1. Introduction

An OB association is a young star group (≤50 Myr) of low density which has a significant population of O and B stars. It is believed that they originated as a group which was born in a relatively small region of space within a giant molecular cloud. After the removal of the gas and the dust, the stellar association is transformed into a gravitationally unbound association and it expands. Its projected dimensions cover a range of ∽10 a ∽100 pc (Brown et al. 1999).

Table 1

NGC 4755 data available in the literature.

Among all the reasons that make the study of OB associations important, it is the capacity of its large-mass members of causing a big impact in the evolution of the interstellar medium and the creation of neutral hydrogen (Hi) shell that are the most significant.

As part of a project in which the investigation of the possible link between star sets and Hi shells is proposed, the Hi GS305+04−26, centred in (l, b) = (305°, +4°) (Corti et al. 2012) was investigated. In a study of this kind it was determined that the Hi GS305+04−26, could have been generated by the open cluster NGC 4755 and the stellar association Cen OB1. To study the possible generator of the Hi GS305+04−26, it was necessary to identify the members of NGC 4755 and Cen OB1.

Studies made so far to NGC 4755 and Cen OB1 were:

  • Humphreys (1978) was the first to publish a list ofmembers of Cen OB1 as a result of aspectral-photometric study and obtained 29 possible members,from which 7 stars would belong tothe open cluster NGC 4755.

  • Humphreys & McElroy (1984), based on photometric work, published a catalogue of Cen OB1 with 106 members.

  • Baumgardt et al. (2000) discussed the membership of NGC 4755 using parallaxes, proper motion data and photometry data from the Hipparcos Catalogue and found 7 members.

  • McClure-Griffiths et al. (2001) incorporated the star Wolf-Rayet WR 48 (≡HD113904   ≡   ΘMus) as a member of Cen OB1.

  • More recently, Kharchenko et al. (2005) estimated the mean absolute proper motion of NGC 4755 and found 15 members using the ASCC-2.5 Catalogue data. The distance estimated was 1976 pc.

  • Corti et al. (2012) incorporated the PSRJ 1253−5820 and PSRJ 1254−6150 pulsars as members of Cen OB1. Both could have arisen as a result of the explosion as supernovae (SNe) of two stars that are possible members of Cen OB1.

Upon consulting these works, it is evident that there are no astrometric studies on the Cen OB1 association, and there are a few works for the open cluster NGC 4755 (Baumgardt et al. 2000; Kharchenko et al. 2005) which do not agree regarding the membership assigned to it. In this paper, we propose to revisit the region of Cen OB1 and NGC 4755, using the astrometric and photometric data of the Tycho-2 Catalogue and spectro-photometric data obtained from Simbad and our own data.

2. Observational data

This research was carried out using new observational data and databases publicly available, namely spectroscopic observations and astrometric and photometric data.

2.1. Spectroscopic observations

Spectroscopic observations of 31 stars that are possible members of Cen OB1 were obtained at Complejo Astronómico El Leoncito (CASLEO)1 during April 2009. The spectra were obtained using the REOSC Cassegrain echelle spectrograph attached to the 2.15-m Jorge Sahade telescope. The detector was a TEK CCD (1024 × 1024 pixels) which has a pixel size of 24 μm. A grating of 400 l/mm was used as a cross disperser, and the slit width was set either to 250 μm or 300 μm. The reciprocal dispersion was 0.2 Å px-1. These spectra covered the wavelength range from 3800 Å to 6500 Å, and the signal-to-noise ratio was 20 < S/N < 50.

Thorium-argon (Th-Ar) comparison arc images used for the wavelength calibration in stellar spectra were observed at the same sky position as that of the stellar images, immediately after or before the stellar exposures. Bias frames were also obtained every night, as well as spectra of the stars HR 2806 and HR 7773 as radial velocity standards. The spectra of several standard spectral types (SpTs) were also obtained during the observing run. All spectra were processed and analysed using the IRAF2 package. SpTs and radial velocities from the stars that could not be observed at the CASLEO were obtained from the SIMBAD Astronomical Database3 (for references see Table 5).

