Electron acceleration during threedimensional relaxation of an electron beamreturn current plasma system in a magnetic field
^{1} Astronomical Institute of the Academy of Sciences of the Czech Republic, 25165 Ondřejov, Czech Republic
email: karlicky@asu.cas.cz
^{2} SUPA, School of Physics & Astronomy, University of Glasgow, G12 8QQ, UK
Received: 12 April 2012
Accepted: 10 July 2012
Aims. We investigate the effects of acceleration during nonlinear electronbeam relaxation in magnetized plasma in the case of electron transport in solar flares.
Methods. The evolution of electron distribution functions is computed using a threedimensional particleincell electromagnetic code. Analytical estimations under simplified assumptions are made to provide comparisons.
Results. We show that, during the nonlinear evolution of the beamplasma system, the accelerated electron population appears. We found that, although the electron beam loses its energy efficiently to the thermal plasma, a noticeable part of the electron population is accelerated. For model cases with initially monoenergetic beams in uniform plasma, we found that the amount of energy in the accelerated electrons above the injected beamelectron energy varies depending the plasma conditions and could be around 10–30% of the initial beam energy.
Conclusions. This type of acceleration could be important for the interpretation of nonthermal electron populations in solar flares. Its neglect could lead to the overestimation of accelerated electron numbers. The results emphasize that collective plasma effects should not be treated simply as an additional energyloss mechanism, when hard Xray emission in solar flares is interpreted, notably in the case of RHESSI data.
Key words: Sun: flares / Sun: particle emission / Sun: Xrays, gamma rays
© ESO, 2012
1. Introduction
Solar flare Xray observations provide often unique insights into the processes of electron acceleration and transport. Recent observations of solar flares, notably with RHESSI (Lin et al. 2002) have emphasized the high efficiency of electron acceleration in solar flares (for a recent review of electron properties, see Kontar et al. 2011; and for the corresponding implications for particle transport in solar flares, Karlický 1997; and Holman et al. 2011).
The high efficiency of electron acceleration results in high electron fluxes or concentrations of dekakeV electrons in solar flares, and the subsequent importance of collective effects to particle transport in the solar atmosphere. The presence of large number of energetic electrons in coronal loops could trigger a number of instabilities and generate plasma waves, which in turn affect the transport of energetic particles from the acceleration region down to the chromosphere. It has been shown that accounting for these collective effects could affect the interpretation of hard Xray spectra and lead to additional observational consequences that are essential to the study of solar flares. For example, the inclusion of Langmuir wave generation in the treatment of spatially localized electron beams (Hannah et al. 2009) prevents the formation of a pronounced lowenergy cutoff that appears in purely collisional models (e.g. Brown 1971; Brown et al. 2002). Weibel instability (Weibel 1959) can quickly increase the velocities in the direction perpendicular to the beam propagation and affect the observed Xray anisotropy (Karlický & Bárta 2009; Karlický & Kašparová 2009). The presence of Langmuir waves in a flaring loop could also result in plasma emission (e.g. Vlahos & Papadopoulos 1979; Emslie & Smith 1984; Hamilton & Petrosian 1987), providing additional constraints on nonthermal electron populations in solar flares.
In laboratory plasma experiments, collisionless effects involving various instabilities have been demonstrated to play a key role in electron transport. In experiments to study the beamplasma interaction, the appearance of electrons with energies exceeding that of the injected beam energy was noted in early studies (e.g. Berezin et al. 1964; Fainberg 1968; Kovalenko 1983). These abovetheinjected energy electrons are normally connected to either the presence of plasma inhomogeneities (Vedenov et al. 1967; Ryutov 1969; Nishikawa & Ryutov 1976; Escande 1979) or the nonlinear effects of waveparticle interactions (Breizman & Ryutov 1975; Timofeev & Terekhov 2010). Furthermore, the influence of plasma inhomogeneities or wavewave interactions on beamplasma instability in the solar context has been studied extensively in connection to the theory of solar radiotype III bursts (e.g. Muschietti et al. 1985; Tyshetskiy et al. 2007; Kontar & Reid 2009; Tsiklauri 2010; Reid & Kontar 2010; Ziebell et al. 2011). The processes governing nonthermal electron evolution in solar flares span a computationally prohibitive range of timescales from the inverse plasma period to observational timescales of thousands of seconds. Therefore, modeling efforts in solar flare physics have focused either on relatively long observational timescales by either ignoring shorttimescales or addressing the microphysics on scales smaller than the observational scales (e.g. Bret 2009; Bingham et al. 2001; Eliasson et al. 2006; Hewett et al. 1991; Lee et al. 2008; Messmer 2002; Rose et al. 2002; Sakai et al. 2006; Saito & Sakai 2004).
