Fragmentation of electric currents in the solar corona by plasma flows
^{1}
Astronomical Institute,
AV ČR, Fričova 298,
25165
Ondřejov,
Czech Republic
email:
dieter.nickeler@asu.cas.cz
^{2}
MaxPlanck Institute for Solar System Research,
KatlenburgLindau, MaxPlanck
Strasse 2, 37191
KatlenburgLindau,
Germany
Received:
6
May
2013
Accepted:
14
June
2013
Aims. We consider a magnetic configuration consisting of an arcade structure and a detached plasmoid, resulting from a magnetic reconnection process, as is typically found in connection with solar flares. We study spontaneous current fragmentation caused by shear and vortex plasma flows.
Methods. An exact analytical transformation method was applied to calculate selfconsistent solutions of the nonlinear stationary magnetohydrodynamic equations. The assumption of incompressible fieldaligned flows implies that both the Alfvén Mach number and the mass density are constant on field lines. We first calculated nonlinear magnetohydrostatic equilibria with the help of the Liouville method, emulating the scenario of a solar eruptive flare configuration with plasmoids (magnetic ropes or currentcarrying loops in 3D) and flare arcade. Then a Mach number profile was constructed that describes the upflow along the open magnetic field lines and implements a vortex flow inside the plasmoid. This Mach number profile was used to map the magnetohydrostatic equilibrium to the stationary one.
Results. We find that current fragmentation takes place at different locations within our configuration. Steep gradients of the Alfvén Mach number are required, implying the strong influence of shear flows on current amplification and filamentation of the magnetohydrostatic current sheets. Crescent or ringlike structures appear along the outer separatrix, butterfly structures between the upper and lower plasmoids, and strong current peaks close the lower boundary (photosphere). Furthermore, impressing an intrinsic smallscale structure on the upper plasmoid results in strong fragmentation of the plasmoid. Hence fragmentation of current sheets and plasmoids is an inherent property of magnetohydrodynamic theory.
Conclusions. Transformations from magnetohydrostatic into magnetohydrodynamic steadystates deliver finestructures needed for plasma heating and acceleration of particles and bulk plasma flows in dissipative events that are typically connected to magnetic reconnection processes in flares and coronal mass ejections.
Key words: magnetohydrodynamics (MHD) / Sun: flares / Sun: corona / methods: analytical
© ESO, 2013
1. Introduction
In the standard flare scenario (e.g., Magara et al. 1996) the energy release of the primary flare (primary magnetic reconnection) takes place in the current sheet below a rising magnetic rope. Here, the plasmoids (the secondary magnetic ropes in 3D), which are a natural outcome of the reconnection process, are formed and ejected. The ejection of plasmoids can be traced observationally via soft Xray and radio waves, which map the magneticfield reconnection (Ohyama & Shibata 1998; Kliem et al. 2000; Karlický et al. 2002; Karlický 2004). With increasing spatial resolution of the solar photosphere and chromosphere, flares, jets, and plasmoids on different scales are observed (e.g., Cargill 2013; Cirtain et al. 2013). This means that the solar atmosphere is highly structured, and magnetic reconnection processes are ubiquitous. As such, the current sheets initiating reconnection processes cannot be smooth but must contain some internal fragmented structure. Consequently, magnetic reconnection itself must be fractal. As an efficient mechanism to cascade down to smaller scales, instabilities have proven to be an ideal trigger.
Many nonlinear, timedependent magnetohydrodynamic (MHD) simulations focus on linear and nonlinear instabilities, which are initiated via arbitrarily prescribed small perturbations of an initially smooth, static equilibrium. These instabilities typically result in reconnection, and in the following in fragmentation of the magnetic field and hence the current density (e.g., Bárta et al. 2010; Karlický & Bárta 2011; Bárta et al. 2011), forming chains of plasmoids (Loureiro et al. 2007; Uzdensky et al. 2010), coalescence and further fragmentation of plasmoids (Pegoraro et al. 2010; Karlický & Bárta 2011), and plasmoids on progressively smaller scales (Shibata & Tanuma 2001).
The process of cascading can also be initiated by stochastic velocity fluctuations, generating smallscale structures of the largescale magnetic field (Lazarian & Vishniac 1999; Kowal et al. 2009; Eyink 2011). This turbulent approach, however, originates from external perturbations impressed on initial background (magnetic and velocity) fields, requiring the prescription of initial noise, e.g., in the form of powerlaw spectra of perturbations. On the other hand, the turbulent reconnection can result from a successive coalescence and fragmentation of plasmoids, their fast heating, and an increase of the plasma beta parameter at some locations, where the flow instabilities become important as well (Karlický et al. 2012).
In contrast to studies using instabilities or turbulence as the initial trigger for fragmentation, the MHD theory itself inherently provides the cradles for fractal structures, because the MHD is scalefree and therefore applies to large as well as to small scales (Shibata 2012a,b). In their studies of the Earth’s magnetotail using a quasistatic adiabatic MHD approach, Wiegelmann & Schindler (1995) previously noticed the fragmentation of a thin current sheet. In their investigations, they found the formation of doublestructures of the current density when using nonsimilarity solutions of the quasistatic equations. Similarly, the numerical investigations of Becker et al. (2001) revealed the formation of thin current sheets from a sequence of static equilibria. Thus, instead of using perturbations of a smooth, static equilibrium, one might start directly from already structured, fragmented MHD equilibrium states. For this, one needs to construct a selfconsistent analytical description of the timeindependent, nonlinear dynamics (see, e.g., Nickeler & Fahr 2001; Nickeler et al. 2006; Nickeler & Wiegelmann 2010, 2012).
Separatrices form during magnetic reconnection processes, which originate in socalled Xpoints. These Xpoints can separate regions of closed and open field lines. The open fieldline regions can be regarded as field lines along which, e.g., the solar wind can flow into the interplanetary space, while the closed regions correspond to, e.g., magnetic arcades or flux ropes (plasmoids) from which plasma cannot leave. To stabilize such a configuration, in which strong flows occur outside and (almost) no flows inside, shear currents have to keep the system in equilibrium. Hence the physical problem can be approximately described with the static approach in regions of closed field lines, while in regions with open field lines the problem is in steadystate (see, e.g., Nickeler et al. 2006; Nickeler & Wiegelmann 2010, 2012).
