Letter to the Editor
Constraining the properties of HD 206893 B
A combination of radial velocity, direct imaging, and astrometry data^{⋆}
^{1}
Univ. Grenoble Alpes, CNRS, IPAG, 38000 Grenoble, France
email: Antoine.Grandjean1@univgrenoblealpes.fr
^{2}
European Southern Observatory (ESO), Alonso de Córdova 3107, Vitacura, Casilla, 19001 Santiago, Chile
^{3}
Pixyl S.A., La Tronche, France
^{4}
GEPI, Observatoire de Paris, Université PSL, CNRS, 5 Place Jules Janssen, 92190 Meudon, France
^{5}
Department of Astrophysics, University of Oxford, UK
^{6}
Institute for Astronomy, University of Edinburgh, Blackford Hill, Edinburgh EH9 3HJ, UK
^{7}
Centre for Exoplanet Science, University of Edinburgh, Edinburgh, UK
^{8}
Department of Physics, University of Oxford, UK
^{9}
LESIA, Observatoire de Paris, PSL Research University, CNRS, Sorbonne Universités, UPMC Univ. Paris 06, Univ. Paris Diderot, France
^{10}
Observatoire de Genève, University of Geneva, 51 Chemin des Maillettes, 1290 Versoix, Switzerland
^{11}
Space Telescope Science Institute, Baltimore, USA
^{12}
Department of Astronomy, Stockholm University, AlbaNova University Center, 106 91 Stockholm, Sweden
^{13}
INAF – Osservatorio Astronomico di Padova, Italy
^{14}
INAF – Osservatorio Astronomico di Brera, Via E. Bianchi 46, 23807 Merate, Italy
^{15}
Astronomical Observatory of Padova/Asiago, Italy
^{16}
MaxPlanckInstitut für Astronomie, Königstuhl 17, 69117 Heidelberg, Germany
^{17}
Instituto de Física y Astronomía, Facultad de Ciencias, Universidad de Valparaíso, Av. Gran Bretaña 1111, Valparaíso, Chile
^{18}
Núcleo Milenio Formación Planetaria – NPF, Universidad de Valparaíso, Av. Gran Bretaña 1111, Valparaíso, Chile
^{19}
Aix Marseille Univ, CNRS, CNES, LAM, Marseille, France
^{20}
Núcleo de Astronomía, Facultad de Ingeniería y Ciencias, Universidad Diego Portales, Av. Ejercito 441, Santiago, Chile
^{21}
Escuela de Ingeniería Industrial, Facultad de Ingeniería y Ciencias, Universidad Diego Portales, Av. Ejercito 441, Santiago, Chile
Received:
11
January
2019
Accepted:
24
May
2019
Context. High contrast imaging enables the determination of orbital parameters for substellar companions (planets, brown dwarfs) from the observed relative astrometry and the estimation of model and agedependent masses from their observed magnitudes or spectra. Combining astrometric positions with radial velocity gives direct constraints on the orbit and on the dynamical masses of companions. A brown dwarf was discovered with the VLT/SPHERE instrument at the Very Large Telescope (VLT) in 2017, which orbits at ∼11 au around HD 206893. Its mass was estimated between 12 and 50 M_{J} from evolutionary models and its photometry. However, given the significant uncertainty on the age of the system and the peculiar spectrophotometric properties of the companion, this mass is not well constrained.
Aims. We aim at constraining the orbit and dynamical mass of HD 206893 B.
Methods. We combined radial velocity data obtained with HARPS spectra and astrometric data obtained with the high contrast imaging VLT/SPHERE and VLT/NaCo instruments, with a time baseline less than three years. We then combined those data with astrometry data obtained by HIPPARCOS and Gaia with a time baseline of 24 yr. We used a Markov chain Monte Carlo approach to estimate the orbital parameters and dynamical mass of the brown dwarf from those data.
Results. We infer a period between 21 and 33 yr and an inclination in the range 20−41° from poleon from HD 206893 B relative astrometry. The RV data show a significant RV drift over 1.6 yr. We show that HD 206893 B cannot be the source of this observed RV drift as it would lead to a dynamical mass inconsistent with its photometry and spectra and with HIPPARCOS and Gaia data. An additional inner (semimajor axis in the range 1.4–2.6 au) and massive (∼15 M_{J}) companion is needed to explain the RV drift, which is compatible with the available astrometric data of the star, as well as with the VLT/SPHERE and VLT/NaCo nondetection.
Key words: techniques: radial velocities / techniques: high angular resolution / astrometry / brown dwarfs / binaries: close
© A. Grandjean et al. 2019
Open Access article, published by EDP Sciences, under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
1. Introduction
Owing to their wide separations from their host stars (>20 au), dynamical masses of directly imaged planet and brown dwarf (BD) companions are difficult to measure. Thus, most of the current mass estimates for these companions rely on evolutionary models. These models still require qualibration, especially at young ages. Such calibrations can be performed using systems for which the companion mass is independently measured.
Indirect measurements of the host star can also provide important constraints on companion properties. In particular, measuring the radial velocity (RV) of a host star enables measurement or at least a constraint on the dynamical mass, M_{c} sin i, of a companion. Calissendorff & Janson (2018), Snellen & Brown (2018), and Dupuy et al. (2019) demonstrated that HIPPARCOS and Gaia measurements of the proper motion of a host star can also be used to better constrain the dynamical mass of its companion.
HD 206893 is a nearby F5V star, located at (Gaia Collaboration 2018). Zuckerman & Song (2004) estimated an age between 0.2 and 2 Gyr, which was later refined to by Delorme et al. (2017) using Desidera et al. (2015) method. Additional characteristics of the stars are presented in Table 1.
HD 206893 stellar parameters.
Milli et al. (2017) discovered a BD companion around HD 206893 via direct imaging using the Highcontrast Exoplanet REsearch (SPHERE) instrument (Beuzit et al. 2008) and the NaCo instruments at the Very Large Telescope (VLT). The companion has a projected separation of 270 mas (11 au). The star also appears to host a barely resolved disk inclined by 40 ± 10° from poleon. From their data taken in 2015–2016, Milli et al. (2017) estimated a period of ∼37 yr, in the case of low eccentricity, and the mass of the companion from models in the range 24 to 73 M_{J}, for a corresponding age in the range 0.2 to 2 Gyr. Using these data and VLT/SPHERE epochs taken in 2016, Delorme et al. (2017) refined the orbital parameters, finding a period P of ∼27 yr and mass M_{c} between 12 and 50 M_{J} for a corresponding age in the range 50−700 Myr. As the age of the system is poorly known, the estimated mass of HD 206893 B, derived from brightnessmass relations, is still poorly constrained.
We report on the High Accuracy Radial velocity Planet Searcher (HARPS) observations of HD 206893, which reveal an RV drift and two new VLT/SPHERE datasets. The data are presented in Sect. 2, and the analysis of the RV is presented in Sect. 3. In Sect. 4 we use high contrast direct imaging observations to constrain the orbit of HD 206893 B. In Sect. 5 we combine high contrast direct imaging and RV observations to constrain the orbit and dynamical mass of HD 206893 B. In Sect. 6 we combine high contrast direct imaging, RVs, and proper motion data of the host star from HIPPARCOS and Gaia (presented in Sect. 2.3) to fully constrain the system. Finally, we discuss our results in Sect. 7.
2. Data
2.1. Radial velocities
HD 206893 was observed over a 1.6 year timespan, between October 2016 and May 2018 with HARPS (La Silla, ESO) (Mayor et al. 2003), as part of our Young Nearby Stars survey (YNS; Lagrange et al. 2013). A total of 66 spectra were obtained with a sun altitude below −10°. We use our Spectroscopic data via analysis of the Fourier Interspectrum RVs (SAFIR) software (Galland et al. 2005) to compute the RVs, which are shown in Fig. 1a.
Fig. 1. Left: HARPS RV variations of HD 206893 over a 700 day period, Top right corner: zoom on shortterm variations. Right: position of HD 206893 B relative to the host star, as measured with VLT/SPHERE and VLT/NaCo at different epochs.

