1. Introduction

Understanding strong interaction physics at extreme conditions of temperature and/or density is a central topic of current theoretical and experimental nuclear research. Recently, lattice quantum chromodynamics (QCD) calculations have established that chiral symmetry restoration proceeds as a smooth crossover at vanishing baryo-chemical potential (μB = 0). The pseudo-critical temperature, defined by the maximal change of the order parameter of the chiral transition (the chiral condensate) was found to be approximately Tc = 155 ± 10 MeV (Borsanyi et al. 2010; Bazavov & Petreczky 2010). Since lattice QCD results cannot be directly extended to finite chemical potential (Fodor & Katz 2002, 2004; de Forcrand & Philipsen 2008; Endrodi et al. 2011), one has to rely on expansions of μB = 0 lattice data in powers of chemical potential, imaginary chemical potential extensions (de Forcrand & Philipsen 2008), reweighing techniques (Fodor & Katz 2002, 2004), complex Langevin approaches (Sexty 2014), functional renormalization group approaches (Pawlowski 2007; Berges et al. 2002; Schaefer & Wambach 2008), or effective models (see, e.g., Refs. Mishustin et al. 1993; Heide et al. 1994, for early ideas and Papazoglou et al. 1998, 1999; Tsubakihara et al. 2010, for hadronic models), to estimate the phase structure of QCD at large baryon number densities.

The study of ultra-relativistic heavy-ion collisions provides a crucial tool to obtain information about high temperature and, depending on the beam energy, low to high baryon number densities. In contrast, the properties of compact stars, such as neutron or hybrid stars, might lead to a better understanding of extremely dense, but relatively cold matter. Finally, the environment of proto-neutron stars and binary neutron star mergers could help to bridge these two regimes of density and temperature. In order to theoretically investigate the properties of strongly interacting matter in all of these environments, one has to employ a model approach containing hadrons and quarks in a comprehensive manner. After having analyzed (isospin-symmetric) heavy-ion-collision matter within the aforementioned approach (Mukherjee et al. 2017) based on an extension of the SU(3) parity-doublet model of Steinheimer et al. (2011b), we use the same model to investigate the behavior of hybrid stars in the current paper. As an important outcome, we see that not only does this approach lead to a good description of the ground state properties of nuclear matter, but such an approach also leads to heavy hybrid stars with relatively smaller radii. In addition, the quarks do not feature a strong repulsive vector interaction, which would otherwise lead to conflicts with lattice QCD data (Steinheimer & Schramm 2014, 2011; Kunihiro 1991).

The paper is organized as follows: after introducing the basic model equations and discussing isospin-symmetric matter in Sect. 2, we determine the behavior of isospin-asymmetric matter in Sect. 3. Section 4 contains results for the properties of compact stars, which is followed by our conclusions and an outlook.

2. The model

In the Quark-Hadron Chiral Parity Doublet model (QχP), an explicit mass term for baryons, which preserves chiral symmetry, is introduced in the Lagrangian. In this case, the signature for chiral symmetry restoration is the degeneracy of the usual baryons and their respective negative-parity partner states. This is different from the standard chiral picture, where this degeneracy occurs only for essentially massless nucleons. Recent results from lattice QCD, in fact, indicate that the mass of the ground state baryons undergo only a very small change and, as chiral symmetry is restored, mainly the parity partners undergo a significant mass shift (Aarts et al. 2017).

Positive and negative parity states of the baryons can be grouped in doublets N = (N+,N) as discussed in DeTar & Kunihiro (1989), Hatsuda & Prakash (1989). The three-flavor extension of this approach was first presented in Nemoto et al. (1998), the application to compact stars can be found in Dexheimer et al. (2008a,b, 2013) and the application to the QχP model was first introduced in Steinheimer et al. (2011b). To describe the interaction potential, one constructs SU(3)-invariant terms in the Lagrangian including the meson-baryon and meson-meson self-interaction terms outlined in Papazoglou et al. (1998). Taking into account the scalar and vector condensates in mean-field approximation, the resulting baryon-Lagrangian () reads (Steinheimer et al. 2011b) (1)summing over the states of the baryon octet, where all the gφis are set to zero for this study. As already mentioned, this model allows for a significant bare mass term m0 of the baryons. The effective masses of the baryons then follow as (2)where are the coupling constants of the baryons with the non-strange (σ) and strange (ζ) scalar fields. In addition, there is an SU(3) symmetry-breaking mass term proportional to the strangeness, ns, of the respective baryon. Parity-doublet models allow for two different scalar coupling terms with i (orj) = 1and2, which lead to a different dependence of the mass of the parity-partners when the value of the chiral condensate changes. For simplicity, we assume equal mass difference of the various baryons and their parity partners in vacuum, by setting and , where σ0 is the vacuum expectation value of the chiral field σ.

