Asteroseismology of red giants from the first four months of Kepler data: Fundamental stellar parameters
^{1}
Institute for Astronomy (IfA), University of Vienna,
Türkenschanzstrasse 17,
1180
Vienna,
Austria
email: kallinger@phas.ubc.ca
^{2}
Department of Physics and Astronomy, University of British
Columbia, 6224 Agricultural Road,
Vancouver, BC
V6T 1Z1,
Canada
^{3}
LESIA, CNRS, Université Pierre et Marie Curie, Université Denis,
Diderot, Observatoire de Paris, 92195
Meudon Cedex,
France
^{4}
School of Physics and Astronomy, University of Birmingham,
Edgbaston,
Birmingham
B15 2TT,
UK
^{5}
Sydney Institute for Astronomy (SIfA), School of Physics,
University of Sydney, NSW, 2006, Australia
^{6}
High Altitude Observatory, NCAR,
PO Box 3000, Boulder, CO
80307,
USA
^{7}
Department of Astronomy, Yale University,
PO Box 208101, New Haven, CT
065208101,
USA
^{8}
Instituut voor Sterrenkunde, K.U. Leuven,
Celestijnenlaan 200D,
3001
Leuven,
Belgium
^{9}
Danish AsteroSeismology Centre (DASC), Department of Physics and
Astronomy, Aarhus University, 8000
Aarhus C,
Denmark
^{10}
Laboratoire AIM, CEA/DSMCNRS, Université Paris 7 Diderot,
IRFU/SAp, Centre de Saclay,
91191, GIfsurYvette, France
^{11}
Institute for Computational Astrophysics, Department of Astronomy
and Physics, Saint Marys University, Halifax, NS
B3H 3C3,
Canada
^{12}
NASA Ames Research Center, MS 24430, Moffett Field, CA
94035,
USA
^{13}
Department of Physics and Astronomy, Building 1520, Aarhus
University, 8000
Aarhus C,
Denmark
^{14}
Space Telescope Science Institute, 3700 San Martin Drive, Baltimore, MD
21218,
USA
Received:
23
June
2010
Accepted:
28
August
2010
Context. Clear power excess in a frequency range typical for solartype oscillations in red giants has been detected in more than 1000 stars, which have been observed during the first 138 days of the science operation of the NASA Kepler satellite. This sample includes stars in a wide mass and radius range with spectral types G and K, extending in luminosity from the bottom of the giant branch up to highluminous red giants, including the red bump and clump. The highprecision asteroseismic observations with Kepler provide a perfect source for testing stellar structure and evolutionary models, as well as investigating the stellar population in our Galaxy.
Aims. We aim to extract accurate seismic parameters from the Kepler time series and use them to infer asteroseismic fundamental parameters from scaling relations and a comparison with redgiant models.
Methods. We fit a global model to the observed power density spectra, which allows us to accurately estimate the granulation background signal and the global oscillation parameters, such as the frequency of maximum oscillation power. We find regular patterns of radial and nonradial oscillation modes and use a new technique to automatically identify the mode degree and the characteristic frequency separations between consecutive modes of the same spherical degree. In most cases, we can also measure the small separation between l = 0, 1, and 2 modes. Subsequently, the seismic parameters are used to estimate stellar masses and radii and to place the stars in an HR diagram by using an extensive grid of stellar models that covers a wide parameter range. Using Bayesian techniques throughout our entire analysis allows us to determine reliable uncertainties for all parameters.
Results. We provide accurate seismic parameters and their uncertainties for a large sample of red giants and determine their asteroseismic fundamental parameters. We investigate the influence of the stars' metallicities on their positions in the HR diagram. Finally, we study the redgiant populations in the red clump and bump and compare them to a synthetic population. We find a mass and metallicity gradient in the red clump and clear evidence of a secondaryclump population.
Key words: stars: latetype / stars: oscillations / stars: fundamental parameters
© ESO, 2010
1. Introduction
Studying solartype oscillations has proved to be a powerful way to test the physical processes in stars (e.g. ChristensenDalsgaard 2004) that are similar to our Sun and also to the more evolved red giants, which represent the future of our Sun. The turbulent motions in the convective envelopes of these stars produce an acoustic noise that can stochastically drive (and damp) resonant pmode oscillations, typically with small amplitudes. On the other hand, the global properties of solartype oscillations, such as the frequency range where they are excited to observable amplitudes and their characteristic spacings, are predominantly defined by the stellar mass and radius. By using accurate asteroseismic data, it should therefore be possible to constrain fundamental parameters to levels of precision that would otherwise be impossible. This has important applications in, for example, exoplanet studies, which depend on firm knowledge of the fundamental parameters of the host star. Asteroseismic data can put tight constraints on the absolute radii of transiting planets, or determine the age of an exoplanetary system (e.g. ChristensenDalsgaard et al. 2010).
An obvious requirement for such asteroseismic studies is the availability of accurate observational data. The first indications of solartype oscillations in G and Ktype giants were based on groundbased observations in radial velocity (Arcturus: Merline 1999; ξ Hya: Frandsen et al. 2002; ϵ Oph: De Ridder et al. 2006) and photometry (M 67: Stello et al. 2007), which largely suffered from low signaltonoise data sets and aliasing. The periods of solartype oscillations in red giants range from hours to days and hence call for long and preferably uninterrupted observations to resolve the oscillations, which can be done best from space. Spacebased detection were made with the star tracker of the Wide Field Infrared Explorer satellite (WIRE; e.g. Buzasi et al. 2000; Retter et al. 2003), the Hubble Space Telescope (HST; e.g. Edmonds & Gilliland 1996; Kallinger et al. 2005; Stello & Gilliland 2009), Microvariability and Oscillation of Stars (MOST; Barban et al. 2007; Kallinger et al. 2008a,b), and the Solar Mass Ejection Imager (SMEI; Tarrant et al. 2007). Significant improvement in quality and quantity of the observations came from the 150day long observations with the Convection, Rotation and planetary Transits satellite (CoRoT), which provided clear detections of radial and nonradial oscillation modes in numerous stars (De Ridder et al. 2009; Hekker et al. 2009; Carrier et al. 2010; Kallinger et al. 2010; Mosser et al. 2010). Most recently, the NASA Kepler Mission has demonstrated its great asteroseismic potential to observe solartype oscillations in red giants (Bedding et al. 2010; Hekker et al. 2010b; Stello et al. 2010). We refer to our companion papers presenting a more detailed study of the asteroseismic observables (Huber et al. 2010) and a comparison of global oscillation parameters derived using different methods (Hekker et al. 2010c).
The oscillation spectrum of a solartype oscillating star presents a pattern of modes with nearly regular frequency spacings, where the signature of these spacings carries information about the internal structure of the star. The large frequency spacing (Δν), for example, is the frequency differences between consecutive overtones having the same spherical degree (l), and is related to the acoustic radius and therefore to the mean density of the star (Brown et al. 1991; Kjeldsen & Bedding 1995). Another directly accessible seismic parameter, the frequency of maximum oscillation power (ν_{max}), is related to the acoustic cutoff frequency and therefore, in the adiabatic case and under the assumption of an ideal gas, defined by the surface gravity and effective temperature of the star (e.g. Kjeldsen & Bedding 1995).
Estimating fundamental parameters from these seismic parameters has become an important application of asteroseismic observations. Recent investigations in this context were made by Stello et al. (2008), who analysed 11 bright red giants observed with the WIRE satellite. They compared traditional methods to determine stellar masses with a new method, that uses the effective temperature, the Hipparcos parallaxes and their measurement for ν_{max}, to estimate an asteroseismic mass. The A2Z pipeline (Mathur et al. 2010) uses two different methods to estimate the mass and radius of a star: one based on the scaling laws and the other one that starts with the measurement of Δν and uses a precalculated grid of evolutionary models to obtain an initial guess of the fundamental parameters of the star. For the latter method, a minimisation algorithm is performed to estimate the radius and the mass with a higher accuracy (Creevey et al. 2007). Basu et al. (2010) presented the YaleBirmingham (YB) method, which aims to deduce precise stellar radii from a combination of seismic and conventional variables. Within the context of the asteroFLAG hareandhounds exercises for the Kepler Mission, Stello et al. (2009b) summarised other methods, which provide stellar radii based on the observed large frequency separation and conventional observables. The basic principle of the YB and asteroFLAG methods is the same. They compare observed seismic parameters (ν_{max} and/or Δν) and other observables (T_{eff}, V, π, log g, metallicity, etc.) to those of stellar models, where the seismic parameters of the models are determined from scaling relations or adiabatic model frequencies. If the input parameters are well defined, these methods enable very precise estimates for the stellar radius. Most of the red giants observed with CoRoT and Kepler, however, are rather faint and, although the seismic parameters can be determined with high precision, additional constraints are generally very uncertain, if available at all. To account for this, Kallinger et al. (2010, hereafter Paper I) presented a modified approach for 31 red giants observed for about 150 days with the CoRoT space telescope. They exclusively used the measured seismic parameters ν_{max} and Δν to derive estimates for stellar fundamental parameters from the aforementioned scaling relations and a grid of solarcalibrated redgiant models, without making use of any other input parameters. They also indicated that their mass and radius determination is relatively insensitive to the metallicity and/or evolutionary stage of the investigated red giants.
In this paper, we largely follow the approach of Paper I but for red giants that have been observed during the first ~138 days of science operation of the Kepler satellite. We fit a global model to the power density spectra of the highprecision photometric time series to measure ν_{max}. We use an improved approach to determine the large and small frequency spacings, which also provides an automated identification of the mode degree. We apply the same methods to determine ν_{max} and Δν to SOHO/VIRGO (Variability of solar IRradiance and Gravity Oscillations; Frohlich et al. 1997) data to measure the solar reference values needed as an input for the scaling relations. We compare the measured seismic parameters with those determined from a multimetallicity redgiant model grid (by using the scaling relations) to derive a reliable stellar mass and radius and a reasonable effective temperature and luminosity for the red giants in our sample. We investigate the error sources in our analysis and discuss the stellar populations on the giant branch.
2. Observations
The NASA Kepler Mission (Borucki et al. 2008, 2010) was launched in March 2009 with the primary goal of searching for transits of Earthsized planets in and near the habitable zones of Sunlike stars. The satellite houses a 95cm aperture modified Schmidt telescope that points at a single field in the constellation Cygnus for the entire mission lifetime (>3.5 years). The telescope feeds a differential photometer with a wide field of view that continuously monitors the brightnesses of about 150 000 stars. This makes it an ideal instrument for asteroseismology and the Kepler Asteroseismic Science Consortium (KASC)^{1} has been set up to study many of the observed stars (see Gilliland et al. 2010, for an overview and first results).
In this paper we concentrate on the longcadence (29.4 min sampling; Jenkins et al. 2010) data that have been collected within the astrometric and asteroseismic programmes during the commissioning phase (Q0; ~11d) and the first (Q1; ~34d) and second (Q2; ~89d) roll of the satellite. We analyse all stars for which at least Q1 and Q2 time series have been made available via KASC, including those which have not been flagged as red giants in the Kepler Input Catalogue (KIC; Latham et al. 2005). The combined time series consist of about 5900 or 5430 measurements and span a total duration of about 138 or 127 days, depending on the availability of Q0 data.
In Fig. 1 we show the relative flux for a typical red giant. Whereas the Q0 and Q1 time series show only long term trends, the Q2 data reveal a more complex behaviour. The time series appears to consist of five parts with sudden jumps at the transitions, which are instrumental. Additionally there is a step gradient at least at the beginning of the second and fourth “subset” (BJD – 2450000 ≃ 5018 and 5062). These artefacts appear at the same time in most data sets and are due to some satellite failures during the Q2 observations, where Kepler had to be cooled down again after safemode operations. To account for these instrumental artefacts, we split the time series into 7 subsets (Q0, Q1, and 5 subsets for Q2). We tried several approaches to model the gradients, but this turned out to be quite difficult as the actual shape differed from star to star, even increasing gradients have been found in some cases. Therefore, we simply removed the leading data points, including the steepest part of the gradient for the first, second, and fourth subsets of the Q2 data. In total we rejected about 5.5 days of measurements, degrading the overall duty cycle from about 91 to 87%, with only minor consequences on the spectral window function. Finally, we subtracted a secondorder polynomial fit from each subset. The resulting time series is shown in the bottom panel of Fig. 1. This approach does, of course, suppress any intrinsic long period signal. The shortest subset is about 11 days long, which means that we filter out signal below about 1 μHz.
The longcadence data from Kepler that are accessible to KASC consist of two major samples. Firstly, the socalled astrometric reference stars (Batalha et al. 2010; Monet et al. 2010) comprising about 1000 stars that have been selected to be distant (and therefore having a small parallax), but bright (and therefore being mostly giants) and unsaturated stars in a Kepler magnitude range of 11.0–12.5 mag, which are uncrowded and uniformly distributed over the focal plane. Secondly, about 1300 stars that have been selected for asteroseismology by the various working groups of KASC according to different criteria such as their presumed membership to a cluster or due to their colour index. We computed the power density spectra between 1 μHz and the Nyquist frequency (~280 μHz) for all stars and searched them visually (i.e., by eye) for redgiant characteristics. We found a total of 1041 stars (670 astrometric and 371 asteroseismic) that show both a clear power excess hump with regularly spaced peaks and a background that decreases towards higher frequencies. We identified them as red giants for the subsequent analysis.
Fig. 1
Relative flux for the Q0, Q1, and Q2 data of KIC 6838420. The top panel shows the original time series (grey points) with the 2nd order polynomial fits overlaid (black lines). The bottom panel shows the residual time series.

