MASSIVE: A Bayesian analysis of giant planet populations around lowmass stars
^{1} Univ. Grenoble Alpes, Institut de Planétologie et d’Astrophysique de Grenoble (IPAG, UMR 5274), 38000 Grenoble, France
email: justine.lannier@univgrenoblealpes.fr
^{2} Institut de Recherche sur les Exoplanètes (iREx), Département de physique and Observatoire du Mont Mégantic, Université de Montréal, CP 6128, Succursale CentreVille, Montréal, QC H3C 3J7, Canada
^{3} NASA Ames Research Center, Space Science and Astrobiology Division, MS 2456, Moffett Field, CA 94035, USA
^{4} Department of Terrestrial Magnetism, Carnegie Institution of Washington, Washington, DC 20015, USA
^{5} Institute for Astronomy, The University of Edinburgh, Royal Observatory, Blackford Hill, Edinburgh, EH9 3HJ, UK
^{6} CFHT Corporation, 651238 Mamalahoa Hwy, Kamuela, HI 96743, USA
^{7} European Southern Observatory, Alonso de Cordova 3107, Vitacura, Santiago, Chile
Received: 2 February 2016
Accepted: 22 June 2016
Context. Direct imaging has led to the discovery of several giant planet and brown dwarf companions. These imaged companions populate a mass, separation and age domain (mass >1 M_{Jup}, orbits > 5 AU, age < 1 Gyr) quite distinct from the one occupied by exoplanets discovered by the radial velocity or transit methods. This distinction could indicate that different formation mechanisms are at play.
Aims. We aim at investigating correlations between the host star’s mass and the presence of wideorbit giant planets, and at providing new observational constraints on planetary formation models.
Methods. We observed 58 young and nearby Mtype dwarfs in L′band with the VLT/NaCo instrument and used angular differential imaging algorithms to optimize the sensitivity to planetarymass companions and to derive the best detection limits. We estimate the probability of detecting a planet as a function of its mass and physical separation around each target. We conduct a Bayesian analysis to determine the frequency of substellar companions orbiting lowmass stars, using a homogenous subsample of 54 stars.
Results. We derive a frequency of 4.4^{+3.2}_{1.3} for companions with masses in the range of 2−80 M_{Jup}, and 2.3^{+2.9}_{0.7}% for planetary mass companions (2−14 M_{Jup}), at physical separations of 8 to 400 AU for both cases. Comparing our results with a previous survey targeting more massive stars, we find evidence that substellar companions more massive than 1 M_{Jup} with a low mass ratio Q with respect to their host star (Q < 1%), are less frequent around lowmass stars. This may represent observational evidence that the frequency of imaged wideorbit substellar companions is correlated with stellar mass, corroborating theoretical expectations. Contrarily, we show statistical evidence that intermediatemass ratio (1% < Q < 5%) companion with masses >2 M_{Jup} might be independent from the mass of the host star.
Key words: planetary systems / stars: lowmass / methods: statistical / planets and satellites: formation
© ESO, 2016
1. Introduction
After more than two decades of exoplanet discoveries (e.g., Wolszczan & Frail 1992; Mayor & Queloz 1995; Udalski et al. 2002), more than two thousand planets have been identified, mostly using radial velocity (hereafter RV) and transit methods. Both techniques have detected exoplanets with masses ranging from one Earth mass up to the brown dwarf mass regime (~ 13−80M_{Jup}), orbiting at close separations from their host star (usually within 5 AU). Direct imaging (DI) has provided data for about 60 large separation (≥10 AU) massive planets and brown dwarfs for more than a decade^{1} (e.g., 51 Eri b, Macintosh et al. 2015; HD 95086b, Rameau et al. 2013a; GJ504b, Kuzuhara et al. 2013; 2MASS0103(AB)b, Delorme et al. 2013; β Pictoris b, Lagrange et al. 2010; HR 8799bcde, Marois et al. 2008, 2010; 2M1207b, Chauvin et al. 2004). About a third of the imaged substellar companions (SCs, < 80 M_{Jup}) have young Mtype dwarf host stars (Table 1).
DI is usually limited to the detection of distant young massive planets because of their more favorable planettohoststar contrast and their larger angular separation. Some of the limitations of DI can be mitigated by using thermal imaging (in L′band) where young massive planets emit most of their flux, and by taking advantage of the intrinsically lower flux of lowmass stars, which provides a more favorable starplanet contrast.
Giant planets and brown dwarfs imaged around selfluminous young Mdwarfs (source: http://exoplanet.eu).
Both populations of planetary mass companions (hereafter PMCs, <14 M_{Jup}; closein RV and transit PMCs on one hand, and wideorbit DI PMCs on the other) challenge our view on planetary formation. Core accretion (CA, Pollack et al. 1996; Alibert et al. 2004) followed by planet migration is the preferred model to explain both the formation of solar system giant planets and hot Jupiters found around solartype stars. Nevertheless, CA does not easily explain the massive gas giants imaged around lowmass stars, especially at large separations, even in the case of pebble accretion (Lambrechts & Johansen 2012). Indeed, the mass of the planets are of the same order of magnitude (e.g., 2M0103b, Delorme et al. 2013) or even greater (2M1207b, Chauvin et al. 2004) than the total mass of the protoplanetary disc (≈10% of the star’s mass). On the other hand, gravitational instability (GI, Boss 2011; Cameron 1978) provides an interesting alternative to CA to explain the formation of wideorbit, massive planets within the disk of a lowmass star. Other initial conditions for the formation of PMCs, such as the position of the ice line and the stellar metallicity, impact their formation mechanisms. For instance, there are indications that planets with masses between 10 M_{Earth} and 4 M_{Jup} orbiting metalpoor stars are found at larger separations (Adibekyan et al. 2013).
