1. Introduction

Weak lensing is a powerful tool for probing the mass distribution of massive clusters of galaxies. By studying the distortion induced by the lens on images of extended background sources, weak lensing techniques have often been used to measure the masses of clusters of galaxies (see e.g. Lombardi et al. 2000; Clowe & Schneider 2002; Broadhurst et al. 2005; Clowe et al. 2006; Gavazzi et al. 2009). However, weak lensing suffers from a fundamental limitation set by the so-called mass-sheet degeneracy: the projected surface mass density map κ(θ) can be determined only up to transformations of the form $\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{}\mathrm{\to }{\mathit{\kappa }}^{\mathrm{\prime }}\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{=}\mathit{\lambda \kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{+}\mathrm{1}\mathrm{-}\mathit{\lambda }\mathit{.}$(1)In other words, weak lensing measurements alone are unable to constrain the total mass of a lens, unless further assumptions are made.

Although many strategies have been proposed to break this degeneracy, no definitive solution has been found so far. In principle, the mass-sheet degeneracy can be removed with the determination of the absolute value of κ at a single point in the lens plane where κ(θ) ≠ 1. One can assume that the surface mass density vanishes at the boundaries of the image, far from the lens, and that the average value of κ along the sides of the field of observation is zero. However, these assumptions require the field of view to be sufficiently large, which is not always possible. Moreover, current structure formation models predict that many clusters of galaxies have non-vanishing surface mass densities far from the lens center, so the first assumption is bound to lead to total mass estimates being significantly underestimated. Another possibility is to assume that the minimum value of κ is zero so that the mass density is everywhere positive, which might seem a plausible assumption. The problem with this approach is that noise can produce negative values of κ, and adjusting the overall density profile on the basis of a noise feature may not be wise. A popular solution is to fit weak lensing measurements to parametric model mass distributions, usually NFW (Navarro et al. 1997) profiles. This method has the disadvantage that it relies on an assumed mass profile for the lens, which might differ from that of the actual cluster, thus reducing the power of weak lensing as a mass measurement technique.

If we wish to find an assumption-free method to break the mass-sheet degeneracy, additional information must be added to the weak lensing measurements. Several attempts have been made in this direction. One possibility is to include magnification information in the data set because measurements of the magnification and of the shear field can lead to a direct determination of the surface mass density κ. Broadhurst et al. (1995) proposed a method based on the study of the number counts of faint background galaxies to help determine the magnification. Their technique was successfully used in a few cases of particularly massive clusters (Fort et al. 1997; Taylor et al. 1998; Broadhurst et al. 2005; Umetsu et al. 2011). However, for this method a detailed calibration of nontrivial model quantities, such as the number counts of unlensed sources, is essential. Moreover, the count process in the central regions of rich clusters is made difficult by bright cluster members that hide the faintest background galaxies.

The form of the invariance transformation given in Eq. (1) is referred to a fixed source redshift: the same transformation referred to a source at a different redshift changes by means of the coefficient that multiplies the term 1 − λ. In other words, each portion of the redshift space suffers from a different invariance transformation, so that in principle the mass-sheet degeneracy can also be broken by combining lensing information from images of sources at different known redshifts. Bradac˘ et al. (2004) investigated this possibility in the context of weak lensing, considering the hypothetical case in which the individual redshifts of the lensed background galaxies are available. They showed that, under these favorable circumstances, the mass-sheet degeneracy can be broken for critical clusters (i.e. those that can produce multiple images), but still not for subcritical ones.

A significant improvement can come from the addition of information from strongly lensed images (i.e. arcs or multiple images), provided that the redshifts of the strongly lensed sources differ from the mean redshift of the sources used for the weak lensing analysis. Several methods based on the inclusion of strong lensing information have been devised and applied to real cases (Bradac˘ et al. 2005a,b; Cacciato et al. 2006; Diego et al. 2007; Merten et al. 2009). However, strongly lensed images can only be produced by critical clusters. Thus, for subcritical clusters the mass-sheet degeneracy still remains a fundamental problem in the determination of the total mass.

In this context, Bertin & Lombardi (2006, BL06 from now on) proposed a new method to measure the lensing magnification induced by a cluster, which can be used to break the mass-sheet degeneracy. They showed that estimates of the magnification can be obtained by observing background early-type galaxies. Early-type galaxies can be treated as standard rods, in virtue of the empirical law of the fundamental plane. From a fundamental plane analysis, the intrinsic effective radius of an early-type galaxy can be recovered with a 15% accuracy (BL06). By measuring the observed (magnified) effective radius, the magnification can then be derived.

In this paper, we investigate the potential of this technique. In particular, we wish to determine the accuracy to which the total mass of a cluster can be determined by combining fundamental plane measurements with a weak lensing study. This is done by prescribing a method to break the degeneracy and studying its properties, both analytically and with the aid of simulations. In principle, substructures in the lensing cluster can introduce noise in the magnification signal, so that a given measurement might be used to set interesting constraints on the amount of substructure rather than the mass of the cluster. We also study this issue in this paper, with the use of numerical simulations. We then address the problem of identifying the optimal conditions for both the lens and source galaxies in order to get a reliable measurement in concrete cases.

The structure of the paper is the following. In Sect. 2, we present the basic lensing equations and present the problem of the mass-sheet degeneracy. In Sect. 3, we show how fundamental plane measurements can be used to infer the magnification and present a simple method to use these measurements to break the mass-sheet degeneracy. In Sect. 4, the statistical properties of this method are studied. In Sect. 5, we address the issue of how substructures can influence the magnification signal we seek to measure. In Sect. 6, we describe the simulations set up to test the method and show the results. Conclusions are drawn in Sect. 7.

2. Weak lensing preliminaries

2.1. Basic notation and equations

We start by introducing the projected surface mass density of a given lens, Σ(θ). The nature of the lensing equations make it convenient to introduce the dimensionless surface mass density κ(θ,z) for a source at redshift z, defined as $\mathit{\kappa }\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}\mathrm{\equiv }\frac{\mathrm{\Sigma }\mathrm{\left(}{\theta }\mathrm{\right)}}{{\mathrm{\Sigma }}_{\mathrm{cr}}\mathrm{\left(}\mathit{z}\mathrm{\right)}} \mathrm{where} {\mathrm{\Sigma }}_{\mathrm{cr}}\mathrm{\equiv }\frac{{\mathit{c}}^{\mathrm{2}}}{\mathrm{4}\mathit{\pi G}}\frac{{\mathit{D}}_{\mathrm{s}}}{{\mathit{D}}_{\mathrm{d}}{\mathit{D}}_{\mathrm{ds}}}\mathrm{·}$(2)Here D_d, D_s, D_ds are the angular diameter distances of both the lens and source with respect to the observer, and of the source with respect to the lens, respectively. The surface mass density is referred to a fiducial source at infinite redshift such that $\mathit{\kappa }\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}\mathrm{\equiv }\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathit{,}$(3)through the cosmological weight function $\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathrm{\equiv }\frac{{\lim }_{{\mathit{z}}^{\mathrm{\prime }}\mathrm{\to }\mathrm{\infty }}{\mathrm{\Sigma }}_{\mathrm{cr}}\left({\mathit{z}}^{\mathrm{\prime }}\right)}{{\mathrm{\Sigma }}_{\mathrm{cr}}\mathrm{\left(}\mathit{z}\mathrm{\right)}}\mathit{H}\mathrm{(}\mathit{z}\mathrm{-}{\mathit{z}}_{\mathrm{d}}\mathrm{)}\mathit{.}$(4)Here H(z − z_s) is the Heaviside step function, which takes into account that the images of sources at redshifts lower than that of the lens are not lensed.

An important quantity that enters the weak lensing problem is the redshift-dependent reduced shear g(θ,z) $\mathit{g}\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}\mathrm{=}\frac{\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathit{\gamma }\mathrm{\left(}{\theta }\mathrm{\right)}}{\mathrm{1}\mathrm{-}\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}}\mathit{,}$(5)where the shear γ(θ) can be expressed as a nonlocal function of κ(θ) $\mathit{\gamma }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{=}\frac{\mathrm{1}}{\mathit{\pi }}{\mathrm{\int }}_{R^{\mathrm{2}}}\mathrm{𝒟}\mathrm{(}{\theta }\mathrm{-}{\theta }\mathrm{\prime }\mathrm{)}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\prime }\mathrm{\right)}{\mathrm{d}}^{\mathrm{2}}{\mathit{\theta }}^{\mathrm{\prime }}\mathit{,}$(6)$\mathrm{with} \mathrm{𝒟}\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{\equiv }\mathrm{-}\frac{\mathrm{1}}{\mathrm{(}{\mathit{\theta }}_{\mathrm{1}}\mathrm{-}\mathrm{i}{\mathit{\theta }}_{\mathrm{2}}{\mathrm{)}}^{\mathrm{2}}}\mathrm{·}$(7)Weak lensing consists of the study of the distortion induced by the lens on the images of background sources. This can be done in terms of a complex ellipticity ϵ, defined from the quadrupole moments Q_ij of the surface brightness as $\mathit{ϵ}\mathrm{\equiv }\frac{{\mathit{Q}}_{\mathrm{11}}\mathrm{-}{\mathit{Q}}_{\mathrm{22}}\mathrm{+}\mathrm{2}\mathrm{i}{\mathit{Q}}_{\mathrm{12}}}{{\mathit{Q}}_{\mathrm{11}}\mathrm{+}{\mathit{Q}}_{\mathrm{22}}\mathrm{+}\mathrm{2}\sqrt{{\mathit{Q}}_{\mathrm{11}}{\mathit{Q}}_{\mathrm{22}}\mathrm{-}{\mathit{Q}}_{\mathrm{12}}^{\mathrm{2}}}}\mathrm{·}$(8)Seitz & Schneider (1997) showed that the image ellipticity is related to the intrinsic (unlensed) source ellipticity ϵ^s in the way $\mathit{ϵ}\mathrm{=}\{\begin{array}{}\\ \frac{{\mathit{ϵ}}^{\mathit{s}}\mathrm{+}\mathit{g}\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}}{\mathrm{1}\mathrm{+}\mathit{g}\mathrm{(}{\theta }\mathit{,z}{\mathrm{)}}^{\mathrm{\ast }}{\mathit{ϵ}}^{\mathit{s}}}\mathrm{if}\mathrm{\left|}\mathit{g}\mathrm{\right(}{\theta }\mathit{,z}\mathrm{\left)}\mathrm{\right|}\mathit{<}\mathrm{1}\\ \\ \frac{\mathrm{1}\mathrm{+}\mathit{g}\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}{\mathit{ϵ}}^{\mathit{s}\mathrm{\ast }}}{{\mathit{ϵ}}^{\mathit{s}\mathrm{\ast }}\mathrm{+}\mathit{g}\mathrm{(}{\theta }\mathit{,z}{\mathrm{)}}^{\mathrm{\ast }}}\mathrm{otherwise}\mathrm{.}\end{array}$(9)Therefore, under the assumption that the intrinsic ellipticity distribution of background sources is isotropic, the expectation value of the observed ellipticity for sources at redshift z is $\mathit{E}\mathrm{\left[}\mathit{ϵ}\mathrm{\right(}\mathit{z}\mathrm{\left)}\mathrm{\right]}\mathrm{=}\{\begin{array}{}\\ \mathit{g}\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}\mathrm{if}\mathrm{\left|}\mathit{g}\mathrm{\right(}{\theta }\mathit{,z}\mathrm{\left)}\mathrm{\right|}\mathit{<}\mathrm{1}\\ \\ \frac{\mathrm{1}}{{\mathit{g}}^{\mathrm{\ast }}\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}}\mathrm{otherwise}\mathrm{.}\end{array}$(10)In the general case of sources distributed in redshift, the approximation $\mathit{E}\mathrm{\left[}\mathit{ϵ}\mathrm{\right]}\mathrm{\simeq }\frac{\mathrm{⟨}\mathit{Z}\mathrm{⟩}\mathit{\gamma }\mathrm{\left(}{\theta }\mathrm{\right)}}{\mathrm{1}\mathrm{-}\frac{⟨{\mathit{Z}}^{\mathrm{2}}⟩}{\mathrm{⟨}\mathit{Z}\mathrm{⟩}}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}}\mathit{,}$(11)holds for κ ≲ 0.6 as shown by Seitz & Schneider (1997), where ⟨Zⁿ⟩ are the moments of the redshift probability distribution of the background galaxies.

