1. Introduction

The standard theory of low-mass star formation predicts that protostars form from the gravitational collapse of molecular cores and mass accretes onto the protostar via an accretion disk (e.g., Shu et al. 1987). However, whether the formation of high-mass (O-B type) stars follows a similar process is still a matter of debate. The main difficulty arises because the intense radiation pressure from the stellar luminosity and the thermal pressure from the HII region around the massive young stellar objects (YSOs) may be sufficient to reverse the accretion flow and prevent matter from reaching the star. Recent theoretical studies have demonstrated, however, that the radiation pressure problem can be solved if accretion occurs through a circumstellar disk continuously fed from an infalling envelope (e.g., Kuiper et al. 2010, 2011), thus explaining the formation of stars up to 140 M. Despite the theoretical evidence, while a handful of disk candidates in B-type protostars (M< 20M) has been reported in the literature in recent years (Moscadelli et al. 2013; Sánchez-Monge et al. 2013; Cesaroni et al. 2007; Zhang 2005; Beuther et al. 2005, and references therein), there has been no clear evidence of accretion disks around more massive O-type stars so far (Qiu et al. 2012). Likewise, evidence of bulk infall motions has been presented only towards a few luminous star forming regions, mostly based on observations of inverse P-Cygni profiles of molecular lines along the line of sight to a bright background (dust or HII emission), with redshifted absorption and blueshifted emission (Zhang & Ho 1997; Sollins & Ho 2005; Beltrán et al. 2006, 2011). The problem is that O-type stars are mostly found at large distances (>1 kpc) and deeply embedded inside dense massive cores (likely containing protoclusters), therefore confusion generally precludes establishing whether the globally infalling (and rotating) material in the clump, on scales of tens of thousands of AU, would feed a central cluster of lower-mass protostars or accrete onto a single O-type star (e.g., Sollins & Ho 2005; Beltrán et al. 2011). In order to resolve and decouple individual rotating disks from the infalling envelopes, infall and rotation should be measured in the proximity (<1000 AU) to individual protostars. This has been done so far only in a few YSOs with intermediate-mass (<20 M) using molecular masers observed with Very Long Baseline Interferometry (VLBI), which provide the gas 3D velocity field on AU scales (e.g., Matthews et al. 2010; Goddi et al. 2011b).

Therefore, observational signatures of mass accretion in O-type forming stars remain one of the main issues in observational high-mass star formation (HMSF). From an observational point of view, there are two crucial elements: the high angular resolution and the choice of the molecular tracer. In this context, sub-arcsecond resolution observations of highly-excited lines from high-density tracers are useful, as they enable to probe the hottest and densest gas, which presumably lies at small radii from O-type forming stars, i.e., around centrifugally-supported disks and/or infalling envelopes. Traditionally, accretion signatures have been searched using molecular transitions in the (sub)mm regime (e.g., Beltrán et al. 2005). These transitions however can only probe outer parts of disks/envelopes where dust optical depth is low, but cannot penetrate the innermost regions, where dust emission is optically thick and, hence, dominates over molecular emission at a given frequency. We argue instead that observations of optically thin, highly-excited molecular lines at λ ~1 cm could be more effective than (sub)mm interferometry in probing the innermost regions of disks/envelopes around OB-type young stars.

Table 1

Parameters of JVLA observations toward NGC 7538 IRS1.

1.1. JVLA imaging of highly excited inversion transitions of NH3 in high-mass star forming regions

NH3  has a symmetric top structure which produces inversion doublets as the nitrogen nucleus oscillates through the plane of the hydrogen nuclei. The frequencies of the transitions between two states of an inversion-doublet depend on the total angular momentum J and its projection on the molecular axis, K, and are therefore described by the pair of quantum numbers (J, K): K = 0, 3, 6, 9, 12... defines ortho-NH3 and K = 1, 2, 4, 5, 7... defines para-NH3. The non-metastable (JK) levels decay downward quickly (A ~ 10-2 s-1), populating the metastable (J = K) levels. The metastable levels cannot radiatively decay and are collisionally excited, thus multiple transitions can be used to calculate the kinetic temperature (Tkin) using a rotational diagram analysis (Ho & Townes 1983). Therefore, NH3 is an excellent thermometer of dense molecular gas. From a chemical viewpoint, two basic chemical properties make NH3 unique. Like other nitrogen bearing species (e.g., N2H+), it is not easily depleted and is therefore prominent in quiescent cloud cores. Moreover, with a dust evaporation temperature of about 100 K, hydrogenated nitrogen-bearing molecules like NH3, copiously synthesized in dust grain mantles, can be extremely abundant in the gas phase in the neighborhood of recently formed O-type stars. Perhaps the most appealing aspect of NH3 among all is that it can trace excitation up to temperatures of ~2000 K by observing its inversion transitions within a relatively narrow frequency range, 2040 GHz (e.g., Ho & Townes 1983).

Observations of highly excited NH3 inversion lines present multiple advantages. i) The high excitation temperatures imply that these transitions trace the hottest molecular gas in the vicinity of the central YSO(s) rather than the cold gas in the circumstellar envelopes. ii) Molecular transitions in the cm-regime tend to be optically thin and can more easily probe the innermost disk/envelope regions than the (sub)mm lines (e.g., Krumholz et al. 2007). iii) Measuring infall is easier in cm lines than in the mm regime, because the molecular gas can be seen in absorption against the bright continuum background of H II regions, and the absorption can be sufficiently strong even when probed with high angular resolution (the same lines in emission would be submerged by noise), thus enabling studies of gas kinematics at very small scales. iv) The detection of faint lines of high-density tracers in the (sub)mm spectrum can be severely affected by blending with stronger transitions from other species (i.e., line forest); this is not a problem at radio wavelengths.

A first attempt in this direction was a study conducted in the southern hemisphere with the Australia Telescope Compact Array (ATCA) in a small sample of HMSF regions (Beuther et al. 2007; Beuther & Walsh 2008; Beuther et al. 2009). This study revealed clear signatures of rotation and/or infall motions in about half of the observed sample, but did not identify Keplerian signatures or even flattened structures resembling accretion disks in any of the sources, at least on the linear scales probed by ATCA (103 − 104 AU). Besides the limited angular resolution (typically 0.′′52′′), the ATCA study was limited to just two lines, the (4, 4) and (5, 5), of modest excitation (Eu< 400 K), which turned out to have high optical depths, preventing reasonable rotational temperature estimates. A step forward was taken by Goddi et al. (2011a), who used the JVLA in C-configuration (0.′′7 beamsize, 300 AU) to image for the first time the NH3 lines (6, 6) to (12, 12) (with Eu = 400 − 1500 K) in the Orion Hot Core. The multi-transition data set enabled to produce resolved images of the integrated intensity, velocity field, rotational temperature and column density of NH3. This in turn enabled small-scale investigation of kinematics and physical conditions of hot gas, and eventually identification of sources responsible for heating the famous Orion Hot Core (Goddi et al. 2011a).

We have started a program with the Karl Jansky Very Large Array (JVLA) at λ ~ 1 cm to observe highly-excited inversion lines of NH3 toward Galactic hot molecular cores. The sample has been selected from a survey conducted with the Effelsberg 100 m telescope (Mauersberger et al. 1986). All the selected targets are among the most luminous HMSF regions in the Galaxy (with L ~ 105−7L), containing clusters of OB-type stars, and are associated with compact HII regions and hot molecular cores. So far, we have obtained data for NGC 7538 IRS1 and the W51 complex, while W3(OH), Sgr B2 (N), and G10.62 will be observed between the end of 2014 and 2015.

The most important goal of the program is to examine the kinematics and physical conditions of hot gas at very small radii from young O-type stars, through the combination of subarcsecond resolutions and the high temperatures required to excite high-JK lines.

