1. Introduction

Radio emission from the jets of active galactic nuclei (AGN) has been extensively studied for more than 30 years. The early model of Blandford & Königl (1979) has been successfully used to explain most of the AGN observations at several bands and spatial resolutions, from the radio to γ rays (e.g., Begelman 1984; Maraschi et al. 1992). One of the main successes of this model in the radio band was the prediction of the so-called core-shift effect, i.e., the apparent shift of the core’s position with frequency, owing to optical depth effects. The effect was later discovered by Marcaide & Shapiro (1984) and then studied in many AGN, from quasars and BL-Lacs (e.g., Kovalev et al. 2008) to low-luminosity AGN (e.g., Martí-Vidal et al. 2011).

Although jets with constant opening angles (i.e., conical jets) can be used to model the spectra and the structures seen on VLBI scales (e.g., Lobanov 1998), deviations from simple conical structures have been found (e.g., Asada & Nakamura 2012). From the theoretical point of view, departures from a jet conical shape are expected from magneto-hydrodynamic collimation effects close to the jet base. Marscher (1980) built a parametric model of the continuum emission from AGN jets, from radio to X-rays, based on the earlier theoretical studies by Blandford & Rees (1974), in which these collimation effects were taken into account. According to this model, the jet structure can be divided into three parts: 1) the jet “nozzle” that connects the central AGN engine (i.e., the super-massive black hole, SMBH) to the jet base; 2) the collimation region (with a concave shape), where the trajectories of the electrons are focused towards the jet direction, so part of the “internal” contribution to their Lorentz factors becomes a “bulk”, or common, Lorentz factor; and 3) the free region (with a conical shape), where the trajectory of the plasma, once a maximum bulk Lorentz factor has been achieved, is believed to be ballistic.

Despite the success of the standard jet model to explain the multiband spectra and the VLBI structures seen in many radio-loud AGN, the injection and launching mechanisms of the jets are poorly understood. It is believed that the accretion of material into the SMBH triggers the injection of plasma into the jet. This leads to the well-known disk-jet connection, or the fundamental plane model of black-hole accretion (Merloni et al. 2003). However, the exact mechanism from which the material is brought from the infalling region of the accretion disk to the base of the jet is unknown. Observational constraints on the emission from the regions involved in this process (e.g., Marscher et al. 2008) are essential for the progress of the theoretical models, although limited, owing to the large distances to these objects and the small spatial scales (sub-parsec) involved.

In the present paper, we use ALMA continuum observations of the blazar PKS 1830−211 to follow its variability at observing frequencies from 100 to 300 GHz. The blazar is located at a redshift of z = 2.507 ± 0.002 (Lidman etal. 1999) and is lensed by a foreground z = 0.89 galaxy (Wiklind & Combes 1996), which generates two bright and compact images of the core, separated by 1′′ and embedded in a weaker pseudo-Einstein ring seen at radio cm wavelengths (Jauncey et al. 1991). The compact images are located to the northeast and southwest of the pseudo-ring, and we hereafter refer to them as NE and SW images. Due to the steep spectral index of the pseudo-ring, only the NE and SW images remain visible at mm/submm wavelengths (with a lens magnification factor of about 5–6 for the NE image and 3–4 for the SW image, e.g., Nair et al. 1993; Winn et al. 2002). The most precise measurement of the time delay between the two images is 27.1 ± 0.6 days (Barnacka et al. 2011, see also Lovell et al. 1998; Wiklind & Combes 2001), with the NE image leading. Thanks to this rare geometry, it is possible to measure the temporal and spectral variations in the flux ratio ℜ between the two images with high accuracy at submm wavelengths. We show that such observations can help constrain the physics of plasmon ejection in regions very close to (if not at) the base of the collimation region in the jet.

We adopt the cosmological parameters H0 = 67.3 km s-1 Mpc-1, ΩM = 0.315, ΩΛ = 0.685 and a flat Universe (Planck collaboration 2013). Accordingly, 1 mas corresponds to 8.28 pc at z = 2.5 and to 8.00 pc at z = 0.89.

2. Observations and data reduction

The observations are part of an ALMA Early Science Cycle 0 project for the spectral study of absorption lines in the z = 0.89 lensing galaxy toward PKS 1830−211(Muller et al., in prep.). Here, we briefly summarize the points relevant for this paper.

The observations were taken in spectral mode at frequencies around 100 GHz (B3), 250 GHz (B6), 290 GHz (B7), and 300 GHz (B7), targeting strong absorption lines of common interstellar species. The corresponding frequencies in the z = 2.5 blazar rest frame are ~350, 880, 1020, and 1050 GHz. For each tuning, four different 1.875 GHz-wide spectral windows were set, each counting 3840 channels separated by 0.488 kHz. Data were taken on 9–11 April (B6 and B7), 22–23 May (B3, B6, and B7), 4 June (B3 and B7), and 15 June 2012 (B3 and B6), see Table 1. The project was not designed as a monitoring of PKS 1830−211 hence the loose and irregular time sampling. The array configuration resulted in a synthesized beam of ~2′′ in B3, and ~0.5′′ in B6 and B7. The two compact images of the blazar (separated by 1′′) are easily resolved in the Fourier plane (see below), while their individual substructure (of mas scale) remains unresolved.

The flux calibration was performed by short observations of Titan or Neptune. The absolute flux scale was set from a subset of short baselines, for which the planets were not resolved. This scaling was then bootstrapped to other sources for all baselines. We estimate an absolute flux accuracy of ~5% in B3 and ~10% in B6 and B7.

VLA observations at 15 and 22.5 GHz by Subrahmanyan et al. (1990) reveal that the pseudo-Einstein ring has a steep spectral index (α = 1.5–2.0, with the flux S ∝ ν− α) compared to the two compact images (α ~ 0.7). Extrapolating the flux density of the components labeled C and D by Subrahmanyan et al. (1990) to 100 GHz and higher frequencies, we checked that their contribution becomes negligible for the ALMA observations. The continuum emission of the blazar images was thus modeled as two point sources (NE and SW). We used an in-house developed software (uvmultifit; Martí-Vidal et al., in prep.), based on the common-astronomy-software-applications (CASA) package1, to perform the visibility model-fitting. Absorption lines from the z = 0.89 galaxy and atmospheric lines were removed from the data before the fit. These lines are narrow (~100 km s-1, at most), compared to the bandwidth of each spectral window, and sparse, so that the remaining number of line-free channels was always large (typically >2000). The parameter uncertainties were derived from their covariance matrix, computed at the χ2 minimum, and scaled so that the reduced χ2 equals unity.