Open with DEXTER
3. Power spectra modelling
The power spectra of solartype oscillations have characteristic features. Besides an instrumental white noise component, they show a frequencydependent background signal. This signal can be represented by several superLorentzian functions^{2} with increasing characteristic frequencies and decreasing characteristic amplitudes. Each of these components is believed to represent a separate class of physical process such as stellar activity and the different scales of granulation, and most of them are strongly connected to the turbulent motions in the convective envelope. On top of the background signal, one finds additional power due to pulsation in a broad hump. This power excess arises from a sequence of stochastically excited and damped oscillations, which correspond to highovertone radial and nonradial acoustic modes. The mode amplitudes are defined by the excitation and damping and are modulated by a broad envelope. The centre of the envelope is usually called the frequency of maximum oscillation power (ν_{max}) and its shape is approximately Gaussian.
Fig. 2
Left panel: power density spectra for a sample of red giants observed with Kepler. Black lines indicate the global model fit and dotted lines show the global model plotted without the Gaussian component, which serve as a model for the background signal. Dashed lines indicate the background components. KIC numbers are given in the upper right corners. Right panel: residual power density spectra shifted to the central frequency (given in absolute numbers in the plots) of our model to determine the frequency separations and normalised to the large frequency separation. Black lines correspond to the best fitting model. The dashed line marks the midpoint between adjacent l = 0 modes.