1.2. NGC 7538 IRS1

This paper is the first in a series of NH3 multilevel imaging studies in well-known HMSF regions and focuses on NGC 7538 IRS1. At a distance of 2.7 kpc (Moscadelli et al. 2009), this YSO has a luminosity equivalent to an O6/7 ZAMS star (8 × 104L) and a mass of about 30 M (e.g., Akabane & Kuno 2005). Recently, a number of interferometric studies conducted with increasing angular resolution, at 1.3 mm with SMA (3′′ beamsize, Qiu et al. 2011), at 1.3 and 3.4 mm with SMA and CARMA (0.′′7 beamsize, Zhu et al. 2013), and at 0.8 mm with PdBI (0.′′2 beamsize, Beuther et al. 2013) and SMA (2′′ beamsize, Frau et al. 2014), detected several typical hot-core species, showing inverse P-Cygni profiles, probing inward motion of the dense gas toward IRS1 with ~ 10-3M yr-1 on scales 1000 AU. Radio and mm studies also identified several outflows emanating from IRS1, along north-south or N-S (Gaume et al. 1995; Sandell et al. 2009), northwest-southeast or NW-SE (Qiu et al. 2011), and northeast-southwest or NE-SW (Beuther et al. 2013). The simultaneous presence of a jet/outflow and strong accretion flow toward IRS 1, led some authors to postulate the presence of an accretion disk surrounding IRS 1, whose evidence is mainly based on VLBI imaging of methanol masers (Minier et al. 1998; Pestalozzi et al. 2004; Surcis et al. 2011). Competing models have been however proposed by different groups, to explain positions and l.o.s. velocities of CH3OH maser spots in the region, involving disk/outflow systems with different orientations. Based on multi-epoch VLBI observations of methanol masers, Moscadelli & Goddi (2014) measured line-of-sight velocities, proper motions, and acceleration of individual maser spots in the region, building a detailed model of the 3D dynamics of molecular gas in IRS1. Based on this model, they proposed the existence of a multiple system of massive YSOs surrounded by accreting disks and possibly driving different outflows. Despite the detailed dynamical model from masers, the kinematics of thermal molecular gas as well as its physical conditions at small radii (<1000 AU) from the exciting YSO(s) are largely unknown.

Using the JVLA, we imaged at a resolution of 0.′′150.′′3 seven NH3 lines with energy levels high above the ground state (equivalent to 4001950 K), from (J,K) = (6, 6) to (14, 14), in NGC 7538 IRS1. A partial dataset/analysis were presented in Moscadelli & Goddi (2014). In this article we present a full report on the results and a complete analysis of the NH3 data.

2. Observations and data reduction

Observations of NH3 towards NGC 7538 IRS1 were conducted using the JVLA of the National Radio Astronomy Observatory (NRAO)1 in B configuration. By using the broadband JVLA K-and Ka-band receivers, we observed a total of seven metastable inversion transitions of NH3: (J,K) = (6,6), (7, 7), (9, 9), (10, 10), (12, 12), (13, 13), (14, 14) at 1 cm (25–35 GHz). Transitions were observed in pairs of (independently tunable) basebands during 6h tracks (two targets per track) on three different dates in 2012: the (6, 6) and (7, 7) lines on May 31 at K-band, the (9, 9) and (13, 13) lines on June 21, and the (10, 10) along with the CH3CN (21) transition on August 7, both at Ka-band. The (12, 12) and (14, 14) transitions were observed in a 30 min track on December 21 (2013), as part of a test aimed at measuring the absolute position of the phase-reference source (see below). Table 1 summarizes the observations and reports frequencies of all the observed transitions. Each baseband had 8 sub-bands with a 4 MHz bandwidth per sub-band (~40 km s-1 at 30 GHz) and 128 channels per sub-band, providing a total coverage of 32 MHz (~320 km s-1 at 30 GHz) and a channel separation of 31.25 kHz (~0.3 km s-1 at 30 GHz). In December 2013, the JVLA correlator was more flexible, allowing different settings for different sub-bands, therefore we used a 16 MHz bandwidth and 1024 channels with a separation of 15.6 kHz for the sub-bands containing the lines, and 128 MHz bandwidth with 128 channels for the remaining sub-bands for the continuum. Typical on-source integration time was 53 min in the 2012 tracks, and 7 min in the 2013 track (thus the different rms sensitivity reported in Table 1).

Each transition was observed with “fast switching”, where 60s scans on-target were alternated with 60s scans of the nearby (3°) QSO J2339+6010 (measured flux density 0.20.3 Jy, depending on frequency). We derived absolute flux calibration from observations of 3C 48 (Fν = 0.5 − 0.7 Jy, depending on frequency), and bandpass calibration from observations of 3C 84 (Fν = 24−28 Jy, depending on frequency).

The data were edited, calibrated, and imaged in a standard fashion using the Common Astronomy Software Applications (CASA) package. We fitted and subtracted continuum emission from the spectral line data in the uv plane using CASA task UVCONTSUB, combining the continuum (line-free) signal from all eight sub-bands around the NH3 line. We performed self-calibration of the continuum emission (typically, two phase-cycles and one amplitude-cycle), providing continuum images with an integrated flux density and a 1σ rms around 400 mJy and 0.20.3 mJy beam-1, from 25 to 36 GHz, respectively. We then applied the self-calibration solutions from the continuum to the line datasets. Using the CASA task CLEAN, we imaged the NGC 7538 region with a cell size of 0.′′04, covering a 8′′ field around the phase-center position: α(J2000) = 23h13m45.s4, δ(J2000) = + 61°28′10. We adopted Briggs weighting with a ROBUST parameter set to 0.5 for all transitions observed in 2012, resulting in a synthesized clean beam FWHM of 0.′′150.′′27 and an RMS noise level per channel of ~1.53 mJy beam-1 (depending on frequency). In order to boost sensitivity in the images of the (12, 12) and (14, 14) lines (integrated over only 7 min), we used natural weighting, which resulted in slightly larger beams. For all transitions, we smoothed the velocity resolution to 0.4 km s-1. Table 1 summarizes the observations.

Table 2

Parameters of the NH3  inversion lines observed toward NGC 7538 IRS1.

Since the position of the phase calibrator, J2339+6010, was only accurate within 0.′′15, according to the VLA Calibrator Manual2, we conducted a 30 min test in December 2013 to check the astrometry of our NH3 maps, observing J2339+6010 and NGC 7538 in the fast-switching mode using QSO J2230+6946 as a calibrator. We measured a positional offset of Δα ~ −0.′′01, Δδ ~ 0.′′16 from the nominal position of J2339+6010 reported in the VLA catalog. All the NH3 maps of NGC 7538 IRS1 reported in this paper were shifted accordingly to the measured offset.

3. Results

For the first time we have mapped the hot NH3 gas from metastable transitions (6, 6) up to (14, 14) with 0.′′3–0.′′15 resolution towards NGC 7538 IRS1. These transitions are observed in absorption against the strong HC-HII region associated with NGC 7538 IRS1. In particular, we observed three ortho (6, 6; 9, 9; 12, 12) and four para (7, 7; 10, 10; 13, 13; 14, 14) transitions, with lower-state energy from approximately 400 K to 1950 K3. This enables us to probe various temperature components of the hottest molecular gas in the region. Remarkably, for the lower-excitation lines, from (6, 6) to (9, 9), we even detect pairs of hyperfine quadrupole satellites, which enabled direct estimation of the optical depth (see Sect. 4.1).

thumbnail Fig. 1

Spectra of various NH3 inversion transitions integrated over the compact core only of NGC 7538 IRS1. Spectral profiles for transitions (6, 6), (7, 7), (9, 9), (10, 10), (12, 12), (13, 13), and (14, 14) are shown in the same panel, where an offset in flux density of 0.02 Jy is applied to transitions adjacent in energy, to better display individual profiles. The lower state energy levels of transitions shown here are ~ 408−1947 K (see Table 1). The velocity resolution is 0.4 km s-1. Upper panel: The hyperfine satellite lines, separated by ~ ± 24−31 km s-1 (see Table 3), are clearly detected for the (6, 6), (7, 7), and (9, 9) lines. Lower panel: A narrower velocity range is displayed here, in order to show more clearly the line profiles of the main hyperfine component of each inversion transition. The vertical dashed lines indicate the two main velocity components at 59.3 km s-1 and 56.4 km s-1 (see text).

Open with DEXTER

thumbnail Fig. 2

Spectral profile of the JK = 132 − 131 line of CH3OH (νrest = 27.473 GHz), integrated over the core component (black line) and the southern spherical component (gray line). The vertical dashed lines indicate velocities of 59.3 km s-1 and 56.4 km s-1, corresponding to the two main velocity components in the core (see text). The velocity resolution is 0.4 km s-1.

Open with DEXTER

Besides NH3, we detected also the JK = 132 − 131 line of CH3OH (with a rest frequency of 27.47253 GHz). The CH3CN (21) line included in our bandwidth (with a rest frequency of 36.79371 GHz) was not detected.