The estimated positions and fluxes of the NE and SW images were used to build a visibility model to perform phase self-calibration, with one complex gain solution every 30 s. The high dynamic range of our observations (~1000–3000) and the large number of antennas involved in the observations (>16) ensure that no spurious signal appears in the data after this self-calibration process (e.g., Martí-Vidal & Marcaide 2008). After self-calibration, the visiblity model-fitting process was repeated.

Rather than fitting the flux density of each of the two images, we have fitted the values fNE, the flux density of the NE image, and ℜ = fNE/fSW, their flux-density ratio. The fitting allows us to derive the ratio of flux densities between the images with high precision and accuracy. In particular, the uncertainty in the flux-ratio estimate is close to the inverse of the achieved dynamic range (i.e., ~10-3), and since we are comparing two sources within the same field of view (the field of view is much larger than the separation of 1′′ between the lensed images), it is free from systematics related to instrumental (e.g., bandpass) or observational (e.g., flux calibration) effects. We emphasize that, to the best of our knowledge, no flux-monitoring of any source has so far been reported at rest frequencies between 350 to 1050 GHz, with an accuracy similar to what was achieved in the flux ratios derived from our ALMA observations toward PKS 1830−211.

3. Results

The time variations of the flux-density ratio ℜ between the two lensed images (ℜ = fNE/fSW) during our ALMA observations are shown in Fig. 1 for the different bands. Data cover a time span of roughly three times the time delay between the two lensed images. The flux ratio varies from a low value of ℜ ~ 1.2 at the first data points on April 09–11 to a peak of ℜ ~ 1.5 on 22–23 May, and then decreases to ℜ ~ 1.3 on 04–15 June. The frequency dependence of the ratio is particularly interesting. While the data points do not show a large spread between bands in April, there is a strong frequency dependence during the flux-ratio increase in May, with higher ratios at higher frequencies, which later becomes inverted in the June data points (i.e., with higher ratios at lower frequencies). These strong changes in the flux ratio are not clearly reflected in the flux-density evolution of the blazar (Fig. 2).

thumbnail Fig. 1

Evolution of the flux-density ratio between the NE and the SW images, measured for each spectral window in our ALMA observations. The error bars are much smaller than the symbol sizes. The flux-ratio evolution based on our jet model (see text) is overlaid for frequencies of 100 GHz (red) and 300 GHz (blue). At high frequencies (e.g., 300 GHz), our model predicts fast and large variations of the flux ratio.

thumbnail Fig. 2

Evolution of the submm flux density of the NE image of the blazar. Filled symbols are the actual flux density measurements of the NE image; empty symbols correspond to the flux densities of the SW image shifted backwards in time by 27 days (i.e., the time delay of the lens, Barnacka et al. 2011) and scaled up according to a quiescent flux ratio of ℜquiet = 1.34 (see Table 2). For each epoch and band, the flux densities of the four ALMA spectral windows (Table 1) were averaged together. The dashed line marks the time when the effect of the ejected plasmon begins to be seen in the NE image, according to our model.

thumbnail Fig. 3

Fermi-LAT light curve of PKS 1830−211. The dotted lines mark the epochs of our ALMA observations. The dashed line marks the time when the effect of the ejected plasmon begins to be seen at ALMA frequencies in the NE image, according to our model. Only Fermi-LAT points with a confidence level above 2σ are shown. The time binning is of seven days.

Besides the general time variations over a monthly timescale, we do observe rapid variations of ℜ, of a few percent, on a much shorter timescale of hours (at 300 GHz on 23 May and at 290 GHz on 11 April). This rapid behavior seems to be seen at only the high frequency end, but the sparse time sampling of our observations does not allow us to investigate the intra-day variability further.

At cm wavelengths, Pramesh Rao & Subrahmanyan (1988) and Nair et al. (1993) noted long ago that the flux ratio varies with time and frequency. A (sparse) monitoring of PKS 1830−211at 3 mm over a time period of 12 years shows that the flux ratio can vary around a value of ~1.6 (see Muller & Guélin 2008), with extreme excursions in the range 1–2. In these 3 mm observations, however, the two images were not resolved, and the ratio was determined from the saturation of the HCO+J = 2–1 line at the velocity of the SW absorption, assuming a covering factor fc of unity. Since fc is actually slightly lower than unity (Muller et al., in prep.), the flux ratio was likely slightly overestimated with this method. Using the BIMA interferometer at 3 mm, Swift et al. (2001) resolved the two lensed images and could measure a flux ratio ℜ of 1.18 ± 0.06 at the time of their observations (27–28 December 1999), within the range of ratios reported by Muller & Guélin (2008). We should emphasize that there has been no previous measurement of the flux-ratio variability on timescales shorter than a day, that we are aware of.

PKS 1830−211 is in the list of the Fermi Large Area Telescope (Fermi-LAT) monitored sources and its daily light curve can be retrieved from the Fermi-LAT website2. Several major γ-ray flares have been reported in the past (e.g., Ciprini 2010, 2012), with amplitude variations up to a factor of tens on short timescales (~hours), revealing the strong intrinsic variation of the source (e.g., Donnarumma et al. 2011). The Fermi-LAT light curve (for energy above 100 MeV) for year 2012, as retrieved from the Fermi-LAT public archive, is shown in Fig. 3. It can be seen from this figure that our ALMA observations have been performed, although serendipitously, during the time of a major γ-ray flare, the strongest one in a period of two years, corresponding to an increase by a factor of up to seven within about one month. This coincidence provides us with a good opportunity to study the submm counterpart of a γ-ray flare from a blazar.

Hereafter we discuss the interpretation of the temporal and chromatic evolution of the flux ratio in our ALMA data. We consider the potential effect of gravitational micro- and milli-lensing, showing that structural changes in the blazar’s jet are needed anyway to explain the observations. Further, we consider a simple model of plasmon ejection, which can naturally and simply reproduce the flux-ratio evolution and its chromatic behavior.

