1. Introduction

The majority of the γ-ray sources detected by the Fermi/LAT instrument are associated with the so-called blazars, a type of active galactic nuclei (AGNs) with powerful jets pointing almost directly at us (Acero et al. 2015; Ackermann et al. 2015). The blazar population is made up by two subclasses of objects: the flat-spectrum radio quasars (FSRQs) and the Bl Lac objects. The former present a prominent environment surrounding the jet, including dense, high-velocity clouds located at the broad-line region (BLR). This work focuses on a mechanism that may contribute to the observed high-energy γ-ray (HE) emission from FSRQs.

The spectral energy distribution (SED) of a blazar typically consists of two broad “humps”, one at low energies (that extend to X-rays at most), presumably synchrotron in nature, and one in γ rays, most likely produced by inverse Compton (IC) radiation1. A detailed study of the emission properties of the blazar population detected by Fermi has been recently published by Ghisellini et al. (2017). Based on their analysis of the SED of 448 Fermi FSRQs, they report the following behavior in γ rays: i) the Compton dominance (i.e. the ratio between the γ-ray and the synchrotron emission) increases with the blazar luminosity from 0.5 for Lγ ∼ 1044 to 15 for Lγ ∼ 1048; ii) the γ-ray slope is almost constant; and iii) the Compton peak frequency varies slightly from 5 × 1021 to 9 × 1020 Hz (i.e. from ∼21 to 4 MeV) for an increase in luminosity of 4 orders of magnitude. Here we investigate the γ-ray emission, focusing in particular on the HE range, for the scenario of a jet-BLR cloud interaction (JCI) in a blazar (e.g. Barkov et al. 2012a; Khangulyan et al. 2013; Aharonian et al. 2017). Araudo et al. (2010) showed that BLR clouds can penetrate inside the AGN relativistic jet leading to the formation of strong shocks, in which non-thermal (NT) particles can accelerate through diffusive shock acceleration (DSA) and generate γ-ray emission (for similar scenarios, also see e.g. Dar & Laor 1997; Beall & Bednarek 1999; Beall et al. 2002). We consistently model the dynamics of this interaction, the evolution of the NT particle population in the emitting cloud (i.e. the shocked jet material surrounding the shocked cloud), and its expected γ-ray output, including Doppler boosting effects. The γ-ray emission from external Compton (EC) interactions of relativistic electrons in the jet with BLR photons has been studied by several authors (e.g. Tavecchio & Ghisellini 2008; Finke 2016). In such works neither the nature of the dynamical mechanism leading to the acceleration of NT particles nor its evolution is specified. Thus, here we aim to explore the role of the JCI scenario as a potential contributor to the overall blazar HE emission. Our findings can be put in contrast with the recent results by Costamante et al. (2018) who suggest that the role of the BLR in blazar γ-ray emission is rather minor.

2. Physical scenario

The BLR has a large number of relatively dense clouds that can possibly penetrate into the jet. As shown by Araudo et al. (2010), the cloud volume takes only a short timescale to fully enter the jet, and the impact of the relativistic jet on the cloud surface leads to the formation of two shocks. One shock propagates in the cloud, whereas the other (the bow-shock) propagates in the jet material; the latter is suitable for the acceleration of NT particles that can produce high-energy radiation2. A sketch is presented in Fig. 1.

thumbnail Fig. 1.

Schematic representation of the BLR, the JCIs, and some of the relevant quantities defined in Sect. 3.1.

Open with DEXTER

Neither the formation process of the BLR nor its geometry are clearly understood. Several works favour a spherical geometry for the BLR (Kaspi & Netzer 1999; Kaspi et al. 2005, 2007; Liu & Bai 2006), whereas others consider a bowl-like geometry (Gaskell 2009; Goad et al. 2012). Grier et al. (2013) presented observations that are compatible with inflows and outflows from either an inclined disc or a spherical shell geometry. In general, both the number density of clouds (Nc) and their size (Rc, 0) are considered to depend on the radial distance as Nc ∝ rp, with p = 1.5 − 2, and Rc, 0 ∝ rq, q = 1/3 − 1, depending on the geometry. Typical values of the size and density of the BLR clouds are Rc, 0 ∼ 1013 cm and nc, 0 ∼ 1010 − 11 cm−3 (e.g. Netzer 2015, and references therein).

For simplicity, in this work we assume that the BLR is spherical and with an outer radius RBLR of which the clouds fill only a small fraction of the volume. We further assume that all BLR clouds have a similar size and density, fixing Rc, 0 = 1013 cm and nc, 0 = 1010 cm−3. From these considerations, the total number of BLR clouds is Nc, tot ≳ 106 for RBLR ≳ 1017 cm (see also Dietrich et al. 1999), and the cloud mass (assuming hydrogen), Mc = 7 × 1025 g. A further analysis regarding the implications of the size and spatial distribution of the BLR clouds is discussed in Sect. 5. The BLR radiation field can be regarded as isotropic within RBLR given that the number of clouds is very large, and assuming that they are distributed uniformly inside the BLR (e.g. Donea & Protheroe 2003).