The parameters of all the observed transitions are reported in Tables 1 and 2.

For each transition, we derived spectral profiles (Sect. 3.1), maps of total intensity (Sect. 3.2) and velocity field (Sect. 3.3), position-velocity diagrams (Sect. 3.4), and velocity-channel centroid maps (Sect. 3.5).

3.1. Spectral profiles

For each transition, we produced spectra by mapping each spectral channel and summing the flux density in each channel map (Figs. 1 and 2). Since we resolve IRS1 in the central core and a southern component (see Sect. 3.2 and Fig. 3), we extracted spectral profiles towards both components of the radio continuum. In the core, multiple transitions of NH3, from (6, 6) to (12, 12), show similar central velocities (Vc = −59.1 to 59.4 km s-1), and FWHM line-widths (ΔV1/2 = 7.1−8.3 km s-1) of the main hyperfine component, as determined from single-Gaussian fits (Table 2). We assume 59.3 km s-1 as the systemic velocity of the core. The most highly excited lines, the (13, 13) and (14, 14) lines, display larger line-widths (10 km s-1 and 13 km s-1) and more redshifted central velocities (58.2 km s-1 and 58.8 km s-1). This may reflect lower signal-to-noise ratio in the Gaussian fitting. Alternatively, these differences may reflect dynamical properties of the hottest molecular gas, expected to be closer to the central YSO and therefore to move faster. A third possibility is the presence of multiple velocity components. Figure 1 (lower panel) shows in more detail the profiles of the main hyperfine component from different NH3 transitions towards the core. These profiles show indeed two main velocity components, the dominant one, around 59.3 km s-1 (the systemic velocity), and a weaker one, around 56.4 km s-1, which becomes more comparable to the main component with higher excitation energy (for the 13, 13 line they show similar strengths). This explains the progressive increase of the central velocity (and line-width) with the excitation energy, when only one Gaussian is employed for the fit of the spectral profiles. The two velocity components are also evident in the CH3OH spectral profile towards the core (see Fig. 2). Since in the case of CH3OH the relative intensity of the weaker component is higher with respect to the lower excitation NH3 lines, single-Gaussian fitting provides a more redshifted central velocity (see Table 2). Besides the presence of two components, the profiles are quite symmetric and can be reasonably fitted by a Gaussian profile4.

Table 3

Parameters of the hyperfine components of NH3  inversion lines observed toward NGC 7538 IRS1.

Our results are consistent with previous spectroscopic studies. Based on CARMA and SMA observations, Zhu et al. (2013) report a similar value of 59.5 km s-1  for the systemic velocity, employing low-excitation lines at 1.3 mm (Eup ~ 70 − 500 K), but also find an average peak velocity of 58.6 km s-1, using more highly excited (and more optically thin) lines at 0.86 mm. Interestingly, the spectral profile of the 13CO (21) line shows multiple velocity components in absorption, with the strongest ones at 59 km s-1 and 57 km s-1, consistent with our findings. Similar velocity components are observed in absorption in many other molecules imaged with the PdBI at 1.36 mm (e.g., OCS 1817, HC3N 2423, NH2CHO 109, CH3OH 43; Beuther et al. 2012, their Fig. 7). Finally, Knez et al. (2009) analyzed high-resolution mid-IR spectra with absorption lines from several molecules (C2H2, CH3, CH4, NH3, HCN, HNCO, CS) and found two Doppler shift components at 59.7 km s-1 and 56.4 km s-1, very close to the values observed in NH3. These velocities also correspond to the velocity-centroids of two methanol maser clusters separated by 0.′′2 as imaged with VLBI (Moscadelli & Goddi 2014).

Previous single-dish observations of the (7, 7) inversion line with the Effelsberg 100-m telescope, provided a line flux density of ~260 mJy (assuming an equivalence relation K = 0.86 Jy; Mauersberger et al. 1986), so we recovered more than 80% of the single-dish flux density. Therefore, we can safely assume that most of the flux density for transitions from (6, 6) to (14, 14) is recovered by the JVLA B-array. This is not surprising considering that these transitions arise from levels >400 K above the ground and are seen in absorption against the compact HII region.

thumbnail Fig. 3

Total intensity images of seven inversion transitions of NH3 as well as the CH3OH line, as observed toward NGC 7538 IRS1 with the JVLA B-array. Contours of the NH3 line absorption are overplotted on the continuum emission (black image) at the frequency corresponding to each line. The contours represent factors 1, 3, 6, 12,... (afterwards, they are spaced by 10) of 20 mJy beam-1, for all transitions. The images were integrated over the velocity range 71 km s-1 to 47 km s-1, covering only the main hyperfine component. The line to continuum ratio decreases from 0.7 for the (6, 6) transition to 0.1 for the (13, 13) line (Table 2). For the (6, 6), (7, 7), and (9, 9) lines we overplotted also the absorption from one pair of hyperfine components (red contours). The velocity resolution was smoothed to 0.4 km s-1 for all transitions. The images were constructed with a 0.′′04 pixel for all transitions. No flux cutoff was applied. The synthesized beams (0.′′170.′′33) are shown in the lower left corner of each panel (see Table 1). The lower state energy levels of transitions shown here are 4081947 K.

Open with DEXTER

Owing to interaction with the quadrupole moment of the nitrogen nucleus, each NH3 inversion line is split into five components, a “main component” and four symmetrically spaced “satellites”, which make up the quadrupole hyperfine structure (HFS). The relative intensities and frequency separations of the four satellite components can be calculated using quantum mechanics formalism for a symmetric molecular rotor (see Table 3). The four satellite components are predicted to have nearly equal intensities, at least in LTE. In NGC 7538 IRS1, we found prominent hyperfine satellite lines in the lower-excitation doublets, from (6, 6) to (9, 9), spaced ~2731 km s-1  from the main components (Fig. 1). We used five-component Gaussian models to fit the HFS in each of those inversion transitions, where we fixed their velocity separations according to the calculated values (Table 3). Fitting of HFS was done in CLASS, part of the GILDAS software5. The (calculated and measured) line parameters of the hyperfine components are given in Table 3. Even though the satellites are well resolved from the main lines, each pair of satellites has components with a frequency difference of only ~0.30.4 MHz or 35 km s-1, therefore they are blended together. For this reason, we refrain from using these satellite components to study the gas kinematics.

3.2. Total intensity maps

We produced total intensity images of the main component of various NH3 inversion transitions, integrated over their line-widths. In Fig. 3, the integrated intensity images of NH3 (contours) are overlaid on the continuum emission at the corresponding frequency of the inversion line (black images).

The NH3  absorption follows closely the continuum emission, as expected. In particular, for lower excitation transitions, (6, 6; 7, 7; 9, 9), the absorption is extended N-S across ~ 1′′ × 0.7′′ (1900 × 2700 AU), and reveals two main condensations of hot molecular gas associated with different peaks of the radio continuum emission, the core and the southern spherical components identified by Gaume et al. (1995) at 1.3 cm. The highest excitation NH3 lines, (12, 12) and upwards, originate exclusively from the core of the radio continuum and probe the hottest gas associated with the hot molecular core in NGC 7538 IRS1. The southern spherical component has the weakest integrated absorption and it is not detected in the highest-JK transitions, indicating lower temperatures and/or densities (see Sect. 4). A detection of the satellite hyperfine components in the (6, 6) and (7, 7) lines indicates that also this southern component is optically thick, although the estimated opacity values are lower than those for the central core (Table 3, Sect. 4.1).

We fit an elliptical Gaussian to the strong core component. In all transitions, the component is fairly compact and we obtain an average deconvolved FWHM size of 0.′′24 × 0.′′14. At the source distance of 2.7 kpc, this angular size corresponds to a linear size of ~500 AU.

thumbnail Fig. 4

Velocity fields of seven inversion transitions of NH3 as well as the CH3OH line, as measured toward NGC 7538 IRS1 with the JVLA B-array. The 1st moment maps (images) are overlaid on the total intensity 0th moment maps (contours). Colors indicate VLSR in km s-1. The images were constructed with a 0.′′04 pixel for all transitions. The contours represent factors 1, 3, 6, 12,... (afterwards, they are spaced by 10) of 20 mJy beam-1, for all transitions. A flux cutoff of 7 to 11 mJy beam-1 (~ 3 − 4σ) was used for various transitions, except the (12, 12) and (14, 14) transitions, for which the cutoff was set to 20 mJy beam-1. We note that different velocity scales are used in different panels; in particular, color scales are expanded towards higher velocities with increasing quantum number to clearly show the redshifted absorption, e.g., NH3 (13, 13). All transitions show a velocity gradient NE-SW from NGC 7538 IRS1, at approximately 3040° (depending on transition), with the exception of the (14, 14) line. The synthesized beams (0.′′170.′′33) are shown in the lower left corner of each panel (see Table 1).