The scalar meson interaction between the baryons drives the spontaneous breaking of the chiral symmetry. While preserving the relevant symmetries, the interaction can be written in terms of the SU(3) invariants I2 = (σ2 + ζ2),I4 = − (σ4/ 2 + ζ4) and I6 = (σ6 + 4ζ6) as:(3)where V0 is fixed by demanding that the potential vanishes in vacuum. As has been pointed out in Horowitz & Piekarewicz (2002), Dexheimer et al. (2015), and references therein, and discussed in general in Schramm (2003), a coupling term between ω and ρ meson leads to a reduced value of the slope parameter of the symmetry energy. Without this coupling, the slope parameter is close to a value of 100 MeV, which is rather large compared to current estimates. We introduce such a term in the model as (4)For the sake of simplicity, we did not add this term in an SU(3) invariant way, although it is possible to do so in principle. This is reasonable because the strange-vector field necessary for the invariance, φ, is effectively zero, as no hyperons occur in the system at relevant densities. The parameters seen above are summarized in Table 1.

Table 1

Model parameters.

As the quarks also couple to the scalar fields, their masses are partly generated by the scalar mesons except for an explicit mass term (δmq for up and down quarks, and δms for the strange quarks) and m0q as follows: (5)The mass parameter for the quarks is m0q = 165 MeV. This additional mass term can be understood as a coupling of the quarks to the dilaton field (gluon condensate). Since it is known (Sasaki & Mishustin 2012) that the dilaton field slowly vanishes (much slower than the chiral condensate), the quark mass can still be significantly larger than the current mass δmq around the transition line. Eventually, if coupled to the dilaton field, the m0q should also asymptotically vanish in the de-confined phase. However, for simplicity, we leave it constant in this work. Given such a mass term, the quarks do not appear in the nuclear ground state, which would be a clearly nonphysical result. This also allows us to set the vector-type repulsive interaction strength of the quarks to zero. A non-zero vector interaction strength would lead to a massive deviation of the quark number susceptibilities from lattice data, as has been observed in different mean field studies (Kunihiro 1991; Ferroni & Koch 2011; Steinheimer & Schramm 2011, 2014).

thumbnail Fig. 1

Mass of the nucleon ground state N+ and its parity partner N, normalized to the N+ mass, as function of normalized temperature for μB = 0 and isospin symmetric matter. We compare results from the QχP model with lattice QCD data (Aarts et al. 2017). For comparison, we also include QχP results (green, dashed line), where N is normalized by the lattice QCD nucleon mass, which in the cited study is still unphysically large.

Open with DEXTER

To include a transition from a hadronic to a deconfined quark phase in the model, the thermal contribution of the quarks is added to the grand canonical potential of the model, analogously to the way it is performed in PNJL type models (Fukushima 2004; Ratti et al. 2006) as follows: (6)and (7)The sums run over all quark flavors, where γi is the corresponding degeneracy factor, the energy, and μi the chemical potential of the quark.

At low temperatures and densities, the quarks are confined by the Polyakov loop potential (Ratti et al. 2006), (8)where , .

The parameters a0,a1,a2, and b3 are initially fixed, as in Ratti et al. (2006), by demanding a first order phase transition in the pure gauge sector at T0 = 270 MeV. The Stefan-Boltzmann limit of a gas of gluons is reached in the limit T → ∞.

Finally, in order to slowly remove the hadrons from the system as deconfinement is realized, we introduce an excluded volume description for the hadrons. The parameter vi is the volume excluded by a particle of species i, where we only distinguish between baryons, mesons, and quarks. Consequently, vi assume three values written as where a is a number larger than one. In our calculations, we choose the value a = 8. This treatment eventually modifies the effective chemical potential of all the hadrons, causing these hadrons to be suppressed once the quarks and gluons contribute to the thermodynamic potential. As a result, we obtain a naturally smooth transition from a hadronic to a quark-dominated system. A detailed description of the excluded volume prescription can be found in Mukherjee et al. (2017), Steinheimer et al. (2011a), Steinheimer & Schramm (2011).

thumbnail Fig. 2

Binding energies for symmetric and asymmetric nuclear matter, as functions of the baryon number density, which is normalized to nuclear matter saturation density ρ0.

