SEREN – a new SPH code for star and planet formation simulations
Algorithms and tests^{⋆}
^{1}
Department of Physics and AstronomyUniversity of Sheffield, Hicks Building, Hounsfield Road, Sheffield S3 7RH, UK
email: D.Hubber@sheffield.ac.uk
^{2}
School of Physics and Astronomy, Cardiff University, Queens Buildings, The Parade, Cardiff, CF24 3AA, Wales, UK
^{3}
Institute for Theoretical Astrophysics, University of Oslo, Pb 1029 Blindern, 0315 Oslo, Norway
^{4}
Centre of Mathematics for Applications, University of Oslo, Pb 1053 Blindern, 0316 Oslo, Norway
^{5} Astronomical Institute, Academy of Sciences of the Czech Republic, Boční II 1401, 141 31 Praha 4, Czech Republic
Received: 6 May 2010
Accepted: 29 January 2011
We present SEREN, a new hybrid Smoothed Particle Hydrodynamics and Nbody code designed to simulate astrophysical processes such as star and planet formation. It is written in Fortran 95/2003 and has been parallelised using OpenMP. SEREN is designed in a flexible, modular style, thereby allowing a large number of options to be selected or disabled easily and without compromising performance. SEREN uses the conservative “gradh” formulation of SPH, but can easily be configured to use traditional SPH or Godunov SPH. Thermal physics is treated either with a barotropic equation of state, or by solving the energy equation and modelling the transport of cooling radiation. A BarnesHut tree is used to obtain neighbour lists and compute gravitational accelerations efficiently, and an hierarchical timestepping scheme is used to reduce the number of computations per timestep. Dense gravitationally bound objects are replaced by sink particles, to allow the simulation to be evolved longer, and to facilitate the identification of protostars and the compilation of stellar and binary properties. At the termination of a hydrodynamical simulation, SEREN has the option of switching to a pure Nbody simulation, using a 4thorder Hermite integrator, and following the ballistic evolution of the sink particles (e.g. to determine the final binary statistics once a star cluster has relaxed). We describe in detail all the algorithms implemented in SEREN and we present the results of a suite of tests designed to demonstrate the fidelity of SEREN and its performance and scalability.
Key words: hydrodynamics / methods: numerical / stars: formation
Further information and additional tests of SEREN can be found at the webpage http://www.astro.group.shef.ac.uk/seren.
© ESO, 2011
1. Introduction
Star formation problems are amongst the most demanding in computational astrophysics, requiring a large number of physical processes to be modeled (e.g. hydrodynamics, selfgravity, optically thick radiative cooling, gas chemistry, ionization, gasion coupling, magnetohydrodynamics, radiative and mechanical feedback) over a very large range of physical conditions (i.e. gas densities from ~ 10^{20} g cm^{3} to ~ 10^{ + 1} g cm^{3}, and gas temperatures from ~ 10 K to ~ 10^{7} K). It is nontrivial to include all of the above physics in a single code which works over such a wide range of physical conditions and produces accurate results in an efficient manner. There are also often multiple methods available to model these processes, and one must choose the most appropriate and/or optimal method to study a given problem. The principal choice is whether to use an Eulerian gridbased code to simulate the fluid dynamics, or a Lagrangian particlebased code. Gridbased schemes are capable of modelling incompressible fluid dynamics accurately and efficiently, but for highly compressible fluids, where the density can take a large range of values, expensive adaptivemeshrefinement techniques are required. Particlebased schemes, such as smoothed particle hydrodynamics, do not model hydrodynamical processes as well as gridbased schemes (Agertz et al. 2007), but they can model highly compressible fluids through a large range of scales with ease. This makes particle codes well suited to modelling selfgravitating fluids such as those involved in star formation. A number of publicly available codes using either static or adaptivemeshrefinement grids (e.g. ZEUS, Stone & Norman 1992;FLASH, Fryxell et al. 2000; RAMSES, Teyssier 2002; ENZO, Abel et al. 2002) or particles (e.g. GADGET, Springel et al. 2001; GADGET2, Springel 2005; VINE, Wetzstein et al. 2009; Nelson et al. 2009) are available, and have been applied to a variety of different phenomena in interstellar gas dynamics, star and galaxy formation, and cosmology.
Here we present SEREN, a new multidimensional selfgravitating hydrodynamics and Nbody code. SEREN uses the smoothed particle hydrodynamics (SPH) algorithm to model fluid dynamics, in combination with treegravity and hierarchical blocktimestepping routines. It also includes a variety of specialist routines designed to tackle star and planet formation problems, such as sink particles (Bate et al. 1995), and a 4th order Hermite Nbody integrator (Makino & Aarseth 1992) to follow the ballistic evolution of a star cluster once its gas has been accreted or dispersed.
The purposes of this paper are (i) to describe the algorithms implemented in SEREN, and (ii) to demonstrate the fidelity of SEREN – i.e. that the algorithms are coded correctly and reproduce known results in tests, so that future publications presenting simulations performed with SEREN can refer to this paper for a full description of the code. In Sect. 2, we give a brief overview of SEREN and all of its main features,and compare these features with those available in other available astrophysical SPH codes. In Sect. 3, we describe in detail the SPH algorithms used. In Sect. 4, we describe the implementation of selfgravity in SPH. In Sect. 5, we briefly discuss the available thermal physics modules, including the transport of heating, cooling and ionizing radiation. In Sect. 6, we discuss the integration schemes and timestepping criteria. In Sect. 7, we discuss the implementation of sink particles. In Sect. 8, we discuss the 4th order Hermite Nbody integrator and the additional features contained within it (e.g. binary identification). In Sect. 9, we discuss the implementation of the BarnesHut tree, and how it is used to determine neighbour lists and calculate gravitational accelerations. In Sect. 10, we present a large suite of tests, to demonstrate that SEREN simulates correctly the physical processes it is intended to capture. In Sect. 11, we discuss the memory optimisations used. In Sect. 12, we discuss the techniques used to parallelise SEREN using OpenMP, and we demonstrate how SEREN scales on sharedmemory machines. In Sect. 13, we outline the major features that are still to be implemented.
2. Overview of SEREN and other codes
SEREN is a multidimensional selfgravitating SPH and Nbody code. It has been designed for star and planet formation problems, but it can easily be adapted to simulate other astrophysical phenomena. SEREN is written in Fortran 95 (with some Fortran 2003 features) and is parallelised using OpenMP. It is written in a highly modular style, with a large number of features that can be switched on or off using Makefile options and conditional compilation flags. It can be compiled for one, two or threedimensions, although it is most optimal in threedimensional mode. We list here the main algorithms and features included in SEREN:

standard SPH (e.g. Monaghan 1992), “gradh” SPH (Springel & Hernquist 2002; Price & Monaghan 2004b), and Godunov SPH(Inutsuka 2002; Cha & Whitworth 2003);

kernelsoftened selfgravity (Price & Monaghan 2007b);

artificial dissipation (Lattanzio & Monaghan 1985; Balsara 1995; Monaghan 1997; Morris & Monaghan 1997; Price 2008);

2ndorder RungeKutta, 2ndorder PredictorCorrector and 2ndorder kickdriftkick and driftkickdrift Leapfrog integration schemes;

hierarchical block timestepping (e.g. Hernquist & Katz 1989);

periodic boundary conditions, including periodic gravity (Hernquist et al. 1991; Klessen 1997);

several particle types: selfgravitating gas particles, nongravitating intercloud particles, static or nonstatic boundary particles;

octalspatial trees for neighboursearching and gravity (Barnes & Hut 1986; Pfalzner & Gibbon 1996);

simple isothermal, polytropic or barotropic equations of state, solution of the energy equation with associated radiation transport (Stamatellos et al. 2007), and propagation of ionizing radiation using HEALPix rays (Bisbas et al. 2009);

sink particles (Bate et al. 1995);

4th order Hermite Nbody integrator (Makino & Aarseth 1992);