Open with DEXTER
2.2. Direct imaging astrometry
In this paper, we used all epochs obtained for HD 206893 with VLT/SPHERE in InfraRed Dual Imaging and Spectrograph (IRDIS) mode and with VLT/NaCo. Milli et al. (2017) obtained the first epochs in 2015 and 2016. Then, as part of the SpHere INfrared survey for Exoplanets (SHINE) survey (Chauvin et al. 2017), HD 206893 was observed with SPHERE in September 2016, whose results are reported in Delorme et al. (2017). Finally, HD 206893 was observed two more times with SPHERE in 2017, as part of the followup of the SPHERE HighAngular Resolution Debris Disk Survey (SHARDDS; Milli et al. 2017), and in 2018, as part of the SHINE survey.
The data were reduced and calibrated as described in Maire et al. (2016) and Delorme et al. (2017). Table 2 summarizes the observational set up and the measured positions of the companion. The companion positions are presented in Fig. 1b. The last epoch shows a curvature of the trajectory, which is promising for further orbital characterization of the companion.
Astrometry: separation and position angle of HD 206893 B.
2.3. HIPPARCOS and Gaia proper motion
Proper motion and position measurements for HD 206893 are available from both the HIPPARCOS (van Leeuwen 2007) and Gaia (Gaia Collaboration 2018) missions, with a time baseline of 24 years between the two missions.
HIPPARCOS and Gaia probe the position of the photocenter of the system, which is not the same as the barycenter of the system. Once corrected from the difference in position of the star induced by the companion, the proper motion deduced from the difference of position between HIPPARCOS and Gaia measurements corresponds to the proper motion of the barycenter of the system. The difference between the proper motion as measured by HIPPARCOS and Gaia and the barycenter proper motion provides information on the variation of the tangential velocity over the duration of both datasets (two years for HIPPARCOS, more than two years for Gaia).
These measurements thus constrain both the orientation of the orbit and the dynamical mass of the companion because the impact of the companion on the proper motion of the star should be within the uncertainties of the measurements. Snellen & Brown (2018) and Dupuy et al. (2019) have provided an example of such constraints gained by combining HIPPARCOS and Gaia measurements with direct imaging and RV constraints for the planet β Pic b.
Both the HIPPARCOS and Gaia fiveparameter solutions are well behaved for HD 206893 (see Appendix D.1). We present the proper motion measured by HIPPARCOS and Gaia and the proper motion deduced from the difference of position in Table 3.
HIPPARCOS2 and Gaia DR2 proper motion and proper motion deduced from the difference of position.
3. Radial velocity analysis
The RVs show a strong dispersion due to high frequency variations (hereafter HF). In addition, a linear trend is clearly present (see Fig. 1).
The HF variations seem to have periods slightly less than one day (see Fig. 1a), which is consistent with the photometric variations reported in Delorme et al. (2017). Given the star’s spectral type of F5V, the variations could a priori either be due to pulsations or spots. The bisector velocity span (BVS; Queloz et al. 2001) versus RV diagram shows a vertical spread on the 2018 observations and our last epoch shows sinusoidal variations over one hour (see Fig. 2). Such a short timescale indicates that the HF variations are due to pulsations rather than magnetic activity. Additionally, vertical (BVS,RV) spread also indicates pulsations rather than spots because spots usually produce a correlation between RV and BVS (see examples in Lagrange et al. 2009, 2013).
Fig. 2. HD 206893 RV variations on JD 2458249.