Open with DEXTER

3.3. Velocity field maps

We also derived the kinematics of the molecular gas associated with IRS1. In Fig. 4, we show the intensity-weighted velocity fields (or first moment maps), for all NH3 transitions as well as the CH3OH line. In the figure, the velocity (in colors) is superimposed on the total intensity map (in contours), for each transition.

Remarkably, the NH3 absorption towards the core shows an apparent velocity gradient in each line, with redshifted absorption towards NE and blueshifted absorption towards SW with respect to the hot core center (with the exception of the 14, 14 line). The velocity gradient is at a position angle [PA] ~ 3040°, and has a magnitude ΔV ~ 5 → 9 km s-1, going from the lower-excitation to the higher excitation lines. A velocity gradient at the same position and with similar orientation and amplitude was measured by Zhu et al. (2013) from SMA images of high-density tracers such as the OCS (19-18), CH3CN (1211), and 13CO (21) lines with 0.′′7 angular resolution, and by Beuther et al. (2013) in PdBI images of highly excited lines such as the HCN (43) v2 = 1 and the CH3OH (151,14–150,15) transitions. The NH3 (14, 14) line is an exception, since it shows an apparent velocity gradient along the SE-NW direction.

Interestingly, the NH3 velocity gradient becomes apparently steeper with the excitation energy (Fig. 4), as one would expect if gas closer to the star moves faster. The most natural explanation for the observed velocity gradient would be a rotating disk. However, as discussed in Sect. 3.1, multiple velocity components are present, which may mimic the presence of a velocity gradient or alter its orientation/amplitude, if a gradient is truly present. We will discuss these points in Sects. 3.5 and 5.2.

3.4. Position-velocity maps

To investigate the nature of the motion in NGC 7538 IRS1, we present position-velocity (pv) plots of the NH3  inversion lines in Figs. 5 and 6. The cuts are taken at the peak of the NH3 core along the direction of the main velocity gradients observed in the velocity field maps, PA = 35 − 40°. The velocity gradients shown in the velocity maps are evident in the pv-diagrams as well. It is instructive to compare different lines. While the lower-excitation lines, (6, 6), (7, 7) and even the (9, 9), are dominated by a strong central component around –59 km s-1, with increasing excitation energy several components become evident, with the most prominent, besides the one between –56 and –57 km s-1 (e.g., Fig. 5). This is consistent with the spectral profiles and suggests the presence of multiple individual objects moving at slightly different l.o.s. velocities (see discussion in Sect. 5.1).

Figure 6 shows an overlay of pv-diagrams for the most highly-excited lines: (J,K) = (9, 9), (10, 10), (12, 12), and (13, 13)6. While the presence of a velocity gradient is clear from this plot, there is no evident steepening of the gradient with excitation energy. In fact, different transitions seem to occupy the same locus in pv-space. It is worth noting that while the structure in the negative velocity - negative offset quadrant could in principle be consistent with Keplerian rotation, the asymmetry in the opposite quadrant indicates a more complex (non-Keplerian) profile.

thumbnail Fig. 5

Position-velocity diagrams of the (J,K) = (6, 6), (7, 7). (9, 9), (10, 10), (12, 12), (13, 13), (14, 14) lines as well as the CH3OH line observed with the JVLA B-array towards NGC 7538 IRS1. The cut is taken at the peak of the NH3 core with a PA = 40° for the NH3 (6, 6), (7, 7). (9, 9), and CH3OH lines, and PA = 35° for the NH3 (10, 10), (12, 12), (13, 13), and (14, 14) lines. The contours are drawn at steps of 0.008 Jy beam-1 starting from 0.004 Jy beam-1. The images were constructed with a 0.′′04 pixel for all transitions. Only the main hyperfine line is shown for each transition. The vertical dashed lines indicate the velocities of 59.3 and 56.4 km s-1. The PA is measured from north to east.

Open with DEXTER

thumbnail Fig. 6

Overlay of position-velocity diagrams of the (J, K) = (9, 9), (10, 10), (12, 12), (13, 13) lines observed with the JVLA B-array towards NGC 7538 IRS1. The cut is taken at the peak of the NH3 core with a PA = 35°, except the (9, 9) line (taken at PA = 40°). The image shows the pv-diagram for (9, 9) line. The contours are 0.004, 0.012, 0.024 Jy beam-1 for all transitions, except the (9, 9) transition that shows only the contour at 0.004 Jy beam-1 and the (12, 12) transition that shows only the contours at 0.012 and 0.024 Jy beam-1, respectively. The vertical dashed gray lines indicate the velocities of 59.3 and 56.4 km s-1. The PA is measured from north to east.

Open with DEXTER

3.5. Velocity-channel centroid maps

Although the core of NGC 7538 IRS1 is not resolved in our NH3 images (with a resolution of 0.′′2 or 500 AU), when observed with the VLA in A-configuration (with a resolution of 0.′′08 or 200 AU), the 1.3 cm continuum is resolved in two components, 0.′′2 apart (Moscadelli & Goddi 2014). In the following of this section, we refer to these two components as northern and southern components7.

In order to compare more in detail the structure and velocity distribution of the NH3 gas with the higher resolution continuum emission, we made velocity-centroid maps by performing two-dimensional Gaussian fitting to the absorption peak in individual velocity channels maps. The positional uncertainty of the absorption centroids is proportional to the synthesized beam size and is inversely proportional to the signal-to-noise ratio of the channel maps. With typical signal-to-noise ratios of 10–100, the positional accuracy is estimated to be on the order of a few mas (the formal errors in the Gaussian fitting, 1σ = 0.′′001 − 0.′′02, are consistent with this expectation). Therefore, Gaussian-fitting the positions of the absorption peaks in individual spectral channels, enables us to “super-resolve” the NH3 gas distribution and to better compare it with the higher resolution continuum emission.

Figure 7 shows positions, velocities, and the intensity of the absorption peaks in different velocity channels for each individual inversion line, overlaid on the 1.3 cm continuum imaged with the VLA in A-configuration8.

Figure 7 illustrates four points: 1) The absorption of all the NH3 lines is mainly distributed N-S, in between the northern and southern components of the core. 2) The absorption occurs at well separated velocities, being redshifted (in the range –56 to –50 km s-1) in the northern component, and blueshifted (in the range –65 to –57 km s-1) in the southern component. 3) The strongest absorption occurs at blueshifted velocities (peak around –59 km s-1) towards the southern component. 4) The absorption in between the two continuum peaks shows that the gas velocity steadily increases, going from the southern to the northern component.

There are remarkable differences between the velocity-centroid maps of Fig. 7 and the 1st moment maps in Fig. 4. First, in the intensity-weighted velocity maps the largest velocity gradients (with the most redshifted absorption) are observed in the highest excited lines, going from (–61, –56 km s-1) for the (6, 6) line to (–61, –52 km s-1) for the (13, 13) line, suggesting a potential steepening of the velocity gradient with the excitation energy (see Sect. 3.3 and Fig. 4). The velocity-centroid maps show instead a similar spatial distribution and velocity extent of the NH3 absorption peaks among the various inversion lines, indicating a similar velocity gradient for lines at different excitation. Second, in the 1st moment maps the higher velocities are suppressed because of weaker signal, while the channel peak maps reveal the full extent of the gradient, from 65 km s-1 (at the center of the southern peak) to 50 km s-1 (close to the northern peak). Finally, the orientation of the velocity gradient seems to change from NE-SW in the 1st moment maps (Fig. 4) to close to N-S in channel peak maps (Fig. 7). We ascribe these differences to the blending of two (spatially) unresolved velocity components. In particular, the intensity-integrated velocity in 1st moment maps over pixels of weaker signal, e.g., around the northern component of the radio continuum, could be heavily contaminated by nearby (within the synthesized beam) stronger absorption at different velocities, e.g., coming from the southern component of the radio continuum. For these reasons, we consider the velocity field traced by the velocity-centroid maps more reliable than the intensity-integrated velocity maps.