Nickeler & Wiegelmann (2010) considered that the Alfvén Mach number, M_{A}, determining the strength of the flow and therefore the plasma velocity, vanishes within the plasmoid, so that the structure is basically magnetohydrostatic (MHS). However, not every closed fieldline region must necessarily be of MHS nature. Instead, plasmoids might contain vortices, because slight asymmetries during the ejection event could result in a nonzero angular momentum transfer. Hence the flow inside plasmoids can be sheared. Shear flows were found to produce current filamentation not only in solar or magnetospheric environments, but also in space and astrophysical plasmas, e.g., in astrophysical jets, where shear flows also induce the filamentation of currents (Wiechen et al. 1998; Konz et al. 2000).
In this paper, we investigate the role of shear flows within a configuration containing a magnetic dome and detached plasmoids, resembling a typical solarflare configuration after a first reconnection process. In our investigations, we used a selfconsistent analytical description of the timeindependent, nonlinear dynamics. The paper is structured as follows: in Sect. 2 we introduce the basic equations and the transformation method, while the results are described in Sect. 3. The assumptions are discussed in Sect. 4, and the conclusions are given in Sect. 5.
2. Basic equations
Fig. 1 Sketch of a magnetic configuration of a solar flare with plasmoids formed via magnetic reconnection processes.

Open with DEXTER
We assumed a magnetic configuration of a solar flare with a plasmoid formed via some first magnetic reconnection event (see Fig. 1). The plasmoid is enclosed by two Xpoints, while the plasmoid itself hosts a magnetic Opoint in its center. The equilibrium of such a system can be formulated using the steady/static approach. This is, however, only strictly valid if the plasmoid has no or only marginal motion in y direction. The dynamics of plasmoids depends on the reconnection rate at the Xpoints below and above the plasmoid, and plasmoids “in rest” (see, e.g., Bárta et al. 2008a,b) and stable (i.e. without further coalescence, see, e.g., Knoll & Chacón 2006) have been found by numerical simulations, justifying our assumption.
The choice of a certain equilibrium defines an arbitrary, but fixed lengthscale. This does not allow one to make inferences on the properties of the plasmoid on (much) smaller scales, on which, e.g., stationary shear flows related to vortex sheets might exist. Such shear flows would generate additional forces on the former MHS states, which can only be compensated for by changes in Lorentz forces and pressure gradients. To maintain the force balance selfconsistently, we applied the transformation method developed by Gebhardt & Kiessling (1992) and advanced/progressed by Petrie & Neukirch (1999) and Nickeler et al. (2006). In the past decades many attempts have been made to find exact and analytical solutions of nonlinear steadystate (=stationary) MHD equations (e.g., Tsinganos 1981; Contopoulos 1996; Goedbloed & Lifschitz 1997; Nickeler & Fahr 2005, 2006). However, the transformation is the only systematic method that physically and mathematically relates steadystate MHD flows to MHS states. For such a transformation to work, it is reasonable to request that in the stationary state the velocity field and the magnetic field are parallel (fieldaligned flows). This guarantees that the electric field vanishes, according to the ideal Ohm’s law (1)We note that other transformations between steady MHD states exist, which lead to configurations in which the velocity field and the magnetic field are not necessarily parallel (Bogoyavlenskij 2000, 2001, 2002). However, only in the case of incompressible fieldaligned flows one can always reduce the steadystate MHD equations to the MHS equations. Another advantage of the transformation method is that it is independent of the dimensions, i.e., it can be performed in 1, 2, and 3D.
2.1. Transformation from MHS states to stationary MHD configurations
In the following we restrict the analysis to subAlfvénic flows to emphasize in particular their relationship to MHS states. In addition, we use normalized parameters, for which we introduce normalization constants and , where is the normalized Alfvén velocity. Let v be the plasma velocity normalized on , ρ the mass density normalized on , j = ∇ × B the current density vector normalized on with as the characteristic length scale, and p the scalar plasma pressure normalized on . With these definitions, we can write the set of equations of stationary, fieldaligned incompressible MHD, consisting of the mass continuity equation, the Euler equation, the definition for fieldaligned flow and Alfvén Mach number, the incompressibility condition, and the solenoidal condition for the magnetic field, in the form This set of equations can always be reduced to the set of static equations using the transformation equations (for details see Nickeler & Wiegelmann 2010, 2012) of the form where the subscript S refers to the original MHS fields. Here it is a necessary condition that the Alfvén Mach number M_{A} and the density ρ are constant along fieldlines, i.e., An important property of this type of transformation is the fact that every transformed magnetic field strength  B  is stronger than the original static magnetic field strength  B_{S}  (as long as M_{A} ≠ 0). Moreover, as j is directly proportional to the term ∇M_{A}, which can have an arbitrarily (but not infinite) high value, basically every infinitesimale scale 1/∇ = l > 0 can be chosen. Therefore, we can produce a current that is higher than any current threshold to excite anomalous resistivity, such that currentdriven instabilities and hence magnetic reconnection can be induced. This generated current can be even more amplified when the Alfvén Mach number approaches the limit M_{A} ≲ 1. We stress that the transformation method provides a nonlinear selfconsistent solution of the stationary MHD equations, and changing any of the physical variables produces a nonlinear feedback of all other variables. Variations of M_{A} should not be misunderstood as an explicit timedependent change or sequence of the underlying MHS equilibrium, like in the quasistatic sequences of Wiegelmann & Schindler (1995) or Becker et al. (2001). Instead, the transformation has to be interpreted as a nonlinear variation or displacement of the former initial MHS equilibrium. That is, in affinity to variational calculus, the steadystates are “located” in the proximity of MHS states.
The set of transformation equations (Eqs. (7)–(11)) together with the conditions of Eqs. (12), (13) provide a “recipe” to construct fieldaligned, incompressible flows along the MHS structures. In practice, we first need to calculate an MHS equilibrium. In the following we assumed that the equilibrium has some sort of symmetry (e.g. in zdirection), so that it can be reduced to a pure 2dimensional (2D) problem^{1}. In that case, the equilibrium value of the magnetic field has the form B_{S} = ∇A(x,y) × e_{z}.
Next, we need to determine a Mach number profile, M_{A}(A). This profile has to depend locally only on the flux function, A, so that B_{S}·∇M_{A} = 0, and hence the condition Eq. (12) is automatically fulfilled. The “new” magnetic field, i.e., the steadystate field, is then given by a new flux function α, which is a function of A, such that (14)and B = ∇α × e_{z} (see Nickeler & Wiegelmann 2010). The prime denotes the derivative with respect to A. Armed with this Mach number profile and B_{S}, the set of transformation equations (Eqs. (7) to (11)) can be evaluated.