Open with DEXTER
A linear regression gives a slope of 92 m s^{−1} yr^{−1} for the trend. However, because of the very poor data sampling in 2017, coupled with high amplitude stellar variations, the slope is not well constrained. Binning the RV would also lead to a poor estimation of the slope.
To better constrain the slope of the trend, we used a genetic algorithm that fits the RV variations with a sum of 3 sine functions with periods between 0.5 an 2 days to fit the pulsations plus a linear slope to fit the longterm RV variations and an offset to account for the fact that the RV are relative to a reference spectrum (Galland et al. 2005). Fitting three sine function components provides a good overall fit without overfitting. We used 500 different seeds to estimate the uncertainties associated with the fit. We obtained a median slope of and a median offset of . Given the resulting (offset,slope) distribution, we can associate to each date a distribution of RV with a linear model. We present this RV distribution in Figure 3. Our RV observations fit broadly into three distinct time epochs. For each of these epochs, we estimated the corresponding RV of the drift and its 1−2σ errorbar from the median of the RV distribution and its 1−2σ limits at the mean date of the epoch. The resulting RVs are presented in red in Fig. 3. We use these RVs in the rest of the study.
Fig. 3. RV drifts solutions deduced from the fit of the pulsations (blue) and deduced RV (red). The original RV are plotted in black.

