Search for light curve modulations among Kepler candidates
Three very lowmass transiting companions
^{1} European Southern Observatory (ESO), Alonso de Córdova 3107, Vitacura, Casilla 19001, Santiago de Chile, Chile
email: jlillobox@eso.org
^{2} Department of Astronomy, Boston University, 725 Commonwealth Avenue, Boston, MA 02215, USA
^{3} Depto. de Astrofísica, Centro de Astrobiología (CSICINTA), ESAC campus, 28692 Villanueva de la Cañada, Madrid, Spain
^{4} European Space Astronomy Centre (ESA), 28691 Villanueva de la Cañada, Spain
Received: 18 December 2015
Accepted: 18 May 2016
Context. Light curve modulations in the sample of Kepler planet candidates allows the disentangling of the nature of the transiting object by photometrically measuring its mass. This is possible by detecting the effects of the gravitational pull of the companion (ellipsoidal modulations) and in some cases, the photometric imprints of the Doppler effect when observing in a broad band (Doppler beaming).
Aims. We aim to photometrically unveil the nature of some transiting objects showing clear light curve modulations in the phasefolded Kepler light curve.
Methods. We selected a subsample among the large crop of Kepler objects of interest (KOIs) based on their chances to show detectable light curve modulations, i.e., close (a< 12 R_{⋆}) and large (in terms of radius, according to their transit signal) candidates. We modeled their phasefolded light curves with consistent equations for the three effects, namely, reflection, ellipsoidal and beaming (known as REB modulations).
Results. We provide detailed general equations for the fit of the REB modulations for the case of eccentric orbits. These equations are accurate to the photometric precisions achievable by current and forthcoming instruments and space missions. By using this mathematical apparatus, we find three closein very lowmass companions (two of them in the brown dwarf mass domain) orbiting mainsequence stars (KOI554, KOI1074, and KOI3728), and reject the planetary nature of the transiting objects (thus classifying them as false positives). In contrast, the detection of the REB modulations and transit/eclipse signal allows the measurement of their mass and radius that can provide important constraints for modeling their interiors since just a few cases of lowmass eclipsing binaries are known. Additionally, these new systems can help to constrain the similarities in the formation process of the more massive and closein planets (hot Jupiters), brown dwarfs, and very lowmass companions.
Key words: brown dwarfs / binaries: eclipsing / stars: lowmass / techniques: photometric / binaries (including multiple): close
© ESO, 2016
1. Introduction
In the last two decades, the populations of Jupiterlike planets in closein orbits around their host stars have been continuously growing. Although the most frequently used detection techniques (i.e., transits and radial velocity) are more efficient for this type of planets, the process by which these hot Jupiters have reached these close orbits is still puzzling. The two competing planet formation mechanisms (i.e., core accretion and gravitational instability) allow the growth of these bodies at large radii (namely ~5–20 AU for core accretion and >50 AU for the gravitational instability model). After the detection of gas giants at orbital separations below 0.5 AU, it was necessary to develop a planet migration theory allowing an inward migration of these planets to closer orbits (see Chambers 2009, and references therein). The detection of massive planets and substellar objects in closein orbits around their hosts can provide hints about the actual formation mechanism or at least the necessary conditions in which each of the two mechanisms play a role.
The low number of wellcharacterized brown dwarfs (with known radius and mass) prevents a contrast between theory and observations. Different theoretical studies suggest that these substellar objects present large radii during the first stages of their formation while they are contracting. Later on, they can have Jupiterlike radii (or even smaller). However, in a few cases it was possible to directly quantify the radius of these objects. Stassun et al. (2006) characterized the radius of a young brown dwarf pair in the Orion Nebula cluster for the first time, confirming a large radius for this object in a Myr old star forming region (Hillenbrand 1997; Palla & Stahler 1999). Apart from this, to our knowledge, just a few more brown dwarfs have been characterized by deriving accurate radius. Hence, measuring masses and radii of these substellar objects may help to constrain theoretical models. Additionally, their formation could be similar to that of hot Jupiters and so discovering closein brown dwarfs in binary systems can help to constrain this scenario.