identification of binaries and calculation of binary properties (e.g. Aarseth 2003).
We control which algorithms are used in SEREN using Makefile options, so only the employed subroutines are compiled and included in the executable file. The parameters which determine how the selected algorithms function are set in a separate parameters file. In Sects. 3 to 9, we describe in more detail the implementation of these algorithms in SEREN.
Several other SPH codes are available to the astrophysics community for performing simulations of selfgravitating hydrodynamics. While these codes share a common set of basic features, most contain specialised algorithms to model certain astrophysical processes, or are optimised to perform a particular class of simulation. We briefly discuss the algorithms and features in other available astrophysical SPH codes, in order to highlight to potential users the relative merits of each code for solving particular problemsand how they contrast with the features implemented in SEREN. We only discuss here those codes that have a refereed or archived publication containing details of the implementation and tests.
2.1. GADGET and GADGET 2
GADGET (Springel et al. 2001) and GADGET 2 (Springel 2005) are written in C and parallelised using MPI. While the original GADGET code was designed to investigate galaxy formation problems, GADGET 2 was designed to investigate largescale cosmological problems such as galaxy cluster formation and the formation of structure in the Universe (e.g. Springel et al. 2005). MPI can be used very efficiently when the work distributed to all CPUS is automatically loadbalanced. Therefore, the approximately uniform (largescale) density distribution used in cosmological simulations is a problem that an MPI code like GADGET 2 can handle efficiently on very large clusters with 1000 s of CPUs (e.g. Springel 2005). GADGET 2 uses a PeanoHilbert spacefilling curve in order to determine how to distribute the particles amongst the available processors. This improves the scalability, by reducing communication overheads. GADGET 2 uses a conservative SPH formulation combined with solving the entropy equation for the thermal physics (Springel & Hernquist 2002). Particle properties can be integrated using either a LeapfrogKDK or LeapfrogDKD integration scheme, in combination with a hierarchical blocktimestep scheme. The calculation of gravitational forces is split into short and longrange computations; short range forces are computed using a BarnesHut tree (which is efficient for clumpy density distributions), and longrange forces are computed using a particlemesh scheme (which is efficient for smoother density distributions). GADGET 2 contains the ability to model several different particle types relevant to galaxy and cosmology simulations, namely gas, colddark matter and star particles. Star particles usually represent a whole cluster of stars, in comparison to sink particles in SEREN which represent individual stars, or unresolved small, multiple systems.
2.2. GASOLINE
GASOLINE (Wadsley et al. 2004) is written in Fortran and is parallelised for sharedmemory machines. GASOLINE uses the standard formulation of SPH (e.g. Monaghan 1992) with (α, β) viscosity (Monaghan & Gingold 1983) and a Balsara switch (Balsara 1995) for reducing unwanted shear viscosity. GASOLINE can use two separate trees; a KD tree for neighbour searching and a BarnesHut octal tree (Barnes & Hut 1986) for calculating gravitational forces. The code computes multipole moments up to hexadecapoleorder to compute gravitational forces efficiently, but only uses the geometrical MAC for evaluating the cellinteraction list. Ewald summation is also available for simulating periodic boxes. GASOLINE contains a number of options for treating thermal physics, including an implicit integrator for solving the energy equation. A number of cooling and ionisation processes can be selected, as well as a simple heatingfeedback prescription due to star formation. GASOLINE uses a LeapfrogKDK integration scheme for advancing particle positions and velocities, along with a standard hierarchical blocktimestep scheme.
2.3. VINE
VINE (Wetzstein et al. 2009; Nelson et al. 2009) is written in Fortran 95 and parallelised using OpenMP. As with GADGET and GADGET 2, VINE has been designed to investigate galaxy and cosmological problems. VINE has also been parallelised using OpenMP. It has been tested on up to 128 CPUs and scales well provided the problem size is large enough. VINE uses a nearestneighbour binary tree (e.g. Benz et al. 1990) to compute gravitational forces and to search for neighbours efficiently. VINE also has the facility to use GRAPE boards (e.g. Makino et al. 2003) and thus can significantly speed up the calculation of the gravitational forces for particular problems. VINE does not use a conservative form of SPH, but rather uses the traditional form of SPH (Monaghan 1992). VINE contains a variety of particle types similar to GADGET 2, such as gas, colddark matter and star particles.
2.4. MAGMA
MAGMA (Rosswog & Price 2007) is an Smoothed Particle Magnetohydrodynamics (SPMHD) code which is parallelised using OpenMP. MAGMA has been designed to model compact objects, such as binaryneutron stars. MAGMA uses the conservative “gradh” SPH scheme for computing hydro and gravitational forces, and “Euler potentials” for solving the ideal MHD equations; this enforces div B = 0 by design. The code includes dissipative artificial viscosity, conductivity and resistivity terms, with switches such as timedependent viscosity (Morris & Monaghan 1997) for reducing dissipation. Thermal physics includes an equationofstate for modelling the nucleon fluid at supernuclear densities, and a method for modelling neutrino emission. No additional particle types (e.g. sink particles) are included. Gravitational forces are computed with a binary tree (Benz et al. 1990) and particleparticle interactions are computed with kernelsoftened gravity (Price & Monaghan 2007b). Particle positions and velocities are integrated with a secondorder predictorcorrector scheme, using an individual timestep scheme.
2.5. EvoL
EvoL (Merlin et al. 2010) is written in Fortran 95 and is parallelised using MPI. EvoL was designed to investigate cosmological structure, galaxycluster and galaxy formation problems, similar to GADGET 2 and VINE. As with other galaxy/cosmological codes, EvoL can model selfgravitating gas, cold dark matter and star particles. EvoL models the gasdynamics using a modified “gradh” SPH formulation, and also contains terms that correct for unequalmass particles. Gravity is calculated using a BarnesHut tree, and neighbouring particle gravitational forces are computed with a conservative scheme similar to Price & Monaghan (2007b), but using the number density instead of the mass density, which again is beneficial when using unequal mass particles. EvoL uses a LeapfrogKDK scheme for integrating particle positions and velocities. A standard hierarchical blocktimestep scheme is employed, along with the instantaneous timestepreduction procedure (Saitoh & Makino 2009) to ensure the timesteps used for neighbouring particles are not greatly different. EvoL also contains the ability to evolve the particle positions using the XSPH method (e.g. Monaghan 1992) which can prevent particle interpenetration.
3. Smoothed particle hydrodynamics
SPH is a Lagrangian hydrodynamics scheme which uses particles to represent the fluid (Gingold & Monaghan 1977; Lucy 1977). SEREN contains three different variants of SPH: the standard implementation (Monaghan 1992), the conservative “gradh” implementation (Springel & Hernquist 2002; Price & Monaghan 2004b) and the Godunov implementation (Cha & Whitworth 2003; Eqs. (9), (10)). The “gradh” implementation is the favoured, default implementation in SEREN.
In SPH, particle properties are smoothed over a length scale, h, called the smoothing length, using a weighting function, W(r,h), called the kernel function. The fluid is thus still a continuous medium despite being represented by a finite number of discrete particles. The volume over which a particle is smoothed is called its smoothing kernel. Particle i interacts hydrodynamically with all other SPH particles, j, that lie inside the smoothing kernel of i (gather), and/or whose own smoothing kernels overlap i (scatter). These particles are referred to as the neighbours of i. The smoothing length determines the spatial resolution and can in principle be set to any value. The simplest choice is to keep h uniform in space and constant in time, throughout the simulation. However, to take advantage of the Lagrangian nature of SPH, it is often desirable to set the smoothing length of an SPH particle to be of order the local mean particle separation. The resolution then automatically adapts to the local conditions, providing an adaptability that is much more difficult to achieve with grid codes. SEREN contains two choices for the kernel function, both of which have finite extent, r_{MAX} = ℛh: the M4 cubic spline kernel (Monaghan & Lattanzio 1985) with ℛ = 2, and the quintic spline kernel (Morris 1996) with ℛ = 3. Detailed properties of these kernels are given in Appendix A.
Since “gradh” is the default implementation of SPH in SEREN, we briefly describe its main features here. In order to guarantee conservation of momentum, angular momentum and energy, the SPH fluid equations are derived from the EulerLagrange equations. This requires that the smoothing length of a particle be either constant, a function of the particle’s coordinates, or a function of some property that is itself a function of the particle’s coordinates. We follow Springel & Hernquist (2002) and Price & Monaghan (2004b) in making the smoothing length a function of the density. Specifically, for particle i we put (1)where m_{i} is the mass of particle i, ρ_{i} is the SPH density at the position of particle i, D is the spatial dimensionality, and is a parameter that controls the mean number of neighbours, in one, two and three dimensions respectively. ρ_{i} is calculated using (2)where r_{ij} ≡ r_{i} − r_{j}, and the summation includes particle i itself. Since the smoothing length is needed in order to calculate the density in Eq. (2) and vice versa in Eq. (1), h_{i} and ρ_{i} are obtained by iteration.
Once h and ρ are evaluated for all particles, the terms in the SPH fluid equations can be computed. The momentum equation is (3)where P_{i} is the pressure of particle i, ∇_{i}W is the gradient of the kernel function at the position of particle i, and (4)Ω_{i} is a dimensionless quantity that corrects for the spatial variability of h. ∂h_{i}/∂ρ_{i} is obtained explicitly from Eq. (1). ∂W/∂h is obtained from the kernel function (see Appendix A). The SPH energy equation is (5)where v_{ij} ≡ v_{i} − v_{j}. Since the mass of each particle is constant, and the density is computed using Eq. (2), there is no need to solve the SPH continuity equation.
The summations in Eqs. (2)–(5) are formally over all particles in the simulation. However, since the kernels used in SEREN both have finite extent, the summations are actually only over the neighbours of particle i. SEREN uses a BarnesHut tree (Barnes & Hut 1986) to obtain neighbour lists. The procedures for constructing and walking the tree are described in Sect. 9.
3.1. Artificial viscosity and conductivity
In most formulations of SPH, artificial viscosity terms are needed to ensure that shocks are captured, i.e. that converging particle streams do not interpenetrate, but rather form a contact discontinuity, and that kinetic energy is converted into thermal energy at the shock, thereby generating entropy. SEREN includes two different forms of artificial viscosity: the standard (α,β) formulation (Monaghan & Gingold 1983), and the formulation based on Riemann solvers (Monaghan 1997). The MonaghanRiemann formulation is the default in SEREN, and involves adding the following extra terms to the momentum and energy equations, where α and α′ are user specified coefficients of order unity, and are signal speeds, , and (8)This form of artificial dissipation is chosen as the default because (a) it has a physically informed motivation; and (b) it can be generalised to model dissipation in other quantities while giving just as good results as the standard (α, β) viscosity when modelling shocks. The dissipation term on the righthand side of Eq. (6) and the first term on the righthand side of Eq. (7) represent artificial viscosity – i.e. exchange of momentum between neighbouring particles which are approaching or receding from one another, and conversion of the kinetic energy lost into thermal energy – and they are moderated by the signal speed . The second term on the righthand side of Eq. (7) represents artificial conductivity, and acts to smooth out gradients in the specific internal energy. For purely hydrodynamic simulations, Price (2008) advocates that the artificial conductivity be moderated by the signal speed (9)However, in selfgravitating simulations this can drain thermal energy from dense condensations, thereby artificially accelerating gravitational contraction. Wadsley et al. (2006) have proposed the alternative signal speed (10)for artificial conductivity. Both Eqs. (9) and (10) are included as options in SEREN. We note that when the GodunovSPH formulation is selected, we can disable the artificial viscosity since the Riemann solver should allow us to capture shocks accurately. We may need to retain the artificial conductivity sinceour simple implementation of a Riemann solver into SPH does not address that problem.
3.1.1. Artificial viscosity switches
Artificial viscosity can have undesirable side effects. In the absence of shocks it can lead to kinetic energy being dissipated at an unacceptably high rate, i.e. much faster than would happen with physical viscosity; this is an important consideration in simulations of interstellar turbulence. It can also deliver an unacceptably high shear viscosity, and thereby corrupt shear flows; this is an important consideration in simulations of the longterm evolution of accretion discs. A number of devices has been proposed to reduce the artificial viscosity in regions where it is not needed. Three such viscosity limiters are included in SEREN. The first is the switch proposed by Balsara (1995) in which α is multiplied by the dimensionless quantity , where (11)In regions of strong compression (i.e. shocks), the  ∇·v  terms tend to dominate over the  ∇ × v  term, so f_{i} → 1. In regions where vorticity dominates (i.e. shear flows), the  ∇ × v  term dominates, so f_{i} → 0.
The second device (which can be used in conjunction with the first) is timedependent viscosity (Morris & Monaghan 1997). In timedependent viscosity, each particle i has its own value of α_{i}, which evolves according to the equation (12)Here is the default value of α_{i}, and τ_{i} is the efolding time on which α_{i} relaxes to , if the source term, (13)vanishes (cf. Rosswog et al. 2000). Reasonable results are obtained with α_{MIN} = 0.1, since a small residual artificial viscosity is needed to suppress highfrequency particle noise. The efolding time is given by with (i.e. roughly a soundcrossing time for the smoothing kernel). The source term ensures that if particle i enters a shock, α_{i} quickly increases towards α_{MAX} ~ 1, but as soon as the shock is passed it decays back to . If we use (α,β) viscosity, then we set β_{i} = 2α_{i}.
The third device is the patternmatching switch described by Cartwright & Stamatellos (2010). This switch is very effective in pure Keplerian discs, i.e. nonselfgravitating equilibrium discs modelled in the frame of reference of the central star, but has not yet been adapted to work in more general situations.
4. Selfgravity
Although the calculation of gravitational accelerations resembles an Nbody problem, with forces between point masses, one should – for consistency with the calculation of SPH accelerations – take proper account of fact that the underlying density field, given by Eq. (2), is actually continuous, and the gravitational potential is related to this continuous density field by Poisson’s equation, ∇^{2}Φ = 4 π G ρ. Price & Monaghan (2007b) derive the equations of selfgravitating SPH by including the gravitational potential in the Lagrangian, and then proceeding as in Price & Monaghan (2004a). It is then necessary to introduce two additional kernel functions, the gravitational acceleration kernel (φ′) and the gravitational potential kernel (φ, called the softening kernel by Price & Monaghan 2007b), As with the basic kernel function, W, and its other derivatives, these new gravitational kernels are computed in advance, on a grid, and stored, so that subsequently values can be obtained efficiently by interpolation. The forms of both of these kernels are discussed in Appendix A. Using these kernels, Price & Monaghan (2007b) show that the gravitational acceleration of particle i is (16)where (17)(18)and Ω_{i} is given by Eq. (4). The two summation terms in Eq. (16) are, respectively, the kernelsoftened gravitational acceleration, and the “gradh” corrections that account for adaptive smoothing lengths. The ζ_{i} term is calculated and stored when other SPH quantities are calculated (i.e. ρ_{i}, (∇·v)_{i}, Ω_{i}, etc.). To compute ζ_{i} requires ∂φ/∂h, which can be calculated and stored, once the form of W has been specified (see Appendix A). The gravitational potential at the position of particle i due to all other particles is (19)where (20)If we choose standard SPH or Godunov SPH, the second summation in Eq. (16) is omitted, and the total energy is not as well conserved (see Price & Monaghan 2007b).
To compute gravitational accelerations exactly, using Eqs. (16)–(18), requires a summation over all particle pairs and is therefore an process. To speed up the computation of gravitational accelerations, SEREN uses a BarnesHut tree (Barnes & Hut 1986). The resulting gravitational accelerations are not exact, but the resulting small fractional errors are considered acceptable, since there are other comparable or larger sources of error. The implementation of the gravity tree is described in Sect. 9.
4.1. Periodic gravity
Cosmological simulations (e.g. Springel et al. 2005) and simulations of turbulent molecular clouds (e.g. Klessen et al. 2000) often set out to model a representative piece of an infinite (or much more extended) medium, by assuming that the infinite medium consists of an infinite number of replicas of the main computational domain, extending periodically in all directions, and then employing periodic boundary conditions. For purely hydrodynamic simulations, periodic wrapping is sufficient to give acceptable boundary conditions. When selfgravity is invoked, we must include a contribution to the acceleration from all the replicas of the computational domain, extending to infinity. SEREN does this using the Ewald method (Hernquist et al. 1991; Klessen 1997). If the computational domain is a cube of sidelength L, the total gravitational acceleration exerted on particle i by all of the infinite replicas of particle j (but not directly by the particle j itself) is (21)where (22)and α = 2/L. The first summation in Eq. (22) is over all replicas in all directions (i.e. all nspace) and the second summation is over all phasespace (i.e. all kspace). The summations converge rapidly and can be truncated for  r − nL  < 3.6L and k^{2} < 40π^{2}/L^{2}. SEREN computes the dimensionless correction forces for a wide range of separations and tabulates the values in a lookup table.
5. Thermal physics
SEREN contains several equationofstate (EOS) algorithms which can be selected using Makefile options. In all cases we assume that the gas is ideal, and so the pressure and specific internal energy are related by (23)where is Boltzmann’s constant, is the mean gasparticle mass, and γ is the ratio of specific heats. With Options 1 to 3 below there is no need to solve the SPH energy equation, whereas with Options 4 and 5 there is.
1. Isothermal equation of state. If the gas is isothermal at temperature , (24)with constant isothermal sound speed, .
2. Polytropic equation of state. The polytropic EOS has the form (25)where K is the polytropic constant and η is the polytropic exponent; the polytropic index is n = (η − 1)^{1}.
3. Barotropic equation of state. SEREN includes a barotropic equation of state of the form (26)This mimics the behaviour of interstellar gas in molecular clouds, where the gas is optically thin to its cooling radiation and approximately isothermal (at T_{O} ~ 10 K) when the density is low (ρ < ρ_{CRIT} ~ 10^{13} g cm^{3}), and optically thick to its own cooling radiation and approximately adiabatic (e.g. with γ ≃ 5/3) at higher densities (ρ > ρ_{CRIT}).
4. Adiabatic equation of state. We integrate the internal energy equation explicitly (using Eq. (5)) and then calculate the thermal pressure from Eq. (23). Changes in the specific internal energy are solely due to compressional and/or viscous heating.
5. Radiative cooling. The method of Stamatellos et al. (2007) is used to capture realistically the main effects of radiative heating and cooling (in the optically thin, thick and intermediate regimes), but without the expense of a full radiative transfer calculation. This algorithm uses local functions of state (namely the density, temperature and gravitational potential) to compute an approximate optical depth to infinity, and hence to obtain an approximate cooling rate. This cooling rate is then used to solve the energy equation implicitly, and hence to determine the thermal evolution of the gas.
6. Ionising radiation. SEREN also includes the option to model a single discrete source of ionising radiation (i.e. an OB star or tight cluster of OB stars) using the algorithm of Bisbas et al. (2009). This algorithm generates an isotropic distribution of HEALPix rays, which are split into smaller child rays wherever finer resolution is needed. The rays propagate until they reach the ionisation front, where they are terminated. Particles well inside the Hii region are given a high temperature (~10 000 K) and particles well outside the Hii region are treated with one of the EOS algorithms listed above. There is a region with thickness of order the local smoothing length in which the temperature variation is smoothed, so as to avoid problems associated with abrupt temperature discontinuities.
6. Time integration
6.1. Integration schemes
SEREN offers a choice of four integration schemes: 2ndorder RungeKutta, 2ndorder Leapfrog (kickdriftkick and driftkickdrift) and 2ndorder PredictorCorrector. The default choice isthe 2ndorder Leapfrog driftkickdrift: The main advantage of this scheme is that it only requires one acceleration calculation per timestep, as opposed to two in the 2ndorder RungeKutta scheme. Leapfrog schemes (both the Leapfrog kickdriftkick and driftkickdrift) are symplectic (i.e. they conserve phasespace) and so they are more stable for orbital integration (for example, in disc simulations). They are also, in principle, timereversible for constant, global timesteps. The use of block timestepping breaks exact timereversibility (see Sect. 6.3), and also breaks exact momentum and angular momentum conservation. The other integration schemes are included because some perform better than the Leapfrog scheme in non–selfgravitating problems, and to allow comparison with other codes that use different integrators.
6.2. Optimal timesteps
SEREN calculates (but does not explicitly use) the optimal timestep for particle i, Δt_{i}, by determining the minimum value of three separate timesteps. The first is based on a modified Courant condition of the form (33)The denominator contains the h_{i}  ∇·v  _{i} term (which is frameindependent) instead of the absolute speed,  v  _{i} (which is normally used in the Courant condition). The terms involving α and β in the denominator account for particles that are in the vicinity of shocks. The second timestep condition is an acceleration condition similar to those used in some Nbody codes, i.e. (34)where η_{a} is a small positive acceleration to ensure the denominator does not at any time fall to zero. The third timestep condition is the heating condition, which limits the fractional change in the internal energy per timestep, (35)where is a small positive heating rate to ensure the denominator does not fall to zero. This timestep criterion is only used when the SPH energy equation (Eq. (5)) is solved explicitly. If we solve the energy equation implicitly (e.g. Stamatellos et al. 2007), we only use the Courant and acceleration timesteps, Eqs. (33) and (34), to compute the optimal timestep for particle i, Δt_{i}.
6.3. Hierarchical block timesteps
SEREN uses hierarchical block timestepping (e.g. Aarseth 2003) to reduce the runtime of a simulation. In a typical star formation simulation, only a small fraction of the particles might require very small timesteps, for example those passing through a shock or those near the centre of a condensation. If a global timestep is used, accelerations are recalculated for all particles, irrespective of whether the recalculation is really needed. Instead, we allow each particle to have its own timestep, chosen from a binary hierarchy of possible values, Δt_{n} = 2^{n} Δt_{MIN}, where n = 0,1,2,...,n_{MAX}. Particle i is then allocated the largest value of Δt_{n} from this hierarchy that is smaller than its optimal timestep, Δt_{i} (based on Eqs. (33)–(35)). By restricting the ratio of timesteps to integer powers of 2, we ensure that the particles are always synchronised at the end of the largest timestep, Δt_{MAX} = 2^{nMAX} Δt_{MIN}.
The acceleration of a particle is then recalculated with a frequency determined by its allocated timestep, Δt_{n}. The most expensive parts of this recalculation are those associated with walking the trees. At any time, the positions, velocities and thermodynamic properties of particles whose accelerations do not yet need to be recalculated are simply estimated by extrapolation.