Open with DEXTER
4. Direct imaging astrometry
To constrain the orbital parameters of the BD we fit the astrometry of the companion using a Bayesian approach. We used the model described in Bonnefoy et al. (2014) based on the six orbital parameters to compute the astrometric position of the companion. This model was implemented into the likelihood function used by the python implementation of the Affine Invariant Markov chain Monte Carlo (MCMC) Ensemble sampler emcee (ForemanMackey et al. 2013; Goodman & Weare 2010). We describe the parameters and our priors in Appendix E.1.
We present the results of the MCMC run in Fig. A.1, and the 1−2σ intervals in Table 4. At the end of the MCMC run, the median reduced χ^{2} of the chain is 1.1, with a standard deviation of 0.4, ensuring that the data are well fit by the model. We find a period consistent within 1σ with 27 yr period estimated by Delorme et al. (2017); in our results P is in the range 21−33 yr. The orbit is most likely eccentric, between 0 and 0.5, and has a maximum of probability at 0.37. We find an inclination in the range 20−41° from poleon, which is consistent with the inclination of the disk, i.e., i_{Disk} = 40 ± 10°, and the inclination of the equatorial plane of the star, i.e., i_{*} = 30 ± 5°. The orbit of the BD is then likely coplanar with the disk and in the equatorial plane of its host star. We note a strong degeneracy between period and inclination. We also find a degeneracy between inclination and eccentricity and between the period and eccentricity. We do not discriminate between extended and inclined circular orbits and shorter, eccentric and close to poleon orbits.
1σ and 2σ intervals of the orbital parameters of HD 206893 B estimated by the MCMC on the companion astrometry alone.
5. Direct imaging astrometry and RV analysis
To constrain the dynamical mass of the BD, we assumed that the observed companion was responsible for the RV drift then fit the combined RV, presented in Sect. 3, and direct imaging data with a MCMC. Our approach is similar to that used by Bonnefoy et al. (2014) on β Pic b. We used the six orbital parameters, the mass of the BD, and an offset in the RV in our orbital fit. This model was implemented into the likelihood function of our MCMC. We describe the parameters and our priors in Appendix E.2.
We present the results of the MCMC run in Appendix B. At the end of the MCMC run, the median reduced χ^{2} of the chain is 1.1, with a standard deviation of 0.4, ensuring that the data are well fit by the model. We find similar orbital parameters compared to the fit on the astrometric position of the companion alone. The dynamical mass is now constrained, essentially between 60 and 720 M_{J} (2σ) with a maximum of probability at 140 M_{J}. This mass is incompatible at 2σ with the 12−50 M_{J} mass inferred from its observed photometry and spectra by Delorme et al. (2017).
6. Direct imaging astrometry, RV, and star proper motion analysis
The proper motion induced by HD 206893 B during HIPPARCOS and Gaia observations should be consistent with the difference between the proper motion measured by HIPPARCOS and Gaia and the barycenter proper motion. The HIPPARCOS and Gaia measurements provide mass constraints complementary to those from the RV observations, as the observed proper motion traces the tangential velocity of the star induced by the BD. HIPPARCOS and Gaia astrometry also yields information on the orientation of the orbit and is thus complementary to direct imaging astrometry as well.
None of the solutions at the end of the MCMC on the companion relative astrometry and RV fit HIPPARCOS or Gaia measurements in right ascension and declination, as the amplitude of the tangential velocity is too high (see Fig. B.3).
We add the model to compute the proper motion induced by the companion and the reference proper motion in the likelihood function of the MCMC (see Appendices D.3 and D.2). We describe the parameters and our priors in Appendix E.3. Then, we run the MCMC with the direct imaging astrometric data, the three RV epochs presented in Sect. 3 and the proper motion measured by HIPPARCOS and Gaia. The results are presented in Appendix C. At the end of the MCMC run, the median reduced χ^{2} of the chain is 3.4; the standard deviation is 0.5, which is significantly worse than the results on relative astrometry and RV. The median χ^{2} on the RV data is six times higher than for the solutions of the MCMC on the direct imaging astrometry and RV. We find a mass of , which is consistent at 1σ with the mass inferred from the photometry and spectra of HD 206893 B by Delorme et al. (2017); this result favors the hypothesis of young ages. This indicates that HIPPARCOS and Gaia are probing the dynamical influence of the BDs but not the RVs.
However, the median χ^{2} on the companion astrometry is slightly worse than for the solutions of the MCMC on the direct imaging alone, but not significantly. Moreover, HIPPARCOS and Gaia proper motion are well fitted except for the Gaia proper motion in RA that is not fitted because the HD 206893 B tangential velocity contribution in RA was null during Gaia observations. We also find longer periods, P between 35 and 54 years with a maximum at 39 years, which are only consistent at 2σ with the periods found in Sect. 4. Adding HIPPARCOS and Gaia constraints favors lower eccentricities, with a maximum at 0.14, and orbits misaligned with the star equator plane, about from poleon. In order to fit HIPPARCOS and Gaia data, the MCMC selected results that fit the companion astrometry less well and therefore were discarded by the MCMC done in Sects. 4 and 5, which shows that HIPPARCOS and Gaia data do not probe the dynamical influence of the BD only.
7. Discussion
Assuming that the RV drift in the RV of HD 206893 is due to HD 206893 B leads to a mass that is incompatible at 2σ with the 12−50 M_{J} mass inferred from its observed photometry and spectra by Delorme et al. (2017) and with HIPPARCOS and Gaia proper motion measurements.
An additional inner body that would contribute significantly to the observed RV drift and the tangential velocity in RA is needed. Its orbital period should be larger than our time baseline of 1.6 yr (1.4 au). We used the following formula from Lazzoni et al. (2018) for the width of the chaotic zone around a planet to estimate the third body’s semimajor axis a_{crit} beyond which the system is not stable:
where a_{B} is the first companion semimajor axis, e_{B} is its eccentricity, and μ is the mass ratio of the first companion to the star. Using the characteristics of HD 206893 AB estimated by Delorme et al. (2017), M_{*} = 1.32 M_{⊙}, M_{c} = 22 M_{J}, e = 0.31 and a_{B} between 8 and 10 au, we obtain a critical semimajor axis between 2.1 and 2.6 au, which corresponds to periods between 3 and 4 yr and to an angular separation on the sky between 50 and 60 mas. The critical semimajor axis can be underestimated because the presence of the inner companion induces a wobble of the host star, which produces a bias on the relative positions of the BD toward the host star and thus produces a bias on the eccentricity of its orbit (Pearce et al. 2014). To constrain the properties of the inner body, we used a MCMC to fit the RV alone with a sinusoid (e = 0) and for the inclination of the star: i = 30° from poleon, leaving free the phase, mass of the second companion, and period between 1.6 and 4 yr. The fit converges to a mass of 15 M_{J}. Such a mass would lead to a contrast lower than 10^{−4} in the near infrared. Given the expected contrast and the upper limit on the separation, it is not possible to detect this body with VLT SPHERE. This third body can be compatible with the HIPPARCOS and Gaia constraint as its period is close to their time baseline; the impact of this third body on the proper motion of the star is then averaged.
HIPPARCOS and Gaia data imply a dynamical mass of for HD 206893 B. This low mass is compatible with an age for the system lower than 50 Myr. Its probability of membership to the Argus association is higher than previously estimated. It would also explain the low luminosity of the BD compared to the models and its redness reported by Delorme et al. (2017). However, we note that this mass can be under or overestimated as the presence of the second companion could impact on the star tangential velocity. More RV and direct imaging data are needed to further constrain both companions of HD 206893 system.
Acknowledgments
We acknowledge support from the French CNRS and from the Agence Nationale de la Recherche (ANR grant GIPSE ANR14CE330018). Part of the observations were performed under SHINE GTO time. These results have made use of the SIMBAD database, operated at the CDS, Strasbourg, France. The authors thank Philippe Delorme and Eric Lagadec (SPHERE Data Center) for their help with the data reduction. We acknowledge financial support from the Programme National de Planétologie (PNP) and the Programme National de Physique Stellaire (PNPS) of CNRSINSU. This work has also been supported by a grant from the French Labex OSUG@2020 (Investissements d’avenir – ANR10 LABX56). The project is supported by CNRS. This work has made use of the SPHERE Data Centre, jointly operated by OSUG/IPAG (Grenoble), PYTHEAS/LAM/CeSAM (Marseille), OCA/Lagrange (Nice), and Observatoire de Paris/LESIA (Paris). SPHERE is an instrument designed and built by a consortium consisting of IPAG (Grenoble, France), MPIA (Heidelberg, Germany), LAM (Marseille, France), LESIA (Paris, France), Laboratoire Lagrange (Nice, France), INAF – Osservatorio di Padova (Italy), Observatoire astronomique de l’Université de Genève (Switzerland), ETH Zurich (Switzerland), NOVA (Netherlands), ONERA (France), and ASTRON (Netherlands), in collaboration with ESO. SPHERE was funded by ESO, with additional contributions from the CNRS (France), MPIA (Germany), INAF (Italy), FINES (Switzerland), and NOVA (Netherlands). SPHERE also received funding from the European Commission Sixth and Seventh Framework Programs as part of the Optical Infrared Coordination Network for Astronomy (OPTICON) under grant number RII3Ct2004001566 for FP6 (2004–2008), grant number 226604 for FP7 (2009–2012), and grant number 312430 for FP7 (2013–2016). This work has been supported by a grant from Labex OSUG@2020 (Investissements d’avenir – ANR10 LABX56). C. P. acknowledges support from the ICM (Iniciativa Científica Milenio) via the Núcleo Milenio de Formación Planetaria grant. C. P. acknowledges financial support from Fondecyt (grant 3190691).
References
 Beuzit, J. L., Feldt, M., Dohlen, K., et al. 2008, in Groundbased and Airborne Instrumentation for Astronomy II, Proc. SPIE, 7014, 701418 [CrossRef] [Google Scholar]
 Bonnefoy, M., Marleau, G.D., Galicher, R., et al. 2014, A&A, 567, L9 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Calissendorff, P., & Janson, M. 2018, A&A, 615, A149 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Chauvin, G., Desidera, S., Lagrange, A. M., et al. 2017, in SF2A2017: Proceedings of the Annual Meeting of the French Society of Astronomy and Astrophysics, eds. C. Reylé, P. Di Matteo, F. Herpin, et al., 331 [Google Scholar]
 Delorme, P., Schmidt, T., Bonnefoy, M., et al. 2017, A&A, 608, A79 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Desidera, S., Covino, E., Messina, S., et al. 2015, A&A, 573, A126 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Dupuy, T. J., Brandt, T. D., Kratter, K. M., & Bowler, B. P. 2019, ApJ, 871, L4 [NASA ADS] [CrossRef] [Google Scholar]
 ForemanMackey, D., Hogg, D. W., Lang, D., & Goodman, J. 2013, PASP, 125, 306 [NASA ADS] [CrossRef] [Google Scholar]
 Gaia Collaboration (Brown, A. G. A., et al.) 2018, A&A, 616, A1 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Galland, F., Lagrange, A. M., Udry, S., et al. 2005, A&A, 443, 337 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Goodman, J., & Weare, J. 2010, Appl. Math. Comput. Sci., 5, 65 [Google Scholar]
 Høg, E., Fabricius, C., Makarov, V. V., et al. 2000, A&A, 355, L27 [Google Scholar]
 Lagrange, A. M., Desort, M., Galland, F., Udry, S., & Mayor, M. 2009, A&A, 495, 335 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lagrange, A.M., Meunier, N., Chauvin, G., et al. 2013, A&A, 559, A83 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lazzoni, C., Desidera, S., Marzari, F., et al. 2018, A&A, 611, A43 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lindegren, L., Hernández, J., Bombrun, A., et al. 2018, A&A, 616, A2 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Maire, A. L., Bonnefoy, M., Ginski, C., et al. 2016, A&A, 587, A56 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Mayor, M., Pepe, F., Queloz, D., et al. 2003, The Messenger, 114, 2 [Google Scholar]
 Milli, J., Hibon, P., Christiaens, V., et al. 2017, A&A, 597, L2 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Pearce, T. D., Wyatt, M. C., & Kennedy, G. M. 2014, MNRAS, 437, 2686 [NASA ADS] [CrossRef] [Google Scholar]
 Queloz, D., Henry, G. W., Sivan, J. P., et al. 2001, A&A, 379, 279 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Snellen, I. A. G., & Brown, A. G. A. 2018, Nat. Astron., 2, 883 [NASA ADS] [CrossRef] [Google Scholar]
 van Leeuwen, F. 2007, A&A, 474, 653 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Zuckerman, B., & Song, I. 2004, ARA&A, 42, 685 [NASA ADS] [CrossRef] [MathSciNet] [Google Scholar]
Appendix A: MCMC results on direct imaging astrometry
Fig. A.1. Estimated probability distributions of the orbital parameters HD 206893 B obtained with the direct imaging astrometry data.