Open with DEXTER
3.1. Global power spectrum model and ν_{max}
The background signal in the power spectra of solartype oscillations can be modelled by the sum of superLorentzian functions, P(ν) = ∑ A_{i}/(1 + (2πντ_{i})^{ci}), with ν being the frequency, A_{i}, τ_{i}, and c_{i} being the characteristic amplitudes, timescales, and the slopes of the background model. This model was first introduced by Harvey (1985) to characterise the solar background signal. In Paper I, it was shown that the solar background model also works for the power spectra of red giants. Due to the larger radii of red giants compared to the Sun, the amplitudes and timescales of the background components are quite different but the model, particularly the slopes of the components are the same. Here, we follow the approach of Paper I and model the observed power density spectra with a superposition of white noise, the sum of superLorentzian functions, and a power excess hump approximated by a Gaussian:
where P_{n} corresponds to the white noise contributions and a_{i} is the rms amplitude of the ith background components. The parameter b_{i} corresponds to the frequency at which the power of the component is equal to half its value at zero frequency and is called the characteristic frequency. P_{g}, ν_{max}, and σ_{g} are the height, the central frequency, and the width of the power excess hump, respectively. Note that σ_{g} is about 1.18 times the HWHM. For our sample of red giants, the frequency coverage of the Kepler observations allowed us to model up to three background components.
The only difference compared to the model in Paper I is the numerator in the background models. Originally, a single parameter, A, was used which corresponds to the power at frequency equal to zero of the given component. However, tests have shown that fitting a and b instead of fitting A and b, with A = 2πa^{2}/b, yields a more robust fit and allows a more accurate measurement of the characteristic frequencies. This notation also makes more sense physically because a^{2} corresponds to the variance that the signal produces in the time domain and can easily be related to the observed total energy of, e.g., granulation.
We used a Bayesian MarkovChain MonteCarlo (MCMC) algorithm to fit the global model to the power density spectra. See Paper I and Gruberbauer et al. (2009) for a detailed description. Briefly, the algorithm automatically samples a wide parameter space and delivers probability density distributions for all fitted parameters and their marginal distributions, from which we computed the most probable values and their 1σ uncertainties. For the parameter limits, we followed a slightly modified approach to that in Paper I. During the fitting process we kept ν_{max} within ± 25% of the value inferred from the visual inspection of the spectrum. The width of the power excess was allowed to vary between 5% and 50% of the initial guess of ν_{max}, where the lower limit prevented the algorithm from fitting the Gaussian to a single frequency bin in the spectrum. The frequency parameters b_{i} were allowed to vary from 0 to 1.5 times ν_{max}, with the condition b_{1} > b_{2} > b_{3}, where the indices indicate consecutive background components. The amplitude parameters a_{i} were kept between 0 and 10 times the square root of the highest peak power in the spectra. P_{g} was allowed to vary from zero to 10 times the average power in the spectrum around the initial guess for ν_{max}, and P_{n} was kept between 0.5 and 2 times the average power at the high frequency end of the spectrum. The left panel of Fig. 2 shows examples of power density spectra with the corresponding fits.
An important aspect of our analysis is to understand the uncertainties of the determined parameters. One might expect that the white noise, and therefore the brightness of a star, is responsible for a significant part of the uncertainty in ν_{max} but we do not find any correlation with the magnitude. On the other hand, there is a clear correlation between σ_{νmax} and the ratio of the heighttobackground ratio (HBR) to the width of the power excess (σ_{g}), where we define the HBR as the ratio between the height of the power excess (P_{g}) and the background signal at ν_{max}. In other words, we can more accurately determine the centre of a narrow power excess hump with a large HBR than the centre of a broad hump with a small HBR.
Fig. 3 The uncertainty in ν_{max} in actual value (right axis) and in units of the frequency resolution as a function of the ratio between the heighttobackground ratio (HBR) and the width of the power excess, σ_{g}. The line indicates a powerlaw model for the lower envelope.

Open with DEXTER
For the solar case we would expect an uncertainty in ν_{max} of about 5.3 μHz, which is in good agreement with the value of 5.23 μHz found in Sect. 3.3 for SOHO/VIRGO data. Given this relatively simple error law we are confident that our uncertainties for ν_{max} are reliable and do mainly reflect the constraints of the observations and not of our method. It is also interesting to see that the uncertainty of ν_{max} is very much defined by the star itself, since HBR/σ_{g} is largely intrinsic to the star, for a given instrument and observing time. Nevertheless, we mention that the error law is purely phenomenological and might not be valid outside the range we use it.
A histogram of the relative uncertainties in ν_{max} is given in the top panel of Fig. 4, showing a clear peak at about 2%. This is not surprising as a large fraction of the analysed red giants are redclump stars having a very similar ν_{max}, and therefore a similar width and heighttobackground ratio of the power excess. We see that, for almost all stars, we could determine ν_{max} to within 4% and, for about half of our sample, to within 2%.
Fig. 4
Histograms of the relative uncertainties for ν_{max}, the large frequency separation Δν, and the small separations δν_{01} and δν_{02}.

Open with DEXTER
A potential problem for the subsequent analysis is that we assumed the power excess hump to be symmetric, so that an intrinsic asymmetry might result in a systematic error. In Paper I it was claimed that the asymmetry of the power excess hump is within the observational uncertainties of ν_{max}, and therefore negligible. However, that conclusion was based on the analysis of only 31 stars. Our sample is more than 30 times larger and should give a statistically more significant conclusion. We computed the weighted mean frequency, ν_{wm}, in the frequency range of pulsation (ν_{max} ± 3σ_{g}), where we used the residual power after correcting for the background signal as weight. We found ν_{wm} consistently shifted towards higher frequencies compared to ν_{max} by 3.1 ± 1.3% and therefore outside the average uncertainty for ν_{max} of about 2.3%. This is, however, not a problem in our subsequent analysis since we find the same shift of about 3% in the solar data (see Sect. 3.3), and as long as we compare ν_{max} values that are determined in the same way, we do not have to take into account asymmetries in the power excess humps.
3.2. Frequency spacings
In the next step we used the white noise and background components of the global model (dotted lines in Fig. 2) to correct the power density spectra for the background signal, leaving only the oscillation signal and white noise. The second parameter that can directly be determined from the observed power spectrum is the large frequency separation, Δν. To determine Δν, we use a similar approach as in Paper I and fit the following general model to the residual power density spectrum over a frequency range spanning three radial orders around the frequency of maximum oscillation power:
The model represents a sequence of eight Lorentzian profiles whose frequencies are parameterised by a central frequency, ν_{0}, and three spacings, Δν, δν_{01}, and δν_{02}, where the first, second, and third sum corresponds to three radial, three l = 2, and two l = 1 modes, respectively. A_{i}, A_{j}, and A_{k} are the individual rms amplitudes. As in Paper I, we assume the same mode lifetime τ for all modes, which might not be true in reality, but this assumption has no impact on the determination of the spacings and significantly stabilises the fit. We again used the Bayesian MCMC algorithm to fit the model to the residual power density spectrum. All mode amplitudes were allowed to vary independently between zero and 10 times the highest peak in the amplitude spectrum. This allowed the algorithm to account for missing modes or modes hidden in the noise. The mode lifetime was sampled between 1 and 100 days. Most important here were the parameter ranges for the spacings. With the condition that δν_{01} ≪ Δν and δν_{02} < Δν/2, the model basically represents the asymptotic relation (Tassoul 1980) for lowdegree and highradial order p modes. Consequently, δν_{02} and δν_{01} correspond to the small separations between adjacent l = 0 and 2 modes and between l = 1 modes and the midpoint of consecutive radial modes, respectively. A critical parameter is the central frequency because the central mode must be a radial mode. Otherwise, the interpretation of the spacings contradicts the asymptotic relation. It turned out when allowing ν_{o} and Δν to vary over a relatively wide range (ν_{max} ± 2σ_{g} for ν_{o} and 0.5 μHz to 2σ_{g} for Δν) the algorithm was able to automatically find the central mode that corresponds to a radial mode if l = 2 modes were present. In case of no detectable l = 2 modes, the mode identification is ambiguous, but the delivered large spacing was still a good estimate.
We have determined Δν for all 1041 stars and found at least two l = 2 modes in the oscillation spectrum of about half of our sample, which allowed us to determine small spacings based on an automated mode identification. In principle, we have also δν_{01} values for these stars but only accepted them for about one third of the total sample. This is because of the multiple dipole modes over a relatively broad frequency range per order, which occur due to their mixed gravity/acoustic mode character (Dupret et al. 2009), and makes it difficult for our algorithm to obtain robust results. We do not further investigate the small spacings here but refer to Huber et al. (2010), where those results are presented.
The oscillation spectra and the corresponding best fits for the stars in Fig. 2 are illustrated in the right panel of that figure. As for our global fit parameters, we determined the most probable parameters from the marginal distributions of the probability density delivered by the MCMC algorithm. Unlike for ν_{max}, we were not able to find a clear correlation between the uncertainty in Δν and any other parameter combination. We expect, however, that σ_{Δν} depends on the frequency resolution, the signaltonoise ratio of the individual modes and their lifetime. We could not reliably determine the mode lifetimes for many stars because their mode profiles are undersampled, which means that the peak width due to the spectral window function of the observations is broader than the actual profile width. In such a case our amplitudes and lifetimes are meaningless. The mode frequencies and therefore the spacings are, however, not affected by this phenomenon. Histograms for the uncertainties of the spacing parameters are given in Fig. 4, showing that we can determine Δν to within 1% for about 30% of our sample. Whereas the accuracy of δν_{02} is mostly better than 10%, the relative errors for δν_{01} are relatively large. But one has to keep in mind that δν_{01} is well below 1 μHz for a red giant and the absolute uncertainties of δν_{01} are still quite low.
Originally, we would have had to exclude a number of stars from our sample because they pulsate with low frequencies making it difficult to reliably determine spacings from a frequency spectrum. There is, however, the socalled autocorrelation method described by Mosser & Appourchaux (2009), which measures Δν from the first peak in the autocorrelation of the time series. This method is less affected by the limited duration of the observations than Fourierbased methods and is able to detect regular spacings down to a few times the frequency resolution (Mosser et al. 2010). To account for this, we used the Δν values from the autocorrelation method for all stars with ν_{max} < 15 μHz (~7% of the total sample) for the subsequent analysis.
Finally, we crosschecked our results for ν_{max} and Δν with those of other methods (Hekker et al. 2010a; Huber et al. 2009; Mathur et al. 2010; Mosser & Appourchaux 2009) which have been used to determine the same seismic parameters for our sample (or subsample) of red giants. A direct comparison of the different methods shows that there are a number of outliers but for most stars in our sample, at least one other method gave a value that is compatible with our results (i.e., within the uncertainties). Additionally, we have carefully checked by hand the reliability of the seismic parameters for all stars for which we found a significant disagreement in the direct comparison (see Hekker et al. 2010c, for the detailed comparison) and identified only a few stars (less than 1%) which we had to eliminate from our sample because their seismic parameters are ambiguous.
3.3. Solar reference parameters
The large frequency separation is related to the inverse sound travel time through the star and therefore to the mean density of the star. It scales as Δν_{⊙ }(M/R^{3})^{1/2} from the solar case, with R and M being the total mass and the radius of the star, respectively, in solar units. An important point when using scaling relations to estimate fundamental parameters is the definitions of the scaled seismic parameters. An often used solar reference value, Δν= 134.95 μHz is based on the frequency difference between the radial modes with order n = 20 and 21 where the maximum oscillation power is seen (Toutain & Froehlich 1992). The frequency difference of two single modes is difficult to determine for other stars and an average value of all (or some) observable modes is often used (e.g., ~134.8 μHz for the Sun; Kjeldsen et al. 2008). However, the frequency separation is a function of the frequency itself (see e.g. Broomhall et al. 2009 for the Sun and Mosser et al. 2010 for CoRoT red giants), and an average Δν will depend on the actual number and frequency range of the observed modes and is difficult to compare for different observations.
The frequency of maximum oscillation power, on the other hand, is related to the acoustic cutoff frequency in the stellar atmosphere (e.g., Brown et al. 1991; Kjeldsen & Bedding 1995), which in turn scales as ν_{max} from the solar case, where often used values are ν_{max}_{,⊙ } = 3050 μHz (e.g., Kjeldsen & Bedding 1995) or 3100 μHz (e.g., Basu et al. 2010). Both seismic parameters scale with the stellar mass and radius and can therefore be used to estimate R and M of a star from its seismic parameters. But to use these seismic scaling relations in a consistent way we need values for the solar parameters, measured in the same way as for our sample of red giants. Note that the seismic scaling relations are not laws of physics and possibly include some additional uncertainties. There are, however, strong indications that at least the Δνscaling is quite accurate for cool stars like our sample of red giants (Basu et al. 2010; Stello et al. 2009a).
We used a 1year time series from the green channel of the SOHO/VIRGO data (Frohlich et al. 1997) obtained during a solar activity minimum and fitted our global model (Eq. (1)) to the corresponding power density spectrum. The result is given in Fig. 5, showing the original power density spectrum and a smoothed version of the average power density spectrum of nine consecutive 1year time series along with the best fitting model. Although the model is fitted to “only” a 1year time series, it almost perfectly reproduces the average spectrum of the full 9year time series. The reason why we do not use the 9year time series is because of limited computer resources. Also shown is the probability density function of the solar ν_{max} parameter, from which we determined ν_{max}_{,⊙ } = 3120 ± 5 μHz.
Fig. 5
Power density spectrum of a 1year VIRGO time series (lightgrey) and the corresponding global model fit (black line). The darkgrey line shows a smoothed (5 μHz boxcar filter) version from the average of nine consecutive 1year VIRGO time series. The inset gives the probability density function for ν_{max} with the vertical solid and dashed lines indicating the median value and the 1σ limits, respectively.