The timestep for a particle is recalculated at the end of its current timestep, using Eqs. (33) to (35). When the allocated timestep of a particle decreases (i.e. it moves to lower n in the hierarchy), there is no problem, because any lower timestep in the hierarchy is automatically synchronised with the higher one from which the particle is descending. On the other hand, this is not necessarily the case when a particle’s allocated timestep increases (i.e. it moves to higher n in the hierarchy). In this situation, we have to check that the lower timestep is correctly synchronised with the higher one before we can move the particle up (i.e. increase its allocated timestep). In addition, we only allow a particle to increase its allocated timestep one level at a time.
As shown by Saitoh & Makino (2009), SPH can perform poorly when neighbouring particles have very different timesteps. For example, in a high Machnumber shock, the particles may interpenetrate because particles from the lowdensity preshock gas have much longer timesteps than those in the highdensity postshock gas, and therefore in a single timestep they advance deep into the shocked region. SEREN mitigates this effect by broadcasting each particle’s allocated timestep to all it neighbours. If one of the neighbours j of particle i has an allocated timestep which is more than two levels higher in the hierarchy(i.e. more than a factor 4 longer; t_{j} > 4 t_{i}), the neighbour’s timestep is automatically reduced to t_{j} = 4 t_{i} as soon as the timestep hierarchy is correctly synchronised.
7. Sink particles
Sink particles are used in SPH to allow simulations of star formation to be followed longer (Bate et al. 1995). Gravitational collapse inevitably leads to high densities, short smoothing lengths, high accelerations, and therefore short timesteps. Under these circumstances, even the use of block timestepping (Sect. 6.3) cannot prevent runtimes from becoming impractically long. To circumvent this problem, we replace dense condensations with sink particles. A sink particle possesses the collective properties of the condensation it represents (i.e. mass, centreofmass position and net momentum) but does not retain any information about the internal structure and evolution of the condensation. Thus SPH particles that would otherwise have continued evolving inexorably towards higher density (thereby using up ever increasing amounts of CPUtime) are instead excised from the simulation. This means that the dynamics of the remaining more diffuse gas, and the formation of additional condensations, can be followed in an acceptable runtime. The assumption is made that – in the absence of feedback from the resulting protostar – the only important effect that the material inside a sink particle will have on its surroundings is due to its gravitational field. Thus sink particles interact gravitationally, but not hydrodynamically, with other sink and SPH particles.
A sink particle is created when an SPH particle satisfies all the stipulated sinkcreation criteria. These criteria are divided into default criteria and optional criteria. The SPH particle which triggers the formation of a sink is referred to as the seed particle. The default criteria for sink creation are then (i) that the SPH density of the seed particle is greater than ; and (ii) that there is no other sink particle within 2r_{SINK} of the seed particle (i.e. a sink particle should not be formed overlapping a preexisting sink particle). In principle, and can be chosen independently. However, the results are only realistic if the material going initially into a sink particle is resolved. The default procedure in SEREN is to set r_{SINK} = ℛh_{s}, where h_{s} is the smoothing length of the seed particle. This means that different sink particles have slightly different radii. The option exists in SEREN to prescribe a universal .
The four optional sinkcreation criteria are (iii) that the mean density of the seed particle and all its neighbours exceeds (this ensures that a stochastic density fluctuation does not result in the formation of a sink); (iv) that the SPH velocity divergence of the seed particle is negative, (∇·v)_{s} < 0 (this ensures that the particles going into the sink are condensing, and not being sheared apart); (v) that the SPH acceleration divergence of the seed particle is negative, (∇·a)_{s} < 0 (this ensures that the condensation is not being torn apart by tidal forces); (vi) that the total mechanical energy of the seed particle and its neighbours (kinetic plus gravitational potential energy in the centreofmass frame) is negative.
Only one sink particle can be created in any one timestep; otherwise the possibility would exist to generate multiple overlapping sinks. At each timestep, SEREN loops over all the SPH particles, and finds those whose SPH density (or, if required, mean density) exceeds . These candidate seed particles are then ordered in a list of decreasing SPH density (or mean density), and SEREN runs through this list until it finds a seed particle that satisfies all the creation criteria, and creates a sink particle out of this seed particle and all its neighbours.
An SPH particle i is accreted by an existing sink particle s if (a) the SPH particle lies inside the sinkparticle’s radius,  r_{i} − r_{s}  ≤ r_{SINK}, and (b) the kinetic plus gravitational energy of the twobody system comprising the sinkparticle and the SPHparticle is negative. The SPH particle’s mass, linear and angular momentum are then assimilated by the sink particle, and the SPH particle itself is removed from the simulation. When determining which SPH particles are accreted by which sink particles, we first compile a list of all the SPH particles which are to be accreted by each sink, and only when these lists are complete do we update the sink properties (mass, position, momentum) to account for the SPH particles it has just assimilated. This is necessary because otherwise the accretion process would depend on the order in which the SPH particles were interrogated.
8. Nbody integrator
Simulations of star formation very often result in the formation of multiple stellar systems. Such simulations are modelled with hydrodynamical codes until most of the gas has been accreted by protostars, or dispersed by feedback; this is referred to as the accretion phase. In the absence of magnetic fields and feedback, the accretion phase is driven entirely by the competition between thermal pressure, viscosity, and gravity. The system then enters the ballistic phase, in which Nbody dynamics modify the final clustering and binary properties, typically over a period of several tens of crossing times (Van Albada 1968). SPH simulations are often terminated after the accretion phase and not evolved through the ballistic phase.
SEREN includes an Nbody integrator, so that it can follow both the accretion phase and the ballistic phase, in a single simulation. SEREN switches from an SPH simulation of the accretion phase, to an Nbody simulation of the ballistic phase, if one of two conditions are met: either the simulation has reached the endtime stipulated in the parameters file, or a critical fraction of the original gas mass has been accreted by sink particles. At the switchover, SEREN identifies any SPH particles which are strongly bound to a particular sink. On the assumption that these SPH particles are either about to be accreted by that sink, or will form a tightly bound disc around it (and eventually be accreted or form a planetary system), they are instantaneously accreted by the sink to which they are bound. This ensures that their contribution to the overall gravitational potential is not suddenly lost at the switchover.
One problem that corrupts Nbody codes is inaccuracies resulting from close interactions. These can build up over the course of a simulation, or materialise quickly in near headon interactions, causing large energy errors. A variety of techniques has been employed to alleviate this problem, such as using very short timesteps (e.g. Portegies Zwart et al. 2001), gravitysoftening (Aarseth 2003) or transformation of the equations of motion (e.g. KS regularization, Stiefel & Scheifele 1971). In SEREN, the Nbody code retains the kernelsoftened gravity used in the SPH code, in order to ensure that the gravitational accelerations are computed consistently between the two parts of a simulation. This has the advantage of preventing large energy errors due to close interactions, but has the disadvantage of preventing the formation of close binaries (separations less than ).
8.1. Hermite integrator
The Nbody integrator of choice is a fourthorder Hermite integrator (Makino 1991; Makino & Aarseth 1992). The Hermite integrator has been presented in two different forms in the literature, either as a fourthorder leapfrog scheme or as a fourthorder predictorcorrector scheme (Aarseth 2003). SEREN uses the predictorcorrector version of the Hermite integrator. Both forms are considered superior to other 4thorder Nbody integrators, in the sense of giving better energy conservation and allowing longer timesteps (Makino 1991; Aarseth 2003). The leapfrog version of the Hermite scheme also maintains many of the properties of a traditional 2nd order leapfrog integrator (for example, it is symplectic), but it is of higher order by virtue of using both the acceleration and its first time derivative.
The Nbody code uses a global timestep informed by the Aarseth (2001) criterion, (36)Here , and are, respectively, the 1st, 2nd and 3rd time derivatives of the acceleration, calculated at the end of the previous timestep; γ is an accuracy factor of order ~ 0.1 (Makino & Aarseth 1992). Next we calculate the acceleration and its timederivative (sometimes called the jerk) at the beginning of the step. The acceleration is given by (37)where is the same gravitationalacceleration kernel as used in calculating kernelsoftened gravitational accelerations in SPH (Eq. (14)). The kernelsoftening means we must account for the rate of change of the kernel function and include extra terms in the expression for the jerk (Makino & Aarseth 1992). Using the same notation as in Sect. 4, the expression for the jerk becomes (38)The particle positions and velocities are then advanced to the end of the timestep, We calculate the acceleration and jerk again using the new positions and velocities. We can thus calculate the second and third time derivatives at the beginning of the step (Makino & Aarseth 1992), Finally, we add the higher order terms to the position and velocity vectors, The values of a, , and computed at the end of the timestep allow the code to calculate the next time step using Eq. (36). This is not possible on the very first timestep, and there we use explicit equations to calculate and (e.g. Aarseth 2001, his Eqs. (6) and (7)); all subsequent timesteps are determined using and from Eqs. (41) and (42).
8.2. Identification of multiple systems
During the Nbody simulation, SEREN automatically searches for binaries and hierarchical triples and quadruples. There is no single robust method for identifying a bound, stable multiple system that contains an arbitrary number of components. We use a simple twostage procedure. The first stage is to identify all binary systems present at the current time. This involves calculating the twobody energies of all starpairs in the simulation. If (a) stars 1 and 2 are found to be mutually mostbound (i.e. the twobody energy of stars 1 and 2 is a minimum and negative for both stars); and (b) stars 1 and 2 are not bound to any other stars (i.e. the twobody energies of 1 and 2 with all other stars are positive), then they are identified as a bound binary system. If the primary and secondary masses are m_{1} and m_{2} respectively, the instantaneous relative displacement is r_{12} ≡ r_{1} − r_{2}, and the instantaneous relative velocity is v_{12} = v_{1} − v_{2}, then the twobody energy and angular momentum arewhere μ = m_{1}m_{2}/(m_{1} + m_{2}). The orbital binary parameters are then given by The next stage is to search for hierarchical systems. In order to facilitate this search, each binary found in the previous step is replaced by a single ghostbinary particle. We then repeat the procedure performed in the first stage, searching for any mutually mostbound pairs, but now using the ghostbinaries and the remaining unattached stars. If a ghostbinary is found to be mostbound to a single star and vice versa, they are identified as an hierarchical triple, and the orbit of the system is calculated as above and recorded. If two ghostbinaries are found to be mostbound to each other, then they are recorded as an hierarchical quadruple.
9. Tree
SEREN uses an implementation of the BarnesHut tree (Barnes & Hut 1986; Pfalzner & Gibbon 1996) to rapidly obtain neighbour lists for SPH interactions, and to efficiently calculate gravitational accelerations. The BarnesHut tree is an octalspatial decomposition tree that splits the volume of the tree cells at each level into eight equalvolume cubic subcells (or four equalarea square subcells in 2D) – recursively until only a few, or zero, particles remain in each subcell. The cells at which a branch of the tree terminates are called leaf cells. SEREN decomposes the particles as an ensemble, in a similar manner to the algorithm described by Pfalzner & Gibbon (1996) (as distinct from the original BarnesHut method, which considers one particle at a time as the tree structure is built). The Pfalzner & Gibbon algorithm makes it easier to parallelise the treebuild routine using OpenMP.
We construct two separate trees, one for particles that experience hydrodynamic accelerations and one for particles that experience gravitational accelerations. This is advantageous because these accelerations are computed using different cell properties. In the case where all SPH particles are selfgravitating, we can build the tree structure once, copy this structure to the second tree, but then stock the two trees (i.e. calculate the properties of the tree cells) separately. Since the timestep criteria restrict how far particles can move in any one timestep, the tree structure will not change appreciably from one timestep to the next. Therefore we only build the tree structure every ~10 timesteps, but restock it every timestep.
9.1. Neighbour searching
The BarnesHut neighbour tree is constructed using all SPH particles. For each cell, we record (i) the position of centre of the bounding box containing all particles in the cell; (ii) the maximum distance of all particles from the bounding box centre; (iii) the maximum smoothing length of all particles in the cell, and, if it is a leaf cell; (iv) the identifiers of all particles contained in the cell. Storing these quantities enables us to find neighbours efficiently, either by gather (i.e. all particles for which ), or by scatter (i.e. all particles for which ), or both. When we perform a treesearch of this type, we obtain a potential neighbour list, which is guaranteed to contain all of the true neighbours but normally also contains nonneighbours. There is no need to cull this list, because all nonneighbours which are passed to the SPH routines have no effect, since the kernel and its derivatives are zero for nonneighbours.
9.2. Tree gravity
The BarnesHut gravity tree is built using only selfgravitating SPH particles. For each cell, we record by default (i) the total mass of the cell; (ii) the position of the centre of mass, and, if it is a leaf cell; (iii) the IDs of all SPH particles contained in the cell. Additionally, we can compute and store higherorder multipole terms, in order to calculate the gravity of a cell to greater accuracy. A multipole expansion can in principle be made up to any order, although it is usually optimal to truncate after only a few terms. The monopole term is simply the centre of mass term for each cell and the dipole term is always zero if calculated with respect to the centre of mass of the cell. In SEREN, we provide the option to include either the quadrupole moment terms, or the quadrupole and octupole moment terms. The equations for the quadrupole and octupole moment tensors of a cell are given in Appendix B. The quadrupole moment tensor is a traceless symmetric matrix, Q, meaning there are 5 independent terms to be stored for each cell. The octupole moment tensor is a more complicated rank3 tensor, S, whose symmetries result in 10 independent terms which must be stored for each cell. The gravitational potential at the position of particle i due to cell c, up to octupole order, is (50)where r = r_{i} − r_{c} is the position of particle i relative to cell c, (r_{1},r_{2},r_{3}) are the Cartesian components of r, and we employ the Einstein summation convention (i.e. we sum over repeated indices). If we define to be the unit vector in the ath Cartesian direction, the gravitational acceleration of particle i, due to cell c, up to octupole order, is (51)When walking the gravity tree, the code must interrogate cells to decide whether to use the multipole expansion or to open up the cell and interrogate its child cells. This decision is determined by the multipoleacceptance criterion (MAC). SEREN includes a simple Geometric MAC and a GADGETstyle MAC; it also includes a new Eigenvalue MAC, which uses the eigenvalues of the quadrupole moment terms to determine whether to open a cell.
9.2.1. Geometric MAC
The Geometric MAC uses the size of the cell, ℓ_{c} (i.e. its longest cornertocorner length), and its distance from the particle,  r_{i} − r_{c}  , to calculate the angle the cell subtends at the particle, θ_{ci} = ℓ_{c}/r_{i} − r_{c}. If θ_{c} is smaller than some predefined tolerance, , the gravitational acceleration due to the cell is given by the multipole expansion, Eq. (51). If this criterion is not satisfied, the cell is opened and the subcells on the next level are interrogated in the same way. If a leaf cell is opened, we store the identifiers of all the particles contained in it, and compute their contribution to the net gravitational acceleration directly (using Eqs. (16)–(18)). For computational efficiency, the code calculates and stores for each cell the quantity . An unnecessary squareroot operation is then avoided by applying the geometric MAC in the form (52)
9.2.2. GADGETstyle MAC
Springel et al. (2001) have formulated another type of MAC for the SPH code GADGET. This MAC uses an approximation to the leading error term in the multipole expansion to calculate for each cell the smallest distance from the cell at which the multipole expansion can be used. GADGET includes quadrupole moment corrections, and so the leading error term is the octupole term. However, Springel et al. suggest that the octupole moment term is small in a homogeneous density field, in which case the hexadecapole term is the largest error term. For a cell c of total mass M_{c} and linear size ℓ_{c}, an approximation to the magnitude of the acceleration of particle i due to the hexadecipole term is . If is less than some userdefined fraction of the total gravitational acceleration of particle i, i.e. a_{HEX} < α_{MAC}  a_{GRAV}  , the multipole expansion is used; otherwise cell c must be opened to the next level. Since the current acceleration of particle i is not yet available, the code uses the acceleration from the previous timestep as an approximation. The code therefore calculates and stores for each cell the quantity , and then applies the GADGETstyle MAC in the form (53)When the quadrupole and octupole moment terms are not used, the leading error term is the quadrupole term. Therefore an approximation to the acceleration of the quadrupole term, , is used instead. In this case the code calculates and stores for each cell the quantity , and then applies the GADGETstyle MAC in the form (54)Since we do not have a value of on the very first timestep, we use the Geometric MAC with θ_{MAC} = 1.0 to obtain an initial estimate and then revert to Equations. (53) and (54). Equations (53) and (54) do not guarantee a maximum fractional force error, but rather attempt to set an upper limit on the error contribution from each cell. It is therefore possible that the error is larger than desired. Therefore we use the Geometric MAC with θ_{MAC} = 1.0, alongside the GADGETstyle MAC, as a safety measure for the rare cases where Eqs. (53) and (54) are inadequate.
9.2.3. Eigenvalue MAC
We introduce here a new Eigenvalue MAC, based on the quadrupole moment terms of a cell. Salmon & Warren (1994) originally suggested using higherorder multipole moments directly to formulate a MAC, but they only used upper limits to the multipole moment terms to constrain the leading error term of the multipole expansion. This resulted in a more conservative MAC than was actually required to achieve the desired accuracy, and hence more expensive tree walks. The Eigenvalue MAC is formulated by determining the maximum values of the gravitational potential (or acceleration) due to the quadrupole moment terms of a cell. The quadrupole moment tensor is a real, symmetric and traceless matrix. It therefore has three real eigenvalues, λ_{1},λ_{2},λ_{3}. From Eq. (50), the gravitational potential due to the quadrupole moment term is (55)The term in the numerator, Q_{ab,c}r_{a}r_{b}, is the quadratic form between the quadrupole matrix Q and the vector r. It can be shown (e.g. Riley et al. 1997) that the quadratic form has a maximum absolute value given by  λ_{MAX}   r  ^{2}, where is the largestin magnitude of the three eigenvalues. We therefore solve the eigenvalue equation, Since, by design, C = Tr [ Q ] = 0, Eq. (56) is a depressed cubic equation, i.e. a cubic equation with no quadratic term. Since also Q is real and symmetric, the eigenvalues are real, and Eq. (56) can be solved by the method of Vieta (e.g. Martin 1998). In particular, the largest eigenvalue is (60)We therefore require that the magnitude of the quadrupole moment potential,  φ_{QUAD}  = Gλ_{MAX}/2  r_{i} − r_{c}  ^{3}, be less than some userdefined fraction of the total potential,  φ_{QUAD}  < α_{MAC}  φ_{GRAV}  . The code approximates with the value from the previous timestep, and calculates and stores for each cell the quantity . The Eigenvalue MAC is then applied in the form (61)Equation (61) does not guarantee a maximum fractional error, but attempts to limit the error contribution from each cell. Therefore we also use the Geometric MAC with θ_{MAC} = 1.0, alongside the Eigenvalue MAC, as an extra safety measure.
9.2.4. SPHneighbour cellopening criterion
The multipole expansions used in SEREN assume that each SPH particle in a cell is a pointmass. In contrast, the derivation of the equation of motion takes account of the finite extent of an SPH particle (i.e. kernelsoftened gravity; see Sect. 4). The SPHneighbour criterion therefore requires that any cell that might contain neighbours of particle i be opened. The code calculates and stores for each cell the quantity , where the maximum is over all the particles j in the cell; d_{c} is the maximum extent of the smoothing kernels of the particles in cell c. The overall cellopening criterion then takes the form (62)This additional criterion adds an extra overhead to calculating the properties of the cells, and also to the gravity walk, since there are now two cellopening criteria to check. However, in highly clustered geometries such as those found in gravitational collapse problems, this extra check brings significant accuracy and speed benefits.
10. Tests
We have performed a large number of standard and nonstandard tests to demonstrate that the algorithms in SEREN have been implemented correctly and perform well. It is not practical to test all possible combinations of the options available in SEREN, and we have therefore chosen tests which demonstrate the performance of particular algorithms. Where possible, we compare the test results with known analytic or semianalytic solutions. Where an algorithm has been developed in another SPH code and the subroutine then imported into SEREN (e.g. the radiative cooling module of Stamatellos et al. 2007), or has been written directly into SEREN as an independent module (e.g. the HEALPix module for treating ionising radiation; Bisbas et al. 2009), the testing is not described here, and the interested reader is referred to the original paper.
10.1. Generation of initial conditions
The generation of initial conditions in SPH often needs careful consideration, since particle noise and edge effects can impact negatively on test simulations such as those described here. For example, random initial conditions suffer from Poissonnoise in the particle distribution which leads to highfrequency noise in the density and particle accelerations. A safer approach is to generate a socalled “glass” distribution of particles. A glass is a semiregular structure in which all the particles are roughly equidistant from each other.
In order to generate a glass, we initially place equalmass particles randomly in a periodic box. The particles are evolved using SEREN, with artificial viscosity to dissipate the kinetic energy, until the particles have settled into an equilibrium structure. We use an isothermal EOS and a Courant factor of γ_{COUR} = 0.2. Once settled, the particle boxes can be replicated and joined together to create larger settled particle distributions, and uniformdensity spheres can be cut from a box. All of the glass distributions used in this paper are setup using this method. We note that glassstructures can be set up with different methods (e.g. “repulsive” gravity in GADGET2, Springel 2005).
Fig. 1 Results of the adiabatic shock test using the “gradh” SPH formulation (Price & Monaghan 2004a) showing a) the density, b) the xvelocity, c) the thermal pressure, and d) the specific internal energy after a time t = 1.0. The black dots represent the results from the SPH simulation and the red lines show the semianalytic solution obtained using a Riemann solver.

