1. Introduction

Superluminous supernovae (SLSNe) are a newly discovered class of supernovae (SNe; see Gal-Yam 2012 for a review), and their origin is still a mystery. In particular, the origin of Type Ic SLSNe that do not show hydrogen features in the early phases (e.g., Quimby et al. 2011) has been actively discussed. Several scenarios for making Type Ic SLSNe bright have been proposed, such as magnetar spin-down (e.g., Kasen & Bildsten 2010; Dessart et al. 2012; Inserra et al. 2013; Chen et al. 2015; Metzger et al. 2015), large production of 56Ni (e.g., Gal-Yam et al. 2009; Moriya et al. 2010; Kasen et al. 2011; Dessart et al. 2013; Kozyreva et al. 2014; Whalen et al. 2014), and the interaction of SN ejecta with hydrogen-free dense circumstellar media (e.g., Chevalier & Irwin 2011; Moriya & Maeda 2012; Ginzburg & Balberg 2012; Chatzopoulos & Wheeler 2012a; Baklanov et al. 2015; Sorokina et al. 2015). Revealing the progenitors and the power source of Type Ic SLSNe is essential for better understanding massive star evolution (Langer 2012), as well as for possibly using Type Ic SLSNe as a standardizable candle (Quimby et al. 2013; Inserra & Smartt 2014).

Type Ic SLSNe were thought to be hydrogen-free; however, Yan et al. (2015, Y15 hereafter) have recently reported detecting nebular Hα emission at about 250 days after the r-band light-curve (LC) peak in the slowly declining Type Ic SLSN iPTF13ehe. The LC evolution and spectral properties of iPTF13ehe are similar to those of SN 2007bi (e.g., Gal-Yam et al. 2009), which is suggested to be a pair-instability SN (e.g., Heger & Woosley 2002). Y15 estimate that about 10% of Type Ic SLSNe may have nebular Hα emission as observed in iPTF13ehe.

Y15 suggest that the nebular Hα emission in iPTF13ehe results from the interaction between the SN ejecta and a hydrogen-rich circumstellar shell. If the shell is located far from the progenitor, it takes time for the SN ejecta to reach the hydrogen-rich shell. Thus, the Hα emission is observed in late phases. They propose that the hydrogen-rich shell is formed by the pulsational pair instability (e.g., Woosley et al. 2007) of the progenitor and that the subsequent explosion may have resulted in iPTF13ehe. The confinement of stellar wind by external photoionization may also result in the formation of a massive circumstellar shell (Mackey et al. 2014). Wang et al. (2015) invoke the necessity to simultaneously consider three suggested luminosity sources in iPTF13ehe, i.e., 56Ni, magnetars, and interaction.

In this Letter, we present an alternative interpretation for the nebular Hα emission. We suggest that the hydrogen observed in iPTF13ehe originates in the matter stripped from the companion star contaminating the inner low-velocity layers of the SN ejecta. The photosphere is in the outer high-velocity layers soon after explosion, and we do not observe emission from the inner layers in the early phase. In the nebular phase when the inner layers are transparent, emission from the contaminated inner layers becomes observable. It has been argued that nebular Hα emission from the stripped matter should be detectable in Type Ia SNe that originate in single-degenerate progenitor systems, although this has not yet been observed (Mattila et al. 2005; Leonard 2007; Shappee et al. 2013; Lundqvist et al. 2013, 2015; Maeda et al. 2014). The stripped mass in Type Ia SNe is estimated to be less than ~10-3 M. We apply the same idea to the case of iPTF13ehe and argue that iPTF13ehe may be the first SN for which the emission of stripped matter from a companion star is detected.

2. Stripped mass from the companion

In this section, we estimate the mass that is required to be stripped from the companion star during the collision in order to explain the hydrogen emission observed in iPTF13ehe.

2.1. Scaling relation

Mattila et al. (2005) performed nebular spectral modeling of Type Ia SNe assuming that the inner layers of the ejecta of the W7 model (Nomoto et al. 1984) are contaminated by solar-metallicity matter stripped from the companion.They predict that the nebular Hα luminosity from the stripped matter is ≃ 5 × 1036 erg s-1 at 380 days after the explosion for a stripped mass of Mst = 0.05 M. We scale this result to estimate the stripped mass in iPTF13ehe.