Open with DEXTER

Results for this model, regarding properties of isospin symmetric matter, have already been shown in Mukherjee et al. (2017). A particular feature of the parity doublet model is that the nucleon and its negative parity partner suffer a different change in their mass from the melting chiral condensate. To put our model in context of recent lattice QCD calculations we show, in Fig. 1, a comparison of the mass of the nucleon and its parity partner with lattice QCD data (Aarts et al. 2017) as a function of temperature, at μB = 0. Even though the vacuum mass of the nucleons in the lattice QCD calculations is still off its physical value, the temperature dependence shows a remarkable similarity with our results. This result indeed supports a basic assumption of the QχP model, where chiral symmetry restoration is observed in a mass degeneracy for hadrons and their parity partner and not in a complete absence of mass.

When we studied the model properties at T = 0 we found that, for the parameters used in the previous paper and in this work, nuclear saturation properties are well described. Even the nuclear (in)compressibility (κ) was found to be 267 MeV, which is well in line with experimental observations. The red dashed line in Fig. 2 shows the resulting binding energy per baryon for infinite and isospin-symmetric nuclear matter, as a function of the normalized net-baryon-number density ρB/ρ0, where ρ0 (=0.142 fm-3) is the nuclear saturation density of the model.

3. Isospin-asymmetric matter

As we investigate neutron stars, i.e., highly isospin-asymmetric matter, we first determined the basic isospin-dependent coefficients around nuclear matter saturation density. To this end, we calculated the value of the isospin-asymmetry energy Sv, given by (9)where ε is the energy density, ρB the baryon number density, I3 the isospin 3-component, and B the net baryon number. The density dependence of Sv is usually parametrized by the slope parameter (10)Using our model, we obtain Sv = 30.02 MeV and L = 56.86 MeV, which are in agreement with ranges of L and Sv, from various experiments and analyses in, for example, Lattimer & Lim (2013).

thumbnail Fig. 3

Speed of sound squared as a function of normalized baryon number density (on a logarithmic scale), with the dashed, black line representing the kinetic-theory-bound on (cf. Moustakidis et al. 2017).

Open with DEXTER

thumbnail Fig. 4

Comparison between the pressure, normalized to the Stefan-Boltzmann pressure, P/PSB obtained from our model and PQCD calculations from Fraga et al. (2014).

Open with DEXTER

The binding energy per baryon of asymmetric star matter is also shown in Fig. 2. In this case, the energy is determined self-consistently by the imposition of electric charge neutrality and chemical equilibrium, including free, charged leptons. In addition, we show the square of the speed of sound for star matter in Fig. 3. It is calculated from our equation of state as (11)where P is the pressure and ε the energy density. The sharp decrease in the speed of sound around ρB ≈ 3ρ0 signals the appearance of the parity partner, N∗ 0, of the neutron, as it starts to be populated. The smaller sharp decrease in the speed of sound just before ρB ≈ 2ρ0 signals the appearance of the down quarks, although only a few quarks contribute to the particle cocktail at low density. Figure 3 also shows that, in our model, the speed of sound never crosses the boundary established by kinetic theory (Moustakidis et al. 2017), (12)In addition, for very large densities, our speed of sound remains around , as expected.

The pressure of star matter, divided by the Stefan-Boltzmann pressure (ideal-gas limit), as a function of baryo-chemical potential is shown in Fig. 4. We compare our results with star-matter, perturbative-QCD (PQCD) calculations at zero temperature from Fraga et al. (2014), which can be considered a constraint on the high density QCD equation of state (EoS; Kurkela et al. 2014). Our EoS falls inside the band in Fig. 4, which represents their uncertainty estimates. One should note, however, that the agreement of our model with the PQCD result gets worse for very large values of chemical potential. This is because we have assumed the quark mass parameter (m0q in Eq. (5)) to remain constant for all densities. In reality, we expect that, as the dilaton field melts slowly at large values of chemical potential, the quark mass also slowly approaches the current quark mass value, i.e., the quark mass parameter should vanish. Thus, for high values of the chemical potential, our model shows a rise in pressure that is too slow near the Stefan-Boltzmann limit.