2.2. The mass-sheet degeneracy

By averaging over image ellipticities of background galaxies and identifying ⟨ϵ⟩ with E [ϵ], we can estimate the quantity Eq. (11) in the field of observation. Since γ depends on κ through Eq. (6), relation (11) can then be inverted and the surface mass density κ can be recovered from the observed average ellipticity. Practical realizations of this picture were provided by Kaiser (1995), Seitz & Schneider (1997) and Lombardi & Bertin (1999).

It can be shown that the quantity E [ϵ] in Eq. (11), which is the observable quantity, is invariant under transformations of the form $\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{\to }{\mathit{\kappa }}^{\mathrm{\prime }}\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{=}\mathit{\lambda \kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{+}\mathit{w}\mathrm{(}\mathrm{1}\mathrm{-}\mathit{\lambda }\mathrm{)}\mathit{,}$(12)where we introduce $\mathit{w}\mathrm{\equiv }\frac{\mathrm{⟨}\mathit{Z}\mathrm{⟩}}{⟨{\mathit{Z}}^{\mathrm{2}}⟩}\mathrm{·}$(13)This is the mass-sheet degeneracy for the general case of sources distributed across a range of redshifts: with ellipticity measurements it is only possible to recover the surface mass density up to the above transformation. In the simplified case that all sources are at the same redshift z, the invariance transformation reduces to Eq. (1), where κ(θ,z) = κ(θ).

In principle, the mass-sheet degeneracy can be broken with a local measurement of the magnification. The magnification μ(θ,z) is related to κ(θ) and γ(θ) through the relation $\mathit{\mu }\mathrm{\left(}{\theta }\mathit{,z}\mathrm{\right)}\mathrm{=}{\left|\mathrm{[}\mathrm{1}\mathrm{-}\mathit{Z}\mathrm{(}\mathit{z}\mathrm{\left)}\mathit{\kappa }\mathrm{\right(}{\theta }\mathrm{)}{\mathrm{]}}^{\mathrm{2}}\mathrm{-}{\mathit{Z}}^{\mathrm{2}}\mathrm{(}\mathit{z}\mathrm{\left)}\mathrm{\right|}\mathit{\gamma }\mathrm{\left(}{\theta }\mathrm{\right)}{\mathrm{|}}^{\mathrm{2}}\right|}^{-1}\mathit{.}$(14)By measuring ⟨ϵ⟩ and μ(z) and combining Eq. (11) with (14), we obtain a two-equation system in terms of κ and γ, which can be solved for κ, thus breaking the mass-sheet degeneracy. We need to know, however, the redshift z to which the magnification measurement is referred to, to calculate the cosmological weight Z(z) that enters Eq. (14).

3. Breaking the mass-sheet degeneracy

We introduce a mass measurement method based on the combined use of weak lensing and magnification measurements.

3.1. The fundamental plane

The fundamental plane (FP from now on; Dressler et al. 1987; Djorgovski & Davis 1987) is an empirical scaling law that applies to early-type galaxies (E/S0). It relates three well-defined observable quantities for these objects: the effective radius, R_e, the effective surface brightness, ⟨SB⟩_e, and the central velocity dispersion of the stellar component, σ₀. The three quantities are related according to the relation $\log \hspace{0.17em}{\mathit{R}}_{\mathrm{e}}\mathrm{=}\log \hspace{0.17em}{\mathit{r}}_{\mathrm{e}}\mathrm{+}\log \hspace{0.17em}{\mathit{D}}_{\mathrm{A}}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathrm{=}\mathit{\alpha }\log \hspace{0.17em}{\mathit{\sigma }}_{\mathrm{0}}\mathrm{+}\mathit{\beta }{⟨\mathrm{SB}⟩}_{\mathrm{e}}\mathrm{+}\mathit{\gamma ,}$(15)where α, β, and γ are empirically determined coefficients that depend on the waveband of observation, r_e is the effective radius in angular units, and D_A(z) is the angular diameter distance of the galaxy at redshift z. The existence of this relation has been extensively confirmed by a number of studies of both field and cluster galaxies out to cosmological distances (e.g. Jørgensen et al. 1993; Bender et al. 1998; Treu et al. 1999). The measurement of the FP parameters for the most distant sample of objects to date was carried out by van der Wel et al. (2005, vdW05 from now on), who examined early-type galaxies out to z ≈ 1.1. This relation is observed to hold with a 0.07 scatter in log    r_e, or 15% in r_e, rather independently of the position on the FP plane (Jørgensen et al. 1996) and to increase with increasing redshift (Treu et al. 2005). Treu et al. (2005) quantified the increase in the scatter in log    r_e in the FP relation as dσ_γ/dz = 0.032 ± 0.012, which translates into a scatter of 23% in r_e at z = 1. It is still unclear whether the source of this scatter is totally intrinsic or can be reduced by improving the observational precision. Auger et al. (2010) estimated the intrinsic scatter in the FP to be as low as 11%.

Observations have been used to measure a variation in the coefficient γ with redshift, quantified as $\mathrm{d}\mathit{\gamma }\mathit{/}\mathrm{d}\mathit{z}\mathrm{=}\mathrm{0.5}{\mathrm{8}}_{-0.06}^{\mathrm{+}\mathrm{0.04}}$ by Treu et al. (2005). For cluster galaxies, there is evidence of a slower evolution (see e.g. Wuyts et al. 2004, vdW05), such that the FP of cluster galaxies appears to differ from that of field galaxies. In vdW05, it was shown that this difference is insignificant for massive (M > 2 × 10¹¹ M_⊙) galaxies, and a similar result was found by van Dokkum & van der Marel (2007). According to vdW05, the scatter in the FP is also smaller for the more massive objects. Evidence of a variation in the coefficients α and β with redshift has also been reported (Treu et al. 2005), but this is generally assumed to be less significant.

3.2. The FP seen through a lens

As shown in BL06, the FP changes in a well-defined way when viewed through a gravitational lens. Both the surface brightness ⟨SB⟩_e and the central velocity dispersion σ₀ are lens-invariant. Therefore, by measuring these two quantities for early-type galaxies and by making use of the FP relation given in Eq. (15) it is possible to obtain an estimate of the effective radius of the observed galaxy, ${\mathit{R}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}$. By measuring the redshift of the galaxy, it is then possible to convert this measurement of the effective radius to angular units, ${\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}$. By observing the effective radius ${\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{obs}\mathrm{\right)}}$, magnified by the lens effect, the lens magnification will then be given by the square of the ratio of the intrinsic size to the observed image size, as $\mathit{\mu }\mathrm{=}{\left(\frac{{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{obs}\mathrm{\right)}}}{{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}}\right)}^{\mathrm{2}}\mathrm{·}$(16)With a 15% scatter in the FP relation, the same error will affect our estimate of the intrinsic effective radius, ${\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}$, which translates into a  ~ 30% error in the magnification.

The quantity that is lens invariant is the intrinsic surface brightness, which in general differs from the observed surface brightness. Nevertheless, van der Wel et al. (2005) showed that the intrinsic surface brightness of galaxies at high redshift can be effectively measured by fitting Sersic models convolved with the PSF. We expect this task to be made easier by the magnifying effect of lensing.

3.3. A minimum-χ² approach

The method presented here has been developed and tested for noncritical lenses only, although it can be generalized to the critical case. Therefore, from now on we assume that the lens does not have critical curves, unless stated differently. This is also the most interesting case, because it is for subcritical lenses that the problem of the mass-sheet degeneracy is harder to overcome.

Suppose we performed a weak lensing analysis of a cluster, that led to the determination of the average distortion ⟨ϵ⟩(θ) within the field of view. By inverting the distortion map (for instance with the nonparametric method of Lombardi & Bertin 1999), it is possible to recover the surface mass density of the lens κ(θ) up to the invariance transformation Eq. (12). Then, suppose that we performed a set of N_FP FP measurements, through which we estimate the magnification in a corresponding number of positions  { θ_i }  on the image plane.

Among the infinitely possible mass density maps compatible with the distortion measurements, spanned by Eq. (12), we select the one for which the accordance with the observations of magnified early-type galaxies is best. To do so, we first transform the estimates of the magnification into estimates of the surface mass density, κ^(FP)(θ_i), making use of Eqs. (11) and (14). This requires that we know the average distortion in the image position, ⟨ϵ⟩(θ_i), determined from the weak lensing study, and the redshift z_i of each galaxy, which can be measured with the same spectroscopic observation necessary to measure σ₀. The expression that gives κ^(FP)(θ_i) in terms of μ(θ_i), ⟨ϵ⟩(θ_i), and z_i is ${\mathit{\kappa }}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{=}\frac{\mathrm{-}\mathit{b}\mathrm{-}\sqrt{{\mathit{b}}^{\mathrm{2}}\mathrm{-}\mathit{a}\mathrm{(}\mathit{c}\mathrm{-}\mathrm{1}\mathit{/}\mathit{\mu }\mathrm{)}}}{\mathit{a}}\mathit{,}$(17)where $\begin{array}{ccc}\mathit{a}& \mathrm{\equiv }& {\mathit{Z}}_{\mathit{i}}^{\mathrm{2}}\left(\mathrm{1}\mathrm{-}\frac{\mathrm{1}}{{\mathit{w}}^{\mathrm{2}}{⟨\mathit{Z}⟩}^{\mathrm{2}}}{\left|⟨\mathit{ϵ}⟩\right|}^{\mathrm{2}}\right)\mathit{,} \mathit{b}\mathrm{\equiv }{\mathit{Z}}_{\mathit{i}}\left(\frac{{\mathit{Z}}_{\mathit{i}}}{\mathit{w}{⟨\mathit{Z}⟩}^{\mathrm{2}}}{\left|⟨\mathit{ϵ}⟩\right|}^{\mathrm{2}}\mathrm{-}\mathrm{1}\right)\mathit{,}\\ \mathit{c}& \mathrm{\equiv }& \mathrm{1}\mathrm{-}\frac{{\mathit{Z}}_{\mathit{i}}^{\mathrm{2}}}{{⟨\mathit{Z}⟩}^{\mathrm{2}}}{\left|⟨\mathit{ϵ}⟩\right|}^{\mathrm{2}} \mathrm{and} {\mathit{Z}}_{\mathit{i}}\mathrm{\equiv }\mathit{Z}\mathrm{(}{\mathit{z}}_{\mathit{i}}\mathrm{)}\mathit{.}\end{array}$The minus sign for the square root in Eq. (17) reflects our assumption that the lens is everywhere subcritical.