For the adopted 2D shape of the magnetic field the currenttransformation equation (Eq. (10)) takes the form The current fragmentation is strong where the magnetic field is strong, as the increase in current and its spatial variation is mainly governed by but amplified by (∇A)^{2}.
One interesting and important property of this transformed current is the fact that it can have a zerocrossing even for an initially monopolar MHScurrent distribution. This means that any suitable choice of a transformation can make j_{z} negative (positive), although the MHS current is completely positive (negative). In particular, the zerocrossing of the current requires that it has to vanish at some point, i.e., . This delivers a condition for the Mach number profile of the form (17)with the restriction (∇A)^{2} ≠ 0. As an important example of a monopolar MHScurrent we refer to Liouville’s equation given by ΔA = exp(−2A) (see Eq. (20) below). Because ΔA is always positive and (∇A)^{2} and are positive as well, the lefthand side derivative of Eq. (17) must be negative, i.e., . This condition can in principle be fulfilled with any suitable Alfvén Mach number profile that is monotonically decreasing with A (at least locally). This demonstrates the power of the transformation method and shows that it can be used to generate strong current fragmentation.
The zerocrossing is a definite sign that fragmentation can take place, but in many cases it is sufficient to have a strong gradient concerning M_{A} and/or a large (∇A)^{2}. On the other hand, this means that in the vicinity of a magnetic null point must be extremely large to compensate the vanishing magnetic field strength. Nevertheless, depending on the choice of the Mach number profile, current fragmentation can happen even without a zerocrossing of the transformed current.
3. Results
3.1. Nonlinear static equilibria
As described in the previous section, the first step is to derive a reasonable initial MHS equilibrium, which is able to reproduce a fieldline scenario with individual disconnected plasmoids, as drawn schematically in Fig. 1. For this, we used two wellknown equilibrium configurations and combined them.
Starting from the static magnetic field in 2D, B_{S} = ∇A × e_{z}, and inserting it into the MHS equilibrium equation (Eq. (11)) delivers the wellknown GradShafranovequation, often also called LüstSchlüterequation (see, e.g., Lüst & Schlüter 1957; Shafranov 1958) (18)Because B_{S}·∇A = 0 is valid, lines of constant A are field lines. This implies that the current j = −ΔA is constant along field lines, as is the pressure p_{S}, because they are functions of A, and consequently the isocontours of the current have the same topological and geometrical structure as those of the field lines.
For the pressure function p_{S}(A) we use (19)as derived in the frame of the Vlasov theory by, e.g., Bennett (1934), Harris (1962), and Kan (1973). The same function is typically applied in MHS or MHD configurations in which the pressure monotonically decreases in the direction perpendicular to the current sheet. Examples are flare configurations, magnetotails, and helmet streamers (see, e.g., Birn et al. 1975; Wiegelmann et al. 1998; Bárta et al. 2008a, 2010). With this pressure function, the GradShafranovequation has the form (20)also known as Liouville’s equation (e.g., Bandle 1975).
By defining u = x + iy, ν= x − iy, and i^{2} = −1, Liouville’s equation can be written as (see Bandle 1975; Birn et al. 1978) (21)The general solution of Liouville’s equation, Eq. (21), is given by (22)implying that every holomorphic function Ψ(u) gives us an exact solution of the nonlinear GradShafranovequation, Eq. (20).
The classical ansatz is (23)leading to the Harrissheet equilibrium (Harris 1962) (24)which represents a bipolar magnetic field structure, i.e., a plasma or current sheet separating magnetic fields with opposite orientations. This is a onedimensional structure.
A modified magneticfield structure including a normal component penetrating the 2D current sheet was calculated by Kan (1973) for the case of the Earth’s magnetotail region. Such a configuration emulates the dipole structure that extends into and influences the Earth’s magnetotail. In addition, with respect to configurations within the solar corona, such a scenario ideally resembles, e.g., magnetic dome structures. Kan (1973) chose the function Ψ = 2exp^{(}u + d/u^{)}, which drops off for  u → ∞. Here, d is a constant. This choice is a slight perturbation of the original 1D Harris sheet toward a 2D magneticfield configuration, converging for large distances back again to the original Harrissheet equilibrium. The corresponding flux function is (25)where . The resulting field lines, computed for d = 0.5, are shown in the top panel of Fig. 2, with the yaxis pointing in magnetotail direction, and the Earth (in the original Kan picture) located at the origin of the coordinate system. This scenario allows one to describe stretched, taillike structures, including a dipolelike configuration close to the Earth (i.e., for low values of y).
To describe the field lines of periodic structures, we applied the approach of SchmidBurgk (1967), who developed a formalism to solve Liouville’s equation resulting in the socalled periodic, corrugated sheetpinch. In this scenario, the original Harrissheet equilibrium is slightly modified to with δ as a constant, leading to the following flux function: (26)The field lines evaluated for δ = 0.1 are shown in the middle panel of Fig. 2.
For our purposes, we used the approaches from both Kan and SchmidBurgk, and combined them, i.e., we applied the modification of the Harrissheet found by SchmidBurgk (1967) to the Kan equilibrium. This is necessary, because we aim at achieving a representation in which the equilibrium has a strong B_{x}component close to the lower boundary y = 0 and a periodicsheet pinch for y → ∞. This means that Ψ is now represented by (27)With this function, we finally obtain a flux function of the form (28)whose contour plot has field lines as depicted in the bottom panel of Fig. 2. In our representation the yaxis corresponds to the height above the solar photosphere, and the photosphere itself is located at y = 0. The symmetry axis of the postflare magnetic field configuration is given by x = 0. This flux function (Eq. (28)) is used in the following and serves as our initial MHS equilibrium.
Fig. 2 Field lines for the Kan magnetotail (top), the periodic sheet pinch or periodic Harris sheet (middle), and the combined one (bottom) that serves as our initial MHS equilibrium.

Open with DEXTER
3.2. Different transformation approaches
There exist three different approaches to model field aligned shear flows. These are the transformations via

magnetic field amplification defined by α′,

peaked plasma flows defined by M_{A}, and

asymptotical 1D current structures defined by j.
Each approach requires the specification of either one of the finally transformed MHD values (such as the current or the magnetic field, the latter is even identical to the transformation itself), or the plasma flow of the stationary MHD configuration. In combination with the prescribed intrinsic MHS values, the corresponding transformation between these two states can be evaluated.