Open with DEXTER
Initial conditions for the adiabatic Sod test (Cols. 2 and 3), and for the colliding flows test (Cols. 4 and 5).
10.2. Adiabatic Sod test (Sod 1978)
The initial conditions for this test are summarised in Table 1 (left side). The computational domain is − 4 ≤ x ≤ + 4,0 ≤ y ≤ 1,0 ≤ z ≤ 1, and periodic wrapping is invoked in all three dimensions. Initially (at t = 0), the lefthand half of the domain (x < 0) contains a highdensity, highpressure gas, represented by 64 000 particles, and the righthand half (x > 0) contains a lowdensity, lowpressure gas, represented by 16 000 particles. The particles have been relaxed to a glass, and are at rest; they have equal mass. The gas evolves adiabatically, with adiabatic exponent γ = 1.4. We therefore solve the momentum and energy equations, using both artificial viscosity and artificial conductivity, to moderate the discontinuities in velocity and temperature, respectively. We perform this test in 3D (since this is the dimensionality of starformation simulations) using the default “gradh” SPH method, the Monaghan (1997) artificial viscosity and the Price (2008) artificial conductivity.
Figure 1 shows the density, xvelocity, thermal pressure and specific internal energy profiles (black dots), and the accurate 1D solution obtained using a Riemann solver (red lines), at the end of the simulation (t = 1) in the interval x < 2. A rarefaction wave is propagating into the highdensity gas on the left (its head is at x ~ −1.3), and a shock wave is propagating into the lowdensity gas on the right (it has reached x ~ 1.5). There is also a contact discontinuity (at x ~ 0.6), since the gas from the right has higher specific entropy than that from the left. The SPH results reproduce the gross features of the accurate solution well, but the discontinuities are inevitably spread over a few smoothing lengths.
10.3. Colliding flows test
Fig. 2 Results of the colliding flows test using the standard SPH equations with the Monaghan (1997) artificial viscosity showing a) the density and b) the xvelocity, after a time t = 0.6. The black dots represent the results from the SPH simulation and the red lines show the analytic solution.