Kontar et al. (2012) showed that the kspectrum evolution of beamgenerated Langmuir waves in collisional plasma could result in substantial energy gain by high energy electrons or the effective acceleration of electrons of the same beam above 20 keV for solar flare conditions. Thus, if collisional relaxation is assumed, the number of energetic electrons inferred from Xray spectra could be overestimated and may lead to an apparently large number of accelerated electrons. However, the treatment of Kontar et al. (2012) is a onedimensional analysis based on weak turbulence theory. They showed that a positive density gradient, externally excited density fluctuations, and the threewave interaction involving ionsound mode could lead to an effective acceleration of beam electrons. However, the role of the guiding magnetic field as well as threedimensional (3D) aspects of beamplasma interaction have not yet been addressed.
This paper investigates the nonlinear evolution of nonthermal electron beams in a plasma. Using the particleincell (PIC) model developed in Karlický (2009) and Karlický & Kašparová (2009), we investigate the effects of the acceleration of electrons in the beam during a nonlinear stage of beamplasma instability for various values of the guiding magnetic field. We show that about ≃ 10 − 30% of electrons are accelerated to the energies greater than the energies at which they were injected. The presence of a guiding field increases the number of electrons accelerated during a beamplasma interaction. The results show the appearance of accelerated electrons and highlight that collective effects can lead to not only additional energy losses for lower energy electrons but the acceleration of some electrons above the initial energy of electrons. As the hard Xray spectra in solar flares is normally due to dekakeV electrons, this acceleration effect should be taken into account when the number of accelerated electrons is estimated. In this paper, we compared these results with analytical estimates.
Fig. 1 The electron velocity distributions for model E at four different times: at the initial state a), at ω_{pe}t = 40 b), at ω_{pe}t = 140 c), and ω_{pe}t = 200 d). Crosses correspond to f(v_{z}), dotted and dashed lines display f(v_{x}) and f(v_{y}), respectively. Note that f(v_{x}) and f(v_{y}) overlap. The vertical line in the part a) at v/c = 0.666 denotes the monoenergetic electron beam.
Fig. 2 The Langmuir wave energy for model E in the kspace at four different times: ω_{pe}t = 40 a), ω_{pe}t = 60 b), ω_{pe}t = 140 c), and ω_{pe}t = 200 d) (solid lines). For comparison in each panel, the initial Langmuir wave energy is added (dashed line).
Fig. 3 The electron energy distributions for model E at four different times: ω_{pe}t = 40 a), ω_{pe}t = 60 b), ω_{pe}t = 140 c), and ω_{pe}t = 200 d) (solid lines). For comparison in each panel, the initial electronplasma distribution together with the initial monoenergetic beam are added (dashed lines).
Fig. 4 The electron energy distributions (solid lines) at ω_{pe}t = 200 as a function of the magnetic field in models AF with ω_{ce}/ω_{pe} = 0.0, 0.1, 0.5, 0.7, 1.0, and 1.3, respectively. For comparison in each panel we plot the initial electron plasma distribution together with the initial monoenergetic beam (dashed lines).
2. Simulation model
It is commonly accepted that electrons in solar flares are accelerated at low corona heights by primary energyrelease processes. They propagate along the magnetic field lines as electron beams downwards to loop footpoints, where they generate hard Xray emission. The rapid variations (of timescales ~45 ms) in this hard Xray emission observed in some events indicate that the acceleration as well as the electron beam flux can may themselves rapidly varying (e.g. Kiplinger et al. 1983; Aschwanden et al. 1995). This means that the effect of fast propagation needs to be considered in the evolution of these electron beams. Assuming that the electrons have a powerlaw distribution in the acceleration region. Owing to the propagation, fast electrons could then overtake slower ones at some distance from the acceleration site (e.g. Hannah et al. 2009), forming an unstable distribution that can be approximated by the monoenergetic beam.
For our study, we used a 3D (three spatial and three velocity components) relativistic electromagnetic PIC code (Karlický 2009). The system sizes are L_{x} = 45Δ, L_{y} = 45Δ, and L_{z} = 600Δ, where Δ is the grid size.
