Scholar]
 Gerhard, O. 2011, Mem. Soc. Astron. It. Suppl., 18, 185 [Google Scholar]
 Gerhard, O. E., & Vietri, M. 1986, MNRAS, 223, 377 [NASA ADS] [Google Scholar]
 Goldreich, P. 1965, MNRAS, 130, 159 [NASA ADS] [Google Scholar]
 Grosbøl, P., & Patsis, P. A. 1998, A&A, 336, 840 [NASA ADS] [Google Scholar]
 Grosbøl, P., Patsis, P. A., & Pompei, E. 2004, A&A, 423, 849 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Ibata, R. A., & Gilmore, G. F. 1995, MNRAS, 275, 605 [NASA ADS] [CrossRef] [Google Scholar]
 Kalnajs, A. J. 1972, ApJ, 175, 63 [NASA ADS] [CrossRef] [Google Scholar]
 Kendall, S., Kennicutt, R. C., & Clarke, C. 2011, MNRAS, 414, 538 [NASA ADS] [CrossRef] [Google Scholar]
 Kent, S. M. 1992, ApJ, 387, 181 [NASA ADS] [CrossRef] [Google Scholar]
 Lépine, J. R. D., & Leroy, P. 2000, MNRAS, 313, 263 [NASA ADS] [CrossRef] [Google Scholar]
 Lépine, J. R. D., Dias, W. S., & Mishurov, Y. N. 2008, MNRAS, 386, 2081 [NASA ADS] [CrossRef] [Google Scholar]
 Lépine, J. R. D., RomanLopes, A., Abraham, Z., Junqueira, T. C., & Mishurov, Y. N. 2011a, MNRAS, 414, 1607 [NASA ADS] [CrossRef] [Google Scholar]
 Lépine, J. R. D., Cruz, P., Scarano, S., Jr., et al. 2011b, MNRAS, 417, 698 [NASA ADS] [CrossRef] [Google Scholar]
 Marochnik, L. S., Mishurov, Y. N., & Suchkov, A. A. 1972, Ap&SS, 19, 285 [NASA ADS] [CrossRef] [Google Scholar]
 MéndezAbreu, J., Simonneau, E., Aguerri, J. A. L., & Corsini, E. M. 2010, A&A, 521, A71 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mishurov, Y. N., & Zenina, I. A. 1999, A&A, 341, 81 [NASA ADS] [Google Scholar]
 Lin, C. C., & Shu, F. H. 1964, ApJ, 140, 64 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Lin, C. C., Yuan, C., & Shu, F. H. 1969, ApJ, 155, 721 [NASA ADS] [CrossRef] [Google Scholar]
 Martos, M., Yañez, M., Hernandez, X., Moreno, E., & Pichardo, B. 2004, J. Korean Astron. Soc., 37, 199 [NASA ADS] [CrossRef] [Google Scholar]
 Patsis, P. A., Contopoulos, G., & Grosbøl, P. 1991, A&A, 243, 373 [NASA ADS] [Google Scholar]
 Patsis, P. A., Hiotelis, N., Contopoulos, G., & Grosbøl, P. 1994, A&A, 286, 46 [NASA ADS] [Google Scholar]
 Patsis, P. A., Grosbøl, P., & Hiotelis, N., 1997, A&A, 323, 762 [NASA ADS] [Google Scholar]
 Pichardo, B., Martos, M., Moreno, E., & Espresate, J. 2003, ApJ, 582, 230 [NASA ADS] [CrossRef] [Google Scholar]
 Poincaré, H., 1892, Les Méthodes Nouvelles de la Mécanique Céleste (Paris: GrauthierViltars) [Google Scholar]
 Rix, H.W., & Rieke, M. J., 1993, ApJ, 418, 123 [NASA ADS] [CrossRef] [Google Scholar]
 Rix, H.W., & Zaritsky, D. 1994, Astronomy with Arrays, The Next Generation, 190, 151 [Google Scholar]
 Russeil, D. 2003, A&A, 397, 133 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 SanzSerna, J. M., & Calvo, M. P. 1994 (Chapman & Hall, London: St Edmundsbury Press), 207 [Google Scholar]
 Scarano, S., Jr, & Lépine, J. R. D. 2013, MNRAS, 428, 625 [NASA ADS] [CrossRef] [Google Scholar]
 Sellwood, J. A. 2011, MNRAS, 410, 1637 [NASA ADS] [Google Scholar]
 Shen, J., Rich, R. M., Kormendy, J., et al. 2010, ApJ, 720, L72 [NASA ADS] [CrossRef] [Google Scholar]
 Sofue, Y., Honma, M., & Omodaka, T. 2009, PASJ, 61, 227 [NASA ADS] [Google Scholar]
 Toomre, A. 1964, ApJ, 139, 1217 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Deduction of the Gaussian potential following a logarithmic spiral
A Gaussian in two dimensions with equal standard deviation σ = σ_{x} = σ_{y} is given by (A.1)In polar coordinates we have (A.2)and (A.3)where R_{0} = gives the position of the logarithmic spiral. If we fix the radii and just look at the variation in the azimuthal direction, Eqs. (A.2) and (A.3), become Adding the two equations and using the law of cosines we have (A.6)Taking Eq. (A.6) and putting into Eq. (A.1), this becomes (A.7)Now we can set the angle α as a logarithmic function, which defines the spiral arm: (A.8)but Eq. (A.7) describes only one arm. However, it is simple to generalize for m − arms. We simply multiply the term (θ − α) inside the cosine, in Eq. (A.7), by m: (A.9)This is the final equation to describe m − arms.
Appendix B: Thindisk approach for the new potential
The Poisson’s equation for a thin disk is (B.1)where we can write the potential as follows: (B.2)Therefore the Poisson’s equation has the form (B.3)where is the Laplacian in polar coordinates. Integrating both sides of this equation from z = −∞ to z = ∞, the second term on the righthand side of this equation disappears, then Eq. (B.3) becomes (B.4)For the potential Φ_{10} equal to (B.5)with χ = m(θ − α), and α given by Eq. (A.8).
Solving we have that (B.6)where \arraycolsep1.75ptand (B.9)The derivatives of ψ are \arraycolsep1.75ptand (B.13)For a fixed R the maximum density occurs when cosχ = 1, sinχ = 0. Assuming a small pitch angle i, the most important terms contains tan^{2}i in the denominator. Thus Eq. (B.6) is reduced to (B.14)Thus the maximum density computed from Eq. (B.4) is (B.15)from the classical spiral density wave theory (Lin & Shu 1964). The spiral arms were modeled with a cosine function where the wavenumber k appears, and it is equal to for a logarithmic description. We know that our expression is not a pure cosine law anymore. However, we can locally think of the Gaussian density as a wave for which the amplitude tends to zero far away, so that we can keep the classical definition of k and use it on the equation above. Taking m = 2 we have (B.16)If we chose σ = R, we recover the classical formula from Lin et al. (1969)(B.17)Now the density contrast not only depends on the perturbation amplitude ζ_{0}, but also has a dependence with σ, which describes the width of the arms. In our model, we can set σ as a constant or a function of R.
All Tables
All Figures
Fig. 1 Azimuthal density profile at different radii for m = 2, i = 14°, and σ = 4.7 kpc. Here we set Σ_{s0} = 1, since we only want to show how the density profile varies with the azimuthal angle.