As we have shown, Eq. (14) describes two equivalent methods for a transformation, i.e., via the calculation of either the transformed magnetic field, specified by α′, or the plasma flow in the transformed configuration, given by M_{A}. On the other hand, it is also reasonable to compute the Mach number profile via Eq. (15) by specifying the asymptotic behavior of the transformed current j. These three methods are basically equivalent, but each of them emphasizes a different physical aspect of the fragmentation problem, and consequently needs different constraints and boundary conditions. More specifically, each method is based on the prescription of one physical parameter that serves as control parameter.
3.2.1. Transformation via magneticfield amplification defined by α′
The first mapping method has been described in detail by Nickeler et al. (2006). It is based on the prescription of the magnetic field and is best applicable for potential fields that are asymptotical homogeneous, i.e., their flux function is given by A ≈ B_{S∞}x for large y. In that case, the transformation between the new, steadystate flux function α and the old, stationary flux function A is given by This transformation, which is based on the calculation of α′, produces a series of k Harrissheets with different strengths a_{k}/d_{k} and widths d_{k}, offset by A_{k} from the MHS state. The parameters C, A_{k}, a_{k}, and d_{k} are not completely free. They have to be chosen such that α′(A) > 1 to guarantee subAlfvénic flows and to satisfy the boundary conditions or constraints, provided, e.g., by observations. The number of Harristype current sheets k depends on the number of separatrix lines originating in potential Xpoints. This means that k is determined or fixed by the number of “pauses”, i.e., boundary layers, within the chosen domain. The location of the pauses is marked by A_{k}. Such transformations are ideal for a proper modeling of tail configurations as they appear in the heliotail (or astrotails in general, see Nickeler & Fahr 2001; Nickeler et al. 2006), which require the maintenance of strong current sheets that form the boundary layer in the vicinity of the seperatrix (heliopause/astropause) in between the outer solar/stellar wind and the very local interstellar medium.
3.2.2. Transformation via peaked plasma flows defined by M_{A}
For the second possible transformation method a Mach number profile M_{A}(A) has to be specified. To obtain a highlystructured current distribution, the Mach number profile needs to contain strong gradients and must show strong spatial variation. This means that M_{A} cannot be given by a simple twodimensional function, but has to be constructed out of several pieces or branches, which need to be connected by continuous transitions, meaning that each of these branches must be at least twice continuously differentiable at the boundaries of the intervals so that no discontinuities in the current density profile appear. Consequently, the function M_{A} must be composed of a set of functions m_{k}(A), which exist only within some defined fieldline interval and vanish outside. In addition, the functions m_{k}(A) must have a compact support to guarantee that both and , i.e., the Mach number and its constituents are bounded functions (subAlfvénic).
This goal can be achieved in different ways: (i) One may define piecewise functions that vanish at the boundary of some fieldline interval; (ii) one may apply purely the classical partition of unity; (iii) the partition of unity is used in combination with a continuous sum, i.e., continuous distribution of flow tubes that can be written as an integral. This means that we can define a general function for M_{A} of the form (31)which consists of a sum over k individual peaked plasma flows, each defined within discrete fieldline intervals, and a continuous distribution m(A) of plasma flow tubes.
Such an approach with a pure continuous distribution m(A) ~ 1/cosh(A)^{2} has been used, e.g., by Nickeler & Wiegelmann (2010) to generate a single currentsheet along a magnetic separatrix. In contrast, we show in Sect. 3.3 an example in which piecewise functions are defined.
3.2.3. Transformation via asymptotical 1D current structures defined by j: the inverse method
The third method to determine the transformation is based on the prescription of the transformed current, j, given by Eq. (15) (see also Nickeler et al. 2006). Typically, in magnetostatics the magnetic field is directly calculated from Ampère’s equation ΔA = −j, where the current distribution j is prescribed. In MHD, a prescription of the current distribution or the magnetic field is not possible. Here, the values have to be calculated selfconsistently and simultaneously from the nonlinear MHD equations. But the transformation method enables us to define the current distribution in configurations that occur ubiquitously in space plasmas as an explicit function of the flux function A. If we can find a way to prescribe the current density j as a spatially, i.e., depending on A(x,y), strongly variable current distribution, we can generate selfconsistently current fragmentations on small scales, emulating scenarios that in the literature are often approached via turbulence originating from external perturbations (Lazarian & Vishniac 1999; Kowal et al. 2009; Eyink 2011).
As was shown in Sect. 2.1, the current distribution, resulting from the transformation, is given by (32)with j = j_{z}(x,y). The terms α′′,α′, and ΔA are pure functions of the flux function A. On the other hand, the quadratic expression (∇A)^{2} is a scalar function and generally a function of x and y, which, in the case of 2D equilibria, cannot be expressed as an explicit function of A only. Instead, Eq. (32) is an equation defining or rather determining j(x,y) ≡ j(A,y) from a given transformation α′, which seems to be the most consequent and logical method. However, Eq. (32) cannot be regarded as just a pure ordinary differential equation for α′. Therefore, calculating α′ from Eq. (32) for a given or prescribed j, has in general no formal solution (see Appendix A). Based on this mathematical problem, it is necessary to find a different approach.
Magnetohydrostatic equilibria in space plasmas often have regions where the fields are extremely stretched. Such taillike regions typically occur far away from bipolar or even multipolar field regions, as, e.g., in our case (bottom panel of Fig. 2) in the regions of high  x  values, or, in the case of the Kan equilibrium, also in the regions of high y values (top panel of Fig. 2), or in general for going to ∞ along or in the direction of the tail axis. The regions of stretched field lines can be approximated by a 1D configuration, which depends only weakly on a second coordinate. Examples are asymptotically 1D regions of exact and analytical tail equilibria or socalled weakly 2D or weakly 3D equilibria (see, e.g., Schindler 1972, 1979; Birn et al. 1977). The advantage of this asymptotically 1D approach is that the equilibrium problem can be treated as if it depended on only one coordinate. This coordinate is, at least locally, a unique function of the fieldline label A, and vice versa, so that in a local coordinate system A can always be chosen as coordinate. Therefore, in these stretched field line regions, the problem can be solved. The solution found is, however, a general solution and not restricted to the pure 1D region, because every found solution for  α′ > 1 is an exact solution of the subAlfvénic steadystate problem (Eqs. (7)–(11)).