We conclude that the real velocity gradient in the IRS1 core is close to N-S and has an extent of ~15 km s-1. We also note that, since different inversion lines show similar spatial and velocity structure, the high optical depths at lower excitation do not spoil the study of gas kinematics.

thumbnail Fig. 7

Centroids of NH3 absorption fitted in individual velocity channels (open squares), overlaid on the 1.3 cm continuum map (black image and white contours) imaged with the VLA in A-configuration (Moscadelli & Goddi 2014). Color denotes line-of-sight velocity (color scale on the right-hand side). The sizes of squares scale linearly with the flux density of NH3 absorption. The relative alignment between NH3 and 1.3 cm continuum is accurate to ~30 mas. We note that with a linear resolution of 200 AU, the compact core is resolved in two (northern and southern) components, that are unresolved in our VLA B-array images (Figs. 3 and 4). The southernmost component, separated by ~0.′′4 from the core, is not shown here. We also note that the NH3 absorption distributes between the two peaks of the radio continuum, shows a velocity gradient roughly N–S, and is strongest towards the southern component of the radio continuum.

Open with DEXTER

4. Physical conditions of the molecular gas

Using the parameters measured for the seven NH3 inversion transitions observed in NGC 7538 IRS1, we can estimate the physical conditions of the NH3 gas, such as optical depth, kinetic temperature (Tkin), and column density. In the assumption of LTE (i.e., the metastable inversion lines are thermalized), we can derive the optical depth from fits to hyperfine satellites, the column density from the knowledge of the excitation temperature (Tex) and the opacity, and the kinetic or rotational temperature (Trot) from column densities of individual metastable levels, either with rotational temperature diagrams (RTDs) or ratios of individual transitions (Ho & Townes 1983). The methods as well as the formalism adopted to analyze the NH3 data are described in detail in Appendix A.

4.1. Optical depths

We detected prominent hyperfine pairs of satellite lines spaced ~ 27 − 31 km s-1 from the main component, for the (6, 6), (7, 7), and (9, 9) transitions in the core and the (6, 6) and (7, 7) lines in the southern component (Table 3). The mere presence of measurable hyperfine satellites in the profiles of highly excited transitions indicates very large optical depths. Their values can be estimated using the theoretical values of the ratio of the satellite line to the main line strengths, ams, reported in Table 3 (assuming LTE), and comparing them with the measured values (numerically solving Eq. (A.1)).

Toward the core of IRS1 we derive optical depths in the range 1026 from the (9, 9) down to the (6, 6) line, whereas towards the southern component we estimate 12 and 10 for the (6, 6) and (7, 7) lines, respectively (see Table 3). Wilson et al. (1983) estimated 22 and 34 for the (5, 5) and (6, 6) lines observed with the Effelsberg 100-m telescope, consistent with our JVLA measurements. With spacings of ~ 27 − 31 km s-1 and linewidths of <10 km s-1, these satellite lines can be well resolved from the main line, but since the lines in each pair of satellites have a frequency difference of only ~0.30.4 MHz or 35 km s-1, they are blended together, making harder an accurate estimate of linewidths. Our estimate of optical depths is affected by this systematics.

Unfortunately, we do not have direct estimates of opacities in the highest excited transitions (12, 12 for ortho; 10, 10; 13, 13 and 14, 14 for para), for which the satellite lines were too weak. For these lines, we used either the measurements in the lower excitation lines to extrapolate the opacity values in the higher excitation lines or the measured line to continuum ratio. These methods are described in Appendix A.1. Using Eqs. (A.2) or (A.3), we obtained much lower values than those directly estimated from the satellites to main lines flux ratios, in the range 0.080.7 going from the (14, 14) to the (10, 10) line. An indication that the more highly excited lines are more optically thin comes from the measured values of line to continuum ratios. According to Table 2, this ratio indeed decreases from 0.7 for the (6, 6) transition to 0.1 for the (13, 13) line. Nevertheless, we warn that a lower estimate of optical depths in these lines may systematically boost the derived temperatures (see next section).

4.2. Rotational temperatures and column densities

We estimated rotational temperatures and column densities of the molecular gas using a standard analysis on NH3 data (e.g., Ho & Townes 1983). The relevant equations are reported in Appendix A.2.

Ortho- and para-NH3  have different spin-alignment states, so transitions between para- and ortho-NH3  are forbidden, and the two behave as separate species (Cheung et al. 1969). In principle, there could be deviations from their LTE abundance ratio of 1 (e.g., Goddi et al. 2011a). Therefore, where possible we estimated temperatures using at least two lines of either para or ortho NH3.

We consider the central core first. We have direct measurements of the opacity only for the lowest-JK lines: (6, 6), (7, 7), (9, 9), therefore the most reliable temperature/density estimates come from these lines. Using the (6, 6) and the (9, 9) lines, we measured a rotational temperature for the absorbing gas, Trot~ 290 K, and an NH3 column density over excitation temperature NH3/Tex ~ 5 × 1016 cm-2/K, using both the ratio of the opacities (Eq. (A.6)) and the RTD (Eq. (A.8)). When including in the RTD the para (7, 7) transitions (assuming an ortho-to-para ratio of 1), we obtain a slightly lower Trot~ 260 K and a higher NH3/Tex ~ 7.0 × 1016 cm-2/K. Allowing for a slightly higher value of ortho-to-para ratio of 1.5 (Goddi et al. 2011a), we obtain Trot~ 280 K and NH3/Tex~ 9 × 1016 cm-2/K.

For more highly excited lines, we have only poorly constrained lower limits to the opacities. Using the three higher para lines (10, 10), (13, 13), (14, 14), we estimate Trot~ 510 K and NH3/Tex~ 3 × 1015 cm-2/K. Using line ratios, we obtain Trot~ 330 K, NH3/Tex~ 6 − 9 × 1015 cm-2/K, and Trot~ 460 K, NH3/Tex~ 3 − 5 × 1015 cm-2/K, for the (10, 10)–(13, 13) and (13, 13)–(14, 14) pairs, respectively. If these highly excited lines were still optically thick, both line ratios and RTDs would overestimate the Trot and underestimate the column densities. On the other hand, the higher temperatures are not surprising, since these lines have generally higher level energies (1500–2000 K above the ground), so may be more sensitive to hotter gas, providing rotational temperature closer to the real kinetic temperature of the gas. Therefore, if the (13, 13) and (14, 14) lines were optically thin, then their ratio would reflect the true temperature, indicating the presence of gas with temperatures up to 500 K.

Adopting Trot = 280 K and assuming Tex = Trot, we obtain a column density of ~ 1.4 − 2.5 × 1019 cm-2, averaged on scales 0.′′2. This value is an order of magnitude higher than estimated by Wilson et al. (1983), who observed the non-metastable (J,K) = (2,1) line with the 100-m telescope (therefore their value is averaged on much larger scales, ~40′′).

In the southern component, we detected only the (6, 6), (7, 7), (9, 9), and (10, 10) lines, and we have direct estimates of opacities only for the (6, 6) and (7, 7) lines. Using an RTD over the first three transitions, we obtain Trot~ 100 K and NH3/Tex ~ 8.0 × 1016 cm-2/K. Including also the (10, 10) line, we obtain Trot~ 120 K and NH3/Tex ~ 5.0 × 1016 cm-2/K. A ratio of the (6, 6) and (9, 9) ortho-lines, provide similar values: Trot~ 120 K and NH3/Tex ~ 3 × 1016 cm-2/K. Adopting Trot = 110 K and assuming Tex=Trot, we estimate a column density of ~3−9 × 1018 cm-2, averaged on scales 0.′′2. This is consistent with the southern component being at lower temperature and density, with respect to the central core, as predicted by Moscadelli & Goddi (2014) based on methanol masers.