In our simplified scenario, the properties of the BLR are determined by its outer radius RBLR and its luminosity LBLR. Most of the emission produced by the BLR is a reflection of the disc photons that ionise and excite the atoms in the BLR. It is then sensible to assume that the BLR luminosity, LBLR, is a fraction of the disc luminosity, Ld. Moreover, the jet power also scales with the disc luminosity as , where a ≈ 1 (e.g. Ghisellini et al. 2014) and LBLR ≈ 0.5 − 0.1Lj (Ghisellini & Tavecchio 2009). The size of the BLR is related to the BLR luminosity as . We note that the adopted value of a affects the feasibility of JCIs: values of α >  1 (e.g. Zhang et al. 2015) make it more likely that BLR clouds penetrate powerful jets since JCIs require that RBLR >  zmin (see Eq. (1) and Sect. 3.1).

3. Cloud dynamics and non-thermal processes

In this section we present the formulas used in the calculation of the dynamical quantities, and our radiative code. We focus here on leptonic processes, namely synchrotron and IC, as in this particular scenario the target densities are too low for relativistic Bremsstrahlung, proton-proton emission, and photo-meson production to be efficient, and it is difficult to accelerate protons up to energies high enough for proton synchrotron to be relevant (see e.g. Barkov et al. 2012b; Khangulyan et al. 2013, for similar scenarios with hadronic emission). Throughout this work, un-primed quantities refer to the laboratory frame (LF), primed quantities refer to the cloud (co-moving) frame (CF), and quantities with a hat refer to the observer frame (OF). The shocked fluid is assumed to move with the accelerating cloud, and therefore the shock frame is at rest with respect to the CF. We define β = v/c. We focus on the advanced stages of the JCI, which are particularly interesting for the case of blazars. The main effects to take into account are the following: i) the area of the bow-shock increases because of the expansion of the cloud inside the jet; ii) the IC cooling becomes more efficient when the cloud reaches relativistic velocities because the BLR photon field is Doppler-boosted in the CF; and iii) the emitted radiation is greatly enhanced in the OF by Doppler boosting. All these phenomena lead to a substantially larger γ-ray emission than that estimated by Araudo et al. (2010), in which relativistic effects were not considered, and the clouds were unperturbed.

3.1. Dynamics

We present here the main characteristics of a JCI and show that for conservative assumptions a JCI is likely to occur. The following quantities are required for the analysis: the BLR cloud velocity outside the jet (roughly its Keplerian velocity orbiting the central black hole: cm s−1), the initial cloud number density (nc, 0) and radius (Rc, 0); the jet luminosity (Lj), Lorentz factor (Γj), penetration height (zj), radius (Rj), density (ρj), and aspect ratio (parametrised3 as θj = Rj/zj); the disc luminosity (Ld), radius (Rd), and temperature (Td); the torus luminosity (Lt), inner radius (Rt), and temperature (Tt); and the BLR luminosity (LBLR), radius (RBLR), and characteristic temperature (TBLR). The typical values for these parameters are given in Table 1.

Table 1.

Parameters for a typical JCI.

For clouds to fully penetrate into the jet it is required that vsh <  vc, 0. If this condition is not fulfilled, the cloud becomes disrupted in the shear layer between the jet and the surrounding medium, and it is dragged along the downstream direction without penetrating further into the jet (before being significantly accelerated, so no strong direct interaction would take place). From this condition a minimum penetration height to produce a strong JCI can be derived (Araudo et al. 2010):

(1)

all quantities being in cgs units. The maximum interaction height we are interested in is zmax ≈ RBLR ≈ 3zmin, although the ratio zmax/zmin depends on Lj for a ≠ 1 (see Sect. 2). We take a location for the JCI at an average value (in terms of radiative output) of .

Once we have the initial conditions set, we can calculate the dynamical evolution of the shocked cloud inside the jet. The jet impact initially compresses the cloud in the jet direction of motion; the cloud quickly gets disrupted and begins accelerating along the jet and expanding (Perucho et al. 2017; Zacharias et al. 2017). We can calculate the shocked cloud acceleration by numerically solving a differential equation for its Lorentz factor, Γc. The quantities required in each time-step are calculated as follows. The jet radius is Rj = zcθj, and its ram pressure in the LF is . Equation (A.3) from Barkov et al. (2012a) gives the jet ram pressure in the CF:

(2)

This equation applies to a jet dominated by Poynting flux, although for a matter dominated jet the results are very similar in the relativistic regime when emission matters the most. The electromagnetic energy flux density in the jet is (Barkov et al. 2012a), and the injected power in the shock is

(3)

We consider that, to the first order, the shocked cloud can be modelled as a relatively spherical cloud that expands isotropically with a velocity equal to the sound speed in the cloud4

(4)

where h′ is specific enthalpy, ρ′ is the shocked cloud mass density, and γa = 4/3 is the adiabatic coefficient of a relativistic, monoatomic ideal gas. The cloud mass density is computed as , with , i.e. taking the cloud as spherical in the CF. The specific enthalpy is , where is the shocked cloud pressure, taken equal to the jet ram pressure in the CF (). The lateral expansion of the cloud leads to an increase in the area of the shocked section of the jet.

