The Sunyaev-Zel’dovich (SZ) effect (Sunyaev & Zeldovich 1972) is the inverse Compton energisation of cosmic microwave background (CMB) photons that cross the hot plasma in clusters of galaxies. The same effect is expected in other astrophysical environments, such as the jets and lobes of giant radio-galaxies (see e.g. Colafrancesco et al. 2008).

The SZ effect is a powerful tool for studying the physics of clusters and for using them as cosmological probes (see e.g. Birkinshaw 1999; Carlstrom et al. 2002; Rephaeli et al. 2006).

Large mm-wave telescopes (Carlstrom et al. 2011; Swetz et al. 2011; Schwan et al. 2010), coupled to imaging multi-band arrays of bolometers, are now operating in excellent sites and produce a number of detections and maps of the SZ effect, discover new clusters, and establish cluster and cosmological parameters.

Meanwhile, the Planck space mission (Planck collaboration 2011a) has recently produced a shallow whole-sky survey in nine cm to submm bands, from which an early catalogue of massive clusters detected via the SZ effect has been extracted (Planck collaboration 2011b). The Early-SZ catalogue consists of 169 known clusters, plus 20 new discoveries, including exceptional members (Planck collaboration 2011c).

All these measurements take advantage of the extreme sensitivity of bolometers, with their excellent performance in the frequency range 90–600 GHz where the spectral signatures of the SZ effect lie.

Because all measurements integrate signals along the line of sight (LOS), we summarize below the dependence of the LOS signal on the physical parameters of the cluster. Several components should be considered:

• a)

  A thermal component. In the non-relativistic approximation forthe cluster plasma, the change of the CMB brightness I in a LOS crossing the cluster is (see e.g. Birkinshaw 1999) (1)where I_CMB is the brightness of the CMB, x = hν/kT and (2)which is proportional to the integral of the pressure along the LOS. For rich clusters the optical depth is τ_t = ^∫_LOSn_eσ_Tdℓ ≲ 0.01 and the average energy boost of CMB photons is ΔE/E ~ kT_e/m_ec² ≲ 1%, so that a ΔT/T ≲ 10^-4 is expected. This is reasonably large with respect to the intrinsic CMB anisotropy, and has a characteristic spectrum, with a decrement of CMB brightness at ν ≲ 218   GHz and an increment of CMB brightness at ν ≳ 218   GHz. This peculiar spectrum is the key to distinguish the thermal SZ effect from competing contributions (see below). Relativistic corrections have also been computed for improved precision (see e.g. Itoh et al. 1998) and are used to characterize the physical parameters of the cluster atmospheres (see e.g. Colafrancesco et al. 2011).

• b)

  A Doppler component, caused by the collective motion of the cluster with velocity v in the CMB restframe. The spectrum of this effect is the same as the spectrum of the intrinsic CMB anisotropy, so that the two contributions cannot be separated. The amplitude of the signal is (3)where v_LOS is the projection of v along the LOS; so we get (4)

• c)

  A non-thermal component ΔI_nt, caused by a non-thermal population of electrons, produced by e.g. the AGNs present in the cluster, relativistic plasma in cluster cavities, shock acceleration. If dark matter in galaxy clusters consisted of neutralinos, their annihilation would produce high-energy charged particles as well. For a review, see e.g., Colafrancesco (2010), and references therein. The inverse-Compton spectrum of this component is very different from that of the thermal component, because the energy of CMB photons is boosted to frequencies much higher than the submm frequencies observable with CMB instruments (see Colafrancesco 2008, for details). This component is normally sub-dominant with respect to the thermal component: its optical depth τ_nt is at least 50 times less than τ_t. The parameters characterizing the spectrum, in addition to the optical depth, are the spectral index of the power-law spectrum of the energy of the electrons α (typically around –2.7), and their minimum momentum p₁, typically of the order of a few MeV/c.

• d)

  Additional sources of signal along the same line of sight are the intrinsic anisotropy of the CMB (see point b) above) (5)Since components b) and d) have exactly the same spectrum, we will describe them in the following with the parameter ΔI_CMB = ΔI_CMBi + ΔI_v (or the equivalent ΔT_CMB), which is the sum of the intrinsic anisotropy of the CMB and of the kinetic SZ effect along the line of sight.