Open with DEXTER
Fig. A.2. HD 206893 B orbit solutions at the end of the MCMC on the direct imaging astrometry alone (black) compared to the observations (red).

Open with DEXTER
Appendix B: MCMC results on direct imaging astrometry and RV
Fig. B.1. Estimated probability distributions of the orbital parameters and RV parameters of HD 206893 B obtained with direct imaging astrometry data, and the RV drift estimated from the fit of the pulsations described in Sect. 3.

Open with DEXTER
Fig. B.2. HD 206893 B orbit and RV solutions at the end of the MCMC on direct imaging astrometry and RV (black) compared to the observations (red).

Open with DEXTER
Fig. B.3. HD 206893 B tangential velocity corresponding to the solutions at the end of the MCMC on direct imaging astrometry and RV (black) compared to the proper motion measured by HIPPARCOS and Gaia after removing the photocenter proper motion measured by HIPPARCOS and Gaia, presented at the mean time of their observations (red).

Open with DEXTER
Appendix C: MCMC results on direct imaging astrometry, RV, and proper motion
Fig. C.1. Same as Fig. B.1 adding proper motion constraints as described in Sect. 2.3.

Open with DEXTER
Fig. C.2. HD 206893 B orbit and RV solutions at the end of the MCMC on direct imaging astrometry, RV, and proper motion (black) compared to the observations (red).

Open with DEXTER
Fig. C.3. HD 206893 B tangential velocity solutions at the end of the MCMC on direct imaging astrometry, RV, and proper motion (black) compared to the proper motion measured by HIPPARCOS and Gaia after removing the photocenter proper motion measured by HIPPARCOS and Gaia, presented at the mean time of their observations (red).

Open with DEXTER
Appendix D: HIPPARCOS and Gaia data exploitation
D.1. HIPPARCOS and Gaia data correction
We used HIPPARCOS2 (van Leeuwen 2007) and Gaia DR2 (Gaia Collaboration 2018) proper motion and position measurements of HD 206893 for our analysis. First we verified that both HIPPARCOS and Gaia 5parameter solutions are well behaved for HD 206893. The goodness of fit parameter F2 is 0.71 for the HIPPARCOS reduction and the renormalized unit weight error^{1} (Hereafter ruwe) is 1.1 for Gaia, which ensures that the fiveparameter solutions are relevant.
Then we corrected the HIPPARCOS and Gaia proper motions measures from systematics. The global rotation between the Gaia and HIPPARCOS proper motions, which takes into account systematics on both sides (Lindegren et al. 2018), was corrected for w_{X} = −0.011, w_{Y} = 0.265, w_{Z} = 0.127. We quadratically added an extra error of 0.5 mas yr^{−1} on HIPPARCOS proper motion errors and we rescaled the Gaia DR2 proper motion errors and the errors on the proper motion deduced from the difference of position by a factor 1.4. The rotations and errors inflations have been derived from the distributions of well behaved Gaia DR2 and HIPPARCOS sources (e.g., sources not already flagged as binaries in Simbad, with an HIPPARCOS F2 < 5, a Gaiaruwe < 1.4 and proper motions compatible within 5σ). However, unresolved binaries are still expected to be present with this selection and our error inflations are therefore conservative.
D.2. Barycenter proper motion determination
To compute the proper motion of the barycenter of the system we must correct the proper motion deduced from the difference of position between HIPPARCOS and Gaia measurements (photocenter proper motion) by the effect of the star position induced by the companion.
The position of the star induced by the companion compared to the barycenter of the system on the sky at a time t is
where X_{c}(t) and Y_{c}(t) are the coordinates of the companion on the sky in Dec and RA, respectively, M_{c} and M_{*} are the mass of the companion and mass of the star; d is the distance of the star in pc.
As the measurements of HIPPARCOS and Gaia DR2 are each based on a twoyear timespan, we computed the mean of the positions induced by the companion compared to the barycenter of the system over the corresponding timespans.
We used the times of HIPPARCOS observations available in the HIPPARCOS2 catalog (van Leeuwen 2007). The specific times of observations of Gaia are not published yet. We then took 62 times that were equally spaced between the start and the end of Gaia measurements, i.e., 25 July 2014 and 23 May 2016, respectively (Gaia Collaboration 2018).
The barycenter proper motion is then
D.3. Proper motion induced by the companion model
We present our model to compute the proper motion induced by the companion at HIPPARCOS and Gaia measurement. First, we computed the orbital speed of the companion in the plane of its orbit at a time t (in au yr^{−1}) as follows:
where P is the period in year, a the semimajor axis in au, the eccentricity e, and the eccentric anomaly E of the orbit.
The orbital speed is then projected on the plane of the sky as follows:
where ω is the argument of periapsis in radian, Ω the longitude of the ascending node in radian, and i the inclination of the orbit in radian.
Finally, the star proper motion induced by the companion in as yr^{−1} is
where M_{c} and M_{*} are the mass of the companion and the mass of the star and d is the distance of the star in pc.
As the measurements of HIPPARCOS and Gaia DR2 are each based on a twoyear timespan we computed the mean of the theoretical proper motions over the corresponding timespans.
We used the times of HIPPARCOS observations available in the HIPPARCOS2 catalog (van Leeuwen 2007). The specific times of observations of Gaia are not published yet. We then took 62 times that were equally spaced between the start and the end of Gaia measurements, i.e., 25 July 2014 and 23 May 2016, respectively (Gaia Collaboration 2018).
Appendix E: MCMC inputs
E.1. MCMC on the direct imaging astrometry
We modeled the observations by a Keplerian orbit projected on the sky. The likelihood function is a centered and reduced Gaussian of the χ^{2} function between the model and the observations. The logarithm of our likelihood function is
where y are the observations, σ their corresponding variances, and f(X) the model for parameters X.
To facilitate the convergence of the MCMC we chose the following parameters:

log P: the decimal logarithm of the period in years;

f_{TP}: a factor for which the time at the periastron is computed, i.e., TP = f_{TP} × P. In this study the TP is in years and corresponds to the closest periastron passage from the first direct imaging epoch;

e: the eccentricity;

i: the inclination in radian, 0° and 90° correspond to poleon and edgeon orbit, respectively;

Ω: the longitude of the ascending node in radian;

ω: the argument of periapsis in radian.
We used the same model as Bonnefoy et al. (2014), which works on a combination of the parameters presented above.
We used uniform priors in the following intervals:

0.5 < log P ≤ 3;

−0.5 ≤ f_{TP} ≤ 0.5;

0 < e < 1;

−2π < Ω < 2π;