We solve the differential equation for Γc given by Barkov et al. (2012a) using a first-order Euler method with a non-uniform (logarithmic) step in time,

(5)

where the factor (1 − fNT) was incorporated to take into account the back-reaction due to the emission of photons: if a fraction fNT ∼ 0.1 of the injected jet power goes into relativistic particles, and most of this energy (and therefore momentum) is emitted in the direction of motion (as is the case under the JCI conditions considered), a radiation pressure ∼fNT × the total jet pressure is then exerted opposite to the cloud acceleration. The time intervals in the CF and the LF relate via dt′=dtc, whereas for the OF we have (e.g. Rybicki & Lightman 1979) d = dt(1 − βc cosθobs) = dt/(Γcδc), where θobs is the angle between the line of sight and the jet axis (considered to be equal to ; see Fig. 1) and δc = [(1−βc cos θobsc]−1 is the Doppler boosting factor. When Γc → Γj, we get δc → Γj.

Following Barkov et al. (2012a), we define the parameter D as the dimensionless inverse mass of the cloud:

(6)

Previous works, such as Barkov et al. (2012a), consider a relativistic motion of the obstacle, so D has to be derived for mildly relativistic velocities in order to be comparable with the results obtained by those authors. This means that in order to make a valid comparison, we have to evaluate Rc when the cloud has expanded and accelerated significantly. This leads to D ≳ 1 for a typical JCI, which implies a rather quick dynamical evolution of the cloud inside the jet (Khangulyan et al. 2013): the distance that the cloud travels along the jet during its evolution is smaller than RBLR. Thus, the external radiation fields typically do not change substantially with respect to those at the penetration distance. The cloud acceleration time (in the LF) is tacc, c ∼ zc, 0/(cD)∼106 s for zc, 0 ∼ 1017. The NT activity of the cloud is expected to have a narrow peak in the OF: taking the cloud Lorentz factor Γc ≲ Γj, then 0tacc,c/(δΓc) ∼ 1.5 × 104 s.

Finally, we estimate the magnetic field in the CF as Ghisellini & Tavecchio (2009) by assuming that the jet magnetic pressure is a fraction ηB of the jet ram pressure:

(7)

Throughout this work we adopt ηB = 1 as jets are expected to be rather magnetised close to their base (Khangulyan et al. 2013), but our results are not very sensitive to ηB.

3.2. Radiation fields

There are multiple radiation fields present in the inner region of blazars, such as those produced by the BLR, the torus, and the disc. Nonetheless, for an emitting relativistic cloud, moving in the direction of the jet, and located at a height z ∼ RBLR, the only relevant radiation field for IC interactions in the JCI is the one from the BLR. This can be seen by comparing the energy density of the different radiation fields (e.g. Fig. 2 in Ghisellini & Tavecchio 2009). In the CF the disc photon field is de-boosted, whereas the BLR photon field is boosted; the torus photon field is also boosted, but the energy density of the torus photon field is ∼100 times smaller than the BLR value at z ∼ RBLR. The energy density of the BLR photon field in the CF is related to the energy density in the LF via , where δBLR is the Doppler factor (e.g. Dermer & Menon 2009). The value of UBLR can be estimated as

(8)

while the value of δBLR is obtained considering an isotropic photon field in the LF such that ⟨cosθBLR⟩=0, and for simplicity is mono-directional in the CF. Under these considerations, for z <  RBLR, δBLR = Γc. In the monochromatic approximation, the number of target BLR photons is nBLR = UBLR/ϵBLR, where ϵBLR is the characteristic BLR photon energy and transforms as .

To test whether SSC losses are relevant, we estimate the energy density of the synchrotron photon field (calculated neglecting SSC) as .

3.3. Particle energy distribution

We consider that a fraction ξe = 0.1 of the available injected energy in the shock goes into accelerating relativistic electrons: . We adopt a phenomenological injection function for electrons , with α = 2, and the normalisation constant given by . The particle acceleration and cooling times are much shorter than the dynamical timescales, and therefore the particle energy distribution reaches a steady state before the cooling conditions have changed significantly. The solution for the transport equation is

(9)

with . The results of the model, in particular at HE, are not very sensitive to α unless it is well above 2, meaning little luminosity in the γ-ray band. We take a minimum electron energy at injection of , although this parameter does not significantly affect our results unless it is ≳1 GeV (see Sect. 4.2).

