Electron fraction constraints based on nuclear statistical equilibrium with beta equilibrium
^{1}
Institut für Kernphysik, Technische Universität Darmstadt,
Schlossgartenstr. 9,
64289
Darmstadt
Germany
email: a.arcones@gsi.de
^{2}
GSI Helmholtzzentrum für Schwerionenforschung GmbH,
Planckstr. 1,
64291
Darmstadt,
Germany
^{3}
Department of Astronomy and Astrophysics, University of
California, Santa
Cruz, CA
95064,
USA
Received:
17
February
2010
Accepted:
15
July
2010
The electrontonucleon ratio or electron fraction is a key parameter in many astrophysical studies. Its value is determined by weakinteraction rates that are based on theoretical calculations subject to several nuclear physics uncertainties. Consequently, it is important to have a model independent way of constraining the electron fraction value in different astrophysical environments. Here we show that nuclear statistical equilibrium combined with beta equilibrium can provide such a constraint. We test the validity of this approximation in presupernova models and give lower limits for the electron fraction in type Ia supernova and accretioninduced collapse.
Key words: equation of state / stars: abundances / stars: evolution / supernovae: general
© ESO, 2010
1. Introduction
Weak interactions are known to play a critical role in the structure and evolution of stars and the kind of nucleosynthesis they produce (e.g. Langanke & MartínezPinedo 2003). For nuclei near the valley of betastability, the relevant lifetimes of unstable nuclei are well determined in the laboratory. However at the high temperatures and densities found in stars and stellar explosions, nuclei may be produced that are either very proton or neutronrich. Usually the rates for weak interactions involving such nuclei are only available from theory. Further, these nuclei exist in a distribution of excited levels, making even a theoretical calculation of their weak lifetimes problematic.
Over the years, different groups have calculated weakinteraction rates for astrophysical applications (for a review see Langanke & MartínezPinedo 2003). In the 1980s Fuller et al. (Fuller et al. 1980, 1982b,a, 1985, hereafter FFN) calculated rates for electron capture, positron capture, beta decay, and positron emission for astrophysically relevant nuclei. Their tabulations were based on an examination of all available information at that time and became the standard in the field. With the improvement of methods and computers, complete shellmodel calculations were performed for sdshell nuclei (Oda et al. 1994) and for pfshell nuclei (Langanke & MartínezPinedo 2000; Langanke & MartínezPinedo 2001, hereafter LMP). Although these new shellmodel rates and the FFN rates agree rather well for sdshell nuclei, there are appreciable difference at higher mass. The electroncapture rates, and to a lesser extent, the betadecay rates (see MartínezPinedo et al. 2000) are smaller than the FFN rates by approximately one order of magnitude.
In this paper we discuss an interesting limiting case that can be used to test existing rate tabulations and their implementation as well as to calculate astrophysical models in regions where rate information may currently be inadequate. Dynamic betaequilibrium (Tsuruta & Cameron 1965; Imshennik et al. 1967; Imshennik & Chechetkin 1971; Cameron 2001; Odrzywolek 2009) occurs when sufficient time elapses at a given temperature and density for the electron mole number, Y_{e}, to approach a constant. That is, for an ensemble of nuclei (but not necessarily individual nuclei), electron capture and positron emission occur at a rate balanced by electron emission and positron capture. While physically not the same situation as when neutrino absorption balances neutrino emission (thermal weak equilibrium), the solution to the abundance equations is the same in many of the astrophysical environments of interest, as we will show. Where this approximation holds, a set of nuclear abundances can be obtained, and thus a steady state value for Y_{e}, that depends only on nuclear bulk properties (like binding energy and partition function), the temperature, and the density. Similar work was done by Imshennik & Chechetkin (1971), but our results are based on improved nuclear data present a broader overview of the possible astrophysical scenarios where this approximation becomes useful.
There are only a few places in nature where thermal weak equilibrium actually occurs, but they are interesting. Obviously the Big Bang is one, but there the abundances are simple, just neutrons and protons. Dynamic betaequilibrium exists in neutron stars^{1} (Baym et al. 1971; Weber 1999) and may occur briefly in the cores of massive stars after silicon burning (Aufderheide et al. 1994b,a; Heger et al. 2001a,b). It may also happen in white dwarfs that ignite carbon runaways at very high density (Canal et al. 1990). In the latter case, there is thought to exist a critical ignition density above which the reduction in electron density by electron capture more than offsets the rise in thermal pressure due to the burning. Above this density whose exact value depends on composition, initial mass, and accretion rate (Canal et al. 1990), it is expected that the white dwarf collapses to a neutron star rather than exploding as a supernova. This scenario is still only theoretical since it was not yet observed. Just short of this critical density, which may be ~8 × 10^{9} g cm^{3} (Timmes & Woosley 1992; Woosley 1997), the star does explode but ejects neutronrich isotopes (e.g., ^{48}Ca) that are difficult to make elsewhere in nature (Woosley 1997). In addition, as the Chandrasekhar mass scales as , if a flame reduces the Y_{e} before the star begins to expand vigorously, it will collapse. The race between expansion and electron capture must be determined by hydrodynamical simulations with physical fidelity, preferably in 2D or 3D. Until they are done, it is difficult to make quantitative statements, but it is expected that a 10% change in the terminal value of Y_{e} would cause an approximately 10% change in the terminal density and might affect whether e.g., the critical ignition density for collapse is 8 or 9 × 10^{9} g / cm^{3} (Timmes & Woosley 1992). Instabilities could make the dependence nonlinear. Thus it is important to know what the minimum achievable value is for Y_{e} at a given temperature and density.
