1. Introduction

Gamma-ray bursts (GRBs) show a bimodality in their duration distribution, separated in the Compton Gamma-Ray Observatory/Burst And Transient Source Experiment (CGRO/BATSE) data at T90 = 2 s, with the peak of the short-burst population at T90 ~ 0.5 s and the long-burst population at  ~30 s (Kouveliotou et al. 1993; Sakamoto et al. 2011). Historically, bursts are divided into long and short based on the BATSE scheme, even though the shape of the bimodal distribution is energy-dependent, in particular peaking for Swift/Burst Alert Telescope (BAT) at T90 ~ 0.5 s and  ~70 s, respectively (Sakamoto et al. 2011).

According to the current picture, long bursts originate from the collapse of massive stars into black holes (MacFadyen & Woosley 1999) or into rapidly spinning, strongly magnetized neutron stars (e.g., Usov 1992; Mazzali et al. 2006). Short bursts, on the other hand, are commonly attributed to the merger of compact stellar objects (e.g., Paczyński 1986; Nakar 2007). The physical association of long bursts with the collapse of massive stars has been well established (e.g., Zeh et al. 2004; Hjorth et al. 2003; Kawabata et al. 2003; Matheson et al. 2003; Stanek et al. 2003; Pian et al. 2006; Ferrero et al. 2006; Woosley & Bloom 2006; Fruchter et al. 2006). However, the observational situation with short bursts is less clear.

Until 2005 no afterglow of a short burst had ever been detected, while many important discoveries had already been made for the long-burst sample (redshifts, supernova light, collimated explosions, circumburst wind profiles). The first well-localized short burst (GRB 050509B; Gehrels et al. 2005) was seen close in projection to a massive early-type galaxy (Hjorth et al. 2005; Bloom et al. 2006), supporting the model that compact stellar mergers are the progenitors of short-duration gamma-ray bursts. However, since then observational progress has been rather modest compared to the long-burst population (for recent reviews, see Gehrels et al. 2009; Berger 2011).

There are two main reasons for this situation. Firstly, there is a substantially smaller detection rate of short bursts compared to long bursts. Secondly, short-burst afterglows are rarely brighter than R = 20, even minutes after a trigger (e.g., Kann et al. 2010, 2011). This general faintness makes their discovery and detailed follow-up very challenging. However, only the precise detection of the afterglow, with sub-arcsec accuracy, enables a secure determination of a putative GRB host galaxy and its redshift, while the X-ray plus optical light curves provide information about the processes after the explosion and the properties of the environment of the progenitor along with clues about the physics of the central engine. Rapid follow-up observations of these events are therefore very important to gain as much observational data as possible.

Since there is a substantial overlap between the long- and short-burst duration distribution, a simple division into long and short is only a first guess about the true origin of a burst. Several other phenomenological properties of the bursts and their afterglows have to be considered in order to reveal the nature of their progenitors (Zhang et al. 2007, 2009; Kann et al. 2011). Particularly interesting are the circumburst density profiles, the afterglow luminosities, and the outflow characteristics that might be shaped by or related to the physical properties of the GRB progenitors.

Table 1

The 20 short bursts of our sample.

Theoretical studies suggest that long GRBs are followed by more luminous afterglows than short bursts, mainly due to the expected difference in the circumburst density, around the GRB progenitors (Panaitescu et al. 2001). In addition, the circumburst density profile indicates the nature of the explosion (e.g., Schulze et al. 2011). The distribution functions of the jet-opening angles of long and short bursts should also be different from each other because an extended massive envelope collimates the escaping relativistic outflow (Zhang et al. 2004), while the lack of such a medium in merger events might allow for wider jet-opening angles (Aloy et al. 2005; Rezzolla et al. 2011). Any short-burst afterglow that adds information here is of great interest.

Here we report on the results of the first 3.5 years of follow-up observations of short-duration GRBs using the optical/near-infrared (NIR) seven-channel imager GROND (Greiner et al. 2007, 2008) mounted at the 2.2-m ESO/MPG telescope on La Silla (Chile). GROND has been in continuous operation since mid-2007, observing every burst with a declination  ≲+ 35°. It thus provides a complete sample of events observed with the same instrument at the same telescope. The capability of GROND to observe in seven bands simultaneously, from g′ to Ks, not only provides the opportunity to follow the color evolution of an afterglow but also allows for a stacking of all bands. This is particularly the case for a white-light image in griz′, which reaches a fainter detection threshold. In addition, GROND’s routine operation in rapid response mode allows us to start observations within minutes after a trigger, thereby catching afterglows even if they are fading rapidly.

In this work, we summarize the detections and upper limits for 20 short-burst afterglows in grizJHKs. First results have already been published in Nicuesa Guelbenzu et al. (2011,in the following Paper I) and Nicuesa Guelbenzu et al. (2012,in the following Paper II). Here we add detailed information on all individual bursts. In particular, we compare the afterglow luminosities with those of their long-burst relatives. We also include X-ray data in order to extend this discussion to the high-energy band. If possible, based on our optical data, we derive the spectral energy distribution (SED) of the afterglows and give an estimate of the corresponding jet half-opening angles.

In the following, we mainly are in line with the classical classification scheme into long and short bursts with the border line at T90 = 2 s (Kouveliotou et al. 1993). We stress, however, that this is a matter of discussion and a matter of detector properties (Sakamoto et al. 2011), and a more physically motivated classification scheme is often used (Zhang et al. 2007; Kann et al. 2010, 2011). This revised scheme was basically triggered by GRBs 060605 and 060614. Despite a low redshift, these two long bursts in the classical sense developed no detectable supernova component down to deep luminosity limits (Della Valle et al. 2006; Fynbo et al. 2006; Gal-Yam et al. 2006; Gehrels et al. 2006; Thöne et al. 2008).

Throughout the paper, we adopt a concordance ΛCDM cosmology (ΩM = 0.27, ΩΛ = 0.73, H0 = 71 km s-1 Mpc-1; Spergel et al. 2003) and describe the flux density as Fν(t) ∝ tα   νβ. In cases where no redshift is known for a burst, we adopt a redshift of z = 0.5, which is justified based on the redshift distribution of short bursts detected by Swift by the end of 2010 (Leibler & Berger 2010, their Table 1).

2. Target selection, observations, and data reduction

Between July 2007 and December 2010, a total of 394 GRBs were localized at the arcmin or (mostly) arcsec scale1. Among these 220 events were followed up with GROND. For the present study, we have selected from this data base all those bursts with a duration of T90 ≤ 2 s (within 1σ) and an error circle smaller than 3 arcmin in radius (Table 1), giving us 20 targets.

All optical/NIR data were analysed through standard point spread function (PSF) photometry using DAOPHOT and ALLSTAR tasks of IRAF (Tody 1993) in a similar way to the procedure described in Krühler et al. (2008) and Küpcü Yoldaş et al. (2008). A PSF fitting was used to measure the magnitudes of an optical transient. For completeness, publicly available archives were also checked (Very Large Telescope (VLT) with the instrument Focal Reducer and low dispersion Spectrograph (FORS) and Gemini with the Gemini Multi-Object Spectrographs (GMOS)).

The optical data were calibrated against the Sloan Digital Sky Survey (SDSS DR7; Abazajian et al. 2009), if available. Otherwise a standard star field was observed under photometric conditions. For the NIR bands, photometric calibration was performed against the Two Micron All Sky Survey (2MASS) catalogue (Skrutskie et al. 2006). This procedure results in a typical absolute accuracy of 0.04 mag in griz′, 0.06 mag in JH, and 0.08 mag in Ks. All reported magnitudes are in the AB photometric system. Observed magnitudes were corrected for Galactic reddening based on Schlegel et al. (1998) and assuming a Milky Way extinction curve with a ratio of total-to-selective extinction of RV = 3.1. For GROND, the Vega-to-AB conversion is JAB = JVega + 0.93 mag, HAB = HVega + 1.39 mag, KAB = Ks,Vega + 1.80 mag, except for observations after an intervention on the instrument on March 2008, for which KAB = Ks,Vega + 1.86 mag. Extinction corrections for the GROND filters we used here are A(g′) = 1.253   AV,A(r′) = 0.799   AV,A(i′) = 0.615   AV,A(z′) = 0.454   AV,A(J) = 0.292   AV,A(H) = 0.184   AV,A(Ks) = 0.136   AV.

3. Results

In the following, we combined GROND’s griz′ into a white band in several cases. This turned out to be particularly useful when searching for a faint afterglow, studying the light curve shape, and measuring the offset of a detected afterglow from its suspected host galaxy. Image subtraction between the first and the last epoch was performed using the hotpants package2. Errors in the astrometric accuracy of GROND are less than 03 in right ascension and declination.

3.1. GRBs with an afterglow detected by GROND

In six of the 20 events followed up by GROND, an optical afterglow was detected by GROND. Two of these events, GRB 090426 and GRB 090510, were discussed in detail in Papers I and II. Here we report on the four other cases.

3.1.1. GRB 081226A: discovery of the optical afterglow

Observations: GROND started observations 10 min after the GRB trigger and was on target for 2.5 h. Second-epoch observations were performed the following night, and a final epoch was obtained one month after the burst. Inside the 90% c.l. X-ray Telescope (XRT) error circle (; Evans 2011a,b), the white-band image shows three objects (A–C; Fig. 1).

thumbnail Fig. 1

White-band image of the field of GRB 081226A. Inside the 90% c.l. XRT error circle () lie three objects (A,B,C). The position of the afterglow is indicated (C). In order to go deep, all GROND images of the first and the second epoch have been combined.

Afterglow light curve: after image subtraction is performed on the white-band images, the afterglow appears in the southern part of its very faint host galaxy (object C in Fig. 1). It is detected in all optical bands (Table A.1) and is best-sampled in the r′ band. Fitting the light curve with a single power-law plus host galaxy component (Fig. 2) gives α = 1.3 ± 0.2 (i.e., the afterglow was in the pre-jet break evolutionary phase). The decay slope is in agreement with the two X-ray detections of the afterglow centered at 0.6 ks and 11.5 ks (Evans et al. 2010). We re-reduced archival Gemini r′-band images (Berger et al. 2008a) and found that they fit well into this light curve, confirming the GROND discovery.

Due to the faintness of the afterglow, a well-defined SED, corrected for host-galaxy light, cannot be constructed.

thumbnail Fig. 2

GROND r′-band light curve of the afterglow of GRB 081226A fitted with a single power-law plus host galaxy component. Overplotted in green are the Gemini-S/GMOS r′-band data (Table A.1). No corrections for the slightly different filters have been performed.

Energy budget: no redshift is known for GRB 081226A. Assuming a redshift of z = 0.5 and using the data and the numerical approach from Butler et al. (2007)3, we obtain an isotropic equivalent energy for this burst of  erg. If there is a jet break in the optical light curve, then it must have occurred after about 10 ks. Assuming that the density profile of the circumburst environment is decribed by an interstellar medium (ISM), for the jet half-opening angle (e.g., Frail et al. 2001; Lu et al. 2012) we have (1)Adopting a radiative efficiency of 0.2 and scaling the results to a low gas density of 0.01 cm-3 as might be implied for a neutron star merger, we obtain  deg and a beaming-corrected energy of  erg. There are no X-ray data for t > 10 ks that could yield further evidence for a possible break in the afterglow light curve (Evans et al. 2010).

Host galaxy: the underlying host galaxy (C) is very faint and only visible in the g′,r′ second-epoch images (g′ = 25.88 ± 0.24,r′ = 25.79 ± 0.34). The offset of the afterglow from its center is  ≲05. For an assumed redshift of z = 0.5, this corresponds to  ≲3 kpc. No statement can be made about the morphological type of this galaxy.

3.1.2. GRB 090305: Discovery of a jet break

Afterglow light curve: GROND started observing the field 30 min after the Swift/BAT trigger and was on target for 1.5 h. The fading optical afterglow (Cenko et al. 2009; Berger & Kelson 2009) is detected in all optical bands but it is not seen in the NIR (Table 4).

Gemini-S/GMOS observed from 1.5 ks to 7.5 ks after the burst in g′,r′,i′ and discovered the afterglow (Cenko et al. 2009). No detailed light curve data have been published so far, with i′-band data affected by strong fringing. Figure 4 shows the result of the simultaneous fit of all data (GROND and Gemini) using a broken power-law with the Gemini data overplotted. The fit finds a break in the light curve at tb = 6.6 ± 0.4 ks, a pre-break decay slope of α1 = 0.56 ± 0.04, and a post-break decay slope of α2 = 2.29 ± 0.60. The pre-break decay slope is rather shallow but not unusual (e.g., Zeh et al. 2006). There is no X-ray light curve available for this afterglow (Beardmore et al. 2009b).

thumbnail Fig. 3

Field of GRB 090305: the optical afterglow (A) and the object closest to it (B). Shown here is the griz′-combined (white-band) image taken between 4 ks to 7 ks after the burst. The circle is just drawn to guide the eye; there is no independent Swift/XRT position (Beardmore et al. 2009c).

thumbnail Fig. 4

Gemini and GROND light curve of the optical afterglow of GRB 090305. All data are fit simultaneously. Open circles are GROND, while filled circles are Gemini. Color coding: green g′ band (shifted by  + 0.5 mag), red r′ band, brown i′ band (shifted by −0.5 mag), black z′ band (shifted by −1 mag).