4. Effects of micro- and milli-lensing?

Micro- and milli-lensing events could introduce a variability into the flux ratio, but its chromatic changes directly imply a chromatic structure in the blazar (i.e., a core-shift effect). The variability in the amplification due to micro- and milli-lensing depends on the angular size of the source, θS, relative to the typical angular size of the Einstein radius of the structure causing the light deflection, θE. If the source is smaller than θE, then the lensing variability can be large. Typically, an object in the lens plane with mass M can produce lensing variability if θSθE=1DOS4GMc2DLSDOSDOL,\begin{eqnarray} \theta_{\rm S} \lesssim \theta_{\rm E} = \frac{1}{D_{\rm OS}}\sqrt{\frac{4\,G\,M}{c^ 2}\frac{D_{\rm LS}}{D_{\rm OS}\,D_{\rm OL}}}, \label{microEq} \end{eqnarray}(1)where DIJ is the angular distance from J to I, and the subindices O, L, and S stand for observer, lens, and source, respectively.

In the case of micro-lensing, e.g., by a stellar-mass object in the lens plane, we get a typical Einstein radius θE = 1.7  μas. This is a very low value compared to the expected angular size of the jet emission (e.g., Gear 1991), falling by several orders of magnitude. Indeed, Jin et al. (2003) were able to slightly resolve the core size of PKS 1830−211at 43 GHz in their VLBA observations, getting diameters of ~0.5 mas (see their Fig. 1). In the case of a conical jet, the size of the core emission should scale roughly as ∝ν-1 (for a concave jet, the dependence of size on frequency is weaker). A (conservative) estimate of the core size at our ALMA frequencies therefore falls between 70 μas (at 300 GHz) and 215 μas (at 100 GHz), far too large to allow for an effective variability caused by micro-lensing. We note that X-ray micro-lensing was suggested by Oshima et al. (2001) to explain the large discrepancy between the intensity ratio at X-ray and the magnification ratio of the two lensed images in PKS 1830−211. The size of the blazar’s X-ray emission region, i.e., a few Schwarzschild radii of a ~108  M supermassive black hole (that is a few 10 μpc), is indeed much smaller than that of the continuum-emitting region seen at ALMA frequencies.

Increasing the mass of the perturbing object in the lens plane by several orders of magnitude brings us to the milli-lensing regime. Here, the timescale for an apparent motion of an object in the z = 0.89 galaxy is large: with a transverse velocity of 1000 km s-1, such an object would only cover an apparent drift of ~0.5 mpc (60 μas) within one year (observer frame). Therefore, the timescale of milli-lensing would be too long to explain the short timescales observed in the flux-ratio evolution (i.e., days or a few weeks).

On the other hand, a plasmon travelling at nearly speed of light in the blazar’s jet would cover an apparent projected distance of ~0.2 mas in the lens plane within one month, so that milli-lensing could not be formally ruled out to explain variabilities of a weeks or a few months. However, the intra-day variability detected in our ALMA observations cannot be explained by milli-lensing. In any case, we emphasize that an intrinsic variability in the blazar’s jet is required for milli-lensing to work on timescales of less than one year.

5. Intrinsic variability in the blazar

The simplest way to explain the temporal and chromatic changes in the flux ratio is to consider intrinsic variability in the jet of the blazar, which must indeed be variable by nature. The odd behavior in the evolution of the flux ratio, ℜ, can be explained using a simple model of an overdensity region (plasmon), travelling downstream of the jet. From the evolution of the flux density of the NE image, we can set an upper bound to the flux-density increase of only 5% at 100 GHz (observer frame) during the flare (see Fig. 2). We note that this is probably the weakest flaring event ever detected from a blazar at submm wavelengths. In contrast, the γ-ray emission shows a much larger variability, of a factor of up to seven during the same period.

Table 2

Parameters of our jet model.

thumbnail Fig. 4

Sketch of the path followed by the jet plasma during our observations. Not to scale. The concave region (gray) should be much smaller than the conical region (white). Moreover, the line of sight coincides with the precession axis of the jet tube. The precession angle is θ.

5.1. Model of the blazar’s jet

From 43 GHz VLBA observations, Garrett et al. (1997) and Jin et al. (2003) have reported structural and temporal variations in the radio core/knot images of PKS 1830−211. Jin et al. (2003) could measure changes in the relative distance between the centroids of emission of the NE and SW images to up to 200 μas in a few months. These changes were interpreted by Nair et al. (2005) as due to a helical jet, with a jet precession period of about one year (corresponding to an intrinsic period of ~30 yr for the source at z = 2.5), possibly due to the presence of a binary black-hole system at the center of the AGN. Morphological changes in the continuum emission are also believed to be responsible for the time variations observed in the z = 0.89 molecular absorption (Muller & Guélin 2008).

As far as we know, there has been no further attempt to observe the evolution of PKS 1830−211’s core/jet structure at high angular (VLBI) resolution since the observations reported by Jin et al. (2003). We show below that our ALMA data can help shed new light on this interesting system.

The geometry of the blazar is illustrated as a sketch in Fig. 4. Based on the model of Nair et al. (2005), we set a jet viewing angle of θ = 3°, and assume that the precession axis almost coincides with the viewing direction (so that the viewing angle does not change with time). Indeed, the time span of our observations is much shorter than the precession period reported by Nair et al. (2005), so that we can consider the jet viewing angle as a constant in any case.

By fixing the viewing angle, we can numerically model the mm-submm emission from the jet, using the parametric model by Marscher (1980). The details of our implementation of the Marscher’s model are described in Appendix A. We have simulated a flare in the jet as due to a narrow overdensity in the population of synchrotron-emitting particles (hereafter, a plasmon), due to either a sudden increase in the accretion rate by the SMBH (i.e., related to the disk-jet connexion) or triggered by an internal shock in the jet (e.g., Mimica et al. 2004). Although elaborated hydrodynamical codes are used to model the propagation of internal shocks in jets (e.g., Mimica et al. 2004; Böttcher & Dermer 2010), we built a simplified model for the evolution of the jet flare (see Appendix A), using a minimum number of model parameters in compromise with our limited amount of observations. Then, using a time delay of 27 days between the NE and SW images (the NE image leading), we have computed the flux-density ratio as a function of time and observing frequency. A direct comparison between the observed ratios and the model predictions allowed us to constrain the defining parameters of the jet model by means of least-squares minimization.