We initiated a spatially homogeneous electronproton plasma with the protonelectron mass ratio m_{p}/m_{e} = 16 (models AH in Table 1). This ratio was chosen to shorten the computational times and keep the proton skindepth shorter than the dimensions of the numerical box. Nevertheless, the ratio was still sufficient to clearly separate the dynamics of electrons and protons. The electron thermal velocity was v_{Te} = 0.06 c, where c is the speed of light. In all models, 160 electrons and 160 protons per cube grid were used. The electron plasma frequency was ω_{pe} = 0.05(Δt)^{1} (Δt = 1 is the time step) and the electron Debye length was λ_{D} = v_{Te}/ω_{pe} = 0.6Δ. The electron and proton skindepths were λ_{ce} = c/ω_{pe} = 10Δ and λ_{cp} = c/ω_{pp} = 40Δ (where ω_{pp} is the proton plasma frequency), respectively.
We then included a monoenergetic beam that was homogeneous throughout the numerical box. To keep the total current zero in these models in their initial states, we introduced an initial return current by shifting the background plasma electrons in the velocity space according to the relation v_{d} = −v_{b}n_{b}/n_{e}, where v_{b} is the velocity of the electron beam, and n_{b} and n_{e} are the beam and background plasma densities; for an example of this type of initialization, see Niemiec et al. (2008). In principle, it is possible to start from a zero initial return current. However, owing to inductive effects included in the used 3D electromagnetic code, the current starts to oscillate at the electron plasma frequency with the amplitude of the stabilizing return current. Therefore in these simulations, we recommend starting from an already stabilized return current (Nishikawa 2008). Although these current oscillations can influence the studied acceleration, for simplification, we did not take this effect into account. We similarly neglected any effects of the returncurrent formation (electrostatic ones) on the front of the propagating beams.
Model parameters and the fraction (FR) of the beam energy in the electrons with energies greater than the initialbeam electron energy.
The beam velocity was chosen to be v_{b}/c = 0.666 in the z direction. The ratio of the beam to the plasma densities was chosen to show the details of the acceleration process n_{b}/n_{e} = 1/8, which is a rather high value (however still realistic). The lower values of n_{b}/n_{e} = 1/40, see Table 1, for comparison, were used in models G and H.
To investigate the influence of the magnetic field in the models, we consider several values of the background magnetic field, so that the ratio of the electroncyclotron to electronplasma frequencies (ω_{ce}/ω_{pe}) is 0.0, 0.1, 0.5, 0.7, 1.0, and 1.3 (see Table 1). In all models, the periodic boundary conditions were used.
3. Results of numerical simulations
Using the above described model, we performed eight runs (AH) using the parameters given in Table 1. As an example (see Fig. 1), a time evolution of the electron velocity distribution for model E is shown at four different times: the initial state (a), ω_{pe}t = 40 (b), ω_{pe}t = 140 (c), and ω_{pe}t = 200 (d). Crosses correspond to f(v_{z}), and dotted and dashed lines display f(v_{x}) and f(v_{y}), respectively. The vertical line in the initial state at v/c = 0.666 denotes the monoenergetic electron beam. As can be seen here, a plateau forms in the velocity space between the velocity of the initial beam and that of the background plasma electrons. It is produced by the socalled quasilinear relaxation, in which the electron beam generates the Langmuir waves (see Fig. 2). The Langmuir waves were initially generated at the kwave vector corresponding to the resonance condition for the beamplasma instability, i.e. at ω = k_{z}v_{b} (see the peak in the Langmuir wave energyspectrum in Fig. 2a), where ω is the frequency of the Langmuir waves and v_{b} is the electron beam velocity (Mikhailovskii 1975). These Langmuir waves then decay and merge mainly in accordance with the three wave interactions (for details, see e.g. Bárta & Karlický 2000) and evolve in the kvector space (see the enhanced Langmuir wave spectrum in Figs. 2b − d). The Langmuir waves, on the other hand, scatter the beam electrons and heat the background plasma. During this process, the plateau in the electron distribution function f(v_{z}) is formed (see detailed discussion of the quasilinear relaxation in the following section). However, during this process some beam electrons, owing to an interaction with the Langmuir waves, obtain an energy that is higher than the electron energy in the initial beam. This is shown in Fig. 3, where a time evolution of the electron energy distributions for model E at four different times is presented: at (a) ω_{pe}t = 40 (b) ω_{pe}t = 60, (c) ω_{pe}t = 140, and (d) ω_{pe}t = 200. For comparison, we show in each panel in this figure the initial electronplasma distribution together with the initial monoenergetic beam (dashed lines). Here, it can clearly be seen that some electrons have the energies higher than those of the initial beam.
Although in the initial state, we started from a uniform background plasma, very soon (owing to the dense beam) strong density fluctuations appeared (see Fig. 5). During the evolution, their characteristic lengths became longer (compare Figs. 5a and 5b). In the early stages of evolution, the associated electric field densities are not correlated with the density fluctuations. On the other hand, in the later stages of evolution, e.g., at ω_{pe}t = 190 it can be seen that the electric fields (Langmuir waves) start to be trapped in density depressions (see e.g. the electric field densities at z, equal to 300Δ and 430Δ respectively).
To investigate the energetics of the accelerated electrons, we computed their energy (expressed in fraction of the initial beam energy) above some selected energy levels. The time evolution of these fractions for the energies higher than E/mc^{2} = 0.25 and E/mc^{2} = 0.3, for model E are shown in Fig. 6. The initial energy of the beam electron was E/mc^{2} = 0.22178. In this figure, for comparison the time evolution of the maximum energy of the electron (E/mc^{2}) is plotted. The fractions firstly increase in time, owing to the some time taken for acceleration of these electrons to the selected energy levels. The fractions then slowly decrease to some saturation level, in agreement with the saturation of the quasilinear relaxation process. The fractions generally decrease with the increase in the energy interval between the beam energy and selected energy level. We also computed the fractions of these accelerated electrons for the energy levels just above the beam energy. For all computational models (AH) at the time ω_{pe}t = 200, these fractions are summarized as percentages in the last column of Table 1. These fractions increase as the magnetic field increase, e.g. from FR = 10% for ω_{ce}/ω_{pe} = 0 (model A) to FR = 29% for ω_{ce}/ω_{pe} = 1 (model E). For even greater values of ω_{ce}/ω_{pe}, the fractions start to decrease (see FR = 27% for ω_{ce}/ω_{pe} = 1.3 in model F). Similar results were found for models G and H, where we considered a beam density lower than in models AF (see Table 1). As shown and analyzed in the papers of Karlický & Bárta (2009) and Karlický & Kašparová (2009) for the models with weak magnetic fields (models AB), the Weibel instability is significant and strongly influences the resulting electron distribution function. On the other hand, the strong magnetic field (e.g. model E) reduces the role of the Weibel instability (see also the discussion and Fig. 8).
As an illustration, we present in Fig. 4 the electron energy distributions at ω_{pe}t = 200 for all runs, i.e. for ω_{ce}/ω_{pe} = 0.0, 0.1, 0.5, 0.7, 1.0, and 1.3, respectively (models AF, Table 1). The number of electrons accelerated above the initial electronbeam energy (expressed by the vertical dashed line) corresponds to the fractions FR in Table 1.
4. Quasilinear relaxation – analytical estimates
While the analytical treatment of a 3D nonlinear beamplasma system is impossible, the efficiency of acceleration can be estimated in the quasilinear limit. In this limit, the evolution of energetic electrons is described by two coupled kinetic equations (Vedenov & Velikhov 1963; Vedenov et al. 1967; Tsytovich 1995). For a weakly magnetized plasma, when the field is strong enough to provide onedimensional electron dynamics, the electron beam evolution can be described using standard quasilinear theory (1)(2)where f(v,t) is the electron distribution function, W_{k} is the spectral energy density of the Langmuir waves, ω_{pe} is an electron plasma density, and e and m are the electron charge and mass. The equations describe the resonance (ω_{pe} = kv) interaction of the electron beam with the surrounding plasma via the generation of plasma waves and include plasma inhomogeneity effects (see, e.g. Vedenov et al. 1967; Ryutov 1969; Kontar & Pécseli 2002).
When the plasma is uniform , the stationary solution for the initially unstable beam distribution f(v,t = 0) = g_{0}(v), v < v_{b} of the coupled quasilinear equations is wellknown (Vedenov & Velikhov 1963). The electron distribution function has the form of a plateau (3)and the spectral energy density of plasma waves W_{k} can be found from Eqs. (1), (2) using Eq. (3) (4)thus the spectral energy density becomes (5)for g_{0}(v) = n_{b}δ(v − v_{b}) and takes the form (6)for , v < v_{b}, (see Kontar 2001, for details). The total energy density of plasma waves from Eq. (5) is and for the second case given by Eq. (6).
However, when the plasma has a positive density gradient , which corresponds to electrons propagating into the region of higher density (as in the standard flare scenario), the Langmuir waves slowly evolve towards larger phase velocities or smaller wavenumbers k. As Langmuir wave packets propagate within the plasma, the total energy of the wave packet ω(k,x) must be constant (Vedenov et al. 1967), which requires that the wavenumber change be negative for a positive plasmadensity gradient, such that (7)Therefore, the motion of Langmuir wave over the time range Δt results in a decrease in the wavenumber from k to . The waves shifted to higher v (smaller k) can be effectively reabsorbed by the beam, which leads to an acceleration of the electrons and the formation of an extended plateau above v > v_{b}. Using the conservation of energy, and assuming that all Langmuir waves are reabsorbed by the beam owing to the plasma inhomogeneity, W(k = ω/v,t → ∞) = 0, one finds that for the energy (8)the electron distribution has electrons with velocity v > v_{b}(9)where the new maximum velocity is from Eq. (8) (10)Numerical solutions of Eqs. (1) and (2) (see Kontar 2001, for details) show that the value of the density gradient mostly affects the rate of the extended plateau formation and that the final state of the initially unstable distribution , v < v_{b}, gives . In the case of g_{0}(v) = n_{b}δ(v − v_{b}), one finds that .
Fig. 5 Normalized plasma density (solid line) and the electric field density (dashed line) in the zdirection along the line with x = y = 22Δ for model E at two times: ω_{pe}t = 60 a) and ω_{pe}t = 190 b). The electric field density is expressed in arbitrary units, but the electric field density at b) is multiplied by a factor of 50.
Fig. 6 Fractions of the beam energy in electrons with energies greater than E/mc^{2} = 0.25 (dashed line) and greater than E/mc^{2} = 0.3 (dotted line), for model E. The initial energy of the beam electron is E/mc^{2} = 0.22. For comparison, we plot the time evolution of the maximum energy of the electron (solid line).
Fig. 7 The Xray spectrum for model E at ω_{pe}t = 200 (solid line) and the initial state (dashed line).
In the case of nonlinear interactions and various density fluctuations, the energy exchange between the electrons and plasma waves becomes more complicated. Kontar et al. (2012) used numerical simulations to estimate the role of these effects. Here, assuming that smallscale density fluctuations in the plasma generated during the beamplasma instability are random with zero mean, the evolution of Langmuir waves in plasma can be approximated as a symmetric diffusion in kspace (see Eq. (14) in Kontar et al. 2012). This leads to equal numbers of plasma waves spreading towards smaller and larger the phase velocities. The former waves will be Landauabsorbed by the thermal plasma, while the latter will be absorbed by the beam resulting in electron acceleration in the tail of distribution. Therefore, for the Langmuir wave spectrum flattened in kspace, (see Fig. 2), these simplistic arguments suggest that only half of the Langmuir wave energy given by Eqs. (5) and (6) will be reabsorbed back. The maximum velocity then becomes and the energy of the electrons with v > v_{b} becomes (11)for g_{0}(v) = n_{b}δ(v − v_{b}). We note that these estimates are rather close to the numbers inferred from the 3D PIC simulations presented in Table 1. It is worth noting that the collisional relaxation of the electron powerlaw spectrum, which is initially stable was considered by Kontar et al. (2012), while in this paper we treat a “classical” case of beamplasma instability.
5. Discussion and conclusions
We have performed a number of 3D PIC simulations of the beamplasma instability with monoenergetic beams and have shown that during relaxation a population of electrons with velocities exceeding those of the injected electrons appears. The energy of these electrons is around 10–30% of the initial beam energy.
Using PIC simulations, it is difficult to predict the longterm time evolution of these processes in solar flares. However, as shown in Fig. 7 this effect is indicated by the highenergy limit of the Xray spectrum, namely that the accelerated highenergy electrons shift the Xray spectrum to higher energies. This result together with the radio diagnostics can be used for an estimation of these acceleration processes. For example, if we take the dmspikes as a radio signature of the acceleration process in solar flares (Guedel et al. 1991), then the advanced theory of these bursts can be used to estimate the electron distribution function at the acceleration site. Comparing this function with that determined from the hard Xray spectrum at the flare footpoints, the acceleration efficiency can then be estimated.
We have found that the increasing magnetic field strength leads to a larger fraction of accelerated electrons. Therefore, we decided to compare the electron distribution functions of the cases with and without a magnetic field (in models A and E, Fig. 8). As presented and analyzed in Karlický & Bárta (2009) and Karlický & Kašparová (2009), the main difference in both cases is caused by the Weibel instability. In model E, the Weibel instability is reduced, while in model A (without the magnetic field) the Weibel instability transfers the beam energy to a heating of mainly perpendicular components of the background plasma. Thus, in the case without the magnetic field, not only the bumpontail instability but also the Weibel instability operates and less energy (than in model E) is transferred to the Langmuir waves, leading to a weaker acceleration.
Fig. 8 Comparison of the electron distribution functions in model A (without the magnetic field) and model E (ω_{ce}/ω_{pe} = 1.0). Crosses correspond to f(v_{z}) and dashed lines display overlapping f(v_{x}) and f(v_{y}).
We considered two values of the ratio of the beam to background plasma densities n_{b}/n_{e} = 1/8 and 1/40, which imply that the returncurrent electron speeds are v_{d} = 0.083 c and v_{d} = 0.016 c (where c is the speed of light), respectively. This corresponds to two regimes of the returncurrent electron speed either greater or lower than the thermal plasma velocity, which is in our model v_{Te} = 0.06 c. In both cases, the percentage of the energy in accelerated electrons is similar. The case where n_{b}/n_{e} = 1/8, i.e. the case with the drift speed greater than the initial thermal velocity, should be unstable for the Buneman instability. However, the time of evolution considered in the present study is shorter than the time required to develop such an instability. For much longer term evolutions of similar systems in this regime computed with a 1D Vlasov code, the formation of weak double layers was found and proposed as an explanation of broken powerlaw Xray spectra in solar flares by Lee et al. (2008) (see also Karlický 2012).
We note that the size of our numerical box (45Δ × 45Δ × 600Δ) is limited by the memory and speed limits of our computer. The limited number of spatial grids limits a number of grids in the kvector space. This limitation can influence the wavewave and waveparticle interactions in this acceleration process. This is especially important in the linear regime of these interactions, which would correspond here to the cases with low density beams. However, in the present study we considered very dense beams (n_{b}/n_{e} = 1/8 and 1/40), which generate strong density fluctuations ensuring that these interactions are far from linear regimes (We note that in the interpretation of the hard Xray emission the dense electron beams are often required). We made additional tests for model E. We used the same parameters as in model E, but we varied the size of the numerical system. We obtained similar results. For the system size (20Δ × 20Δ × 1500Δ) at the time ω_{pe}t = 200, the fraction FR is 26% and for the size (10Δ × 10Δ × 3000Δ) at the same time the fraction FR = 25%; compare with the fraction FR = 29% for model E in Table 1. Nevertheless, to make these results more precise we plan to repeat these computations in larger numerical boxes on a more powerful computer.
Comparing the numerical and analytical treatment, we propose that for this type of acceleration the density fluctuations and nonlinear wavewave interactions are essential. While in a strictly uniform plasma this acceleration is impossible (see the analytical estimations), in real conditions with sufficiently dense electron beams some beam electrons are accelerated to energies greater than the initial ones via nonlinear wave interactions and density fluctuations.
In solar flares, high nonthermal electron fluxes are often required to explain the observed Xray emission, which provide the suitable conditions for fast beamplasma instability. As we have shown, the beamplasma instability generates the Langmuir wave turbulence. The acceleration of electrons occurs owing to the kspace evolution of Langmuir waves, in which not only the Langmuir waves with phase velocities smaller than the initial beam velocity are generated (as in the case of beam relaxation in uniform plasma) but also those with higher phase velocities. The process of electron acceleration is fast, and occurs on a timescale much shorter than the electron transport time from an acceleration site to the dense chromospheric region. We therefore expect that during these processes the tail of the distribution extends towards higher energies. The number of highenergy electrons above some energy level increases and thus influences the hard Xray spectrum. However, the total number of beam electrons is conserved and the process only redistributes the beam energy. These results emphasize that the transport of electrons should not be treated using a single particle description, and that the collective effects produce not only energy loss, but an effective acceleration of electrons. The analysis of a hard Xray spectrum assuming only collisional losses could therefore infer that a larger number of electrons than actually is initially accelerated owing to the additional inflight acceleration.
Acknowledgments
The authors thank the anonymous referee for comments that improved the paper. All computations were performed on the parallel computer OCAS (Ondřejov Cluster for Astrophysical Simulations, see http://wave.asu.cas.cz/ocas). This research was supported by the grant P209/12/0103 (GA CR). Financial support by the STFC rolling grant (E.P.K.), the Leverhulme Trust (E.P.K.), and the European Commission through the HESPE (FP7SPACE2010263086) (E.P.K.) and “Radiosun” (PEOPLE2011IRSES295272) Networks (M.K., E.P.K.) is gratefully acknowledged.