• e)

  The emission of dust ΔI_d in our Galaxy and in the galaxies of the cluster. This is modelled as a thermal spectrum with temperature T_d ~ 20   K and a spectral index of emissivity  ~−1.5, or a superposition of several components with different T_d. It is important as a contaminant at frequencies where the thermal SZ is positive.

• f)

  The free-free and synchrotron emission (ΔI_ff, ΔI_sy) from the diffuse medium in our Galaxy and from the galaxies in the cluster: this component can be important at low frequencies, where the SZ is negative.

According to these considerations it follows that SZ measurements promise to estimate several physical parameters of the cluster on the line of sight, provided there are more observation bands than parameters to be determined, or some of the contributions are known to be negligible.

Multi-frequency measurements are therefore mandatory to separate the contributions of the different physical components, taking advantage of the characteristic spectrum of the SZ effect, which significantly departs from the spectra of the foreground and background components (see Fig. 1). The wider and more detailed the frequency coverage of the observations, the more effective the separation of the different components.

The recent results of Planck (Planck collaboration 2011b), for example, have been obtained by exploiting the excellent frequency coverage of the mission and sophisticated component separation techniques (see e.g. Leach et al. 2008).

In this paper we study how effective the various experimental configurations are in separating all the different physical components and in providing unbiased estimates of the cluster parameters (like y, v, T_e, τ_t, τ_nt, p₁ ...) and of the other parameters that describe the signals along the same line of sight (T_d, τ_d, I_s, I_ff, ΔI_CMBi, ...).

Evidently, ground-based few-band photometers cannot provide enough information to separate all physical components. Observations are hampered at high frequencies (≳200   GHz) by atmospheric noise (see Fig. 1): this significantly limits the coverage of the positive part of the thermal SZ spectrum, and makes the removal of parameter degeneracies much more difficult. These instruments need external information (optical, X-ray, far-IR, etc.) to produce mainly measurements of τ_t. With the addition of external data, these experiments provide invaluable information in the current exploration phase: a large database of clusters is being built, and new cluster candidates have been discovered (see e.g. Hincks et al. 2010; Marriage et al. 2010; Brodwin et al. 2011; Hand et al. 2011; Sehgal et al. 2011; Foley et al. 2011; Story et al. 2011; Williamson et al. 2011).

In principle, future space-based spectrometers can cover the full range of interesting frequencies and offer much more information: with these machines it should be possible to measure the parameters of a cluster, and use external information, when available, as a cross-check. Also, other important scientific targets of these instruments are the measurement of the C⁺ and CO lines in the redshift desert and beyond for a large number of galaxies (see e.g. de Bernardis et al. 2010; Gong et al. 2012).

The main purpose of this paper is to analyse quantitatively and compare the performance of these different configurations for SZ measurements.

As samples of experimental configurations we considered a ground-based 4-band photometer; a 4-band photometer and a 4-band differential spectrometer (both suitable for balloon-borne observations, and similar to the configuration of the OLIMPO experiment – see Masi et al. 2008; Conversi et al. 2010), Planck HFI (Planck HFI Core Team 2011), and a full-coverage differential spectrometer suitable for a future, dedicated space mission, like SAGACE (de Bernardis et al. 2010) or Millimetron (http://www.sron.rug.nl/millimetron).

In Sect. 2 we describe and compare the considered configurations; in Sect. 3 we describe the simulations and the analysis method; in Sect. 4 we discuss the results.

2. Experimental configurations

All instruments considered here work at the diffraction limit, with AΩ = λ², to achieve the best possible angular resolution, which is needed to resolve the target cluster.

We limited our analysis to experiments using arrays of bolometers because of their superior mapping speed. Having maps of a sky patch surrounding the cluster is important to identify foreground structures and the internal structure of the cluster, if the resolution is sufficient. This choice limits the frequency coverage to ν ≳ 70   GHz, where bolometer arrays have a significant sensitivity advantage with respect to coherent detectors.