In this context, the Kepler mission has provided an unprecedented photometric precision, delivering long baseline light curves (LC) for more than 150 000 stars with typical precisions of a few tens of parts per million (ppm) (Borucki et al. 2010; Batalha et al. 2013; Burke et al. 2014). This impressive precision has mainly been used to detect planetary transits and eclipses where the radius of the transiting companions can be measured.
Additionally, modulations in the outoftransit region have been detected in several systems. These ellipsoidal variations are caused by tidal effects and are used to photometrically measure the mass of transiting objects and to confirm (or reject) their planetary nature (see, e.g., the confirmation of Kepler91b by LilloBox et al. 2014a). Ellipsoidal variation is one of the three major effects detectable in the outoftransit time interval of the LC, together with the reflection and thermal emission of the planet and the photometric signature of the induced radial velocity, known as Doppler beaming. These three effects (collectively called REBs) modulate the LC of the star according to the position of the companion along its orbit. In particular, the modulations produced by ellipsoidal variations are characterized by a double bump in the outoftransit time interval of the LC. Interestingly, the amplitude of these variations depends strongly on the mass of the companion object and the distance from the host star in units of stellar radii (i.e., a/R_{⋆}). The more massive and the closer the orbit is, the larger the amplitude of this effect is.
Detecting the transit/eclipse of a companion object and the tidal modulations induced by its closeness to the stellar host allows the simultaneous measurement of its mass and radius. Also, the companion has to be closein to have any significant effect in the LC. By using Kepler data from the prime mission, we have looked for LC modulations in the sample of Kepler objects of interest (KOIs) with close transiting companions.
It is also important to note that planets around hot stars (i.e., O to Ftype host stars) are difficult to detect owing to the small number of spectral lines, usually very broad, in their spectra (given their high effective temperatures and rapid rotation of several tens of kilometers per second). Instead, the REB modulations are detectable provided that the companion is close enough and/or massive enough. Therefore, their detection can serve to populate the more massive regime of planet hosts.
In this paper we present the confirmation of three very lowmass companions (two within the brown dwarf mass regime) to mainsequence stars in the sample of Kepler planet candidates. In Sect. 2, we describe the sample selection, the Kepler data, and the processed light curves. In Sect. 3, we present the general equations for fitting the light curve modulations, including eccentric orbits, and the different implications of the different harmonics. The results are shown in Sect. 4, and the implications of these discoveries are discussed in Sect. 5.
2. Sample selection and observations
2.1. Sample selection
REB signatures are stronger for massive closein objects. Considering the nominal Kepler sensitivity limit of 10 ppm (Borucki et al. 2010), very lowmass objects cannot create detectable REB signals if a/R_{⋆}> 12. We therefore restrict our sample to those KOIs with a/R_{⋆} ≤ 12, as determined by the public Kepler catalogues (Batalha et al. 2013; Burke et al. 2014). This yielded a sample of 914 planet candidates.
2.2. Postprocessing of Kepler data
Raw Kepler light curves suffer from strong systematics produced by a combination of effects from the spacecraft, detector, and environment. Therefore, they need to be treated prior to any analysis. The Kepler archive provides calibrated light curves that are corrected via cotrending and detrending vectors computed with different data from the spacecraft. These curves are extremely useful when searching for planetary transits, but could alter (or even destroy) other kinds of astrophysical signals. For this reason, we chose to process the lightcurves of the 914 KOIs with a methodology aimed at preserving REB signatures. The processing was as follows:

1.
For each KOI, we downloaded the available longcadence lightcurves via the kplr python interface.

2.
For each individual light curve, we masked the corresponding transits to avoid fitting them, using data from the Kepler catalogue (e.g., period, ephemeris).

3.
We also masked out the transits of other detected KOIs in the system.

4.