The fit is performed by minimizing the penalty function ${\mathit{\chi }}^{\mathrm{2}}\mathrm{=}\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}{\left|\mathit{\lambda }{\mathit{\kappa }}_{\mathrm{0}}\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{+}\mathit{w}\mathrm{(}\mathrm{1}\mathrm{-}\mathit{\lambda }\mathrm{)}\mathrm{-}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\right|}^{\mathrm{2}}\mathit{,}$(20)where κ₀(θ) is the surface mass density distribution inferred from the weak lensing reconstruction, and ${\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}$ are suitably chosen weights. The minimum-χ² condition can be found by imposing ∂χ²/∂λ = 0, which leads to the determination of the estimator  for the parameter λ$\mathit{\lambda ̂}\mathrm{=}\frac{\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}\mathrm{[}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{-}{\mathit{w}}^{\mathrm{]}}\left[{\mathit{\kappa }}_{\mathrm{0}}\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}{\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}{\left[{\mathit{\kappa }}_{\mathrm{0}}\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}^{\mathrm{2}}}\mathrm{·}$(21)The choice of the weights ${\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}$ that enter this χ² function requires particular care. When attempting to minimize χ², the values of σ_i are taken to be proportional to the measurement errors of the quantity over which the fit is performed, which, in the present case, is the surface mass density κ^(FP). By assuming that the errors come only from the FP measurements (i.e. under the assumption of perfect weak lensing measurements), error propagation in κ^(FP) gives $\mathrm{\Delta }{\mathit{\kappa }}_{\mathrm{FP}}\mathrm{=}{\mathit{\sigma }}_{\mathrm{FP}}\mathrm{\left(}\mathit{z}\mathrm{\right)}\frac{{\left[\mathrm{1}\mathrm{-}\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathit{\kappa }\right]}^{\mathrm{2}}\mathrm{-}\frac{\mathit{Z}\mathrm{(}\mathit{z}{\mathrm{)}}^{\mathrm{2}}}{{⟨\mathit{Z}⟩}^{\mathrm{2}}}{\left(\mathrm{1}\mathrm{-}\frac{\mathit{\kappa }}{\mathit{w}}\right)}^{\mathrm{2}}{\left|⟨\mathit{\epsilon }⟩\right|}^{\mathrm{2}}\mathrm{\left(}{\theta }\mathrm{\right)}}{\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\left[\mathrm{1}\mathrm{-}\mathit{Z}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathit{\kappa }\right]\mathrm{-}\frac{\mathit{Z}\mathrm{(}\mathit{z}{\mathrm{)}}^{\mathrm{2}}}{\mathit{w}{⟨\mathit{Z}⟩}^{\mathrm{2}}}{\left(\mathrm{1}\mathrm{-}\frac{\mathit{\kappa }}{\mathit{w}}\right)}^{\mathrm{2}}{\left|⟨\mathit{\epsilon }⟩\right|}^{\mathrm{2}}\mathrm{\left(}{\theta }\mathrm{\right)}}\mathit{,}$(22)where σ_FP(z) is the scatter in r_e of the FP. Therefore, Δκ_FP depends on the value of κ, which is the quantity we try to determine with the fit. This complicates the definition of the weights. One would be tempted to define σ_i = Δκ(κ^(FP)(θ_i)), but by doing so we would introduce a bias in the estimate of λ: this is because a greater weight would be given to measurements in which fluctuations give higher values of the magnification, relative to cases in which μ is underestimated. The fit would then yield preferentially higher mass estimates.

The solution we propose is an iteration procedure, seeded by the definition of the weights based on the model surface mass density κ₀ obtained from weak lensing: in Eq. (22) we identify κ₀ with κ and define ${\mathit{\sigma }}_{\mathit{i}}\mathrm{\equiv }\mathrm{\Delta }{\mathit{\kappa }}_{\mathrm{FP}}\mathrm{(}{\mathit{\kappa }}_{\mathrm{0}}{\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}}^{\mathrm{)}}\mathit{.}$(23)We can then minimize the χ² function and obtain a new estimate of the density map. If λ₍₀₎ is the value of the parameter λ obtained from the fit with Eq. (21), then this new model for the surface mass density will be given by ${\mathit{\kappa }}_{\mathrm{1}}\mathrm{=}{\mathit{\lambda }}_{\mathrm{\left(}\mathrm{0}\mathrm{\right)}}{\mathit{\kappa }}_{\mathrm{0}}\mathrm{+}\mathit{w}\left(\mathrm{1}\mathrm{-}{\mathit{\lambda }}_{\mathrm{\left(}\mathrm{0}\mathrm{\right)}}\right)\mathit{.}$(24)At this point, we can update the weights to this new model by redefining σ_i = Δκ_FP [κ₁(θ_i)] and iterate the procedure. Figure 1 outlines the basic steps of the method. The method converges quickly and the final solution is found to be invariant under transformations of the form given in Eq. (12) of the input surface mass density map κ₀.

Equation (20) is only one possible definition of a χ² function for our problem. We could have defined a χ² in terms of other quantities, such as the magnification μ or its inverse |det   A|. The advantage of our choice lies in the minimum χ² condition ∂χ²/∂λ = 0 being a linear function of λ. This makes it relatively easy to study the statistical properties of the method, which is the subject of Sect. 4.

Fig. 1 Fitting process.

4. Statistical properties of the method

To assess the reliability of the method introduced to break the mass-sheet degeneracy, it is necessary to study in detail the statistical properties of the results obtained. In particular, we wish to clarify whether the estimate of the total mass resulting from this procedure is biased, and to determine the expected uncertainty.

To do this, we need to discuss the conditions of observation first. It would obviously be preferable to work with a large number of measurements, but a practical limit is imposed by the telescope time required to measure velocity dispersions. We believe that a reasonable number of FP measurements that can be effectively carried out in an observational campaign is N_FP ≈ 20. Another important issue is the possibility of Þnding a sufficient number of sources behind the observed gravitational lens. BL06 estimated the number density of practically observable sources to be  ~2 arcmin^-2. This estimate was based on a study of magnitude-number counts of early-type galaxies (Glazebrook et al. 1995). This sets a limit on the field of view required to have sufficiently high quality statistics of FP measurements. It also tells us that, unless a large field of view is examined, the observer does not have much freedom in selecting objects. Our statistical study takes into account these important factors.

In this section, the weak lensing study is assumed to provide a perfect reconstruction of the surface mass density map, except for the mass-sheet degeneracy. Since the fit method is invariant under tranformations of the form given in Eq. (12) on the input density map κ₀(θ), we can also assume without further restrictions that κ₀(θ) is the exact surface mass density of the lens ${\mathit{\kappa }}_{\mathrm{0}}\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{=}{\mathit{\kappa }}_{\mathrm{true}}\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{\equiv }\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathit{.}$(25)On the basis of these assumptions, we study the statistical properties of the estimator  at the first iteration (i.e. ). The results obtained will provide information about the error in the determination of the mass density map κ₁(θ) after the first iteration. Since the method converges quickly, there is little difference between κ₁(θ) and the final density map, hence we consider the difference between κ₁ and the exact density map κ when evaluating our errors.

4.1. Error in

We define the expectation value of the estimator  to be $\mathit{E}\left\{\mathit{\lambda ̂}\right\}\mathrm{=}\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\mathit{E}\left\{{\mathit{I}}_{\mathit{i}}\right\}\mathit{,}$(26)where we introduced ${\mathit{I}}_{\mathit{i}}\mathrm{(}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathit{,}\mathrm{\{}{\theta }{\mathit{j}}^{\mathrm{\}}}\mathit{,}{\mathrm{\left\{}{\mathit{z}}_{\mathit{j}}\mathrm{\right\}}}^{\mathrm{)}}\mathrm{\equiv }\frac{\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}\mathrm{[}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{-}{\mathit{w}}^{\mathrm{]}}\left[\mathit{\kappa }\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}{\sum _{\mathit{j}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{j}}^{\mathrm{2}}}{\mathrm{[}\mathit{\kappa }\mathrm{(}{\theta }{\mathit{j}}^{\mathrm{)}}\mathrm{-}{\mathit{w}}^{\mathrm{]}}}^{\mathrm{2}}}\mathrm{·}$(27)We assume that the number of FP measurements N_FP is fixed, and that the image positions are randomly distributed. We denote by P_θ,z(θ,z) the probability distribution in redshift and the image position of the observed galaxies.

Given these definitions, we write the quantities E { I_i }  that enter Eq. (26) as $\mathit{E}\left\{{\mathit{I}}_{\mathit{i}}\right\}\mathrm{=}\underset{\mathit{j}\mathrm{=}\mathrm{1}}{\overset{{\mathit{N}}_{\mathrm{FP}}}{\mathrm{􏽙}}}\mathrm{\int }{\mathit{P}}_{{\theta }\mathit{,z}}\mathrm{\left(}{\theta }\mathit{j}\mathit{,}{\mathit{z}}_{\mathit{j}}\mathrm{\right)}\mathrm{d}{\theta }\mathit{j}\mathrm{d}{\mathit{z}}_{\mathit{j}}\mathrm{\int }{\mathit{P}}_{\mathit{\kappa }}\mathrm{(}{{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}}^{\mathrm{)}}\mathrm{d}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}{\mathit{I}}_{\mathit{i}}\mathit{,}$(28)where P_κ is the probability distribution for the estimates of κ from a FP measurement. We assume that ${\mathit{P}}_{\mathit{\kappa }}\mathrm{\left(}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{\right)}$ is a Gaussian function with dispersion σ_i, centered on the exact value of the surface mass density given by ${\mathit{P}}_{\mathit{\kappa }}\mathrm{(}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathit{,}{\left\{\mathit{\kappa ,}{\mathit{\sigma }}_{\mathit{i}}\right\}}^{\mathrm{)}}\mathrm{=}\frac{\mathrm{1}}{\sqrt{\mathrm{2}\mathit{\pi }{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}}\exp \begin{array}{}\mathrm{⎧}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎨}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎩}\end{array}\mathrm{-}\frac{{\mathrm{[}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{-}\mathit{\kappa }{\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}}^{\mathrm{]}}}^{\mathrm{2}}}{\mathrm{2}{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}\begin{array}{}\mathrm{⎫}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎬}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎪}\\ \mathrm{⎭}\end{array}\mathrm{·}$(29)The validity of this assumption will be discussed in Appendix A. We then perform the integration in $\mathrm{d}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}$ in Eq. (28), which yields $\mathrm{\int }\mathrm{d}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}{\mathit{P}}_{\mathit{\kappa }}\mathrm{(}{{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}}^{\mathrm{)}}{\mathit{I}}_{\mathit{i}}\mathrm{=}\frac{\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}{\left[\mathit{\kappa }\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}^{\mathrm{2}}}{\sum _{\mathit{j}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{j}}^{\mathrm{2}}}{\mathrm{[}\mathit{\kappa }\mathrm{(}{\theta }{\mathit{j}}^{\mathrm{)}}\mathrm{-}{\mathit{w}}^{\mathrm{]}}}^{\mathrm{2}}}\mathit{,}$(30)from which, together with Eq. (26), it easily follows that $\mathit{E}\left\{\mathit{\lambda ̂}\right\}\mathrm{=}\mathrm{1.}$(31)Since the input density map was assumed to be the exact surface mass density of the lens (κ₀(θ) = κ(θ)), this result implies that the expectation value for the reconstructed surface mass density distribution is the exact one: the estimator  is not biased.