Studying lowmass stars provides an opportunity to test the formation of PMCs at the low end of the stellar mass function. They also allow the study of a wider range of companion to star mass ratios. Different mechanisms might explain the formation of the planets, as a function of their mass ratio. In this paper, we will investigate whether there are different populations of planets orbiting low and highmass stars.
From an observational point of view, Bonfils et al. (2013) found that the rate of closein giant planets (msin(i) = 100−1000 M_{Earth}) around Mtype stars is low (f < 0.01 for P = 1−10 d, for P = 10−100 d), while closein superEarths are much more numerous ( for P = 10−100d). Concerning highermass stars, Rameau et al. (2013b) find that between 10.8% and 24.8% of A to F type stars host at least one planet defined by the parameter intervals [1,13] M_{Jup} and [1,1000] AU. Recently, Bowler et al. (2015) showed that few M dwarfs host giant planets closer than for <1000 AU and argue that there is no evidence of a relation between the wideorbit giant planet (>10 AU) frequency and the stellar mass (for A, FGK and M stars). However, other studies combining different techniques of detection (RV and DI, micro lensing and RV) have shown that giant planets are less frequent around M dwarfs (respectively, Montet et al. 2014; Clanton & Gaudi 2014).
In this paper, we present the results of the MdwArf Statistical Survey for direct Imaging of massiVe Exoplanets (MASSIVE). Our sample is composed of 58 young and nearby M dwarfs observed in L′band for which we have followup data for all our candidate companions.
We present the MASSIVE survey in Sect. 2. Section 3 details our Bayesian approach to derive the frequency of planetary companions orbiting lowmass stars. In Sect. 4, we explore the influence of the stellar host mass on the planet occurrence by comparing the planetary companion frequency around lowmass stars in the MASSIVE survey and around a similar VLT/NaCo survey that targeted higher mass, AF stars (Rameau et al. 2013b). We present our conclusions in Sect. 5. In all the following sections, we consider three types of companions: PMCs with masses <14 M_{Jup}, brown dwarfs with masses between 14 and 80 M_{Jup}, and SCs that bring together PMCs and brown dwarfs (< 80 M_{Jup}).
2. The MASSIVE survey
2.1. Observations
2.1.1. Sample selection
58 Mdwarfs have been observed. This sample was built as follows:

Age: we selected our targets from the known members of youngstellar associations (e.g., Zuckermanet al. 2004). We selected10 stars from TW Hydrae (5−15 Myr; we use 8 Myr, hereafter TWA, Kastner et al. 1997, Weinberger et al. 2013, and Webb & Zuckerman 1999), 22 stars from the β Pictoris moving group (20−26 Myr; we use 21 Myr, hereafter BPMG, Binks & Jeffries 2014; Malo et al. 2014b; Mamajek & Bell 2014), 8 stars from TucanaHorologium (20−40 Myr; we use 30 Myr, hereafter THA, Zuckerman & Webb 2000; Kraus et al. 2014b), 3 stars from Columba (20−40 Myr; we use 30 Myr, hereafter COL, Torres et al. 2008), 1 star from Argus (30−50 Myr; we use 40 Myr, Makarov & Urban 2000), and 12 stars from ABDoradus (110−130 Myr; we use 120 Myr, hereafter ABDor, Luhman et al. 2005; Barenfeld et al. 2013). Two other targets are young, but do not belong a stellar association. The membership of our targets is based on publications listed in Table 3. The number of known young, Mtype dwarfs has increased substantially thanks to recent surveys (such as 2MASS, ROSAT, Galex, and WISE) and to efforts to identify and characterize new, lowmass members of young moving groups (e.g., Torres et al. 2008; Schlieder et al. 2012; Malo et al. 2013; and Gagné et al. 2015b).

Distance: the M dwarfs in our sample are nearby (d< 62 pc) so that we can probe small starcompanion projected separations, typically down to 5−10 AU.

Brightness: the sample stars are brighter than K_{S} = 12 to allow for good AO correction and for the detection of lowmass planets.
These criteria are summarized for each target in Table 3. The closest and the youngest stars were observed in higher priority.
Observing periods. V stands for visitor mode, S for service mode.
2.1.2. The data
Data were acquired from December 2009 to February 2013, over five runs (see Table 2) with VLT/NaCo (Rousset et al. 2003). The observing conditions are described in Table D.8. NaCo includes an adaptive optics system (NAOS) and a nearinfrared camera (CONICA, Lenzen et al. 2003). It was mounted at the Nasmyth focus of the 8.2 m telescope UT4 at the time of the observations. CONICA is equipped with a CCD infrared camera, and an Aladdin 3 detector (1024 × 1024 pixels). We used the available infrared wavefront sensor (IRWFS/NAOS) to close the adaptive optics (AO) loop on faint red stars such as most MASSIVE targets.