Open with DEXTER
In the next step we use the background part of the global model fit to correct the power density spectrum and fit the asymptotic relation model to the residual spectrum. The solar pmode profiles are naturally much better resolved than the pmodes in our sample of red giants and initial tests have shown that the rotationally split components of the nonradial modes significantly disturb the fit. To account for this we have included rotationally split components for the l = 1 and 2 modes, which are parameterised by a single rotational frequency and an inclination angle that defines the height ratio between the central profile and the split components (e.g., Gizon & Solanki 2003; Ballot et al. 2006). We have also tested asymmetric mode profiles (Nigam et al. 1998) but found no significant influence on the parameters of interest. In Fig. 6, we show the probability density distributions for the three frequency spacings and the central frequency of our model, together with their median values and 1σ limits. The bottom panels illustrate the residual power density spectrum and the best model fit. We have determined Δν_{⊙ } = 134.88 ± 0.04 μHz, δν_{02,⊙ } = 9.00 ± 0.06 μHz, and δν_{01,⊙ } = 6.14 ± 0.10 μHz. The uncertainties might appear unrealistically small but they reflect a well defined case specifically chosen for our approach and should not be mistaken as “global” frequency spacings of the Sun.
4. Asteroseismic fundamental parameters
4.1. Method
Fig. 6
Same as Fig. 5 but as delivered from our algorithm to determine the frequency spacings. Top panels: probability density functions for the three spacing parameters and the central frequency of our model fit. Median values and 1σ limits are indicated by vertical solid and dashed line, respectively. Bottom panel: residual power density spectrum (lightgrey) of a 1year VIRGO time series and the corresponding model fit (black line).