Assuming that lim_{x,y → ∞}B_{S} = B_{S∞}, we define  B_{S∞} = B_{S∞}(A). The limes has to be smooth. Then we can introduce the asymptotical current via ∇ × (lim_{x,y → ∞}B_{S}) = lim_{x,y → ∞}(∇ × B_{S}) = lim_{x,y → ∞}j_{S}, with lim_{x,y → ∞}j_{S} = j_{S∞}(A) = P_{S} ′(A). The last identification thereby again represents the GradShafranovequation (Eq. (18)). With these relations, Eq. (32) can be written as (33)This pure onedimensional differential relation is now a linear ordinary differential equation of first order for α′(A), which can be solved: We divide both sides of Eq. (33) by and multiply with the integrating factor . This leads to a complete differential that can be integrated, resulting in the following general solution (34)Thus for reasonable prescribed stationary asymptotic current densities j_{∞}(A), the general solution of the transformation α′ can be computed from the asymptotic MHS functions for the current density j_{S∞}(A) and the magnetic field B_{S∞}(A). The parameter C_{0} is an integration constant, defining an offset and a boundary condition for α′, hence M_{A}.
To find suitable prescriptions for j_{∞}(A) that guarantee α^{′2} > 1 also in the twodimensional regions is a difficult practical task. However, with this approach it is basically possible to generate current fragmentation scenarios based purely on the selfconsistent solution of the MHD equations. Hence, the transformation method provides a selfconsistent tool in which current fragmentation is a basic property of the nonlinear MHD theory, because j_{∞} is basically not subject to any limitations.
3.3. Example for shearflowinduced current fragmentation
The aim of our analysis is to study the process of current fragmentation that takes place in the vicinity and within an ejected plasmoid that was formed via magnetic reconnection in a typical solar eruptive flare. Observations of such flare processes indicate that the surrounding material on the open fieldlines is moving upwards, while the plasma below the Xpoint located in between the two plasmoids (see Fig. 2), i.e., within the closed fieldline region, can be assumed to be static^{2}. With this picture, it is more convenient to apply the transformation method based on the prescribed nonzero subAlfvénic Mach number profile rather than based on the asymptotic current distribution or the magnetic field amplification, because the latter two are extremely difficult to extract from observations, in particular because of the stilllacking high enough spatial resolution.
In a bipolar MHS structure, assuming the main direction of the magnetic field to be the ydirection, i.e., B_{y} > B_{x} outside the outer separatrix, the main component of the magnetic field, B_{y}, changes its direction and therefore its sign. For symmetric magneticfield lines with respect to the yaxis, A is a symmetric function of x (i.e., B_{S} is antisymmetric and A is symmetric with respect to the yaxis). As M_{A} is a function of A, and the plasma flow is required to be purely upstreaming on both sides (boundary condition), the Mach number profile needs to change its sign. Consequently, one needs to define a piecewise function M_{A}(A) with at least two different branches (left and right of the outer separatrix). Otherwise, M_{A} cannot change its sign.
The Mach number profile, which we apply now to simulate such a scenario, consists of several branches: Within the dipolelike region inside the closed fieldlines, which is assumed to be static, M_{A} = 0. In the regions outside the outer separatrix, we assume that the Mach number profile is symmetric, i.e., M_{A}(−x,y) = −M_{A}(x,y), although asymmetric profiles might also be possible. We furthermore assume that for x < 0 the plasma flow is parallel to the magnetic field (M_{A} > 0), while for x > 0 it is antiparallel (M_{A} < 0). To guarantee a continuous transition between the positive and negative Mach number branches (i.e., to have a smooth flow pattern), M_{A} must vanish at the separatrix itself. To ensure that the current j is also continuous, M_{A} and its derivative must be continuously differentiable in the boundary region (separatrix). Furthermore, we assume that the upper, disconnected plasmoid contains a vortex. This assumption is reasonable, because any small asymmetry during the reconnection process and the disconnection of the plasmoid will immediately result in a nonzero angular momentum and hence in a rotational motion of the plasma. Hence, its representation in the Mach number profile is given by a maximum in the center of the plasmoid, and strong gradients from the center to its edges.
With these specifications, our Mach number profile covering the region in x and y as defined by the MHS configuration (see Fig. 2) is given by the following four branches it is displayed in Fig. 3. Hereby A_{sep} represents the outer separatrix and has the numerical value A_{sep} = 0.0875, and A_{b} is a parameter influencing the steepness of the Mach number profile, and therefore the width of the current sheets. For our model computations we choose A_{b} = 0.1. The parameters f and f_{p} are functions of A, simulating small wavelike spatial fluctuations. For the example presented in Fig. 4, we used f = 1−0.1sin(1.1A) and f_{p} = 1.
Fig. 3 Constructed Mach number profile.

Open with DEXTER
Fig. 4 Static (left) versus stationary (right) current (top) and its isocontours (bottom). For better visualization the current is plotted inversely and cut off at the numerical value of 2. The maximum at the origin approaches a numerical value of 6.

Open with DEXTER
Starting from the MHS equilibrium configuration for the flux function and its corresponding current distribution (see Sect. 3.1), we applied the mapping defined by the Mach number profile. The resulting current and its isocontour lines are displayed in the upper and lower right panels of Fig. 4. Obviously, the current distribution shows new features, which did not exist in the static case (left panels of Fig. 4). These are ringlike and crescentshaped structures around both the lower, static configuration and the upper disconnected plasmoid. In both cases, these new current sheets are located outside but along the separatrix. In addition, inside the detached plasmoid, the current appears domelike in the center, and two more current sheets (current “islands”) formed close to the separatrix. These new current structures (sheets, islands, maximum) are also visible in the isocontour plot. There, additional butterflylike current islands appear in the vicinity of the Xpoint of the outer separatrix. The strongest currents can be recognized at the “Kan dipole”region, because the increase of A and  B_{S}  in the region of the pole of A results in strong currents already in the MHSstate. Applying the shear at the outer separatrix enforces this effect in particular at the bottom separatrix (in the vicinity of the photosphere), generating two additional current peaks. In the center of the static configuration (where M_{A} was set to zero), the current structure has not changed. In contrast to the GradShafranov theory, the stationary current isocontours do not (completely) resemble the fieldline structure anymore.
To highlight the motion of the plasma, we display in Fig. 5 the x and y components of the normalized (with respect to density) plasma velocity field. The y component shows that in the outside regions it is always positive, in agreement with an upstream behavior of the flow on the open fieldlines. The clockwise rotational flow of the plasma within the upper plasmoid is obvious from the y component of the flow being positive on the left side of the plasmoid, and negative on the right side. The x component of the flow is generally very small with a wavy structure due to the curved open fieldlines in the vicinity of the outer separatrix. Only the circular flow inside the upper plasmoid has slightly higher velocity.