We used the L27 camera (27.1 mas/pixel, and a field of view of 28″ × 28″) and the cube mode of NaCo, recording datacubes of single frames with exposure times as low as 0.175 s. We observed in L′ band (λ = 3.8 μm, Δλ = 0.62 μm) to improve our sensitivity to the coolest and therefore lowestmass companions. We used the pupil tracking mode with a high parallactic angle in order to apply Angular Differential Imaging (ADI, Lafrenière et al. 2007; Marois et al. 2006), a method that allows speckle subtraction and deeper closein sensitivity. Otherwise, we used regular field tracking.
Targets of MASSIVE with their characteristics.
2.2. Data reduction
We use our Interactive Data Language (IDL) pipeline developed for AO reduction at the Institut de Planétologie et d’Astrophysique de Grenoble (IPAG) to reduce the VLT/NaCo data. The reduction steps are described in Lagrange et al. (2010) and Delorme et al. (2012). They include bad pixel removal, flatfielding, and frame recentering. Two different methods are used to detect faint companions in the data, dependending on the separation from the star.
At separations closer typically than 0.5′′, noise is dominated by quasistatic speckles. To mitigate this and reveal faint, closein companions, we employ a modified angular differential imaging (ADI) algorithm called Smart ADI (SADI, Marois et al. 2006). The reference point spread function used for PSF subtraction in the SADI framework were derived from a restricted number of images (10) where each had rotated by at least one Full width at half maximum (FWHM) at a separation of 0.4′′. Candidate companions in this region are identified by visual inspection of the residual images.
At separations typically larger than 0.5′′, where the noise in L′band is background limited, we apply a medianfiltering technique. For each pixel in the region of interest, we subtract the median in a 20 × 20 pixel box centered on that pixel. This step is performed on each frame before stacking the images. Candidate companions are identified in this region using the automatic point source detection routine described in Delorme et al. (2012). When the field rotation is too small to apply SADI, which is the case for 18 of our targets, we only apply medianfiltering.
By combining these complementary approaches to candidate detection, we maximize our sensitivity at all separations. The boundary of the inner/outer zone that are used for each target are given in Table D.9 and detailed in Sect. 2.4.2.
2.3. Detection results
2.3.1. Companion detections
We detail hereafter the status of two companions already reported in previous papers and that are part of MASSIVE: 2MASS J01033563–5515561(AB)b and 2MASS J12073346–3932539b. In addition, we present the peculiar case of 2MASS J08540240–3051366, an Mtype star that we excluded from MASSIVE.
2MASS J01033563–5515561(AB)b
2MASS J01033563–5515561(AB), hereafter 2MASS0103(AB), is a 30 Myr Mdwarf binary located at 47 pc. Delorme et al. (2013) discovered an exoplanet orbiting this target, with an estimated mass of 12−14 M_{Jup} using BTSettl models (Allard et al. 2012). We do not present any new result with respect to this target.
2MASS J12073346–3932539b
2MASS J12073346–3932539 (hereafter 2M1207) is an 8 Myr brown dwarf located at 52.4 pc. Chauvin et al. (2005) reported the discovery of an exoplanet orbiting this target. 2M1207b (4 ± 1 M_{Jup}) is at a separation of 772 ± 4 mas (PA: 125.4 ± 0.3°), 768 ± 5 mas (PA: 125.4 ± 0.3°), and 776 ± 8 mas (PA: 125.5 ± 0.3°) from its host star, respectively, for the VLT/NaCo data from 27/04/2004, 05/02/2005, and 31/03/2005. In the 2009 data, we find a separation of 756 ± 12 mas, with a position angle of 124.6°. Our new measurement thus overlaps with the previously reported results and no additional contraints on the orbit is added. 2MASS J08540240–3051366B We conducted an indepth analysis (Appendix C) of 2MASS J08540240–3051366 (hereafter 2MASS J0854) because we identified a potentially interesting bound companion around it. However, a deeper analysis, using a new radial velocity measurement, revealed that the system is likely older than suspected (several Gyr instead of 10 Myr) and that the companion is a lowmass star. Thus, we do not include this target in our analysis.
2.3.2. Background stars
Nine MASSIVE targets were identified with candidate companions, in addition to 2MASS0103(AB) and 2M1207. Two methods were used to discriminate background objects from bonafide companions:
 1.
We used data obtained at different epochs, to test whether or notthe candidate and the star shared the same proper motion. If theydo, this would mean that they are gravitationally bound.
 2.
We used data obtained at different wavelengths when it was possible (J, H, K_{s}, L′bands), to compare the colors of the candidate with that expected for a background contaminant or a young planet companion. Indeed, young low gravity companions have much redder colors than main sequence contaminants: for instance, at 20 Myr, the BTSettl models predict that a 5 M_{Jup} planet would have H−L′ ≈ 2.5, while one of the reddest contaminants such as a 5 Gyr 0.3 M_{⊙} star, would have H−L′ ≈ 0.6.