2.2. Astrometric and photometric data

The astrometric and photometric data used in this paper come from the Tycho-2 Catalogue with position, proper motions, and two-colour photometry for 2.5 million stars covering the whole sky (Høg et al. 2000b). The Tycho-2 Catalogue is the first densification of the Hipparcos frame. The proper motions result from the combination with the re-analysis of 144 additional astrometric catalogues. A detailed description of the construction of the Tycho-2 Catalogue can be found in Høg et al. (2000a).

For the faintest stars in common with Tycho-1, Tycho-2 has better positional and photometric accuracy. This is because the new method of reduction applied to the Hipparcos data uses photon superposition for each star in the ensemble of observations made during the entire mission instead of treating each observation separately.

The Tycho-2 Catalogue presents very precise proper motions. The internal or random errors are generally between 1 and 3 mas yr-1. Tycho-2 proper motions are in the Hipparcos system; there are no significant systematic differences between the proper motions of the two catalogues, as shown by Urban et al. (2000). The systematic errors under 0.5 mas yr-1 are typically 10% of the random errors, and are almost equal to the formal errors for the rotation of the Hipparcos proper motion with respect to the International Celestial Reference System (ICRS), estimated to be 0.25 mas yr-1 (Kovalevsky et al. 1997). The high quality of the Tycho-2 proper motions and their agreement with the Hipparcos set allow the determination of the mean proper motions and the membership of open clusters and associations.

3. Results

3.1. Astrometric analysis

3.1.1. NGC 4755

As a first step, we identified the cluster members. Several studies have shown different results for the open cluster NGC 4755 (Table 1) (Baumgardt et al. 2000; Dias et al. 2002; Kharchenko et al. 2005), where αJ2000.0 (in hours) and δJ2000.0 (in degrees) are the coordinates of the cluster’s centre, Rc is the radius in arcmin, μαcosδ and μδ are the components of its mean absolute proper motion in mas yr-1, RV is the radial velocity in km s-1, N1 is the number of the members, D is the distance in parsec, and t in years represents the age.

We selected the stars from the Tycho-2 Catalogue centred at α = 12:53.5, δ = −60:22 in a circular region of radius 20′ containing 55 stars. An over-density is expected to be found in the sky as well as in the vector point diagram (VPD) for cluster stars. It is possible to analyse these over-densities adopting the mathematical model suggested by Vasilevskis et al. (1958) and the technique based upon the maximum likelihood principle developed by Sanders (1971). The number of stars of this circular region N = 55 had been expressed as (1)where N1 is the number of the cluster members and N2 is the number of the field stars. Jones & Walker (1988) improved the method using an exponential function ρ1(r) to describe the areal stellar density for the cluster stars according to van den Bergh & Sher (1960). The stellar radial density profile was obtained by counting the number of stars within concentric annuli around the cluster centre. This profile was modeled by the overlapping of two functions (2)where ρ1(r) is the cluster stellar density, ρ2 is the field stellar density and ρ2 is a constant. The cluster stellar density is represented by an exponential function (3)where ρ0 is the central cluster stellar density, r0 is the characteristic radius, and r the distance from the cluster’s centre.

The proper motion distribution of the region selected consisted in the overlapping of two bivariate normal frequency functions (4)where φ1i is a circular distribution for cluster stars and φ2i is an elliptical distribution for field stars; , are the ith star proper motion in αcosδ and δ, respectively. These coordinate axes are coincident with the field distribution axes after rotating the VPD by an angle θ.

The circular and elliptical distributions have taken the form (5)and (6), being the field elliptical dispersions, , the field mean proper motion, σc the cluster circular dispersion and μxc, μyc the cluster mean proper motion.

The parameters ρ0, r0, and ρ2 were obtained by fitting Eq. (2) to the radial stellar density profile. The other seven parameters present in Eqs. (5) and (6) can be found by applying the maximum likelihood principle. The unknown cluster parameters, therefore, can be entirely determined.