As a second step, we study the second moment of the probability distribution for , the variance: . A similar calculation leads to $\mathrm{Var}\mathrm{\left(}\mathit{\lambda ̂}\mathrm{\right)}\mathrm{=}\mathit{E}\mathrm{\{}\mathit{\lambda ̂}{\mathrm{2}}^{\mathrm{\}}}\mathrm{-}{\mathit{E}}^{\mathrm{2}}\left\{\mathit{\lambda ̂}\right\}\mathrm{=}⟨\frac{\mathrm{1}}{\sum _{\mathit{i}}^{{\mathit{N}}_{\mathrm{FP}}}\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathit{i}}^{\mathrm{2}}}{\left[\mathit{\kappa }\mathrm{(}{\theta }{\mathit{i}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}^{\mathrm{2}}}⟩\mathit{,}$(32)where the angle brackets indicate that the expression must be averaged over the possible image positions and source redshifts.

We note that in the limit of high N_FP the variance has the typical behavior  ~1/N_FP. We have exactly in the case of a uniform sheet of constant surface mass density.

4.2. Error in the total mass

We have just shown the basic results about the accuracy of the method in determining the parameter λ. We now examine the problem of how an error in λ translates into errors in the estimated total mass M of the lens.

The total mass inside the field of view is given by the integral of κ over the observed portion of the image plane Θ $\mathit{M}\mathrm{=}{\mathrm{\Sigma }}_{\mathrm{cr}}{\mathit{D}}_{\mathrm{d}}^{\mathrm{2}}{\mathrm{\int }}_{\mathrm{\Theta }}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}{\mathrm{d}}^{\mathrm{2}}\mathit{\theta ,}$(33)where D_d is the angular diameter distance of the lens relative to the observer. The surface mass density is subject to the invariance transformation given in Eq. (12). The expectation value of the measured mass  is $\mathit{E}\left\{\mathit{M̂}\right\}\mathrm{=}{\mathrm{\Sigma }}_{\mathrm{cr}}{\mathit{D}}_{\mathrm{d}}^{\mathrm{2}}\mathit{E}\left\{{\mathrm{\int }}_{\mathrm{\Theta }}\left[\mathit{\lambda ̂}\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{+}\mathit{w}\mathrm{(}\mathrm{1}\mathrm{-}\mathit{\lambda ̂}\mathrm{)}\right]{\mathrm{d}}^{\mathrm{2}}\mathit{\theta }\right\}\mathrm{=}\mathit{M,}$(34)where we made use of Eq. (31), and Σ_cr ≡ Σ_cr(z_s → ∞). If the estimator for λ is not biased, then there is also no bias in the estimate of the total mass.

We now consider the variance in . A straightforward calculation based on Eq. (31) gives $\mathrm{Var}\mathrm{\left(}\mathit{M̂}\mathrm{\right)}\mathrm{=}\mathit{E}\mathrm{\{}\mathit{M̂}{\mathrm{2}}^{\mathrm{\}}}\mathrm{-}{\mathit{E}}^{\mathrm{2}}\left\{\mathit{M̂}\right\}\mathrm{=}{\left(\mathit{M}\mathrm{-}\mathit{w}{\mathrm{\Sigma }}_{\mathrm{cr}}{\mathit{D}}_{\mathrm{d}}^{\mathrm{2}}{\mathrm{\int }}_{\mathrm{\Theta }}{\mathrm{d}}^{\mathrm{2}}\mathit{\theta }\right)}^{\mathrm{2}}\mathrm{Var}\mathrm{\left(}\mathit{\lambda ̂}\mathrm{\right)}\mathit{.}$(35)By taking the square root of Eq. (35) and dividing it by M, we obtain the expected relative dispersion of $\frac{\mathit{\sigma }\mathrm{\left(}\mathit{M̂}\mathrm{\right)}}{\mathit{M}}\mathrm{=}\left|\mathit{w}\frac{\mathrm{1}}{\mathit{\kappa ̅}}\mathrm{-}\mathrm{1}\right|\mathit{\sigma }\mathrm{\left(}\mathit{\lambda ̂}\mathrm{\right)}\mathit{,}$(36)where  is the average surface mass density inside the field of view and is the square root of Eq. (32), namely the dispersion of .

This result allows us to calculate, for a given lens, the accuracy with which its mass can be measured. For fixed average surface mass density , the only quantity that determines this accuracy is the precision of the determination of λ, . This quantity might depend on the shape of the lens mass distribution, so that lenses with certain characteristics may be more suitable candidates than others. This issue, which is important for determining which lenses are the ideal candidates for an application of the present technique, is addressed in the next subsection by studying and  for different lens models.

4.3. Simple examples

To more clearly understand the above results, it is useful to focus on simple situations. We start by discussing the case with N_FP = 1 and consider the quantity in brackets in Eq. (32) ${\mathit{J}}_{\mathrm{1}}\mathrm{\equiv }\frac{\mathrm{1}}{\frac{\mathrm{1}}{{\mathit{\sigma }}_{\mathrm{1}}^{\mathrm{2}}}{\left[\mathit{\kappa }\mathrm{(}{\theta }{\mathrm{1}}^{\mathrm{)}}\mathrm{-}\mathit{w}\right]}^{\mathrm{2}}}\mathrm{·}$(37)Then, as a first example, we consider an approximate representation of the nonsingular isothermal sphere (NIS), which has a density profile given by $\mathit{\rho }\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{=}\frac{{\mathit{\sigma }}_{\mathit{v}}^{\mathrm{2}}}{\mathrm{2}\mathit{\pi G}}\frac{\mathrm{1}}{{\mathit{r}}^{\mathrm{2}}\mathrm{+}{\mathit{r}}_{\mathrm{c}}^{\mathrm{2}}}\mathrm{·}$(38)The projected mass density κ(θ) of a NIS is given by $\mathit{\kappa }\mathrm{\left(}{\theta }\mathrm{\right)}\mathrm{=}\frac{{\mathit{\sigma }}_{\mathit{v}}^{\mathrm{2}}}{\mathrm{2}\mathit{G}{\mathrm{\Sigma }}_{\mathrm{cr}}}\frac{\mathrm{1}}{\sqrt{\mathrm{1}\mathrm{+}{\mathrm{(}\mathit{\theta }{\mathit{D}}_{\mathrm{d}}\mathit{/}{\mathit{r}}_{\mathrm{c}}\mathrm{)}}^{\mathrm{2}}}}\mathrm{\equiv }{\mathit{\kappa }}_{\mathrm{c}}\frac{\mathrm{1}}{\sqrt{\mathrm{1}\mathrm{+}{\mathrm{(}\mathit{\theta }{\mathit{D}}_{\mathrm{d}}\mathit{/}{\mathit{r}}_{\mathrm{c}}\mathrm{)}}^{\mathrm{2}}}}\mathrm{·}$(39)We take σ_v = 1000 km   s^-1 and r_c = 58.8 kpc and place the lens at redshift z_d = 0.3, so that the projected surface mass density at the center is κ(0) = 1. In Fig. 2, we plot the quantity J₁ as a function of κ (i.e. image position) for a source at redshift z_s = 0.6,0.8,1.0. For this and the following examples, the value of w is computed by assuming a redshift distribution of weak lensing measurements ${\mathit{P}}_{\mathit{z}}^{\mathrm{\left(}\mathrm{WL}\mathrm{\right)}}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathrm{\propto }{\mathit{z}}^{\mathrm{2}}\exp \mathrm{(}\mathrm{-}\mathit{z}\mathit{/}{\mathit{z}}_{\mathrm{0}}\mathrm{)}$ with z₀ = 2/3, as in Bradac˘ et al. (2004), while the scatter in the FP is assumed to be σ_FP = 0.15. It can be seen that J₁ increases with increasing κ, although mildly. This result suggests that, for a given lens observed within a given field of view, it would be preferable to perform FP measurements on objects whose images lie where the surface mass density is lower, as the expected dispersion in λ is smaller. However, it is important to recall the assumptions that underlie this result. In particular, we assume that no error comes from the weak lensing analysis. When this assumption is dropped the situation changes. Real cases are more complex: as we show in Sect. 6, weak lensing reconstructions tend to underestimate the surface mass density in the central parts of the lenses and overestimate it in the outskirts. Therefore, normalizing the overall mass scale of a lens with FP measurements limited to particular regions of the image plane can be risky, because biases can be introduced. The impact of weak lensing errors on the measurement of the mass is reduced by sampling the image plane uniformly. This issue is discussed further in Sect. 6.2.

Fig. 2 J1, as defined in Eq. (37), as a function of κ (i.e. image position) for a NIS lens with σv = 1000 km   s-1 and rc = 58.8 kpc, for three source redshifts.

As a second step, we consider the variation in as a function of the average surface mass density  of the lens, for two simple lens models, again in the case N_FP = 1. As lens models, we consider NIS lenses with various values of σ_v and r_c but fixed central surface mass density κ_c = 1. Equation (39) shows that NIS lenses with different values of r_c and fixed κ_c are rescaled only in the angular dimension. Therefore, for a given lens, changing r_c and keeping κ_c fixed is equivalent to choosing a different field of view.

Fig. 3 as a function of the average surface mass density  for two lens models: a NIS with κ(0) = 1 (solid line) and a sheet of constant surface mass density and no shear (dotted line).

For comparison, we also considered lenses of constant surface mass density and no shear. In Fig. 3, we plot the variance in  as a function of  for these two lens models, for a single source at fixed redshift z_s = 0.8. The space average in Eq. (32) was calculated by ignoring the effects of the magnification on the image position probability P_θ(θ). The value of the variance in the estimator  is found to be similar for the two kinds of lens, for fixed average density . This result is presumably a consequence of the mild dependence of J₁ on κ, as observed in the plot of Fig. 2.

Finally, we calculate the dispersion in the measurement of the mass, for the two cases considered above, plotting the results in Fig. 4. The results for the two lenses are practically indistinguishable. This result, which reflects the similarity of the values of found for the two lenses, suggests that the shape of the mass distribution plays little role in determining the accuracy of the mass measurement, while the decisive factor is the average surface mass density within the field of view, .

Fig. 4 as a function of the average surface mass density  for two lens models: a NIS with κ(0) = 1 (solid line) and a sheet of constant surface mass density and no shear (dotted line).

We recall that these results were obtained by assuming that the image positions are distributed randomly. This may not be true if the observer plays an active role in the object selection. For example, one may wish to sample the field uniformly, avoiding close pairs of images. In this way, the image positions will be correlated, which will affect the value of . However, given the already mild dependence of on the image position (see Fig. 2), we do not expect our results to change significantly.