We assume that the Hα emission is mainly due to the non-thermal excitation of hydrogen caused by γ-rays from the nuclear decay of 56Co → 56Fe in the nebular phase (e.g., Mattila et al. 2005). The inner layers of the W7 model at 380 days are optically thin to γ-rays. Thus, the Hα luminosity (LHα) is proportional to τejLγ, where τej is the γ-ray optical depth in the ejecta and Lγ is the γ-ray luminosity (cf. Kozma & Fransson 1992). The γ-ray optical depth τej is proportional to ρejRej where ρej is the ejecta density, and Rej = (2Eej/Mej)1/2t is the characteristic length scale in the ejecta. Because the inner layers of SN ejecta have an almost-constant density profile (e.g., Kasen 2010), we assume . Then, we obtain . The late-phase γ-ray luminosity is LγM56Niexp(−t/τ56Co) where is the initial 56Ni mass, and τ56Co = 111 days is the 56Co decay timescale. Finally, the Hα luminosity is proportional to the stripped mass Mst. Thus, we expect that the Hα luminosity scales as .

Using the W7 parameters (Mej = 1.4 M, Eej = 1.3 B, and M56Ni = 0.6 M) and LHα ≃ 5 × 1036 erg s-1 at t = 380 days with Mst = 0.05 M (Mattila et al. 2005), we obtain the scaling relation (1)We apply this formula to iPTF13ehe in the next section. Its validity and uncertainties for this application are discussed in Sect. 2.3.

2.2. The stripped mass in iPTF13ehe

iPTF13ehe is observed to have LHα ≃ 2 × 1041 erg s-1 at ~250 days after the LC peak (Y15). The rise time is uncertain, so we adopt ~110 days based on the polynomial fit to the LC (Y15). Given the redshift of iPTF13ehe (0.3434, Y15), we estimate that the above Hα luminosity is observed at about 270 days after the explosion in the rest frame. Y15 find that the Hα luminosity decreases by roughly 20% from 270 days to 290 days in the rest frame. Our interpretation that the stripped matter provides the Hα luminosity predicts about 28% luminosity reduction during this period (Eq. (1)). This is consistent with the observation.

If iPTF13ehe is powered by 56Ni, the required 56Ni mass to obtain the peak luminosity is about 15 M (Y15). If we assume that iPTF13ehe is a pair-instability SN, the expected ejecta mass and explosion energy are roughly 110 M and 60 B, respectively (e.g., Heger & Woosley 2002). Substituting these properties for Eq. (1), we obtain Mst ≃ 0.1 M. If the large 56Ni production is due to a core-collapse SN (e.g., Umeda & Nomoto 2008), the ejecta mass can be less than what we expect from the pair-instability SN (e.g., Moriya et al. 2010). A high explosion energy is still required to have the large 56Ni production. If we adopt Mej = 70 M and Eej = 60 B, we obtain Mst = 0.3 M.

Even if iPTF13ehe is powered by a magnetar, a γ-ray deposition from the magnetar similar to the one in the 56Ni-powered model is required to explain its slowly declining LC. Thus, we estimate the stripped mass by assuming M56Ni = 15 M in Eq. (1) even in the magnetar model. The main difference between the magnetar-powered and 56Ni-powered models is in the SN ejecta mass and energy. If we take typical ejecta mass (5 M) and energy (1 B) estimated for magnetar-driven SLSNe (e.g., Inserra et al. 2013; Nicholl et al. 2015a), we obtain Mst ≃ 0.9 M. However, the magnetar model for iPTF13ehe by Wang et al. (2015) requires Mej = 35 M and Eej = 40 B. In this case, the stripped mass is Mst ≃ 0.7 M.