The resulting curve was then fit via a cubic spline. The nodes for the fit were chosen by splitting the masked curve in periods. The phase and flux for each node were then computed as the median values in time and flux, respectively, of the unmasked data within the corresponding bin. By placing nodes with a frequency similar to the planet transit, we make sure that we are neither fitting nor introducing any signal with such a period or smaller. This procedure is standard and has been used in many other works (e.g., Angerhausen et al. 2015).

5.
The obtained spline was used to normalize the corresponding longcadence light curve, including transits.

6.
Once every individual light curve was processed, we phased and combined them to create the final curve using the period provided in the Kepler catalogue.
After this process, we binned the folded light curves using 500 points across the phase for visual inspection. We first checked that the obtained light curves were consistent with those of previously studied objects in the literature. In particular, we note that features such as secondary transits or planet reflections are preserved in our processed light curves.
2.3. Visual inspection of Kepler light curves
We proceeded to visually inspect each phasefolded light curve, searching for trends resembling REB signatures caused by exoplanets or brown dwarfs. Given the large number of factors that could affect the shape of the final curves, we chose to select only those KOIs with a clear signature (i.e., clearly detectable by eye). The analysis of weak, tentative signals requires much more analysis and is outside of the scope of this paper. Among the several promising candidates, we selected those with no signs of binarity in highspatial resolution imaging (see Sect. 2.4): KOI554.01, KOI1074.01, and KOI3728.01. The remaining possible targets will be modeled in the future when additional data allows a proper estimate of their stellar parameters. We note that we can reproduce the REBs found in the light curve of already confirmed planets by this methodology such as Kepler91 b (LilloBox et al. 2014a,c) or KOI13.01 (Mazeh et al. 2012).
2.4. High spatial resolution images: contaminants in the Kepler apertures
Owing to the large pixel size of the Kepler chargecouple device (CCD) and the large apertures used by the Kepler team to extract the precise photometry (6–10 arcsec), possible close sources can contaminate the light curves of the preselected objects. Several teams have performed groundbased followup of the planet candidates by obtaining highspatial resolution images of the host stars to detect these possible contaminants and be able to correct the light curves. Several techniques have been applied such as adaptive optics in the nearinfrared (e.g., Adams et al. 2012, 2013), adaptive optics in the optical range (e.g., Law et al. 2014), speckle imaging in the optical (e.g., Howell et al. 2011), or luckyimaging in the optical (e.g., LilloBox et al. 2012, 2014b). In the last work, we performed a comparison between the different surveys and techniques by means of the newly defined blended source confidence (BSC) parameter. This parameter provides the probability that a given source detected as being isolated in the highspatial resolution image has no undetected companions within a certain magnitude range and angular separation^{1}.
Luckyimaging observations of KOI3728 with AstraLux (Calar Alto Observatory) were analyzed in LilloBox et al. (2014b). For KOI554 and KOI1074, high spatial resolution images were retrieved from the Community Followup Observing Program^{2} (CFOP) of the Kepler mission and were obtained and analyzed by David Ciardi. We only found a companions closer than 6 arcsec in the case of KOI554. However, by overlaying the Kepler apertures on the highresolution image, we can see that this companion is always out of the apertures used in Q1Q17, so that it does not affect the photometry of the prime target. In Table 1 we show the analysis results of the high spatial resolution images. In the case of KOI3728, observed by our team with the AstraLux instrument, we obtain a BSC = 99.6%. According to these observations we can assume hereafter that the KOIs are isolated.
Ancillary data and calculated blended source confidence values for the three KOIs studied in this paper.
3. Light curve modeling
We model the full light curves, which are composed of the contribution from the transit/eclipse and the outoftransit modulations induced by massive companions. Here, we describe the adopted procedure.