SED: by fitting the Gemini g′- and r′-band data, together with the GROND griz′-band data, we find a spectral slope of βopt = 0.52 ± 0.15 (χ2/d.o.f. = 0.66). No evidence for color evolution was found. Applying the α − β relations, there is no solution with p > 2 for the pre-jet break phase; the light curve decay is too shallow at that time (Table 2). On the other hand, the observed spectral slope suggests that between about 2 ks and 8 ks it was νopt < νc, because then p = 2β + 1 = 2.04 ± 0.32, a standard value. Possibly, the deduced shallow α1 indicates that at early times the evolution of the light curve was affected by re-brightening episodes or energy injections. No decision can be made between a wind and an ISM model.

thumbnail Fig. 5

GROND SED of the afterglow of GRB 090305 at 6 ks after the burst, after correction for Galactic extinction. Index G stands for GROND.

Table 2

GRB 090305: predicted β based on the α − β relations using α1 = 0.56 ± 0.04 and α2 = 2.29 ± 0.60.

Energy budget: assuming a redshift of z = 0.5 and following the same procedure as in Sect. 3.1.1, we find  erg. The observed break time, if interpreted as a jet break in an ISM medium (Eq. (1)), leads to a jet half-opening angle of  deg and a beaming-corrected energy release of  erg.

Host galaxy: at the position of the optical transient, there is no evidence for an underlying host galaxy in any band; only upper limits can be given (grizJHKs > 25.7, 26.0, 24.5, 24.2, 22.4, 22.0, 20.6). The object closest to the optical afterglow is a faint source at a distance of 14 (object B; see Fig. 3). This object is only detected in the GROND i′ band with a magnitude of 24.1 ± 0.2. Object B is also detected in Gemini r′ band data taken ten days after the burst at a magnitude of 26.0 ± 0.1. It was also imaged with VLT/FORS in Rc (program ID 082.D-0451; PI: A. Levan).

Following the procedure described in Bloom et al. (2002) and Perley et al. (2009), the probability p to find a galaxy as bright as object B within 14 distance from the afterglow is about 7%. Formally, this small probability makes B a host galaxy candidate. If its observed color (r′ − i′ = 2.3 ± 0.2 mag) is due to the redshifted stellar 4000 Å bump, its redshift is around z = 0.54. For z = 0.5, the projected distance of the afterglow from object B would be 8.5 kpc. There are, however, at least two more galaxies within r = 7 arcsec around the position of the afterglow for which the p value is of similar or smaller amount (see also Berger 2010a).

3.1.3. GRB 090927: a wind medium?

Observations: GROND started observations about 17 h after the burst and continued for 1.5 h. A second-epoch observation was performed the following night for about 1 h. Both observing runs were affected by bad seeing (23). The afterglow was clearly fading in all GROND optical bands, while it was not detected in the NIR.

Afterglow light curve: the GROND r′-band light curve can be fitted with a single power-law that has a slope of α = 1.32 ± 0.14  (χ2/d.o.f. = 0.39; Fig. 6), which is also in agreement with the results from the Faulkes Telescope South (Cano et al. 2009) and the VLT (Levan et al. 2009a). However, the first two R-band data points from the Zadko telescope (Klotz et al. 2009; see appendix) lie about 1 mag below the extrapolated fit (but also have large errors). Those data suggest that the optical flux was nearly constant between two and four hours after the burst. At the same time, the X-ray light curve shows strong fluctuations but seems to be in a plateau phase.

Assuming a single power-law decay for the X-ray light curve, we obtain αX = 1.30 ± 0.07 for t > 20 ks. On the other hand, the outlier at 70 ks could also be interpreted as evidence for a break in the X-ray light curve. However, the light curve decay after the break is then too shallow for a post-jet break decay slope. We thus conclude that also the X-ray afterglow is best described by pre-jet break evolution up to the end of the XRT observations. A decay slope of 1.3 is in agreement with the ensemble statistics of pre-jet break decay slopes for long-burst afterglows (Zeh et al. 2006).

thumbnail Fig. 6

The r′,i′-band light curve of the optical afterglow of GRB 090927 (the i′-band is shifted by −0.6 mag; Table A.4). Overplotted are also R-band data reported in GCN Circulars (Klotz et al. 2009; Cano et al. 2009; Levan et al. 2009a; in violet) as well as the X-ray data (Evans et al. 2010).

SED: the SED of the afterglow was constructed by combining all GROND data taken from 64 ks to 66 ks after the trigger, when the seeing was best (about 2′′). It is best fit by a power-law with no extinction in the host galaxy (; Fig. 7). The spectral slope is βopt = 0.41 ± 0.16. The α − β-relations then imply that at the time of the GROND observations it was νopt < νc (Table 3). The spectral slope βX in the X-ray band during this time period was 1.2 ± 0.2 (Evans et al. 2010), which in combination with the spectral slope in the optical points to νopt < νc < νX and prefers a wind over an ISM model. For the pre-jet break phase this order in frequencies implies αX − αopt =  ± 0.25 (−  for a wind, + for an ISM), while we measure a difference of −0.02 ± 0.17, not favoring any of both models.

Figure 8 shows the optical-to-X-ray SED of the afterglow at t = 65 ks. Using a Galactic NH = 2.9    ×    1020 cm-2, for the given redshift (z = 1.37; Levan et al. 2009a) the fit finds no evidence for host extinction (SMC dust;  mag), a spectral slope , and a break energy of 42 eV (χ2/d.o.f. = 196/229 = 0.85). A fit with a single power-law is worse, confirming that νopt < νc < νX.

thumbnail Fig. 7

SED of the afterglow of GRB 090927 at t = 65 ks (from g′ to Ks). It is best fitted by a power-law with no evidence for extinction in the host galaxy. Note that the NIR bands are only upper limits.

Energy budget: assuming a wind model, it is (Bloom et al. 2003) (2)where A   is the wind density parameter (Chevalier & Li 2000) and, similar to Eq. (1), we have introduced a radiative efficiency ηγ. For a jet break time of tb > 6    ×    105 s (as implied by the X-ray data), then for z = 1.37 and ηγ = 0.2, with  erg, we find Θjet ≳ 12 ± 2 deg and erg. An ISM model (Eq. (1)) gives  deg and  erg.

Table 3

GRB 090927: predicted β based on the α − β relations using α = 1.32 ± 0.14 (for details, see Table 2).

thumbnail Fig. 8

Optical-to-X-ray SED of the afterglow of GRB 090927 at t = 65 ks.

Host galaxy: observations performed two years after the trigger show no evidence of a host galaxy at the position of the optical transient down to deep upper limits (grizJHKs > 25.2, 25.2, 24.5, 24.2, 22.3, 21.6, 20.4). The late-epoch data reveal that there are two objects, A and B, within a radius of 10 arcsec centered at the position of the optical afterglow (Fig. 9). Both objects are clearly extended. If one of them is the host, the projected offset of the burst was 65 and 75, respectively. For a redshift of z = 1.37 (Levan et al. 2009a), this corresponds to a projected distance of 55 kpc and 63 kpc, respectively. If the progenitor of GRB 090927 was a collapsar, this large distance rules out that A or B is the putative host.

thumbnail Fig. 9

Finding chart of the field of GRB 090927 (GROND griz′-band combined). Left: first-epoch detection of the afterglow with GROND. Right: deep, late-epoch observation of the field in June 2011. The circle (25 in radius), drawn to guide the eye, is centered at the position of the optical afterglow. A and B label the two galaxies nearest to the afterglow.

3.1.4. GRB 100117A: determination of the afterglow decay slope

Observations: GROND started observing the field of GRB 100117A 3.5 h after the GRB trigger and was on target for one hour (Fig. 10). The host galaxy flux was measured half a year later.

thumbnail Fig. 10

Combined GROND griz′-band (white) image of the field of GRB 100117A taken half a year after the burst. The circle is just drawn to guide the eye. It is centered at the position of the optical transient discovered by Fong et al. (2011) and circumscribes the GRB host galaxy.

Afterglow: the optical afterglow on top of its host galaxy was discovered by Fong et al. (2011). During the first night, we measure for the host plus afterglow a g′,r′-band magnitude of 24.37  ±  0.25, 23.72 ± 0.18. However, in the late-epoch data g′,r′ = 25.44 ± 0.37, 24.60 ± 0.35, resulting in a decay between both epochs of 1.07 ± 0.45 mag and 0.88 ± 0.39 mag, respectively.

The second-epoch data can be used to remove the host galaxy flux from the first-epoch data. Based on this result, we obtain an afterglow magnitude of r′ ~ 24.3 during our first-epoch observations at a mean time of t = 4.3 h. We can estimate the decay slope of the afterglow light curve by comparing this result with the r-band detection of the afterglow by Fong et al. (2011) 8.3 h after the burst. This gives α ~ 1.3, assuming no color transformation between both filters. This result is confirmed by combining the GROND gri′ images into a white band. Figure 11 shows the corresponding light curve of the afterglow during the first night, providing a slope of α = 1.2. This indicates that during this time period the afterglow was still in its pre-jet break phase.

thumbnail Fig. 11

Combined GROND gri′ white-band light curve of the decaying afterglow of GRB 100117A, centered on galaxy (Fig. 10). The host galaxy magnitude is shown as a straight line, including the 1σ error (measured by GROND eight months after the burst). Note that the y-axis shows arbitrarily magnitudes.

Energy budget: Swift/XRT data do not cover the time period when GROND and Fong et al. (2011) were observing. The last X-ray detection is at  s after the trigger (Evans et al. 2010). Particularly because the very last XRT data point at around 0.5 d is only an upper limit, optical and XRT data cannot be compared. If the afterglow was in the pre-jet break decay phase until at least 8.3 h after the burst, in combination with the observed isotropic equivalent energy of  erg (Kann et al. 2011) and a redshift of z = 0.92 (Fong et al. 2011), the lower limit on the jet half-opening angle is (Eq. (1)) Θjet = 2.4    ×    (n/0.01)1/8 deg and Ecor ≳ 4.6 × 1048 × (n/0.01)2/8 erg.

Host galaxy: our data do not allow us to measure the offset of the afterglow from its host galaxy center; Fong et al. (2011), using their Gemini-N/GMOS observations, obtained 60  ±  40 mas, corresponding to 0.5 ± 0.3 kpc.

3.2. GRBs with no afterglow detected by GROND

The results for the 14 out of 20 GRBs where GROND could not detect the afterglow are summarized in Table 4. In most cases, we were on target within some hours after the burst. In all cases, deep upper limits can be provided, in particular in the NIR, where we reach down to J = 22.7, H = 22.0, and Ks = 21.2. The individual observations by GROND are described in detail in the appendix. However, of particular interest are two events (GRB 080919, 100702A), where observations started less than 10 min after the trigger.

Table 4

Summary of the 3σ upper limits for the short-burst afterglows not detected with GROND based on first-epoch data (AB magnitudes).

3.2.1. GRB 080919

GROND started observing the field 8 min after the burst. Due to a delay in secure XRT coordinates (Preger et al. 2008a), only the NIR images cover the afterglow position during the first 30 min. Deep second-epoch observations were performed with GROND three years after the burst. Image subtraction was carried out between second- and first-epoch data in all bands, but no afterglow was found. Probably the main reason for this non-detection is the presence of a bright star inside the error circle, which makes it difficult to detect any faint transient despite the small XRT error circle (90% c.l. radius ; Evans 2011b). Therefore, the upper limits we provide in Table 4 refer to isolated objects in the field, while the more reliable upper limits for the afterglow can be substantially less deep than reported there.

thumbnail Fig. 12

Field of GRB 080919. The XRT error circle (radius ) lies close to a relatively bright foreground star.

3.2.2. GRB 100702A

GROND started to observe the field 2.5 min after the burst. Inside the 90% c.l. XRT error circle (r = 24; Siegel et al. 2010a), the GROND data reveal two bright objects (A, B) and two others (C, D) close by (Fig. 13; see also Malesani et al. 2010). Objects A and B have a point-like PSF and might be stars, while C and D might be galaxies.

thumbnail Fig. 13

Finding chart of the field of GRB 100702A in the GROND J band. Shown also is the 90% c.l. XRT error circle (; Siegel et al. 2010a).

Image subtraction and PSF photometry in each band was performed for all objects, but no evidence of variability was found in either the optical or the NIR bands; only upper limits can be provided for any afterglow (Table 4). Similar to GRB 080919, the upper limits refer to isolated objects in the field.