The probability for the ith star has been calculated as (7)A cluster member is found when Pci > 0.5.

thumbnail Fig. 1

Vector point diagram (VPD) of NGC 4755. Open circles around the crosses represent the astrometric cluster members, and crosses the rest of the stars of the region.

thumbnail Fig. 2

Stellar density profiles in the region of NGC 4755 as a function of the distance from the cluster centre.

To apply the model described, we analysed the proper motion data in an elliptical subregion centred in μαcosδ = −6.5 mas yr-1, μδ = −2.5 mas yr-1, with semi-major and semi-minor axes 8 and 5 mas yr-1, respectively, of the VPD containing 42 stars, where θ = 7533 (see Fig. 1). The function ρ(r) given in Eq. (2) was adjusted to the radial stellar density profile, as can be seen in Fig. 2, with the following parameters: ρ0 = 1.558 ± 0.437 stars/(′)2, , and ρ2 = 0.027 ± 0.006 stars/(′)2.

After applying the method of maximum likelihood to Eqs. (5) and (6), the cluster parameters were μxc = −4.14 ± 0.19 mas yr-1, μyc = −1.09 ± 0.12 mas yr-1, σ = 0.63 ± 0.28 mas yr-1, and the field parameters = −4.69 ± 0.57 mas yr-1,  = −1.32 ± 0.53 mas yr-1,  = 1.60 ± 0.45 mas yr-1, and = 2.05 ± 0.51 mas yr-1. Once the cluster and field parameters have been determined, the membership probability of the ith star was given by Eq. (7).

Table 2

Astrometric cluster members of NGC 4755.

Table 3

Possible members of NGC 4755.

Among the 55 stars in the region of NGC 4755, 10 stars with higher than 0.5 probabilities have been found and should be considered as the astrometric members of the cluster. They are located in a circular region 108 from the cluster centre. Figure 1 shows the location of the 10 cluster members in the VPD.

The following information on the astrometric cluster members is shown in Table 2: ID is the identification of the star in some catalogues; r is the distance from the cluster centre in arcmin; (α, δ) are the coordinates in hours and degrees, respectively; μαcosδ and μδ are the components of the proper motion in mas yr-1; Pc is the probability obtained; TYC is Tycho’s number; BT and VT are Tycho-2 magnitudes.

Finally, based on the calculations of distance obtained as described in Sect. 3.2.1, it can be seen that there are four possible members of NGC 4755. The information is given in Table 3, where the V and (B − V) are the magnitude and colour, respectively, corrected from the Tycho-2 system to the Johnson system (Bessell & Brett 1988); RV is the heliocentric radial velocity; and DM the distance modulus of the Sun.

3.1.2. Cen OB1

Previous spectrophotometric studies suggested the existence of a stellar association in addition to an open cluster in the region of Centaurus (Humphreys 1978; Humphreys & McElroy 1984; McClure-Griffiths et al. 2001). To perform an identification of astrometric members, we selected the stars from the Tycho-2 Catalogue centred at α = 12:58:30, δ = −62:30:00 in a square area of 7° containing 898 stars. Then, an over-density in the VPD caused by the low values of the velocity dispersions of the members is expected to be found if there is an association. Therefore, a selection based on proper motion is the most reliable method for the separation of the association from field stars. We analysed this over-density using the model proposed by Orellana et al. (2010). In their paper they proposed for the first time, a standardised way to identify the members of an association. To do this, the authors applied the same technique used for open clusters considering only the proper motions based upon the maximum likelihood principle (Sanders 1971).