To proceed, we calculate the electron fraction and the composition assuming thermal weak equilibrium for temperatures and densities that are relevant to various astrophysical environments. Thermal weak equilibrium will only exist at such high temperatures and densities that nuclear statistical equilibrium (NSE) also prevails, and we assume that to be the case. We show that for temperatures, T ≲ 10 GK, thermal weak equilibrium reduces approximately to the dynamic betaequilibrium of Tsuruta & Cameron (1965). This allows to obtain results that depend only upon binding energies and partition functions, not individual weak interaction rates. At higher temperatures, thermal neutrinos are absorbed with a rate comparable to the electron emission rate. When this happens thermal weak equilibrium and dynamic betaequilibrium become different. Nevertheless, the equilibrium value of the electron fraction for dynamic betaequilibrium can still be obtained using a rather simple description of the relevant weak interaction rates.
Our paper is organized as follows. We start with a brief review of NSE, thermal weak equilibrium and dynamic betaequilibrium in Sect. 2. The results obtained from combining these assumptions are presented in Sect. 3 for broad ranges of temperature and density. In Sect. 4, we discuss the astrophysical implications of our results for presupernova models (Sect. 4.1), protoneutron star evolution (Sect. 4.2), and accretioninduced collapse and type Ia supernovae (Sect. 4.3). Finally, we conclude in Sect. 5.
2. NSE, thermal weak equilibrium and dynamic betaequilibrium
At high temperatures (T > 4 GK ≈ 0.3 MeV) the photon energy in an astrophysical plasma is high enough to dissociate nuclei into nucleons. At the same time, for densities ρ ≈ 10^{6} −10^{13} g / cm^{3}, rapid nuclear reactions lead to the formation of nuclei. An equilibrium is reached between strong and electromagnetic reactions. This is known as the NSE, where the abundances of nuclei follow simply from Saha equation for a given density, temperature, and electron fraction. Although this is well known, we briefly summarize the relevant equations.
When NSE is reached, production and destruction of nuclei occur at the same rate and the chemical potentials of nuclei and nucleons have to satisfy:
where the chemical potentials include the total mass
Here η_{i} is the degeneracy parameter, k the Boltzmann constant, T the temperature, and μ_{c} the Coulomb contribution to the chemical potential (see Appendix in Juodagalvis et al. 2009). The electron chemical potential is given by μ_{e} = m_{e}c^{2} + η_{e}.
The abundance Y_{i} = n_{i} / n of isotope i is given by the ratio of its number density n_{i} over the total baryon number density n. The number density n_{i} is related to the degeneracy parameter η_{i} assuming MaxwellBoltzmann statistics by:
with the partition function G_{i}(T) = ∑ (2J_{k} + 1)e^{ − Ek / kT} and the thermal wavelength . For the partition function we use values calculated by Rauscher (2003).
Protons also follow MaxwellBoltzmann distributions over the densities of interest, but neutrons become degenerate for ρ ≳ 10^{11} g / cm^{3} (the transition from the nondegenerate to degenerate regime of course depends on the temperature). Therefore, we use FermiDirac distributions for nucleons (both neutrons and protons),
where β = kT / mc^{2} is the socalled relativistic parameter, which is almost zero for the range of temperatures considered here, and ℱ_{k} are Fermi functions:
The electron mole number is defined as Y_{e} = n_{e}/n, with the lepton number density n_{e} = n_{e − } − n_{e + }. The electron, n_{e − }, and positron, n_{e + }, number densities are related to the respective chemical potentials by Eq. (4) with the additional condition μ_{e} = μ_{e − } = − μ_{e + }.
Combining Eqs. (1) and (3), the abundance of the nucleus with Z, A is (6)Here ρ is the baryon density and m_{u} the atomic mass unit. Note that small corrections (less than 1%) arise from using m_{i} = Am_{u} (Seitenzahl et al. 2009). To calculate the NSE composition, we take the binding energies, B = Zm_{p}c^{2} + (A − Z)m_{n}c^{2} − m_{(Z,A)}c^{2} from Audi et al. (2003) and supplemented by theoretical values from Möller et al. (1995). In addition, the degeneracy parameters η_{n}, η_{p} are determined by charge neutrality and mass conservation,
Equations (6)–(8) can be solved to obtain η_{n}, η_{p}, and Y(Z,A) for given temperature, density and electron fraction.