Our jet model depends on several parameters, which are listed in Table 2 and described in Appendix A. We distinguish between two kinds of fitting parameters. The first kind describes the quiescent state of the jet: on the one hand, we have the power index of the electron energy distribution, γ, and the bulk Lorentz factor of the electrons, Γ; on the other, the opacity, τν0, for a given reference frequency, ν0, and distance to the jet base, R0. Finally, the integrated flux density at the reference frequency over the jet, Fν0, and the flux ratio of the NE image to the SW image in the quiescent state, ℜquiet. For the case of a concave jet, we must add the curvature index of the jet surface, β.

The second kind of parameter describes the flare as due to an overdensity of plasma, which travels through the jet with the same local bulk Lorentz factor as that of the quiescent plasma. The parameters used here are the width of the overdensity region, Δ, the density contrast factor, K, and the time of injection of the plasmon into the jet, t0. An increase in the local magnetic field is also applied, to keep a constant ratio of the particle and field energy densities.

Regarding the fixed parameters in the model, we have the jet viewing angle, θ (fixed to 3°) and the time delay of the lens, Δτ (fixed to 27 days). We notice that variations in these fixed parameters within reasonable limits (0.5 degrees for θ and a few days for Δτ) do not change the conclusions reported in the following sections (a small change in Δτ basically translates into a change in t0).

thumbnail Fig. 5

Quantities derived from our simplified jet model. The magnetic field B and electron density N (dashed and solid black lines) are shown as a function of radial distance from the jet origin, normalized to their values at 10-1 pc; the Lorentz factor, Γ, (dotted line) is shown unnormalized; the jet brightness at 100, 250, and 300 GHz (blue, green, and red lines) is shown normalized to the brightness peak at 100 GHz. Left, a fitting model obtained assuming that the emission comes from the conical (i.e., free) jet region. Right, a fitting model assuming that the emission comes from the concave jet region. See text for details.

thumbnail Fig. 6

Top, flux-density ratio of the NE image to the SW image. Bottom, flux density of the NE image. Circles are the ALMA data and lines are the predictions from our best-fit jet model. Different colors correspond to different observing epochs. Left, fit to the conical-jet model. Right, fit to the concave-jet model. The dashed line marks the lower flux-density ratio expected from an (unconstrained) previous flare (see text for details).

The set of parameters for the quiescent and flaring stages are listed in Table 2. We note that the large number of parameters to be fitted (8 for a conical jet, 9 for a concave jet), together with the limited amount of data and the nonlinearity in the behavior of most of the parameters, makes it difficult to constrain the parameter space in a statistically robust way. Thus, instead of one single estimate for each parameter, we explored the parameter space and report the range of values that match the data with a similar quality (maximum increase in the χ2 of 20% with respect to the minimum value).

5.2. Fit to a conical jet

We show in Fig. 5 (left) the behavior of the magnetic field, particle density, bulk Lorentz factor, and flux density per unit length of a conical-jet model fitted to our ALMA data. The values of the parameters used are given in Table 2. The plot of model versus data is shown in Fig. 6 (top left). The general trend of the flux-density ratios is roughly followed by the model, with higher ratios in the May epochs and lower ratios in the June epochs. The frequency dependence of the ratios in the June epochs is also recovered. Regarding the spectrum (Fig. 6, bottom left), the conical-jet model is clearly unable to reproduce the optically thin spectrum seen in the data (α = 0.7). Indeed, nearly flat spectra are expected from conical jets in energy equipartition between the leptons and the magnetic field. This effect, known as the “cosmic conspiracy”, is due to the particular dependence of all these quantities with distance to the jet base (Marscher 1977; Blandford & Königl 1979). However, this is only true as long as the jet base is opaque to the radio emission. If the frequencies are high enough, the whole jet becomes optically thin and the spectrum steepens (e.g., Marscher 1980). The peak emission at these high frequencies is obviously located close to (it not at) the physical base of the jet, where the conical model does not apply. The frequency range with a steep spectrum, which implies a (nearly) optically-thin jet, should be modeled using a concave jet, as we describe in the next section.

According to our model, the epochs on April (black; Fig. 6, left) were taken well before the flare. Then, the epochs in May (red) were taken while the flare had already arrived on the NE image (hence the higher flux-density ratios). Finally, the epochs in June (green and blue) were taken when the flare had already arrived on the SW image, thereby explaining the lower flux-density ratios and the slightly higher ratios at the lower frequencies (i.e., those frequencies for which the flare was not strongly illuminating the SW image yet).

We must notice that the model prediction of flux-density ratios for the data taken in April falls above the data (Fig. 6, top). An earlier flare in its final stage (i.e., illuminating only the SW image) is needed to explain the lower ratios at these epochs. Unfortunately, the lack of earlier data prevents us from constraining any quantity for this possible previous flare.

5.3. Fit to a concave jet

The quantities related to a concave-jet model are shown in Fig. 5 (right). We notice the increase in the bulk Lorentz factor with distance, as well as the slower decrease in magnetic-field strength and particle density, which steepen the synthesized spectrum. The parameters used to generate this plot are shown in Table 2. The peak intensity at high frequencies is located at a distance very close to the jet origin (a few mpc). If this distance were close to the nozzle size (e.g., similar to the case of 3C 345, Marscher 1980), Fig. 5 (right) would suggest that the jet is almost (if not completely) optically thin to the emission at our highest frequencies. This would, indeed, steepen the observed spectrum (as discussed in the previous section).

The plot of observed ratios vs. model is shown in Fig. 6 (top right). The fit to the May epochs is improved, so the model can now reproduce the spectrum (Fig. 6; bottom right). As for the conical-jet model, an earlier flare is needed to explain the lower flux ratios observed in April.

We notice that some flux ratios in May at 300 GHz (Fig. 6, magenta) cannot be reproduced by the model. A rapid variability is needed in this case, since the observed ratios changed from 1.49 to 1.54 in only about five hours. Nevertheless, it is remarkable that our simple model is able to reproduce the timescale in the evolution of the flux ratios in all the other cases. Indeed, the higher 300 GHz ratios in May could be explained by substructure in the plasmon or successive flaring events. To illustrate this, we show in Fig. 7 the results of a model with a concave jet, adding an extra flare, ten times weaker than the first flare and emitted about 22 days later. This new model is able to predict a rapid variability for the epochs in May. Unfortunately, we do not have enough observations to perform a (statistically meaningful) fit of models that are more complicated than one simple plasmon.