4. Discussion

Including our discovery of the afterglow and host galaxy of GRB 081226A, nine out of 20 short bursts in our sample have a discovered optical transient, while six have only a Swift/XRT and four have only a Swift/BAT or INTEGRAL/IBIS localization with no optical afterglow. Six of the nine bursts with detected optical transient have a redshift reported in the literature. Additional redshift information comes from the identification of the host galaxies of GRBs 100206A (Cenko et al. 2010a; Perley et al. 2011), 100628A (Cenko et al. 2010b), and 101219A (Chornock & Berger 2011). These redshifts range from z = 0.10 (GRB 100628A) to z = 2.61 (GRB 090426). Four of the nine bursts have a redshift smaller than 0.5, which is a high percentage compared to the long-burst population; for more redshifts of short-bursts, see the compilations by Berger (2009), Kann et al. (2011).

Table 5

Summary of the data for the six bursts with optical afterglow detection by GROND.

The best-sampled light curves are those of GRB 090426 (Paper I) and GRB 090510 (Paper II), followed by (ordered by sampling quality) GRBs 090305, 081226A, 090927, and 100117A. Only the afterglow of GRB 090426 has NIR detections. In three cases, we find a clear break in the light curve, partly in combination with data obtained at other facilities. Two of these events (GRBs 090426, 090510) were imaged by GROND in the post-break decay phase only, and for GRB 090305 the data also included the pre-break phase. In principle, the three breaks might be interpreted as jet breaks, but for GRB 090510 the Swift/Ultraviolet Optical Telescope (UVOT) data suggest a different explanation, namely the passage of the injection frequency across the GROND bands (for details, see Kumar & Barniol Duran 2010; de Pasquale et al. 2010d and Paper II). For the other three cases, the light curves can be fitted with a single power-law and, based on the deduced decay slope, observations were performed during the pre-jet break evolutionary phase. The light curve decay slopes as well as the spectral slopes are not different from what is known for the long-burst sample (Table 5).

4.1. Optical luminosities

In recent years, evidence has been mounting that the classical T90 division between short and long GRBs is not transferable to a more physically inspired division between progenitor models. It seems that merging compact objects may result in high-energy emission on timescales far exceeding T90 = 2 s, whereas conversely collapsar-triggered GRBs can be luminous short spikes with T90,rest < 2 s. This led Zhang et al. (2007) to propose, analogous to the designations of supernovae, that GRBs come in two types: Type I GRBs stem from the coalescence of massive compact objects, whereas Type II GRBs are associated with the core-collapse of massive stars. Zhang et al. (2009) studied the observational signatures of the two classes and devised a scheme to classify GRBs. Kann et al. (2011) studied a large sample of Type I candidate GRBs, adding the optical afterglow luminosity at late times as an additional criterion to discern the two classes, with Type I GRB afterglows being much less luminous than those of Type II GRBs.

thumbnail Fig. 14

Light curves of long and short GRB afterglows. These light curves have been corrected individually for Galactic foreground extinction following Schlegel et al. (1998), and, if possible, for host galaxy contribution. The thin gray lines are the long GRB sample of Kann et al. (2010). The red squares connected by splines represent the afterglow detections reported by Kann et al. (2011). The short GRB afterglows detected by GROND and presented in Papers I and II as well as this work are given as labeled thick black lines (they may include additional data beyond the GROND detections). Upper limits presented in this work (Table 4) are given as blue triangles. GRB 100702A is highlighted also because of its very early upper limits. The last data point for GRB 100117A is from Fong et al. (2011), the other data points as well as the data for GRBs 090305 and 081226A are presented in this paper. Early data for GRB 090927 are taken from Klotz et al. (2009), Levan et al. (2009a), Cano et al. (2009), and Kuin & Grupe (2009).

So far, in this work, we have discussed the sample based on the classic T90 division. What can the optical luminosity of the afterglows (or its upper limits) tell us about the likely progenitor systems? Figure 14 is a continuation of the plots shown in Kann et al. (2006, 2010, 2011). Against the background of Type II GRB afterglow light curves (thin gray lines), we show Type I GRB afterglow detections as presented in Kann et al. (2011; red squares connected by splines, upper limits have been omitted for clarity) as well as the detected afterglows (thick black splines) and upper limits (downward-pointing blue triangles) derived by GROND both in this work and in Papers I and II.

In this plot, it is visible that the short GRB afterglows are less bright than the mean brightness of the long GRB afterglows, with half of them (GRBs 090305, 10017A and 081226A) being as faint or fainter than the faintest so-far detected long GRB afterglows. A true comparison needs to account for the redshift and intrinsic extinction, though.

Figure 15 shows the light curves of the six short GRBs detected with GROND in the z = 1 reference frame, corrected if possible for both distance and intrinsic reddening in the GRB host galaxy (Kann et al. 2006; Nardini et al. 2006). A redshift of z = 0.5 and zero host extinction was assumed for all cases where these values are not known. Of the six afterglows, that of GRB 090426 is now seen to be the most luminous, followed by the ones of GRBs 090927 and 090510. Several arguments have already been put forward that the origin of 090426 was a collapsar event (see Paper I and references therein). Between about 0.01 and 0.1 d after the burst (measured in the GRB host frame), its magnitude (for the fixed distance a measure of the luminosity) was about 2 mag brighter than the magnitude of the optical afterglow of the other two events. The optical afterglow of GRB 090510, if due to a merger event, must be characterized as very luminous between  ~0.005 and 0.1 d after the burst. Because of its emission in the 10–100 GeV band and its outstandingly small jet half-opening angle of Θjet ≲ 1° (de Pasquale et al. 2010d; He et al. 2011; Kumar & Barniol Duran 2010, Paper II; if correctly interpreted in this way), it was special in several other respects, too. The optical afterglow of GRB 090927 reached the luminosity of the afterglow of GRB 090426 at about 1 d after the burst, but its further evolution is unfortunately unknown. This moderately high optical luminosity along with significant lag and other spectral characteristics (Stamatikos et al. 2009) and a redshift beyond what is seen for Type I GRBs (Levan et al. 2009a) strongly indicate that GRB 090927 is also likely to be a Type II GRB. All other afterglows with GROND detections or GROND upper limits fall well within the Type I GRB sample.

thumbnail Fig. 15

Light curves of the six GROND-detected short GRB afterglows as well as the upper limits in the redshift z = 1 frame. The labeling is identical to Fig. 14. GRBs 090426 and 090927 are likely Type II. The luminosity is in units of erg/s. See text for further details.

Between the host time frame of about 0.01 and 0.1 d, the three optical afterglows mentioned above (which have a measured redshift) were about 7 ± 1 mag brighter than the afterglows of GRBs 081226A, 090305, and 100117A (of which only the latter has a secure redshift)6. For GRB 090510, the situation changes after about 0.1 d, when the early break and following steep decay (Paper II) cause it to become much fainter than Type II GRB afterglows (see also Kann et al. 2011). From the perspective of optical luminosities, we therefore find additional evidence for a collapsar origin of GRB 090927, despite its short duration, whereas there is no evidence indicating that GRBs 090305 and 081226A are not members of the classical short/Type I GRB population. We note, though, that Panaitescu (2011) also discussed a collapsar origin for GRB 090510.

4.2. Jet half-opening angles

Observations of jet breaks in short-burst afterglow light curves are rather sparse, in the optical as well as in the X-ray band. In the optical band, the best-sampled cases are GRBs 090426 and 090510. However, the former burst is suspected to be owing to a collapsar explosion rather than to a merger event (e.g., Thöne et al. 2011), while the latter stands apart even from the long-burst sample because of its very small jet half-opening angle (He et al. 2011). The third member of this group is GRB 050709 with an estimated Θjet ~ 14 deg (Fox et al. 2005), which is based on a very sparsely sampled light curve, however.

In the X-ray band, the observational situation is not much better. The best case might again be GRB 090510 (de Pasquale et al. 2010d), followed by GRBs 050724, 051221A, 061201, and 111020A. Unfortunately, the first burst (GRB 050724) allows only for an estimate of a lower limit on Θjet (≳25 deg; Grupe et al. 2006; Malesani et al. 2007), while GRB 051221A relies on a well-sampled light curve (leading to Θjet ~ 4–8 deg; Burrows et al. 2006; Soderberg et al. 2006). The X-ray light curve of GRB 061201 is well-sampled, too (Stratta et al. 2007); again the observed break time is quite early (~40 min; Θjet = 1–2 deg). Recently, Fong et al. (2012) reported on the X-ray light curve of the short burst 111020A, which showed a break at 2 d, leading to an estimated Θjet = 3–8 deg for an assumed z = 0.5–1.5 and n ~ 0.01–0.1 cm-3.

Figure 16 shows the observed distribution of jet half-opening angles of long-bursts based on the compilation of Lu et al. (2012) compared to the short-burst sample (a similar plot has been recently shown by Fong et al. (2012). The latter contains the results summarized in Table 5, supplemented by GRBs 061006 (Θjet ~ 5 deg), 070714B (Θjet ≳ 4 deg), and 071227 (Θjet ≳ 4 deg) taken from the compilation of Fan & Wei (2011), but using ηγ = 0.2 instead of 1.0 (i.e., multiplying their numbers by 0.8; Eq. (1)). At first view, this figure shows tentative evidence that short bursts have wider jet-opening angles than long bursts. Some caution is necessary, however. First of all, when calculating the jet half-opening angles, Lu et al. (2012) assumed n = 0.1 cm-3 and ηγ = 0.2 throughout. Even though Θjet is only modestly sensitive to changes in both parameters (see Eq. (1)), gas densities derived for bursts based on multi-wavelength data show a spread from burst to burst by several orders of magnitude (e.g., Panaitescu & Kumar 2001). Second, error bars in Θjet are not taken into account in the histogram. Similarly, our standard assumption of n = 0.01 cm-3 for short bursts is also a simplification. For individual bursts it can be wrong by a factor of up to 100 in both directions. Finally, our plot contains only long bursts with measured jet break times. A more detailed study should also contain those long bursts for which only a lower limit on Θjet can be given (e.g., Grupe et al. 2007).

thumbnail Fig. 16

Observed distribution of jet half-opening angles of 74 long bursts (based on the compilation in Lu et al. 2012) compared to the short-burst sample. Since the latter has much less data, we do not plot a histogram but only points. An arrow indicates a lower limit on Θjet. The Type I events GRB 051221A, 060614, and 070714B listed in Lu et al. (2012) have not been used for the plot of the long-burst data.

4.3. X-ray afterglows

From the Swift Burst Analyser (Evans et al. 2010), we selected all bursts with detected X-ray afterglow and measured redshift that were detected between January 2005 and August 20117. We then shifted all light curves to their rest frames following Greiner et al. (2009). If no redshift information was available for a short-burst in our sample (Table 1), we assumed a redshift of z = 0.5.

Figure 17 displays the resulting luminosity evolution of those 14 bursts in our sample for which an X-ray afterglow light curve can be constructed, i.e., the X-ray afterglow is detected during at least two epochs. This excludes GRBs 071112B, 081226B, 090305, 091117A, and 101129A from the plot, which have no afterglow detection at all as well as GRB 100206A, which is only detected once. The figure also shows the luminosity evolution of 191 long GRBs with measured redshift. In addition, we overplot the short-burst sample compiled by Kann et al. (2011), consisting of an additional group of 19 events that are not included in our short-burst sample.

Figure 17 demonstrates that the X-ray afterglows of short bursts represent the low end of the luminosity distribution of X-ray afterglows. They are on average a factor of  ~100 less luminous than those of long bursts, similar to what is seen for optical afterglows (Fig. 15; see also Gehrels et al. 2008; Nysewander et al. 2009; Kann et al. 2011). However, with the single exception of GRB 050509B, short bursts do not represent the least luminous X-ray afterglows known. There is a continuous overlap between both populations; for certain time intervals, several long-burst afterglows are even less luminous than the population of short-burst afterglows.

There is a remarkable concentration of short-burst afterglows in a relatively narrow luminosity band around LX,   (0.3−10)   keV]  ≃ 1048   erg/s at t ~ 100   s in the rest frame. Even after removing bursts with assumed redshifts, the concentration is still present, indicating that this is a genuine feature and not an artifact caused by bursts with assumed redshifts. After that time, the luminosities of most short-burst afterglows drop notably and their luminosity distribution broadens by an additional factor of  ~10 to a final range of  ~100, which holds up to at least t = 1 d. At even later times, most short bursts are not detected anymore. Outstanding here is the X-ray afterglow of GRB 060614, which was detected until t = 2    ×    106 s (rest frame), while in our sample only three events (GRBs 090426, 090927, and 100628A) have been detected beyond t = 105 s. We caution that the former two are possibly Type II GRBs, i.e., originating from the gravitational collapse of a massive star.