2.3.3. Visual binary stars
We identified 13 close binary (<1′′) stars, which are reported in Table D.1. Some of them are very well resolved while others are tight or suspected binaries (some data show elongated intensity distributions).These binaries are studied within a larger sample of young binaries in another paper (Bonavita et al. 2016).
2.4. Detection limits in mass and semimajor axis for MASSIVE
In this section, we present the performances of MASSIVE in a (mass, semimajor axis) parameter space.
2.4.1. 2D contrast maps
Since we apply a different reduction technique at close and at large separations to detect SCs (see Sect. 2.2), we also derive 2D detection contrast maps in each case (see Delorme et al. 2012). Since the focus of this article is a statistical analysis, we choose to present the results from the simple and robust ADI technique such as SADI, rather than the slightly more sensitive LOCI (locally optimized combination of images, Lafrenière et al. 2007) or PCA (principal component analysis, Soummer et al. 2012) analyses that use subjective parameters (such as the size of the optimization zones in LOCI or the numbers of components kept in PCA) that can be optimized for individual analyses but not easily adapted for such a systematic analysis. The benefit of LOCI or PCA in sensitivity are moderated in L′band because the speckledominated area is smaller. We therefore caution that our detection limits on individual stars are probably conservative at short separations (see Table D.9) by typically a few tenths of magnitudes with respect to the best performance that could be achieved with a carefully tuned LOCI or PCA analysis.
2.4.2. 2D mass detection limit maps
We use Baraffe et al. (2003) evolution models that assume a hot start together with BTSettl model atmosphere (Allard et al. 2012) to estimate the masses of planets detectable at 5σ given the computed contrast limits. We emphasize that the systematic errors of the models are very difficult to quantify, and can be significant, see for example Dupuy et al. (2014). However, hotstart models have been commonly used for a long time and provide the best reference for the comparison between various imaging surveys.
Since the inner and outer regions of the 40 stars where SADI was applied are dominated by different sources of noise, we generate composite maps to cover the full range of possible semimajor axes. We determine the location of the boundary between the inner and outer regions on a star by star basis by comparing the detection limits reached using each image processing technique (the brighter the target, the wider the boundary, see Table D.9).
Figure 1 gives the median detection performances of MASSIVE in terms of contrasts in L′band and mass as a function of semimajor axis. The median detection performances for MASSIVE in apparent magnitudes of companions, is L′ ≈ 17 mag at 1′′ (at 5σ) and further away. The contrasts reachable at L′ are presented in Table D.9. The MASSIVE survey is the deepest DI survey yet conducted on M dwarfs.
Fig. 1 Median detection performances for MASSIVE in magnitude (L′band) and mass (M_{Jup}).

Open with DEXTER
2.4.3. Detection probabilities
Using the 2D mass detection limit maps that we built in Sect. 2.4.2, we estimate the probability to detect companions orbiting our stars, as a function of given mass and semimajor axis.
We use an optimized version (Rameau et al. 2013b) of the original MESS code (Bonavita et al. 2012) which takes into account projection effects that can hide a companion behind its host star on a fraction of its orbits. Hence the detection limits represent the sensitivity to planets according to their semimajor axis (hereafter, SMA) and not to their projected separations. From a technic point of view, MESS is a Monte Carlo simulation code that builds synthetic planet populations described in terms of frequency, orbital elements and physical properties. It uses a semiempirical approach to generate the planet populations using a regularly spaced grid. We generate 100 000 planets for each [mass,SMA] pair of the grid. The semimajor axis range is 0.5 to 1000 AU with steps of 2 AU and the masses are in the range [0.5,80] M_{Jup} with steps of 0.16 M_{Jup}. The MESS code computes the SMA for each synthetic planet for a given mass and period. It also assigns eccentricities, inclinations, longitudes of periastron, longitudes of ascending node and times of periastron passage for each orbit, assuming uniform distributions. The eccentricity values marginally affect the detection probabilities, while the inclination strongly affects the detection probabilities.
We apply the MESS code to all of our targets, taking into account the host star age, distance, and mass (using BTSettl models), as well as the masses and semimajor axes of the simulated planets, to derive mean planet detection probabilities for all MASSIVE targets (see Fig. 2).
We found that MASSIVE has a good sensitivity (mean detection probability > 50%) in the range 8 to 400 AU and 2 to 80 M_{Jup} (see Fig. 2) from the generation of 100 000 planets for each point of the [mass,SMA] grid. We consider only this best parameter range in most of the following analysis.
Fig. 2 MASSIVE survey mean detection probability curves (left) and contour plot of detection probabilities (right) for several masses, as a function of semimajor axis.

Open with DEXTER
3. Frequency of planetary companions orbiting lowmass stars of the MASSIVE survey
We detail the statistical formalism used for our Bayesian analysis in Appendix A.
For this analysis (Sects. 3 and 4), we exclude 4 targets out of the 58 targets of the MASSIVE sample, either because the estimated age is too uncertain (i.e., not members of young moving groups, like it is the case for 2MASS J14112131−2119503), or because of the close binarity of some targets that makes the total mass too big to consider it as a lowmass system (this is the case for 2MASS J01071194–1935359, 2MASS J05320450–0305291 and 2MASS J07285137–3014490, see Table D.2). However, we kept in our survey components of wideseparation binaries for which our AO observations allowed to look for SCs around each component individually. This led to a homogeneous sample of 54 targets.