We calculate the IC cooling with the parametrisation given by Khangulyan et al. (2014) for an isotropic radiation field. We define the temperature of the radiation field in the CF as , and introduce the dilution factor , with σSB the Stefan-Boltzmann constant. We define the constant ), a normalised temperature , and the parameter . We calculate the IC loss time with the BLR field as , with and

(10)

The magnetic field in the shocked region is assumed to be isotropic, so that the perpendicular component of the magnetic field is (this is also taken into account when computing the synchrotron emissivity). The synchrotron losses are given by , which is accurate for an isotropic magnetic field.

The NT particles are convected by the jet material that flows along the bow-shock. For the convection and adiabatic losses we make the following consideration. As we are working under the one-zone model approximation, the relevant characteristic size in which the target fields change is of the order of zc. We thus take , where . The radiative losses dominate over the non-radiative losses if , with and . The cooling time is then .

The acceleration time for relativistic electrons is , where qe is the elementary charge, and we fix the acceleration efficiency to ηacc = 0.1. The electron maximum energy is obtained as the minimum from the condition and accounting for diffusive losses.

3.4. Non-thermal emission

We estimate the IC emission considering a monochromatic, homogeneous, and isotropic BLR photon field. In the CF, the electrons “see” that the BLR photons come from a direction given by . During the early stages of the JCI, Γc ∼ 1 and the BLR photon phield for the relativistic electrons is nearly isotropic, but for later stages with Γ >  2 (which are the more relevant ones in the context of this work), this photon field in the CF is nearly mono-directional because of relativistic effects, and the interactions of the relativistic electrons with the BLR photons proceed as (quasi) head-on collisions.

First, we calculate the emitted luminosity in the CF. The BLR photon field is characterised by the photon energy and the photon number density given in Sect. 3.2. In the monochromatic approximation, we consider ϵBLR ≈ ϵLyα ≈ 10 eV. We use the angle-dependent expression for σIC (e.g. Khangulyan et al. 2014) with an angle α′=arccos( − βc). The SED (i.e. the emitted specific luminosity) in the CF is computed as

(11)

The total luminosity at a given time is L′=∫L′(ϵ′)dϵ′. We also compute the synchrotron luminosity in the CF from the particle energy distribution. However, we do not study the synchrotron component in detail as it is very sensitive to the adopted values for ηB and (see forthcoming Sect. 4.2). We also note that we do not expect the JCIs to dominate the synchrotron emission in blazars, but instead to be a minor contribution to the overall observed flux. To properly model the synchrotron SED, additional absorption processes such as synchrotron self-absorption should be considered in Sect. 3.5. Second, we calculate the expected luminosity in the OF, which is related to the emitted luminosity in the CF as , where δc = [(1−βc cos θobsc]−1 is the Doppler boosting factor.

3.5. Absorption

The γ-ray photons emitted in the shock have to escape the AGN before reaching the observer. During their propagation, these photons can interact with ambient photons producing e± pairs, resulting in their annihilation. This absorption process is more effective when the photons interact head-on and if the ambient photon field intensity is high. As shown by several authors (Liu & Bai 2006; Finke 2016; Böttcher & Els 2016; Abolmasov & Poutanen 2017), γ rays with energies between 30 GeV and ∼TeV emitted within RBLR are completely absorbed in the BLR photon field; moreover, the torus radiation field is totally opaque for γ rays with energies exceeding a few TeV for even larger distances (Donea & Protheroe 2003). Therefore, to the first order, we can consider the γ-ray emission to be unabsorbed for ϵ ≲ 30 GeV and totally absorbed for ϵ ≳ 30 GeV. At this point we do not calculate the radiation from electromagnetic cascades that could potentially result in a more transparent medium for γ-ray photons. However, we can qualitatively assess the importance of the emission coming from secondary pairs.

To test whether pair emission could be relevant, we need to compare the predicted OF γ-ray luminosity in the 0.1 − 30 GeV energy band, 0.1−30, to the OF luminosity produced by the secondary pairs. If these pairs are created within the jet, they will be attached to the jet flow and their emission luminosity (Le±) beamed; under fast cooling these pairs will have an OF luminosity comparable to that absorbed (as seen by the observer). Within the jet, it is possible that the boosted BLR field will dominate over the magnetic field, and IC cascades could develop. If the pairs isotropise in the LF outside the jet, then their luminosity towards the observer will be times lower. In the LF outside the jet, the magnetic field may be more relevant, in which case pairs would cool through synchrotron. The maximum value of the luminosity of the pairs e± depends on the emitted (i.e. unabsorbed) and observed (i.e. absorption corrected) luminosities as , and is between and .