In our sample, the X-ray afterglows of the short-bursts GRBs 071227 (z = 0.383; D’Avanzo et al. 2007) and 080905A (z = 0.122; Rowlinson et al. 2010) have the lowest luminosities, while GRB 090927 (z = 1.37; Levan et al. 2009a) and 090426 (z = 2.609; Levesque et al. 2009) are the most luminous short-bursts in our sample. Again we stress that the latter two are likely Type II GRBs. Adding the data set discussed in Kann et al. (2011), the X-ray afterglow of GRB 050509B represents the low end of the luminosity distribution between  ~0.3 ks and  ~30 ks, followed by GRBs 061201, 060505, and 0606148 at later times. On the other hand, the most luminous short-burst afterglows are those of GRBs 080503 and 051210, which reach log (LX,   (0.3−10)   keV]  [erg/s] )) ≃ 49.25 during the peak of their emission at  ~100 s. Only the X-ray afterglow of GRB 060121 is more luminous at later times, assuming z = 4.6 (de Ugarte Postigo et al. 2006); but this GRB is possibly also Type II GRB (Kann et al. 2011).

thumbnail Fig. 17

Luminosity evolution of the X-ray afterglows of the short bursts in our sample. Highlighted are the bursts with optical afterglows (Figs. 14, 15). Black lines represent the afterglows of the likely Type II events GRB 090426 and GRB 00927, green the afterglows of the Type I events GRBs 081226A, 090510, and 100117A. No X-ray afterglow light curve was reported for GRB 090305. Overplotted is also the short-burst sample compiled by Kann et al. (2011) (red color) as well as the X-ray afterglows of the long-burst sample with known redshift (gray). All short-burst afterglows are less luminous than the mean of long-burst afterglow luminosities (orange line); however, there is a continuous overlap between short and long GRB afterglows.

5. Summary

We have reported on the results of 3.5 yrs follow-up observations of short-duration GRBs (defined by T90 < 2 s) using the multi-channel imager GROND mounted at the 2.2-m telescope on La Silla. GROND is especially designed to perform rapid follow-up observations of afterglows, which is particularly useful for short-duration GRBs because of their on average very faint optical afterglows (Nysewander et al. 2009; Kann et al. 2010, 2011). To our knowledge, what we have presented here is one of the most comprehensive data sets on short-burst follow-up observations published so far.

In six of the 20 events GROND followed up, it could image the fading optical afterglow. Five of these cases were already known in the literature (GRBs 090305, 090426, 090510, 090927, 100117A), and the GROND follow-up observations of GRBs 090426 and 090510 were already represented in Papers I and II. The new discovery reported here is the optical afterglow of GRB 081226A. It was imaged by GROND superimposed on its faint host galaxy (r′ ~ 25.8) and faded away already within 10 ks after the burst. GRB 081226A also belongs to those three cases in our sample where GROND was on target within 10 min after the trigger. The other two events (GRBs 080919 and 100702A), even though with very small X-ray error circles, were unfortunately located in fields crowded by stars, preventing the discovery of the optical/NIR afterglow in any band.

Three of the six optical afterglow light curves (GRBs 090305, 090426, 090510) show a break that can be interpreted as a jet break. The other three afterglows (GRBs 081226A, 090927, 100117A) show a decay slope in agreement with a pre-jet break evolution, allowing us to set lower constraints on their corresponding jet half-opening angle, Θjet. When comparing these results with the long-burst population, we find tentative evidence for wider jet-opening angles of short bursts compared to their long-duration relatives. However, in order to constrain theoretical models, more data are required. Moreover, it should be kept in mind that some long-duration GRBs have relatively large jet-opening angles, too (e.g., Grupe et al. 2007; Racusin et al. 2009; Liang et al. 2008); a clear separation between long and short bursts with respect to their Θjet values obviously does not exist.

The separation between merger and collapsar events becomes more evident when the luminosities of their optical and X-ray afterglows are compared. If the Type I/II classification scheme is used, GRBs 090426 and 090927 have a collapsar origin (Kann et al. 2011), and their afterglow luminosities in the optical band lie in the region occupied by the main body of the long-burst/collapsar population (Fig. 15). The optical luminosities of the afterglows of the Type I GRBs 081226A, 090305, and 100117A are substantially smaller and stand apart from the parameter space occupied by the long-burst sample. On the other hand, the optical afterglow of GRB 090510, which was special due to its very high-energy emission (see appendix), seems to be an intermediate case.

Seven years after the first precise localizations of short-duration GRBs by Swift, the discovery of their optical afterglows remains an observational challenge. Even though the list of well-localized short bursts is not that small anymore (Nysewander et al. 2009; Kann et al. 2011; for a continuous update, see footnote 1), the number of well-observed light curves of short burst afterglows is small. Progress in this respect might be strongly linked to the availability of GRB-dedicated instruments on at least medium-class optical telescopes. GROND is one of them.

Online material

Appendix A: Data tables



Table A.1

Log of the GROND observations of the afterglow (plus host) of GRB 081226A (Fig. 2).

Table A.2

Log of the GROND observations of the afterglow of GRB 090305 (Fig. 4).

Table A.3

Log of the Gemini observations of the afterglow of GRB 090305 (Fig. 4).

Table A.4

Log of the GROND observations of the afterglow of GRB 090927 (Fig. 6).

Appendix B: GRBs without afterglow detection by GROND

B.1. GRB 070729

The original 90% c.l. XRT error circle radius was 57 (Guidorzi et al. 2007a), which was refined to 45 some hours later (Guidorzi et al. 2007b). A host galaxy candidate was soon reported (Berger & Kaplan 2007). However, the final XRT position lies about 9′′ northeast and does not overlap with the previous XRT error circle (Evans 2011a,b).

GRB 070729 was the first short GRB observed with GROND after its commissioning in mid-2007. GROND observations started 6 h after the burst and continued for 4.5 h until sunrise. A second-epoch observation was performed the following night for 1 h. No transient object between the two epochs was detected in any band (Küpcü Yoldaş et al. 2008).

B.2. GRB 071227

GROND started observing the field 4 h after the GRB trigger. At that time, the weather conditions were not good. GROND could not detect the afterglow in any band (Table 4). Second-epoch observations were performed the following night. GROND was on target 29 h after the burst and observed for one hour. At that time, the host galaxy had already been discovered by Swift/UVOT (Sakamoto et al. 2007a; Cucchiara & Sakamoto 2007), and its redshift was measured to be z = 0.381 ± 0.001 (D’Avanzo et al. 2007, 2009; Berger et al. 2007b). VLT observations revealed an optical afterglow situated 31 away from the center of its host, an edge-on galaxy (D’Avanzo et al. 2008, 2009). GROND could not detect the afterglow anymore, only deep limiting magnitudes can be provided: grizJH = 25.5, 25.0, 24.2, 24.4, 21.5, 20.5 at 29 h after the burst. The r′-band upper limit is in agreement with the expectations based on the VLT R-band detection at 0.3 d after the burst if the optical afterglow was fading analogeous to its X-ray counterpart with a decay slope of α ~ 1 (see Fig. 7 in D’Avanzo et al. 2009). The GRB host galaxy is discussed in detail by D’Avanzo et al. (2009).

B.3. GRB 080905A

GROND started observing the field of GRB 080905A about 17.5 h after the burst. Observations continued for only 11 min at a seeing of 22. The combined griz′-band image as well as the combined JHKs-band image do not show the afterglow and faint host galaxy discovered with the ESO/VLT (Rowlinson et al. 2010). Our non-detection is in agreement with these authors, according to whom at the time of our observations the magnitude of the afterglow was around RC = 24, about 1 mag below our detection limit. Although the field is very crowded with stars, the afterglow was situated in a region free of stars. In addition, it was well separated from the center of its suspected anonymous host galaxy. Therefore, the upper limits we can provide (Table 4) are not affected by the light of the host galaxy. We refer to Rowlinson et al. (2010) for a detailed study of this burst and its host galaxy.

B.4. GRB 091109B

GROND observed GRB 091109B six hrs after the trigger. The weather conditions over La Silla observatory were not good at that time. Although GROND was on target for one hour, observations were not deep enough because of clouds. Inside the 28 90% c.l. XRT error circle, no source can be detected in the GROND images (Table 4).

A faint optical transient was discovered by VLT/FORS in the RC band at the time when GROND was observing (Levan et al. 2009b; Malesani et al. 2009), but it was not detected in the NIR (VLT/High Acuity Wide field K-band Imager (HAWK-I)). The non-detection of the afterglow by GROND is in agreement with the magnitude reported by Levan et al. (2009b), RC ~ 25, which is deeper than our limiting r′-band magnitude (23.3; Table 4). Re-analysing the VLT/FORS data, we find that from 20 ks to 40 ks the light curve of the afterglow can be fitted with a single power-law with a slope of α = 0.80 ± 0.04. For this time period, there are also simultaneous Swift/XRT observations which, within errors, can be fitted with the same decay slope (αX = 1.08 ± 0.36).

B.5. GRB 100206A

GROND started observing the field 11 h after the trigger. Observations were performed at high airmass and under poor seeing conditions. No evidence for an afterglow candidate was found in any band (Nicuesa Guelbenzu et al. 2010). Perley et al. (2011) published a detailed investigation of the GRB host galaxy.

B.6. GRB 100625A

GROND visited the field of GRB 100625A several times. First-epoch observations started 11.7 h after the GRB trigger and lasted for about 1 h. Second-epoch observations were done on June 27, about 39 h after the trigger, and a third run was performed on July 1 (about 5.5 d after the trigger). Further data of the field were collected in 2010.

Within the 90% c.l. XRT error circle (Goad et al. 2010b), an object is detected in all GROND epochs, the potential GRB host galaxy (Berger et al. 2010a). No evidence was found in the GROND data for a decaying afterglow superimposed upon this galaxy (Table 4; note that these upper limits refer to an isolated afterglow).

B.7. GRB 100628A

GROND started observing the field about 17 h after the GRB trigger and remained on target for 1.5 h. At that time, two extended objects were already detected inside the final 90% c.l. XRT error circle (Berger et al. 2010e,d). No optical afterglow was detected.

B.8. GRB 101219A

Observations with GROND started about 80 min after the GRB trigger and continued for about two hrs. Although they were performed under good weather conditions (seeing 08, airmass 1.1), the proximity of the Moon affected the depth of the observations. No optical transient was detected by GROND in any band down to deep flux limits (Table 4).

B.9. GRBs with arcmin-sized error circles

This sample contains four bursts where only a Swift/BAT or, in one case, an INTEGRAL/IBIS error circle is known. They are typically 3 arcmin in radius. These events are GRBs 071112B, 081226B, 091117A, and 101129A. Because of visibility constraints by GROND or Swift/XRT in these cases, GROND was on target not earlier than between 6 and 31 h after the corresponding GRB trigger. Given that, on average, short GRB afterglows are intrinsically substantially fainter than those of long GRBs (see Kann et al. 2010, 2011), it was not very likely that in these cases GROND could image the afterglow in any band. Indeed, only upper limits can be provided (Table 4).

Appendix C: Additional observations reported in the literature

C.1. GRB 070729

Swift/BAT triggered on GRB 070729 at 00:25:53 UT (Guidorzi et al. 2007a) and had a duration of T90(15–350 keV) = 0.9 ± 0.1 s (Guidorzi et al. 2007c). The burst was also seen by Konus A (Golenetskii et al. 2007b). An uncatalogued X-ray source was found by Swift/XRT but no optical afterglow by Swift/UVOT (Guidorzi et al. 2007a). Inside the initial XRT error circle, Berger & Kaplan (2007) reported the detection of an extended object visible in the K band. A refined XRT error circle with a radius of was later reported by Guidorzi et al. (2007b). This error circle lies away from the initial XRT position. Optical follow-up observations were performed in the R band with the Swope 40-inch telescope at Las Campanas Observatory, but no sources were detected inside the XRT error circles, implying that the aforementioned galaxy is a red object (Berger & Murphy 2007). No afterglow was detected in the radio band (Chandra & Frail 2007). The position of the XRT afterglow was later refined and shifted by about 5′′ in NE direction while it shrunk to (Evans 2011a,b).

C.2. GRB 071227

This was a bright and multi-peaked GRB with T90(15–350 keV) = 1.8 ± 0.4 s that triggered Swift/BAT at 20:13:47 UT (Sakamoto et al. 2007a; Sato et al. 2007). It was also detected by Konus-Wind (Golenetskii et al. 2007a) and Suzaku/Wide-Band All-Sky Monitor (WAM; Onda et al. 2008). Swift localized a bright X-ray afterglow (Beardmore et al. 2007). UVOT observations (Sakamoto et al. 2007a; Cucchiara & Sakamoto 2007) revealed a single faint source near the XRT error circle, which was identified as a galaxy also visible in the DSS (Berger et al. 2007a). VLT (D’Avanzo et al. 2007, 2009) and Magellan (Berger et al. 2007b) spectroscopy revealed a redshift of this galaxy of z = 0.381 ± 0.001, and further VLT follow-up detected the optical afterglow (D’Avanzo et al. 2008, 2009) at the tip of this edge-on spiral galaxy.

C.3. GRB 080905A

Swift/BAT and Fermi/GBM triggered on GRB 080905 at 11:58:55 UT (Pagani et al. 2008a; Bissaldi et al. 2008). The BAT light curve shows three peaks with a total duration of about 2 s (Pagani et al. 2008a). Its duration was T90 (15–350 keV) = 1.1 ± 0.1s (Cummings et al. 2008). A fading X-ray afterglow was found, but no optical afterglow was detected with UVOT (Pagani et al. 2008a). A faint afterglow candidate was then discovered with the VLT (Malesani et al. 2008), and a host galaxy was also seen (de Ugarte Postigo et al. 2008). The revised XRT error circle is in agreement with this afterglow position (Evans et al. 2008). The afterglow is located in an outer arm of a star-forming spiral galaxy at z = 0.1218 ± 0.0003, making it the closest short GRB known so far. This event has been analyzed in detail by Rowlinson et al. (2010).

C.4. GRB 080919

GRB 080919 triggered Swift/BAT at 00:05:13 UT. The burst consists of a single spike and had a total duration of T90 (15–350 keV) = 0.6 ± 0.1 s. Swift/XRT began observing about 71 s after the BAT trigger. The detected X-ray afterglow could be localized with high precision (; Preger et al. 2008a), but remained undetected from the second orbit on. Swift/UVOT started observing about 11 s after XRT, but no afterglow candidate could be found in the white filter down to m = 18 (Preger et al. 2008b; Baumgartner et al. 2008; Immler & Holland 2008). The size of the X-ray error circle could finally be improved to (Preger et al. 2008c). Ground-based observations with the robotic REM telescope on La Silla, Chile, started already 74 s after the BAT trigger and revealed a bright NIR source in the XRT error circle (H = 13.73 ± 0.03). This source, however, is also listed in the 2MASS catalogue and might therefore be an unrelated Galactic foreground object (Covino et al. 2008). No further follow-up observations are reported in the literature. The position of the XRT afterglow was slightly refined three years after the event (Evans 2011a,b).

C.5. GRB 081226A

GRB 081226A triggered Fermi/Gamma-ray Burst Monitor (GBM) and Swift/BAT at 01:03:37 UT (Godet et al. 2008; Kouveliotou & Connaughton 2009). Its duration was T90(15–350 keV) = 0.4 ± 0.1 s (Krimm et al. 2008). Swift/XRT started observing the field 94.5 s after the BAT trigger, and an afterglow was found (Godet 2008). UVOT started observing 156 s after the trigger, but no optical afterglow was identified (Hoversten & Godet 2008). Optical observations by Robotic Optical Transient Search Experiment (ROTSE)-IIIc starting 25 s after the GRB could only reveal upper limits on any optical afterglow (Schaefer et al. 2008). GROND detected an afterglow candidate (Afonso et al. 2008), but observations with Gemini-S did not reveal a fading behavior, neither of this source nor of a second one found in the XRT error circle (Berger et al. 2008a,b). No radio counterpart of the optical afterglow candidate(s) could be found with the Australia Telescope Compact Array (ATCA; Moin et al. 2009b). The position of the XRT afterglow was slightly refined three years after the event (Evans 2011a,b).

C.6. GRB 090305

The burst triggered Swift/BAT at 05:19:51 UT. The BAT light curve shows a single short spike with a duration of T90(15–350 keV) = 0.4 ± 0.1 s. XRT began observing the field 93 s after the trigger, but no X-ray afterglow was initially detected. UVOT started observing 96 seconds after the trigger, but no optical afterglow candidate was discovered either (Beardmore et al. 2009a; Krimm et al. 2009). Despite the lack of an XRT position, rapid follow-up of the BAT error circle with Gemini-S/GMOS and Magellan/Baade led to the discovery of the optical afterglow (Cenko et al. 2009; Berger & Kelson 2009). In addition, a re-analysis with relaxed constraints allowed the detection of an extremely faint X-ray afterglow at the position of the optical counterpart (Beardmore et al. 2009c). No host galaxy was detected down to deep limits right under the optical afterglow position (Berger 2010b).

C.7. GRB 090927

The burst was detected by Swift/BAT at 10:07:16 UT (Grupe et al. 2009a). It had a Fast Rise Exponential Decay (FRED)-like shape with some substructure and a duration of T90(15–350 keV) = 2.2 ± 0.4 s (Stamatikos et al. 2009). It was also detected by Fermi/GBM (Gruber et al. 2009). The final classification of the burst is not totally clear. It is more likely a long GRB because it shows significant spectral lag and was relatively soft (Grupe et al. 2009b). After its BAT trigger, Swift could not immediately slew to the field due to an Earth-limb constraint. When Swift/UVOT began observing the field 2121 s after the trigger, it immediately discovered an optical afterglow candidate (Gronwall & Grupe 2009; Kuin & Grupe 2009). Only thereafter was the detection of the X-ray afterglow announced, a quite unusual situation (Evans et al. 2009). The afterglow was observed with the 1-m f/4 Zadko telescope in Western Australia (Klotz et al. 2009), which started observations 50 min after the trigger (with the first magnitude value for t ~ 2 h). It was also observed with the Faulkes Telescope South in Australia (Cano et al. 2009), which observed 4.2 h after the onset of the GRB, and with VLT/FORS2 on ESO Paranal (Levan et al. 2009a), which observed 16.5 h after the burst trigger. The VLT observations allowed for a measurement of the afterglow redshift (z = 1.37; Levan et al. 2009a). Radio observations with the Australian ATCA array did not reveal the afterglow (Moin et al. 2009a).

C.8. GRB 091109B

Swift/BAT triggered on GRB 091109B at 21:49:03 UT (T90(15–350 keV) = 0.30 ± 0.03 s; Oates et al. 2009b). An X-ray afterglow was immediately detected, but no optical afterglow was found (Oates et al. 2009a). The burst was a symmetrical spike with no sign of extended emission (Oates et al. 2009b). A faint, rapidly decaying afterglow was discovered with the VLT at coordinates RA, Dec(J2000) = 07:30:56.61, −54:05:22.85 (Levan et al. 2009b; Malesani et al. 2009).

C.9. GRB 100117A

The burst triggered Swift/BAT (de Pasquale et al. 2010a) and Fermi/GBM (Paciesas 2010) at 21:06:19 UT. It had a duration of T90(15–350 keV) = 0.3 ± 0.05 s (Markwardt et al. 2010). Swift/XRT began observing the field 80 s after the BAT trigger and found a bright X-ray afterglow, which could be localized with an uncertainty of (radius) that could later be refined to (Sbarufatti et al. 2010). UVOT started observing about 1 min later but could not find an optical counterpart (de Pasquale et al. 2010a,b). The optical afterglow was detected by Gemini-North 8.3 h after the burst with rAB = 25.46 ± 0.20 (Levan et al. 2010a). The burst is in detail discussed in Fong et al. (2011).

C.10. GRB 100206A

The burst triggered Swift/BAT at 13:30:05 UT (Krimm et al. 2010b) and had a duration of T90 = 0.12 ± 0.03 s (Sakamoto et al. 2010). XRT started observing the field 75 s after the trigger and found an uncatalogued X-ray source (Krimm et al. 2010b), whose coordinates were later refined to RA, Dec(J2000) = 03:08:38.94, 13:09:25.5, with an error radius of (Goad et al. 2010a). The burst was also seen by Fermi/GBM with a spectral peak at  keV, assuming a Band function (von Kienlin 2010). No optical counterpart was detected by Swift/UVOT (Krimm et al. 2010b; Marshall & Krimm 2010) and other ground-based observatories (Bhattacharya et al. 2010; Guziy et al. 2010; Noda et al. 2010; Leloudas et al. 2010; Yurkov et al. 2010; Mao et al. 2010; Andreev et al. 2010; Rumyantsev et al. 2010). Evidence for a galaxy close to the XRT error circle was soon reported based on archival images of the field (Miller et al. 2010), whose redshift was later determined to be z = 0.41 (Cenko et al. 2010a). Morgan et al. (2010) found that at this redshift this galaxy is very bright in JHK, suggesting that this is a luminous infrared galaxy. Levan et al. (2010c) speculated about the discovery of the faint optical afterglow of GRB 100206A based on William Herschel Telescope (WHT) observations starting 7 h after the burst. However, no fading of this source was seen on Gemini images taken 7 and 11.5 h after the event, suggesting that in fact this source could be the true GRB host galaxy (Berger et al. 2010b; Berger & Chornock 2010). This placed a limit of i > 24.7 on the brightness of the optical afterglow at 15.7 h after the burst (Berger & Chornock 2010). The position of the XRT afterglow was slightly refined three years after the event (Evans 2011a,b). Perley et al. (2011) dispute that another faint source very close to the z = 0.41 galaxy might instead be the host.

C.11. GRB 100625A

Swift/BAT triggered and located GRB 100625A at 18:32:28 UT (Holland et al. 2010a). The BAT light curve showed a single spike with a substructure and a duration of about 0.33 s. XRT started observing the field 48 s after the trigger and found an uncatalogued X-ray source, whose coordinates were later refined to RA, Dec(J2000) = 01:03:10.98, −39:05:18.3, with an error radius of . No optical counterpart was detected by Swift/UVOT. The burst was also seen by Konus-Wind and Fermi. The Fermi/GBM light curve shows two closely spaced narrow pulses with a duration (T90) of about 0.32 s (50–300 keV; Holland et al. 2010b). Inside the XRT error circle, an object was reported in the optical bands by ground-based observatories (Levan & Tanvir 2010; Berger et al. 2010a; Tanvir & Levan 2010). However, the non-variation of the object and its extended shape pointed to it being a host galaxy candidate. The position of the XRT afterglow was slightly refined three years after the event (Evans 2011a,b).

C.12. GRB 100628A

Swift/BAT triggered and located GRB 100628A at 08:16:40 UT as did INTEGRAL (Beckmann et al. 2010). In the BAT window, it had a duration of T90(15–350 keV) = 0.036 ± 0.009 s (Immler et al. 2010). Swift/XRT began observing the field 86 s later and located an X-ray afterglow at coordinates RA, Dec(J2000) = 15:03:52.95, −31:39:41.7, with an error radius of (Starling & Immler 2010). No optical afterglow was found, neither by UVOT nor by ground-based observatories

(Immler 2010; Burenin et al. 2010; Berger et al. 2010e,d; Suzuki et al. 2010; Levan et al. 2010b). Based on Magellan observations, Berger et al. (2010e) noticed, however, the presence of several galaxies close to and inside the XRT error circle (see also Berger 2010c). The position of the X-ray afterglow was later rejected when another faint X-ray source was found that had faded away. This source at coordinates RA, Dec(J2000) = 15:03:52.41, −31:39:30.2 (error radius 7′′) is now considered as the most likely X-ray afterglow (Starling et al. 2010). Inside this error circle Berger (2010d) reports the presence of two galaxies; they, however, did not show any evidence of a superposed optical afterglow. For one of these galaxies, Cenko et al. (2010b) measured a redshift of z = 0.102.

C.13. GRB 100702A

The burst triggered Swift/BAT at 01:03:47 UT (Siegel et al. 2010a). It was a FRED-like single-peaked burst with a duration of T90(15–350 keV) = 0.16 ± 0.03 s (Baumgartner et al. 2010). Swift slewed immediately to the burst and found a bright X-ray afterglow, which faded rapidly after an early plateau phase and was already undetected after the first orbit (Grupe & Siegel 2010; Siegel et al. 2010b). No optical/NIR afterglow candidate was found, neither in rapid response observations by ROTSE-IIIc located at Mt. Gamsberg, Namibia (Flewelling et al. 2010) nor by optical observations with the acquisition camera of VLT/X-shooter (Malesani et al. 2010) and NIR observations using Persson’s Auxilliary Nasmyth Infrared Camera (PANIC) at the Magellan/Baade telescope (Fong et al. 2010; Berger et al. 2010c).

C.14. GRB 101219A

GRB 101219A was a short-hard burst localized by Swift/BAT at 02:31:29 UT (Gelbord et al. 2010), which was also detected by Konus-Wind (Golenetskii et al. 2010). The BAT light curve consists of a single spike with a duration of T90(15–350 keV) = 0.6 ± 0.2 s (Krimm et al. 2010a). A fading X-ray afterglow was found 60 s after the trigger, but no optical afterglow was detected (Gelbord et al. 2010). Inside the XRT error circle, a faint extended object was observed in the i and r band with the Gemini South telescope 43 min after the burst (Perley et al. 2010). In addition, the same faint source was detected in the J band with the 6.5-m Magellan Baade telescope 1.5 h after the trigger (Chornock et al. 2010). Second-epoch observations showed no variable source inside the XRT error circle. Spectroscopic observations performed on the host galaxy candidate with GMOS mounted at the Gemini-North telescope derived a redshift of z = 0.718 (Chornock & Berger 2011). The position of the XRT afterglow was slightly revised two years after the event (Evans 2011a,b).