In order to better understand the chemical composition of our asymmetric EoS, we determined the corresponding particle populations. Figure 5 shows the number densities of various particle species normalized to the total baryon number, where quark number densities are divided by 3. At low densities, as expected, we only observe neutrons. An increase in density is followed by the appearance of protons, leptons and, soon after, down-quarks. Later, the up-quarks appear, followed by the chiral partner of the neutrons. The latter appears rather suddenly and causes the rapid decrease of the speed of sound mentioned earlier (cf. Fig. 3). Finally, the chiral partner for the protons, and afterwards the strange quarks, appear. Although the hyperons are included in the model, they are completely absent from the particle cocktail shown in Fig. 5. The chiral partners of the nucleons have lower masses than the hyperons and owing to the crossover formalism, quarks can also appear very early. In addition, the hyperons are suppressed by the appearance of the other light quark states through the excluded volume formalism. Eventually, the strange quarks appear in the cocktail, however only at much higher densities.

thumbnail Fig. 5

Normalized baryon-number densities of various particle species as functions of the normalized baryon-number density.

Open with DEXTER

As we have already mentioned, the isospin asymmetry of charge neutral and chemically equilibrated matter is self-consistently determined. In this case, we show in Fig. 6 how the pressure to energy density ratio P/ε changes as a function of isospin per baryon, which is defined as (13)and the normalized baryon density. The colors in the figure show regions where the pressure is positive (red) and negative (blue). All the unstable and metastable states of the nuclear liquid-gas transition fall into the blue region at small baryon number densities. We also observe small regions, both at large and small values of isospin-per-baryon, where the pressure decreases as function of density, or in other words, where the speed of sound becomes imaginary and matter becomes mechanically unstable. This region corresponds to the spinodal region of a first-order phase transition, which appears only for large isospin asymmetries. The bold, black line corresponds to the EoS of neutron star matter, where the isospin per baryon is fixed by condition of beta-equilibrium.

4. Neutron stars

thumbnail Fig. 6

Contour plot of the ratio P/ε on a normalized I3ρB plane, showing regions of stability in red and those of instability in blue. The bold, black line represents the isospin-per-baryon for charge-neutral and chemically equilibrated matter.

Open with DEXTER

In order to describe neutron stars we make use of a Maxwell construction around the first-order phase transition to avoid thermodynamical instabilities, i.e., we guarantee that the pressure increases as a function of energy density in our EoS. We also add a standard result for the crust to our EoS, originally calculated by Baym, Pethick, and Sutherland (Baym et al. 1971). The mass-radius diagram for the resulting compact stars, as shown in Fig. 7, is determined using the Tolman-Oppenheimer-Volkoff equations (Oppenheimer & Volkoff 1939; Tolman 1939) for a range of central pressures. The most massive star of the family has a mass of 1.98M (M = the solar mass) and a radius of 10.25 km. The canonical 1.4M star has a radius of 11.10 km. This radius value, which is small for models of hybrid or other exotic matter, is in agreement with a number of observational studies, particularly of low-mass X-ray binaries that point to small neutron star radii in the range of about 9 km to 11 km (Guillot et al. 2013, 2011; Ozel & Freire 2016; Ozel & Psaltis 2015). Since most of the stellar cores we reproduce contain some amount of quarks, we choose to mark the stars from the family that contain 20%, 25%, and 30% of baryon mass coming from quarks (blue dots in Fig. 7). For the most massive star of the family 35% of its baryon mass is generated by quark matter.

When we include rotation effects, Fig. 8 shows how the stellar maximum mass increases as a function of rotational frequency in two cases, keeping a fixed central pressure or the number of baryons in the star. In the second case, we describe the evolution of an isolated star, as the frequency of rotation decreases over time, which has a Kepler frequency of 1606 Hz. Here, we considered monopole and quadrupole corrections to the metric due to the rotation, as was derived in Glendenning & Weber (1994). The higher the rotational frequency, the more massive and larger the stars become. The increase in mass of the most massive star of the family is about 5% for a star with fixed baryon number rotating at its Kepler frequency (compared to a non-rotating star). In a previous publication we have shown that this kind of calculation differs by about 1% from full general relativity results from Stergioulas & Friedman (1995).

thumbnail Fig. 7

Mass-radius diagram. The blue dots indicate stars with a fraction of 20%, 25%, and 30% of the baryon mass coming from quarks.