Open with DEXTER
Our approach to determining an asteroseismic mass and radius depends on the aforementioned scaling relations for ν_{max} and Δν:
with M and R in solar units and T = T_{eff}/5777 K. Obviously the ν_{max} scaling relation depends on the effective temperature of the star. Although there are temperatures available in the KIC for most of the analysed stars, we decided not to directly use them in our analysis (i.e., in the above scaling relations). The KIC parameters (T_{eff}, log g, and [Fe/H]) are mostly determined from multicolour photometry and they are calibrated to be correct in a statistical sense, i.e., the average values of a large sample of stars are correct. However, a starbystar comparison (e.g., for stars associated in a cluster) has shown that the individual values can have a large scatter (up to some 100 K in T_{eff}). Consequently, adopting the KIC temperatures would add uncertainties of up to 5% and 10% to our radius and mass determinations, respectively. Therefore, we also compared the seismic parameters of the observed stars and their KIC temperatures to those inferred from stellar models, and then adopted the fundamental parameters from the model that best reproduced all input parameters. There are several ways to do this. In Paper I, an initial guess for the stellar mass and radius was determined using an average temperature for stars on the red giant branch. The initial mass and radius values were then compared to those of a grid of solarcalibrated redgiant models to get a better estimate for the temperature. The new temperature was adopted and the procedure repeated, converging to a certain location in the HR diagram after a few iterations and delivering a full set of fundamental parameters for each star. However, these iteratively determined parameters also depend on the chemical composition and the evolutionary status of the model (i.e., whether the model is a redgiant branch or an asymptoticgiant branch model). This ambiguity allows a given set of seismic parameters to converge to different locations in the HR diagram if different model grids with, e.g., a different chemical composition are used. This uncertainty has, however, only small effects on the mass and radius determination. For the effective temperature and luminosity it adds about ± 150 K and ± 20% uncertainties, respectively.
A more general approach was presented by Basu et al. (2010). They used a combination of seismic and conventional stellar parameters and compared them to those of a multimetallicity model grid, where the aforementioned scaling relations are used to determine the seismic parameters for the models. Basu et al. (2010) defined a model likelihood from the difference between the model and input parameters and infer the stellar radius from the resulting likelihood function. From their tests with a number of artificial stars they concluded that it is very unlikely to get a reasonable estimate for a red giants’ radius if no accurate temperature and parallax are available. This conclusion was, however, based on only a single redgiant test star that is located high up the red giant branch and therefore quite far away from where most of the observed red giants are expected (i.e. in the red clump). Additionally, they have assumed uncertainties for the seismic input parameters that are about ten times larger than what we have determined for our sample of red giants.
Here, we follow the approach of Basu et al. (2010) but formulate our search for a best set of fundamental parameters in a Bayesian sense. Given a set of seismic input parameters ν_{max,obs} and Δν_{obs}, and the Gaussian distribution of their uncertainties, σ_{νmax} and σ_{Δν}, we define the likelihood that the seismic model parameters, ν_{max,model} and Δν_{model}, matches the observed ones as
To simplify matters, we also assume a Gaussian error for the KIC effective temperatures and define the likelihood that the model matches the observed temperature as
with a typical value of 200 K for σ_{Teff}. In the Bayesian approach we can assign an overall probability of the model M_{i} with the posterior probability I matching the observed parameters D with respect to the entire set of models according to Bayes theorem as
is the uniform prior probability for a specific model with N_{m} being the total number of models, and
is the likelihood function. The denominator of Eq. (9) is a normalisation factor for the specific model probability in the form of
Since the uniform priors are the same for all models they cancel in Eq. (9), which simplifies to
The resulting model probability distribution automatically translates into most probable fundamental parameters and their uncertainties by constructing the marginal distribution for the corresponding parameter. The normalised probability of the most probable parameters is therefore a measure of how likely they are with respect to the other models of the specific grid. We stress that it does not tell us how probable the parameters are in an absolute sense, although formally it must be implicitly assumed than one of the tested models is actually true. The probability must be interpreted as being restricted to the space of the models being considered, and their associated physics. This means that as soon as additional models are added to the model space, the probabilities will change.
We also mention for completeness that since we use an uniform prior that rates each model with the same prior probability our Bayesian approach is actually not very different from the likelihood method of Basu et al. (2010). But as soon as we would add additional informations such as, e.g., an initial mass function, the advantages of the Bayesian technique would become obvious. But this is beyond the scope of the present paper and we leave it to future investigations.
4.2. Models
The redgiant models used for our analysis were extracted from the canonical scaledsolar BaSTI^{3} isochrones (Pietrinferni et al. 2004) in version 5.0.0 with a massloss parameter η = 0.2. The grid includes models which were evolved from the zeroage mainsequence up to the tip of the redgiant branch (RGB), down to the Hecore burning main sequence (red clump) and back up to the asymptotic giant branch (ABG) to an age of about 15 Gyr. We restricted the grid to models that have already left the main sequence with initial chemical compositions of (Z,Y) = (0.008,0.256), (0.01, 0.259), (0.0198, 0.2734), (0.03, 0.288), and (0.04, 0.303). The model mass ranges from 0.7 to 4 M_{⊙} with steps of typically 0.02 M_{⊙}. We rejected models both with a mass above 4 M_{⊙} and with metallicities below Z = 0.008 because they develop a distinctive horizontal giant branch that would significantly complicate our analysis.
We think this is justified because very high mass and very metalpoor stars are both quite rare and it is unlikely to find more than a few in a random sample of red giants. Initial tests showed that the poor resolution in chemical composition leads to an artificial clustering of stars in the HR diagram, i.e., the redclump stars are concentrated in sharp features corresponding to the redclump models of the different metallicity grids. We therefore increased the resolution in chemical composition to steps of 0.002 in Z via interpolating the effective temperature for models of approximately constant mass and radius but with different chemical composition. The corresponding luminosities were determined from the StefanBoltzmann law, L ∝ R^{2}T^{4}. The final grid used consists of about 1.4 million models based on about 340 000 original BaSTI models.
4.3. Testing the method
To test our algorithm we use test star 6 from Basu et al. (2010) from their Table 1. The input ν_{max} and Δν are 21 ± 0.2 and 2.2 ± 0.05 μHz, respectively, where we adopt typical uncertainties from our sample of red giants. The resulting model probabilities and cumulative probability distributions for the model radius are illustrated in Fig. 7, from which we infer the most probable radius and its uncertainty to be R = 22.1 ± 0.9 R_{⊙ }, which is in good agreement with the input radius of 21.44 R_{⊙ } (Basu et al. 2010).
A more realistic test case is the red giant ϵ Oph, for which an interferometric radius is available. With ν_{max} = 53.5 ± 2.0, Δν = 5.2 ± 0.1 μHz (Kallinger et al. 2008a), and a spectroscopic T_{eff} = 4877 ± 100 K (De Ridder et al. 2006) we determined a radius of 10.7 ± 0.4 R_{⊙ }, which is in good agreement with the interferometric radius of 10.55 ± 0.15 R_{⊙ } (Mazumdar et al. 2009). The other parameters are also in fairly good agreement with independent measurements. Our mass estimate of 1.89 ± 0.08 M_{⊙} compares well to stellar masses determined from a detailed modelling: 1.85 ± 0.05 M_{⊙} (Mazumdar et al. 2009) and 2.02 M_{⊙} (Kallinger et al. 2008a). Even our luminosity estimate of 59 ± 5 L_{⊙ } is compatible with the luminosity of 58 ± 4 L_{⊙ } based on the Hipparcos parallax (van Leeuwen 2007).
4.4. Results for Kepler stars
In a first step, we have excluded 65 red giants which are associated with clusters from our sample because they might bias the subsequent analysis. Figure 8 shows the radius as a function of the mass for the remaining sample of red giants. Whereas in the top panel, R and M are directly determined from the seismic scaling relations adopting the KIC temperatures, the bottom panel shows R and M as they follow from the Bayesian comparison with the stellar model grid. Both distributions include many stars located in a narrow range around ten solar radii. Most of the stars in this range are expected to correspond to the red clump (e.g., Miglio et al. 2009) and their large number is due to the different evolutionary rates of giantbranch stars. Whereas stellar evolution takes place quite rapidly during the RGB phase and after the He flash at the tip of the RGB, it significantly slows down during the quiescent Hecore burning phase in the red clump. Hence one can expect to find more redclump stars and therefore stars with a similar radius than RGB stars in a random sample of red giants.
Fig. 7
The projected probability (left) and cumulative probability (right) distribution functions for the radius of the artificial test star 6 (Basu et al. 2010). The full horizontal line correspond to the median and the dashed lines give the ± 1σ confidence interval.

Open with DEXTER
Fig. 8
The stellar radius as a function of mass for the sample of red giants as directly determined from Eqs. (4) and (5) using the KIC effective temperatures (top) and from the comparison with the stellar model grid (bottom).

Open with DEXTER
Although the two methods to determine R and M give a similar picture there are some important differences. Firstly, the verylowmass stars in the top panel are most likely artefacts because, apart from binary stars which have lost a significant fraction of their mass, the universe is not old enough for 0.5–0.7 solar mass stars to have become 10–15 solar radii giants. Secondly, the distribution of stars below the red clump seems to be more realistic in the bottom panel than in the top panel. The higher mass stars evolve faster than the lower mass stars and therefore fewer higher mass stars should be present in a random sample of giants. Additionally, the error bars are in general smaller in the bottom panel and the redclump feature is more pronounced. We are therefore confident that the additional efforts in determining the fundamental parameters are justified because they enable a more detailed picture of the stellar population on the giant branch.
Fig. 9
HR diagram showing the location of our redgiant sample as directly determined from Eqs. (4) and (5) using the KIC effective temperatures (panel a)) and from the comparison with the stellar model grid (panel b) to e)). The colour code (in the online version only) indicates the stellar mass (a) and b)), radius c)), age d)), and metallicity (e)), where the radius scale has been truncated below 6 and above 14 R_{⊙ }. Grey lines show solarmetallicity BaSTI evolutionary tracks. The boxes given in the lower right corners illustrate typical uncertainties.