4

Assuming that this is the GRB host galaxy, this color cannot be the Lyman break because the afterglow was detected in the g′ band (Cenko et al. 2009).

5

Observing block, a pre-define observing sequence

6

If the redshift of the former two bursts is not 0.5, as assumed here, but somewhere between 0.2 and 1.0, then the magnitude difference changes by about  ± 2 mag.

7

For a more comprehensive statistical analysis of 650 Swift/XRT light curves, we refer to a recent work by Margutti et al. (2012).

8

This is likely a Type I GRB, despite its long duration (Zhang et al. 2009; Kann et al. 2011).

Acknowledgments

A.N.G., D.A.K., A.R., and S.K. acknowledge support by grant DFG Kl 766/16-1. A.N.G., A.R., D.A.K., and A.U. are grateful for travel funding support through the MPE. A.R. acknowledges additional support by the Jenaer Graduiertenakademie. S.S. acknowledges support by a Grant of Excellence from the Iceland Research. T.K. acknowledges funding by the DFG cluster of excellence “Origin and Structure of the Universe”, F.O.E. funding of his Ph.D. through the DAAD, M.N. support by DFG grant SA 2001/2-1 and P.S. by DFG grant SA 2001/1-1. Part of the funding for GROND (both hardware and personnel) was generously granted by the Leibniz-Prize to G. Hasinger (DFG grant HA 1850/28-1). This work made use of data supplied by the UK Swift science data center at the University of Leicester. We thank W. Fong and R. Margutti for valuable comments to the manuscript. We thank the referee for a fast and constructive reply.