3.1. Eclipse signal
The eclipses were modeled by using the Mandel & Agol (2002) prescriptions. We assumed the stellar properties (T_{eff}, log g, and [Fe/H]) – publicly available on the CFOP of the Kepler mission and published in Huber et al. (2014) – to determine the limb darkening and gravity darkening coefficients (see Table 2). These coefficients were obtained by trilinearly interpolating the Claret & Bloemen (2011) tabulated values on the estimated stellar properties. We performed a bootstrapping on the stellar properties and their corresponding uncertainties to measure their impact on the limb darkening coefficients. The resulting relative errors of these parameters are around 2–5%, which is much smaller than the inferred uncertainties of the parameters. This given, the transit/eclipse model depends on six free parameters: planettostar radius (R_{p}), orbital eccentricity (e), argument of the periastron (ω), semimajor axis (a), stellar radius (R_{⋆}), and orbital inclination from the plane of the sky perpendicular to our line of sight (i).
3.2. Light curve modulations
In this section we present a complete set of the equations used to model these photometric effects for any type of orbital configuration (including eccentric orbits).
Planet reflection and emission. The reflected light by the companion is described by the inverse ratio of the orbital distance and its radius (R_{p}/d), the ratio between the incident and reflected light (also known as the albedo, A_{g}), and the phase function of the companion generally expressed as Φ(z). The last function is formulated in two main recipes, called the Lambertian reflection phase function, Φ_{Lam}(z), and the geometric phase function, Φ_{geo}(z). As demonstrated by Faigler & Mazeh (2011), Φ_{Lam}(z) = Φ_{geo}(z) + 0.18sin^{2}i cos(2θ) + C, where the term C encompasses other constant and negligible terms. Determining which of the two phase functions is more correct is not possible with just the Kepler data. By assuming one or the other, we can introduce a doublepeak signal that can increase the ellipsoidal amplitude by up to 18%, artificially increasing or decreasing the mass of the companion if we assume the incorrect phase function. Regardless of the assumed phase function, the expression for the reflected light of the companion is given by (1)Throughout this work we assume the Lambert approach to ensure that the obtained masses are the highest of the two possibilities.
Ellipsoidal variations.The ellipsoidal variations are produced by the gravitational pull of the close companion on the host star. This effect was theoretically investigated by Pfahl et al. (2008), who determined the flux variations due to stellar oscillations induced by close substellar companions. Based on this theoretical analysis, the ellipsoidal modulations can be expressed as a sum of different harmonics. In particular, l = 2 and l = 3 are the only relevant values in this work. Indeed, the third harmonic (l = 3) has only been detected in the wellknown case of KOI13.01 (Mazeh et al. 2012; Esteves et al. 2013). Higher order harmonics (l ≥ 4) induce amplitudes more than one order of magnitude smaller than l = 2 for a/R_{⋆} ≳ 3. Only for extremely closein companions (a/R_{⋆} ≲ 2) will higher harmonics play a relevant role for the current and forthcoming achievable photometric precisions. Then, we can neglect harmonics with l ≥ 4, and so the relative flux variations caused by a companion of mass M_{p} at an orbital separation of d/R_{⋆} in an orbit with an inclination i around a star of mass M_{⋆} is given by (2)
where the f_{1} and f_{2} coefficients are defined in Pfahl et al. (2008). These coefficients can be written in terms of the linear limbdarkening and gravity darkening coefficients. From Eqs. (9)–(13) in Esteves et al. (2013) we can identify that f_{2} = 4α_{2}/ 3 and f_{3} = 8α_{1}α_{2}, being (3)In cases where the third harmonic is also negligible (e.g., for highly inclined orbits or large orbital separations), the relative variations can be rewritten as (4)We note that the orbital separation between the two objects is given by d/R_{⋆} = a/R_{⋆}(1−e^{2})/(1 + esinω). Thus, in the particular case of nearcircular orbits where d ≈ a = constant, the second term of the righthand side of this equation is constant and can then be neglected. This yields the commonly used equation for this type of modulations with the cos2θ dependency that provides the characteristic doublepeak in the phasefolded light curve (5)In this work, we have used the more complete Eq. (2) in our modeling since the same number of free parameters is needed and always accounts for the two relevant harmonics.