Open with DEXTER

thumbnail Fig. 8

Mass of the most massive star of the family as a function of rotational frequency. In two cases, we keep a fixed central pressure or number of baryons in the star.

Open with DEXTER

Usually, the effect of rotation in hybrid stars is to suppress their quark phase (cf. Wei et al. 2017, for a recent discussion on the topic). A phase transition to deconfined matter can only take place when heavy stars spin down and their central densities increase. In our case, the situation is different because the quarks occupy a fraction of almost all stars, heavy and light. We have quarks present in almost all stars that rotate with any allowed frequency and only their fraction (compared to hadrons) increases as stars spin down.

The term “compactness” refers to how packed together matter is in a star. Our QχP equation of state is shown in Fig. 9 together with other equations of state calculated using nonrelativistic models, relativistic models, models containing quarks, and models containing strange hadrons. This figure was adapted from Lattimer & Prakash (2005), Lattimer (2012). It is interesting to see that the star we generate is very compact, and is more compact than all the massive exotic stars shown in the figure. Naturally, the maximum-mass star we reproduce is between the line that represent EoS with constant speeds-of-sound, equal to or 1.

Concerning star cooling, our EoS does not allow the hadronic direct Urca process. This is the case because, although a large fraction of the star core contains nucleons and their parity partners, there are not enough electrons to complete the reactions. For a more detailed study of the role of chiral partners in neutron star cooling, see Lattimer (2012). For quarks, we assumed that all flavors are paired and as such the quark direct Urca process is heavily suppressed (Blaschke et al. 2006; Page et al. 2006; Alford et al. 2005; Negreiros et al. 2012). The absence of the direct Urca process is a large advantage of our EoS, as it prevents the enhanced cooling of heavy stars, as discussed in Page et al. (2004), Negreiros et al. (2013).

5. Conclusions and outlook

We presented results for isospin asymmetric matter and compact star properties within the QχP. The model produces 2 M hybrid stars (without quark-vector interactions), with a large quark fraction of about 30 percent, as quark degrees of freedom begin to be populated at low densities. Also, because of that, the hyperons do not appear in the star. However, the parity-doublet partners of the nucleons are present.

thumbnail Fig. 9

Compactness (stellar mass vs. central density) of the most massive star generated by our equation of state. Other equations of state shown are calculated using nonrelativistic models, relativistic models, models containing quarks, and models containing strange hadrons. The figure has been adapted from Lattimer & Prakash (2005), Lattimer (2012).

Open with DEXTER

The radius of the reproduced canonical 1.4 M star is very small, i.e., about 11 km; this is in accordance with the radius estimates obtained from studies of low-mass X-ray binaries (cf. Guillot et al. 2011). This behavior is also reflected in the large compactness of the reproduced maximum mass star. Additionally, extending the EoS to high chemical potential, it meets the band of pressure values obtained in PQCD studies. At extreme values of μB (>3500 MeV), the model underestimates the pressure mainly due to the remaining large bare mass term of the quarks.

An important result of our work is that we have at hand a single model for the description of hybrid stars with a hadronic and a quark phase. The properties of the EoS are different from most simpler models, which usually incorporate the phase transition from a hadronic to a quark phase through an artificial construction. Thus, we presented a hybrid EoS that leads to more compact stars and still allows for a large quark fraction, while not forbidding the appearance of hyperons.

The application of the QχP-model EoS to dynamic simulations for heavy ion collisions can be used to study observables for the QCD phase transition in iso-spin symmetric matter. At the same time, numerical studies of neutron-star mergers can be conducted with the same model EoS in a consistent manner. This enables us to study nuclear matter in very different environments and in systems of vastly different scales using a single EoS.

Acknowledgments

The authors would like to thank G. Aarts and M. Hanauske for helpful discussions and M. Strickland for carefully reading the manuscript. The authors also acknowledge the support from NewCompStar COST Action MP1304, from GSI, HIC for FAIR, and from BMBF. The computational resources were provided by the Frankfurt Centre for Scientific Computing (CSC) and Center for Nuclear Research (Kent State University). In addition, the authors acknowledge the insights and comments of the referee who took the time to review this paper.