Open with DEXTER
Fig. 3 Results of the colliding flows test using the standard SPH equations and timedependent (α, β) viscosity (Morris & Monaghan 1997) showing a) the density and b) the xvelocity, after a time t = 0.6. The black dots represent the results from the SPH simulation and the red lines show the analytic solution.

Open with DEXTER
The initial conditions for this test are summarised in Table 1 (right side). The computational domain is −4 ≤ x ≤ + 4,0 ≤ y ≤ 0.2,0 ≤ z ≤ 0.2, and periodic wrapping is invoked in the y and z dimensions, but not in the x dimension. Initially, the density is uniform, but the gas in the lefthand half of the computational domain (x < 0) has velocity v_{x} = + 4, and the gas in the righthand half (x > 0) has velocity v_{x} = − 4; the gas is represented by 128 000 equalmass particles which have been relaxed to a glass.The velocities are smoothed near x = 0 instead of having an unresolved xvelocity discontinuity.Therefore the discontinuous velocity profile, v′(r), is replaced by the smoothed velocity,(63)The gas is isothermal, with dimensionless sound speed c_{S} = 1, so the code does not need to solve the energy equation, nor does it need to invoke artificial conductivity. This test demonstrates how well artificial viscosity enables the code to suppress particle interpenetration and capture shocks.We perform the test in 3D, using standard SPH with Monaghan (1997) with and without timedependent artificial viscosity (Morris & Monaghan 1997). For the timedependent viscosity simulation, we set α_{MAX} = 2 (and β_{MAX} = 4) with α_{MIN} = 0.1. We adopt a global timestep for both simulations.
Figure 2 compares the SPH density and xvelocity as a function of x (black dots) with the analytic solution (red line), for the standard SPH run, and Fig. 3 makes the same comparison for the timedependent viscosity run, both at t = 0.6. The peak density and the width of the shock are in agreement with the analytic solution for both runs, but the discontinuities in density and velocity are smeared out over a few smoothing lengths. This smearing is an inherent feature of SPH simulations. The timedependent viscosity performs almost as well as the standard Monaghan (1997) viscosity, with a little more scatter in the postshock density. The scatter in the density is partly a result of increased particle disorder at the shock front due to a small amount of particle penetration when the shock forms (Figs. 2b and 3b).
10.4. Sedov blast wave (Sedov 1959)
This test demonstrates that the code can handle the steep temperature and density gradients created by an explosion, and the consequent requirement for a timestep limiter (see Sect. 6.3 and Saitoh & Makino 2009). A settled, uniformdensity glasslike distribution of 200 000 SPH particles is created. Then the central particle and its (~50) neighbours are given a net impulse of thermal energy ΣU = 1, divided amongst them according to the smoothing kernel. The remaining particles have a total thermal energy 10^{6} times smaller than the particle with the maximum internal energy (i.e. the particle closest to the centre). The impulse of thermal energy results in an outward propagating shock front which sweeps the surrounding gas into a dense layer. Sedov (1959) providesan analytic similarity solution for the subsequent evolution of this system (strictly speaking, one in which the surrounding particles start with zero thermal energy).
We perform three realisations of this test, with three different timestepping schemes. The resulting density profiles at time t = 0.02 are shown in Fig. 4, and compared with the semianalytic solution. The SPH simulation with global timesteps (Fig. 4a) shows good agreement with the semianalytic solution; the maximum density in the shell is reduced by smoothing, but the position and width of the shock front are comparable with the analytic solution. The SPH simulation using hierarchical block timesteps (Fig. 4b) fails to reproduce any of the features of the semianalytic solution, because the cold particles have such a long timestep, compared with the hot ones, that they cannot respond to the pressure of the explosion and the hot particles penetrate through them. The SPH simulation using hierarchical block timesteps with a timestep limiter (i.e. not allowing any SPH particle to have a timestep more than four times longer than its neighbours; Fig. 4c) produces results which are indistinguishable from the simulation using global timesteps, but uses ~ 8% of the computing time.
Fig. 4 Results of the Sedov blast wave test at a time t = 0.02 using a) global timesteps; b) individual block timesteps; c) individual timesteps with the timesteplimiter described in Sect. 6.3 and in Saitoh & Makino (2009). The block dots represent the SPH results and the red line shows the semianalytic solution provided by Sedov (1959).

Open with DEXTER
10.5. KelvinHelmholtz instability
The KelvinHelmholtz instability (hereafter KHI) is a classical hydrodynamical instability that occurs, in the simplest case, between two bulk flows that are shearing past one another. It has been extensively studied in recent years as a diagnostic for comparing the ability of both SPH and grid codes to model mixing of interacting fluids (e.g. Agertz et al. 2006; Price 2008; Read et al. 2010). In particular, this test has highlighted an intrinsic problem in the standard formulation of SPH and has led to several suggested modifications to SPH (e.g. Price 2008; Read et al. 2010).
We use similar initial conditions to Springel (2010) where two fluids with densities ρ_{1} = 1 and ρ_{2} = 2 are in shearflow along the y = 0 plane with relative velocity  v_{1} − v_{2} = 1.0. The two fluids are in pressurebalance, P = 2.5, and have ratio of specific heats γ = 5/3. Therefore, there is discontinuity in the specific internal energy, u = P/ (γ − 1) ρ, and also in the specific entropy. Both layers are contained within a periodic box of extent −0.5 < x < 0.5 and −0.5 < y < 0.5. Springel (2010) adds a velocity perturbation of the form (64)xwhere λ = 0.5 is the wavelength of the velocity perturbation between the two fluids, w_{0} = 0.1 is its amplitude and σ = 0.05/ is the scaleheight of the perturbation in the ydirection. We invoke timedependent artificial viscosity and artificial conductivity (see Sect. 3.1). We adopt the quintic kernel (see Appendix A.2) for computing all SPH quantities, instead of the more common M4 kernel (see Appendix A.1). We follow the growth of the instability for a total dimensionless time of t = 1.5. The linear growthtimescale of the instability is (65)For our initial conditions, the growth timescale is τ_{KH} = 1.06. Therefore, by the end of the simulation the instability should have entered the nonlinear phase where significant vorticity and mixing occur near the shearing interface. We perform simulations using these initial conditions at both low (12 242 particles) and high (98 290 particles) resolutions.
In Fig. 5, we show the evolution of the density field and the development of the instability at three different times, t = 0.5, 1.0 and 1.5. For both the low and high resolution cases, the instability evolves at approximately the same rate through the linearphase (t = 0.5), and subsequently during the nonlinear phase (t = 1.0 and 1.5) where significant vorticity develops. The largescale properties of the vortices formed are very similar in both the low and high resolutions cases. The main difference between the two is the number of resolved spiral turns in a vortex. The low resolution case has just enough spatial resolution to model the formation of one complete spiral loop by t = 1.5. The high resolution case has enough resolution to model two complete spiral loops and can be seen to have less dispersion in the density field around the contact regions between the two fluids.
10.6. Tree multipole expansion and scaling characteristics
Fig. 5 Development of the KelvinHelmholtz instability for the lowresolution case (toprow; 12 242 particles) and the highresolution case (bottomrow; 98 290 particles). The plots show the evolution of the densityfield (colour bar on righthand side) at times t = 0.5, 1.0 and 1.5 (left, middle and right columns respectively).

Open with DEXTER
We test the accuracy of the BarnesHut gravity tree and the multipole moment correction terms (Sect. 9.2), by comparing the gravitational acceleration obtained by walking the tree, , with that obtained by a directsummation over all particles, (cf. McMillan & Aarseth 1993). Specifically, we compute the rootmeansquare fractional acceleration error, (66)The density field used in this test is a uniformdensity, glasslike sphere (see Sect. 10.1) of 32 000 SPH particles; we note that this is actually a stiffer test of the tree than a highly structured density field. We compute ϵ using the Geometric MAC (Sect. 9.2.1) and the Eigenvalue MAC (Sect. 9.2.3). For the Geometric MAC, we compute ϵ using different values of in the range 0.1 to 1.0, and including terms up to monopole, quadrupole and octupole order. For the Eigenvalue MAC, we compute ϵ using different values of in the range 10^{6} to 10^{2}, and including terms up to quadrupole and octupole order; we do not consider monopoleonly since we must calculate the quadrupole moment terms anyway in order to formulate the Eigenvalue MAC. We do not include the effects of kernelsoftening in this test and therefore we effectively set the smoothing lengths to zero for the purposes of using the SPHneighbour opening criterion; Sect. 9.2.4.
The resulting values of ϵ are plotted against and in Figs. 6a and 7a. We see that for the Geometric MAC, ϵ decreases monotonically with decreasing and with the inclusion of higherorder multipole terms (cf. McMillan & Aarseth 1993). Likewise the value of ϵ computed with the Eigenvalue MAC decreases monotonically for decreasing .
In Figs. 6b and 7b, we plot the CPU time required to compute all the gravitational accelerations using, respectively, the Geometric and Eigenvalue MACs, against the computed RMS fractional force error, ϵ. For both MACS, and for all multipoleexpansions, the CPU time increases as ϵ decreases. For the Geometric MAC, acceptably small values of ϵ are delivered much faster if the quadrupole terms are included. For both the Geometric and Eigenvalue MACs, the octupole terms do not deliver a big improvement in accuracy, and therefore – in the interests of memory and CPU efficiency – we normally evaluate only monopole and quadrupole terms.
The time required to calculate the gravitational accelerations using the tree is expected to scale as N log N (e.g. Pfalzner & Gibbon 1996), compared with N^{2} for a directsummation. Figure 8 shows the average CPU time for calculating gravitational accelerations in a uniform density sphere using the tree with the Geometric MAC (red triangles) and using directsummation (solid black circles). The two graphs scale as expected up to 10^{5} particles and beyond.
Fig. 6 a) The rootmeansquare fractional force error computing the gravitational forces for all particles in a uniformdensity sphere with the BarnesHut tree using the Geometric MAC as a function of , and b) the ratio of CPU time for computing all gravitational forces with the tree to directsummation as a function ϵ. The gravitational accelerations are calculated without kernelsoftening, up to monopole (blue diamonds), quadrupole (solid black circles) and octupole (red triangles) order.