As a final note, there are a couple of systematics that may affect the physical condition analysis. First, we assume that the different metastable lines fill the same volume. Although we are probing relatively small scales, on the order of a thousand AU, it is reasonable to expect that the lower excitation lines, such as the (6, 6) doublet, fill a larger volume than the higher excitation lines. In fact, this seems to be the case, with the lowest-JK transitions showing a more uniform N-S distribution in the core and the highest-JK transitions concentrating preferably around the two radio continuum peaks, as resolved in the VLA A-configuration images (see Fig. 7 and discussion in Sect. 5.2). Second, the absorption lines are seen against the continuum, which is optically thick (Sandell et al. 2009) and therefore its structure may change slightly between 25 and 35 GHz: this may potentially affect the line intensities. We argue however that both systematics should not affect our estimates of physical conditions. In fact our calculations of rotational temperatures always consider doublets in adjacent/close energy levels, like the (6, 6) and (9, 9) or the (10, 10) and (13, 13), but not for example the (7, 7) with the (13, 13). Therefore we can reasonably assume that the transitions used to estimated Trot occupy similar volumes. Likewise, our analysis involves transitions close in frequency (we never compare transitions at ~25 GHz with transitions at ~ 35 GHz), therefore we do not expect structure changes in the continuum to affect our temperature estimates.

4.3. Total mass

We can estimate a volume density of molecular gas and a total mass of the core in NGC 7538 IRS1, by using our estimates of NH3 column density and assuming a fraction of ammonia with respect to molecular hydrogen. For the IRS 1 core, we estimate a total column density of molecular gas of ~1.4−2.5 × 1026 cm-2, using Tex = 280 K and assuming [NH3]/[H2] = 10-7 (typical value for hot-cores – e.g., Mauersberger et al. 1986). In the assumption of spherical distribution of the molecular gas within a radius of 270 AU9, we estimate a molecular density of ~3.5−6.2 × 1010 cm-3 and a total gas clump mass in the range 19–34 M10.

For the southern component, using Tex = 110 K and assuming [NH3]/[H2] = 10-7, we estimate a molecular density of ~0.7−2 × 1010 cm-3 and a gas mass in the range 4–12 M. This mass estimate is consistent with the hypothesis of a high-mass YSO forming in the southern component, as proposed by Moscadelli & Goddi (2014).

Our analysis indicates an extraordinary concentration of mass in a small area, making IRS1 one of the densest hot-cores known.

4.4. Comparison with previous studies

Assuming thermal equilibrium between the dense gas and dust and adopting a temperature of 245 K derived from modeling the CH3CN emission, Qiu et al. (2011) estimated a gas mass of the core of 20 ± 12M over about 2.′′5 (or 6000 AU), and an average H2 number density of about 107 cm-3 (from the 1.3 mm dust emission). Beuther et al. (2012) estimates H2 column density on the order of 1026 cm-2, corresponding to an H2 number density of about 2 × 109 cm-3 averaged over 2000 AU, from which they estimate a total mass on the order of 100 M. Using dust emission (Tb = 219 K) imaged with the PdBI at comparable resolution to our NH3 maps, Beuther et al. (2013) estimates an H2 number density in excess of 109 cm-3 and a mass of 1125 M (depending on the assumed dust properties). Since we zoom in closer with our NH3 maps with respect to previous interferometric studies, we estimate even higher values for the molecular density (and temperature), confirming the special nature of the dense hot core in NGC 7538 IRS1.

5. Discussion

NGC 7538 IRS1 is reported to be one of the rare cases of an O-type young star displaying the simultaneous presence of a rotating disk, infalling envelope, and outflow. This claim is partly based on interferometric studies generally affected by insufficient linear resolution (on the order of a few thousand AU). To complicate matters, the highest angular resolution studies with VLBI of methanol masers and mid-IR imaging disagreed on the disk orientation, postulating a rotation axis either NW-SE (e.g. Pestalozzi et al. 2004) or NE-SW (e.g. De Buizer & Minier 2005; Surcis et al. 2011). This led to competing models being proposed to interpret different observations.

Recently, based on high-angular resolution observations of CH3OH masers with VLBI, Moscadelli & Goddi (2014) presented convincing evidence that IRS1 is actually a multiple system of massive YSOs, which solved the controversy aroused in previous models of the region. While our NH3 data do not resolve all the individual YSOs, the multi-transition analysis presented here has enabled us to probe, for the first time, the kinematics and physical conditions of the molecular envelope (hosting the multiple) in a wide range of excitation energies, on scales of 5002000 AU, thus complementing the picture provided by VLBI measurements of CH3OH masers on smaller scales.

In the following, we will discuss implications of our NH3 measurements on the multiple system model (Sect. 5.1), the evidence of rotation in the (circumbinary) envelope (Sect. 5.2), and signatures of infall/outflow in the hot core on different scales (Sect. 5.3).

5.1. A multiple protostellar system in NGC 7538 IRS1

With ~0.′′2 resolution, our NH3 maps clearly resolve IRS1 in the hot core, where the highest excitation NH3 absorption lines originate, and a southern component separated by 0.′′4 or 1000 AU from the core, which shows the weakest integrated absorption (see Figs. 3 and 4). With 0.′′08 resolution, the core component of the radio continuum is further resolved in a northern and southern component, 0.′′2 or 500 AU apart (see Fig. 7). The three components of the radio continuum are associated with three different clusters of CH3OH masers, and Moscadelli & Goddi (2014) proposed that they identify a multiple system of massive YSOs: IRS1a, IRS1b, and IRS1c. IRS1c is associated with the most southern component of the radio continuum and is the least massive of the three. Consistently, we do not detect IRS1c in the highest-JK transitions and we estimate lower temperatures and densities with respect to the core (see Sect. 4). The two YSOs IRS1a and IRS1b are forming in the core, have a separation smaller than 500 AU, and move at velocities of –59.5 km s-1 and –56.4 km s-1, as estimated from CH3OH maser measurements. While these two objects are not resolved in the intensity and velocity maps of NH3 (with a resolution of 500 AU), these velocities are in good agreement with the observed peaks in the spectral line profiles (see Fig. 1) and in the pv-diagrams for different NH3 transitions (see Figs. 5 and 6).

If two YSOs IRS1a and IRS1b are forming in the core, we expect gas motion both between the two YSOs (in the natal core) and around each individual YSO (in accretion disks). Moscadelli & Goddi (2014) presented compelling evidence that both IRS1a and IRS1b are surrounded by rotating disks. Since their size of 500 AU, as inferred from the masers, is comparable to the linear resolution of our NH3 observations, we do not resolve individual disks. NH3 probes instead dense and hot molecular material rotating in the envelope that is likely feeding the two accretion disks. A cartoon schematizing this model is presented in Fig. 8. We investigate the kinematic properties of the NH3 envelope in the next section.

thumbnail Fig. 8

Schematic cartoon illustrating several crucial features of NGC 7538 IRS1 that are discussed in the text. 6.7 GHz CH3OH masers observed with the EVN (filled circles) identify two high-mass YSOs, IRS1a and IRS1b, surrounded by (quasi-)edge-on disks. The black ellipses represent the disk planes, with the solid lines indicating the near-side and the dashed lines the far-side of the disks. These star-disk systems reside in the inner cavity of the circumbinary envelope (probed by hot ammonia), cleared up by the orbital motion of the binary members. The cartoon shows only the central section of such a molecular envelope (supposedly spherical). The gas in the envelope may feed the circumstellar disks of IRS1a/b (this is however of too high-order complexity to be shown). Colors denote line-of-sight velocities, with blue indicating blueshifted emission and red indicating redshifted emission, while green represents systemic velocity. Material in both the disks and the envelope is rotating, in the sense indicated by the black arrows.

Open with DEXTER

5.2. A rotating (circumbinary) envelope in NGC 7538 IRS1

The compact structure of the NH3 core shows a clear velocity gradient, in both the velocity field maps (Fig. 4) and the position-velocity plots (Figs. 5 and 6), which may be indicative of rotation in the envelope surrounding the two high-mass YSOs IRS1a and IRS1b. Since the linear size of this envelope is ~500 AU, comparable with the separation between IRS1a and IRS1b and with their disk sizes (Moscadelli & Goddi 2014), the hot gas surrounding the two YSOs is blended in our NH3 maps. While the observed velocity gradient in the 1st moment maps may be affected by the blending of the two objects, the velocity field from plots of (Gaussian-fitted) channel peak positions is not, since the two YSOs move at different velocities. Therefore, we consider the velocity field traced by the velocity-centroid maps more reliable than the intensity-integrated velocity maps (as already argued in Sect. 3.5), and, accordingly, we will base the following discussion on the former.

A few considerations are in order.