Open with DEXTER
4.4.1. Kepler red giants in the HR diagram
As our algorithm also delivers effective temperatures and luminosities we can put the analysed stars in a HR diagram. Panel a of Fig. 9 shows the modelindependent positions in the HR diagram, with the temperatures from the KIC and the luminosities following from the StefanBoltzmann law, with R directly determined from the seismic scaling relations (by using the KIC temperatures). The other panels show the positions in the HR diagram as they follow from the Bayesian comparison with the stellar model grid with the colour code indicating the mass, radius, age, and metallicity of the best fit models. The distribution of stars in the HR diagram reveals some interesting features. The most distinctive one (denoted as “A” in panel b of Fig. 9) consists of a large number of stars (~35% of the total sample) lining up at almost constant luminosity and corresponds to the red clump. A similar feature (B) is located at slightly lower luminosities and with an almost constant temperature. It most likely corresponds to the socalled red bump, which is another characteristics of stellar evolution on the giant branch due to the outwardmoving hydrogenburning shell that burns through the mean molecular weight discontinuity left by the first dredgeup from the convective envelope causing a slight contraction of the star before the star starts to ascend the giant branch again. Significantly less populated than the red clump and bump is the feature (C) that corresponds to the socalled secondary clump (Girardi 1999) including highmass stars (>2 M_{⊙}) that settle as Hecore burning stars at lower luminosities than the lowermass redclump stars. The secondaryclump population is of particular interest because its mass puts tight constraints on, e.g., the convectivecore overshooting or the recent history of star formation in the Galaxy (Girardi 1999). We refer to Huber et al. (2010) who report on the signature of secondaryclump stars in the distributions of the seismic observables of red giants in the Kepler field of view (see also Mosser et al. 2010, for CoRoT red giants).
Combining the mass distribution in the HR diagram (panel b in Fig. 9) with the radius distribution (panel c in Fig. 9) we infer that the red clump consists of about 0.8 to 1.8 M_{⊙} stars (with the lowmass stars accumulated at the bottom of the red clump) with a radius between about 10 to 12 R_{⊙ }. The red bump, on the other hand, is dominated by 1 M_{⊙} stars but with a lower average radius than the redclump stars. The secondaryclump covers a similar radius range but includes stars with masses above about 2 M_{⊙}. Outside the red clumps and bump, the stars follow the usual mass distribution with increasing masses towards higher temperatures and luminosities. The detailed structure in the HR diagram is almost not visible in the modelindependent approach (panel a). The uncertain KIC temperatures obviously blur the distribution of the stars in the red clumps and bumps. However, we note that the modelindependent approach tentatively shows the mass gradient in the red clump as well.
Fig. 10
HR diagrams showing our sample of red giants (black dots) with respect to different metallicity model grids (red dots – in the online version only).

Open with DEXTER
Fig. 11
Histograms of the relative (and absolute for T_{eff}) uncertainties for the asteroseismic fundamental parameter.

Open with DEXTER
Although we cannot constrain the metallicity to better than about ± 50% for individual stars, the metallicity distribution shows some interesting trends (see panel e in Fig. 9). In the red clump, there is a metallicity gradient ranging from metalpoor stars at the bottom to metalrich stars at higher luminosities. And the red bump tentatively consists of metalenhanced stars.
To analyse the red clump and bump in more detail we compare in Fig. 10 the observed features with different metallicity grids. As indicated in panel d of Fig. 9, the red clump is dominated by Hecore burning stars of the solarmetallicity grid (middle panel of Fig. 10). The metallicity gradient in the red clump is due to the position of the Hecore burning mainsequence in the different metallicity grids. Whereas the metalpoor models are shifted towards higher temperatures and therefore towards the bottom of the observed red clump, the metalrich models accumulate at the opposite side of the red clump. Similar can be seen for the red bump. But there, metalenhanced models are more consistent with the observed sample than solarmetallicity models.
In Fig. 11 we show histograms for the relative uncertainties in mass and radius (bottom panel) showing that for about half of our sample we can constrain the mass and radius to within 7% and 3%, respectively. These uncertainties are dominated by the observational uncertainties of the seismic input parameters and are only slightly affected by the model related parameters. On the other hand, the effective temperature and luminosity of a model with a given mass and radius can significantly differ for, e.g., a different initial chemical composition or mixing length parameter. Compared to Paper I, where only a single metallicity grid was used, we cover a wide range in chemical composition and therefore expect to get a more realistic uncertainty for the HR diagram position. Histograms for the relative uncertainties in effective temperature, age, and luminosity are given in the top panel of Fig. 11 showing that we can determine the effective temperature, age and luminosity to within ± 110 K, ± 30%, and ± 11%, respectively, for most of the analysed red giants.
We have tested our results with the RADIUS (Stello et al. 2009b) and A2Z (Mathur et al. 2010) methods, which showed qualitative agreement. However, a direct comparison is meaningless since RADIUS and A2Z use only hydrogen burning models and therefore do not include the red clump.
4.4.2. Radius and mass distributions
The radius and mass distribution in our sample of red giants is given in Fig. 12. The radius distribution clearly shows two populations of stars that are located in the same region of the HR diagram. The Hshell burning stars ascending the giant branch and the Hecore burning stars in the red clump. The very different rate at which they change their fundamental parameters (e.g., the radius) results in two superposed components of their radius distribution. The main component is a broad Gaussianlike distribution with a maximum number of stars between 9.5 and 10 R_{⊙ }. This component is dominated by RGB stars ascending the giant branch and the maximum falls onto the average radius of the red bump (see panel c of Fig. 9) but also includes the secondaryclump stars. The RGB stars are superposed with the sharp distribution of redclump stars with their radii ranging from 10.5 to 11.5 R_{⊙ }. Also interesting is the excess of stars with a radius around 20 R_{⊙ }. If real, this clustering of stars would be very interesting because it might indicate stars on the AGB whose Heburning shells burn through the discontinuity left by the second dredge up, which happens indeed at about 20 solar radii in solar metallicity models. But a significantly larger sample would be needed to verify if the excess is real.
Fig. 12
Histograms for the radius and mass distribution in our sample of redgiant stars compared to the distribution of a synthetic redgiant population.

Open with DEXTER
The mass distributions in the bottom panel of Fig. 12 shows that there are only very few lowmass stars in our sample. Their number slowly increases between 0.8 to 1.5 M_{⊙} with a small excess between 1 to 1.2 M_{⊙}, and rapidly drops for higher masses. To test for bias of our composite sample we computed the radius and mass distributions in the subsamples (red and blue bars in Fig. 12) and found no significant difference for the radius distribution. The mass distributions, on the other hand, are different. Obviously, there are more 1.3 to 1.5 M_{⊙} stars in the asteroseismic sample than in the astrometric sample showing its maximum between 1 to 1.2 M_{⊙}. We expect the excess of “highmass” stars in the asteroseismic sample to be due to the original selection of the stars.
The detailed structure in the radius and mass distribution enabled us to identify different stellar populations in our sample which we can compare with synthetic populations for the Kepler field of view. To do so, we used the synthetic redgiant population for the Kepler field of view as presented by Huber et al. (2010) and computed with the stellar synthesis code TRILEGAL (Girardi et al. 2005) in the same way as by Miglio et al. (2009) for one of the CoRoT fields. The synthetic radius and mass distributions are indicated as dashed lines in Fig. 12. Although the comparison can not be done in an absolute sense as the observed sample is biased, the observed and synthetic distributions look quite similar but show also some interesting differences. The redclump feature in the synthetic radius distribution is slightly broader and has its maximum at a lower radius compared to the observed distribution. Additionally, the RGB component is less pronounced, which is due to significantly less redbump stars in the synthetic population. Since the stellar synthesis does not include stellar clusters, the main difference in the mass distributions is due to fewer 1.3 to 1.5 M_{⊙} stars in the synthetic distribution. More interesting is, however, the difference for highmass stars (>2 M_{⊙}) indicating differently populated secondary clumps. Although these differences potentially carry detailed informations about the star formation history in the Kepler field of view and the associated physics, it would require detailed modelling to further investigate them, which is beyond the scope of this paper.
4.4.3. Testing the KIC parameters
Finally, we compared in Fig. 13 (upper panel) the seismically determined effective temperature with the KIC temperature. We find the seismic temperature systematically shifted towards lower temperatures by about 50 K (see linear fit and binned values). The rms scatter (about 120 K) of the temperature difference is, however, within the assumed uncertainties for the KIC temperatures of 200 K (priv. comm. Brown). The KIC uncertainties seem therefore to be overestimated but one has to keep in mind that our algorithm uses the KIC temperatures as an input parameter and the two temperature estimates are therefore not independent. A more meaningful indicator for the reliability of our fundamental parameter estimation is the surface gravity, which is also given in the KIC but not used in our analysis. The seismic mass and radius directly translate to a surface gravity and a comparison between the seismic and KIC surface gravity is shown in the bottom panel of Fig. 13. Here we found a systematic difference indicated by a linear fit and binned values. For the redclump stars (around log g = 2.5) the difference is negligible but drifts apart for stars above (towards lower surface gravity) and below (towards higher surface gravity) the red clump. The difference is, however, less than 0.5 dex for the entire range, and therefore within the uncertainties for the KIC parameters.
We also compared our seismic log g values for a few stars in common with the spectroscopic study of Bruntt et al. (2010, A&A, in prep.). There is very good agreement with a mean difference (spectroscopy minus seismic log g) of Δlog g = + 0.03 ± 0.15. We quote the rms scatter for the seven stars in common.
Fig. 13
Comparison between the seismically determined effective temperature and surface gravity and the corresponding KIC parameters. Dashed lines indicate a linear fit and red square symbols (in the online version only) show binned values.