Few-band photometers have been traditionally matched to the mm/submm atmospheric windows, i.e. the frequency bands W1 =  [75−115]  GHz, W2 =  [125−175]  GHz, W3 =  [190−315]  GHz, W4 =  [330−365]  GHz, W5 =  [390−420]  GHz. Operation in the higher frequency windows is significantly hampered by atmospheric noise and poor transmission, which strongly depends on the telescope site. In general ground-based photometers use narrower bands within the ranges above, while balloon-borne multi-band photometers can have wider bands and can use the higher frequency bands efficiently. Satellite instruments do not have these limitations, and the operation bands are selected based on the necessity to calibrate the instrument and to study the Galactic and extragalactic contaminating foregrounds (like the CO lines, and the continuum from interstellar dust, free-free and synchrotron emission).

For our spectroscopy we considered a Fourier Transform Spectrometer (FTS) because, at variance with dispersion spectrometers (see e.g. Bradford et al. 2003), this instrument is intrinsically imaging, a crucial requirement for studying appropriately the SZ effect in cosmic structures. Moreover, at variance with Fabry-Perot spectrometers (see e.g. Benford et al. 2003) the FTS can be used in a differential configuration where a sky field is compared to an internal reference blackbody (as in the COBE-FIRAS instrument, Mather et al. 1993; or in the Herschel-SPIRE, Griffin et al. 2007), and also in a differential configuration where two sky-fields are compared, thus rejecting most of the common mode signal from the instrument, the atmosphere, the foregrounds, and the CMB (see e.g. de Bernardis et al. 2010).

Experimental Configuration 0 (EC0) is a ground-based 4-band photometer that measures the bands W1, W2, and the two halves of W3 ([200–240] GHz and [240–310] GHz) in an excellent site like the Atacama desert, South Pole, or Dome-C. We assumed 2.7%, 2.5%, 3.5%, 5.0% average emissivity for the atmosphere, respectively, in the 4 bands above (corresponding to a precipitable water vapor  ~0.5 mm), and an equivalent temperature of the atmosphere of 240 K. Only photon noise was considered, assuming that the telescope is used in a differential configuration, where most of the turbulence is subtracted out as a common mode signal.

Experimental Configuration 1 (EC1) is a balloon-borne 4-band photometer that measures bands W2, W3, W4, and W5. Here the background is limited by the temperature (~230 K) and emissivity of the telescope mirrors and of the cryostat window. Again a differential configuration was considered.

Experimental Configuration 2 (EC2) is a balloon-borne 4-band differential spectrometer that measures the low-resolution (Δν = 6 GHz) spectra in four ranges coincident with W2, W3, W4, and W5. Here the background is limited by the temperature and emissivity of the telescope, of the interferometer mirrors, and of the cryostat window, all at room temperature (230 K). Note that in this (and in the following) photon-noise limited configurations, that use Fourier transform spectrometers, the error on each spectral bin scales as the inverse of the spectral resolution Δν (see Sect. 3).

Experimental Configuration 3 (EC3) is an Earth-orbit (EO) satellite with a telescope radiatively cooled at 80 K, which measures spectra in four consecutive ranges b0 = [100, 200] GHz, b1 = [201, 350] GHz, b2 = [351, 500] GHz, b3 = [501, 600] GHz with 6 GHz resolution. Here the background is limited by the temperature and emissivity of the cold telescope and of the cryostat window (total emissivity ϵ ~ 0.01), while the interferometer mirrors are kept at  <4 K and do not contribute to the photon noise. The spectral coverage has been divided in the four ranges observed simultaneously by independent detector arrays in order to limit the radiative background on each array.

Experimental Configuration 4 (EC4) is a 6-band photometer similar to Planck-HFI, which operates in the Lagrangian point L2 of the Sun-Earth system, with the telescope radiatively cooled at 45 K, measuring simultaneously in the bands b0 = [83.5, 116.5] GHz, b1 = [119.4, 166.6] GHz, b2 = [181.2, 252.8] GHz, b3 = [303.6, 402.4] GHz, b4 = [460.5, 629.5] GHz, b5 = [728.5, 985.6] GHz. Here the background is limited by the temperature and emissivity of the cold telescope (total emissivity ϵ ~ 0.005).

Experimental Configuration 5 (EC5) is a 4-range differential interferometer that operates in deep space (L2), with an actively cooled telescope (T ≲ 6   K), in the bands b0 = [100, 200] GHz, b1 = [201, 400] GHz, b2 = [401, 600] GHz, b3 = [601, 800] GHz with 6 GHz resolution. Here the background is limited by natural radiation sources (Galactic, extragalactic, CMB): this allows a wider coverage (including high frequencies) without the risk of a high background on the detectors.