The electron fraction is generally determined by weak process that are much slower than the strong and electromagnetic nuclear reactions responsible for maintaining NSE. However, if the system remains at a given temperature and density long enough, weak reactions can also reach equilibrium. If the neutrinos produced by the weak interaction do not leave the system, the equilibrium reached is denoted as thermal weak equilibrium. In order to determine the evolution of the system before thermal weak equilibrium is achieved neutrino transport calculations are necessary (see Murphy 1980). Once, thermal weak equilibrium is achieved, the neutrinos have a FermiDirac spectrum with a temperature, T, and neutrino chemical potential . The state of the system is completely determined by the temperature, density and lepton fraction (relative number of electrons and neutrinos).
Once thermal weak equilibrium is reached, the composition does not change unless the temperature or density varies. Therefore, entropy is conserved which implies that TdS = ∑ _{i}μ_{i}dY_{i} = 0 (see Meyer 1993, for useful discussion of equilibrium in nucleosynthesis), thus
here the righthand side is obtained from the assumption of NSE and the condition of lepton number conservation that implies, Ẏ_{ν} = − Ẏ_{e}. The time variation of the abundance of nucleus i is given by Ẏ_{i}. Using Eqs. (7) and (8) this reduces to
The value of Y_{e} for which equilibrium is attained can be obtained from the thermal weak equilibrium condition
This implies that the value of the neutrino chemical potential is a function of lepton fraction, temperature, and baryon density. Alternatively, the equilibrium Y_{e} can be obtained from
which requires the knowledge of the weak interaction rates for electron capture (ec), positron emission (β^{ + }), antineutrino absorption (), inverse of electron emission (inβ^{ − }), positron capture (pc), electron emission (β^{ − }), neutrino absorption (ν_{e}), and inverse of possitron emission (inβ^{ + }) for a large ensemble of nuclei. Equations (11) and (12) represent equivalent ways of obtaining the steady state value of Y_{e}, if entropy is constant. Equation (11) is certainly advantageous as it depends only on bulk nuclear properties like binding energies and partition functions. However, its applicability is rather limited because at stellar densities below ~10^{11} g cm^{3} neutrinos scape and consequently a neutrino chemical potential cannot be defined. In these cases, a dynamical betaequilibrium can still be achieved and its equilibrium Y_{e} value is given by Eq. (12) suppressing the neutrino absorption rates:
Nevertheless, we will show in the following that Eq. (11) together with the assumption μ_{ν} = 0 provides a very good approximation to the solution of Eq. (13), i.e., thermal weak equilibrium with μ_{ν} = 0 reduces to dynamical betaequilibrium. In this case the neutrino density depends only on temperature:
with p being the neutrino momentum and pc its energy. At low temperatures the neutrino densities are so small that can be neglected and consequently the condition μ_{ν} = 0 reduces to n_{ν} = 0. This is the situation in cold neutron stars where Eq. (11) with μ_{ν} = 0 is commonly used (Weber 1999) to determine the composition. However, at higher temperatures the assumption of μ_{ν} = 0 results in neutrino densities comparable to electron densities and consequently thermal weak equilibrium, Eq. (11), and dynamical beta equilibrium, Eq. (13), predict different values of Y_{e}. Under these conditions, one has to solve Eq. (13) using a full set of weak interaction rates (Odrzywolek 2009).
As discussed in the introduction, the determination of weakinteraction rates on nuclei is a very challenging nuclear structure problem that requires sophisticated many body calculations. Reliable weakinteraction rates are necessary to determine the evolution of the system and to account for the energy loss by neutrinos (Odrzywolek 2009). However, in this paper we are not interested in the evolution towards equilibrium, but only in the value of the equilibrium electron fraction for a given temperature and density. Therefore, only a simple description of the weak interaction rates is necessary.
We start considering the case of thermal weak equilibrium under the assumption that μ_{ν} = 0. This has the advantage that we can use Eqs. (11) and (12) to check the validity of our implementation of the weak interaction rates. Once these are validated, we can can easily generalize our approach to the case with neutrinos leaving the system, by setting the neutrino densities to zero. Let us consider a couple of nuclei (A,Z) and (A,Z − 1) connected by the weak interactions:
If neutrinos are present, these reactions can operate in both directions. Only the right direction is relevant for cases where neutrinos leave the system. One can approximate these reactions assuming that they occur by a transition from the ground state of the initial nucleus to the ground state of the final nucleus. This is an exact result for neutrons and protons and has been shown to provide a reasonable description of electron capture rates for a broad range of nuclei (see Fig. 2 of Langanke et al. 2003). Here we generalize this prescription to the other rates in Eq. (15). Our aim is not to obtain accurate weakinteraction rates but an approach that reproduces the balance between forward and reverse reactions once equilibrium is achieved. In this sense our results should not be considered as a substitute to the different tabulations of weak interaction rates available in the literature. We use the following expressions to calculate the weakinteraction rates in Eq. (15):
where the first four equations correspond to the forward direction in Eq. (15) describing the rates for electron capture (ec), positron emission (β^{ + }), electron emission (β^{ − }), and positron capture (pc), respectively. The last four equations describe neutrino absorption (ν_{e}), the inverse of positron emission (inβ^{ + }), the inverse of electron emission (inβ^{ + }), and antineutrino absorption (). Q is the transition Q value, i.e. Q = M(A,Z − 1)c^{2} − M(A,Z)c^{2}, that is positive for neutronrich nuclei and protons. M(A,Z) is the nuclear mass. The quantity C is given by
with K = 6144 s (Hardy & Towner 2009) and B the nuclear matrix element. We use the value for nucleons and B = 4.6 for nuclei (Langanke et al. 2003). We have checked that our results are not sensitive to 20% variations of this value. f is the FermiDirac distribution
The quantity w_{ec} = max(m_{e}c^{2},Q) is the threshold energy for electron capture, and w_{pc} = max(m_{e}c^{2}, − Q) for positron capture rate. The integral in Eqs. (16b) and (16f) are defined only for − Q > m_{e}c^{2}. Similarly, the integrals in Eqs. (16c) and (16g) are defined only for Q > m_{e}c^{2}.