3.1. Optimal parameter range to be considered in our formalism
The choice of parameter range on which we carry out our statistical analysis has a direct impact on the results. For instance, if we choose a broad range, such as [1−13] M_{Jup} and [1−1000] AU used by Rameau et al. (2013b), we include probability integration ranges like [1−8] AU or [400−1000] AU where our probability of detecting any planet is close to zero. This would lead to larger errors because of the lack of actual information injected into the probability calculation. Also, since we carried out a Bayesian analysis, including such ranges with no observational constraints would artificially bias the results toward a posterior that is close to the supposed prior. We therefore choose to focus on ranges of mass and SMAs for which the MASSIVE observational constraints are stronger (cf. Sect. 2.4.3), that is [2, 80] M_{Jup} or [1, 80] M_{Jup} at [8, 400] AU.
3.2. Results of our Bayesian analysis
3.2.1. Working hypotheses
We choose to address several distinct statistical questions (hereafter, we use Q as the mass ratio between a host star and its planet):

What is the probability to have a massive companion(2 M_{Jup}<M< 80M_{Jup}) regardless of its Q value?(case 1)

What is the probability to have a massive companion (2 M_{Jup}<M< 80M_{Jup}) at an intermediate mass ratio 0.01 ≤ Q ≤ 0.05 ? (case 2)

What is the probability to have a massive companion (1 M_{Jup}<M< 80 M_{Jup}) at a low mass ratio Q ≤ 0.01? (case 3)
We choose an upper limit of 0.05 for the intermediate mass ratio (case 2), because it excludes most lowmass star companions. Such companions might make the system appear as a binary, which could cause a selection bias because known binaries were excluded in the survey of Rameau et al. (2013b). Choosing such an upper limit in mass ratio keeps only the very high contrast companions in the selection range, and therefore effectively removes this possible bias.
We choose 1 M_{Jup} as a lower mass limit for case 3 since our previous lower mass limit (2 M_{Jup}, cases 1 and 2) is not relevant for such low Q because in practice it excludes all the lowest mass stars (<0.2 M_{⊙}) of our sample. Indeed, by choosing 1 M_{Jup} instead of 2 M_{Jup}, we increase the effective number of LMSs (number of stars in sample times average companion detection probability in the chosen semimajor axis and mass range) by 15% (see Table D.3). So, decreasing the lowermass limit allows to better constrain case 3, which is not true for cases 1 and 2. Our statistical formalism correctly addresses the fact that the sensitivity of MASSIVE concerning some stars for case 2 and 3 is very weak or even zero, with the hypothesis that the planetary frequency in the considered mass range is homogeneous.
More precisely, our three cases correspond to 3 working hypotheses: Case 1. We consider all detections, regardless of their Q: we want to know the frequency of stars hosting substellar companions (PMCs and brown dwarfs). We will therefore consider all known detections, namely the systems 2MASS0103(AB) and 2M1207. Case 2. We want to know the frequency of stars hosting SCs having a moderate mass ratio Q (that is 0.01 <Q< 0.05) only. With the limitations detailed below (see Sect. 3.2.2), this intermediate Q range would tentatively target objects formed via GI. For this second case, there is one detection in our sample (2MASS0103(AB)b). The median value for the MASSIVE targets is 0.45 M_{⊙}, corresponding to 22.5 M_{Jup} and 4.5 M_{Jup} companion upper mass limit for Q = 0.05 and Q = 0.01 respectively. Case 3. We consider SCs with a very low mass ratio Q, Q ≤ 0.01. With the limitations detailed below (see Sect. 3.2.2), this very low Q range tentatively targets objects that more likely formed via CA. There are no detections of such lowQ companions in the MASSIVE survey.
3.2.2. Companion frequencies for lowmass stars in MASSIVE
We use Eqs. (4) and (5) to determine the minimum and maximum value of the substellar companion frequency given a confidence level, respectively f_{min} and f_{max}, using Bayes rule and a binomial likelihood distribution (see Appendix A). In the case where no companion is detected in a given parameter range, we use Eq. (9) to determine f_{max}. We use both natural conjugate priors and uniform priors. Using a uniform prior is a strong hypothesis in terms of planet frequency probability distribution, and a hypothesis that is rather discrepant with the relatively low observed giant planet frequency. We nevertheless use it to compare our results with published ones which generally use it, mostly because uniform prior does not use any observational information, in other words it is fixed regardless of the data. Note also that the flat prior is not an uninformative prior. We also use our observational constraints by estimating a natural conjugate prior (see Appendix A) in our empirical Bayesian analysis. We consider that this conjugate prior is better adapted to our analysis than the uniform prior because it is much more consistent with observations.