4. Results of a typical interaction

We present the results of the interaction of a single JCI under typical conditions (parameters given in Table 1). From Eq. (1) we obtain zmin ≈ 5 × 1016 cm and zj ≈ 1017 cm. Equation (7) yields B0 ≈ 350 G. The evolution of the relevant dynamical quantities is shown in Fig. 2. In the LF, after ∼104 s the cloud expands considerably, up to ∼10% of the jet radius, and after ∼4 × 104 s it accelerates to a Lorentz factor > 2, reaching Γc ≈ Γj after ∼106 s. The magnetic field in the CF drops significantly as Γc increases (from Eq. (7), B′≲Bc). During the early, non-relativistic stage (tLF <  104 s), the momentum transfer from the jet to the cloud is significant, but not the energy transfer. Later, in the relativistic stage (tLF >  104 s), the transfer of energy from the jet to the cloud (in the CF) becomes more efficient. Once the cloud accelerates and zc starts growing significantly (t ≳ 105 s), the cloud expansion is negligible and the fraction of the jet section it occupies becomes smaller (Fig. 2). When Γc → Γj, the relative velocity between the jet and the shock becomes very small and so does the energy flux through the shock, q′ (Eq. (2); the available luminosity per unit surface also diminishes); in consequence, no further energy is deposited in NT particles.

thumbnail Fig. 2.

Evolution of the dynamical quantities in a typical JCI. The grey shaded area represents the radiatively efficient stage in the OF.

Open with DEXTER

The relativistic particle energy distribution normalisation depends on , which varies as a function of time (see Fig. 2). Qualitatively, increases as the cloud expands and the shocked jet area becomes larger, but once the cloud has accelerated significantly q′ decreases and so does .

The shape of the relativistic particle energy distribution depends on the dominant cooling/escape mechanisms. The IC/SSC and synchrotron losses depend on the energy density of the target photon fields and the magnetic field, respectively (see Fig. 3). The IC losses also depend on the product of the electron and target photon energies: if E′ ϵ′> (mec2)2, the interaction occurs in the Klein-Nishina (K-N) regime, which has a much smaller interaction probability, making the IC cooling less efficient. For early times, the dominant cooling mechanism is synchrotron, whereas at later times (which are more relevant in terms of γ-ray emission) the cooling is dominated by IC scattering with the boosted BLR photon field. However, electrons with E′≳1 − 10 GeV interact in the K-N regime once the cloud reaches Γc ≫ 15. The electron maximum energy is limited by synchrotron cooling, so it increases as a function of time as B′ decreases. The electron maximum energy obtained is ≈1 TeV at early stages, and it later increases up to ∼10 TeV. Electrons cool down locally regardless of their energy. The radiatively efficient stage is during tLF ∼ 105 − 106 s, and is shown as a grey shaded area in Figs. 23. The electron energy distribution for different times (in the LF) is shown in Fig. 4. The distribution is a soft power law with , except for tLF ∼ 106 when a hardening for electrons with energies E′∼109 − 1010 eV appears because IC is in the K-N regime; the distribution softens again at higher energies as synchrotron cooling takes over.

thumbnail Fig. 3.

Evolution of different energy densities in the CF during a JCI. For tLF ≲ 2 × 105 s the synchrotron cooling is dominant (followed by SSC, not considered in the model). For tLF ≳ 2 × 105 s the BLR photon field dominates the cooling of electrons that interact in the Thomson regime. The grey shaded area represents the radiatively efficient stage in the OF.

Open with DEXTER

thumbnail Fig. 4.

Relativistic electron energy distribution for different times in the LF during the JCI. The distribution is roughly , as expected when IC-Thomson or synchrotron losses are dominant. At tLF ∼ 106 s, the IC cooling for electrons with E′∼109 − 1010 eV occurs in the K-N regime, which leads to a hardening in the electron distribution up to energies at which synchrotron cooling takes over and softens the particle distribution.

Open with DEXTER

4.1. Lightcurve

In Fig. 5 we show the evolution of the synchrotron and IC-BLR SEDs for different observing times. During the early stage, the electrons cool down more efficiently through synchrotron cooling, although this process hardly generates emission above 0.1 GeV. However, as the interaction evolves, the shocked cloud accelerates from Γc ≈ 1 to Γc ≈ Γj = 13. Thus, due to the increased BLR photon field in the CF, for later stages the IC losses with BLR photons dominate the radiative cooling and becomes larger than . The IC-BLR process is responsible for most of the emission in the 1 − 30 GeV energy band. Moreover, Doppler boosting has the effect of displacing the SEDs to higher energies by a factor δc ≲ Γj and enhancing the flux by a factor . Thus, Doppler boosting has a major effect in the shape of the SED, in particular enhancing the emission by more than four orders of magnitude for late stages. The synchrotron process can radiate appreciably in the 0.1 − 1 GeV energy range due to the Doppler emission combined with the presence of very high-energy electrons (≳10 TeV, Fig. 4) at late stages, under the adopted acceleration efficiency. In addition, Fig. 6 shows that the fraction of the luminosity that goes into secondary e± pairs is not dominant, although the absorption process is relevant in shaping the IC spectrum at energies > 30 GeV.

thumbnail Fig. 5.

SEDs for different observing times. The dashed and dash-dotted lines represent the IC and synchrotron contribution, respectively, while the solid lines are the total emission. The emission increases with time until 4 × 104 s, when it starts to decrease. The synchrotron emission dominates at energies < 10 GeV for early times, but IC dominates the whole SED above 0.1 GeV during the most luminous stages.