To find the members of the association, cluster members were taken out. The new subregion has a total population of 884 stars. So, the proper motion distribution in the new subregion took the form (8)where (9)and (10)The symbols , are the elliptical dispersions for the field stars, σa the circular dispersion for the association stars, , the field star mean proper motion, and μxa, μya the association mean proper motion. N3 is the number of the association members, and N4 the number of the field stars. The parameters present in Eqs. (9) and (10) would be found by applying the maximum likelihood principle. It determines the association and field unknowns. The probability for the ith star has been calculated as (11)Then, we analysed the proper motion data of an elliptical subregion centred in μαcosδ = 0.0 mas yr-1, μδ = 0.0 mas yr-1, with semi-major and semi-minor axes 23 and 18 mas yr-1, respectively, of VPD containing 661 stars, where θ = 4575. We applied the method of the maximum likelihood to Eqs. (9) and (10). The association parameters were found to be N3 = 299, μxa = −5.40 ± 0.18 mas yr-1, μya = −1.04 ± 0.16 mas yr-1, σa = 1.89 ± 0.11 mas yr-1, and for the field stars N4 = 362, mas yr-1, mas yr-1, mas yr-1, and = 6.40 ± 0.37 mas yr-1. Figures 3a and 4a show the location of the 299 association members in the spatial distribution and in the VPD, respectively, with open circles around the dots.

thumbnail Fig. 3

Spatial distribution of the stellar association Cen OB1. a) Open circles around the dots represent the 299 astrometric association members; the points represent the rest of the stars of the region in the first analysis. b) Open circles represent the 52 astrometric and spectrophotometric association members obtained using the model proposed by Orellana et al. (2010). The NGC 4755 cluster is indicated by the large circle.

thumbnail Fig. 4

VPD of the stellar association Cen OB1. a) Open circles around the dots represent the 299 astrometric association members; points represent the rest of the stars of the region in the first analysis. b) Open circles represent the 86 astrometric and spectrophotometric members. c) Open circles represent the 52 astrometric and spectrophotometric association members obtained using the model proposed by Orellana et al. (2010).

Next, we removed the contamination produced by the field stars located at different distances. For this we inspected the BT and VT of the 299 astrometric member stars whose DM were calculated following the procedure in Sect. 3.2.1. and are shown in Fig. 5. We can see a concentration of 86 stars for DM = 12 ± 0.6 which corresponds to a distance D = 2588 ± 534 pc. Figure 4b shows the 86 association members. Further adjustment was made by applying the Orellana et al. (2010) model by eliminating from the initial group of 299 stars the 213 that are not distance members. The new parameters are N3 = 52, μxa = −4.78 ± 0.10 mas yr-1, μya = −0.93 ± 0.10 mas yr-1, σa = 1.05 ± 0.14 mas yr-1, and for the field stars N4 = 609, mas yr-1, mas yr-1, mas yr-1 and mas yr-1.

A total of 52 stars were identified as likely candidates to be members of Cen OB1. These stars are listed in Table 5 and the spatial distribution and VPD are shown in Figs. 3b and 4c, respectively, with open circles around the dots.

3.2. Spectrophotometric analysis

3.2.1. Distance

The combination of photometric and spectroscopic information provides the possibility of determining individual colour excesses E(B − V) of the program stars. The photometric magnitudes VT and BT were corrected from the Tycho-2 system to the Johnson system (Bessell & Brett 1988). The intrinsic (B − V)o colour index and the absolute visual magnitude Mv, were obtained from Schmidt-Kaler (1982). The quoted error stems from an assumed Mv uncertainty of 0.5 mag (Walborn 1972). In the SpT for which Mv was not found, linear interpolation was performed. With these data the visual extinction of each star could be obtained (12)where Rv is the standard selective absorption coefficient, calculated as (13)Equation (13) was obtained from Schmidt-Kaler (1982) and the value of Rv calculated using Eq. (13) for each star is in the range of 3.25 ≤ Rv ≤ 3.32. Then, it was possible to estimate distance moduli (14)Figure 5 is the histogram that represents the 299 astrometric member stars of Cen OB1 (Fig. 4a) according to the DM. This Fig. 5 shows the group of 86 stars with dark colour bins with 11.4 ≤ DM ≤ 12.6 (Fig. 4b). Within both bins there are the 52 stars members of Cen OB1, according to Sect. 3.1.2, with a DM = 12.0 ± 0.4 (2591 ± 458 pc).

thumbnail Fig. 5

Distribution of the DM of the 299 astrometric member stars of Cen OB1 (Fig. 4a). The dark colour bins are the 86 stars with 11.4 ≤ DM ≤ 12.6 (Fig. 4b).