Our statistical results concerning the MASSIVE survey are reported in Table D.6, Figs. D.1 and D.2. The figures show the frequency distributions derived considering the whole mass and SMA ranges, ie [0.5, 80] M_{Jup} and [0.5, 1000] AU. These parameter ranges are not optimal for our analysis (cf. Sect. 3.1) but present the advantages to show how sensitive the frequency distributions are with respect to the parameters choice. The results that we report in the next sections are based on the use of optimized parameters ranges (cf. Sect. 3.1). We find that % (68% CL) of our lowmass stars host at least one giant planet in the mass range 2−14 M_{Jup} and SMA range 8−400 AU. To derive this value, we use the natural conjugate prior and took into account the detection of the 2MASS0103 system. When we consider the same SMA range and a broader mass range, that is 2−80 M_{Jup}, we find that of our lowmass stars host at least one SC (68% CL, case 1), using a natural conjugate prior and considering the detection of 2MASS0103(AB)b and 2M1207b. The frequency distributions are wider when considering the uniform prior instead of the conjugate prior (see Table D.6, Figs. D.1 and D.2): the lower value does not change significantly, which is due to the fact that uniform priors assume more numerous planets, while conjugate priors use the observations that revealed few companions.
Our frequencies are lower for cases 2 and 3 which is expected because cases 2 and 3 companions are subsamples of case1 companions. We derive that % of the lowmass stars host at least one SC (68% CL, case 2: 2 M_{Jup}<M< 80M_{Jup} and 0.01 ≤ Q ≤ 0.05), the fraction range is [0%, 2.6%] for case 3 (1 M_{Jup}<M< 80 M_{Jup} and Q ≤ 0.01).
3.2.3. Strengths and limitations of our approach
Our objective is to derive the planet frequency around lowmass stars and compare this value with the frequency of planets orbiting highmass stars (see Sect. 4). In the present analysis, we focus on the mass ratio Q between the planets and their host stars instead of their masses, since the resulting Q can significantly differ if considering lowmass or highmass stars. For instance, while Q is around 20% for the 2M1207 system, its value is less than 1% for the β Pictoris system (Lagrange et al. 2010), more than an order of magnitude smaller, while the companion masses are comparable. This issue is particularly important since planetary formation mechanisms that take place in a protostellar disc (such as CA and GI) directly depend on the disc mass and hence on the stellar mass (Andrews et al. 2013). Formation scenarios are probably more sensitive to Q than to the mass of the companion. Indeed, CA is not expected to form planets with a mass ratio greater than a few percents (e.g., Mordasini et al. 2012). In contrast, GI has difficulties to form low Q companions and tends to form only companions with higher Q, such as brown dwarfs or even lowmass stars (e.g., DodsonRobinson et al. 2009; Vorobyov 2013).
However, the mass ratio needs to be used with caution, because it sometimes corresponds to companion mass ranges where survey sensitivities are low (e.g. for Q< 0.01, see “case 3” below, around lowmass stars). Another shortfall of using the mass ratio to extract observational constraints on companion formation mechanisms is that even though the range where each formation mechanism takes place is qualitatively clear (CA at low Q, GI at moderate Q and stellar formation mechanisms for high Q), they would likely overlap (e.g., Reggiani et al. 2016). Nevertheless, the semiarbitrary limits in the Q interval we retain for “case 2” (0.01 <Q< 0.05) accommodate both our goals of probing the range of “intermediate Q′′, and of probing the range of mass where our observational constraints are relevant. Moreover, in case 2, where Q = 0.05 and the host star mass is 2 M_{⊙} (the typical mass of an Atype star), we should include companions of up to 100 M_{Jup} that are cut by our additional limit in absolute mass of 80 M_{Jup}. Thus, the fraction f of the most massive stars hosting SCs is underestimated for case 2. That limitation cannot be avoided when comparing planet imaging surveys of lowmass stars and more massive hosts whether or not using mass ratio. Moreover, depending on the mass ratio, the statistical significance of each observation (that is the probability to detect a companion) is taken into account, depending on the considered mass ratio. For instance, a young lateM dwarf with a mass of 0.1 M_{⊙} would have a high statistical significance in case 1 because contrast around faint stars is usually favorable. On the contrary, this lateM dwarf would have a very low significance for case 3 (Q< 0.01) because only planets lower than 1 M_{Jup} would be taken into account, and our observations are only marginally sensitive to these masses. Despite these limitations, using the Q approach is an improvement over the common approach that consists of using only masses.
4. Impact of the stellar mass on the planet frequencies
In this section, we test the dependence of planet occurrence rate with respect to stellar mass (to identify possible population differences). To do so, we compare the planet frequencies found for the lowmass stars in MASSIVE to the ones corresponding to higher mass stars in Rameau et al. (2013b), which we derive using the same statistical formalism.
The sample that we use for comparison is made of 37 A to F type stars that are young (<100 Myr), nearby (<65 pc), and bright (K< 7 mag)^{2}.
Both surveys (MASSIVE and AF type stars survey) share roughly the same sample selection criteria (distance, age). The data were obtained, reduced and analyzed with the same tools so that relative biases are limited. The sensitivity of each survey is different which is properly handled by our statistical formalism see Fig. 4). In the following, we refer the MASSIVE targets as lowmass stars (hereafter LMS), and the AF type stars as highmass stars (hereafter HMS).