Fig. 5 x and y components of the plasma flow field.

Open with DEXTER
In summary, from an initially smooth current distribution our applied mapping created a new distribution, which shows multiple current filaments that can be regarded as current fragmentation.
Fig. 6 Mach number profile (top), transformed inverse current density (middle) and its isocontours (bottom), for a narrower intrinsic current sheet with A_{b} = 0.01 and an intrinsically structured plasmoid with f_{p} ≠ 1.

Open with DEXTER
4. Discussion
The results shown in the previous section serve as an illustration. There, the width of the current sheet, prescribed by the parameter A_{b}, was set to a value of 0.1, which resulted in pure, crescentshaped current sheet structures. However, decreasing the value of A_{b}, i.e., steepening the Mach number profile and shrinking the width of the current sheet resulted in additional fragmentation of the crescentshaped current sheet into several strong current peaks, as shown in the middle panel of Fig. 6 for which A_{b} was set to 0.01. For better visualization the current was cut at the numerical value of ten. From these results we may thus conclude that fragmentation is enforced when reaching smaller scales of the shear flows. Furthermore, fragmentation of the flux rope’s current density profile occurs when the parameter f_{p} is different from 1. In the example depicted in Fig. 6 we used f_{p} = 1−0.1sin [1/(A^{2} + 0.01)] and f = 1. The corresponding Mach number profile, which now already shows a smallscale structure imprinted on the plasmoid, is shown in the top panel of Fig. 6. The finestructure obtained in the transformed current is obvious from both the current density profile and its isocontours (bottom panel of Fig. 6). For better visualization we also show in Fig. 7 a highresolution zoom of the isocontours and the inverse current density for the same model parameters as in Fig. 6. The zoomed region contains the left side of the plasmoid. The plot of the isocontours demonstrates that the topology of the current isolines is much more complex than the one of the flux function isolines, i.e., the magneticfield lines. The bottom panel of Fig. 7 displays the comparison between the static (dashed lines) and the stationary, fragmented current density (solid line) along the yaxis within the plasmoid region for x = −0.4. This plot highlights the strong spatial variation of the stationary current density, which shows steep gradients that imply fragmentation of the initially smooth current sheet. This relatively simple example stresses that to achieve fragmentation on much smaller scales, it is essential to use a Mach number profile, which is much more complex and contains highly alternating structures, e.g., in the form of sawtoothlike or other oscillating functions. Furthermore, every Mach number profile could in principle successively and infinitely be refined by, e.g., an iterative scheme of the form f((M_{A})_{n}) = (M_{A})_{n + 1}. Such an iterative mapping can be performed because (M_{A})_{n} is constant along the field lines, so every regular function or mapping has to be constant on the field lines as well. These iterations define fractal structures and hence demonstrate the fractal nature of MHD. The concept of fragmentation in the frame of ideal MHD remains valid down to length scales of 100 m to ~5 m for conditions typical for the solar corona. The value of ~5 m thereby corresponds to the ion inertial length, defined as the ratio of the speed of light and the ion plasma frequency. On length scales similar to and shorther than the ion inertial length, either the HallMHD or the twofluid MHD needs to be applied.
Fig. 7 Highresolution zoom into the plasmoid region for the same model as in Fig. 6. Shown are the isocontours (top), the transformed inverse current density (middle), and a cut through the current density at x = −0.4 (bottom) for the stationary (j_{z}, solid) and the static case (j_{zs}, dashed).

Open with DEXTER
In our analysis we ignored resistive or nonideal effects to guarantee the existence of plausible stationary flows. However, the presence of nonideal terms, particularly in the shape of a resistivity on the righthand side of Ohm’s law, does not automatically imply the nonexistence of stationary solutions. The inclusion of a resistivity, η, such that ∇ × (ηj) = 0, supports stationary nonideal MHD flows and hence the existence of ideal equilibria. The stationarity of Maxwell equations in 2D demands that the electricfield component E_{z} = ηj_{z} is constant. As E_{z} is at the same time the reconnection rate, this implies that the reconnection rate is independent of the resistivity (e.g., Knoll & Chacón 2006). Consequently, even if, as in our case, the flows are fieldaligned and steadystate, these MHD flows can be regarded as an analogy to steadystate reconnection solutions with constant reconnection rate. The existence of resistive steady states with fieldaligned flows and reasonable resistivity profiles has been shown by Throumoulopoulos & Tasso (2000, 2003). Under such conditions in our 2D case, Ohmic heating of the plasma is directly proportional to j_{z} and occurs everywhere where filamentation or fragmentation takes place and could in principle contribute (at least partially) to the heating of the corona.
Although we had limited our analysis to a pure 2D configuration, the transformation technique is valid in all dimensions because it is based on vector analysis identities. Therefore, starting from a 3D MHS equilibrium, the mapping would deliver current fragmentation also in 3D. However, to find suitable MHS equilibria as starting configurations is a difficult task, hence precomputed fully 3D MHS equilibria are so far rare. MHS equilibria for laminar flows and magnetic fields have been constructed by, e.g., Petrie & Neukirch (1999), which might serve as starting points for a future 3D analysis.
5. Conclusions
Observations of the solar atmosphere with increasing spatial resolution reveal that the atmosphere is highly structured or fragmented. Hence, the mechanisms initiating the formation of smallscale structures, such as jets, flares, and plasmoids, which typically occur as a result of magnetic reconnection processes of current sheets, must be inherently fractal.
Although solutions of the MHD equations pretend that physical parameters, such as the magnetic field or the current, are smooth on large scales, they do not necessarily have to be smooth on small scales. This is shown by our analysis, in which, starting from an MHS equilibrium with a smooth current distribution for a stationary plasmoid configuration, we obtained a current structure displaying steep gradients, i.e., strong spatial variations of the current density, as well as an internally fragmented plasmoid, depending on the initially chosen Mach number profile. Hence, pure MHD equilibria are able to display intrinsic fine structure, which can serve as the seeds for instabilities, i.e., as “secondary instabilities” (see, e.g., Pegoraro et al. 2010), and therefore as triggering mechanisms for secondgeneration current fragmentation.
Because the MHD equations are scalefree, our results are valid not only for the global flare scale, but also for scales close to dissipation scales.
As a natural next step, our stationary equilibrium configuration should be implemented into MHD simulations as the starting configuration, to see and test the onset of instabilities and the timedependent evolution of the resulting additional current fragmentation.
In dynamical flare scenarios, the plasma within the closed arcade structure tends to flow downwards, i.e. back to the surface because of plasma cooling, which forces the arcade structure to shrink. However, our model aims at studying the posteruptive flare phase, in which the photospheric layers (i.e., the arcade structures at the bottom of our configuration) are back in static equilibrium (see, e.g., Wang et al. 2012).
Acknowledgments
We thank the anonymous referee for useful comments and suggestions on the draft. This research made use of the NASA Astrophysics Data System (ADS). D.H.N. and M.K. acknowledge financial support from GA ČR under grant number 1324782. M.K. also acknowledges financial support from GA ČR under grant number P209/12/0103. The Astronomical Institute Ondřejov is supported by the project RVO:67985815.
References
 Bandle, C. 1975, Archive for Rational Mechanics and Analysis, 58, 219 [NASA ADS] [CrossRef] [Google Scholar]
 Bárta, M., Karlický, M., & Žemlička, R. 2008a, Sol. Phys., 253, 173 [NASA ADS] [CrossRef] [Google Scholar]
 Bárta, M., Vršnak, B., & Karlický, M. 2008b, A&A, 477, 649 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Bárta, M., Büchner, J., & Karlický, M. 2010, Adv. Space Res., 45, 10 [NASA ADS] [CrossRef] [Google Scholar]
 Bárta, M., Büchner, J., Karlický, M., & Skála, J. 2011, ApJ, 737, 24 [NASA ADS] [CrossRef] [Google Scholar]
 Becker, U., Neukirch, T., & Schindler, K. 2001, J. Geophys. Res., 106, 3811 [NASA ADS] [CrossRef] [Google Scholar]
 Bennett, W. H. 1934, Phys. Rev., 45, 890 [NASA ADS] [CrossRef] [Google Scholar]
 Birn, J., Sommer, R., & Schindler, K. 1975, Ap&SS, 35, 389 [NASA ADS] [CrossRef] [Google Scholar]
 Birn, J., Sommer, R. R., & Schindler, K. 1977, J. Geophys. Res., 82, 147 [NASA ADS] [CrossRef] [Google Scholar]
 Birn, J., Goldstein, H., & Schindler, K. 1978, Sol. Phys., 57, 81 [NASA ADS] [CrossRef] [Google Scholar]
 Bogoyavlenskij, O. I. 2000, Phys. Rev. E, 62, 8616 [NASA ADS] [CrossRef] [Google Scholar]
 Bogoyavlenskij, O. I. 2001, Phys. Lett. A, 291, 256 [NASA ADS] [CrossRef] [Google Scholar]
 Bogoyavlenskij, O. I. 2002, Phys. Rev. E, 66, 056410 [NASA ADS] [CrossRef] [Google Scholar]
 Cargill, P. 2013, Nature, 493, 485 [NASA ADS] [CrossRef] [Google Scholar]
 Cirtain, J. W., Golub, L., Winebarger, A. R., et al. 2013, Nature, 493, 501 [NASA ADS] [CrossRef] [Google Scholar]
 Contopoulos, J. 1996, ApJ, 460, 185 [NASA ADS] [CrossRef] [Google Scholar]
 Eyink, G. L. 2011, Phys. Rev. E, 83, 056405 [NASA ADS] [CrossRef] [Google Scholar]
 Gebhardt, U., & Kiessling, M. 1992, Phys. Fluids B, 4, 1689 [NASA ADS] [CrossRef] [Google Scholar]
 Goedbloed, J. P., & Lifschitz, A. 1997, Phys. Plasmas, 4, 3544 [NASA ADS] [CrossRef] [Google Scholar]
 Harris, E. G. 1962, Il Nuovo Cimento, 23, 115 [Google Scholar]
 Kan, J. R. 1973, J. Geophys. Res., 78, 3773 [NASA ADS] [CrossRef] [Google Scholar]
 Karlický, M. 2004, A&A, 417, 325 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Karlický, M., & Bárta, M. 2011, ApJ, 733, 107 [NASA ADS] [CrossRef] [Google Scholar]
 Karlický, M., Fárník, F., & Mészárosová, H. 2002, A&A, 395, 677 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Karlický, M., Bárta, M., & Nickeler, D. 2012, A&A, 541, A86 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Kliem, B., Karlický, M., & Benz, A. O. 2000, A&A, 360, 715 [NASA ADS] [Google Scholar]
 Knoll, D. A., & Chacón, L. 2006, Phys. Plasmas, 13, 032307 [NASA ADS] [CrossRef] [Google Scholar]
 Konz, C., Wiechen, H., & Lesch, H. 2000, Phys. Plasmas, 7, 5159 [NASA ADS] [CrossRef] [Google Scholar]
 Kowal, G., Lazarian, A., Vishniac, E. T., & OtmianowskaMazur, K. 2009, ApJ, 700, 63 [NASA ADS] [CrossRef] [Google Scholar]
 Lazarian, A., & Vishniac, E. T. 1999, ApJ, 517, 700 [NASA ADS] [CrossRef] [Google Scholar]
 Loureiro, N. F., Schekochihin, A. A., & Cowley, S. C. 2007, Phys. Plasmas, 14, 100703 [NASA ADS] [CrossRef] [Google Scholar]
 Lüst, R., & Schlüter, A. 1957, Zeitschrift Naturforschung Teil A, 12, 850 [NASA ADS] [Google Scholar]
 Magara, T., Mineshige, S., Yokoyama, T., & Shibata, K. 1996, ApJ, 466, 1054 [NASA ADS] [CrossRef] [Google Scholar]
 Nickeler, D., & Fahr, H. J. 2001, in The Outer Heliosphere: The Next Frontiers, eds. K. Scherer, H. Fichtner, H. J. Fahr, & E. Marsch, 57 [Google Scholar]
 Nickeler, D. H., & Fahr, H.J. 2005, Adv. Space Res., 35, 2067 [NASA ADS] [CrossRef] [Google Scholar]
 Nickeler, D. H., & Fahr, H.J. 2006, Adv. Space Res., 37, 1292 [NASA ADS] [CrossRef] [Google Scholar]
 Nickeler, D. H., & Wiegelmann, T. 2010, Ann. Geophys., 28, 1523 [NASA ADS] [CrossRef] [Google Scholar]
 Nickeler, D. H., & Wiegelmann, T. 2012, Ann. Geophys., 30, 545 [NASA ADS] [CrossRef] [Google Scholar]
 Nickeler, D. H., Goedbloed, J. P., & Fahr, H.J. 2006, A&A, 454, 797 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Ohyama, M., & Shibata, K. 1998, ApJ, 499, 934 [NASA ADS] [CrossRef] [Google Scholar]
 Pegoraro, F., Califano, F., Faganello, M., & Tenerani, A. 2010, in AIP Conf. Ser., 1242, eds. G. Bertin, F. de Luca, G. Lodato, R. Pozzoli, & M. Romé, 89 [Google Scholar]
 Petrie, G. J. D., & Neukirch, T. 1999, Geophys. Astrophys. Fluid Dynam., 91, 269 [NASA ADS] [CrossRef] [Google Scholar]