3.2.2. Spectral classification

Of the final group of the 52 stars that are possible members of Cen OB1, and the 4 stars that are possible members of NGC 4755, blue spectral images of 8 stars have been obtained. We also obtained the spectrum of HD 111973, member star of NGC 4755 according to Kharchenko et al. (2004). The SpT of those stars which do not have their spectra were obtained from Kharchenko & Roeser (2009) and Pickles & Depagne (2010), and the radial velocity of these same stars was obtained from Kharchenko et al. (2007). The spectral classification of these nine stars, was made using the spectral classification criteria of Walborn & Fitzpatrick (1990, hereafter WF90) Catalogue. Figures 6–9, show the spectra of these stars without HD 112364 (multiple system). Using an IRAF task it was possible to present the spectra of the REOSC Cassegrain echelle in this way. The features indicated in the spectra are the classification criteria used in these SpT.

thumbnail Fig. 6

Blue optical spectra of two B1 supergiant stars, members of Cen OB1. The features indicated are the classification criteria used in the SpTs by the WF90 Catalogue.

thumbnail Fig. 7

Blue optical spectra of two B supergiant stars members of Cen OB1 and the B supergiant star, HD 111934, member of NGC 4755. The features indicated are the classification criteria used in the SpTs by the WF90 Catalogue.

thumbnail Fig. 8

Blue optical spectra of HD 111973 and HD 111904, both B supergiant stars, members of Cen OB1 and NGC 4755, respectively. The features indicated are the classification criteria used in the SpTs by the WF90 Catalogue.

thumbnail Fig. 9

Blue optical spectra of HD 113708, a B giant star, member of Cen OB1. The features indicated are the classification criteria used in the SpT by the WF90 Catalogue.

thumbnail Fig. 10

Absorption lines with double and triple profiles of HD 112364. This is a binary system of two spectra (SB2).

As the spectral resolution of our data (0.16 Å px-1) was higher than the WF90 Catalogue (0.5 Å px-1), the spectra of several stars of this catalogue were also obtained using the same instrumental configuration used in the observation of the stars under study. We obtained the 24 spectra of the WF90 Catalogue with better resolution. Stars observed at CASLEO were re-classified (see Col. 6 in Table 5), changing the SpT of 2 of them (see Sect. 4.2). From the set of 52 stars, there are 49 stars classified as early (OB) type and 3 stars with SpT = A0 Ib–II, SpT = F0 II, and SpT = M3 II each. Among the OB type, there are 7 O-type stars (3 of luminosity class (LC) = V, 3 of LC = III, and 1 of LC = II), 42 B-type stars (2 of LC = V, 2 of LC = IV, 2 of LC = III–IV or LC = III–V, 19 of LC = III or LC = II–III, 7 of LC = II, 3 of LC = I–II, and 7 of LC = Ia or Ib or Ia–b).

The HD 112364 star is a multiple-system member of Cen OB1. Figure 10 shows some of the absorption lines with a double feature of this star. The double feature are evident in all lines of He I among λ4009 and λ4921; Mg III λ4038; Mg II λ4481; O II among λ4070 and λ4677; Si IV λ4089; Si III λ4553, λ4568, λ4575, λ5219, and λ5740. This is a binary system of two spectra (SB2). The spectral profile of OII λ4415−4417 is triple because the opposing lines of the two spectra are added in the middle; the same addition occurs with the Mg II λ4481 line. Only two spectra of this star could be obtained and they show the presence of the He II λ4685 profile and the very weak absorption of the N II λ3995 line.

The stars HD 113754 and CPD−60 4558 are presented in Kharchenko & Roeser (2009) without LC; for this reason in this paper it was decided to assume that they are main sequence stars.