First, the direction of the velocity gradient is close to N–S, i.e., the direction along the line connecting the two continuum peaks or YSOs IRS1a and IRS1b. We note that the NH3 velocity-centroids do not trace material in the individual rotating disks (which are unresolved in our maps). Rather, each centroid represents the average velocity of the molecular material that is orbiting around the two YSOs inside the natal molecular core. Thefore, the velocity gradient in the NH3 gas between the two continuum peaks implies that the molecular gas inside the core rotates on the orbital plane of the binary.

Second, there is no steepening of the velocity gradient with the increase in the excitation energy. This is inconsistent with molecular material orbiting around one single central YSO, since one would naturally expect higher-excitation energy lines to probe inner radii, but this is still consistent with two “heating centers”, e.g., one at the northern and one at the southern edge of the core. In fact, in this case one would expect different transitions to trace a similar N-S distribution with a size given by the separation of the two YSOs, and to observe the hottest material around each YSO (i.e., around the northern and southern continuum peaks), and the colder material in between. This is indeed what we observe, with the highest-JK transitions showing weaker absorption in between the two radio continuum peaks, and the lowest-JK transitions showing a more uniform distribution (see Fig. 7). This explains also why the pv-diagrams from different transitions probe similar regions (Fig. 6).

A final interesting aspect worth discussing is the velocity profile. While the observed velocity gradient is consistent with rotation, the structural asymmetry in different quadrants shown in the overlay of pv-diagrams from different transitions (Fig. 6), indicates a complex (non-Keplerian) profile. This is not surprising, since the NH3 absorption in IRS1 is not tracing a rotating disk but rather a flattened rotating envelope, for which we do not expect a Keplerian profile. Nevertheless, as an order of magnitude, we could calculate the rotationally supported binding mass Mbind for the core in NGC 7538 IRS1, assuming equilibrium between the gravitational and rotational force at the outer envelope radius: , where R is the envelope radius, Vrot is rotational velocity, and i is the inclination angle between the rotation axis and the line of sight (i = 90° for an edge-on system). Taking as radius half the separation between the continuum peaks, ~0.′′1 or 270 AU, and as rotation velocity the total range in the velocity-centroid maps divided by 2, Vrot ~ 7.5 km s-1, the enclosed mass would be ~ 42/sin2(i)M. This mass value agrees well with the total (stars + gas) mass estimated from the VLBI measurements of CH3OH masers (25 + 16 = 41 M) , for a system close to edge-on. This total mass is also higher than the gas mass from NH3 column density, 19–34 M (Sect. 4.3), indicating that substantial mass is contained in the central stars.

We conclude that, although we cannot confirm the presence of protostellar disks around individual YSOs, the NH3 images presented here still indicate the presence of a rotating core of size ~500 AU, feeding the two smaller disks observed in CH3OH masers, as schematized in Fig. 8.

5.3. Is the NH3 core infalling or outflowing?

Previous interferometric studies on NGC 7538 IRS1, have provided a contradictory picture regarding the dominant motion in the core, depending on the spatial scales probed.

Lower-resolution NH3 (1, 1), (2, 2) observations (7–10′′ resolution) revealed P-Cygni profiles with blueshifted absorption (–60 km s-1) toward IRS 1 (e.g., Keto 1991; Zheng et al. 2001). Since the NH3 absorption is optically thick and therefore presumably traces gas residing in outer layers in the foreground of the HII region, the absorption was attributed to outflowing gas toward the observer (e.g., Zheng et al. 2001). Subsequent higher resolution (0.̋73′′) interferometric studies (Qiu et al. 2011; Beuther et al. 2012; Zhu et al. 2013), revealed inverse P-Cygni profiles with redshifted absorption (from –54.6 to –57 km s-1) in (sub)mm molecular lines from different species, like C18O, SO, HCN, HNCO, HCO+, OCS, CH3OH, and CH3CN (see for ex., Fig. 8 from Qiu et al. 2011). In these lines, the absorption comes from dense gas lying in the foreground of the bright continuum emission from the HII region and moving toward the source (away from the observer); the emission comes instead from dense gas residing in the background of the HII region and moving toward the observer.

How can we reconcile the (contrasting) signatures on small and large scales? As discussed in Sect. 5.1, the core of IRS1 hosts two compact objects, IRS1a, the dominant object at systemic velocity (–59.3 km s-1), and IRS1b, a lower mass object with redshifted velocity (–56.4 km s-1); a third object, IRS1c, is associated with the southern component of the radio continuum and NH3 absorption, and is moving with blueshifted velocity (–59.8 km s-1). In Sect. 3, based on spectral profiles and pv-diagrams, we demonstrated that the lower-excitation lines tracked here, from (6, 6) to (9, 9), are dominated by the object at –59.3 km s-1, with some weak emission contributed by the southern blueshifted YSO IRS1c. With higher excitation energy, the redshifted component at 56.4 km s-1 becomes more comparable to the main component (e.g., for the 13, 13 line both components show similar strengths; see Fig. 5), whereas the blueshifted southernmost component disappears. Based on this finding, we conclude that the blueshifted absorption observed on large scales in the NH3 (1, 1), (2, 2) inversion lines is not tracing outflowing gas, but most probably material associated with IRS1a and IRS1c. On the other hand, (sub)mm lines of higher excitation would be sensitive to all (blueshifted and redshifted) velocity components. The presence of both blueshifted emission and redshifted absorption in these (sub)mm lines (Qiu et al. 2011; Beuther et al. 2013), indicates that the infall signature is real.

If the redshifted absorption that we observe in the highly-excited NH3 inversion lines (with El up to 1950 K) were due to infall, this would indicate ongoing accretion of very hot and dense gas across the HII region within a radius of only 270 AU. While we clearly detect the absorption, our observations are not however sensitive enough to detect highly excited NH3 in emission. Therefore, without a full inverse P-Cygni profile we do not have a reference velocity, and we cannot conclude if the highly excited NH3 gas is infalling or outflowing. Nevertheless, recent observations of the HCN (43) ν2 = 1 line (Eup ~ 1000 K) with the PdBI, with an angular resolution of 0.′′2 (comparable with our JVLA measurements), revealed a clear inverse P-Cygni profile tracing infalling gas at a rate of ≈ 3.6 × 10-3M yr-1 (Beuther et al. 2013). Therefore, it may be the case that the NH3 gas in the core is infalling onto the multiple protostellar system at a similar rate.

6. Summary

We imaged the core of NGC 7538 IRS1 with the JVLA at a 0.′′2 resolution in seven metastable inversion transitions of ammonia, which are emitted from doublet levels from about 400 K up to 1950 K above the ground state. We conclude the following:

  • 1.

    The highly-excited NH3 inversion transitionsare observed in absorption against the strong HC-HII regionassociated with NGC 7538 IRS1.With the 500 AU linear resolution, we resolve theelongated north-south NH3 structure into twocompact components, the main core and a southern component.

  • 2.

    Based on intensity-weighted velocity (or first moment) maps, the NH3 inversion lines show an apparent velocity gradient oriented NE–SW, with a total extent of 9 km s-1. This velocity gradient has been already observed in other molecular transitions and has been interpreted as a rotating disk perpendicular to a known CO outflow. Examining the pv-diagrams, however, we do not find a Keplerian profile, nor a steepening of the gradient with increasing line excitation energy (one would expect warmer gas closer to the central YSO to move faster). Although this argues against the disk interpretation, we demonstrate that the velocity gradient still traces gas rotation in the molecular core (rather than in a disk; see item 4).

  • 3.

    VLBI measurements of CH3OH masers recently provided compelling evidence that IRS1 is forming a triple system of high-mass YSOs: IRS1a, IRS1b, and IRS1c. IRS1c, with a line-of-sight velocity around 60 km s-1, is associated with the southernmost component of the radio continuum, separated by a 1000 AU or 0.′′4 from the core, and is not detected in the highest-JK transitions, indicating lower-excitation temperatures. The two YSOs IRS1a and IRS1b, embedded in the hot molecular core, are associated with two resolved components of the radio continuum imaged with 0.′′08 (or 200 AU) resolution, have a separation smaller than 500 AU or 0.′′2, and move at velocities around 59 km s-1  and 56 km s-1, respectively. While these two objects are not resolved in the intensity and velocity maps of NH3, with a resolution of 500 AU, these velocities are in good agreement with the observed peaks in the spectral line profiles and in the pv-diagrams for different NH3 transitions. JVLA observations in the A-configuration are needed to resolve the binary system in the core with a separation of 500 AU.

  • 4.