The value of the equilibrium electron fraction agrees up to 3 significant figures when we solve Eqs. (11) or (12). This justifies our simple scheme, Eq. (16), for calculating the weak interaction rates.
Dynamic betaequilibrium, Eq. (13), can be obtained from the rates in Eqs. (16) setting the neutrino distributions to zero. The equilibrium electron fraction in dynamic betaequilibrium is typically smaller than the one calculated in thermal weak equilibrium. As in the latter, neutrino absorption results in an increase of the electron fraction.
3. Results
We solve the NSE equations (Eqs. (6) − (8)) under the constraint of thermal weak equilibrium, Eq. (11), assuming μ_{ν} = 0 for temperatures from 5 to 150 GK (0.43 − 13 MeV) and densities in the range 10^{6} − 10^{12} g / cm^{3}. This results in the equilibrium electron fraction shown in Fig. 1 and in the composition shown in Figs. 4 − 6. Because only small changes are expected at high temperatures, we plot all quantities only over a smaller temperature range. The whole data table is available on request.
Fig. 1
The electron fraction for NSE with thermal weak equilibrium is shown by color contours for a range of densities and temperatures where NSE can be applied and which are relevant in different astrophysical scenarios. The solid black line shows the corecollapse trajectory for a 15 M_{⊙} (A. Marek, priv. com.); the dashed lines represent the presupernova evolution of a 15 M_{⊙} (black) and 25 M_{⊙} (blue) stars; the red dashed lines represent a type Ia trajectory (F. Röpke, priv. com.); and the solid yellow lines correspond to the evolution of the protoneutron star surface. Not all these scenarios will reach beta equilibrium and their electron fraction can therefore be different to the one shown here.
In Fig. 1 the color contours show the electron fraction assuming thermal weak equilibrium and the lines represent trajectories (density and temperature evolution) of various astrophysical scenarios: presupernova, core collapse, protoneutron star surface, and type Ia supernovae. The collapse trajectory (A. Marek, priv. com.) of a 15 M_{⊙} star based on the presupernova models of Woosley et al. (2002) is shown by the solid black line. When the inner core of a massive star collapses the evolution is much faster than weak reactions, therefore beta equilibrium is not achieved. Once densities above 10^{11} g cm^{3} are reached neutrinos begin to be trapped and the assumption of μ_{ν} = 0 is not valid any more. Therefore, the equilibrium Y_{e} differs from the value obtained in detailed hydrodynamical simulations with neutrino transport. However, we include this trajectory in our figure for completeness, to have an idea of the range of temperatures and densities we are studying. Presupernova trajectories for 15 M_{⊙} and 25 M_{⊙} stars (Woosley et al. 2002) are shown by the dashed lines. This is discussed in detail in Sect. 4.1. The solid yellow line in the high temperature region represents the evolution of the hot protoneutron star surface, where both thermal weak equilibrium and NSE are fulfilled (Sect. 4.2). And the red dashed line represents a trajectory of a type Ia supernova (F. Röpke, priv. com.), where the evolution normally proceeds much faster than the weak interaction timescale and consequently no equilibrium is achieved (Sect. 4.3).
Fig. 2
The electron fraction for NSE with dynamic betaequilibrium is shown by color contours for the same range as in Fig. 1. The black line represent the region where .
For completeness we show in Fig. 2 the electron fraction obtained in NSE assuming dynamic betaequilibrium, Eq. (13), for the same temperatures and densities as shown in Fig. 1. As discussed in Sect. 2, we expect that dynamic betaequilibrium and thermal weak equilibrium with μ_{ν} = 0 give similar electron fraction whenever the absorption of thermal neutrinos is negligible. This occurs on the left side of the solid line shown in Fig. 2. This line marks the conditions for which the antineutrino absorption would become equal to beta decay if neutrinos did not escape. At high temperatures the results for both equilibria are not so different because the composition is dominated by neutrons and protons and moreover positron captures also become important. In fact, at low densities (below the curve marked as η_{e} = 0 in Fig. 3) one has that μ_{e} ≈ μ_{e + } ≈ 0 implying that the contributions of electrons/positrons and antineutrinos/neutrinos are similar. This explains why both equilibria lead to same electron fraction for Big Bang conditions. The biggest differences between both approaches appear in the region where the composition changes from heavy nuclei to nucleons (Fig. 3). Moreover, it is in this region where the electron fraction drops more abruptly and consequently its value becomes rather sensitive to the equilibrium approach used.