Open with DEXTER
In the text
Fig. 2 Map of the perturbing potential in the plane of the galaxy. The colors represent the values of Φ_{1}(R,ϕ) in arbitrary units. The picture on the left is the potential with σ = 2.5 kpc and on the right σ = 4.7 kpc. For i = 14° we have on the left σ_{ ⊥ } = 0.6 kpc and on the right σ_{ ⊥ } = 1.1 kpc.

Open with DEXTER
In the text
Fig. 3 Radial force due to the spiral arm in the direction ϕ = 0. The circles in red represent the radial force due to our potential, while the crosses in green represent the radial force associated with the classical sine function perturbation. Here, positive values of the force mean that a star would be pushed outward and negatives values that it would be pulled inward with respect to the galactic center. In this figure, the number of arms is m = 2, the pitch angle i = 14°, ε_{s} = 0.4 kpc^{1}, and for our model the arm width σ = 4.7 kpc.

Open with DEXTER
In the text
Fig. 4 Density contrast Σ_{s0}/Σ_{d} as a function of perturbation amplitude for the Milk Way.

Open with DEXTER
In the text
Fig. 5 Rotation curve of the Galaxy. The red line is the rotation curve fitted using Clemens’ data (black dots), and the blue line is the pattern speed Ω_{p} × R corresponding to an angular velocity Ω_{p} = 23 km s^{1} kpc^{1}. The corotation radius is at 8.4 kpc. We adopted R_{0} = 7.5 kpc and V_{0} = 210 km s^{1}.

Open with DEXTER
In the text
Fig. 6 Axisymmetrical potential as a function of the galactocentric radius R.

Open with DEXTER
In the text
Fig. 7 Scheme of the Galactic plane. The yellow dot represents a star rotating with speed in a frame of reference (dashed line) corotating with the spiral arms at the angular velocity Ω_{p}.

Open with DEXTER
In the text
Fig. 8 Series of closed orbits in the plane of the Galaxy obtained using the rotation curve of Eq. (17). The spirals indicated in green represent the imposed perturbation; they coincide with the response density (red dots) up to 4:1 resonance. The red circle is the corotation radius (R_{cor} = 8.4 kpc). The perturbation amplitude is ζ_{0} = 600 km^{2} s^{2} kpc^{1}. The yellow dot shows the Sun position.

Open with DEXTER
In the text
Fig. 9 Plot of the observed arm structure of the Galaxy in the solar neighbourhood. The Sun is at the center of the figure, and the distances on the two axes are relative to the Sun. The Galactic center is downward and outside the figure. Different kinds of objects have been added to better trace the structure, all of them shown with a same symbol (gray dots): Cepheids, open clusters, CS sources (see text for details). Curve a, in brown, represents a stellar orbit at the 4:1 resonance, and curve b an orbit at the 6:1 resonance. Curve c is not identified in terms of resonances, since it is a linear fit to the observed points. The other lines (two in red, one in green) are logarithmic spirals fitted to the data.

Open with DEXTER
In the text
Fig. 10 Rotation curves and corresponding inner orbits for different strengths of the bulge. At the top are the rotation curves for different values of f_{b} (see text). From left to right, the parameter f_{b} is 3.2, 2.2, 1.2, and 0, respectively. Below are the orbits associated with each rotation curve. The blue line is the bulge contribution, the green line is the disk contribution, and the red line is the bulge + disk contribution.

Open with DEXTER
In the text
Fig. 11 Poincaré diagrams and their respective families (x_{1},x_{2}) of perturbed periodic orbits (see Contopoulos 1975, for details). In both cases we set the energy at R_{c} = 2.2 kpc, and the perturbation parameters are the same as Table 1. The only difference is the bulge fraction f_{b}; at the top we have f_{b} = 3.2 and below we have f_{b} = 0.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