5.4. Constraints on the jet physics

As described in Appendix A, our model assumes a jet with a very small opening angle. Indeed, our fitting parameters determine all the proportionality constants between the distance to the jet base R, the source function ϵν/κν, and the opacity τν, without any need to use an absolute width of the jet. As a result, the magnetic field and particle density cannot be directly determined from our fitted parameters, unless we assume a given absolute size (i.e., basically, an opening angle) of the jet tube.

Nevertheless, a quantity that can be well constrained in our model is the core shift among the observing frequencies (i.e., roughly speaking, the separation between the τ = 1 surfaces at the different frequencies; Blandford & Königl 1979). Even though the resolution of our ALMA observations is not high enough to actually measure the core shift, we can still estimate it indirectly based on our model. For any pair of frequencies, the core shift is related to the time needed by the plasmon to travel from one τ = 1 surface to the other. Since the speed of the plasmon is likely close to the speed of light, the timescale in the variability of the flux-density ratios (Fig. 6, top) constrains the distance between the cores at our three observing frequencies. We notice, though, that the dependence of the opacity with distance to the jet base is very smooth in the concave-jet model, so the effect of the core shift in this model is less pronounced than in the conical-jet model. This can be easily seen in Fig. 8, where the complete simulation of the flux-density ratios is shown for both the conical-jet and the concave-jet models. However, both models still allow us to estimate the core-shift from the observed time evolution of the flux-density ratios. From our jet models, both conical and concave, we estimate a distance of 0.3–0.5 pc between the cores at 100 GHz and 300 GHz. Assuming a viewing angle of 3° for the jet, the distance between the cores translates into a projected angular shift of 2–3 μas. However, the blazar is lensed, and a magnification of 3–6 (depending on the image) eventually results in an apparent core shift of 5–8 μas between 100 and 300 GHz (for a shift of 0.5 pc)3.

Concerning the overdensity region of emitting particles in the jet (i.e., the plasmon), satisfactory fits are only obtained when the density contrast is high (>100) and the size is narrow (~1 mpc). Since the length of the radio jet (pc scale) is much greater than the size of the plasmon, the contribution of the latter to the total submm emission is small. This would explain the weak flux-density enhancement at submm wavelengths due to flare dilution. In contrast, if the γ-ray emitting region is small compared to the radio jet (e.g., Valtaoja & Teraesranta 1996), the γ-ray flare would not be significantly diluted, and the γ-ray variability would be larger than at submm wavelengths, as observed (Figs. 2 and 3).

Regarding the injection time of the plasmon, we estimate it to be about 20 days after the first ALMA observation. However, this is not a direct estimate (based on the evolution of the flux density), but it is based on our model and on the time delay of the lens. In any case, we do not expect the real injection time to differ from our estimate by more than a few days, as we discuss in the following lines. The chromatic behavior seen in the flux ratios observed on 23 May and 6 June (Fig. 1) must be due to the flare reaching the SW image between these two epochs4. Since the time delay is well known, our model allows us to constrain the start of the flare in the NE image with a precision of just a few days. Thus, the time lag between the γ-ray and submm flares should not be more than a few days (Fig. 3), suggesting that both flares originate in the same region in the jet. The cospatiality of the γ-ray and submm flares is a direct prediction of the shock-in-jet model (Valtaoja & Teraesranta 1996), in which the γ-rays are created by Compton up-scattering in the region of synchrotron-emitting electrons. Similar short time lags between γ-ray and mm/submm flares have been seen in other blazars, although the flaring activity can sometimes be located as far as several parsecs from the central engine (e.g., Agudo et al. 2011). In our case, the flaring event should be generated at, or close to, the base of the jet (i.e., in the region where the submm emission changes from optically thick to optically thin), to account for the observed frequency-dependent evolution of the image flux ratios.

thumbnail Fig. 7

Fit of a concave-jet model to the data, but adding a second (and weaker) flare, emitted after the first one. Same color code as in Fig. 6. The shaded area covers the variability of the model within ±1 day. Notice the large variability of the model on 22–23 May.

thumbnail Fig. 8

Flux ratios derived from our jet model, as a function of time and frequency. Left: using a conical jet. Right: using a concave jet. Black points correspond to the epochs and frequencies of our ALMA observations.

A few months after our ALMA observations, another γ-ray flare was seen in the Fermi-LAT light curve (i.e., between JD 2 456 140 and 2 456 180). Since the γ-ray flaring events in PKS 1830−211 are rare, the overall γ activity in 2012 (concentrated within a few months) may be related. Indeed, similar multiple γ-ray flares have been observed in other blazars. For example, Orienti et al. (2013) observed a double γ-ray flaring event in PKS 1510−089, where the first episode was not seen in radio (suggesting an origin close to the radio-opaque base of the jet), but the second episode had a strong radio counterpart, indicating an origin several parsecs downstream the jet. Similarly, the consecutive γ-ray flaring events seen in PKS 1830−211 in 2012 might be the signature of the same plasmon, propagating downstream the jet.

5.5. Comparison with mm/submm flaring activity in other AGN

There is intense observational work in flux-density monitoring of blazars, covering different bands of the electromagnetic spectrum (e.g., Giommi et al. 2012; Kurinsky et al. 2013, and references therein). Nevertheless, the study of blazar variability at mm and submm wavelengths is technically limited, so only strong flares observed in bright and/or nearby sources can be detected (e.g., Giommi et al. 2012). Even with this limitation, the detection of flares at mm wavelengths, lasting several weeks, is not rare in sources as instrinsically weak as Sgr A* (Miyazaki et al. 2006).

The intensity of the flare reported in the present paper is much weaker than the quiescent flux density of the blazar’s jet (~5% at 100 GHz). This flaring event could only be spotted from the flux-ratio evolution, thanks to the time delay between the two lensed images. On the one hand, relative fluxes among images are free of absolute calibration effects, so very weak flares can be clearly detected (variabilities as weak as a few times the inverse of the dynamic range in the image can be identified). On the other hand, the large frequency coverage of our observations (a factor 3 in frequency space) allows us to see the frequency dependence in the jet emission as the plasmon travels through it. The possibility of monitoring the evolution of very weak flares (and at very different ALMA frequencies), using the flux-density ratios in the PKS 1830−211images, therefore opens a new window onto the study of blazar variability at frequencies and energy regimes that have not been explored yet.