For a summary see Fig. 1, where the coverage of the different configurations is compared to the SZ and foreground spectra.

3. Simulation of line-of-sight observations

In order to evaluate the performance of different experimental configurations, we have considered the following benchmark situation: the observation of a line of sight that crosses a rich cluster of galaxies, with τ_t = 0.005, T_e = 5   keV, ΔT_CMB = 22   μK (corresponding to v = 480   km   s^-1, if the intrinsic anisotropy of the CMB along the line of sight is negligible), τ_nt = 0.0001, α = −2.7, p₁ = 2.75 × 511   keV/c).

We assumed that the angular resolution of all channels of all experimental configurations is sufficient to resolve the source. Otherwise we would have needed to take into account dilution and shape factors: in this LOS approach we avoided these complications. We believe that this approach is adequate for the purpose of this paper, which is to compare the performance of different experimental configurations.

The integration time on the same line of sight is assumed to be 3 h for all cases but EC4. For EC4 (a space-borne whole-sky survey à-la-Planck) the integration time on the considered sky pixel is 30 s.

The signal power on the detectors was computed as (6)where A is the collecting area, Ω is the solid angle sampled by each detector, E(ν) is the efficiency of the detection system, ϵ_m(ν) is the total emissivity of the optical system at room temperature and of the atmosphere in the measurement band.

We have neglected ΔI_ff and ΔI_sy because they are negligible with respect to ΔI_d in the frequency range and for the observations at high galactic latitudes of interest here. We modelled typical Galactic cirrus anisotropy at the angular scale of a cluster (a few arcmin) as ΔI_d(ν) = A(ν/ν_o)⁴ with A = 600   Jy/sr and ν_o = 150   GHz: a value typical of very clean high-latitude regions (see e.g. Masi et al. 2006).

We assumed that the detector array is optimized to be limited by the photon noise of the radiative background that is produced by the instrument and the atmosphere (if present). Cryogenic bolometers reach this performance level even in the extremely low background achievable in space, if properly designed (see e.g. Holmes et al. 2008).

The background power on the detectors was computed as (7)where x_m = hν/kT_m, T_m is the temperature of the optical system and of the atmosphere, x = hν/kT, T is the temperature of the cosmic microwave background.

The fluctuations of the background were computed as For the photometric measurements we integrated Eqs. (6) and (8) over the detection bandwidth BW to obtain the error on the signal for each band: (11)where t is the total integration time.

In the case of spectroscopic measurements, the error on the measurement of each spectral bin was computed as follows. In the FTS the input power is splitted in the two arms of the interferometer, and a variable delay is introduced in one of the two beams, before recombining them on the detector. The variable delay is introduced by a moving mirror, which can be offset by x with respect to the corresponding steady mirror in the other arm of the interferometer. In this way a 2cx delay is introduced. The power measured in position x of the moving mirror is P(x) (the interferogram), and the spectrum is estimated as the Fourier transform of the interferogram: (12)where σ is the wavenumber (in cm^-1). The spectral resolution of the measurement is (13)(see e.g. Chantry 1971). In a real instrument the interferogram is sampled at the positions x_i = iΔx, (i = 1...N), with N = x_max/Δx. The integral is then estimated as a discrete sum (14)Since each sample of the interferogram has an integration time T/N, and photons from the whole observed frequency bandwidth contribute to the noise, the error in the measurement is therefore (15)The error in the measurement of each spectral bin is thus (16)or (17)For each experimental configuration (EC*) we simulated 3000 measurements, using Eq. (6), and adding an error term extracted from a Gaussian distribution with zero average and standard deviation derived from Eqs. (11) and (17).

Typical simulated spectral measurements are reported in Fig. 2.

4. Results and discussion

We fitted each simulated measurement using Eq. (6). In Table 1 we report the averages of the best-fit parameters with their standard deviation.

While giving a general idea of the relative efficiency of the different configurations, the results reported in Table 1 can be misleading in the details, since the distributions of the best-fit parameters are not Gaussian (nor symmetrical), and there are significant correlations between the parameters. This is evident from the joint likelihood contours plotted in Figs. 3, 5–7, 9–11.