Open with DEXTER
Fig. 7 a) The rootmeansquare fractional force error computing the gravitational forces for all particles in a uniformdensity sphere with the BarnesHut tree using the Eigenvalue MAC as a function of , and b) the ratio of CPU time for computing all gravitational forces with the tree to directsummation as a function ϵ. The gravitational accelerations are calculated without kernelsoftening, up to quadrupole (solid black circles) and octupole (red triangles) order.

Open with DEXTER
Fig. 8 Scaling characteristics of the BarnesHut tree code in SEREN. The time taken to compute gravitational forces for all particles for directsummation (solid black circles) and the BarnesHut tree (red triangles) as a function of particle number. For reference, we show the expected scaling for N^{2} (dashed line) and N log N (solid red line).

Open with DEXTER
10.7. Freefall and isothermal collapse of a uniform density sphere
We test the accuracy of the gravitational acceleration evaluation in a dynamicallyevolving system, by simulating the freefall collapse of a uniform density sphere. A static, uniformdensity sphere with mass , initial radius and initial density, , collapses to a singularity on a timescale ; and a shell of the sphere which is initially (t = 0) at radius is at subsequent times (0 < t ≤ t_{FF}) at radius r, given by (67)We set up the initial conditions by constructing a glasslike uniformdensity sphere containing 100 000 SPH particles (as described in Sect. 10.1). The subsequent evolution of the particles is then followed invoking gravitational accelerations only. Figure 9a compares the 90%, 50% and 10% mass radii as a function of time (dots) with the analytic solution (dashed lines). Significant divergence between the numerical results and the analytic solution – due to gravitational softening, particle noise, and integration error – occurs only after the density has increased by more than 10^{7} (see Fig. 9b).
This test has been repeated, but now imposing an isothermal equation of state and invoking both gravitational and hydrostatic accelerations. The collapse is no longer homologous, since there is a pressure gradient at the edge of the sphere, and this drives a rarefaction wave into the cloud. Ahead of the rarefaction wave, the gas collapses in freefall, as before, but behind it the gas decelerates and then expands. Figure 10 compares the 90%, 50% and 10% mass radii as a function of time (solid lines) with the analytic solution for the pressureless collapse (Eq. 67; dashed lines) and the position of the rarefaction wave as a function of time (Truelove et al. 1998; dotdashed line). We use a dimensionless isothermal sound speed, c_{S} = 1, so that the rarefaction wave reaches the centre of the sphere in less than a freefall time, preventing collapse to a singularity. Figure 10 shows that the gas motion diverges from freefall collapse just after the rarefaction wave passes, as it should. Slight deviations before this juncture are due to smoothing, gravitational softening, particle noise, and integration error.
Fig. 9 a) Freefall collapse of a pressureless, uniformdensity sphere. The figure shows the analytic solution (dashed lines), and the radial position of three representative particles at 90%, 50% and 10% mass radii (filled circles). b) Same as a), but with time measured from the end of the collapse and using logarithmic axis.

Open with DEXTER
Fig. 10 Collapse of a uniform density sphere with an isothermal equation of state and dimensionless isothermal sound speed c_{s} = 1. The figure shows the analytic solution for pressureless freefall collapse (solid red lines) and the radial position of the 90%, 50% and 10% mass radii (blue dashed lines). The black dotdashed line shows the analytic solution for the progression of the rarefaction wavefront.

Open with DEXTER
Fig. 11 Results of the polytrope test for an η = 5/3 polytrope, using a) 114, b) 1086, and c) 10^{5} SPH particles.

Open with DEXTER
10.8. Polytropes
This test demonstrates that SEREN can model the structure of an η = 5/3 polytrope, and therefore should be able to handle general selfgravitating equilibria. The density profile of a polytrope is obtained by solving the LaneEmden equation (Chandrasekhar 1939, Chap. IV). An η = 5/3 polytrope with mass M = 1 and radius R = 1 (in dimensionless code units) has polytropic constant K = 0.4246 (cf. Price & Monaghan 2007b). The initial conditions are generated by cutting a unitmass, unitradius sphere from a cube of settled particles (see Sect. 10.1), and then stretching the particles radially so that, in spherical polar coordinates, the new radius of particle i, , is related to its old radius, r_{i}, by , where M_{POLY}(r′) is the mass interior to radius r′ in the polytropic configuration; the angular coordinates of particle i are not changed. Stretching distorts the local arrangement of individual particles, and so the new configuration is not in detailed equilibrium. We therefore evolve it with η_{SPH} = 1.2, using artificial viscosity, until the system reaches equilibrium. This test has been performed with N = 114,1086 and 10^{5} SPH particles. For η_{SPH} = 1.2, . Bate & Burkert (1997) suggest that in SPH only condensations with particles are resolved. Therefore our very lowresolution test with particles (Fig. 11a) demonstrates that SEREN can indeedcrudely model such a condensation, albeit with only approximately the correct radius and central density; the grouping of particles near the boundary (at r ~ 0.6) in Fig. 11a reflects the tendency for well relaxed distributions of SPH particles to adopt a glasslike arrangement. Figure 11b shows that with the polytrope is much better resolved, and Fig. 11c shows that with N = 10^{5} the density profilealmost exactly matches the LaneEmden solution.
We test convergence with the exact solution by calculating the L1 error norm as a function of particle number for varying resolutions. SPH is formally secondorder accurate in space (e.g. Monaghan 1992) and therefore the L1 error should scale as L1 ∝ h^{2} ∝ N^{ − 2/D} where D is the dimensionality (cf. Springel 2010b). However, the discretization of the gas into particles introduces additional errors, so the error scales less well than secondorder (e.g. L1 ∝ N^{1} log N; e.g. Monaghan 1991). Figure 12 demonstrates the L1 error norm as a function of total particle number. We see that the L1 error norm decreases with increasing particle number, and therefore converges with increasing resolution. Also plotted in Fig. 12 is the expected scaling for an ideal secondorder scheme. It can be seen that the convergence rate is similar to the ideal case, but a little shallower suggesting discretization errors are reducing the effective order of the scheme.
Fig. 12 L1 error norm as a function of particle number for the static polytrope test. The expected behaviour for an ideal 2ndorder numerical hydrodynamics scheme, L1 ∝ N^{ − 2/3}, is also plotted for reference (blue dashed line).

Open with DEXTER
10.9. BossBodenheimer test
Fig. 13 SPH and sink particle plots of BossBodenheimer test at times a) t = 0.025 Myr, b) t = 0.033 Myr and c) t = 0.055 Myr. SPH particles are represented by black dots (only one in every three plotted for clarity) and the position and motion of the sink particles are represented by the red lines. The first tile (t = 0.025 Myr) shows the particle distribution just after the formation of the two sinks in the condensations that form either end of the bar. The subsequent times shows the motion of the sink particles as they move with the gas and the small disks that form around each sink. All figures show the region −0.005 < x < 0.005, −0.005 < y < 0.005.

Open with DEXTER
The BossBodenheimer test (Boss & Bodenheimer 1979) is a standard test of star formation codes designed to investigate the nonaxisymmetric collapse and fragmentation of a rotating, selfgravitating gas cloud. The rotating cloud is seeded with an m = 2 azimuthal perturbation and therefore collapses under selfgravity and forms a barlike structure. At the ends of the bar, dense condensations are formed.
The initial conditions are set up as follows. A relaxed (i.e. glasslike) uniform density sphere (see Sect. 10.1, for details) is rescaled to produce the correct total mass, M = 1 M_{⊙}, radius, R = 3.2 × 10^{16} cm, and density ρ_{0} = 1.44 × 10^{17} g cm^{3}. We then add a sinusoidal, azimuthal density perturbation of the form (68)where φ is the azimuthal angle about the zaxis, A = 0.5 is the magnitude of the perturbation, and m = 2 is the order of the azimuthal perturbation. The density perturbation is achieved by altering the particle positions rather than changing the masses of the particles. The cloud is initially set in solidbody rotation with an angular velocity of Ω = 1.6 × 10^{12} rad s^{1}. In our simulation, we use a barotropic EOS (Eq. (26) with T_{0} = 10 K and ρ_{CRIT} = 10^{14} g cm^{3}) in order to set a minimum scale for fragmentation of the cloud. We use sink particles with a sink formation density of ρ_{SINK} = 2 × 10^{12} g cm^{3} and sink radius r_{SINK} = 2 h_{FORM} where is the smoothing length of the SPH particle that triggers sink formation. The freefall collapse timescale of the original unperturbed cloud is t_{FF} = 17.4 yr. We use 50 000 SPH particles in the original cloud in order to adequately resolve gravitational fragmentation with our choice of EOS (Bate & Burkert 1997; Hubber et al. 2006). The simulation is run until a time of t = 100 kyr.
The gas initially collapses under selfgravity to form a thin, dense “bar” with two denser condensations at either end. The barotropic EOS (along with the relatively low resolution of the bar) prevents the bar collapsing to high densities once its density exceeds . The denser condensations at either end of the bar are able to collapse to higher densities. Eventually, the two condensations form sinks. Figure 13a shows the particle positions just after the formation of the two sinks. The gas surrounding the sinks has some angular momentum relative to the sinks (from the original rotational field of the cloud) and assembles into two small disks which are connected together by the bar. Subsequently, the two sinks follow eccentric orbits with a series of close approaches, during which the increased compression loads more mass into the disks, from both the surrounding gas and the bar. This leads to a period of rapid accretion, followed by a relatively quiet period as the sinks move towards apastron and the accretion rate drops off. We note that in the presence of a reservoir of gas that constantly feeds accretion, the orbital properties of the system change continuously until the gas supply becomes negligible.
10.10. 3body tests
Since the Nbody integrator in SEREN is intended to follow smallN systems, it is appropriate to perform 3body tests for which accurate solutions are known (rather then largeN tests to which only statistical constraints can be applied). We limit ourselves to two such tests.
The first test is the figureeight 3body problem defined by Chenciner & Montgomery (2000). The initial conditions for this test are summarised in Table 2 (left side). With these initial conditions, all three particles follow the same figureeight trajectory, with period . We have evolved this system using SEREN’s Hermite Nbody integrator with a timestep multiplier of γ = 0.05, without the trajectory being corrupted. Figure 14 shows the trajectory, and the positions of the three stars at for , demonstrating that the stars return to the same positions every period. After 100 orbits, energy is conserved to better than one part in 10^{6}, and the errors in the net linear and angular momenta are of order machine rounding error. The Hermite integrator therefore appears to be very stable.
The second test is the 3body problem devised by Burrau (1913), in which three particles are placed at the vertices of a rightangled triangle with sides 5, 4 and 3, and each particle has a mass equal to the length of the side opposite it. The initial conditions for this test are summarised in Table 2 (right side). The subsequent evolution involves close encounters (separations  Δr_{ij}  ≲ 10^{3}), and is therefore highly chaotic. The Burrau problem was first integrated numerically, to the point where one star is ejected permanently, by Szebehely & Peters (1967), using the twodimensional LeviCivita (1904) regularisation method. We have evolved this system up to t = 70, using SEREN’s Hermite integrator with a low timestep multiplier of γ = 0.02 and a smoothing length of h = 10^{4}. Energy is conserved to one part in 10^{7}, and the errors in the net linear and angular momenta are of order machine rounding error. In Figs. 15 and 16 we plot orbital tracks for the same time intervals as Szebehely & Peters (1967) and using the same line styles. The close agreement between our tracks and those of Szebehely & Peters (1967) demonstrates the accuracy and robustness of SEREN’s Hermite Nbody integrator.
Fig. 14 Tracks for the first 20 periods of the figureeight 3body problem. The positions of the stars are plotted every period, with solid black dots.

Open with DEXTER
Fig. 15 Tracks for the Burrau problem in the time intervals a) 0 < t < 10, b) 10 < t < 20, and c) 20 < t < 30. The dotted lines track star 1, the dashed lines star 2, and the solid lines star 3. Each track includes solid dots at intervals of one time unit (i.e. at t = 1, 2, 3, etc.). These tracks should be compared with those presented by Szebehely & Peters (1967, their Figs. 2–4).

Open with DEXTER
Fig. 16 As Fig. 15, but for the time intervals d) 30 < t < 40, e) 40 < t < 50, and f) 50 < t < 60. These tracks should be compared with Figs. 5–7 in Szebehely & Peters (1967).