 Schindler, K. 1972, in Earth’s Magnetospheric Processes, ed. B. M. McCormac, Astrophys. Space Sci. Lib., 32, 200 [Google Scholar]
 Schindler, K. 1979, Space Sci. Rev., 23, 365 [NASA ADS] [CrossRef] [Google Scholar]
 SchmidBurgk, J. 1967, ApJ, 149, 727 [NASA ADS] [CrossRef] [Google Scholar]
 Shafranov, V. D. 1958, Sov. J. Exp. Theoret. Phys., 6, 545 [NASA ADS] [Google Scholar]
 Shibata, K. 2012a, in EGU General Assembly Conference Abstracts, 14, eds. A. Abbasi, & N. Giesen, 3226 [Google Scholar]
 Shibata, K. 2012b, in 39th COSPAR Scientific Assembly. Held 14–22 July, in Mysore, India, Abstract B0.5312, COSPAR Meeting, 39, 1785 [Google Scholar]
 Shibata, K., & Tanuma, S. 2001, Earth, Planets, and Space, 53, 473 [NASA ADS] [CrossRef] [Google Scholar]
 Throumoulopoulos, G. N., & Tasso, H. 2000, J. Plasma Phys., 64, 601 [NASA ADS] [CrossRef] [Google Scholar]
 Throumoulopoulos, G. N., & Tasso, H. 2003, Phys. Plasmas, 10, 2382 [NASA ADS] [CrossRef] [Google Scholar]
 Tsinganos, K. C. 1981, ApJ, 245, 764 [NASA ADS] [CrossRef] [Google Scholar]
 Uzdensky, D. A., Loureiro, N. F., & Schekochihin, A. A. 2010, Phys. Rev. Lett., 105, 235002 [NASA ADS] [CrossRef] [Google Scholar]
 Wang, S., Liu, C., & Wang, H. 2012, ApJ, 757, L5 [NASA ADS] [CrossRef] [Google Scholar]
 Wiechen, H., Birk, G. T., & Lesch, H. 1998, Phys. Plasmas, 5, 3732 [NASA ADS] [CrossRef] [Google Scholar]
 Wiegelmann, T., & Schindler, K. 1995, Geophys. Res. Lett., 22, 2057 [NASA ADS] [CrossRef] [Google Scholar]
 Wiegelmann, T., Schindler, K., & Neukirch, T. 1998, Sol. Phys., 180, 439 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Proof of theorem
In Sect. 3.2.3 we claimed that for a given j Eq. (32) has in general no formal solution. One may argue that it is always possible to reduce Eq. (32) to an ordinary differential equation for α as a function of A. Here we show that this is indeed not the case, because the solution to any such differential equation returns the original form of the equation.
An equivalent representation of the current transformation Eq. (32) would be to use instead of the coordinates x and y the flux function A and the arc length s along a field line, or instead of s one of the coordinates x and y. The choice of such a representation has pure mathematical reasons: Eq. (32) should present an ordinary differential equation for α, and α itself should depend only on one single coordinate A. But the nonconstant coefficients of α′ are depending on two coordinates. The choice of a coordinate system that includes A as one of the coordinates enables us to formulate a constraint for which current distributions j the Eq. (32) is really an ordinary differential equation for α as a function of A.
As long as A is locally monotonic, usually depends explicitely on the flux function A and the arc length s along a field line as coordinates equivalent to x,y in 2D, i.e. etc.
Taking the function j(A,s) as a constraint for the MHD system, one has to solve a partial differential equation in A,s or x,y. The special shape (A.1)is a strong restriction for every prescribed current (function) j(A,s). How to solve it correctly for any arbitrarily prescribed j(A,s)? The problem is caused by the fact that Eq. (A.1) is an equation defining or rather determining j(A,s) from a given transformation. Therefore, to prescribe α′(A) to calculate j(A,s) seems to be the most consequent and logical method.
Nevertheless, an inverse method for calculating the transformation α(A) or rather α′(A) from the transformation equation for the current (Eq. (A.1)) would have great advantages, because it would make it possible to generate current fragmentation and strong currentsheets of arbitrary, “turbulent” structure, needed to induce magnetic reconnection or general plasma instabilities.
However, there are several obstacles to use an inverse method. First, it will be difficult to express as , at least analytically. Second, one has to assume a special dependence of the current density j(A,s) to fulfill Eq. (A.1). But any “arbitrary” choice of j(A,s) can overdetermine this ordinary (mixed) differential equation, because the function j(A,s) must be “separable” in the sense of Eq. (A.1).
An equivalent formulation of Eq. (A.1) can be found by eliminating all terms and derivatives of α. This results in the following differential equation (A.2)which represents a constraint for j(A,s).
Because any formal integration of Eq. (A.2) leads automatically back to Eq. (A.1), Eq. (A.2) is only a necessary condition, testing or proving if any considered current density j(A,s) enables the calculation of the transformation α′(A) from Eq. (A.1).
The same integration procedure as in Eq. (33) leading to Eq. (34) could basically also be performed for completely 2D equilibria, which are not asymptotically 1D. The only restriction is again the integrability condition: to guarantee the existence of an allowed transformation (to be precise, α′ should be an explicit function of A only), the condition must be valid. Here C_{0} is an explicit function of s only, is an explicit function of A, and B_{S} and j are explicit functions of A and s. The partial differential equation Eq. (A.3) is now only of first order, concerning the ∂/∂s derivative, in contrast to the Eq. (A.2), but the problem of integrability can also neither be eliminated nor solved in this way. Conversely, the procedure in Sect. 3.2.3 fulfills the integrability condition Eq. (A.3) automatically, because it is an asymptotical 1D problem.