For EC0 (4-band ground-based photometer), where only four independent data-sets are available for each measurement, we tried to fit either three parameters (τ_t, T, ΔI_d) or four parameters (τ_t, T_e, ΔI_d and ΔT_CMB), adding a fictitious data point with zero brightness at zero frequency. The results are dominated by the degeneracy between T_e and τ_t, evident from Eqs. (1) and (2): without relativistic corrections, the thermal SZ depends on the product of electron density and electron temperature. For this reason a decrease of, say, a factor 2 of τ_t is almost perfectly compensated for by an increase of a factor 2 of T_e. The only way to break the degeneracy is through the relativistic corrections, which, however, are very small: their effect is negligible with respect to the typical uncertainties of ground-based measurements. For this reason we had to use a prior on T_e, assuming that the information is obtained through independent X-ray measurements of the specific brightness of the cluster along the same line of sight. We tried a very weak prior, with a Gaussian distribution centred on the true value and a standard deviation of 8 keV: otherwise the best fit would converge to non-physical values for T_e. The bias is only mitigated by the introduction of this prior. In the 3-parameter case the best fits converge on values of the parameters that are not very close (in units of their standard deviation) to the input values, and the typical χ² is high, confirming that the effect of the measurement error is negligible with respect to the effect of the parameter degeneracies and to the necessity of neglecting the non-thermal component in the fit.

In Fig. 3 we plot the joint likelihood contours for couples of parameters in the 3-parameter fits. The comparison with Fig. 5 shows that part but not all of the bias depends on the presence of the non-thermal component: indeed the bias changes with τ_nt = 0, but is still present.

If a 4-parameter fit is used, the bias is significantly reduced, and does not depend anymore on the presence of the non-thermal component. However, this comes at the cost of wider confidence areas, as evident from Fig. 6.

The contamination of dust is significant and degenerates to some extent also with ΔT_CMB: in the 3-parameter fit, where ΔT_CMB is not fitted, the best-fit for ΔI_d is far from the input value, and this probably contributes to the tension between the best-fit value of T_e and its input value. We believe that this is the result of a degeneracy of parameters combined with the poor coverage of high frequencies in ground-based experiments. In the 4-parameter fits the χ² improves, but the best fits are still biased, and only with the 3 keV prior the estimates of all parameters are consistent with the input values (see Fig. 6).

For EC1 (4-bands balloon-borne photometer) the coverage of frequencies higher than 300 GHz helps in removing the degeneracy (see Fig. 7). If we use the very weak prior on T_e (Gaussian with standard deviation 8 keV), the best-fit cluster parameters are already close to the input values, even if the error (completely dominated by the degeneracy) is relatively large. The situation improves, of course, if the standard deviation on the prior is reduced to 3 keV. ΔT_CMB is better constrained, but is biased low. While performing significantly better than EC0, this configuration is limited by radiation noise in the high-frequency bands, which can be removed only by cooling the telescope or/and adding spectroscopic capabilities (see below).

In Fig. 8 we plot the histograms of the best-fit T_e × τ_t normalized to the input of the simulation. It is evident how the bias is reduced passing from EC0 with three parameters to EC0 with four parameters to EC1, which shows how important the coverage of high frequencies is, which are difficult to observe from the ground.

For EC4, where six independent data-sets are available for each measurement, we tried to fit four parameters (τ_t, T_e, ΔI_d and ΔT_CMB, see Fig. 9 ) and also six parameters (including τ_nt and p₁, see Fig. 10), always adding the fictitious zero frequency zero brightness data point. The good coverage of high frequencies and low photon noise owing to the low radiative background results in very good performance in terms of statistical errors. Again, the presence of the non-thermal component produces a bias in the determination of the other parameters for the 4-parameter fit. In the 6-parameter fits, the non thermal parameters are basically not constrained (with a bimodal distribution of the best fit p₁), but the other parameters are well constrained and unbiased. The effects of parameters degeneracies are still evident, however, and it is difficult to estimate ΔT_CMB because it tends to be biased low in the 4-parameter fit, while is not well constrained in the 6-parameter fits (see also Table 1).