Doppler beaming. The Doppler beaming is the photometric imprint of the radial velocity when we obtain precise photometry at a particular (fixed) bandpass. Loeb & Gaudi (2003) and more recently Bloemen et al. (2011) have provided a theoretical expression for this effect, being (6)where K is the radial velocity semiamplitude, c is the speed of light, and B is the beaming factor defined as B = 5 + dLnF_{λ}/ dLnλ, where F_{λ} is the stellar flux. In the case of the Kepler observations, this factor can be computed as (7)where ϵ_{λ} is the response function of the Kepler bandpass^{3}. The stellar flux F_{λ} is obtained from the nextgen models (Hauschildt et al. 1999) according to the physical parameters of the star shown in Table 3.
4. Results
We used a Bayesian approach to derive robust uncertainties for the parameters in our models. For this purpose, we used the emcee implementation (ForemanMackey et al. 2013) of the affineinvariant ensemble sampler for Markov chain Monte Carlo (MCMC; Goodman & Weare 2010).
We then modeled the processed light curves by adding the REB signals to the transits (computed using PyTransit; Parviainen 2015) in the phased curves. Our model contains ten free parameters: mass and radius of the planet (M_{p}, R_{p}), mass and radius of the star (M_{s}, R_{s}), semimajor axis (a), orbital inclination (i), eccentricity (e), argument of the periastron (ω), the beaming factor (B), the albedo, and a scaling factor. This last parameter accounts for the fact that the outoftransit flux is not constant for light curves with REB signals and depends on different factors (shape of REB signal, processing of light curves, etc.). For some of these parameters, we have previous information from the CFOP or they were previously calculated by using the CFOP stellar parameters (from Huber et al. 2014) such as the beaming factor. The used mean values and uncertainties are shown in Table 3. These values are included with Gaussian priors, which are listed in Table 4.
Priors used in the model fit of the REB modulations and transit, together with the results of the fit for each of the three characterized companions.
With this setup, we ran 20 000 iterations with emcee using 50 walkers. We discarded the first 15 000 iterations to ensure that convergence had been reached in all cases, which was confirmed via visual inspection of the chain evolution. The remaining chain positions trace the posterior distributions, and can be used to estimate different confidence intervals for each parameter. The resulting median value and the 15.9–84.1% confidence intervals (corresponding to 1σ in Gaussian distributions) for each target are listed in Table 4. We find three of the KOIs studied to be lowmass eclipsing binaries, two of which are compatible with being brown dwarfs within 1σ uncertainties^{4}.
In the case of KOI1074.01, the large albedo indicates an intrinsic luminosity of the companion. However, since no secondary eclipse is found, the contamination introduced by this companion is already taken into account in the scaling factor. This is clear when comparing the weighted goodness of fit (Bayesian information criterion, BIC) of the two models: the one presented above and a second model including a dilution factor to account for the brightness of the secondary star and restricting the albedo to be A_{B}< 1. The result shows a difference in the BIC value of 12 in favor of the former (simpler) model. This is expected since we do not have a significant detection of the secondary. Additionally, since the detection of the REB modulations is less clear in this system, we tested the hypothesis of nondetection by just fitting the transit signal. In this case, we find a difference in the BIC value of ΔBIC = 63 in favor of the complex model (including REBs), showing significant evidence against the nondetection hypothesis.
Fig. 1 Fitting results for the three KOIs analyzed in this work. For each object, the top panel shows a close view of the outofeclipse time interval where the light curve modulations are detectable. The middle panel shows the complex light curve including the eclipse and an inset showing each contribution to the outofeclipse modulations. In the bottom panel, we show the residuals of the fit. Gray circles represent 500 bins along the orbit and red circles represent binnings of 100 datapoints. The best one hundred models are shown with black lines and the best model is shown with a blue line.

Open with DEXTER
Fig. 2 Asymmetric posterior distribution in the analysis of the light curve modulations of KOI554.01 obtained from an MCMC analysis with 20 000 steps with 50 walkers (see Sect. 4). Only the last 5000 steps are used to compute the final parameters and to build these posterior distributions. The vertical solid line represents the median value of the distribution, while the dashed lines show the 16.7 and 83.4 percentiles of the distribution.