Open with DEXTER

thumbnail Fig. 6.

Comparison between the emitted (i.e. without absorption) and the observed (i.e. absorption corrected) integrated γ-ray luminosity above 0.1 GeV in the OF, and , respectively, and the maximum luminosity produced by pairs, , estimated as .

Open with DEXTER

The lightcurve for a single JCI has a sharp peak at s (Fig. 7). In the OF, the radiatively significant stage of the interaction lasts for s. It is interesting to see whether the emission in the 0.1–30 GeV energy range presents different signatures in sub-bands (Fig. 7). The emission at ϵ >  10 GeV has the most significant variation, as it is produced only by IC scattering with the BLR photons. In Fig. 7 we also show the integrated luminosity (i.e. total radiated energy) received in different energy bands. The total emitted energy in the 0.1–1 GeV energy range is almost twice the emitted at 1–10 GeV, leading to a SED with an average slope α ≈ −0.2. This can be explained in terms of the flat IC SED and a significant synchrotron contribution at ϵ <  1 GeV (Fig. 5). Figure 8 shows that the time-averaged SED above 100 keV is completely dominated by IC with BLR photons. The time-averaged total luminosity is erg s−1 during each interaction, and in the 0.1 − 30 GeV energy band it is erg s−1.

thumbnail Fig. 7.

Luminosity (top panel) and integrated luminosity (i.e. radiated energy; bottom panel) in the OF as a function of time, for different energy bands. The majority of the observed emission occurs between s and s, in the range 0.1 − 30 GeV. The γ-γ absorption has a dramatic effect on photon energies above 30 GeV.

Open with DEXTER

thumbnail Fig. 8.

Time-averaged synchrotron and IC SEDs for a typical JCI (top panel) and for the favourable scenario described in Sect. 4.2 (bottom panel).

Open with DEXTER

4.2. Emissivity scaling on free parameters

The value of the equipartition magnetic field considered (corresponding to ηB = 1) is rather high, so it is worth analysing the impact that this assumption could have on the predicted luminosity of a JCI. If the magnetic field is less intense (ηB <  1), the IC-BLR dominates the electron cooling earlier than suggested in Fig. 3. In consequence, the γ-ray luminosity peaks slightly sooner and at slightly higher values. The predicted time-averaged γ-ray luminosity in the 0.1–30 GeV energy range grows from erg s−1 for ηB = 1 to erg s−1 for ηB = 0.1; smaller values of B would be in contradiction with a jet magnetically dominated at its base. In addition, the γ-ray spectrum becomes slightly harder for smaller ηB as the flat IC component becomes more dominant than the softer synchrotron component; also the Compton dominance (given by the ratio of the IC and synchrotron fluxes) increases for smaller values of ηB.

Another free parameter of our model is the minimum energy of the injected relativistic electron population, . Qualitatively, a higher value of implies that there is more energy available for higher energy electrons (as can be inferred from Eq. (9)), and also that the low-energy tail of the IC-BLR SED shifts to higher energies (roughly . Increasing from 1 MeV to 10–50 MeV increases by a 15–30%.

At last, the acceleration efficiency of relativistic particles is also a free parameter of the model and it affects the maximum energy achieved by the relativistic electrons. The adopted value of ηacc = 0.1 for a typical JCI is somewhat high, but even considering a much smaller value of ηacc = 10−3 only has a minor impact in , enhancing it by a 5%. However, the value of can have a significant impact in the shape of the SED as it determinates the maximum photon energy for each process. In the case of IC-BLR, the maximum value of ϵγ is hardly relevant as all photons with ϵγ >  30 GeV are absorbed. For synchrotron radiation, considering a lower value of ηacc shifts the synchrotron peak to lower frequencies. In Fig. 8 we also show an example of a SED for a favourable scenario with ηB = 0.1, ηacc = 10−3 and . In this case the SED has the characteristic two humps of blazar SEDs and the γ-ray luminosity is almost a factor of three higher than that obtained for the typical values previously considered, erg s−1.

In summary, the different free parameters in the model (ηB, , ηacc) can have a strong impact on shaping the broad-band SED of a JCI. Nonetheless, the emitted γ-ray luminosity in the GeV band by a JCI is not very sensitive to variations in these parameters and the values reported for a typical JCI should be correct within a factor of ∼3. This supports the decision of focusing on the study of the GeV γ-ray luminosity in JCIs as the results obtained are rather robust and not strongly model-dependent.

5. Interaction rates

To determine whether JCIs give rise to transient/flaring or steady emission, we need to take into account the rate of events and their duration. This can be achieved by estimating the duty-cycle of these interactions.

