Fig. 16

Differential core formation efficiency (CFE) as function of ambient cloud column density expressed in AV units (blue histogram with error bars), obtained by dividing the mass in the form of candidate prestellar cores in a given column density bin by the cloud mass observed in the same column density bin. The upper x-axis provides an approximate mass-per-unit-length scale, assuming the local background around each core is dominated by the contribution of a parent filament with a characteristic width
Wfil = 0.1 pc (see end of Sect. 4.5). The vertical dashed line marks the fiducial threshold at
7. The horizontal dotted line marks the rough asymptotic value of ~15% for the CFE at AV > 15.