6. Implications for the absorption studies in the foreground z = 0.89 galaxy

In general, the effects of the core shift and the frequency-dependent size of the continuum emission should be taken into account as possible sources of systematics in absorption studies. Different continuum emission (at different frequencies) would illuminate different regions of the absorbing molecular gas in the foreground galaxy. As we discuss in Sect. 5.4, a core shift of 5 μas (for the SW image, with a magnification factor of 3) can be expected between 100 and 300 GHz. Projected in the plane of the foreground z = 0.89 galaxy, this value translates into a distance of ~0.04 pc. At frequencies lower than those of our ALMA observations, the effect can be stronger. Using our model, we can estimate the core shift in the blazar’s jet at any pair of frequencies (e.g., Lobanov 1998) using Δα=Ω(1ν21ν1),\begin{eqnarray} \Delta\alpha = \Omega \left( \frac{1}{\nu_2} - \frac{1}{\nu_1} \right), \label{CoreShiftEq} \end{eqnarray}(2)

where ν1 and ν2 are the observing frequencies, and Ω is the normalized core shift. Energy equipartition (or a constant ratio) between particles and fields is assumed. This equation also assumes a conical jet for the emission at all frequencies, but it can still be used as a rough approximation using the core shifts determined at the ALMA frequencies. As can be seen from Eq. (2), the core shift increases rapidly with decreasing frequency. Our model suggests a value of Ω ~ 0.8 mas GHz (that already includes a fiducial lens magnification of three, i.e. for the SW image).

Bagdonaite et al. (2013) used several methanol lines redshifted between 6 GHz and 32 GHz to constrain a cosmological variation in the proton-to-electron mass ratio, μ, at z = 0.89 toward PKS 1830−211. Their method lies in the fact that a cosmological variation of μ would introduce velocity shifts between different lines of methanol (Jansen et al. 2011). For their observing frequencies, our estimate of the core shift is on the order of 0.1 mas, which corresponds to a projected linear scale in the foreground z = 0.89 galaxy of ~1 pc, comparable to the typical size of molecular clumps. As a result, the different methanol lines might trace gas with slightly different kinematics, introducing a systematic source of uncertainty on velocity offsets and on a constraint on μ variation. According to the Larson law (Larson 1981), clumps of 1 pc would have a velocity dispersion of a few km s-1. In turn, an offset of 1 km s-1 would translate into an uncertainty of ~10-7 in the estimate of Δμ/μ.

The molecular absorption toward PKS 1830−211 can also be used to measure the temperature of the cosmic microwave background, TCMB , at z = 0.89. For this purpose, several molecular transitions, in general at different frequencies, need to be observed to derive the excitation conditions of the gas. Sato et al. (2013) made milli-arcsecond-resolution Very Long Baseline Array observations of the HC3N J = 3–2 and 5–4 transitions redshifted to 14.5 and 24.1 GHz, respectively. An excitation analysis based on their lower (26 mas) resolution images yielded a value TCMB = 5.6-0.9+2.5\hbox{$5.6^{+2.5}_{-0.9}$} K, consistent with value predicted by the standard cosmology (TCMB = 5.14 K at z = 0.89). However, their full resolution data yielded significantly lower values of 1–2.5 K. As possible explanations of this finding, Sato et al. (2013) discuss both of the latter scenarios, illumination of different absorbing gas volumes and the core-shift effect, which would amount to a displacement of ~0.022 mas (or ~0.2 pc) at their observing frequencies. In contrast, Muller et al. (2013) find a value TCMB = (5.08 ± 0.10) K from a variety of molecules observed between 7 mm and 3 mm with the Australia Telescope Compact Array (at epochs with no apparent γ-ray flaring activity). In that study, the effect of the core shift on the determination of TCMB is minimized by the use of higher frequencies and smeared out by the use of multiple frequency combinations in the excitation analysis.

Future multifrequency VLBI observations will be needed to address the issue of the frequency-dependent continuum illumination for absorption studies.

7. Summary and conclusions

We present multi-epoch and multifrequency ALMA Early Science Cycle 0 submm continuum data of the lensed blazar PKS 1830−211, serendipitously coincident with a strong γ-ray flare observed by Fermi-LAT. The ALMA observations, spanning a frequency range between 350 and 1050 GHz in the z = 2.5 blazar rest frame, resolve the two compact lensed images of the core of PKS 1830−211. This allows us to monitor the variation in their flux-density ratio as a function of time and frequency during the γ-ray flare.

The time variations are large (~30%) and, even more interestingly, show a remarkable chromatic behavior. We rule out the possibility of micro- and milli-lensing, based on the timescale of the variability. Instead, we propose a simple model of jet and plasmon that can explain the time evolution and frequency dependence of the flux ratio naturally. This picture is consistent with the γ-ray flaring activity. According to the model, the frequency dependence of the flux ratio is related to opacity effects close to the base of the jet. Since the time lag between the γ-ray and the submm flares is short (a few days at most), we suggest that both flares are cospatial, in agreement with the shock-in-jet model of γ-ray emission.

The frequency dependence of the flux ratio is a direct probe of the chromatic structure of the jet, implying there is a core-shift effect in PKS 1830−211 blazar’s jet (as seen in many other AGN jets). This core shift should be considered as a possible source of systematics for absorption studies in the foreground z = 0.89 galaxy, since the line of sight through the absorbing gas varies with the observing frequency.

Given the peculiar properties of PKS 1830−211 at submm wavelengths (resolvability of the lensed images, high radio brightness, and achievable accuracy of the flux-ratio measurements), we suggest that PKS 1830−211 is probably one of the best sources (if not the best) for future monitoring of (even weak) submm variability, which is related to activity at the jet base of a blazar, and study of the radio/γ-ray connection.

Online material

Table 1

Flux densities of the NE image and flux ratios measured at the epochs of our ALMA observations.

Appendix A: Simplified jet model

Following Marscher (1980), a simple model of a radio-loud AGN jet can be divided into three parts. The first one, the “nozzle”, connects the central engine (SMBH) to the physical base of the jet; the second part consists of a small region in the jet base, the launching region, where the electrons of the plasma are accelerated to relativistic speeds; the third part, the conical jet, corresponds to the region usually observed, and resolved, in VLBI at mm and cm wavelengths. In this conical region, the bulk Lorentz factor of the plasma has reached a maximum value, and the only energy gain of the leptons is due to synchrotron self-absorption (SSA), which is s much smaller effect than the energy loss due to both expansion and synchrotron radiation.