Although solution of the full equations gives the value of the equilibrium electron fraction, some simple approximations help to understand the results. We divide the ρ − T plane in different temperature and density ranges to explain the behaviour of the electron fraction. These ranges are shown in Fig. 3. The two horizontal lines correspond to electron and neutron degeneracy equal zero. We consider densities below the line of η_{e} = 0 to be low and above the line of η_{n} = 0 to be high. The temperatures are considered to be low when heavy nuclei or alpha particles are present, which in the figure correspond to the regions labeled as X_{heavy} > 0.5 and X_{a} > 0.5, respectively.
Fig. 3
Lines limit the regions where different approximations for Y_{e} can be used. Horizontal lines indicate where the degeneracy of electrons (η_{e}) and neutrons (η_{n}) is zero. The regions where nuclei and alpha particles dominate the composition are at low temperatures.
In NSE at high temperature (T ≳ 15 GK) one can assume that only nucleons are present because all nuclei are dissociated, thus Y_{e} = Y_{p} and Y_{n} = 1 − Y_{e}. For low densities conditions are similar to the Big Bang, where the composition consists mainly of nondegenerate neutrons, protons, and electrons. Therefore, we have μ_{e} = 0 and μ_{n} ≈ μ_{p} that together with Eq. (3) give:
where Δ = m_{n} − m_{p} = 1.293 MeV. Under these conditions Y_{e} can reach rather high values when the temperature becomes smaller than Δ. At higher densities (ρ ≳ 10^{8} − 10^{9} g / cm^{3}), electrons become degenerate and this approximation is not valid anymore. This happens when the density is above:
which corresponds to Eq. (4) assuming η_{e} ≈ 0 and using the values from Bludman & van Riper (1977) for the Fermi functions (ℱ_{1 / 2}(η = 0) = 0.6773 and ℱ_{3 / 2}(η = 0) = 1.153). This line is shown in Fig. 3 labeled as η_{e} = 0.
For densities above the line given by Eq. (20) the electron fraction can be estimated by taking into account that the electron number density is approximately given by:
From this equation we get directly η_{e}. If we assume that the nucleons follow MaxwellBoltzmann distributions (Eq. (3)), their chemical potentials are:
Inserting all this in the beta equilibrium equation (μ_{n} = μ_{p} + μ_{e}) we obtain a nonlinear equation for the electron fraction:
This can be solved numerically using as guess value the Y_{e} of Eq. (19). At high density, low Y_{e} (more neutronrich material) is expected from Eq. (23). The last term in Eq. (23) increases as the density increases, unless Y_{e} decreases. Moreover, a reduction of Y_{e} leads to an increase of the third term, which has opposite sign to the term containing the density. The exact solution, shown in Fig. 1, demonstrates the neutron richness of the matter at high densities.
For low temperatures (T ≲ 15 GK) the situation is more complicated because of the presence of bound nuclei. We estimate the densities and temperatures at which nuclei dominate the composition following the derivation of Hoyle & Fowler (1960). This leads to nuclei (represented by ^{56}Fe) corresponding to half of the mass at:
In a similar way, taking mass fraction (X_{i} = A_{i}Y_{i}) of alpha particles X_{α} = 0.5, alpha particles represent half of the mass, for which one has:
where X_{α}, X_{n}, and X_{p} are the alpha, neutron, and proton mass fractions, respectively, which are obtained from mass and charge conservation:
At low densities, between the two lines given by Eqs. (24) and (25), there are mainly alpha particles, therefore Y_{e} = 0.5. Above the line given by Eq. (24), the composition is more complicated due to the presence of different nuclei. For high density the nuclei become neutron rich. We can delimit the region where heavy nuclei are present using simple approximations, as described before. However, the detail composition and thus the electron fraction in this region can only be obtained by numerically solving NSE equations under the assumption of thermal weak equilibrium or dynamic betaequilibrium, as described in Sect. 2.
The mass fraction of alphaparticles is shown in Fig. 4. Alphaparticles appear mostly at low density and temperature, between the region where nucleons dominate the composition (high temperature) and the region where heavier nuclei are formed from the alpha particles. Notice that the formation alpha particle leads to a change in the behaviour of Y_{e} at low densities (Fig. 1). The mass fractions of heavy nuclei (A > 4) are shown in the panel (a) of Fig. 5, they dominate the composition at low temperatures and high densities. Figure 5 shows the average mass, proton and neutron numbers of the nuclei in panels (b) − (d) respectively. In addition we find that the abundances of light nuclei (A < 4) are significant at high temperatures and relative high densities, as shown in Fig. 6. Such conditions are found in the outer layer of the protoneutron star which is still hot as shown by the trajectory (yellow line) in Fig. 1.