Open with DEXTER
Fig. 3 Asymmetric posterior distribution in the analysis of the light curve modulations of KOI1074.01 obtained from an MCMC analysis with 20 000 steps with 50 walkers (see Sect. 4). Only the last 5000 steps are used to compute the final parameters and to build these posterior distributions. The vertical solid line represents the median value of the distribution, while the dashed lines show the 16.7 and 83.4 percentiles of the distribution.

Open with DEXTER
Fig. 4 Asymmetric posterior distribution in the analysis of the light curve modulations of KOI3728.01 obtained from an MCMC analysis with 20 000 steps with 50 walkers (see Sect. 4). Only the last 5000 steps are used to compute the final parameters and to build these posterior distributions. The vertical solid line represents the median value of the distribution, while the dashed lines show the 16.7 and 83.4 percentiles of the distribution.

Open with DEXTER
5. Discussion and conclusions
In this paper we have presented detailed general equations to model the light curve modulations produced by closeby companions. By making use of the Kepler data, we have analyzed three cases where very lowmass companions were found in the sample of planet candidates: KOI554.01, KOI1074.01, and KOI3728.01. These candidates are thus false positive planets and should be catalogued as binary systems.
Since they are also transiting, we can measure their basic parameters, namely their mass and their radius. This has been possible for a few very lowmass objects (e.g., Huélamo et al. 2009; Shkolnik et al. 2008; Díaz et al. 2014; LilloBox et al. 2015) so these detections increase the sample. This is important in order to understand the properties of these sources since they allow a direct measurement of their density and surface gravity. In Fig. 5, we show the location of the three characterized very lowmass companions together with the known sample of lowmass eclipsing binaries and the more massive confirmed planets from the literature. The three systems studied here (together with a few others) fill a void region in the diagram, part of the socalled browndwarf desert. The derived properties of these lowmass companions can feed formation theories and interior models (Baraffe 2014) of objects of this type, since very few of them are known.
In the particular case of KOI3728, in LilloBox et al. (2015) we provided a radial velocity based upper limit to the mass of the transiting object of M_{2} ≲ 116 M_{Jup}. Here, we found a mass of M_{2} = 83 ± 13 M_{Jup}, in good agreement with this upper limit. This object orbits a massive star (M_{⋆} = 2.05 ± 0.17 M_{⊙}) in the subgiant phase. It shows a larger radius than expected for the age of the system, which may indicate some inflation. This system is thus in a key step of the evolutionary process when several processes take place (dynamical instabilities, tidal forces, etc.) and can affect the orbital and physical structure of the components of the system. It has been theorized that the inflation of lowmass shortperiod binaries (discussed in Ribas 2006) is produced by the inhibition of convection due to magnetic fields (e.g., David et al. 2016), which could be reinforced by the tidal forces induced during the subgiant phase. Although this is just one possibility, this system can be a test case for these theories.
Additionally, by constraining the detection of the secondary eclipses (considering them as upper limits to their depths) and comparing their depth with that of the primary transit, we can obtain the ratio of temperatures between the two objects. So, from Table 3 we can infer an upper limit for the effective temperature of the companion since δ_{1}/δ_{2} = (T_{A}/T_{B})^{4}, where A is the primary star and B is the companion, and δ_{1} and δ_{2} represent the depth of the primary and secondary eclipses, respectively. By doing so, we obtained T_{554.01}< 2500 K, T_{1074.01}< 1500 K, and T_{3728.01}< 2100 K, indicating that the companions are ultracool dwarf companions.
Fig. 5 Massradius relationship for the three detected binaries in the Kepler sample, namely KOI554 (blue), KOI1074 (green), and KOI3728 (red). Primary stars are represented by squares, while the close companions are represented by circles. Other lowmass eclipsing binaries from the literature are also plotted with black plus symbols (Huélamo et al. 2009; Shkolnik et al. 2008; Díaz et al. 2014; LilloBox et al. 2015). Massive planets from the Exoplanet Catalogue (exoplanet.eu) are plotted as black crosses. Leftward arrows show the upper limits to the masses of the three fast rotators in LilloBox et al. (2015). Solar metallicity isochrones of Baraffe et al. (1998) are also plotted for reference as gray thick lines. From top to bottom: 50 Myr, 100 Myr, 500 Myr, 1 Gyr, and 5 Gyr.