The jet diameter, r, is parameterized in the conical region as a function of the distance to the central engine, R, in the form r ∝ R. Regarding the particle density, it follows a power law of energy, N = N0E− γ, up to a cutoff energy Emax. The factor N0 decreases as N0 ∝ R− 2(γ + 2)/3 (to account for adiabatic losses), and the magnetic-field strength, B, decreases as B ∝ R-1 (to account for energy conservation). In these expressions, energy gain by SSA is not taken into account. The maximum energy of the leptons, Emax, also decreases with increasing R, due to both adiabatic and radiative cooling.

In the launching (or concave) region, the jet diameter follows the relation r ∝ Rβ (with β positive and ≪1), so it does not vary much with distance to the jet base. The bulk Lorentz factor, Γ, depends on distance as Γ ∝ Rβ (i.e., the plasma is still being accelerated to be injected later into the conical jet region). A changing Γ maps into a running Doppler shift and boost factor, which will steepen the observed spectrum. The particle density and the magnetic field change as N0 ∝ R− β(γ + 2) and B ∝ R− 2β, respectively. The maximum cutoff energy in the lepton population, Emax, also decreases with increasing distance to the jet base.

Appendix A.1: Implementation of the model

Our simplified jet model makes use of the relationships described above, but with some simplifications. On the one hand, we assume that the cutoff energy, Emax, is always higher than the energy whose critical frequency corresponds to our highest observing frequency (see Appendix A.3 for a discussion on the implementation of lower high-energy cutoffs in the electron population).

On the other hand, we assume that the jet tube (where the plasma is confined) is very narrow, so that r ≪ R for all R. This way, the radiative-transfer equation can be solved easily in both, the conical and the concave jet region, as Iν(R)=δ(R)3ϵν(R)κν(R)(1exp(2κν(R)rsinθ)),\appendix \setcounter{section}{1} \begin{eqnarray} I_\nu(R) = \delta(R)^3\frac{\epsilon_\nu(R)}{\kappa_\nu(R)}\left(1 - \exp{\left(-\frac{2\kappa_\nu(R)\,r}{\sin{\theta}} \right)}\right), \label{InuEq} \end{eqnarray}(A.1)where δ is the Lorentz boost factor at a distance R to the jet base; θ is the viewing angle of the jet (see Fig. 4); ϵν(R) is the synchrotron emissivity at frequency ν and distance R; and κν(R) is the absorption coefficient. The opacity, τν, is just κν times the path length of the light ray towards the observer, i.e., 2r/sinθ). In this expression, we also assume that the opening angle of the tube, φ, is much smaller than the viewing angle θ, although this condition can be relaxed with little change in the results5. The quantities ϵν and κν can be written in terms of N0 and B (e.g., Pacholczyk 1970) in the form ϵνN0B(1+γ)/2(νδ)(1γ)/2\appendix \setcounter{section}{1} \begin{eqnarray} \epsilon_\nu \propto N_0\,B^{(1+\gamma)/2}\,\left(\frac{\nu}{\delta}\right)^{(1-\gamma)/2} \end{eqnarray}(A.2)and κνN0B(2+γ)/2(νδ)(4+γ)/2·\appendix \setcounter{section}{1} \begin{eqnarray} \kappa_\nu \propto N_0\,B^{(2+\gamma)/2}\,\left(\frac{\nu}{\delta}\right)^{-(4+\gamma)/2}\cdot \end{eqnarray}(A.3)The two quantities, B and N0, are in turn power laws of R, so we can arrange the terms in all the power laws and write ϵνκνR1/2(νδ)5/2andτνR(7γ+8)/6(νδ)(γ+4)/2,\appendix \setcounter{section}{1} \begin{eqnarray} \frac{\epsilon_\nu}{\kappa_\nu} \propto R^{1/2} \left(\frac{\nu}{\delta}\right)^{5/2}~~\textrm{and}~~\tau_\nu \propto R^{-(7\gamma+8)/6} \left(\frac{\nu}{\delta}\right)^{-(\gamma+4)/2}, \label{EpKapCone} \end{eqnarray}(A.4)for the conical region, and ϵνκνRβ(νδ)5/2andτνR2β(γ+2)(νδ)(γ+4)/2,\appendix \setcounter{section}{1} \begin{eqnarray} \frac{\epsilon_\nu}{\kappa_\nu} \propto R^\beta \left(\frac{\nu}{\delta}\right)^{5/2}~~\textrm{and}~~\tau_\nu \propto R^{-2\beta(\gamma+2)} \left(\frac{\nu}{\delta}\right)^{-(\gamma+4)/2}, \label{EpKapLaunch} \end{eqnarray}(A.5)for the concave region. Equation (A.1) can be solved, using Eqs. (A.4) or (A.5), by imposing two boundary conditions to determine all the proportionality constants. The two conditions that we choose to solve Eq. (A.1) are, on the one hand, the value of R for which we have a given opacity (τ = 1) at a given frequency (100 GHz) and, on the other hand, the integrated flux density (i.e., the integral Fν = ∫Iν   dΩ over the jet) at a given frequency (100 GHz). These quantities are given in Table 2. We notice that all the cosmological effects (e.g., redshift and time stretching) are taken into account and the absolute values of B and N0 are not needed in the model.

The plasmon that triggers the flare in our model is parametrized as an overdensity in the electron population, of width Δ and contrast K. For a given location of the plasmon, R′, we make N(R) → K   N(R) for R ∈  [R′−Δ/2,R′ + Δ/2].

The magnetic field in the region of the plasmon is also scaled, to keep the ratio of particle energy density to magnetic-field energy density unchanged, with respect to the one in the quiescent state. The magnetic field and the particle density are related as B ∝ Nη. We therefore scale B with the factor Kη. The parameter η takes the values 3/(2γ + 4) (case of the conical region) and 2/(γ + 2) (case of the concave region).

In our model, the plasmon travels through the jet at a speed determined by the Lorentz factor, Γ (computed for each distance, R) by keeping Δ and K constant. Effects of the finite light travel time from the different R to the observer are also taken into account.

Appendix A.2: Known limitations of the model

Besides the simplifications described in the previous section of this appendix, there are other limitations in the model that have to be noticed, as listed.