Fig. 4
Mass fraction of alpha particles for the same temperature and density range as in Fig. 1. In the white regions the mass fraction of alpha particles is negligible.
Fig. 5
The panel a) shows the mass fraction of heavy nuclei (A > 4), in the white region no heavy nuclei are present. The other panels give the average mass b), atomic c), and neutron d) numbers. The blue line in the mass fraction plot marks the contour where heavy nuclei are half of the mass. In the average number plots, the black lines correspond to magic numbers and the red ones to ^{56}Fe.
4. Discussion and astrophysical implications
There are several astrophysical environments where our results are interesting (Fig. 1). These are situations where sufficient time elapses at high temperature for NSE to prevail and for weak interactions to approach equilibrium. Even when equilibrium is not fully achieved, our results give an interesting lower bound on Y_{e} in cases where electron capture is dominant.
4.1. Presupernova evolution
We investigate here two presupernova models that were already studied in detail in the frame of weak interactions by Heger et al. (2001a,b). Figure 7 shows the results for the 15 M_{⊙} star in the left column and for the 25 M_{⊙} star in the right one. All results are plotted versus time before collapse which is at time zero. The dotted lines are the Y_{e} of the old models of Woosley & Weaver (1995) (WW). These models were computed with electroncapture rates of Fuller et al. (1980) (FFN) and betadecay rates of Hansen (1968); )Mazurek et al. (1974). The dashed lines were obtained when using the weakinteraction rates of Langanke & MartínezPinedo (2001) (LMP) in the calculation of the presupernova models. These two results were already presented in Heger et al. (2001a,b), where they discuss that differences in the electron fraction are mainly due to discrepancies between the old beta decay rates and the new ones. The bottom panels in Fig. 7 show the electroncapture and betadecay rates as calculated by Langanke & MartínezPinedo (2001) and used for the presupernova models presented in Heger et al. (2001a,b).
Before silicon burning, the evolution of the electron fraction is very similar for WW and LMP because electron captures dominate over beta decays (see bottom panels in Fig. 7) and these rates are similar for FFN and LMP. In this first phase when Y_{e} starts to decrease from the starting value of 0.5, the temperature is too low and the assumption of NSE is not valid and there are no values for the equilibrium electron fraction.
During silicon shell burning the electron fraction continues dropping and beta decay becomes important and comparable to electron capture. For the 15 M_{⊙} star both rates are equal and a dynamic betaequilibrium is reached (Aufderheide et al. 1994a; Heger et al. 2001b). After silicon burning the electron fraction stays almost constant although electron captures become dominant over beta decays because the dynamical evolution is faster than the capture rates. Therefore, as it was pointed out by Heger et al. (2001b), the final electron fraction is set before the core begins its final contraction. The most important period for determining the core structure is thus the silicon shell burning phase.
Fig. 6
Mass fraction of light nuclei (A < 4).
Fig. 7
The electron fraction (upper plots), the electroncapture, and betadecay rates (bottom plots) as a function of time till collapse are shown for two presupernova models: 15 M_{⊙} (left) and 25 M_{⊙} (right). In the electron fraction plots the dotted lines (blue) and dashed lines (red) were already shown by Heger et al. (2001a) and correspond to the old models of Woosley & Weaver (1995) and to the new ones of Heger et al. (2001b), respectively. Here we have added the solid lines, which results from assuming NSE and thermal weak equilibrium (solid black line) or dynamic betaequilibrium (solid green line).
We use the density and temperature evolutions shown in Fig. 1 for the presupernova models of Woosley & Weaver (1995) and calculate the equilibrium electron fraction. This Y_{e} correspond to the solid lines in the upper panels of Fig. 7. Notice that there are two solid lines, the black one results from the assumption of thermal weak equilibrium, Eq. (11), while the green one is obtained under the assumption of dynamic betaequilibrium, Eq. (13). The resulting Y_{e} values are almost identical. For the 15 M_{⊙} star, where dynamic betaequilibrium is achieved in the simulation (see lower right panel of Fig. 7), all the Y_{e} values are almost identical for times around 10^{4} s. For the 25 M_{⊙} star, dynamic betaequilibrium is never reached and consequently our equilibrium Y_{e} is slightly smaller.
Our equilibrium electron fraction represents a static equilibrium and is obtained independently of the weakinteraction rates. Such an equilibrium is reached if the temperature and density are kept constant long enough. There are two points that a set of weakinteraction rates has to fulfil to be used in presupernova models: 1) if dynamic betaequilibrium is reached, the electron fraction should be very similar to our equilibrium electron fraction; 2) the electron fraction in the presupernova models can not drop below the equilibrium value we calculate. The older presupernova models of Woosley & Weaver (1995) do not fulfil these two constraints. Aufderheide et al. (1994a); )Heger et al. (2001b) suggested that older models needed to be recomputed with consistent set of weakinteraction rates. The new results (Heger et al. 2001b) based on better determination of the rates satisfy the two constraints. This test should also apply to future compilations of weakinteraction rates and their implementation in presupernova simulations.