5. Substructure effects

In some galaxy-galaxy strong lensing systems, we note that while it is relatively easy to build smooth lens models that closely reproduce the multiple image positions of distant QSOs, the same models are unable to reproduce the observed flux ratios of these images (e.g. Kent & Falco 1988; Hogg & Blandford 1994; Falco et al. 1997). It is now common belief that these flux ratio anomalies may be due to the presence of substructures, and several attempts have been made to develop suitable lens models that take substructure into account, such as those by Mao & Schneider (1998), Metcalf & Madau (2001), Bradac˘ et al. (2002), and Chiba (2002). The argument of these studies is supported by the following reasoning: a substructure with an Einstein radius comparable to the angular size of the source’s light emitting region can cause a significant change in its apparent size, while its position on the lens plane can be almost unaffected. This condition is relatively easy to obtain in the case of a compact source such as a distant QSO lensed by a galaxy; objects as massive as a typical globular cluster (~10⁶ M_⊙) can indeed appreciably change the flux received from such a source, if properly aligned. This effect is enhanced in the proximity of critical curves (i.e. curves where |det   A| ≃ 0). Since $\mathit{\mu }\mathrm{=}\mathrm{|}\begin{array}{}\det \end{array}\hspace{0.17em}\mathit{A}{\mathrm{|}}^{-1}\mathrm{=}\left|\frac{\mathrm{1}}{\mathrm{(}\mathrm{1}\mathrm{-}\mathit{\kappa }{\mathrm{)}}^{\mathrm{2}}\mathrm{-}\mathrm{|}\mathit{\gamma }{\mathrm{|}}^{\mathrm{2}}}\right|\mathit{,}$(40)if |det   A| ≃ 0 a small change in κ can produce a large change in the magnification.

Weak lensing is a good tracer of the surface mass density averaged over finite portions of the image plane, but is insensitive to small-scale variations in the projected mass distribution. Weak lensing methods recover the reduced shear g by averaging the distortion signal over a number of background galaxies over angular scales of tens of arcseconds (e.g. see Lombardi et al. 2000). Therefore, they only provide smoothed mass density profiles. If we wish to break the mass-sheet degeneracy with magnification measurements, we must be sure that these magnification measurements also reflect the properties of this smoothed mass profile. Substructures modify the lensing signal in a nontrivial way and can complicate the interpretation of magnification measurements. For the purpose of constraining the total mass of the lens, the contribution from smaller clumps has the same effect as noise.

The problem is addressed with the aid of numerical simulations. We construct a model cluster as a superposition of a smooth principal halo and a number of smaller subhalos. We generate images of background early-type galaxies, compare the observed magnification with that inferred from a smooth lens model, and then analyze the results.

In this section, we use the terms clump, halo, subclump, subhalo, and substructure synonymously to refer to mass concentrations inside a galaxy cluster.

5.1. Modeling substructure in clusters of galaxies

It is unclear how much substructure is present in clusters of galaxies. Cosmological simulations predict the existence of a large number of subhalos of mass M < 10¹⁰ M_⊙, but observations have failed to prove their presence, so far. Here we adopt a conservative approach and take into account the possibility that substructures are present in the abundances predicted by ΛCDM models.

5.1.1. Masses and spatial distribution of subclumps

N-body simulations of structure formation on cluster scales based on the ΛCDM scenario have shown that the dark matter halos that maintain their identity after the formation process can be approximately described by a power-law mass function $\frac{\mathrm{d}\mathit{N}}{\mathrm{d}\mathit{M}}\mathrm{\propto }{\mathit{M}}^{\mathrm{-}\mathrm{(}\mathrm{1}\mathrm{+}\mathit{\alpha }\mathrm{)}}\mathit{,}$(41)with α ≈ 0.9 − 1, as demonstrated for example in the papers by Tormen et al. (1998), Ghigna et al. (2000), De Lucia et al. (2004), and Gao et al. (2004). These dark matter subclumps are believed to account for a few percent of the total mass of the cluster. We note that the mass fraction in substructure also depends on the age of the cluster: as a cluster evolves the subhalos merge with the main halo until the whole structure virializes and fewer substructures are left.

Given these results, we model clusters in a semi-analytic way. A smooth mass density profile for the main halo is chosen; a distribution of subclumps is randomly generated from the mass distribution given by Eq. (41), with the total mass in substructures fixed; these subclumps are randomly distributed with a spatial probability distribution proportional to the mass density of the main halo. More details about the practical realization of this procedure are given below.

Numerical simulations have also shown that more massive clumps tend to be located far from the cluster center, where only small scale halos survive the merging process (Tormen et al. 1998; Ghigna et al. 2000). For simplicity, we adopted a uniform spatial distribution of subhalos, as appropriate for the kind of study we wish to perform.

5.1.2. Internal structure of subclumps

For the description of the internal structure of dark matter subhalos, we follow the work of Metcalf & Madau (2001), who developed numerical simulations to study the effects of subclumps in galaxies on the measured lensing magnification of distant QSOs. In our work, we extend the use of their tools to galaxy cluster environments. Metcalf & Madau modeled subclumps as truncated singular isothermal spheres. The advantage of using singular isothermal spheres is that their lensing properties can be easily described analytically. On the other hand a singular isothermal sphere (hereafter SIS) has infinite mass. For this reason, a truncation radius is introduced. For a clump of mass m at radial distance R from the center of the main halo, the truncation radius is taken to be equal to the tidal radius r_t, which is estimated as (Metcalf & Madau 2001) ${\mathit{r}}_{\mathrm{t}}\mathrm{\simeq }\mathit{R}{\left[\frac{\mathit{m}}{\mathrm{3}\mathit{M}\mathrm{\left(}\mathit{R}\mathrm{\right)}}\right]}^{\mathrm{1}\mathit{/}\mathrm{3}}\mathit{,}$(42)where M(R) is the mass of the main halo enclosed by the sphere of radius R. With this choice, if M(R) grows less steeply than R³ (both SIS and NFW models have this property), then clumps closer to the center tend to be more compact than those that lie far from the center.

Once the mass and truncation radius of the clump are fixed there is a unique truncated singular isothermal sphere (hereafter TSIS) with those characteristics. In particular, if we adopt the following notation for the density of a TSIS $\mathit{\rho }\mathrm{\left(}\mathit{r}\mathrm{\right)}\mathrm{=}\{\begin{array}{}\\ \frac{{\mathit{\sigma }}_{\mathit{v}}^{\mathrm{2}}}{\mathrm{2}\mathit{\pi G}{\mathit{r}}^{\mathrm{2}}}\mathrm{if}\mathit{r}\mathit{<}{\mathit{r}}_{\mathrm{t}}\\ \\ \mathrm{0}\mathrm{elsewhere,}\end{array}$(43)the parameter σ_v (often called the velocity dispersion) is given in terms of the mass m of the clump by ${\mathit{\sigma }}_{\mathit{v}}^{\mathrm{2}}\mathrm{=}\frac{\mathit{Gm}}{\mathrm{2}{\mathit{r}}_{\mathrm{t}}}\mathrm{=}\frac{\mathit{G}{\mathit{m}}^{\mathrm{2}\mathit{/}\mathrm{3}}}{\mathrm{2}\mathit{R}}{\left[\mathrm{3}\mathit{M}\mathrm{\left(}\mathit{R}\mathrm{\right)}\right]}^{\mathrm{1}\mathit{/}\mathrm{3}}\mathit{.}$(44)

5.2. Lensing simulations

5.2.1. General prescriptions

A simulated cluster is generated with the procedure described in Sect. 5.1. For the main halo, we adopt a nonsingular isothermal sphere as described in Eq. (38). Subhalos with a mass distribution given by Eq. (41) and cumulative mass that accounts for a fraction f of the total mass of the cluster within r₂₀₀ are then added to this smooth component. Here r₂₀₀ represents the radius of the sphere whose mean density is 200 times the critical density at the redshift of the object, and M₂₀₀ is the corresponding mass. The total mass in subhalos is then fM₂₀₀. A direct application of Eq. (41) results in a very large number of clumps with very small mass. These small clumps are not relevant to the lensing problem because they produce negligible effects on the magnification of extended images such as those of early-type galaxies. Moreover, the inclusion of a large number of clumps increases the computational effort required to run the simulations, so that it is useful to introduce a cutoff to the lower range of possible masses. A reasonable choice for this lower mass cutoff is a value m_min for which the typical lensing deflection angle is only a small fraction of the angular size of the source considered.

To test how the results of our simulations depend on the assumed internal structure of clumps, we also adopted an alternative (and non realistic) internal profile: we assumed clumps to be point masses. The TSIS clump clearly produces a smaller deflection angle up to r_t. For distances larger than r_t the two clumps will produce equal values of the deflection angle, as they both act as if they were point masses located at the center. For this reason, the effects on magnification produced by a point mass will be generally higher than those produced by an extended lens of the same mass. Therefore, if we study the problem of the magnification induced by substructure by modeling substructure as point masses we can obtain an upper limit to the effects of substructure on the magnification.

5.2.2. Practical realization

We simulate the observed image of a circular early-type galaxy with effective radius R_e = 5 kpc at redshift z_s = 0.8 being lensed by a NIS cluster with substructures at redshift z_d = 0.3. The parameters of the NIS model chosen for the test of the method are taken from a study of the Coma cluster by De Boni & Bertin (2008), who found the best-fit parameters for the description of the dark matter halo as a NIS model of r_c = 88 kpc and σ_v = 1156 km   s^-1.

We fix the mass fraction in substructure f and generate substructures with the procedure described above, with a lower mass cutoff of m_min = 10⁹ M_⊙. This value was chosen because, for the redshift configuration of our system, the Einstein radii of point masses less massive than m_min are smaller than 0.3 kpc, thus with little impact on the distortion of the images chosen for our study. We note that in a situation in which all the substructures account for a fraction f of the total mass of the cluster, those with masses greater than m_min will in general account for a lower fraction f′ of the total mass. A fraction f − f′ will consist of clumps with m < m_min. Since the lensing effect of these low-mass clumps is small we simulate them by adding a smooth component for a fraction f − f′ of the total mass. We generated clusters with values of f equal to 0.05, 0.10, and 0.15. In these three situations and with the adopted value of m_min, the corresponding value of f′ is 0.029, 0.061, and 0.093, respectively.

To simulate the image formation we proceed as follows, taking inspiration from the work by Metcalf & Madau (2001). We define a field of view of 4 × 4 arcmin² centered on the main halo. We then define a grid over the entire field of view. The resolution of the grid is such that the observed effective radius of the early-type galaxy sources in the absence of magnification is ten grid cells long.

At every grid point, the lensing deflection angle is computed. The contribution of the subclumps is calculated in the following way: the clumps are first assumed to be point masses and the deflection angle generated by each clump is calculated at every grid point. Only for the clumps that lie within the field of view considered is the deflection angle inside the circle of radius r_t then corrected with the expression for the deflection angle of a TSIS lens (Metcalf & Madau 2001) $\mathit{\alpha }\mathrm{\left(}\mathit{x}\mathrm{\right)}\mathrm{=}{\mathit{\alpha }}_{\mathrm{0}}\{\begin{array}{}\\ \frac{\mathrm{1}}{\mathit{a}}\mathrm{-}\sqrt{\frac{\mathrm{1}}{{\mathit{a}}^{\mathrm{2}}}\mathrm{-}\mathrm{1}}\mathrm{+}\arctan \sqrt{\frac{\mathrm{1}}{{\mathit{a}}^{\mathrm{2}}}\mathrm{-}\mathrm{1}}\mathrm{if}\mathit{a}\mathit{<}\mathrm{1}\mathrm{,}\\ \\ \frac{\mathrm{1}}{\mathit{a}}\mathrm{if}\mathit{a}\mathit{>}\mathrm{1}\mathrm{,}\end{array}$(45)where a ≡ xr_c/r_t, x ≡ r/r_c. More simply, a = r/r_t. In contrast to Metcalf & Madau (2001), we calculate once the deflection angle for all the grid points in the field, taking into account the contribution to α of every subhalo in the lens.