If the interaction between the SN ejecta and a hydrogen-free dense circumstellar medium is the major luminosity source of iPTF13ehe, the SN explosion itself can be normal. For instance, the Type Ic SLSN 2010gx had a spectrum that is similar to those observed in broad-line Type Ic SNe (Pastorello et al. 2010). If we adopt typical broad-line Type Ic SN properties (Eej = 10 B, Mej = 5 M, and M56Ni = 1 M, e.g., Taddia et al. 2015), we obtain Mst ≃ 140 M, which is unrealistically high. If we assume a higher ejecta mass, for example Mej = 20 M, we obtain a lower stripped mass, 8 M. A significant central heating source is necessary to excite hydrogen to explain the nebular Hα emission from the stripped mass. We note that a reverse shock created by the interaction, which could propagate into the inner layers to excite hydrogen, does not move rapidly inward because the interaction forms a radiative, dense, cool shell (e.g., Sorokina et al. 2015). Table 1 summarizes the stripped masses estimated in this section.

Table 1

Estimated stripped mass Mst for different progenitor models.

2.3. Consistency check and uncertainties

In Eq. (1), it is assumed that the inner layers of the SN ejecta are optically thin to γ-rays as in the Type Ia SN model of Mattila et al. (2005) at t = 380 days. Assuming a γ-ray opacity of 0.03 cm2 g-1 (Axelrod 1980), the Type Ia SN model has τej ~ 10-2. For the models at 270 days in the previous section, we obtain τej ~ 1. Thus, the scaling relation is still able to provide a rough estimate for the stripped mass. Because the optical depth is around unity, the scaling relation may slightly underestimate the stripped mass.

Y15 estimate a 56Ni mass of 2.5 M in iPTF13ehe based on their nebular spectral modeling. This 56Ni mass is too low to explain the peak luminosity of iPTF13ehe, leading to the suggestion that two or more luminosity sources power iPTF13ehe (Y15 and Wang et al. 2015). However, this 56Ni mass estimate assumes that 56Ni is irrelevant to the Hα emission. If the Hα emission is powered by radioactive decay, the mass estimate of 56Ni increases. The estimated 56Ni mass is also uncertain because of the uncertainties in the spectral modeling itself (Y15). Thus, the 56Ni-powered model with 15 M of 56Ni is not ruled out if the Hα emission is emitted by the stripped matter.

3. Constraint on the progenitor binary system

Liu et al. (2015b) have recently studied the collision between SN ejecta and its companion star in core-collapse SNe with different separations, companion masses, ejecta masses, and explosion energies (see also Hirai et al. 2014). They investigate how the stripping fraction fMst/M2 (where M2 is the companion mass before the collision) is affected by these parameters. Liu et al. (2015b) only investigate the collision with the companion stars of 0.9 and 3.5 M. To constrain the massive progenitor system of iPTF13ehe, we performed numerical simulations of the collision between the SN ejecta (110 M and 60 B) and a massive main-sequence star (50 M with 10 R) by adopting the same method as in Liu et al. (2015b). The three-dimensional smoothed-particle hydrodynamics code Stellar GADGET (Pakmor et al. 2012) is used for the simulations. We ran simulations for two separations, 5 R2 and 10 R2, where R2 is the companion radius. The Roche-lobe radii for the mass ratios of 0.5 and 1 are 3.1 R2 and 2.6 R2, respectively (Eggleton 1983).

The numerical simulations reveal stripped masses of 0.3 M (f ≃ 6 × 10-3) and 0.05 M (f ≃ 10-3) for the separations of 5 R2 and 10 R2, respectively. The stripped mass therefore reaches more than 0.1 M, as required from our estimate, and the binary system with the 50 M main-sequence companion is consistent with the Hα luminosity observed in iPTF13ehe. When assuming f = (6−1) × 10-3, the companion mass needs to be around 20−100 M if Mst = 0.1 M. Because the ejecta mass does not strongly affect the stripping fraction (Liu et al. 2015b), the companion mass is expected to be 50−300 M if the ejecta mass is 70 M (Mst = 0.3 M).