Open with DEXTER
11. Memory and cache optimisations
Here we describe the features of SEREN which are designed to improve cache performance and reduce overall memory usage.
11.1. Particle reordering
Particle data arrays are arranged in treewalk order, i.e. the order in which individual particles are interrogated during a treewalk. This ensures that all particles in the same leaf cell are contiguous in memory, and particles in nearby branches are likely to be in a nearby (if not contiguous) part of the memory, i.e. they are likely to be within the same cache block. This requires that the data arrays are repeatedly reordered, but the computational cost of reordering is relatively low compared with the run time saved by optimising the cache usage. For large numbers of particles run times are more than halved. We do not use a more sophisticated spacefilling curve, such as the Hilbert spacefilling curve used in GADGET 2 (Springel 2005), which is optimal for distributedmemory architectures requiring large amounts of communication between nodes.
11.2. Grouping particle data
Since the run times of most SEREN simulations are dominated by the routines that compute gravitational accelerations, we group together in a single array all the data required for particleparticle gravitational interactions (i.e. position, mass, smoothing length). This optimises cache usage by ensuring that all the data required for calculating the gravitational interaction due to a particle is loaded in the same cache block, and therefore avoids thrashing the memory while loading the required variables.
11.3. Minimising memory allocation
For subroutines that compute SPH sums, we first walk the neighbour tree to obtain a potentialneighbour list. In the first instance, the code only allocates a small amount of memory to store the potential neighbour list ( elements, where N_{MAX} ≪ N), in order to reduce memory fragmentation. For example, in a 3D simulation, the expected mean number of neighbours might be (in the gradh formulation, ), and in this case an appropriate choice would be N_{MAX} = 200). Then, in the rare instances where more than potential neighbours are found (e.g. an isolated particle with a very large smoothing length), the memory is deallocated and reallocated to N elements.
12. Parallelisation
SEREN is parallelised using OpenMP, for use on sharedmemory architectures (for example, symmetric multiprocessing (SMP) and nonuniform memory access (NUMA) machines).OpenMP requires that each processor can see all the data, and so there is no need for any explicit transfer of data between each processor’s RAM, although there is some overhead associated with transferring data from the shared RAM to the local caches of individual processors. OpenMP works by parallelising doloops. If the operations executed in each cycle of a loop are independent of those executed in the other cycles, this can be achieved simply by adding OpenMP directives at the beginning and end of the loop. The cycles of the loop are then farmed out to the available processors; if there are N cycles (corresponding to N particles) and N_{p} processors, each processor receives N_{BATCH} = N/N_{p} cycles to execute.
The scaling of a parallel code, , is defined as the wallclock time, t(1), the code takes to perform a reference simulation on one processor, divided by the time, t(N_{p}), it takes to perform the same simulation on N_{p} processors, i.e. . A perfectly scaling code has , but normally scaling is less than perfect, because (i) some fraction of the code is inherently serial and cannot be parallelised (Amdahl’s law); (ii) the code is not perfectly loadbalanced at all times (i.e. not all processors are equally busy at all times); and (iii)there is latency, for example due to communication of data between the OpenMP master node and the slave nodes. In SEREN, these difficulties are compounded by the implementation of hierarchical block timesteps (see Sect. 6.3).
The main routines in SEREN are those that (a) construct and stock the tree, (b) determine the SPH smoothing lengths, densities and other local functions of state, (c) compute the hydrodynamic accelerations and heating terms, (d) compute the gravitational accelerations, and (e) advance the particle positions, velocities and internal energies. Of these the last four can be parallelised quite straightforwardly and effectively, but the first (treebuilding) can not. In particular, the assigning of new tree cells, the construction of linked lists, and the reordering of particles (see Sect. 11.1) can not be parallelised efficiently, and it is these elements, along with the other smaller serial sections of code, that ultimately limit the scalability of SEREN.
Even if the operations executed in each cycle of a doloop are independent, naïve application of OpenMP directives to the beginning and end of the doloop will not guarantee load balancing, because the individual cycles do not necessarily entail similar amounts of computation. For example, walking the gravity tree is a much more computeintensive operation for a particle in the densest regions of a fragmenting prestellar core than for a particle in the diffuse outer envelope of the same core. Therefore, in order to improve load balancing, the code delivers to each processor a small batch of cycles, and when the processor is finished executing these cycles it requests another batch. We find, empirically, that SEREN runs most efficiently with N_{BATCH} ~ 10^{3}N/N_{p}.
When hierarchical block timesteps are used, SEREN maintains a list of the IDs of all the active particles (i.e. the particles whose accelerations and heating terms are being computed on the current timestep). Load balancing is then achieved by only looping over this active list, and farming out batches of size N_{BATCH} ~ 10^{3}N_{ACTIVE}/N_{p} to the individual processors.
12.1. Scaling tests
To test the scaling of SEREN we revisit the collapse of a spherical isothermal cloud which initially is at rest with uniform density (see Sect. 10.7). We model the cloud with 10^{6} particles, and follow the evolution to dimensionless time t = 0.6, using global timesteps. Since the cloud does not develop any complicated internal structure, this is a relatively undemanding test. Figure 17a shows the net scaling obtained on a 16core SMP node of the Cardiff University Merlin cluster, using 1, 2, 4, 8 and 16 processors. The scaling is good up to 8 processors, but for 16 processors is starting to deteriorate (). This indicates that SEREN is not likely to be able to exploit SMP machines with 100+ cores. Figure 17b shows how the main routines in SEREN scale individually. Evidently the gravity routines scale very well, almost perfectly; the SPH routines start to deteriorate at 8 processors (); and the treebuilding routines scale very poorly. It is the treebuilding routines that limit the net scaling.
Fig. 17 a) Net scaling of SEREN, using OpenMP on a 16core SMP machine, as a function of the number of processors. b) Scaling of the individual gravity, SPH and treebuilding routines, as a function of the number of processors.

Open with DEXTER
13. Future development
We are continuing to develop SEREN and add new features. Some of these features have already been implemented in our development code and will be released to the main working version of SEREN once they are fully tested and debugged. The most important of these additions are (i) an MPIparallelised version of the code (McLeod et al., in prep.); (ii) an hybrid fluxlimited diffusion and radiative cooling scheme (Forgan et al. 2009); (iii) the use of different timesteps for hydrodynamical and gravitational accelerations (Saitoh & Makino 2010); (iv) improved sink particles with feedback; (v) an integrated Nbody and SPH integrator to model cluster dynamics with a live gas potential; (vi) ideal MHD using divergence cleaning and/or Euler potentials (Price & Monaghan 2004a,b, 2005; Rosswog & Price 2007a); and (vii) nonideal MHD (Hosking & Whitworth 2004). The MPI version of SEREN will be a hybrid MPI/OpenMP code that can parallelise a group of shared memory nodes using MPI communication to link them together. This will reduce the amount of communication between nodes, which is often the bottleneck to good scalability over a large number of processors. The remaining additions to SEREN are implementations of existing algorithms. We will provide uptodate information on the development status of SEREN, and any further tests we have performed, at the web address http://www.astro.group.shef.ac.uk/seren.
Acknowledgments
We would like to thank Simon Goodwin for providing the DRAGON SPH code to the authors on which some of the initial development of SEREN was based upon. We would also like to thank Sumedh Anathpindika, Thomas Bisbas, Steinar Børve, Murat Kaplan, Dimitrios Stamatellos, Jan Trulsen, Stephanie Walch & Richard Wünsch for helpful suggestions and comments during the development of the codeand for donating some routines to SEREN. We also thank the anonymous referee for useful suggestions that have improved the paper. D.A.H. is funded by a Leverhulme Trust Research Project Grant (F/00 118/BJ). C.P.B. is funded by an STFC studentship. A.M. is funded by an STFC studentship and was funded as an EarlyStage Researcher by the ECfunded CONSTELLATION Marie Curie Training Network MRTNCT2006035890. A.P.W. gratefully acknowledges the support of the STFC rolling grant PP/E000967/1, and the CONSTELLATION network. We thank Daniel Price for the use SPLASH (Price 2007a) for creating some images.
References
 Aarseth, S. J. 2001, NewA, 6, 277 [NASA ADS] [CrossRef] [Google Scholar]
 Aarseth, S. J. 2003, Gravitational Nbody Simulations: Tools and Algorithms (Cambridge University Press) [Google Scholar]
 Abel, T., Bryan, G. I., & Norman, M. L., 2002, Science, 295, 93 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Agertz, O., Moore, B., Stadel, J., et al. 2007, MNRAS, 380, 963 [NASA ADS] [CrossRef] [Google Scholar]
 Balsara, D. S. 1995, JCoPh, 121, 357 [NASA ADS] [CrossRef] [Google Scholar]
 Barnes, J., & Hut, P. 1986, Nature, 324, 446 [NASA ADS] [CrossRef] [Google Scholar]
 Bate, M. R., & Burkert, A. 1997, MNRAS, 288, 1060 [NASA ADS] [CrossRef] [Google Scholar]
 Bate, M. R., Bonnell, I. A., & Price, N. M. 1995, MNRAS, 277, 362 [NASA ADS] [CrossRef] [Google Scholar]
 Benz, W. 1990, Numerical Modelling of Nonlinear Stellar Pulsations: Problems and Prospects (Kluwer Academic Publishers), ed. Buchler, J. R., 269 [Google Scholar]
 Bisbas, T. G., Wünsch, R., Whitworth, A. P., & Hubber, D. A. 2009, A&A, 497, 649 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Boss, A. P., & Bodenheimer, P. 1979, ApJ, 234, 289 [NASA ADS] [CrossRef] [Google Scholar]
 Burrau, C. 1913, AN, 195, 113 [NASA ADS] [Google Scholar]
 Cartwright, A., & Stamatellos, D. 2010, A&A, 516, A99 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Cha, S. H., & Whitworth, A. 2003, MNRAS, 340, 73 [NASA ADS] [CrossRef] [Google Scholar]
 Chandrasekhar, S. 1939, An Introduction to the Study of Stellar Structure (New York: Dover Publs. Inc.;) [Google Scholar]
 Chenciner, A., & Montgomery, R. 2000, AnMat, 152, 881 [Google Scholar]
 Delgado Donate, E. J., Clarke, C. J., & Bate, M. R. 2003, MNRAS, 342, 1926 [NASA ADS] [CrossRef] [Google Scholar]
 Forgan, D., Rice, K., Stamatellos, D., & Whitworth, A. P. 2009, MNRAS, 394, 882 [NASA ADS] [CrossRef] [Google Scholar]
 Fryxell, B., Olson, K., Ricker, P., et al. 2000, ApJS, 131, 273 [NASA ADS] [CrossRef] [Google Scholar]
 Gingold, R. A., & Monaghan, J. J. 1977, MNRAS, 181, 375 [NASA ADS] [CrossRef] [Google Scholar]
 Hernquist, L. 1987, ApJS, 64, 715 [NASA ADS] [CrossRef] [Google Scholar]
 Hernquist, L., & Katz, N. 1989, ApJS, 70, 419 [NASA ADS] [CrossRef] [Google Scholar]
 Hernquist, L., Bouchet, F. R., & Suto, Y. 1991, ApJS, 75, 231 [NASA ADS] [CrossRef] [Google Scholar]
 Hosking, J. G., & Whitworth, A. P. 2004, MNRAS, 347, 994 [NASA ADS] [CrossRef] [Google Scholar]
 Hubber, D. A., Goodwin, S. P., & Whitworth, A. P. 2006, 450, 881 [Google Scholar]
 Inutsuka, S. 2002, JCoPh, 179, 238 [NASA ADS] [CrossRef] [Google Scholar]
 Klessen, R. S. 1997, MNRAS, 292, 11 [NASA ADS] [CrossRef] [Google Scholar]
 Klessen, R. S., Heitsch, F., & Mac Low, M.M. 2000, ApJ, 535, 887 [NASA ADS] [CrossRef] [Google Scholar]
 LeviCivita, T. 1904, Ann. Mat. Ser., 9, 1 [Google Scholar]
 Lucy, L. 1977, AJ, 82, 1013 [NASA ADS] [CrossRef] [Google Scholar]
 Martin, G. E. 1998, Geometric constructions (SpringerVerlag) [Google Scholar]
 Makino, J. 1991, ApJ, 369, 200 [NASA ADS] [CrossRef] [Google Scholar]
 Makino, J., & Aarseth, S. J. 1992, PASJ, 44, 141 [NASA ADS] [Google Scholar]
 Makino, J., Fukushige, T., Koga, M., & Namura, K. 2003, PASJ, 55, 1163 [NASA ADS] [CrossRef] [Google Scholar]
 McMillan, S. L. W., & Aarseth, S. J. 1993, AJ, 414, 200 [NASA ADS] [CrossRef] [Google Scholar]
 Merlin, E., Buonomo, U., Grassi, T., Piovan, L., & Chiosi, C. 2010, A&A, 513, 36 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Monaghan, J. J. 1992, ARA&A, 30, 543 [NASA ADS] [CrossRef] [Google Scholar]
 Monaghan, J. J. 1997, JCoPh, 136, 298 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Monaghan, J. J. 2002, MNRAS, 335, 843 [NASA ADS] [CrossRef] [Google Scholar]
 Monaghan, J. J. 2005, RPPh, 68, 1703 [NASA ADS] [CrossRef] [Google Scholar]
 Monaghan, J. J. 2006, MNRAS, 365, 199 [NASA ADS] [CrossRef] [Google Scholar]
 Monaghan, J. J., & Gingold, R. A. 1983, J. Comp. Phys, 52, 374 [NASA ADS] [CrossRef] [Google Scholar]
 Monaghan, J. J., & Lattanzio, J. C. 1985, A&A, 149, 135 [NASA ADS] [Google Scholar]
 Morris, J. P. 1996, PhD Thesis – Analysis of Smoothed Particle Hydrodynamics with Applications, Monash University [Google Scholar]
 Morris, J. P., & Monaghan, J. J. 1997, JCoPh, 136, 41 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Nelson, R. P., & Papaloizou, J. C. B. 1994, MNRAS, 270, 1 [NASA ADS] [Google Scholar]
 Nitadori, K., & Makino, J. 2008, NewA, 13, 498 [NASA ADS] [CrossRef] [Google Scholar]
 Pfalzner, S., & Gibbon, S. 1996, Manybody tree methods in Physics (Cambridge University Press) [Google Scholar]
 Portegies Zwart, S. F., McMillan, S. L.W, Hut, P., & Makino, J. 2001, MNRAS, 321, 199 [NASA ADS] [CrossRef] [Google Scholar]
 Price, D. J. 2007, PASA, 24, 159 [NASA ADS] [CrossRef] [Google Scholar]
 Price, D. J. 2008, JCoPh, 227, 10040 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Price, D. J., & Monaghan, J. J. 2004a, MNRAS, 348, 123 [NASA ADS] [CrossRef] [Google Scholar]
 Price, D. J., & Monaghan, J. J. 2004b, MNRAS, 348, 139 [NASA ADS] [CrossRef] [Google Scholar]
 Price, D. J., & Monaghan, J. J. 2005, MNRAS, 364, 384 [NASA ADS] [Google Scholar]
 Price, D. J., & Monaghan, J. J. 2007, MNRAS, 374, 1347 [NASA ADS] [CrossRef] [Google Scholar]
 Read, J. I., Hayfield, T., & Agertz, O. 2010, MNRAS, 405, 1513 [NASA ADS] [Google Scholar]
 Riley, K. F., Hobson, M. P., & Bence, S. J. 1998, Mathematical methods for physics and engineering (Cambridge University Press) [Google Scholar]
 Rosswog, S., & Price, D. J. 2007, MNRAS, 379, 915 [NASA ADS] [CrossRef] [Google Scholar]
 Rosswog, S., Davies, M.B., Thielemann, F.K., & Piran, T. 2000, A&A, 360, 171 [NASA ADS] [Google Scholar]
 Saigo, K., & Tomisaka, K. 2006, ApJ, 645, 381 [NASA ADS] [CrossRef] [Google Scholar]
 Saitoh, T. R., & Makino, J. 2009, ApJ, 697, 99 [NASA ADS] [CrossRef] [Google Scholar]
 Saitoh, T. R., & Makino, J. 2010, PASJ, 62, 301 [NASA ADS] [Google Scholar]
 Sedov, L. I. 1959, Similarity and Dimensional Methods in Mechanics (New York: Academic Press) [Google Scholar]
 Sod, G. A. 1978, JCoPh., 27, 1 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Springel, V. 2005, MNRAS, 364, 1105 [NASA ADS] [CrossRef] [Google Scholar]
 Springel, V. 2010, MNRAS, 401, 791 [NASA ADS] [CrossRef] [Google Scholar]
 Springel, V., & Hernquist L. 2002, MNRAS, 333, 649 [NASA ADS] [CrossRef] [Google Scholar]
 Springel, V., White, S. D. M., Jenkins, A., et al. 2005, Nature 435, 629 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Springel, V., Yoshida, N., & White, S. D. M. 2001, NewA, 6, 79 [NASA ADS] [CrossRef] [Google Scholar]
 Stamatellos, D., Whitworth, A. P., Bisbas, T., & Goodwin, S. P. 2007, MNRAS, 475, 37 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Stiefel, E. L., & Scheifele, G. 1971, Linear and regular celestial mechanics (SpringerVerlag) [Google Scholar]
 Stone, J. M., & Norman, M. L. 1992, AJS, 80, 753 [Google Scholar]
 Szebehely, V., & Peters, C. F. 1967, AJ, 72, 876 [NASA ADS] [CrossRef] [Google Scholar]
 Teyssier, R. 2002, A&A, 385, 337 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Thomas, P. A., & Couchman, H. M. P. 1992, MNRAS, 257, 11 [NASA ADS] [CrossRef] [Google Scholar]
 Truelove, J. K., Klein R. I., McKee, C. F., et al. 1998, ApJ, 495, 821 [NASA ADS] [CrossRef] [Google Scholar]
 Van Albada, T. S. 1968, BAN, 19, 479 [NASA ADS] [Google Scholar]
 Wadsley, J. W., Stadel, J., & Quinn, T. 2004, NewA, 8, 137 [NASA ADS] [CrossRef] [Google Scholar]
 Wetzstein, M., Nelson, A. F., Naab, T., & Burkert, A. 2009, ApJS, 184, 298 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Kernel functions
A.1. M4 cubic spline kernel
The M4 cubic spline kernel (Monaghan & Lattanzio 1985) is used in many implementations of SPH, due to its simple form and its compact support. The M4 kernel is a function of s ≡ r/h only. For D = 1,2, and 3 dimensions, it takes the form (A.1)where σ_{1} = 2/3, σ_{2} = 10/7π, and σ_{3} = 1/π. The first spatial derivative is (A.2)SEREN also allows the modified derivative proposed by Thomas & Couchman (1992) to prevent the clumping instability, (A.3)For “gradh” SPH, the Ω correction kernel function is given by (A.4)For kernelsoftened gravity (three dimensions only), the kernel function φ′ is (A.5)For calculating the gravitational potential, the kernel function φ is (A.6)For “gradh” gravity (Price & Monaghan 2007), the kernel function ζ is calculated using (A.7)
A.2. Quintic spline kernel
The quintic spline kernel (Morris 1996) is a fifthorder polynomial function with compact support. It was originally presented in the form of a factorised polynomial. However, to facilitate the processes of differentiation and integration that are required to compute the other kernel functions, we expand the brackets into a simple power series: (A.8)where s ≡ r/h and σ_{1} = 120, σ_{2} = 7/478π, and σ_{3} = 3/359π. The first spatial derivative is (A.9)For “gradh” SPH, (A.10)For kernelsoftened gravity (three dimensions only), the kernel function φ′ is (A.11)The gravitational potential kernel φ is (three dimensions only) (A.12)For “gradh” gravity (three dimensions only), the kernel function ζ is calculated using (A.13)
Appendix B: Multipole moments
When calculating gravitational accelerations, using the BarnesHut gravity tree, SEREN calculate the contribution from a cell up to octupole order, if requested. The multipole moments of each cell are computed relative to the centre of mass of the cell; this means that the dipole term is always zero. The components of the quadrupole moment tensor, Q, for a leaf cell, c, are given by (B.1)where the summation is over all the particles i in the leaf cell. If the cell is not a leaf cell, the quadrupole moment tensor is given by (B.2)where the summation is over all the daughter cells d. The octupole moment tensor, S, for a leaf cell, c, is given by and for a nonleaf cell by
All Tables
Initial conditions for the adiabatic Sod test (Cols. 2 and 3), and for the colliding flows test (Cols. 4 and 5).
All Figures
Fig. 1 Results of the adiabatic shock test using the “gradh” SPH formulation (Price & Monaghan 2004a) showing a) the density, b) the xvelocity, c) the thermal pressure, and d) the specific internal energy after a time t = 1.0. The black dots represent the results from the SPH simulation and the red lines show the semianalytic solution obtained using a Riemann solver.