Open with DEXTER
5. Summary and conclusions
We have analysed highprecision photometric time series from the first four months of Kepler observations and found more than 1 000 stars that show a clear power excess in a frequency range typical for solartype oscillations in red giants. We have applied robust and automated methods to accurately determine the global seismic parameters ν_{max} and Δν, and provide an automated identification of the mode degree as well as small spacings for about one half of our sample. We have analysed the uncertainties in our parameter determination and find a clear relation for the uncertainty of ν_{max} depending on the frequency resolution but also on the heighttobackground ratio and the width of the power excess, which are largely determined by the star itself as long as the power excess is well above the white noise of the observations. We have applied our methods to solar data to determine solar reference values for ν_{max} and Δν. The measured seismic parameters were then compared to those of an extensive multimetallicity grid of stellar models, where the seismic parameters of the models were determined from scaling relations. A Bayesian approach for the search of a best fit between observed and model parameters allowed us to derive realistic uncertainties for all fundamental parameters. In principle, we could have estimated the fundamental parameters from the seismic scaling relations using the KIC temperatures. However, we found strong indications that our analysis produced more accurate fundamental parameters and gives us a more detailed view of the stellar populations in our sample of stars.
We have placed the analysed stars in a HR diagram and found clear features in the distribution of the stars, which we identified as the red clump, the secondary clump, and the red bump. We found a mass gradient in the red clump with the lowmass stars accumulated at the bottom of the red clump and that the red bump is dominated by 1 M_{⊙} stars. Although we cannot determine the chemical composition reliably of individual stars we can conclude in a statistical sense that most of the redclump stars in our sample are similar to the Sun in terms of the their initial chemical composition with some indications for a metallicity gradient that follows the mass gradient of the red clump. On the other hand we found that the bump stars are more consistent with metalenhanced stars, which is surprising for a sample of stars that is selected according to criteria that do not constrain the chemical composition. A possible explanation could be that the mixing length parameter used to construct the models is too high. A slightly less efficient convection would shift the solar metallicity redbump models towards lower temperatures in the direction of the observed red bump.
The large sample allowed us to investigate the detailed structure of the radius and mass distribution of red giants in the Kepler field of view clearly showing the different populations. A comparison with synthetic distributions indicated quantitative agreement but needs further investigations. With the present study and what was presented by Huber et al. (2010) and Mosser et al. (2010) there are now detailed redgiant populations available for three different regions in the sky, which should be used for future detailed population synthesis studies as first done by Miglio et al. (2009).
Finally, we mention that although the parameters uncertainties in our analysis are already quite realistic they still represent only a lower limit. There are several effects we do not yet take into account. For example, the frequency dependence of the large frequency spacing (cf. Mosser et al. 2010) might play a role, as might the weak asymmetry of the power excess humps. To investigate this in more detail we have to wait until Kepler can provide significantly longer time series. On the other hand, we expect a larger effect from the limitations of the used model grid. Although our grid covers a wide range in chemical composition, which is one of the parameters that can significantly influence the MLRT_{eff} relation, there are other model parameters such as overshooting or a better description of convection, that could change this relation as well and therefore could have consequences to our analysis. These effects are difficult to estimate and are still largely unexplored territory.
For the individual seismic parameters we refer to Hekker et al. (2010c) providing an online table for all red giants observed with Kepler. However, our fundamental parameter estimates are not included in this table because they will continuously be improved with the ongoing observations. But we encourage everybody who is interested in our results to request them personally from the lead author.
Note that this function is frequently referred to as power law or Harveylike model. It is, however, clearly not a power law and Harvey (1985) originally used a Lorentzian. We therefore suggest the name “superLorentzian” with the power 4, which is sometimes used in optics.
Available from http://albione.oateramo.inaf.it/
Acknowledgments
Funding for the Kepler Mission is provided by NASA’s Science Mission Directorate. T.K. is supported by the Canadian Space Agency, the Austrian Research Promotion Agency, and the Austrian Science Fund. S.H., Y.P.E. and W.J.C. acknowledge support by the UK Science and Technology Facilities Council. D.H. acknowledges support by the Astronomical Society of Australia. The research leading to these results has received funding from the European Research Council under the European Community’s Seventh Framework Programme (FP7/2007–2013)/ERC grant agreement no 227224 (PROSPERITY), as well as from the Research Council of K.U. Leuven grant agreement GOA/2008/04. The National Center for Atmospheric Research is a federally funded research and development center sponsored by the US National Science Foundation. We acknowledge support from the Australian Research Council. The authors gratefully acknowledge the Kepler Science Team and all those who have contributed to making the Kepler Mission possible.
References
 Ballot, J., García, R. A., & Lambert, P. 2006, MNRAS, 369, 1281 [NASA ADS] [CrossRef] [Google Scholar]
 Barban, C., Matthews, J. M., De Ridder, J., et al. 2007, A&A, 468, 1033 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Basu, S., Chaplin, W. J., & Elsworth, Y. 2010, ApJ, 710, 1596 [NASA ADS] [CrossRef] [Google Scholar]
 Batalha, N. M., Borucki, W. J., Koch, D. G., et al. 2010, ApJ, 713, L109 [NASA ADS] [CrossRef] [Google Scholar]
 Bedding, T. R., Huber, D., Stello, D., et al. 2010, ApJ, 713, L176 [NASA ADS] [CrossRef] [Google Scholar]
 Borucki, W., Koch, D., Basri, G., et al. 2008, ed. Y.S. Sun, S. FerrazMello, & J.L. Zhou, IAU Symp., 249, 17 [Google Scholar]
 Borucki, W. J., Koch, D., Basri, G., et al. 2010, Science, 327, 977 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Broomhall, A., Chaplin, W. J., Davies, G. R., et al. 2009, MNRAS, 396, L100 [NASA ADS] [CrossRef] [Google Scholar]
 Brown, T. M., Gilliland, R. L., Noyes, R. W., & Ramsey, L. W. 1991, ApJ, 368, 599 [NASA ADS] [CrossRef] [Google Scholar]
 Buzasi, D., Catanzarite, J., Laher, R., et al. 2000, ApJL, 532, 133 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Carrier, F., De Ridder, J., Baudin, F., et al. 2010, A&A, 509, A73 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 ChristensenDalsgaard, J. 2004, Solar Phys., 220, 137 [NASA ADS] [CrossRef] [Google Scholar]
 ChristensenDalsgaard, J., Kjeldsen, H., Brown, T. M., et al. 2010, ApJ, 713, L164 [NASA ADS] [CrossRef] [Google Scholar]
 Creevey, O. L., Monteiro, M. J. P. F. G., Metcalfe, T. S., et al. 2007, ApJ, 659, 616 [NASA ADS] [CrossRef] [Google Scholar]
 De Ridder, J., Barban, C., Carrier, F., et al. 2006, A&A, 448, 689 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 De Ridder, J., Barban, C., Baudin, F., et al. 2009, Nature, 459, 398 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Dupret, M., Belkacem, K., Samadi, R., et al. 2009, A&A, 506, 57 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Edmonds, P. D., & Gilliland, R. L. 1996, ApJ, 464, L157 [NASA ADS] [CrossRef] [Google Scholar]
 Frandsen, S., Carrier, F., Aerts, C., et al. 2002, A&A, 394, L5 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Frohlich, C., Andersen, B. N., Appourchaux, T., et al. 1997, Solar Phys., 170, 1 [NASA ADS] [CrossRef] [Google Scholar]
 Gilliland, R. L., Brown, T. M., ChristensenDalsgaard, J., et al. 2010, PASP, 122, 131 [NASA ADS] [CrossRef] [Google Scholar]
 Girardi, L. 1999, MNRAS, 308, 818 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
 Girardi, L., Groenewegen, M. A. T., Hatziminaoglou, E., & da Costa, L. 2005, A&A, 436, 895 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Gizon, L., & Solanki, S. K. 2003, ApJ, 589, 1009 [NASA ADS] [CrossRef] [Google Scholar]
 Gruberbauer, M., Kallinger, T., Weiss, W. W., & Guenther, D. B. 2009, A&A, 506, 1043 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Harvey, J. 1985, in Future Missions in Solar, Heliospheric & Space Plasma Physics, ed. E. Rolfe & B. Battrick, ESA SP, 235, 199 [Google Scholar]
 Hekker, S., Kallinger, T., Baudin, F., et al. 2009, A&A, 506, 465 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Hekker, S., Broomhall, A., Chaplin, W. J., et al. 2010a, MNRAS, 402, 2049 [NASA ADS] [CrossRef] [Google Scholar]
 Hekker, S., Debosscher, J., Huber, D., et al. 2010b, ApJ, 713, L187 [NASA ADS] [CrossRef] [Google Scholar]
 Hekker, S., Elsworth, Y., De Ridder, J., et al. 2010c, A&A, accepted [Google Scholar]
 Huber, D., Bedding, T. R., Stello, D., et al. 2010, ApJ, accepted [arXiv:1010.4566] [Google Scholar]
 Huber, D., Stello, D., Bedding, T. R., et al. 2009, Commun. Asteroseismol., 160, 74 [NASA ADS] [CrossRef] [Google Scholar]
 Jenkins, J. M., Caldwell, D. A., Chandrasekaran, H., et al. 2010, ApJ, 713, L120 [NASA ADS] [CrossRef] [Google Scholar]
 Kallinger, T., Guenther, D. B., Matthews, J. M., et al. 2008a, A&A, 478, 497 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kallinger, T., Guenther, D. B., Weiss, W. W., et al. 2008b, CoAst, 153, 84 [NASA ADS] [CrossRef] [Google Scholar]
 Kallinger, T., Weiss, W. W., Barban, C., et al. 2010, A&A, 509, A77 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kallinger, T., Zwintz, K., Pamyatnykh, A. A., Guenther, D. B., & Weiss, W. W. 2005, A&A, 433, 267 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kjeldsen, H., & Bedding, T. R. 1995, A&A, 293, 87 [NASA ADS] [Google Scholar]
 Kjeldsen, H., Bedding, T. R., & ChristensenDalsgaard, J. 2008, ApJ, 683, L175 [NASA ADS] [CrossRef] [Google Scholar]
 Latham, D. W., Brown, T. M., Monet, D. G., et al. 2005, in BAAS, 37, 1340 [NASA ADS] [Google Scholar]
 Mathur, S., García, R. A., Régulo, C., et al. 2010, A&A, 511, A46 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mazumdar, A., Mérand, A., Demarque, P., et al. 2009, A&A, 503, 521 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Merline, W. J. 1999, in Precise Stellar Radial Velocities, ed. J. B. Hearnshaw, & C. D. Scarfe, ASP Conf. Ser., 185, IAU Colloq., 170, 187 [Google Scholar]
 Miglio, A., Montalbán, J., Baudin, F., et al. 2009, A&A, 503, L21 [NASA ADS] [CrossRef] [EDP Sciences] [MathSciNet] [Google Scholar]
 Monet, D. G., Jenkins, J. M., Dunham, E. W., et al. 2010, ApJL, submitted [arXiv:1001.0305] [Google Scholar]
 Mosser, B., & Appourchaux, T. 2009, A&A, 508, 877 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mosser, B., Belkacem, K., Goupil, M. J., et al. 2010, A&A, 517, A22 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Nigam, R., Kosovichev, A. G., Scherrer, P. H., & Schou, J. 1998, ApJL, 495, 115 [NASA ADS] [CrossRef] [Google Scholar]
 Pietrinferni, A., Cassisi, S., Salaris, M., & Castelli, F. 2004, ApJ, 612, 168 [NASA ADS] [CrossRef] [Google Scholar]
 Retter, A., Bedding, T. R., Buzasi, D. L., Kjeldsen, H., & Kiss, L. L. 2003, ApJ, 591, L151 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., & Gilliland, R. L. 2009, ApJ, 700, 949 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., Bruntt, H., Kjeldsen, H., et al. 2007, MNRAS, 377, 584 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., Bruntt, H., Preston, H., & Buzasi, D. 2008, ApJ, 674, L53 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., Chaplin, W. J., Basu, S., Elsworth, Y., & Bedding, T. R. 2009a, MNRAS, 400, L80 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., Chaplin, W. J., Bruntt, H., et al. 2009b, ApJ, 700, 1589 [NASA ADS] [CrossRef] [Google Scholar]
 Stello, D., Basu, S., Bruntt, H., et al. 2010, ApJ, 713, L182 [NASA ADS] [CrossRef] [Google Scholar]
 Tarrant, N. J., Chaplin, W. J., Elsworth, Y., Spreckley, S. A., & Stevens, I. R. 2007, MNRAS, 382, L48 [NASA ADS] [CrossRef] [Google Scholar]
 Tassoul, M. 1980, ApJS, 43, 469 [NASA ADS] [CrossRef] [Google Scholar]
 Toutain, T., & Froehlich, C. 1992, A&A, 257, 287 [NASA ADS] [Google Scholar]
 van Leeuwen, F. 2007, A&A, 474, 653 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
All Figures
Fig. 1
Relative flux for the Q0, Q1, and Q2 data of KIC 6838420. The top panel shows the original time series (grey points) with the 2nd order polynomial fits overlaid (black lines). The bottom panel shows the residual time series.