    Resolved images of NH3 absorption peak positions in individual spectral channels (fitted with Gaussians) identify a velocity gradient close to N–S, i.e., the direction along the line connecting the two components of the radio continuum separated by 500 AU or 0.′′2. This reflects the global rotation of the natal massive core, in the orbital plane of the binary composed by the two high-mass YSOs IRS1a and IRS1b. With an apparent extent of ~15 km s-1, this velocity gradient corresponds to an enclosed mass in the core of ~ 42M  (assuming the NH3 gas is rotating in centrifugal equilibrium), in good agreement with the total dynamical mass estimated from VLBI measurements of CH3OH masers (41 M).

  • 5.

    From simple LTE analysis, the molecular gas in the core has a temperature of 280 K, with a potential hotter component up to 500 K. The H2 density is over 1010 cm-3 (assuming [NH3]/[H2] = 10-7), making NGC 7538 IRS1 the densest hot core known. We also estimate a gas mass from NH3 of 1934 M for the core, which is lower than the total (stars + gas) dynamical masses estimated from NH3 and CH3OH masers. The southern component has a lower temperature, around hundred K, but similar (though lower) molecular gas density.

This study on NGC 7538 IRS1, demonstrates that high-angular (i.e., a few tenths of arcseconds) resolution imaging of high-excitation lines of NH3  at ~1 cm wavelengths are well suited to study the kinematics and physical conditions of the hottest and densest molecular gas in the vicinity of the central high-mass YSO(s), that is in accretion disks and the innermost regions of circumstellar envelopes. Our observational program at the JVLA aims to apply the analysis presented in this paper to a sizable sample of very luminous Galactic hot molecular cores hosting O-type YSOs. The ultimate goal is to characterize observationally the mass-accretion process in the most massive young stars.


1

NRAO is a facility of the National Science Foundation operated under cooperative agreement by Associated Universities, Inc.

3

It is worth noting that the (13, 13) and (14, 14) lines are at 1691 K and 1945 K above the ground, and therefore provide the lines with the highest energy above the ground state imaged with an interferometer so far (these lines have been detected with the 100-m telescope in Orion BN/KL and Sgr-B2 by Wilson et al. 1993; and Huettemeister et al. 1995, respectively).

4

We also attempted a two-component fitting, which reported smaller line-widths, ~3 km s-1 and ~56 km s-1 for the dominant and weaker component, respectively. However, since the NH3 spectral profiles show, besides the main component, a hyperfine structure with two extra pairs of weak satellites, the signal-to-noise ratio in the latter did not warrant two-component fitting, resulting in very unreliable estimates of physical parameters (see Sect. 4), such as the optical depth, calculated from the satellite to the main line intensity ratio (this implies that a small error in the line intensity of the satellite results in a large change in the opacity). Therefore, in the analysis presented in this paper we adopted one component fitting.

6

We excluded the (14, 14) lines because of a too low signal-to-noise ratio.

7

The latter should be distinguished from the southern spherical component, first identified by Gaume et al. (1995), separated by 0.′′4 or 1000 AU from the core, from which is resolved in our NH3 images with 0.′′2 resolution.

8

In Fig. 7 we do not show the more southern component, separated by ~0.′′4 from the core, shown in our VLA-B array images (see Figs. 3 and 4).

9

If we consider the compact core unresolved, the radius is half the beamsize, ~0.′′1 or 270 AU. This is approximately the deconvolved value of the radius obtained from Gaussian fitting the core continuum emission.

10

We explicitly note that the value of [NH3]/[H2] is known within an order of magnitude, therefore the estimates of mass and molecular density are just order-of-magnitude estimates. Likewise, our calculations assume a fixed [NH3]/[H2] ratio in the core, therefore our analysis neglects the effect of chemistry on the location and abundance of ammonia molecules.

Acknowledgments

We thank the anonymous referee for a constructive report. We are grateful to Malcolm Walmsley for carefully reading the manuscript and for providing useful suggestions. We are grateful to Xing Lu and A. Sanchez-Monge for helping on different spectral line fitting methods. These data were obtained under JVLA program 12A-274.

References

Appendix A: Methods to estimate the physical conditions of the NH3 gas

In this Appendix, we describe the methods and formalism we adopted to estimate the physical conditions, such as optical depth, rotational temperature, and column density, of the NH3  gas.

Appendix A.1: Optical depth analysis

When both the main line and the hyperfine satellites are detected, the line opacity of one specific inversion transition can be estimated numerically by comparing the measured and theoretical ratios of the satellite line to the main line strengths (e.g., Ho & Townes 1983): (A.1)(the theoretical values ams are reported in Table 3).

This method assumes that the hyperfine satellites are optically thin, a reasonable assumption since the relative line strengths of the satellite lines are a very small fraction of the main line intensity (<1% for the (6, 6) and upper transitions).

For the highest excited transitions, the satellite lines are too weak to be directly detected. For those lines, two indirect methods can be used for estimating the optical depths. In the cases where τ(J1,K1) can be measured for an adjacent lower state, τ(J2,K2) for the higher state can be deduced from the ratio of the observed brightness temperatures or integrated fluxes (e.g., Ho & Townes 1983): (A.2)In alternative, the optical depth can be computed from the measured line to continuum ratio using the relation: (A.3)where F(J,K) is line peak flux and Fcont is the continuum flux integrated in the area of the absorption line. Here, we assume that the source covering factor (the fraction of the continuum covered by the NH3 absorbing cloud along the line of sight) is close to unity since the radio continuum emission is compact towards the core. This method works best if the optical depths are low. In case of high opacities, however, F(J,K) /Fcont is close to unity, therefore the exact value of τ becomes very uncertain.

Both methods may provide lower estimates of the optical depths, which in turn may systematically boost the derived temperatures.

Appendix A.2: Temperature and column density analysis

The NH3 populations can be described in terms of different temperatures. The excitation temperature, Tex, characterizes the relative populations of the lower and upper levels of a (J, K) inversion doublet, according to the Boltzmann distribution: Nu/Nl = gu/gle(EuEl) /Tex. The rotational temperature, Trot, characterizes the ratio of the populations of two (J, K) doublets. Since the metastable populations can only be exchanged by collisions (radiative transitions are forbidden between K levels), characterized by the kinetic temperature, Tkin, there is a direct relation between Trot and Tkin, with Trot close but generally lower than Tkin. When collisions dominate the excitation and radiative processes are unimportant, the population reaches local thermal equilibrium (LTE), and it is customary to assume Tex = Trot = Tkin. This assumption is generally valid for metastable inversion lines (e.g., Walmsley & Ungerechts 1983), and in general for hot molecular cores, which have typical densities > 107 cm-3. In the following analysis, we therefore assume that a single excitation temperature (equal to a kinetic temperature), describes all the observed metastable transitions.

The column density of one optically thick NH3 inversion line in absorption may be found from the line optical depth: (A.4)where N(J,K) is in cm-2, Δv is the linewidth (in km s-1), ν is the transition frequency (in GHz), Tex is the excitation temperature (in K), and τ is the line opacity (e.g., Huettemeister et al. 1995).

In order to find the total column density, we assume that all the energy levels are populated according to a Boltzmann distribution, characterized by a single Trot. The total column density of NH3 can then be expressed as: (A.5)where g(J,K) = gop (2J + 1) are the statistical weights (gop = 1 for para- and gop = 2 for ortho-transitions), Q(Trot) is the partition function, and El is the lower state energy of the (J, K) transition (in K). Therefore, assuming Boltzmann statistics, we need to estimate Trot in order to estimate N. We use two different methods.

The rotational temperature between two different levels can be derived in terms of the ratio of their optical depths (e.g., Ho & Townes 1983): (A.6)where are the dipole matrix elements, E1 and E2 are the lower state energies of the (J1,K1) and (J2,K2) doublets, and Trot is the rotational temperature between them. Once Trot is known, we can use Eqs. (A.4) and (A.5) to derive an NH3 column density.

When more than two transitions are observed, we can use RTDs, where the rotational temperature and the column density are measured simultaneously. Rearranging Eq. (A.5) and using Eq. (A.4) for the column density N(J,K), we have: (A.7)Taking the natural logarithm of both sides, we find: (A.8)Equation (A.8) shows that the logarithm of the left member is a linear function of El (if all transitions have the same Tex), with slope − 1 /Trot and intercept at El = 0. We can then determine Trot  and N from a least squares fit of lower state energy to the optical depth for different transitions in log space.