References

  1. Abazajian, K. N., Adelman-McCarthy, J. K., Agüeros, M. A., et al. 2009, ApJS, 182, 543 [NASA ADS] [CrossRef] [Google Scholar]
  2. Afonso, P., Krühler, T., Klose, S., & Greiner, J. 2008, GCN, 8731 [Google Scholar]
  3. Aloy, M. A., Janka, H.-T., & Müller, E. 2005, A&A, 436, 273 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  4. Andreev, M., Sergeev, A., Parakhin, N., et al. 2010, GCN, 10455 [Google Scholar]
  5. Baumgartner, W. H., Barthelmy, S. D., Cummings, J. R., et al. 2008, GCN, 8275 [Google Scholar]
  6. Baumgartner, W. H., Barthelmy, S. D., Cummings, J. R., et al. 2010, GCN, 10926 [Google Scholar]
  7. Beardmore, A. P., Page, K. L., & Sakamoto, T. 2007, GCN, 7153 [Google Scholar]
  8. Beardmore, A. P., Cummings, J. R., Holland, S. T., et al. 2009a, GCN, 8932 [Google Scholar]
  9. Beardmore, A. P., Page, K. L., Evans, P. A., et al. 2009b, GRB Coordinates Network, 8937, 1 [NASA ADS] [Google Scholar]
  10. Beardmore, A. P., Page, K. L., Evans, P. A., et al. 2009c, GCN, 8937 [Google Scholar]
  11. Beckmann, V., Beck, M., Ferrigno, C., et al. 2010, GCN, 10898 [Google Scholar]
  12. Berger, E. 2009, ApJ, 690, 231 [NASA ADS] [CrossRef] [Google Scholar]
  13. Berger, E. 2010a, ApJ, 722, 1946 [NASA ADS] [CrossRef] [Google Scholar]
  14. Berger, E. 2010b, ApJ, 722, 1946 [NASA ADS] [CrossRef] [Google Scholar]
  15. Berger, E. 2010c, GCN, 10908 [Google Scholar]
  16. Berger, E. 2010d, GCN, 10943 [Google Scholar]
  17. Berger, E. 2011, New A Rev., 55, 1 [Google Scholar]
  18. Berger, E., & Chornock, R. 2010, GCN, 10410 [Google Scholar]
  19. Berger, E., & Kaplan, D. L. 2007, GCN, 6680 [Google Scholar]
  20. Berger, E., & Kelson, D. 2009, GCN, 8934 [Google Scholar]
  21. Berger, E., & Murphy, D. 2007, GCN, 6686 [Google Scholar]
  22. Berger, E., Morrell, N., & Roth, M. 2007a, GCN, 7151 [Google Scholar]
  23. Berger, E., Morrell, N., & Roth, M. 2007b, GCN, 7154 [Google Scholar]
  24. Berger, E., Cucchiara, A., & Fox, D. B. 2008a, GCN, 8732 [Google Scholar]
  25. Berger, E., Soderberg, A. M., Cucchiara, A., & Fox, D. B. 2008b, GCN, 8736 [Google Scholar]
  26. Berger, E., Chornock, R., Fong, W., Krzeminski, W., & Anglada, G. 2010a, GCN, 10897 [Google Scholar]
  27. Berger, E., Chornock, R., Tanvir, N., et al. 2010b, GCN, 10395 [Google Scholar]
  28. Berger, E., Fong, W., & Servillat, M. 2010c, GCN, 10921 [Google Scholar]
  29. Berger, E., Guver, T., & Fong, W. 2010d, GCN, 10911 [Google Scholar]
  30. Berger, E., Guver, T., Fong, W., & Chornock, R. 2010e, GCN, 10902 [Google Scholar]
  31. Bhattacharya, D., Mohan, V., Ramaprakash, A. N., Rajarshi, C., & Misra, K. 2010, GCN, 10380 [Google Scholar]
  32. Bissaldi, E., McBreen, S., Connaughton, V., & von Kienlin, A. 2008, GCN, 8204 [Google Scholar]
  33. Bloom, J. S., Kulkarni, S. R., & Djorgovski, S. G. 2002, AJ, 123, 1111 [NASA ADS] [CrossRef] [Google Scholar]
  34. Bloom, J. S., Frail, D. A., & Kulkarni, S. R. 2003, ApJ, 594, 674 [NASA ADS] [CrossRef] [Google Scholar]
  35. Bloom, J. S., Prochaska, J. X., Pooley, D., et al. 2006, ApJ, 638, 354 [NASA ADS] [CrossRef] [Google Scholar]
  36. Burenin, R., Khorunzhev, G., Sazonov, S., et al. 2010, GCN, 10900 [Google Scholar]
  37. Burrows, D. N., Grupe, D., Capalbi, M., et al. 2006, ApJ, 653, 468 [NASA ADS] [CrossRef] [Google Scholar]
  38. Butler, N. R., Kocevski, D., Bloom, J. S., & Curtis, J. L. 2007, ApJ, 671, 656 [NASA ADS] [CrossRef] [Google Scholar]
  39. Cano, Z., Melandri, A., Mundell, C., et al. 2009, GCN, 9960 [Google Scholar]
  40. Cenko, S. B., Cobb, B. E., Perley, D. A., & Bloom, J. S. 2009, GCN, 8933 [Google Scholar]
  41. Cenko, S. B., Bloom, J. S., Perley, D. A., et al. 2010a, GCN, 10389 [Google Scholar]
  42. Cenko, S. B., Perley, D. A., Bloom, J. S., Morgan, A. N., & Cucchiara, A. 2010b, GCN, 10946 [Google Scholar]
  43. Chandra, P., & Frail, D. A. 2007, GCN, 6742 [Google Scholar]
  44. Chevalier, R. A., & Li, Z.-Y. 2000, ApJ, 536, 195 [NASA ADS] [CrossRef] [Google Scholar]
  45. Chornock, R., & Berger, E. 2011, GCN, 11518 [Google Scholar]
  46. Chornock, R., Fong, W., Berger, E., & Persson, E. 2010, GCN, 11469 [Google Scholar]
  47. Covino, S., Antonelli, L. A., Calzoletti, L., et al. 2008, GCN, 8271 [Google Scholar]
  48. Cucchiara, A., & Sakamoto, T. 2007, GCN, 7150 [Google Scholar]
  49. Cummings, J., Barthelmy, S. D., Baumgartner, W., et al. 2008, GCN, 8187 [Google Scholar]
  50. Cummings, J. R., Pal’Shin, V., Yamaoka, K., & Evans, P. 2009, GCN, 10171 [Google Scholar]
  51. Cummings, J. R., Palmer, D. M., Barthelmy, S. D., et al. 2010, GCN, 11436 [Google Scholar]
  52. D’Avanzo, P., Fiore, F., Piranomonte, S., et al. 2007, GCN, 7152 [Google Scholar]
  53. D’Avanzo, P., Covino, S., Fugazza, D., et al. 2008, GCN, 7157 [Google Scholar]
  54. D’Avanzo, P., Malesani, D., Covino, S., et al. 2009, A&A, 498, 711 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  55. de Pasquale, M., Barthelmy, S. D., Burrows, D. N., et al. 2010a, GCN, 10336 [Google Scholar]
  56. de Pasquale, M., Holland, S. T., & Oates, S. 2010b, GCN, 10344 [Google Scholar]
  57. de Pasquale, M., Markwardt, C., & Sbarufatti, B. 2010c, GCN Rep., 269, 1 [NASA ADS] [Google Scholar]
  58. de Pasquale, M., Schady, P., Kuin, N. P. M., et al. 2010d, ApJ, 709, L146 [NASA ADS] [CrossRef] [Google Scholar]
  59. de Ugarte Postigo, A., Castro-Tirado, A. J., Guziy, S., et al. 2006, ApJ, 648, L83 [NASA ADS] [CrossRef] [Google Scholar]
  60. de Ugarte Postigo, A., Malesani, D., Levan, A. J., Hjorth, J., & Tanvir, N. R. 2008, GCN, 8195 [Google Scholar]
  61. D’Elia, V., Stratta, G., Perri, M., & Cummings, J. 2009, GCN, 10292 [Google Scholar]
  62. Della Valle, M., Chincarini, G., Panagia, N., et al. 2006, Nature, 444, 1050 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  63. Evans, P. A. 2011a, GCN, 12250 [Google Scholar]
  64. Evans, P. A. 2011b, GCN, 12273 [Google Scholar]
  65. Evans, P. A., Osborne, J. P., & Goad, M. R. 2008, GCN, 8203 [Google Scholar]
  66. Evans, P. A., Goad, M. R., Osborne, J. P., & Beardmore, A. P. 2009, GCN, 9950 [Google Scholar]
  67. Evans, P. A., Willingale, R., Osborne, J. P., et al. 2010, A&A, 519, A102 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  68. Fan, Y.-Z., & Wei, D.-M. 2011, ApJ, 739, 47 [NASA ADS] [CrossRef] [Google Scholar]
  69. Ferrero, P., Kann, D. A., Zeh, A., et al. 2006, A&A, 457, 857 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  70. Flewelling, H., Zheng, W., Pandey, S. B., & Rujopakarn, W. 2010, GCN, 10917 [Google Scholar]
  71. Fong, W., Berger, E., & Servillat, M. 2010, GCN, 10919 [Google Scholar]
  72. Fong, W., Berger, E., Chornock, R., et al. 2011, ApJ, 730, 26 [NASA ADS] [CrossRef] [Google Scholar]
  73. Fong, W.-F., Berger, E., Margutti, R., et al. 2012, ApJ, 756, 189 [NASA ADS] [CrossRef] [Google Scholar]
  74. Fox, D. B., Frail, D. A., Price, P. A., et al. 2005, Nature, 437, 845 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  75. Frail, D. A., Kulkarni, S. R., Sari, R., et al. 2001, ApJ, 562, L55 [NASA ADS] [CrossRef] [Google Scholar]
  76. Fruchter, A. S., Levan, A. J., Strolger, L., et al. 2006, Nature, 441, 463 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  77. Fynbo, J. P. U., Watson, D., Thöne, C. C., et al. 2006, Nature, 444, 1047 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  78. Gal-Yam, A., Fox, D. B., Price, P. A., et al. 2006, Nature, 444, 1053 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  79. Gehrels, N., Sarazin, C. L., O’Brien, P. T., et al. 2005, Nature, 437, 851 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  80. Gehrels, N., Norris, J. P., Barthelmy, S. D., et al. 2006, Nature, 444, 1044 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  81. Gehrels, N., Barthelmy, S. D., Burrows, D. N., et al. 2008, ApJ, 689, 1161 [NASA ADS] [CrossRef] [Google Scholar]
  82. Gehrels, N., Ramirez-Ruiz, E., & Fox, D. B. 2009, ARA&A, 47, 567 [NASA ADS] [CrossRef] [Google Scholar]
  83. Gelbord, J. M., Barthelmy, S. D., Chester, M. M., et al. 2010, GCN, 11461 [Google Scholar]
  84. Goad, M. R., Osborne, J. P., Beardmore, A. P., & Evans, P. A. 2010a, GCN, 10378 [Google Scholar]
  85. Goad, M. R., Osborne, J. P., Beardmore, A. P., & Evans, P. A. 2010b, GCN, 10886 [Google Scholar]
  86. Godet, O. 2008, GCN, 8738 [Google Scholar]
  87. Godet, O., Baumgartner, W. H., Burrows, D. N., et al. 2008, GCN, 8729 [Google Scholar]
  88. Golenetskii, S., Aptekar, R., Mazets, E., et al. 2007a, GCN, 7155 [Google Scholar]
  89. Golenetskii, S., Aptekar, R., Mazets, E., et al. 2007b, GCN, 6690 [Google Scholar]
  90. Golenetskii, S., Aptekar, R., Frederiks, D., et al. 2010, GCN, 11470 [Google Scholar]
  91. Greiner, J., Bornemann, W., Clemens, C., et al. 2007, The Messenger, 130, 12 [NASA ADS] [Google Scholar]
  92. Greiner, J., Bornemann, W., Clemens, C., et al. 2008, PASP, 120, 405 [NASA ADS] [CrossRef] [Google Scholar]
  93. Greiner, J., Krühler, T., Fynbo, J. P. U., et al. 2009, ApJ, 693, 1610 [NASA ADS] [CrossRef] [Google Scholar]
  94. Gronwall, C., & Grupe, D. 2009, GCN, 9946 [Google Scholar]
  95. Gruber, D., Bissaldi, E., & McBreen, S. 2009, GCN, 9974 [Google Scholar]
  96. Grupe, D., & Siegel, M. 2010, GCN, 10924 [Google Scholar]
  97. Grupe, D., Burrows, D. N., Patel, S. K., et al. 2006, ApJ, 653, 462 [NASA ADS] [CrossRef] [Google Scholar]
  98. Grupe, D., Gronwall, C., Wang, X.-Y., et al. 2007, ApJ, 662, 443 [NASA ADS] [CrossRef] [Google Scholar]
  99. Grupe, D., Cummings, J. R., Gronwall, C., et al. 2009a, GCN, 9945 [Google Scholar]
  100. Grupe, D., Kuin, P., Cummings, J. R., et al. 2009b, GCN Rep., 252 [Google Scholar]
  101. Guidorzi, C., Barbier, L. M., Barthelmy, S. D., et al. 2007a, GCN, 6678 [Google Scholar]
  102. Guidorzi, C., Romano, P., & Moretti, A. 2007b, GCN, 6682 [Google Scholar]
  103. Guidorzi, C., Sato, G., Cucciara, A., et al. 2007c, GCN Rep., 77 [Google Scholar]
  104. Guziy, S., Aceituno, F. J., & Castro-Tirado, A. J. 2010, GCN, 10384 [Google Scholar]
  105. He, H.-N., Wu, X.-F., Toma, K., Wang, X.-Y., & Mészáros, P. 2011, ApJ, 733, 22 [NASA ADS] [CrossRef] [Google Scholar]
  106. Hjorth, J., Sollerman, J., Møller, P., et al. 2003, Nature, 423, 847 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  107. Hjorth, J., Sollerman, J., Gorosabel, J., et al. 2005, ApJ, 630, L117 [NASA ADS] [CrossRef] [Google Scholar]
  108. Holland, S. T., Burrows, D. N., Kennea, J. A., et al. 2010a, GCN, 10884 [Google Scholar]
  109. Holland, S. T., Landsman, W. B., Page, K. L., & Stamatikos, M. 2010b, GCN Rep., 289 [Google Scholar]
  110. Hoversten, E. A., & Godet, O. 2008, GCN, 8737 [Google Scholar]
  111. Hoversten, E. A., Krimm, H. A., Grupe, D., et al. 2009, GCN Rep., 218 [Google Scholar]
  112. Immler, S. 2010, GCN, 10901 [Google Scholar]
  113. Immler, S., & Holland, S. T. 2008, GCN, 8277 [Google Scholar]
  114. Immler, S., Starling, R. L. C., Evans, P. A., Barthelmy, S. D., & Sakamoto, T. 2010, GCN Rep., 290 [Google Scholar]
  115. Kann, D. A., Klose, S., & Zeh, A. 2006, ApJ, 641, 993 [NASA ADS] [CrossRef] [Google Scholar]
  116. Kann, D. A., Klose, S., Zhang, B., et al. 2010, ApJ, 720, 1513 [NASA ADS] [CrossRef] [Google Scholar]
  117. Kann, D. A., Klose, S., Zhang, B., et al. 2011, ApJ, 734, 96 [NASA ADS] [CrossRef] [Google Scholar]
  118. Kawabata, K. S., Deng, J., Wang, L., et al. 2003, ApJ, 593, L19 [NASA ADS] [CrossRef] [Google Scholar]
  119. Klotz, A., Vaalsta, T. P., Yan, L., et al. 2009, GCN, 9956 [Google Scholar]
  120. Kouveliotou, C., & Connaughton, V. 2009, GCN, 8785 [Google Scholar]
  121. Kouveliotou, C., Meegan, C. A., Fishman, G. J., et al. 1993, ApJ, 413, L101 [NASA ADS] [CrossRef] [Google Scholar]
  122. Krimm, H. A., Barthelmy, S. D., Baumgartner, W. H., et al. 2008, GCN, 8735 [Google Scholar]
  123. Krimm, H. A., Barthelmy, S. D., Beardmore, A. P., et al. 2009, GCN, 8936 [Google Scholar]
  124. Krimm, H. A., Barthelmy, S. D., Baumgartner, W. H., et al. 2010a, GCN, 11467 [Google Scholar]
  125. Krimm, H. A., Baumgartner, W. H., Evans, P. A., et al. 2010b, GCN, 10376 [Google Scholar]
  126. Krimm, H. A., Cummings, J. R., Evans, P. A., & Marshall, F. E. 2010c, GCN Rep., 271 [Google Scholar]
  127. Krühler, T., Küpcü Yoldaş, A., Greiner, J., et al. 2008, ApJ, 685, 376 [NASA ADS] [CrossRef] [Google Scholar]
  128. Kuin, N. P. M., & Grupe, D. 2009, GCN, 9954 [Google Scholar]
  129. Kumar, P., & Barniol Duran, R. 2010, MNRAS, 409, 226 [NASA ADS] [CrossRef] [Google Scholar]
  130. Küpcü Yoldaş, A., Krühler, T., Greiner, J., et al. 2008, in AIP Conf. Ser. 1000, ed. M. Galassi, D. Palmer, & E. Fenimore, 227 [Google Scholar]
  131. Leibler, C. N., & Berger, E. 2010, ApJ, 725, 1202 [NASA ADS] [CrossRef] [Google Scholar]
  132. Leloudas, G., Xu, D., Malesani, D., et al. 2010, GCN, 10387 [Google Scholar]
  133. Levan, A. J., & Tanvir, N. R. 2010, GCN, 10887 [Google Scholar]
  134. Levan, A. J., Fynbo, J. P. U., Hjorth, J., et al. 2009a, GCN, 9958 [Google Scholar]
  135. Levan, A. J., Tanvir, N. R., Hjorth, J., et al. 2009b, GCN, 10154 [Google Scholar]
  136. Levan, A. J., Graham, J., Fruchter, A., et al. 2010a, GCN, 10349 [Google Scholar]
  137. Levan, A. J., Tanvir, N. R., Wiersema, K., & Cenko, S. B. 2010b, GCN, 10909 [Google Scholar]
  138. Levan, A. J., Tanvir, N. R., Wiersema, K., et al. 2010c, GCN, 10386 [Google Scholar]
  139. Levesque, E., Chornock, R., Kewley, L., et al. 2009, GCN, 9264 [Google Scholar]
  140. Liang, E., Racusin, J. L., Zhang, B., Zhang, B., & Burrows, D. N. 2008, ApJ, 675, 528 [NASA ADS] [CrossRef] [Google Scholar]
  141. Lu, R.-J., Wei, J.-J., Qin, S.-F., & Liang, E.-W. 2012, ApJ, 745, 168 [NASA ADS] [CrossRef] [Google Scholar]
  142. MacFadyen, A. I., & Woosley, S. E. 1999, ApJ, 524, 262 [NASA ADS] [CrossRef] [Google Scholar]
  143. Malesani, D., Covino, S., D’Avanzo, P., et al. 2007, A&A, 473, 77 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  144. Malesani, D., de Ugarte Postigo, A., Fynbo, J. P. U., et al. 2008, GCN, 8190 [Google Scholar]
  145. Malesani, D., de Ugarte Postigo, A., Levan, A. J., et al. 2009, GCN, 10156 [Google Scholar]
  146. Malesani, D., Levan, A. J., & Fynbo, J. P. U. 2010, GCN, 10918 [Google Scholar]
  147. Mao, J., Wang, D., & Bai, J. 2010, GCN, 10392 [Google Scholar]
  148. Margutti, R., Zaninoni, E., Bernardini, M. G., Chincarini, G., & for the Swift-XRT team 2012 [arXiv:1207.0537] [Google Scholar]
  149. Markwardt, C. B., Barthelmy, S. D., Baumgartner, W. H., et al. 2010, GCN, 10338 [Google Scholar]
  150. Marshall, F. E., & Krimm, H. A. 2010, GCN, 10394 [Google Scholar]
  151. Matheson, T., Garnavich, P. M., Stanek, K. Z., et al. 2003, ApJ, 599, 394 [NASA ADS] [CrossRef] [Google Scholar]
  152. Mazzali, P. A., Deng, J., Nomoto, K., et al. 2006, Nature, 442, 1018 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  153. McBreen, S., Krühler, T., Rau, A., et al. 2010, A&A, 516, A71 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  154. Mereghetti, S., Paizis, A., Gotz, D., et al. 2008, GCN, 8734 [Google Scholar]
  155. Miller, A. A., Perley, D. A., Bloom, J. S., Cenko, S. B., & Nugent, P. E. 2010, GCN, 10377 [Google Scholar]
  156. Moin, A., Frail, D. A., Tingay, S., & Macquart, J. 2009a, GCN, 10021 [Google Scholar]
  157. Moin, A., Tingay, S., Phillips, C., et al. 2009b, GCN, 8952 [Google Scholar]
  158. Morgan, A. N., Cobb, B. E., Bloom, J. S., et al. 2010, GCN, 10390 [Google Scholar]
  159. Nakar, E. 2007, Phys. Rep., 442, 166 [NASA ADS] [CrossRef] [Google Scholar]
  160. Nardini, M., Ghisellini, G., Ghirlanda, G., et al. 2006, A&A, 451, 821 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  161. Nicuesa Guelbenzu, A., Krühler, T., Klose, S., & Greiner, J. 2010, GCN, 10396 [Google Scholar]
  162. NicuesaGuelbenzu, A., Klose, S., Rossi, A., et al. 2011, A&A, 531, L6 (Paper I) [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  163. NicuesaGuelbenzu, A., Klose, S., Krühler, T., et al. 2012, A&A, 538, L7 (Paper II) [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  164. Noda, K., Sonoda, E., Hayasi, H., et al. 2010, GCN, 10385 [Google Scholar]
  165. Nysewander, M., Fruchter, A. S., & Pe’er, A. 2009, ApJ, 701, 824 [NASA ADS] [CrossRef] [Google Scholar]
  166. Oates, S. R., Barthelmy, S. D., Baumgartner, W. H., et al. 2009a, GCN, 10148 [Google Scholar]
  167. Oates, S. R., Page, K. L., Evans, P. A., & Markwardt, C. B. 2009b, GCN Rep., 259 [Google Scholar]
  168. Onda, K., Tashiro, M., Terada, Y., et al. 2008, GCN, 7158 [Google Scholar]
  169. Paciesas, W. 2010, GCN, 10345 [Google Scholar]
  170. Paczyński, B. 1986, ApJ, 308, L43 [NASA ADS] [CrossRef] [Google Scholar]
  171. Pagani, C., Baumgartner, W. H., Beardmore, A. P., et al. 2008a, GCN, 8180 [Google Scholar]
  172. Pagani, C., Racusin, J. L., Brown, P., & Cummings, J. 2008b, GCN Rep., 162 [Google Scholar]
  173. Panaitescu, A. 2011, MNRAS, 414, 1379 [NASA ADS] [CrossRef] [Google Scholar]
  174. Panaitescu, A., & Kumar, P. 2001, ApJ, 554, 667 [NASA ADS] [CrossRef] [Google Scholar]
  175. Panaitescu, A., Kumar, P., & Narayan, R. 2001, ApJ, 561, L171 [NASA ADS] [CrossRef] [Google Scholar]
  176. Perley, D. A., Cenko, S. B., Bloom, J. S., et al. 2009, AJ, 138, 1690 [NASA ADS] [CrossRef] [Google Scholar]
  177. Perley, D. A., Berger, E., Cenko, S. B., et al. 2010, GCN, 11464 [Google Scholar]
  178. Perley, D. A., Modjaz, M., Morgan, A. N., et al. 2011, ApJ, in press [arXiv:1112.3963] [Google Scholar]
  179. Perri, M., Stratta, G., Fenimore, E., et al. 2007, GCN Rep., 103 [Google Scholar]
  180. Pian, E., Mazzali, P. A., Masetti, N., et al. 2006, Nature, 442, 1011 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
  181. Preger, B., Barthelmy, S. D., Baumgartner, W. H., et al. 2008a, GCN, 8270 [Google Scholar]
  182. Preger, B., Perri, M., Stratta, G., et al. 2008b, GCN Rep., 172 [Google Scholar]
  183. Preger, B., Stratta, G., & Perri, M. 2008c, GCN, 8276 [Google Scholar]
  184. Racusin, J. L., Liang, E. W., Burrows, D. N., et al. 2009, ApJ, 698, 43 [NASA ADS] [CrossRef] [Google Scholar]
  185. Rau, A., McBreen, S., & Krühler, T. 2009, GCN, 9353 [Google Scholar]
  186. Rezzolla, L., Giacomazzo, B., Baiotti, L., et al. 2011, ApJ, 732, L6 [NASA ADS] [CrossRef] [Google Scholar]
  187. Rowlinson, A., Wiersema, K., Levan, A. J., et al. 2010, MNRAS, 408, 383 [NASA ADS] [CrossRef] [Google Scholar]
  188. Rumyantsev, V., Shakhovkoy, D., & Pozanenko, A. 2010, GCN, 10456 [Google Scholar]
  189. Sakamoto, T., Baumgartner, W. H., Beardmore, A. P., et al. 2007a, GCN, 7147 [Google Scholar]
  190. Sakamoto, T., Norris, J., Ukwatta, T., et al. 2007b, GCN, 7156 [Google Scholar]
  191. Sakamoto, T., Barthelmy, S. D., Baumgartner, W. H., et al. 2009, GCN, 10180 [Google Scholar]
  192. Sakamoto, T., Barthelmy, S. D., Baumgartner, W. H., et al. 2010, GCN, 10379 [Google Scholar]
  193. Sakamoto, T., Barthelmy, S. D., Baumgartner, W. H., et al. 2011, ApJS, 195, 2 [NASA ADS] [CrossRef] [Google Scholar]
  194. Sari, R., Piran, T., & Halpern, J. P. 1999, ApJ, 519, L17 [NASA ADS] [CrossRef] [Google Scholar]
  195. Sato, G., Barbier, L., Barthelmy, S. D., et al. 2007, GCN, 7148 [Google Scholar]
  196. Sato, G., Barthelmy, S. D., Baumgartner, W. H., et al. 2009, GCN, 9263 [Google Scholar]
  197. Sbarufatti, B., Margutti, R., & de Pasquale, M. 2010, GCN, 10342 [Google Scholar]
  198. Schaefer, B. E., Rykoff, E. S., & Yuan, F. 2008, GCN, 8730 [Google Scholar]
  199. Schlegel, D. J., Finkbeiner, D. P., & Davis, M. 1998, ApJ, 500, 525 [NASA ADS] [CrossRef] [Google Scholar]
  200. Schulze, S., Klose, S., Björnsson, G., et al. 2011, A&A, 526, A23 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  201. Siegel, M. H., Barthelmy, S. D., Burrows, D. N., et al. 2010a, GCN, 10916 [Google Scholar]
  202. Siegel, M. H., Grupe, D., de Pasquale, M., et al. 2010b, GCN Rep., 292 [Google Scholar]
  203. Skrutskie, M. F., Cutri, R. M., Stiening, R., et al. 2006, AJ, 131, 1163 [NASA ADS] [CrossRef] [Google Scholar]
  204. Soderberg, A. M., Berger, E., Kasliwal, M., et al. 2006, ApJ, 650, 261 [NASA ADS] [CrossRef] [Google Scholar]
  205. Spergel, D. N., Verde, L., Peiris, H. V., et al. 2003, ApJS, 148, 175 [NASA ADS] [CrossRef] [Google Scholar]
  206. Stamatikos, M., Barthelmy, S. D., Baumgartner, W. H., et al. 2009, GCN, 9955 [Google Scholar]
  207. Stanek, K. Z., Matheson, T., Garnavich, P. M., et al. 2003, ApJ, 591, L17 [NASA ADS] [CrossRef] [Google Scholar]
  208. Starling, R. L. C., & Immler, S. 2010, GCN, 10899 [Google Scholar]
  209. Starling, R. L. C., Evans, P. A., & Immler, S. 2010, GCN, 10941 [Google Scholar]
  210. Stratta, G., D’Avanzo, P., Piranomonte, S., et al. 2007, A&A, 474, 827 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  211. Suzuki, D., Omori, K., Hayashi, F., et al. 2010, GCN, 10904 [Google Scholar]
  212. Tanvir, N. R., & Levan, A. J. 2010, GCN, 10905 [Google Scholar]
  213. Thöne, C. C., Fynbo, J. P. U., Östlin, G., et al. 2008, ApJ, 676, 1151 [NASA ADS] [CrossRef] [Google Scholar]
  214. Thöne, C. C., Campana, S., Lazzati, D., et al. 2011, MNRAS, 414, 479 [NASA ADS] [CrossRef] [Google Scholar]
  215. Tody, D. 1993, ASP Conf. Ser., 52, 173 [Google Scholar]
  216. Usov, V. V. 1992, Nature, 357, 472 [NASA ADS] [CrossRef] [Google Scholar]
  217. von Kienlin, A. 2010, GCN, 10381 [Google Scholar]
  218. Woosley, S. E., & Bloom, J. S. 2006, ARA&A, 44, 507 [NASA ADS] [CrossRef] [Google Scholar]
  219. Yurkov, V., Sergienko, S., Gorbovskoy, E., et al. 2010, GCN, 10391 [Google Scholar]
  220. Zeh, A., Klose, S., & Hartmann, D. H. 2004, ApJ, 609, 952 [NASA ADS] [CrossRef] [Google Scholar]
  221. Zeh, A., Klose, S., & Kann, D. A. 2006, ApJ, 637, 889 [NASA ADS] [CrossRef] [Google Scholar]
  222. Zhang, W., Woosley, S. E., & Heger, A. 2004, ApJ, 608, 365 [NASA ADS] [CrossRef] [Google Scholar]
  223. Zhang, B., Zhang, B.-B., Liang, E.-W., et al. 2007, ApJ, 655, L25 [NASA ADS] [CrossRef] [Google Scholar]
  224. Zhang, B., Zhang, B.-B., Virgili, F. J., et al. 2009, ApJ, 703, 1696 [NASA ADS] [CrossRef] [Google Scholar]