Open with DEXTER
We have also provided comprehensive and general equations for light curve modulation analysis. Given the highprecision photometric missions that will be launched in the near future (e.g., Cheops, TESS, and PLATO), the analysis of light curve modulations can provide important results by unveiling the nature of transiting companions. Also, since there is no need for the companion to transit, new planets and lowmass companions can be detected from these surveys. Even though different works have published the equations of the different components of the REB modulations (e.g., Faigler et al. 2012; Faigler & Mazeh 2015; Esteves et al. 2015; Mazeh et al. 2012), there is still a discrepancy with the masses measured by radial velocity technique. Understanding these differences is crucial in order to correctly characterize the new detections without the need for a subsequent radial velocity followup. Hence more detections are needed to this end. In this work we present three new detections that will help in this task.
The calculation of the BSC will be made available in python and IDLbased codes, as defined in LilloBox et al. (2014b).
Indeed, KOI554.01 was classified as a brown dwarf by Santerne et al. (2012), but no determination of its mass is found in the literature to our knowledge.
Acknowledgments
J.L.B. acknowledges financial support from the Marie Curie Actions of the European Commission (FP7COFUND) and the Spanish grant AYA2012 38897C0201. We appreciate the extraordinary effort and generosity by all the people involved in the Kepler mission at some point, those running the observatory and those providing an amazing database with more than a hundred thousand light curves and thousands of planetary candidates, so the community can work on them, and can confirm and characterize the largest and most comprehensive planetary sample found so far, as well as other interesting astronomical systems. This work used the python packages numpy, matplotlib, astroML, asciitable, pyTransit, kplr, and emcee.
References
 Adams, E. R., Ciardi, D. R., Dupree, A. K., et al. 2012, AJ, 144, 42 [NASA ADS] [CrossRef] [Google Scholar]
 Adams, E. R., Dupree, A. K., Kulesa, C., & McCarthy, D. 2013, AJ, 146, 9 [NASA ADS] [CrossRef] [Google Scholar]
 Angerhausen, D., DeLarme, E., & Morse, J. A. 2015, PASP, 127, 1113 [NASA ADS] [CrossRef] [Google Scholar]
 Baraffe, I. 2014, in 50 Years of Brown Dwarfs, ed. V. Joergens, Astrophys. Space Sci. Lib., 401, 141 [Google Scholar]
 Baraffe, I., Chabrier, G., Allard, F., & Hauschildt, P. H. 1998, A&A, 337, 403 [NASA ADS] [Google Scholar]
 Batalha, N. M., Rowe, J. F., Bryson, S. T., et al. 2013, ApJS, 204, 24 [NASA ADS] [CrossRef] [Google Scholar]
 Bloemen, S., Marsh, T. R., Østensen, R. H., et al. 2011, MNRAS, 410, 1787 [NASA ADS] [Google Scholar]
 Borucki, W. J., Koch, D., Basri, G., et al. 2010, Science, 327, 977 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
 Burke, C. J., Bryson, S. T., Mullally, F., et al. 2014, ApJS, 210, 19 [NASA ADS] [CrossRef] [Google Scholar]
 Chambers, J. E. 2009, Ann. Rev. Earth Planet. Sci., 37, 321 [NASA ADS] [CrossRef] [Google Scholar]