4.2. Protoneutron star
Iron core collapse marks the end of the presupernova phase. When the collapse starts the dynamical evolution is very fast compared to the weak interaction timescale, thus the assumption of equilibrium is not valid. But when collapse continues, neutrinos are trapped due to the increasingly higher central densities, and thermal weak equilibrium can be reached again. However, neutrinos are trapped and their chemical potentials are not negligible anymore (μ_{ν} ≠ 0). Therefore, our results give just a rough estimation of the electron fraction during collapse, but nevertheless are useful to have an idea of the composition in the collapsing material. In Fig. 1 the trajectory of the collapse is in a region where almost only heavy neutronrich nuclei and neutrons are present (Fig. 5). The amount of alpha particles (Fig. 4) and light nuclei (Fig. 6) is negligible.
When central density gets above the density of nuclear matter, collapse stops and falling matter bounces back leading to the formation of a shock. The way this shock propagates through the outer layers of the star in a supernova explosion is still a problem under discussion (Janka et al. 2007). But it is known that a compact object forms in the center and cools by neutrino emission. Neutrinos start to decouple from matter at the neutrinosphere that is placed in the outer layers of the newly born protoneutron star. In this region we assume still that μ_{ν} ≈ 0. Also NSE is satisfied because the temperatures are high enough, T ≈ 50 × 10^{9} K. We compare our equilibrium electron fraction with the one obtained in hydrodynamical simulations of corecollapse supernovae (Arcones et al. 2007). Figure 8 shows the postbounce evolution of the electron fraction. The dashed line is the result of the hydrodynamical simulation of Arcones et al. (2007) for their standard case (M15l1r1), and solid line is the equilibrium electron fraction computed for same density and temperature evolution as for the dashed line. There is a clear discrepancy between the two electron fractions that increases with time. This disagreement comes from the difference in the composition (see Fig. 4 in Arcones et al. 2008). The equations of state that are generally used in supernova simulations include only nucleons, alpha particles, and a representative heavy nucleus. In our calculation of NSE with beta equilibrium, we take into account all nuclei. Figure 6 shows that the abundances of light elements (A < 4) are not negligible in the outer layers of the protoneutron star. Similar results are found with other EoS, for example Horowitz & Schwenk (2006) and Typel et al. (2010). Light nuclei are formed at expenses of the few free protons. This produces also a reduction of the antineutrino absorption and electron captures, which leads to an increase of the electron fraction compared to the case where only neutrons and protons are present (see Eq. (12)).
Fig. 8
The evolution of the electron fraction at the protoneutron star surface is shown. The solid line is obtained by assuming NSE and thermal weak equilibrium, while the dashed line results from the hydrodynamical simulation of the supernova explosion and the subsequent neutrinodriven wind of Arcones et al. (2007).
Dynamic betaequilibrium electron fraction for density values given in the first row and temperature values in the first column.
These light nuclei have an impact on the properties of neutrinos emitted during the first seconds after bounce (Arcones et al. 2008). Sumiyoshi & Röpke (2008) have also pointed out the influence of the light elements during the postbounce evolution. These calculations were both done in a postprocessing step, therefore the real effect of light elements in the dynamics of the supernova evolution is still an open issue that has to be studied in detail by using an equation of state that includes light nuclei in supernova simulations.
4.3. Type Ia supernovae and accretioninduced collapse
Other astrophysical scenarios where the electron fraction plays an important role involve the evolution of white dwarfs in binary systems. A white dwarf accreting up to the Chandrasekhar limit can have two possible outcomes. If the density and temperature become sufficiently high to ignite explosive nuclear burning, then the white dwarf may become a type Ia supernova. But it could also happen that electron capture in the ash reduces central temperature and pressure, and the white dwarf instead collapses to a neutron star. This latter outcome is known as “accretioninduced collapse”, or AIC (Canal et al. 1990; Woosley & Baron 1992; Fryer et al. 1999). Which outcome occurs depends on the ignition density which is in turn determined by the initial white dwarf properties (mass, composition, and temperature) and on the accretion rate (Canal et al. 1990).
The outcome also depends on the weak interaction rates employed in the study and the multidimensional character of the explosion. Burning raises the temperature at constant pressure and, if Y_{e} is constant, that must reduce the density. The density inversion behind the flame drives a RayleighTaylor instability that greatly enhances the advance of the burning front. However, since the pressure is mostly due to relativistic electrons, a decrease in Y_{e} due to electron capture in the ash means that the postburning density will be larger (since pressure depends on the product ρY_{e}). If Y_{e} decreases sufficiently, the density beneath the flame may even rise, thus suppressing the RayleighTaylor instability (see Sect. 4 in Timmes & Woosley 1992). If Y_{e} decreases in a sufficient fraction of the white dwarf before the (now slowly moving) flame makes its way out to regions where the density is lower and electron capture is reduced, the white dwarf collapses. At densities approaching 10^{10} g cm^{3} electron capture is so efficient that it would drive Y_{e} to very low values were it not for the inhibiting effect of betadecay. Yet there are, so far, no accurate calculations of betadecay rates for Y_{e} below about 0.41. Having a reliable lower bound to Y_{e} at a given density will thus be useful in future simulations.