The space spectrometers EC2, EC3, and EC5, featuring wide frequency coverage and low radiative background noise, perform better, and allow an unbiased recovery of six parameters with increasing accuracy. If we compare the parameter space volume constrained by the different configurations, we find that with respect to EC2, EC3 reduces the volume by a factor 4.6, and EC5 by a factor 27 (with the 8 keV prior).

The balloon-borne warm spectrometer EC2 is still limited at high frequencies by radiative background fluctuations. For this reason ΔT_CMB is basically not constrained (see Fig. 11). However, the other parameters are unbiased and well constrained even with the very weak prior on T_e. An experiment like OLIMPO, which combines photometric measurements (as in EC1) and spectroscopic measurements (as EC2), performing both during the same flight, can use the first measurement to optimally constrain ΔI_d and ΔT_CMB, and the second to better constrain τ_t and T_e. Note that even τ_nt is close to be detected (and can be detected with an integration time longer than the 3 h considered here) and p₁ is also constrained (still with a bimodal distribution). Finally note that the spectroscopic capabilities allow the user to remove the contamination of Galactic CO and other cooling lines within the photometric bands unambiguously.

The low-Earth-orbit case EC3 improves over the balloon spectrometer EC2. Cooling the spectrometer results in a significant unbiased measurement of all six parameters, including the elusive ΔT_CMB (see Fig. 12). Because the noise is reduced, the effect of degeneracies is more evident. The 3 keV prior is needed to fully exploit the potential of this configuration.

Experimental configuration EC5, where both the spectrometer and the telescope are cold, results in an improved precision of the determination of all parameters, and little sensitivity to the prior on T_e (see Fig. 13 and Table 1).

We have investigated the possibility of extending the frequency coverage of EC5 up to 1 THz. Keeping the same simplified model for dust, we found an improvement of about a factor 2 in the uncertainties of all parameters but ΔT_CMB (which does not improve) and ΔI_d (which improves by a factor 5). However, our simplistic model with a single dust population probably starts to be insufficient at these high frequencies. There are, however, other drivers to extend the frequency coverage of such an ambitious experiment as high as possible: the study of interstellar atoms and molecules and the study of galaxies in the redshift desert would benefit significantly from such an extension.

5. Conclusions

With this simulation-based study we confirmed that few-band photometric measurements of the SZ effect can be significantly biased, and that most of the bias is removed by adding bands and covering high frequencies (ν ≳ 240   GHz). This requires the use of space-borne experiments. Low-resolution spectroscopic measurements of the SZ are extremely promising. An exploratory experiment, featuring a four-band photometer on a balloon and a plug-in room-temperature FTS (configurations EC1 and EC2, modelled on the OLIMPO experiment Masi et al. 2008) is required to confirm that the expectations estimated here can really be achieved. In other words, we relied here on the differential properties of FTS instruments: we need to demonstrate experimentally that systematic effects are negligible even with the extreme requirements of SZ measurements. OLIMPO, in the dual photometric-spectroscopic configuration, is a perfect demonstrator, and is expected to produce exciting improvements on the physics of cosmic structures derived from the SZ effect. Satellite missions can accommodate a cryogenic FTS (a large cryostat is required anyway to provide the required hold time), reducing the instrumental background at high frequency. A Molniya-orbit mission (like the proposed SAGACE de Bernardis et al. 2010) represents a cost-effective solution, able to provide an extensive catalogue of unbiased SZ measurements in various cosmic structures (e.g. galaxy clusters and groups, radiogalaxy lobes, gaseous halos of galaxies). A cold telescope in L2 (like the proposed Spectrum-M – millimetron mission) would be limited only by the intrinsic degeneracy of the parameters, and would open new horizons in SZ science, allowing a precise determination of both the thermal and non-thermal components of the plasma in the cluster.

Acknowledgments

This work has been supported by Italian Space Agency contracts “Millimetron” and “OLIMPO” and by PRIN 2009 “Mm and submm spectroscopy for high-resolution studies of primeval galaxies and clusters of galaxies” of the Italian Ministero dell’Istruzione, dell’Università e della Ricerca. S.C. acknowledges support by the South African Research Chairs Initiative of the Department of Science and Technology and National Research Foundation and by the Square Kilometre Array (SKA).