  • We use an ad-hoc model for the plasmon and its evolution. Thewidth and contrast factor is assumed to be constant with respect tothat of the quiescent plasma. However, it may vary as the plasmondeparts from the jet base. A more realistic model of plasmon willdepend on the particular physical mechanisms related to itsgeneration (e.g., a shock-shock interaction). Indeed, flaringactivity can also be obtained by changing notonly N0, but other parameters involved in the intensity of the jet emission (e.g., γ, δ, Γ0, etc.)

  • Radiative energy losses are not considered in the evolving electron population. Indeed, the mean life time of the electrons could be short at the high critical frequencies of our observations. This, however, depends on several quantities, such as the strength of the magnetic field, that in turn depend on the absolute diameter of the jet tube, which is undetermined in our model.

  • The width of the plasmon should be be constrained by the cooling time of the electrons, which in turn depends on their energy.

  • A more accurate radiative transfer should consider the diameter of the jet tube, the different values of N0 and B found during the path of the light ray, and the effects from the finite light-travel time through the width of the jet.

  • We assume a jet with a smooth variation in magnetic field and particle density. We do not consider the presence of standing shocks close to the jet base.

Appendix A.3: Effects of radiative and adiabatic cooling

Marscher (1980) models the effect of radiative and adiabatic cooling by using a maximum (i.e., cutoff) energy in the population of relativistic electrons. The cutoff energy decreases as a power law of the distance to the jet base, with the exponent dependent on several parameters related to adiabatic and synchrotron losses. In the scenario of a conical jet (i.e., peak intensity located far from the jet base, due to SSA effects) with a small viewing angle, an electron population with a high-energy cutoff is the only way to generate a steep spectrum similar to the one obtained in our observations. However, we notice that such an electron population would not be able to reproduce the changing flux ratios reported in this paper.

The reason for this statement is subtle. The main contribution to the flux density at a given frequency comes from the region around the τ = 1 surface at that frequency (i.e., the VLBI core). A steep spectrum will thus be obtained if, and only if, the cutoff energies corresponding to the higher critical frequencies are achieved in the jet region behind the core (i.e., at R smaller than that one corresponding to the τ = 1 surface). A flare like that used in our model could therefore never increase the flux density at the higher frequencies (hence changing the flux ratio between the lensed images), since the flux at these frequencies would always be similar to the source function (i.e., the emission at the optically-thick region, which is independent of N0).

If we instead use an electron population with a smooth, although fast, energy decrease after a given critical energy, the problem discussed in the previous paragraph could, in principle, be solved. We use a population of electrons following the energy distribution (e.g., Potter & Cotter 2012) N(E)=N0Eγexp(E/Emax),\appendix \setcounter{section}{1} \begin{eqnarray} N(E) = N_0 E^{-\gamma}\,\exp{\left(-E/E_{\max}\right)}, \label{newNE} \end{eqnarray}(A.6)where Emax can be written as a power law of R. If we assume that an electron with energy E radiates all its power at the critical frequency ν = CB   E2 (where C is a constant, e.g. Pacholczyk 1970), it can be easily shown that the emission and absorption coefficients of the whole electron population are ϵνN(E)(Bνδ)1/2|E(νCδB)1/2\appendix \setcounter{section}{1} \begin{eqnarray} \epsilon_\nu \propto N(E)\,\left.\left(B\,\frac{\nu}{\delta}\right)^{1/2}\right|_{E \rightarrow \left(\frac{\nu}{C\,\delta\,B}\right)^{1/2}} \label{newEps} \end{eqnarray}(A.7)and κνE2ddE(N(E)E2)(Bνδ)1/2|E(νCδB)1/2.\appendix \setcounter{section}{1} \begin{eqnarray} \kappa_\nu \propto -E^2\frac{\rm d}{{\rm d}E}\left(\frac{N(E)}{E^2}\right)\,\left.\left(B\,\frac{\nu}{\delta}\right)^{1/2}\right|_{E \rightarrow \left(\frac{\nu}{C\,\delta\,B}\right)^{1/2}}. \label{newKap} \end{eqnarray}(A.8)We recall that δ is the Doppler boost factor. These new equations can be used to solve Eq. (A.1) using a generic electron population, N(E). In our case, these equations reduce to ϵνN0(νδ)(1γ)/2exp(-1EmaxνCδB)B(1+γ)/2\appendix \setcounter{section}{1} \begin{eqnarray} \epsilon_\nu \propto N_0 \left(\frac{\nu}{\delta}\right)^{(1-\gamma)/2}\exp{\left( \frac{-1}{E_{\max}}\sqrt{\frac{\nu}{C\,\delta\,B}}\right)} B^{(1+\gamma)/2} \label{newEps2} \end{eqnarray}(A.9)and κνN0(νδB)γexp(-1EmaxνCδB)×((δB)1/2(γ+2)ν1/2+1Emax)·\appendix \setcounter{section}{1} \begin{eqnarray} \kappa_\nu \propto N_0 \left(\frac{\nu}{\delta\,B}\right)^{-\gamma}\,\exp{\left( \frac{-1}{E_{\max}}\sqrt{\frac{\nu}{C\,\delta\,B}}\right)}\,\nonumber\\ \times \left(\frac{(\delta\,B)^{1/2}(\gamma+2)}{\nu^{1/2}} + \frac{1}{E_{\max}}\right)\cdot \label{newKap2} \end{eqnarray}(A.10)We have applied Eqs. (A.9) and (A.10) to simulate a conical jet with radiative and/or adiabatic energy losses taken into account. In this case, Emax ∝ R-1. However, we have been unable to reproduce a spectrum as steep as shown by the data, and in any case have we been able to reproduce the behaviour shown by the flux-density ratios as a function of frequency and time. We therefore conclude that our data are incompatible with the scenario of a conical jet, as long as our model of the jet flare, used to explain the observed evolving flux-density ratios, holds.


3

The size amplification goes as the square root of the magnification factor.

4

The γ-ray light curve shows an enhancement of the flare emission in the form of a second peak (i.e., JD around 2 456 090; Fig. 3). The ratio of the two γ-ray peaks (i.e., the first one around JD 2 456 066) is consistent with the magnification ratio between the two lensed images. This is further evidence that the flare is due to intrinsic variability in the blazar.

5

The main effect of a larger opening angle, φ, as long as it does not approach θ/2, is basically a change in the length of the light path within the jet, which can be rewritten as a change in the constant factor for τν in Eqs. (A.4) and (A.5).