Open with DEXTER
In the text
Fig. 2
Left panel: power density spectra for a sample of red giants observed with Kepler. Black lines indicate the global model fit and dotted lines show the global model plotted without the Gaussian component, which serve as a model for the background signal. Dashed lines indicate the background components. KIC numbers are given in the upper right corners. Right panel: residual power density spectra shifted to the central frequency (given in absolute numbers in the plots) of our model to determine the frequency separations and normalised to the large frequency separation. Black lines correspond to the best fitting model. The dashed line marks the midpoint between adjacent l = 0 modes.

Open with DEXTER
In the text
Fig. 3 The uncertainty in ν_{max} in actual value (right axis) and in units of the frequency resolution as a function of the ratio between the heighttobackground ratio (HBR) and the width of the power excess, σ_{g}. The line indicates a powerlaw model for the lower envelope.

Open with DEXTER
In the text
Fig. 4
Histograms of the relative uncertainties for ν_{max}, the large frequency separation Δν, and the small separations δν_{01} and δν_{02}.

Open with DEXTER
In the text
Fig. 5
Power density spectrum of a 1year VIRGO time series (lightgrey) and the corresponding global model fit (black line). The darkgrey line shows a smoothed (5 μHz boxcar filter) version from the average of nine consecutive 1year VIRGO time series. The inset gives the probability density function for ν_{max} with the vertical solid and dashed lines indicating the median value and the 1σ limits, respectively.

Open with DEXTER
In the text
Fig. 6
Same as Fig. 5 but as delivered from our algorithm to determine the frequency spacings. Top panels: probability density functions for the three spacing parameters and the central frequency of our model fit. Median values and 1σ limits are indicated by vertical solid and dashed line, respectively. Bottom panel: residual power density spectrum (lightgrey) of a 1year VIRGO time series and the corresponding model fit (black line).

Open with DEXTER
In the text
Fig. 7
The projected probability (left) and cumulative probability (right) distribution functions for the radius of the artificial test star 6 (Basu et al. 2010). The full horizontal line correspond to the median and the dashed lines give the ± 1σ confidence interval.

Open with DEXTER
In the text
Fig. 8
The stellar radius as a function of mass for the sample of red giants as directly determined from Eqs. (4) and (5) using the KIC effective temperatures (top) and from the comparison with the stellar model grid (bottom).

Open with DEXTER
In the text
Fig. 9
HR diagram showing the location of our redgiant sample as directly determined from Eqs. (4) and (5) using the KIC effective temperatures (panel a)) and from the comparison with the stellar model grid (panel b) to e)). The colour code (in the online version only) indicates the stellar mass (a) and b)), radius c)), age d)), and metallicity (e)), where the radius scale has been truncated below 6 and above 14 R_{⊙ }. Grey lines show solarmetallicity BaSTI evolutionary tracks. The boxes given in the lower right corners illustrate typical uncertainties.

Open with DEXTER
In the text
Fig. 10
HR diagrams showing our sample of red giants (black dots) with respect to different metallicity model grids (red dots – in the online version only).

Open with DEXTER
In the text
Fig. 11
Histograms of the relative (and absolute for T_{eff}) uncertainties for the asteroseismic fundamental parameter.

Open with DEXTER
In the text
Fig. 12
Histograms for the radius and mass distribution in our sample of redgiant stars compared to the distribution of a synthetic redgiant population.

Open with DEXTER
In the text
Fig. 13
Comparison between the seismically determined effective temperature and surface gravity and the corresponding KIC parameters. Dashed lines indicate a linear fit and red square symbols (in the online version only) show binned values.

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