0 < ω < 4π.
Elsewhere, the prior is null. For the inclination, we took a prior that is the product of a uniform prior in cos(i) and a uniform prior in inclination in the range 0 < i < π.
E.2. MCMC on the direct imaging astrometry and RV
We added to the model a Keplerian in RV to model both the astrometry of the companion and the RV. The likelihood function becomes
where y are the observations, σ their corresponding variances, and f(X) the model for parameters X.
To facilitate the convergence of the MCMC we chose additional parameters as

M_{c}: the mass of the companion in M_{J};

f_{V0}: a factor for which the offset in RV are computed, V_{0} = f_{V0} × K(M_{c}, P, e), with K the semiamplitude of the RV.
We used the same model as Bonnefoy et al. (2014), which works on a combination of the parameters presented above.
We used uniform priors for the additional parameters in the following intervals:

1 < M_{c} ≤ 1000

−1 ≤ f_{V0} ≤ 1.
Elsewhere, the prior is null.
E.3. MCMC on the direct imaging astrometry and RV and proper motion
We added to the model the tangential velocity model described in Appendix D.3 and the barycenter proper motion model described in Appendix D.2 to fit the difference between the proper motion measured by HIPPARCOS and Gaia and the barycenter proper motion. The likelihood becomes
where y are the observations, σ their corresponding variances, and f(X) the model for parameters X.
We used the parameters and prior described in Appendix E.2.
E.4. Description of the MCMC runs
We used emcee with the prior and likelihood function as described in Appendices E.1 and E.2.
In order to facilitate the convergence, we ran two MCMC for each analysis described in Sects. 1, 5 and 6. We ran the first MCMC with 100 walkers that were initialized randomly with a uniform probability distribution for each parameter in the intervals of their prior for 100 000 iterations. Then a second MCMC was performed with 100 walkers initialized with a uniform probability distribution for each parameter in the intervals where the majority of the walkers of the first run were converging. This approach permits us to check the uniqueness of the solution.
To ensure convergence, as our problem show a multimodal posterior, we verified that the number of iterations was greater than ten times the autocorrelation time of the chain for each parameters (ForemanMackey et al. 2013).
All Tables
HIPPARCOS2 and Gaia DR2 proper motion and proper motion deduced from the difference of position.
1σ and 2σ intervals of the orbital parameters of HD 206893 B estimated by the MCMC on the companion astrometry alone.
All Figures
Fig. 1. Left: HARPS RV variations of HD 206893 over a 700 day period, Top right corner: zoom on shortterm variations. Right: position of HD 206893 B relative to the host star, as measured with VLT/SPHERE and VLT/NaCo at different epochs.

Open with DEXTER
In the text
Fig. 2. HD 206893 RV variations on JD 2458249.

Open with DEXTER
In the text
Fig. 3. RV drifts solutions deduced from the fit of the pulsations (blue) and deduced RV (red). The original RV are plotted in black.

Open with DEXTER
In the text
Fig. A.1. Estimated probability distributions of the orbital parameters HD 206893 B obtained with the direct imaging astrometry data.

Open with DEXTER
In the text
Fig. A.2. HD 206893 B orbit solutions at the end of the MCMC on the direct imaging astrometry alone (black) compared to the observations (red).

Open with DEXTER
In the text
Fig. B.1. Estimated probability distributions of the orbital parameters and RV parameters of HD 206893 B obtained with direct imaging astrometry data, and the RV drift estimated from the fit of the pulsations described in Sect. 3.

Open with DEXTER
In the text
Fig. B.2. HD 206893 B orbit and RV solutions at the end of the MCMC on direct imaging astrometry and RV (black) compared to the observations (red).

Open with DEXTER
In the text
Fig. B.3. HD 206893 B tangential velocity corresponding to the solutions at the end of the MCMC on direct imaging astrometry and RV (black) compared to the proper motion measured by HIPPARCOS and Gaia after removing the photocenter proper motion measured by HIPPARCOS and Gaia, presented at the mean time of their observations (red).

Open with DEXTER
In the text
Fig. C.1. Same as Fig. B.1 adding proper motion constraints as described in Sect. 2.3.

Open with DEXTER
In the text
Fig. C.2. HD 206893 B orbit and RV solutions at the end of the MCMC on direct imaging astrometry, RV, and proper motion (black) compared to the observations (red).

Open with DEXTER
In the text
Fig. C.3. HD 206893 B tangential velocity solutions at the end of the MCMC on direct imaging astrometry, RV, and proper motion (black) compared to the proper motion measured by HIPPARCOS and Gaia after removing the photocenter proper motion measured by HIPPARCOS and Gaia, presented at the mean time of their observations (red).

Open with DEXTER
In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