The stripping fraction is proportional to Eej (Liu et al. 2015b). The magnetar model in Wang et al. (2015) has a high explosion energy (40 B), and the companion mass needs to be more than about 80 M to have Mst ≃ 0.7 M. If Eej ≃ 1 B, as estimated from the typical magnetar model, the stripping fraction is likely to be f ~ 10-4 or less. Then, the companion mass needs to be higher than ~104 M (Mst = 0.9 M), which is extremely high.

The stripped mass strongly depends on the separation. As the separation becomes larger, the angular size of the companion star from the SN ejecta becomes smaller. Thus, less energy is ejected in the direction of the companion and the mass stripping becomes less efficient. The above stripping fraction is estimated for separations between 5 R2 and 10 R2. As indicated in Liu et al. (2015b), the stripping fraction drops significantly as the separation doubles (see also Hirai et al. 2014). If the separation is more than about 20 R2, the required companion mass is likely to become more than 103M in most of the models.

4. Discussion

4.1. Hα emission features

So far, we have focused on the observed Hα luminosity of iPTF13ehe. Here we discuss other Hα features of iPTF13ehe in the context of our stripping scenario.

The Hα emission in iPTF13ehe is observed to have a line broadening of ≃ 4000 km s-1 and an overall line shift of several 100 km s-1 (Y15). Because the stripped matter remains within the inner layers of the SN ejecta, it is expected to emit at relatively low velocities (≲ 1000 km s-1 in the case of Type Ia SNe, e.g., Liu et al. 2012). If the explosion energy is higher, stripped matter can end up with higher velocities, and we expect to observe broader emission lines, as seen in iPTF13ehe. In Fig. 1, we show the velocity distribution of the stripped matter in our impact simulation with a separation 5 R2. The typical velocity of the stripped matter is around 3000 km s-1, while the typical velocity of the ejecta is around 8000 km s-1. The velocities of the stripped matter are actually lower than the typical ejecta velocity, and they are close to the line broadening observed in iPTF13ehe. If the companion star is located between the progenitor and the observer at the time of the explosion, the collision occurs in the ejecta moving toward the observer. Thus, we expect that the stripped matter has an overall velocity toward the observer and that an observer measures blueshifted Hα emission. If the companion is in the opposite direction, the emission is likely to have an overall redshift. Thus, for emission from the stripped matter, we expect to eventually observe an overall redshift in other Type Ic SLSNe. Detailed modeling of the nebular spectra based on impact simulations similar to Liu et al. (2015b) is required to investigate the expected emission properties further.

thumbnail Fig. 1

Final velocity distribution of the stripped matter from the main-sequence companion star in our numerical simulation with a separation of 5 R2.

Open with DEXTER

4.2. Early brightening observed in Type Ic SLSNe

Some Type Ic SLSNe are known to have an early brightening before the main LC rise (Nicholl et al. 2015b; Leloudas et al. 2012). This early brightening has been related to, for example, circumstellar interaction (Moriya & Maeda 2012) and magnetar spin-down (Kasen et al. 2015). However, if Type Ic SLSNe originate in binary systems, this early emission may be related to the collision between the SN ejecta and the companion (Kasen 2010). We expect an early luminosity of ~(1−5) × 1043 erg s-1 within ten days after the explosion from the analytic formula of Kasen (2010), assuming Mej = 110 M, an ejecta velocity of 13 000 km s-1 (Y15), and a separation of 1013 cm. This is consistent with the early luminosity observed in Type Ic SLSNe (Leloudas et al. 2012; Nicholl et al. 2015b). The luminosity estimate is not sensitive to Mej, and we expect similar luminosity in the magnetar model (Kasen 2010). Because the general likelihood of observing early brightening by the companion star in Type Ic SNe is estimated to be low (Moriya et al. 2015), the frequent observations of an early brightening in Type Ic SLSNe may also imply that they tend to occur in close binary systems. Early brightening by impact onto a companion star strongly depends on the direction to the observer, while Hα emission from stripped matter can be observed from all directions (e.g., Kasen 2010; Liu et al. 2015a). Thus, Hα emission may be observed more frequently. For example, if we assume a companion viewing angle of about ten degrees, as is nearly the case for 5 R2, about 10% of randomly oriented observers are in a preferred direction for finding the early brightening (Kasen 2010).

