Fig. 7


Composite HST images (from F336W U, F438W B, F547M y, F555W V, F657N Hα, F814W I) of objects from Table 3 demonstrating the “Quality” ranks listed in column 15. Both the F336W and F438W filter images make up the blue colors, F547M or F555W images are shown as green, while red colors are from F657N Hα and F814W. Each image is 10′′ on a side. Over-plotted is the 1.̋7 Spitzer point spread function. The quality ranks are: a) an isolated, excellent red candidate, rank 1; b) an extremely red candidate, rank 2; c) an unresolved cluster or other non-point source, rank 3; d) a compact association, rank 4; e) a likely background galaxy, rank 5. In these images, North is up and East is left.

This figure is made of several images, please see below:
