1. Introduction

In a recent paper (Mancuso & Garzelli 2013), we analyzed Faraday rotation measurements of extragalactic radio sources occulted by the corona in order to assess the inner heliospheric magnetic field in May 1997, shortly after the previous solar minimum in 1996. By inverting polarized brightness (pB) data taken from the Large Angle and Spectrometric Coronagraph (LASCO) aboard the Solar and Heliospheric Observatory (SOHO) during the days of observation, we were able to estimate the strength of the heliospheric magnetic field in a range of heliocentric distances spanning from ~5  R to 14 R. The Faraday rotation measurements used in that paper, made by Mancuso & Spangler (2000) with the Very Large Array (VLA) radio telescope of the National Radio Astronomy Observatory (NRAO), have been limited to heliocentric distances greater than 5 R because of a reduction in sensitivity due to solar interference in the beam side lobes. However, field estimates at shorter heliocentric distances are of pivotal importance since the strength and structure of the magnetic field in the region ≲5 R crucially affects the acceleration of the fast solar wind component, that in turn has strong influence on the space weather at larger distances. Among the known techniques for measuring the magnetic field in the middle corona, suitable coronal diagnostics are provided by the analysis of the radiation emitted by the local plasma during the passage of coronal shock waves (e.g., Mann et al. 1995: Mancuso et al. 2002, 2003; Bemporad & Mancuso 2010; Gopalswamy & Yashiro 2011). In the corona, when the difference in speed between an outward propagating coronal mass ejection (CME) and the solar wind is larger than the local fast-mode speed vF1, a forward magnetohydrodynamic (MHD) shock is produced ahead of the front. The collisionless shock leads to the generation of irreversible dissipation processes in the plasma, resulting in heating, acceleration of particles, generation of entropy, and emission of radiation. The accelerated electrons form velocity space beam distributions in the foreshock region that are unstable to the generation of Langmuir waves via wave-particle interactions, which in turn produce electromagnetic emission, leading to the formation of Type II radio bursts in dynamic spectra. Type II radio bursts appear as bands of enhanced radio emission slowly drifting from high to low frequencies and often show a typical fundamental-harmonic structure, i.e, two drifting bands with a frequency ratio about 2:1. The fundamental band, emitted at the electron plasma frequency kHz, relates directly to the local electron density ne and thus to the burst driver’s height. The measured frequency drift rate Df at a given time is directly related to the shock speed vsh and thus provides information on the shock dynamics through the corona. Both observations and theories suggest that Type II radio emission is generated just upstream of the shock (Cairns 1986; Bale et al. 1999), so that it should refer to ambient plasma rather than to shocked material. In a few cases, however, Type II emission appears to be split into two parallel lanes separated by a few MHz and is interpreted as plasma emission occurring both upstream and downstream of the shock front (e.g., Vršnak et al. 2002; Cho et al. 2007; Mancuso & Avetta 2008; Magdalenić et al. 2010). Under appropriate assumptions, the application of the Rankine-Hugoniot jump conditions, which relate the observed band splitting to the shock compression ratio, allows the local Alfvén Mach number MA = ush/vA to be inferred, where ush is the shock speed in the solar wind frame (ush = vsh − vsw). Finally, since by definition vA ≈ 2    ×    1011B/, if information on ne(r) and ush are available, B(r) can be easily estimated. In this Letter, by analyzing the band splitting of a metric Type II radio burst detected on 1997 May 12, we will show that this technique can be complementary to the coronal Faraday rotation method and is thus able to extend the profile of the magnetic field strength obtained at distances greater than 5 R down to about 2 R. In Sect. 2 we describe the observations; in Sect. 3 we show the results. A summary and discussion are presented in Sect. 4.

thumbnail Fig. 1

Radio dynamic spectrum from the Hiraiso Radio Spectrograph (HiRAS; inverse color scale: dark shading corresponds to bright emission) showing the Type II burst observed on 1997 May 12. The superimposed red boxes highlight the fundamental (F) and harmonic (H) split bands under study.

Open with DEXTER

2. Observations and data reduction

On 1997 May 12, a Type II radio burst was observed by both ground- and space-based radio instruments; it was a consequence of a full-halo CME event detected by LASCO C2 on board SOHO. The CME, expanding radially with an estimated speed of ~600 km s-1 (Plunkett et al. 1998), originated near the center of the Sun’s disk and was associated with an eruptive event observed by the Extreme Ultraviolet Imaging Telescope (EIT/SOHO) centered on active region NOAA 8038 at N20 W07. The metric Type II burst observed by the Hiraiso Radio Spectrograph (HiRAS; Fig. 1) shows both fundamental and harmonic components starting at 4:54 UT, 12 min after the onset of the associated GOES C1.3 X-ray flare. The Type II emission was also visible in the RAD2 dynamic spectrum of the Radio and Plasma Wave Experiment (WAVES) on board the Wind spacecraft for a short while below 13.8 MHz, ending at ~10 MHz (Gopalswamy & Kaiser 2002). Both Hiraiso and WAVES radio dynamic spectra show episodes of intermittent band splitting between about 4:54−5:00 UT in the metric band and around 5:12 UT in the decametric range. The two emission lanes show correlated frequency drifts, similar morphologies, and intensity variations, so that the emission is thought to originate from a common radio-source trajectory (Vršnak et al. 2001) rather than from different portions of one global shock surface. We thus interpret the observed band-splitting episodes as a consequence of plasma radiation from the regions upstream and downstream of the shock.

The estimate of the magnetic field strength from Type II band-splitting observations is particularly sensitive to the adopted density profile. Observations of the extended corona are primarily obtained with white-light coronagraphs that are able to detect coronal structures highlighted by photospheric radiation Thomson-scattered by free electrons in the ionized plasma. In general, it is difficult to infer ne(r) in the corona with remote-sensing techniques since the observed emission arises from the contribution of different structures integrated along the line of sight. However, during the previous solar minimum, the overall structure of the corona was highly axially symmetric so that ne(r) can be confidently estimated from the pB values extracted from the coronograph images by inverting a line-of-sight integral, according to the technique developed by van de Hulst (1950). The strength of a MHD fast-mode shock in the corona can vary because of the inhomogeneous distribution of vA, but it is very much enhanced on those parts of the wave front that encounter low-vA structures (Kahler & Reames 2003; Mancuso & Raymond 2004). For this reason, we applied the pB inversion technique along the densest part of the streamer belt (the equatorial region). In this work, we use a combined set of pB observations from both the NCAR/HAO Mauna Loa Solar Observatory’s (MLSO) MK3 coronameter and LASCO C2 recorded on the east limb about a week before the CME onset (Fig. 2). We implicitly assume that the corona has rotated almost rigidly during the interval of time from the reference pB observations to the onset of the Type II radio burst since no CME events have been recorded during this period above the east limb (according to the online SOHO/LASCO CME catalog available at the CDAW Data Center; Gopalswamy et al. 2009). From the combined pB radial profile, a radial power-law fit of the form pB(r) = Ar− α + Br− β (with r in units of R) was performed, after which a radial profile ne(r) = 4.27    ×    109r-9.97 + 4.32    ×    107r-3.25, roughly corresponding to three times the Saito et al. (1977) density profile, was obtained2.

thumbnail Fig. 2

pB radial profile from Mk3 (blue diamonds) and LASCO C2 (red squares) observations obtained on 1997 May 5 above the solar equator at the east limb and radial power-law best-fit to the data (solid black line); the inset shows the electron density profile ne(r) obtained from the pB inversion procedure.

Open with DEXTER

thumbnail Fig. 3

Measured emission frequencies as a function of time as derived from the analysis of the upper (fU) and lower (fL) frequency branches of the harmonic band of the 1997 May 12 Type II burst. Solid black lines represent linear fits to the logarithmic data; the dashed line shows the difference (fU − fL) of the fitted lines.

Open with DEXTER

3. Data analysis and results

According to MHD theory, the heating and compression of the downstream plasma depend on whether the shock is quasi-perpendicular (θBn > 45°) or quasi-parallel (θBn < 45°), with θBn the angle between the upstream magnetic field direction and the shock normal. Assuming that the solar wind is an ideal, adiabatic steady flow of plasma, the fluid equations and Maxwell’s equations can be integrated across a MHD shock to give a set of Rankine-Hugoniot jump conditions relating plasma properties on each side of the front. The observed band-split frequencies map the electron densities behind (nd) and ahead (nu) of the shock, so that in the upstream region the plasma emits radio waves at the frequency fL, while the compressed plasma in the downstream region (nd > nu) emits radio waves at frequency fU > fL. In Fig. 3, we show the measured emission frequencies as a function of time as derived from the analysis of the upper (fU) and lower (fL) frequency branches of the harmonic band as obtained from the dynamic spectrum at selected times, together with linear fits to the logarithmic data. The band splitting, simply related to the density jump X at the shock front by X = nd/nu = (fU/fL)2, implies modest (and slowly decreasing) compression (X ~ 1.5); X is related to the Alfvén Mach number MA, the plasma-to magnetic pressure ratio , and θBn by the cubic equation (e.g., Melrose 1986; Li & Cairns 2012) (1)where The above are all upstream quantities (γ = 5/3 is the ratio of the specific heats). The sound speed profile cS(r) was calculated as in Gibson et al. (1999), under the assumption that the plasma in the streamer belt is in radial hydrostatic equilibrium, yielding a maximum temperature of ~1.2  ×  106 K at 2.2 R. Foley et al. (2002), who analyzed the radial temperature behavior of coronal streamers at solar minimum by using the CDS/SOHO instrument, obtained a similar result. Given the compression ratio X, the above equation was solved for MA, with β expressed as a function of MA. Figure 4 graphically shows the results obtained by solving Eq. (1) for both quasi-perpendicular and quasi-parallel cases. The strong dependence on θBn is clearly evident. Since X = X(r), we are also able to infer the radial profile of MA for arbitrary θBn. Given MA = MA(r,θBn) and an estimate for the shock speed vsh, we obtain the radial dependence of the characteristic plasma speeds vA and vF (shown in Fig. 5 for the two cases of exactly perpendicular and parallel cases). For vsw, we adopted the upper limit of the estimate given by Strachan et al. (2000) at solar minimum obtained in the streamer belt from UVCS/SOHO data (≲30 km s-1). The difference between vA and vF is given by the contribution of the sound speed cS (β ≈ 0.1 in the perpendicular case). Relying on the above estimate of vA, we are finally able to infer B(r,θBn). The result is shown in Fig. 6. In the same figure, we also show an average estimate obtained by a similar analysis of the band splitting observed in the WAVES dynamic spectrum around 10 MHz. This analysis, however, is more uncertain owing to both the very small amount of available data and the higher heliocentric distance (~3  R) that makes the value of the solar wind speed more uncertain.