Fig. 3 Representation of the mass ranges considered for each of our MASSIVE targets (each vertical line represents one target). The upper dashed (respectively dotted) lines represent the upper mass limit for typical A (1.7 M_{⊙}; respectively F, 1.3 M_{⊙}) type stars, and the lowest lines are the lower mass limits for these typical A–F type stars. We limit our study to the planet and brown dwarf mass domain, we therefore fix the upper mass limit to 80 M_{⊙}.

Open with DEXTER
4.1. LMS and HMS companion frequency comparisons
As a first step, we use the KolmogorovSmirnov (KS) test to establish if the probability distributions of the SC frequency derived from each survey are similar or not. If the KS statistic is high, it hints that the two observed companion frequency distributions originate from distinct populations. Such a difference would be indicative of different companion populations as a function of the stellar mass. We use here the KS test to compare probability distributions that artificially count thousands of stars that KS test considers as “observations”. This means that the KS approach is only qualitatively relevant and cannot be used to provide quantitative probabilities. Deriving such quantitative probabilities is the purpose of the next section. Case 1. Actual detections corresponding to this case are made around 2MASS0103(AB) and 2M1207 for the LMS survey, and β Pictoris, HR 8799 and HIP 95261 for the HMS survey (cf. Fig. D.4). We find (see Fig. D.3) that (at 68% CL) of lowmass stars host at least one SC, while this fraction is for HMS^{3}. This difference might be significant, as it is associated to a high KS statistic (0.71). Case 2. We consider the detection of two systems; 2MASS0103(AB) for the LMS survey and HIP 95261 for the HMS survey. We find (see Fig. D.3) that the 68% confidence level (CL) companion frequency ranges are [1.7%, 5.6%] for LMS and [2.4%, 7.9%] for HMS. We find a KS statistic of 0.23. In Fig. 3, we summarize the mass ranges considered in case 2, and the overlap between the LMS the HMS surveys: for some stars, there is very little overlap or no overlap at all, depending on their mass. This is the case for the late M dwarfs in MASSIVE, but our statistical formalism properly handles this, hence they are included even if their actual statistical contribution is marginal or null. Case 3. No companion in the LMS survey fulfills the conditions of case 3, and for the HMS survey we include two systems (β Pictoris and HR 8799). We find that both distributions are well separated (see Fig. D.3) with a KS statistic of 0.82. We find that of the HMS host at least one companion (with 68% CL), while less than 2.6% (68% CL) of the LMS host one companion.
Fig. 4 Detection probability contours for the AF survey (top) and MASSIVE (bottom) for several masses, as a function of semimajor axis. The two white lines correspond to the mass ratio limits for cases 2 and 3 (respectively 0.01 < Q < 0.05 and 0.01 > Q).

Open with DEXTER
4.2. Relation between the SC frequency and the stellar mass
Results presented in Sect. 4.1 seem to qualitatively hint at the existence of two distinct populations of SCs around LMS and HMS. In this section, we quantitatively investigate the following question: are there two distinct populations of SCs, one for lowmass stars, and one for more massive stars?
To mitigate possible observational biases that would artificially enhance the inferred difference, we developed a Monte Carlo code that uses contrapositive logic to provide a conservative absolute probability of whether there are two distinct populations of SCs, depending on the mass of the host star. The idea is to test if the KS statistics that we derive using our observations when comparing the MASSIVE and the AF type star surveys are caused by the low number of detected planets, or truly distinct populations. Our rationale is the following: we assume that there is one unique underlying population of SCs by merging the two samples of stars to derive a single frequency distribution. Then, with the MC code, we test how likely it is that the random fluctuations in the observation of this single population can yield frequency distributions as different as our observations. The details of our code are described in Appendix B.
We report our results in Table D.7. We find a probability of 74.2% that there are two populations of SCs in case 1, 20.6% considering case 2, and 74.5% for case 3.
4.3. Discussion
We compared the frequencies derived from the two surveys in the 3 different cases of the allowed starplanet mass ratio Q described above. Case 1 (any mass ratio is allowed). We derived SC frequencies of for the LMS star sample and for the HMS sample described in Rameau et al. (2013b). We found that in a single population there is only ~26% chance to measure frequencies as distinct as we have. This translates to a ~74% probability that these observations are not randomly drawn from a single population but represent two distinct planet population frequencies. Case 2 (0.01 < Q < 0.05). We tentatively associated the intermediate mass ratios of Case 2 to planets more likely formed by GI. When comparing the lowmass and highmass star SC frequencies, we found moderately strong statistical evidence that there are not distinct populations around lowmass and highmass stars (see Fig. D.3), since we show that there is a ~79% probability that a unique SC population could reproduce the observed distribution of SCs. However, the corresponding companion masses for lowmass and highmass stars seem to be quite different; planetary mass companions for LMSs and mostly brown dwarfs for HMSs. Our results for case 2 hints the existence at large separations of an intermediate massratio population of substellar companions that is almost absent in results of surveys probing short separations and whose frequency would not be correlated with stellar mass. However, our contrapositive logical approach starts by assuming the existence of such a single population. Therefore, the probability derived for the existence of two populations are conservative by construct (as for cases 1 and 3), while on the opposite the ~79% of a unique population for case 2 is not. Our results only suggest that the existence of two distinct populations is not necessary to explain the data considered for case 2. Case 3 (Q ≤ 0.01). We found a ~75% probability that two distinct populations of companions exist around LMSs and HMSs. Given the sensitivity of our survey, we cannot exclude the possibility that less massive giant planets would be as frequent around LMSs as around HMSs. It is known that lowmass planets such as Neptunelike planet masses that form the bulk of gasgiant population around LMSs at short separations (see e.g., Bonfils et al. 2013), and a substantial population of superEarths to Jupitermass planets are detected at moderate separations (~0.5–10 AU) around LMSs using microlensing method (Cassan et al. 2012). Theoretical models of CA also indicate that the formation of giant planets at small separations by CA is difficult around LMSs (Mordasini et al. 2012). If the same is true at large separations, then the frequency derived in this work are significantly lower than the actual frequency when the Neptunelike planets are also considered.