Open with DEXTER
In the text
Fig. 2 Results of the colliding flows test using the standard SPH equations with the Monaghan (1997) artificial viscosity showing a) the density and b) the xvelocity, after a time t = 0.6. The black dots represent the results from the SPH simulation and the red lines show the analytic solution.

Open with DEXTER
In the text
Fig. 3 Results of the colliding flows test using the standard SPH equations and timedependent (α, β) viscosity (Morris & Monaghan 1997) showing a) the density and b) the xvelocity, after a time t = 0.6. The black dots represent the results from the SPH simulation and the red lines show the analytic solution.

Open with DEXTER
In the text
Fig. 4 Results of the Sedov blast wave test at a time t = 0.02 using a) global timesteps; b) individual block timesteps; c) individual timesteps with the timesteplimiter described in Sect. 6.3 and in Saitoh & Makino (2009). The block dots represent the SPH results and the red line shows the semianalytic solution provided by Sedov (1959).

Open with DEXTER
In the text
Fig. 5 Development of the KelvinHelmholtz instability for the lowresolution case (toprow; 12 242 particles) and the highresolution case (bottomrow; 98 290 particles). The plots show the evolution of the densityfield (colour bar on righthand side) at times t = 0.5, 1.0 and 1.5 (left, middle and right columns respectively).

Open with DEXTER
In the text
Fig. 6 a) The rootmeansquare fractional force error computing the gravitational forces for all particles in a uniformdensity sphere with the BarnesHut tree using the Geometric MAC as a function of , and b) the ratio of CPU time for computing all gravitational forces with the tree to directsummation as a function ϵ. The gravitational accelerations are calculated without kernelsoftening, up to monopole (blue diamonds), quadrupole (solid black circles) and octupole (red triangles) order.

Open with DEXTER
In the text
Fig. 7 a) The rootmeansquare fractional force error computing the gravitational forces for all particles in a uniformdensity sphere with the BarnesHut tree using the Eigenvalue MAC as a function of , and b) the ratio of CPU time for computing all gravitational forces with the tree to directsummation as a function ϵ. The gravitational accelerations are calculated without kernelsoftening, up to quadrupole (solid black circles) and octupole (red triangles) order.

Open with DEXTER
In the text
Fig. 8 Scaling characteristics of the BarnesHut tree code in SEREN. The time taken to compute gravitational forces for all particles for directsummation (solid black circles) and the BarnesHut tree (red triangles) as a function of particle number. For reference, we show the expected scaling for N^{2} (dashed line) and N log N (solid red line).

Open with DEXTER
In the text
Fig. 9 a) Freefall collapse of a pressureless, uniformdensity sphere. The figure shows the analytic solution (dashed lines), and the radial position of three representative particles at 90%, 50% and 10% mass radii (filled circles). b) Same as a), but with time measured from the end of the collapse and using logarithmic axis.

Open with DEXTER
In the text
Fig. 10 Collapse of a uniform density sphere with an isothermal equation of state and dimensionless isothermal sound speed c_{s} = 1. The figure shows the analytic solution for pressureless freefall collapse (solid red lines) and the radial position of the 90%, 50% and 10% mass radii (blue dashed lines). The black dotdashed line shows the analytic solution for the progression of the rarefaction wavefront.

Open with DEXTER
In the text
Fig. 11 Results of the polytrope test for an η = 5/3 polytrope, using a) 114, b) 1086, and c) 10^{5} SPH particles.

Open with DEXTER
In the text
Fig. 12 L1 error norm as a function of particle number for the static polytrope test. The expected behaviour for an ideal 2ndorder numerical hydrodynamics scheme, L1 ∝ N^{ − 2/3}, is also plotted for reference (blue dashed line).

Open with DEXTER
In the text
Fig. 13 SPH and sink particle plots of BossBodenheimer test at times a) t = 0.025 Myr, b) t = 0.033 Myr and c) t = 0.055 Myr. SPH particles are represented by black dots (only one in every three plotted for clarity) and the position and motion of the sink particles are represented by the red lines. The first tile (t = 0.025 Myr) shows the particle distribution just after the formation of the two sinks in the condensations that form either end of the bar. The subsequent times shows the motion of the sink particles as they move with the gas and the small disks that form around each sink. All figures show the region −0.005 < x < 0.005, −0.005 < y < 0.005.

Open with DEXTER
In the text
Fig. 14 Tracks for the first 20 periods of the figureeight 3body problem. The positions of the stars are plotted every period, with solid black dots.

Open with DEXTER
In the text
Fig. 15 Tracks for the Burrau problem in the time intervals a) 0 < t < 10, b) 10 < t < 20, and c) 20 < t < 30. The dotted lines track star 1, the dashed lines star 2, and the solid lines star 3. Each track includes solid dots at intervals of one time unit (i.e. at t = 1, 2, 3, etc.). These tracks should be compared with those presented by Szebehely & Peters (1967, their Figs. 2–4).

Open with DEXTER
In the text
Fig. 16 As Fig. 15, but for the time intervals d) 30 < t < 40, e) 40 < t < 50, and f) 50 < t < 60. These tracks should be compared with Figs. 5–7 in Szebehely & Peters (1967).

Open with DEXTER
In the text
Fig. 17 a) Net scaling of SEREN, using OpenMP on a 16core SMP machine, as a function of the number of processors. b) Scaling of the individual gravity, SPH and treebuilding routines, as a function of the number of processors.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