During this phase of the white dwarf evolution, temperatures are high and densities relatively low. Consequently, the produced neutrinos escape. Under such conditions, the lower limit of the electron fraction is thus obtained from dynamic betaequilibrium, Eq. (13). If thermal weak equilibrium were assumed, electron captures would compete with antineutrino absorptions instead of β^{ − } decay, as expected when neutrinos escape. Figure 9 shows the dynamic betaequilibrium electron fraction for the range of temperatures and densities relevant for AIC and type Ia supernovae. In Table 1 some numerical values of the Y_{e} in the figure are given (a complete table is available on request).
The behaviour of the electron fraction is very different at high and low temperatures (Fig. 9). At low temperatures the electron fraction decreases continuously with density. While a high temperatures (T ≳ 12 GK) first decreases and then increases. This seems unintuitive but it can be understood considering the change in composition. At low densities the composition is neutrons, protons, and alphaparticles. With increasing density heavy nuclei are present and their β^{ − } decay produces an increase of Y_{e}. At even higher densities, electron capture dominates and Y_{e} decreases again.
Fig. 9
The dynamic betaequilibrium electron fraction (Eq. (13)) is shown for the range of temperatures and densities relevant in type Ia supernovae and AICs. In Table 1 numerical values of the equilibrium electron fraction are given.
Finally, we notice that the electron fraction and thus weakinteraction rates are important for determining the composition of the ejecta in typical type Ia supernova. In these events the electron captures are very important during the flame propagation because they lead to a reduction of the electron fraction which is the parameter that controls the isotopic composition of the ejecta.
5. Conclusions
Weakinteraction rates determine the evolution of the electron fraction, which is a key parameter affecting the composition and dynamics of stars in the late stages of stellar evolution and supernovae. Here we have presented an interesting limiting case that can be used to test the implementation of theoretical weakinteraction rates in stellar evolution simulations and to place lower bounds on the Y_{e} in the explosion of white dwarfs. Our results depend only on chemical potentials and therefore are independent of the weakinteraction rates.
These equilibrium electron fractions can be compared to those found in presupernova models, where weakinteraction rates play an important role (Heger et al. 2001a). The presupernova phase precedes the collapse of massive stars, therefore temperatures get high enough that NSE is reached, but the dynamical evolution is too fast in most cases for beta equilibrium to be achieved. We find a lower limit for electron fraction and show that the Y_{e} in the old presupernova models of Woosley & Weaver (1995) drops below it. In these presupernova models beta decay rates of Hansen (1968); )Mazurek et al. (1974) were used. These rates are too low compared to FFN and LMP. Similar models calculated using more recent weak rates (Heger et al. 2001b) lead to an electron fraction that stays always above or equal to our lower limit. Moreover, for the 15 M_{⊙} model where the rates predict dynamic betaequilibrium, we find that their electron fraction agrees with the equilibrium value of our calculations.
The accretion onto white dwarfs approaching the Chandrasekhar mass could lead to type Ia supernovae or to AIC. The final outcome depends on the competition between explosive ignition and electron captures (Canal et al. 1990). Therefore, the electron fraction is a key parameter. In this environment densities and temperatures drive the NSE composition towards neutronrich nuclei whose weakinteraction rates are not yet known from theoretical models. Here we give a reliable lower limit for Y_{e}, that can be used in simulations (data are available on request).
In addition, our calculations show that the amount of light elements (A < 4) in the outer layer of the protoneutron star is not negligible. After supernova explosion a hot protoneutron star is born and cools emitting neutrinos. The surface of the protoneutron star, where neutrinos decouple from matter, is hot enough to assume NSE and its evolution is rather slow, thus beta equilibrium is also satisfied. Changes in the composition of this region have an impact on neutrino properties that could affect the nucleosynthesis (Arcones et al. 2008) and the explosion (Sumiyoshi & Röpke 2008).
Acknowledgments
We thank A. Marek and F. Röpke for providing the collapse and type Ia supernova trajectories, and H.Th. Janka, K. Langanke, I. Seitenzahl for valuable discussions. The work of A. Arcones and G. MartínezPinedo was supported by the Deutsche Forschungsgemeinschaft through contract SFB 634 and by the ExtreMe Matter Institute EMMI. S. E. Woosley was supported by the US NSF (AST0909129), the University of California Office of the President (09IR07117968WOOS), and the DOE SciDAC Program (DEFC0206ER41438). L. Roberts was supported by an NNSA/DOE Stewardship Science Graduate Fellowship (DEFC5208NA28752) and the University of California Office of the President (09IR07117968WOOS).