All Tables

Table 1

The 20 short bursts of our sample.

Table 2

GRB 090305: predicted β based on the α − β relations using α1 = 0.56 ± 0.04 and α2 = 2.29 ± 0.60.

Table 3

GRB 090927: predicted β based on the α − β relations using α = 1.32 ± 0.14 (for details, see Table 2).

Table 4

Summary of the 3σ upper limits for the short-burst afterglows not detected with GROND based on first-epoch data (AB magnitudes).

Table 5

Summary of the data for the six bursts with optical afterglow detection by GROND.

Table A.1

Log of the GROND observations of the afterglow (plus host) of GRB 081226A (Fig. 2).

Table A.2

Log of the GROND observations of the afterglow of GRB 090305 (Fig. 4).

Table A.3

Log of the Gemini observations of the afterglow of GRB 090305 (Fig. 4).

Table A.4

Log of the GROND observations of the afterglow of GRB 090927 (Fig. 6).

All Figures

thumbnail Fig. 1

White-band image of the field of GRB 081226A. Inside the 90% c.l. XRT error circle () lie three objects (A,B,C). The position of the afterglow is indicated (C). In order to go deep, all GROND images of the first and the second epoch have been combined.

In the text
thumbnail Fig. 2

GROND r′-band light curve of the afterglow of GRB 081226A fitted with a single power-law plus host galaxy component. Overplotted in green are the Gemini-S/GMOS r′-band data (Table A.1). No corrections for the slightly different filters have been performed.

In the text
thumbnail Fig. 3

Field of GRB 090305: the optical afterglow (A) and the object closest to it (B). Shown here is the griz′-combined (white-band) image taken between 4 ks to 7 ks after the burst. The circle is just drawn to guide the eye; there is no independent Swift/XRT position (Beardmore et al. 2009c).

In the text
thumbnail Fig. 4

Gemini and GROND light curve of the optical afterglow of GRB 090305. All data are fit simultaneously. Open circles are GROND, while filled circles are Gemini. Color coding: green g′ band (shifted by  + 0.5 mag), red r′ band, brown i′ band (shifted by −0.5 mag), black z′ band (shifted by −1 mag).

In the text
thumbnail Fig. 5

GROND SED of the afterglow of GRB 090305 at 6 ks after the burst, after correction for Galactic extinction. Index G stands for GROND.

In the text
thumbnail Fig. 6

The r′,i′-band light curve of the optical afterglow of GRB 090927 (the i′-band is shifted by −0.6 mag; Table A.4). Overplotted are also R-band data reported in GCN Circulars (Klotz et al. 2009; Cano et al. 2009; Levan et al. 2009a; in violet) as well as the X-ray data (Evans et al. 2010).

In the text
thumbnail Fig. 7

SED of the afterglow of GRB 090927 at t = 65 ks (from g′ to Ks). It is best fitted by a power-law with no evidence for extinction in the host galaxy. Note that the NIR bands are only upper limits.

In the text
thumbnail Fig. 8

Optical-to-X-ray SED of the afterglow of GRB 090927 at t = 65 ks.

In the text
thumbnail Fig. 9

Finding chart of the field of GRB 090927 (GROND griz′-band combined). Left: first-epoch detection of the afterglow with GROND. Right: deep, late-epoch observation of the field in June 2011. The circle (25 in radius), drawn to guide the eye, is centered at the position of the optical afterglow. A and B label the two galaxies nearest to the afterglow.

In the text
thumbnail Fig. 10

Combined GROND griz′-band (white) image of the field of GRB 100117A taken half a year after the burst. The circle is just drawn to guide the eye. It is centered at the position of the optical transient discovered by Fong et al. (2011) and circumscribes the GRB host galaxy.

In the text
thumbnail Fig. 11

Combined GROND gri′ white-band light curve of the decaying afterglow of GRB 100117A, centered on galaxy (Fig. 10). The host galaxy magnitude is shown as a straight line, including the 1σ error (measured by GROND eight months after the burst). Note that the y-axis shows arbitrarily magnitudes.

In the text
thumbnail Fig. 12

Field of GRB 080919. The XRT error circle (radius ) lies close to a relatively bright foreground star.

In the text
thumbnail Fig. 13

Finding chart of the field of GRB 100702A in the GROND J band. Shown also is the 90% c.l. XRT error circle (; Siegel et al. 2010a).

In the text
thumbnail Fig. 14

Light curves of long and short GRB afterglows. These light curves have been corrected individually for Galactic foreground extinction following Schlegel et al. (1998), and, if possible, for host galaxy contribution. The thin gray lines are the long GRB sample of Kann et al. (2010). The red squares connected by splines represent the afterglow detections reported by Kann et al. (2011). The short GRB afterglows detected by GROND and presented in Papers I and II as well as this work are given as labeled thick black lines (they may include additional data beyond the GROND detections). Upper limits presented in this work (Table 4) are given as blue triangles. GRB 100702A is highlighted also because of its very early upper limits. The last data point for GRB 100117A is from Fong et al. (2011), the other data points as well as the data for GRBs 090305 and 081226A are presented in this paper. Early data for GRB 090927 are taken from Klotz et al. (2009), Levan et al. (2009a), Cano et al. (2009), and Kuin & Grupe (2009).

In the text
thumbnail Fig. 15

Light curves of the six GROND-detected short GRB afterglows as well as the upper limits in the redshift z = 1 frame. The labeling is identical to Fig. 14. GRBs 090426 and 090927 are likely Type II. The luminosity is in units of erg/s. See text for further details.

In the text
thumbnail Fig. 16

Observed distribution of jet half-opening angles of 74 long bursts (based on the compilation in Lu et al. 2012) compared to the short-burst sample. Since the latter has much less data, we do not plot a histogram but only points. An arrow indicates a lower limit on Θjet. The Type I events GRB 051221A, 060614, and 070714B listed in Lu et al. (2012) have not been used for the plot of the long-burst data.

In the text
thumbnail Fig. 17

Luminosity evolution of the X-ray afterglows of the short bursts in our sample. Highlighted are the bursts with optical afterglows (Figs. 14, 15). Black lines represent the afterglows of the likely Type II events GRB 090426 and GRB 00927, green the afterglows of the Type I events GRBs 081226A, 090510, and 100117A. No X-ray afterglow light curve was reported for GRB 090305. Overplotted is also the short-burst sample compiled by Kann et al. (2011) (red color) as well as the X-ray afterglows of the long-burst sample with known redshift (gray). All short-burst afterglows are less luminous than the mean of long-burst afterglow luminosities (orange line); however, there is a continuous overlap between short and long GRB afterglows.

In the text

Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.

Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.

Initial download of the metrics may take a while.