Comparison with previous studies
We used a conjugate Bayesian prior which qualitatively assumes that since we found few giant exoplanets in the range we selected, low frequencies of exoplanets are more probable than high frequencies. This approach is different from that of Bowler et al. (2015) because 100% of our targets have been followedup, providing perfect completeness in our subsequent statistical analysis which is not the case in Bowler et al. (2015). In contrast with this study, we found some statistical evidence for a correlation between the SC frequency and the stellar mass at large separations.
It is difficult to compare our results with those from other surveys because most of the time the parameter ranges considered are not exactly the same. We therefore applied our formalism by considering exactly the same domains of mass and semimajor axis as those probed by each of RV and DI (Montet et al. 2014), micro lensing and RV (Clanton & Gaudi 2014), and RV surveys (Bonfils et al. 2013). Table D.5 shows our companion frequencies for these ranges and those derived within these surveys. For our calculations, we considered a 0.5 M_{Sun} star and a inclination of 60°. Our results are consistent with results described by Clanton & Gaudi (2014) and Bonfils et al. (2013). They reveal a tension at 1.5σ with the results of Montet et al. (2014), that is of marginal significance.
5. Conclusion
We conducted an adaptive optics survey for exoplanets orbiting nearby young low mass stars using L′band observations with NaCo at VLT. Two planetary mass companions were detected and previously reported (Delorme et al. 2013; Chauvin et al. 2004), but no additional companions were detected. From our significant data set (54 targets), we derived the planetary mass companion (and substellar companion) frequency, defined here by the probability that a star hosts at least one planetary (substellar) mass companion. We used Bayesian statistics with an optimized conjugate prior, and we selected the subrange in planet mass and semimajor axes where our data provides the best information, so that our statistics does not consider parameter ranges where our survey is not sensitive to companions. Our range of interest corresponds to planets more massive than 2 M_{Jup} and a semimajor axis between 8 and 400 AU. Using this range, we determined with a 68% confidence level that substellar companion frequency is %, and that planetary mass companion frequency is %. Considering all companions regardless of planettostar mass ratio, a Monte Carlo comparison between the substellar companion frequencies of the lowmass stars in the MASSIVE survey and a highermass AF type star survey shows that there is a ~74% probability that there are two distinct substellar companion populations, one orbiting around the lowmass stars and one orbiting around the highermass AF type stars. We also found a ~75% probability considering only lowmass ratios (Q< 1%). These results suggest that the frequency of imaged wideorbit substellar companions is correlated with the stellar mass, in agreement with theoretical expectations (see e.g., Laughlin et al. 2004). For intermediate mass ratios (1% <Q< 5%), the same comparison indicates a statistically significant similarity between the substellar companion populations around the lowmass star and highmass star samples. We acknowledge that our results showing that substellar companion frequency could be correlated to stellar mass are still moderately significant. We therefore need more observations to confirm this important result.
The star around which a new planet has been imaged (51 Eri b Macintosh et al. 2015) belongs the AF stars survey. However, the analysis led by Rameau et al. (2013b) takes into account the nondetectability of this planet (with the 2013 data) in the frequency derivation, so that this value is not affected by this new discovery.
The results we obtain for the HMS survey give a lower planetary frequency than those obtained by Rameau et al. (2013b). Using the same data, they found a probability of % at 68% confidence level and considering PMCs ([1, 13] M_{Jup}) at [1, 1000] AU, and they considered two detections, while we find a lower frequency (% for case 1). However, the [mass,semimajor axis] domain we consider focuses only on the range of parameters where the MASSIVE sensitivity is high. Moreover the error bars on our derived frequencies are smaller since we used a natural conjugate prior in our statistical formalism.
Acknowledgments
We thank the staff of ESOVLT for their support at the telescope. We acknowledge support from the French National Research Agency (ANR) through the GuEPARD project grant ANR10BLANC050401. We acknowledge financial support from “Programme National de Physique Stellaire” (PNPS) of CNRS/INSU, France. We thank Didier FraixBurnet for our discussions on statistics. The research of J.E.S. was supported by an appointment to the NASA Postdoctoral Program at NASA Ames Research Center, administered by Oak Ridge Associated Universities through a contract with NASA.