5.1. Duty-cycle

We define the duty-cycle as , where is the number of clouds entering the jet per time unit, and is the duration of each individual interaction in the OF (i.e. the time during which the JCI is visible in the OF). We estimate Nc,j/tj, with Nc, j being the number of clouds inside the jet and tj the time it would take for a cloud to cross the jet width if there were no interaction with the jet. To estimate this timescale we need to consider a representative value of the cloud velocity, ⟨vc, 0⟩, such that tj ∼ 2Rj/⟨vc, 0⟩. According to Eq. (1), the minimum velocity required for a cloud to enter the jet is vc, min ≈ 3 × 108 cm s−1 at z ∼ RBLR under the assumed conditions. Further assuming that the BLR clouds follow a Maxwellian velocity distribution g(vc, 0) with mean value , the value of the most likely velocity can be estimated as

(12)

we obtain a typical value of ⟨vc, 0⟩≈8 × 108 cm s−1.

We consider the simplest scenario of a spherical BLR with clumps of equal size, and use the canonical values given in Table 1. The total number of clouds in the BLR is Nc, tot. If we adopt a fixed filling factor f ∼ 10−6, we can estimate this number as Nc, tot ∼ f (RBLR/Rc, 0)3 (e.g. Araudo et al. 2010). Another possibility is to consider a fixed covering factor CBLR ∼ 0.1, in which case f = 4/3(Rc, 0/RBLR)CBLR and (e.g. Abolmasov & Poutanen 2017); this is the approach followed here, although the difference between the two methods is small. The fraction of clouds that have enough velocity to penetrate into the jet (Sect. 3.1) is fvel, and the total number of clouds inside the jet at a given time is

(13)

where ΔΩ/(4π)=(1 − cosθj)/2 ≈ (θj/2)2 ≈ 0.0025 is the jet-to-BLR volume ratio.

In the OF, the interaction lasts s. For CBLR = 0.1 (e.g. Abolmasov & Poutanen 2017), we obtain f ≈ 8 × 10−6, Nc, tot ∼ 107, and DC ∼ 10 − 100 for typical parameters. Therefore, the emission we expect from JCI events is steady. Considering Poisson statistics, the typical variability timescale we expect is s, and fluctuations in luminosity of ∼DC1/2/DC ≈ 0.20 (DC/30)−1/2 ≈ 20 (D/30)−1/2% (e.g. Owocki et al. 2009, for a similar approach in a microquasar scenario). This effect is observed in the radio and optical bands (Romero et al. 2002). The expected luminosity is DC times the luminosity of a single JCI, i.e. ∼3 × 1045(DC/30) erg s−1. This is similar to the average emission detected from blazars with jet power Lj ∼ 3 × 1046 erg s−1 (Ghisellini et al. 2017). We can also estimate the average luminosity as Eγ⟩ ∼ 1046(N/10−3)(⟨Eγ⟩/1049) erg s−1, which yields similar results.

An interesting feature related to the multiple JCIs is the jet mass-loading produced by the BLR cloud entrainment. The mass-loading rate is of the order of = Mc ∼ 1023(N/10−3)(Mc/1026) g s−1. This process is not dynamically relevant for typical values; for instance, under the conditions assumed here, jLjjc2 ∼ 1024(Lj/1046)(Γj/10)−1 g s−1.

5.2. Emissivity scaling on jet power

We compute a typical JCI for the same cloud parameters (Rc, 0, nc, 0, and vc, 0) as in Table 1, but for jet luminosities different from the canonical value (Lj ∼ 2.5 × 1046 erg s−1). Regardless of the jet power, the basic characteristics of the JCI are essentially the same: the cloud gets accelerated in tLF ∼ 106 s, the high-energy electrons cool down locally through IC interactions with the BLR photon field during the most relevant stage, and the radiatively efficient phase lasts ∼(1 − 2)×104 s in the OF (Fig. 9).

thumbnail Fig. 9.

Evolution of the integrated γ-ray luminosity in the 0.1–30 GeV energy range in the OF for different values of the jet power.

Open with DEXTER

For a less powerful jet with Lj ∼ 1045 erg s−1, the BLR region is smaller and D ≲ 1. Thus, the cloud escapes faster from this region and the assumption of homogeneous conditions is only valid for penetration heights considerably below RBLR. Given that the BLR is less luminous, the convection losses are dominant for electrons with E′< 10 MeV. Synchrotron cooling dominates during most of the JCI, except when the cloud has accelerated to Γj. The jet radius is smaller, and as we are fixing the cloud initial size (Rc, 0), the expanded cloud maximum radius is almost half of the jet radius. This leads to a much larger fraction of the jet power being transferred to the shock. The average SED above ϵ >  1 MeV is dominated by IC emission (below that synchrotron dominates).

For a more powerful jet with Lj ∼ 1048 erg s−1, we get D ∼ 10 and the dominance of the BLR photon field in the radiative features is even more pronounced. However, in this case the cloud maximum radius is only ∼1% of the jet radius, so the amount of jet power deposited in the shock is relatively small, and therefore the luminosity of a single JCI does not increase significantly with respect to the canonical value (Fig. 9).