 Claret, A., & Bloemen, S. 2011, A&A, 529, A75 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 David, T. J., Hillenbrand, L. A., Cody, A. M., Carpenter, J. M., & Howard, A. W. 2016, ApJ, 816, 21 [NASA ADS] [CrossRef] [Google Scholar]
 Díaz, R. F., Montagnier, G., Leconte, J., et al. 2014, A&A, 572, A109 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Esteves, L. J., De Mooij, E. J. W., & Jayawardhana, R. 2013, ApJ, 772, 51 [NASA ADS] [CrossRef] [Google Scholar]
 Esteves, L. J., De Mooij, E. J. W., & Jayawardhana, R. 2015, ApJ, 804, 150 [NASA ADS] [CrossRef] [Google Scholar]
 Faigler, S., & Mazeh, T. 2011, MNRAS, 415, 3921 [NASA ADS] [CrossRef] [Google Scholar]
 Faigler, S., & Mazeh, T. 2015, ApJ, 800, 73 [NASA ADS] [CrossRef] [Google Scholar]
 Faigler, S., Mazeh, T., Quinn, S. N., Latham, D. W., & TalOr, L. 2012, ApJ, 746, 185 [NASA ADS] [CrossRef] [Google Scholar]
 ForemanMackey, D., Hogg, D. W., Lang, D., & Goodman, J. 2013, PASP, 125, 306 [NASA ADS] [CrossRef] [Google Scholar]
 Goodman, J., & Weare, J. 2010, Comm. App. Math. Comp. Sci., 5, 65 [CrossRef] [MathSciNet] [Google Scholar]
 Hauschildt, P. H., Allard, F., & Baron, E. 1999, ApJ, 512, 377 [NASA ADS] [CrossRef] [Google Scholar]
 Hillenbrand, L. A. 1997, AJ, 113, 1733 [NASA ADS] [CrossRef] [Google Scholar]
 Howell, S. B., Everett, M. E., Sherry, W., Horch, E., & Ciardi, D. R. 2011, AJ, 142, 19 [NASA ADS] [CrossRef] [Google Scholar]
 Huber, D., Silva Aguirre, V., Matthews, J. M., et al. 2014, ApJS, 211, 2 [NASA ADS] [CrossRef] [Google Scholar]
 Huélamo, N., Vaz, L. P. R., Torres, C. A. O., et al. 2009, A&A, 503, 873 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Law, N. M., Morton, T., Baranec, C., et al. 2014, ApJ, 791, 35 [NASA ADS] [CrossRef] [Google Scholar]
 LilloBox, J., Barrado, D., & Bouy, H. 2012, A&A, 546, A10 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 LilloBox, J., Barrado, D., Moya, A., et al. 2014a, A&A, 562, A109 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 LilloBox, J., Barrado, D., & Bouy, H. 2014b, A&A, 566, A103 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 LilloBox, J., Barrado, D., Henning, T., et al. 2014c, A&A, 568, L1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 LilloBox, J., Barrado, D., Mancini, L., et al. 2015, A&A, 576, A88 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Loeb, A., & Gaudi, B. S. 2003, ApJ, 588, L117 [NASA ADS] [CrossRef] [Google Scholar]
 Mandel, K., & Agol, E. 2002, ApJ, 580, L171 [NASA ADS] [CrossRef] [Google Scholar]
 Mazeh, T., Nachmani, G., Sokol, G., Faigler, S., & Zucker, S. 2012, A&A, 541, A56 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Palla, F., & Stahler, S. W. 1999, ApJ, 525, 772 [NASA ADS] [CrossRef] [Google Scholar]
 Parviainen, H. 2015, MNRAS, 450, 3233 [NASA ADS] [CrossRef] [Google Scholar]
 Pfahl, E., Arras, P., & Paxton, B. 2008, ApJ, 679, 783 [NASA ADS] [CrossRef] [Google Scholar]
 Ribas, I. 2006, Ap&SS, 304, 89 [NASA ADS] [CrossRef] [Google Scholar]
 Santerne, A., Díaz, R. F., Moutou, C., et al. 2012, A&A, 545, A76 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Shkolnik, E., Liu, M. C., Reid, I. N., et al. 2008, ApJ, 682, 1248 [NASA ADS] [CrossRef] [Google Scholar]
 Stassun, K. G., Mathieu, R. D., & Valenti, J. A. 2006, Nature, 440, 311 [NASA ADS] [CrossRef] [PubMed] [Google Scholar]