thumbnail Fig. 4

Compression ratio X (black line) and Alfvén Mach number MA for quasi-perpendicular (blue area) and quasi-parallel (red area) cases as obtained from the band-splitting structure observed in HiRAS.

Open with DEXTER

thumbnail Fig. 5

Radial profile of the shock speed vsh and comparison with the Alfvén speed vA and the fast-mode speed vF in the ambient corona for both parallel (∥) and perpendicular (⊥) cases. The sound speed cS and the solar wind speed vsw are also shown in the same graph.

Open with DEXTER

thumbnail Fig. 6

Radial profile of the magnetic field strength B: results from this work (see inset) and comparison with the profile inferred from Faraday rotation measurements of radio sources occulted by the corona (r ≈ 5−14  R; green line). Different colors identify the results obtained in the quasi-perpendicular (blue area) and quasi-parallel (red area) cases using both HiRAS (r ≈ 1.8−2.2  R) and WIND (r ≈ 2.8  R) data. The power law of the form B(r) = 3.76  r-2.29  G derived by Mancuso & Garzelli (2013; dotted line) nicely matches the two sets of data.

Open with DEXTER

4. Summary and discussion

We have analyzed the band-splitting of the 1997 May 12 Type II burst to determine the coronal magnetic field strength in the heliocentric distance range r ≈ 1.8 − 2.9  R. The coronal background density ne(r) was obtained by inverting white-light pB coronagraph data, and the shock speed was inferred from the Type II frequency drift. In this work, instead of limiting our study to perpendicular propagation, we considered arbitrary θBn, since mechanisms for acceleration of electrons at both quasi-perpendicular and quasi-parallel shocks have been devised (e.g., Holman & Pesses 1983; Mann et al. 2001). By using the Rankine-Hugoniot relations for MHD, which relate plasma properties on each side of the shock front, and using the compression ratio X inferred by the width of the band split, we found solutions for the Alfvén Mach number MA for arbitrary values of θBn. In the quasi perpendicular case MA ≈ 1.4−1.5, while in the parallel case MA ≈ 1.25, a value that is probably not sufficient to induce the acceleration of the electron beams responsible for the observed Type II emission; Type II emission requires MA ≳ 1.4 (Mann et al. 2003). The coronal magnetic field strength B inferred in this work by the analysis of the band-splitting from HiRAS and WAVES radio dynamic spectra (r ≈ 1.8−2.8  R) for both quasi-perpendicular and quasi-parallel

cases is shown in Fig. 6. In the same figure, we plot the radial profile obtained higher up in the corona (r ≈ 5 − 14  R) by Mancuso & Garzelli (2013) through Faraday rotation measurements of extragalactic radio sources occulted by the corona. The best-fit radial profile derived in that work, expressed by the power-law B(r) = 3.76  r-2.29  G, nicely describes the combined set of data in a wide range of heliocentric distances (r ≈ 1.8 − 14  R).


1

, where vA is the Alfvén speed, cS the sound speed, and θBn the angle between the magnetic field and the direction of propagation.

2

An enhancement factor of Cn = 1.3 was also applied as evinced from the analysis of Mancuso & Garzelli (2013). We note that the coronal density profile obtained in this work differs from that used in the previous analysis because the two profiles refer to different regions in the solar corona. The previous work concerned heliocentric distances up to ~ 14  R, where an ~ r-2 dependence for ne(r) is expected. For this work, the radial dependence is certainly much steeper in the height range of interest (< 3  R).

Acknowledgments

LASCO pB data are produced by a consortium of the NRL, Max-Planck-Institut für Aeronomie, Laboratoire d’Astronomie Spatiale and Univ. of Birmingham. SOHO is a project of international cooperation between ESA and NASA. MLSO is operated by the HAO, a division of the NCAR sponsored by the NSF.