Once the map of the deflection angle over the field of view is created, images of early-type galaxies are generated with a uniform distribution on the lens plane.

The effects of the magnification on the image position distribution are neglected, i.e. a uniform distribution in the image plane is adopted. A rigorous treatment of this aspect would require knowledge of the luminosity function of our target galaxies, but this is beyond the goals of this paper. Nevertheless, we explored different scenarios by applying importance sampling to the outcome of our simulations. In particular, we examined two different probability distributions, the first proportional to the magnification, and the other inversely proportional to the magnification. The difference in the results from the uniform case was less than 15%, indicating that our approximation does not alter the conclusions of our study.

Sources are described with circular de Vaucouleurs profiles, truncated at r_e. Images are then constructed in the following way. We define a square in the image plane centered on the adopted location for the image center. The size of this square is chosen so that the length of its sides are a few times the effective radius times the linear stretching (~μ^1/2) produced by the smooth component of the lens. In this way, the observed image is guaranteed to lie within this square. Each pixel inside the square is then mapped to the source plane with the lens equation of the simulated cluster, where the deflection angle is calculated with the procedure described above. Since gravitational lensing preserves surface brightness, the brightness of each pixel in the image plane is taken to be equal to the brightness of the corresponding point in the source plane to which it is mapped. Pixels mapped outside the circle of radius r_e around the center of the source do not belong to the observed image. The observed magnification is then defined as the ratio of the total brightness of the image to that of the source. This gives us the flux magnification, which is equal to the size magnification because of the conservation of surface brightness.

Fig. 5 Strongly lensed image in the proximity of a massive subhalo.

This procedure introduces an error related to the pixelization of the definition of the observed image. The relevance of this error source was checked while running our simulations. We first performed the simulations for a smooth lens without substructures, and compared the magnification measured with the above procedure with the theoretical value of the magnification in the image centroid, given by the model. The results of this test were $\frac{\mathrm{\Delta }\mathit{\mu }}{\mathit{\mu }}\mathrm{=}\mathrm{0.018}\hspace{0.17em}\hspace{0.17em} \frac{\mathit{\sigma }\mathrm{\left(}\mathit{\mu }\mathrm{\right)}}{\mathit{\mu }}\mathrm{=}\mathrm{0.027}\mathit{,}$(46)where Δμ/μ and σ(μ)/μ are the average relative offset and standard deviation between the theoretical and measured magnifications, respectively. The test was performed with a grid resolution such that the length of a pixel is a tenth of r_e. The resulting typical error in the magnification is on the order of a few percent. This is much smaller than the  ~30% error expected for a measurement of the magnification of an early-type galaxy with the use of the FP relation. Given this result, we adopted the same grid resolution for the actual simulations.

In the simulations with substructures, a small fraction of the images display strong lensing features (multiple images, arcs, or rings). This is because the deflection angle for a TSIS lens approaches a finite value as the distance to the center approaches zero, as can be seen from Eq. (45). For such strongly lensed images, the observed magnification calculated with the above method is very different from the magnification obtained with a smooth lens model. These events are rather rare (typically a few per 1000 images). On the other hand, if this situation occurred in an actual observation it would be easily recognized as a strong lensing feature. A highly distorted image, as an arc is, would not be suitable for a FP measurement. Therefore these images are removed from our analysis. An example of discarded image is shown is Fig. 5. In cases like this, we always wish to ensure sure that the arc feature will be recognizable under realistic observing conditions, i.e. that the arc-like shape will not be smeared out by a realistic PSF. In this example the larger arc is a few arcseconds long and can be easily identified.

At the same time, we also took care not to make excessive use of this procedure, for the following reason. The capability of a clump of a given mass to form arcs and multiple images depends on its internal structure. In our model, we assumed TSIS mass profiles, but the real case is likely to be very different. Meneghetti et al. (2003) showed that semi-analytic models with NFW subhalos provide closer agreement with the observed statistics of arcs than models with SIS subclumps. Then, if in our simulation we observed an arc created by a massive subhalo, the same clump with a more realistic internal structure might not have produced an arc but only a highly distorted image whose magnification could have been measured. For these images, the value of the observed magnification is likely to differ significantly from the value inferred by assuming a smooth mass distribution. Thus by eliminating them from the analysis, we would bias the results towards a closer accordance between observed magnifications and smooth model magnifications. This problem is more relevant to the simulations in which clumps are treated as point masses, as they are more capable of producing arcs.

On the other hand, the most significant departures of the observed magnifications from the smooth case are for images in the proximity of the most massive (m > 10¹¹ M_⊙) subclumps. This is in agreement with the work by Meneghetti et al. (2007, see discussion in their Sect. 6.2.1). These are galaxy-scale objects and it is unlikely that they exist only in dark form. In other words, such substructures are likely to be easily identified with a luminous component. Therefore, for an image that lies in the proximity of one of these objects we should be immediately aware that part of the observed magnification could be caused by this substructure, which could equally cause a bias in interpreting this data as a tracer of the smooth component of the cluster. Moreover, a number of gravitational lensing studies have been presented in which the lensing contribution of individual galaxies is incorporated into the analysis (see e.g. Natarajan et al. 2004). Therefore, the same thing could be done for images of early-type galaxies close to cluster member galaxies, which is the situation discussed here.

When multiple images are observed (such as the pair in Fig. 6), we take the magnification measurement obtained with the larger image only. In a realistic situation, if FP measurements were carried out on both the images, it would be relatively easy to label them as a pair and then infer the presence of a substructure. We decided to adopt the more conservative approach in which the observer does not see the counterimage.

Fig. 6 Multiple image system. This image (and others with similar properties) is not discarded, since the shape of the image on the left is not so strongly distorted and in general it may not be recognized as part of a multiple image system. In such cases, only the larger image is considered for the analysis.

5.3. Results

We studied image magnifications with three realizations of simulated clusters, with a mass fraction in substructures f of 0.05, 0.10, and 0.15. For each case, we adopted two different models for the internal structures of the subclumps: TSIS and point mass. For each case we generated N_s = 10   000 sources with the procedure described above. For each source, we studied the observed in the presence of substructure, μ_subs, and the magnification that would be observed with a smooth mass distribution, μ_smooth. In Tables 1 and 2, we report the differences between the measured values of μ_subs and μ_smooth. In particular, we introduce the average relative difference, defined as $\frac{\mathrm{\Delta }\mathit{\mu }}{\mathit{\mu }}\mathrm{\equiv }\frac{\mathrm{1}}{{\mathit{N}}_{\mathrm{s}}}\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{s}}}\frac{{\mathit{\mu }}_{\mathrm{subs}\mathit{,i}}\mathrm{-}{\mathit{\mu }}_{\mathrm{smooth}\mathit{,i}}}{{\mathit{\mu }}_{\mathrm{smooth}\mathit{,i}}}\mathit{,}$(47)and the expected mean relative error $\frac{{\mathit{\sigma }}_{\mathit{\mu }}}{\mathit{\mu }}\mathrm{\equiv }\sqrt{\frac{\mathrm{1}}{{\mathit{N}}_{\mathrm{s}}}\sum _{\mathit{i}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{s}}}{\left(\frac{{\mathit{\mu }}_{\mathrm{subs}\mathit{,i}}\mathrm{-}{\mathit{\mu }}_{\mathrm{smooth}\mathit{,i}}}{{\mathit{\mu }}_{\mathrm{smooth}\mathit{,i}}}\right)}^{\mathrm{2}}}\mathrm{·}$(48)For completeness, we also record the number N_rej of rejected images in each simulation run.

The quantity that is most relevant to our study is the dispersion in the observed magnification around the expected value, σ_μ. As expected, this quantity increases with increasing mass fraction in substructure. However, the values of this dispersion are somehow small. This is rather good news, because it means that the magnification of early-type galaxies is more sensitive to the smooth component of the mass distribution, which accounts for the bulk of the mass, and is therefore a quantity suited to constraining the total mass of the lens.

The case of point mass substructures deserves further discussion. As noted above, point masses are expected to produce larger differences between the observed magnification and μ_smooth. From a first look at the results of Tables 1 and 2, it seems that the opposite situation is realized. However, in the simulation with point mass substructures the number of strongly lensed images that is rejected is larger than in the TSIS case. This means that a significant fraction of the sources whose images are rejected in the point mass case would be included in the analysis if lensed by a model with TSIS substructures. Presumably, the images of these sources are magnified by substructures and they contribute significantly to the value of the measured dispersion. This means that in the TSIS case the observed higher value of the dispersion is determined by a small number (less than 1 in 100) of images, and by excluding them from the analysis we would obtain a dispersion not larger than the one observed in the point mass simulation. This result is in qualitative agreement with the work of Meneghetti et al. (2007). They showed that in a more realistic cluster realization the probability of having a tangential-to-radial magnification (equivalent to observed axis ratio for circular sources) larger than 5 is less than 3% (see Fig. 7 of the cited paper). They also claim that, in their case, substructures account for 30% of the strong lensing cross-section (the smoothed version of their cluster is still a critical cluster, unlike our case), meaning that the above percentage must be scaled accordingly to be compared with our study.

On the basis of these results, we conclude that the magnification of early-type galaxies is little influenced by the presence of substructure. Substructure seems to have a significant effect on the image that we detect only when present in large amounts, which is an unlikely scenario. Current estimates of the mass fraction in substructure based on numerical simulations is tipically f ≲ 0.10 (Tormen et al. 1998; Ghigna et al. 2000). These results provide support for the technique of magnification measurement based on the use of the FP relation, and set a solid basis for the adoption of the technique described in this paper in solving the problem of the mass-sheet degeneracy.

6. Testing the method

The goal of the study presented in this section is to clarify the extent to which the results obtained in Sect. 4 also hold in more realistic situations.

We take a model cluster lens, apply the mass measurement technique to synthetic weak lensing and magnification data simulated for this model, and then analyze the results obtained. In particular, we compare the dispersion in the measurement of the mass obtained in these simulations with the dispersion expected by considering the effects of FP measurements only, obtained from Eq. (36): if the two quantities do not differ substantially, then it means that weak lensing errors do not play an important role and that the theoretical treatment of Sect. 4 can be practically applied.

Before addressing the problem in full, it is interesting to study how the errors in the weak lensing analysis alone influence the estimates of the total mass of the lens. In other words, we wish to clarify the typical error in the estimate of M in the hypothetical case of perfect FP measurements. This situation is simulated first and a realistic case in its full aspects is studied later.

6.1. Simulations

We now describe the ingredients necessary to set up the simulations.

6.1.1. The lens model

We adopt a NIS model to describe the lens. The choice of a smooth model for the lens is suggested by the results of the analysis described in Sect. 5 about the effects of substructures on the magnification of the images of early-type galaxies.

The parameters of the NIS model chosen for this test are the same as those adopted for the description of the smooth component of the lens model used in the simulations of Sect. 5: r_c = 88 kpc and σ_v = 1156 km   s^-1.

6.1.2. Weak lensing data

We base our simulation of weak lensing measurements on the work of Bradac˘ et al. (2004). The procedure adopted is the following:

• we generate background galaxies with a uniform spatialdistribution in a4 × 4 arcmin² field of view (magnification effects on the spatial distribution of images are neglected). Three different values of the number density are chosen: n = 30, 50, and 70 arcmin^-2;

• each galaxy is assigned a redshift, taken from the distribution ${\mathit{P}}_{\mathit{z}}^{\mathrm{\left(}\mathrm{WL}\mathrm{\right)}}\mathrm{\left(}\mathit{z}\mathrm{\right)}\mathrm{\propto }{\mathit{z}}^{\mathrm{2}}{\mathrm{e}}^{\mathrm{-}\mathit{z}\mathit{/}{\mathit{z}}_{\mathrm{0}}}\mathit{,}$(49)where z₀ = 2/3, as suggested by Brainerd et al. (1996). This is a standard choice for weak lensing simulations;

• each background galaxy is then assigned an intrinsic ellipticity drawn from a truncated Gaussian distribution ${\mathit{P}}_{{\mathit{ϵ}}^{\mathit{s}}}\left({\mathit{ϵ}}^{\mathit{s}}\right)\mathrm{=}\frac{\mathrm{1}}{\mathrm{2}\mathit{\pi }{\mathit{\sigma }}_{\mathit{ϵ}}^{\mathrm{2}}\left[\mathrm{1}\mathrm{-}\exp \left(\mathrm{-}\mathrm{1}\mathit{/}\mathrm{2}{\mathit{\sigma }}_{\mathit{ϵ}}^{\mathrm{2}}\right)\right]}\exp \mathrm{\{}\mathrm{-}{\left|{\mathit{ϵ}}^{\mathit{s}}\right|}^{\mathrm{2}}\mathit{/}\mathrm{2}{{\mathit{\sigma }}_{\mathit{ϵ}}^{\mathrm{2}}}^{\mathrm{\}}}\mathit{,}$(50)where σ_ϵ = 0.25. This is also a standard choice for weak lensing simulations (e.g. see Bartelmann et al. 1996; Seitz & Schneider 1997);

• for each galaxy, the resulting ellipticity is calculated from Eq. (9);

• an artificial measurement error is added, so that the resulting measured ellipticity ϵ^m is ${\mathit{ϵ}}^{\mathit{m}}\mathrm{=}\mathit{ϵ}\mathrm{+}{\mathit{ϵ}}^{\mathrm{err}}\mathit{,}$(51)where ϵ^err is a random error generated from a Gaussian distribution with dispersion σ_err = 0.1. In adding the errors, we ensure that |ϵ^m| < 1.

The data are then processed with the finite-field inversion technique of Seitz & Schneider (1997). A grid in the image plane is defined. At each grid point  { i,j } , the average ellipticity ⟨ϵ⟩ is estimated from the observed ellipticities ϵ_k of background galaxies as ${⟨\mathit{ϵ}⟩}_{\mathit{i,j}}\mathrm{=}\sum _{\mathit{k}\mathrm{=}\mathrm{1}}^{{\mathit{N}}_{\mathrm{g}}}{\mathit{ϵ}}_{\mathit{k}}\mathit{W}\mathrm{(}{\left|{\theta }\mathit{i,j}\mathrm{-}{\theta }\mathit{k}\right|}^{\mathrm{)}}\mathit{,}$(52)where W(θ) is a Gaussian with dispersion Δθ, such that nΔθ²  =  12.

6.1.3. FP measurements

After the weak lensing reconstruction, which provides a model density map κ₀(θ) up to the invariance transformation given by Eq. (12), the simulation proceeds with the generation of N_FP = 20 early-type galaxies and the related FP measurements. This is done as follows.

The position of each galaxy is generated randomly with a uniform distribution on the image plane (again, the effects of magnification in the spatial probability distribution of images are not considered). Each galaxy is then assigned a redshift in the range 0.5 < z < 1.0. The upper limit reflects the redshift limit reached by the FP measurements carried out so far. The lower limit instead is set because the lensing signal for sources too close to the lens is too low. The simulation also requires a specification of the shape of the redshift distribution of the observed early-type galaxies, ${\mathit{P}}_{\mathit{z}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{\left(}\mathit{z}\mathrm{\right)}$. This quantity depends on the intrinsic luminosity function of early-type galaxies, which in general varies with redshift, and also on the object selection procedure. Given these uncertainties, for our simulations we adopted a uniform distribution to reduce the computational effort. It is also assumed that no error is introduced in the determination of the individual redshifts.

For each early-type galaxy, the quantity $\sqrt{\mathrm{1}\mathit{/}\mathit{\mu }}\mathrm{=}{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathit{/}{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{obs}\mathrm{\right)}}$ is then generated from a Gaussian distribution with 15% dispersion, centered on the true value given by the model. This dispersion should reflect the observed scatter in r_e of the FP relation. In our case, we adopted an optimistic estimate of this latter quantity.

6.2. Results

Under the observation conditions described above (N_FP = 20), the expected dispersion in the estimate of the total mass of the lens, calculated from Eq. (36) and therefore ignoring weak lensing errors, is ${\mathit{\sigma }}_{\exp }\mathrm{=}\frac{\mathit{\sigma }\mathrm{\left(}\mathit{M̂}\mathrm{\right)}}{\mathit{M}}\mathrm{=}\mathrm{0.21}\left(\frac{{\mathit{\sigma }}_{\mathrm{FP}}}{\mathrm{0.15}}\right)\mathit{,}$(53)where σ_FP is the dispersion in r_e of the FP, averaged over redshift.

To more accurately quantify the effects of weak lensing, the simulations were first performed in the hypothetical case of perfect magnification measurements $\mathrm{(}{\mathit{\kappa }}_{\mathit{i}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{=}\mathit{\kappa }\mathrm{(}{\theta }{}_{\mathit{i}}\mathrm{\left)}\mathrm{\right)}$, from which we obtained an estimate of the dispersion in the measurement of the total mass introduced by weak lensing errors only. The results of the simulations relative to this particular case are presented in Sect. 6.2.1, while in Sect. 6.2.2 we report those obtained in a more realistic situation, in which the simulated magnification measurements have a 30% dispersion.

We consider a mass density map κ_WL(θ) obtained from weak lensing and transformed with Eq. (12) to reproduce the exact value of the lens mass within the field of view. Since weak lensing reconstructions typically produce smoothed density maps, we expect κ_WL(θ) to underestimate the surface mass density in the central parts of the lens, and to be higher than the true value in the outer parts. This is indeed what is observed in the simulations: in Fig. 7, we plot the difference κ_WL(θ) − κ(θ) for an example case of weak lensing reconstruction.

This property has some consequences for the process of fitting the density map to FP measurements. Since the expectation value of κ^(FP) is approximately the true surface mass density, measurements close to the center will tend to give estimates κ^(FP) higher than κ_WL(θ) and therefore will bias the measurement of the total mass towards higher values (recalling that κ_WL(θ) was defined as the density map that corresponds to the correct value of the mass). In contrast, FP measurements in parts of the lens plane where κ_WL − κ > 0 will tend to bias the mass towards lower values. Thus, if we distribute the sources uniformly we expect that this potential source of bias can be overcome statistically. This effect is more evident when there is no error in κ^(FP): in that case, the errors in the estimate of the total mass are only due to errors in the weak lensing analysis.

Fig. 7 Contour plot of the difference κWL(θ) − κ(θ), where κ(θ) is the true surface mass density of the lens and κWL(θ) is a weak lensing reconstruction of the lens yielding the same total mass. In the central region the reconstructed profile underestimates the surface mass density, while in a significant region of the image plane the opposite case occurs.

6.2.1. Ideal case: perfect magnification measurements

A thousand simulation runs were performed for three different values of the number density of background galaxies: n = 30, 50, 70 arcmin^-2, and two different numbers of FP measurements: N_FP = 1 and N_FP = 20.

In Tables 3 and 4, the relative mean errors and dispersion σ(M)/M obtained in these simulations are reported. As expected, the error in the determination of the total mass decreases as the number density of background galaxies increases. However, the dependence of σ(M) on n is mild: this means that the number density of background galaxies is not a critical factor in the effectiveness of the method. It can also be seen that with a single magnification measurement the total mass is poorly constrained, as expected. This result indicates that with a single local estimate of the surface mass density, regardless of how accurate, it is difficult to break the mass-sheet degeneracy.

On the other hand, in the case of N_FP = 20 FP measurements the dispersion is only a few percent.

Another significant result is that there is practically no bias in the estimate of the total mass (ΔM/M ≃ 0). This result is clearly a consequence of the assumption of a uniform spatial distribution for the FP measurements. If we manage to select a sufficient number of early-type galaxies more or less uniformly distributed in the field of view there is a good chance that the final measurement of the mass will be unbiased. This is a great advantage of the present technique with respect to the use of strong lensing information. Strong lensing features are typically limited to the central regions of clusters. Since the surface mass density in the central parts of a cluster obtained from weak lensing is typically underestimated, the inclusion of strong lensing data might then lead to higher estimates of the total mass. With the present method, this effect can be kept under control.

In principle, substructures can also introduce noise into the weak lensing signal. The nonparametric reconstruction method used here can recover features on the scale of the smoothing length or larger, as shown by Seitz & Schneider (1997). However, King et al. (2001) and Clowe et al. (2004) showed that the effects of small-scale substructures are of modest importance for weak lensing measurements. Therefore we can conclude that the results presented here do not depend on our choice of a simplified cluster model.

Additional noise in the weak lensing measurements can be introduced by the presence of uncorrelated large-scale structure along the line of sight. This was studied extensively by Hoekstra (2003). He found that the contribution of structures not associated with the cluster is significant at large radii, but is negligible for the relatively small fields of view considered in our work (a few arcminutes).

6.2.2. The realistic case

Finally we report the results of the simulations performed in the most general case, in which realistic conditions for both the weak lensing and the FP measurements are simulated. In this case the simulations are performed for n = 30, 50, 70 arcmin^-2 and N_FP = 20. In Table 5, the results for 1000 simulation runs are reported.

The results confirm the picture that emerged in Sect. 6.2.1: weak lensing errors play little role in determining the final dispersion in the estimate of the total mass. The observed dispersion is practically equal to the one obtained in Eq. (53) by assuming perfect weak lensing measurements. This test, although limited to a single lens model, confirms that it is possible, with a sufficient number of FP measurements uniformly distributed across the image plane, to break the mass-sheet degeneracy, at least for Coma cluster-like lenses at intermediate redshift.

Finally, to more clearly illustrate the effect of a cluster on lensed early-type galaxies, we show in Fig. 8 a set of simulated FP measurements, compared with the FP relation expected in the absence of lensing. We consider N_FP = 20 objects in the redshift interval 0.5 < z < 1.0 generated and placed randomly behind the same cluster lens used for the previous simulations. In constructing this plot, we assumed local values of the FP coefficients (α = 1.25, β = 0.32, γ =  −8.970 (Jørgensen et al. 1996; recomputed for H₀ = 65 km   s^-1   Mpc^-1 by Treu et al. 2005), corrected for evolution following Treu et al. (2005): γ(z) = γ(0) + 0.58z. The scatter in the FP is assumed to be 20% in r_e. The signature of the lensing signal can clearly be seen as an upward shift in the FP space.

Fig. 8 NFP = 20 simulated FP measurements, plotted in FP space. The straight line is the FP expected in the absence of lensing, viewed edge-on. Positions in the FP space are corrected for the evolution of the FP with redshift, following Treu et al. (2005).

7. Conclusions and discussion

We have presented a new lensing-based method for the measurement of the mass of galaxy clusters. This method relies on the joint use of weak lensing data and magnification information, where the latter is obtained from FP measurements of background early-type galaxies.

A statistical study of the method was carried out, and simulations were performed to test the importance of the presence of substructures and of errors in the weak lensing analysis on the success of the measurement.

Our main conclusions are the following:

• The most important quantity on which the effectiveness of themethod depends is the mean surface mass density within the fieldof view of observation, , while little role is played by the shape of the mass distribution.

• Substructures contribute the most with a scatter of a few percent in individual magnification measurements.

• Weak lensing errors introduce only a small dispersion into the final estimate of the total mass.

On the basis of these results, we now discuss the best lens candidates for an application of the present technique.

An important limit to the applicability of this method is the difficulty in performing FP measurements, since they require a significant amount of telescope time. A realistic number of FP measurements that can be performed in an observational campaign is  ~20. Given this, we can fix N_FP = 20 and discuss which systems can be most practically analyzed with this number of magnification measurements.

One of the most important factors in determining whether a cluster can be realistically studied with our technique or not is its redshift. The redshift must be sufficiently high for the critical density to be low enough, to allow for higher values of κ for a given physical surface mass density. On the other hand, the redshift must also be sufficiently low to ensure that there is an acceptable number of early-type galaxies behind the cluster for which FP measurements can be performed. The current observational capabilities and the lack of a calibration of the FP relation at very high redshifts set z ~ 1.0 as the highest redshift for which these measurements can be performed today.

Bearing this in mind, we plot in Fig. 9 the value of the critical density as a function of source redshift for three different values of the lens redshift. It can be seen that with a lens redshift z_d = 0.1 the resulting critical density is significantly higher than in the other cases at the source redshifts of interest and for this reason this case should be discarded. At the opposite end, for a lens redshift z_d = 0.4 the critical density is indeed the smallest for source redshifts higher than  ~0.8, but the range of source redshifts for which the critical density is significantly low is limited to z_s > 0.6, and shrinks rapidly for increasing z_d. On the basis of these simple considerations, we conclude that a suitable redshift range for our lens cluster is z_d ~ 0.2−0.4. A thorough analysis of the problem would require a detailed knowledge of the redshift distribution of the observable early-type galaxies.

Fig. 9 Critical density (in kg m-2) as a function of source redshift for three different values of the lens redshift: zd = 0.1,   0.2,   0.4.

We can then ask which intrinsic physical characteristics a cluster should have to be efficiently probed with FP measurements.

If we assume, conservatively, a mean dispersion in the FP relation of 20% in r_e, it can be shown from Eq. (36) that to obtain a mass estimate with a precision of 20% or better with N_FP = 20 FP measurements with a uniform distribution in redshift between z = 0.5 and z = 1.0, the average surface mass density of the lens should be .

The quantity clearly depends on the mass distribution of the lens but also on the size of the field of observation, which is set by the observer. How critical is the choice of this latter quantity for determining a value ? One can always restrict the observations to the inner regions of a given cluster, to increase . However, there is a limit set by the number density of background early-type galaxies for which FP measurements can be effectively performed. This number density was estimated in BL06 to be  ~2 arcmin^-2. Therefore, if we wish to find N_FP = 20 objects suitable for our purposes, we need to cover a field of view of 10 arcmin².

At this point, we can try to determine the minimum mass a cluster should have in order to have a mean surface mass density within a circle of area A = 10 arcmin² (and radius ${\mathit{\theta }}^{\mathrm{\ast }}\mathrm{=}\sqrt{\mathrm{10}\mathit{/}\mathit{\pi }}\mathrm{\simeq }\mathrm{1.8} \mathrm{arcmin}$). Fixing the lens redshift z_d = 0.3, this value of the surface mass density within the circle corresponds to a value of the enclosed projected mass equal to M_enc = 4.2 × 10¹⁴ M_⊙. For a NFW profile with concentration parameter c = 10, this value corresponds to a limiting virial mass ${\mathit{M}}_{\mathrm{200}}^{\mathrm{\ast }}\mathrm{=}\mathrm{8.0}\mathrm{\times }{\mathrm{10}}^{\mathrm{14}} {\mathit{M}}_{\mathrm{\odot }}\mathit{,}$(54)and similar values hold for different values of the concentration c. The quantity ${\mathit{M}}_{\mathrm{200}}^{\mathrm{\ast }}$ is the minimum mass a NFW cluster should have in order to satisfy within a circle of area A = 10 arcmin² in the sky. In that case, the mass of the cluster within the circle could be measured with a 20% or better precision with 20 FP measurements and a weak lensing analysis.

If we wish to extend the analysis to the outer parts of a cluster, we must increase the number of FP measurements, to compensate for the lower average surface mass density .

If we wish to improve the sensitivity to less massive clusters, we must either increase the number of FP measurements for a fixed aperture or choose a smaller aperture for fixed N_FP. In any case, a higher number density of sources is needed, which cannot be obtained without an improvement in the observational capabilities. This shows that the number density of observable sources is indeed a key factor and confirms that the lens redshift should not be too high.

A possible alternative strategy is to select only the brighter objects, since it has been recognized that the FP scatter decreases with increasing mass (Treu et al. 2005; van der Wel et al. 2005): this would allow a more precise estimate of the magnification for a given lens and fixed number of FP measurements. The feasibility of this approach would depend critically on the number density of background sources.

On the basis of this discussion, we conclude that the value of ${\mathit{M}}_{\mathrm{200}}^{\mathrm{\ast }}$ given by Eq. (54) is an estimate of the minimum mass a cluster should have to allow for a mass measurement with the present method. The value is on the high side, but there are indeed many clusters that have observed values of M₂₀₀ higher than this threshold. Well-studied examples are A1689, A1703, A370, and RX J1347-11 (see Broadhurst et al. 2008 for a review). All these systems display strong lensing features that allow for a good estimate of the mass distribution in the inner (θ < 1 arcmin) regions of the clusters. One might believe that the availability of strong lensing data would rule out the need for other observations in such clusters. Nevertheless, the addition of FP measurements can greatly enhance the tightness of any constraints on the mass distribution within a radius at least two times larger.

In summary, the method presented in this paper is, because of its nonparametric form, a potentially powerful tool for breaking the mass-sheet degeneracy in lensing studies of clusters of galaxies. As shown in Sect. 4, it also allows for a relatively easy estimate of the accuracy of the total mass measurement.

In addition, the method can be extended by allowing the inclusion of magnification measurements obtained by different means, for example from the observation of type Ia supernovae (see, e.g., Holz 2001; Goobar et al. 2002; Jönsson et al. 2010). The statistical framework developed in this paper can be applied with little effort to these more general situations, and therefore can be used as a reference framework to estimate the degree of precision of other methods that rely on the combination of weak lensing and magnification measurements.

References

Appendix A: Probability distribution of the estimates of κ_FP

Here we will discuss the choice of a Gaussian probability distribution for the estimates κ_FP of the surface mass density obtained by combining FP and weak lensing measurements. The observable quantity is the ratio $\mathit{r}\mathrm{\equiv }{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathit{/}{\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{obs}\mathrm{\right)}}$ of the galaxy effective radius inferred from the FP relation to the observed (magnified) effective radius. Of these two quantities, the first, with its 15% dispersion, is by far the one with the larger uncertainty. Thus, if the probability distribution of the estimate of ${\mathit{r}}_{\mathrm{e}}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}$ is Gaussian, the ratio r will have a nearly Gaussian distribution as well. Let us assume this is the case.

The surface mass density κ^(FP) at the image position can be expressed as a function of magnification μ, galaxy redshift z and average distortion ⟨ϵ⟩, as in Eqs. (17)–(19). We assume that no error comes from the measurements of z and ⟨ϵ⟩, in accordance with the hypotheses of Sect. 4. The only error source is then the measurement of the magnification. Note that, if κ^(FP) depends linearly on the ratio r, then κ^(FP) will also have a Gaussian probability distribution. However, the dependence of κ^(FP) on magnification is more complicated than a simple linear relation. In reality, κ^(FP) is given by ${\mathit{\kappa }}^{\mathrm{\left(}\mathrm{FP}\mathrm{\right)}}\mathrm{=}\frac{\mathrm{-}\mathit{b}\mathrm{-}\sqrt{{\mathit{b}}^{\mathrm{2}}\mathrm{-}\mathit{a}\left(\mathit{c}\mathrm{-}{\mathit{r}}^{\mathrm{2}}\right)}}{\mathit{a}}\mathrm{·}$(A.1)Now, if the condition ${\mathit{b}}^{\mathrm{2}}\mathrm{-}\mathit{ac}\mathrm{\ll }\mathit{a}{\mathit{r}}^{\mathrm{2}}$(A.2)holds, then the square root can be approximated by $\sqrt{{\mathit{b}}^{\mathrm{2}}\mathrm{-}\mathit{ac}\mathrm{+}\mathit{a}{\mathit{r}}^{\mathrm{2}}}\mathrm{\approx }\sqrt{\mathit{a}}\mathit{r}$(A.3)and (A.1) becomes linear. As a consequence, the Gaussianity of r translates into the Gaussianity of κ^(FP). At this point, we need to demonstrate the validity of Eq. (A.2). The ratio r is typically of order 1, unless there are large magnifications. Thus, it is sufficient to prove that b² − ac ≪ a. We begin by noting that $\mathit{a}\mathrm{~}{\mathit{Z}}_{\mathit{i}}^{\mathrm{2}}\mathrm{[}\mathrm{1}\mathrm{-}\mathit{O}\mathrm{(}\mathrm{|}\mathrm{⟨}\mathit{ϵ}\mathrm{⟩}{\mathrm{|}}^{\mathrm{2}}\mathrm{)}\mathrm{]}$. The quantity |⟨ϵ⟩| is typically small, except in the proximity of critical curves, while the combination of weights that multiplies |⟨ϵ⟩|² in a is on the order of unity. Similarly, b ~ Z_i [1 − O(|⟨ϵ⟩|²)] and c ~ 1 − O(|⟨ϵ⟩|²). The quantity b² − ac is then on the order of ${\mathit{Z}}_{\mathit{i}}^{\mathrm{2}}\mathit{O}\mathrm{\left(}\mathrm{\right|}\mathrm{⟨}\mathit{ϵ}\mathrm{⟩}{\mathrm{|}}^{\mathrm{2}}\mathrm{)}\mathrm{\ll }\mathrm{1}$. Since the

right-hand side of Eq. (A.2) is on the order of unity, Eq. (A.2) is satisfied. This implies that the dependence of κ^(FP) on r is approximately linear. If the probability distribution of r is Gaussian, which is reasonable, the same applies to κ^(FP).