4.3. The progenitor of iPTF13ehe and its binary evolution

It has been suggested that binary evolution is important for SLSN progenitors (e.g., Justham et al. 2014). That we find a possible signature of the companion star in Type Ic SLSN iPTF13ehe suggests that binary evolution can indeed play a key role in their progenitors. For example, binarity can help progenitors to have a large angular momentum through tidal interactions (e.g., de Mink et al. 2009; Song et al. 2015) and mass transfer (e.g., de Mink et al. 2013). Rotationally-induced mixing may reduce the initial mass needed to obtain PISNe (e.g., Yoon et al. 2012; Chatzopoulos & Wheeler 2012b; Yusof et al. 2013). Rapid rotation is also essential in the magnetar-powered model because its energy source is rotation.

Y15 estimate that about 10% of Type Ic SLSNe may have nebular Hα emission. This may indicate that insufficient mass is stripped from the companion to have detectable nebular Hα emission in about 90% of Type Ic SLSNe currently observed. For example, if the typical separation is larger than about 20 R2, we do not expect sufficient stripping to be able to observe the emission, as discussed. Alternatively, many progenitors may be effectively single stars. This does not mean that they are single stars from the beginning. A stellar merger leads to an apparent single star (cf. Justham et al. 2014) and to the increase in its rotational velocity (cf. de Mink et al. 2013).

5. Conclusions

We have suggested that the Hα emission observed during the nebular phases of Type Ic SLSN iPTF13ehe originates in matter that is stripped off a hydrogen-rich companion star of the SN progenitor. Matter near the surface of the companion star is stripped when the SN ejecta collide with the companion, and the hydrogen-rich stripped matter contaminates the inner low-velocity layers of the SN ejecta. Emission from the contaminated ejecta can only be observed during the nebular phases when the inner layers are transparent. The temporal evolution, the line broadening, and the overall blueshift of the observed Hα emission in iPTF13ehe are consistent with emission from stripped matter. By scaling the predicted Hα luminosity based on the W7 model of Type Ia SNe, we estimated a stripped mass in iPTF13ehe between 0.1 and 0.9 M (Table 1). We do not expect nebular Hα emission from the stripped matter if iPTF13ehe is powered by the interaction between the SN ejecta and a dense circumstellar medium because a central heating source is required to excite hydrogen located at the inner low-velocity layers of the SN ejecta.

We performed numerical simulations of the mass stripping using the same technique as in Liu et al. (2015b). We assumed Mej = 110 M and Eej = 60 B and put a main-sequence companion star with 50 M and 10 R at a separation of 5 R2 and 10 R2. We find stripped masses of 0.3 M (5 R2) and 0.05 M (10 R2). Our mass stripping efficiency implies that the companion mass is higher than about 20 M (56Ni-powered models) or more than about 80 M (magnetar spin-down models). Our results imply that the progenitor evolved in a massive binary system and that stellar binarity may play a critical role in the evolution of Type Ic SLSN progenitors. If Type Ic SLSN progenitors are typically in close binary systems, the early brightening sometimes observed in them may also be related to the collision.

If our interpretation of the origin of the Hα emission is correct, we expect some diversity in the Hα emission feature. Especially, the overall line shift, which is a blue shift in the case of iPTF13ehe, is likely to be affected by the viewing angle. If the companion star is located behind the SN progenitor at the time of explosion, an overall redshift of the Hα emission may be observed. It will also be interesting to obtain the Hα detection rate separately in slowly declining and fast-declining Type Ic SLSNe in future SLSN studies. A large number of observations of late-phase emission from Type Ic SLSNe can test our interpretation and reveal the origin and nature of mysterious Type Ic SLSNe.

Acknowledgments

T.J.M. is supported by Japan Society for the Promotion of Science Postdoctoral Fellowships for Research Abroad (26 ·51). J.M. acknowledges support from the Deutsche Forschungsgemeinschaft priority program 1573, Physics of the Interstellar Medium.