Assuming a constant CBLR, . For a fixed value of MBH (supported by Ghisellini et al. 2017), , and therefore the mean velocity of the clouds that are able to penetrate the jet is lower if Lj is high; for example, we obtain ⟨vc, 0⟩≈2 × 109 cm s−1 for Lj ∼ 1045 erg s−1, and ⟨vc, 0⟩≈2 × 108 cm s−1 for Lj ∼ 1048 erg s−1. Putting everything together, the scaling of DC with Lj is weak and is about .

The average γ-ray luminosity and other properties of the JCI for different jet powers are summarised in Table 2. It is interesting to note that both the intensity of a single JCI and the duty-cycle of the events are only weakly dependent on Lj. Therefore, the total (collective) luminosity of the JCIs is not very sensitive to Lj, although more powerful jets are expected to be more luminous.

Table 2.

Comparison of the JCI properties for different jet powers.

Another aspect to take into consideration is the predicted X-ray luminosity, LX. As shown by Ghisellini et al. (2017; their Fig. 6), FSRQs have a minimum in their SEDs close to 1 keV (1017 Hz), and LX ranges from ∼1043 erg s−1 to ∼1046 erg s−1 for Lj from 1045 erg s−1 to 1048 erg s−1, respectively. According to our model, for a typical JCI with ηB = 1 the expected LX is ∼1043 erg s−1 regardless of Lj, and the collective X-ray luminosity of multiple JCIs ranges from ∼1044 erg s−1 to ∼1045 erg s−1 for a value of Lj from 1045 erg s−1 to 1048 erg s−1. Therefore, there is some tension between the predictions of our model when applied to FSRQs with weak jets. However, the expected value of LX is sensitive to the adopted values of the model free parameters and it can be significantly lower than that obtained in the typical scenario (Sect. 4.2). A detailed analysis of the X-ray emission from JCIs is beyond the scope of this work.

6. Conclusions

We have shown that under typical conditions JCIs conspicuously stand out as an efficient γ-ray emitting mechanism in blazars, although the evolution of an interaction between an AGN jet with a BLR cloud is complex. With a simple model accounting for cloud expansion and relativistic effects, we have shown that the interactions of BLR clouds with the jet in a blazar can produce significant γ-ray emission if ξe ≳ 0.1 and if the BLR geometry is roughly spherical. This γ-ray emission is expected to be rather persistent, with some moderate fluctuations. Even though JCIs do not seem to be the dominant emitting mechanism, this mechanism cannot be neglected a priori as partially shaping the observed SED of BLR-hosting blazars, in particular in the GeV range.

If JCIs in the BLR of blazars do not significantly contribute to the emission seen by Fermi from these sources (as proposed by Costamante et al. 2018, due to the lack of strong attenuation in their spectra), we can indirectly assess the study of the BLR properties (e.g. discarding a spherical shape) if we assume that electron acceleration is efficient. Radio and optical variability can be used to test this (Romero et al. 2000, 2002). Otherwise, electron acceleration should be strongly suppressed (i.e. ξe ≪ 1).

An improved model for BLR cloud-jet interactions (and for JCIs in general) should consider that the emission needs to be calculated in the shocked fluid frame rather than in the accelerating cloud reference frame. This improvement requires a more detailed analysis of the emitting fluid (e.g. de la Cita et al. 2016). Another improvement would require a more realistic BLR prescription, although this may not be an easy task given the uncertainties on BLR characterisation.


1

The SED can show additional components of thermal emission from the disc, the dusty torus, and the BLR.

2

In the relativistic regime (when the cloud has been already accelerated by the jet) the energy transfer in both shocked regions (jet and cloud) is similar.

3

For simplicity, the jet region is taken as conical regardless of its actual shape.

4

This rough approximation does not significantly affect the results because of three factors: in the relativistic regime the cloud expansion is slowed down by time dilation, the cloud differential velocity along the jet in the LF is small, and the jet lateral pressure becomes more relevant. In fact, in Barkov et al. (2012a) and Khangulyan et al. (2013) the cloud radius was taken to be constant.

5

As , the transition to the KN regime occurs at . The electrons interact with the torus photon field in the Thomson regime to significantly higher energies, which can become a relevant cooling mechanism for electrons with E′≳100 GeV once the cloud has reached Γc ≳ 10. However, this process does not dominate the SED in the GeV energy range, and is therefore neglected for simplicity.

Acknowledgments

We thank the anonymous referee for the detailed revision of the manuscript and for the constructive suggestions. This work is supported by CONICET (PIP2014-0338) and ANPCyT (PICT-2017-2865), and also by MDM-2014-0369 of ICCUB (Unidad de Excelencia “María de Maeztu”), and the Catalan DEC grant 2017 SGR 643. SdP acknowledges support from PIP 0102 (CONICET). V.B-R. and G.E.R acknowledge support from the Spanish Ministerio de Economía y Competitividad (MINECO/FEDER, UE) under grant AYA2016-76012-C3-1-P, with partial support from the European Regional Development Fund (ERDF/FEDER).