3.2.3. Stellar radial velocities

Using the IRAF standard reduction package, the Gaussian profile was adjusted to the lines of the different ions in the spectrum of each star. Then, to find the radial velocity of the star, only the lines of He I and He II (where they are present) were averaged for each spectrum of each star. In those stars for which it was possible to get more of one spectrum, the values of the radial velocity with their corresponding errors obtained in each spectrum were averaged. Column 10 in Table 5 lists the heliocentric radial velocity obtained for 14 possible members of the association Cen OB1. Among these 14 stars, we obtained the results of the radial velocity for 6 stars and for the other 8 stars we consulted the work of Kharchenko et al. (2007). Each radial velocity result is indicated with its corresponding error in parentheses.

The HD 112364 system mentioned in the previous section shows two sets of lines for the same ion in each of the two spectra obtained for the star. The heliocentric radial velocity obtained with the He I and He II lines is −69 ± 8 and 20 ± 5 km s-1, respectively, in one spectrum, and −61 ± 12 and 21 ± 6 km s-1, respectively, in the other spectrum. With a resolution of 0.32 Å every 2 pixels, and with an uncertainty of 10% in the radial velocity, the instrumental error will be about 2 km s-1, so the error with which the average values of radial velocity have been obtained is very good. The time difference between the two spectra is 3 days and the radial velocity in both spectra is similar. So, it is likely to be a system of at least two supergiants with a long period. This hypothesis is consistent with the fact that there is no evidence of interaction between the two supergiants, such as emission lines. If both components are of similar mass, we can guess a systemic velocity of about −25 km s-1.

thumbnail Fig. 11

Distribution of heliocentric radial velocity of the member stars of Cen OB1. The dark colour bin has the maximum value at about −20 km s-1, the probable radial velocity of the association.

Figure 11 is a histogram with the distribution of all the stars that are possible members of Cen OB1, according to the heliocentric radial velocity of these stars. The width chosen for the bin was 15 km s-1 because of the average error for each star in radial velocity so that each star would be in the appropriate bin. The largest number of stars is in the bin with a heliocentric radial velocity of −20 km s-1.

The radial velocity of each member of NGC 4755 is shown in Table 3 and the radial velocity of the cluster was obtained averaging the radial velocity value of each of its members, which turned out to be −18 ± 2 km s-1.

thumbnail Fig. 12

Members of Cen OB1 in galactic coordinates. The luminous classes of the stars are indicated with different symbols (upper-right corner). The asterisks mark the location of the pulsars. The dashed ellipse represents the Hi shell GS305+04-26 (Corti et al. 2012). The NGC 4755 cluster is indicated with a black box.

3.2.4. Size and age

As can be seen in Fig. 12, the members found for the association are distributed in an almost circular area of 6° in diameter. At the distance of 2600 pc adopted for the association, it would have a linear size of 270 pc in diameter. This size is consistent with the typical sizes traditionally accepted for the stellar association (Efremov et al. 1987).

In Fig. 12 it is possible to see that several members of Cen OB1 are in the galactic plane of our Galaxy. According to the research about the Hi shell GS305+04-26, published in Corti et al. (2012) the possible generators of this Hi shell were the members of Cen OB1, through their winds. Some members of Cen OB1 and the NGC 4755 cluster are inside the Hi, and it has two supergiant members (one of them a possible binary system) and one giant member sharing the location with the members of the association. The location of the stars inside the shell may be a result of the action of the depletion of hydrogen because of the star formation and of the fact that the winds of all stars that are in it have swept away much of that hydrogen since several of these stars could have been formed before the shell.

To know the age of the member stars of the association, we place them in a colour–magnitude diagram (CMD) with isochrones. Figure 13 shows the comparison of the intrinsic visual magnitude and the intrinsic colour index of the stars according to its SpT (Schmidt-Kaler 1982) with theoretical isochrones for solar metallicity, mass loss, and overshooting (Marigo et al. 2008). Some scatter observed with the main sequence stars may possibly be caused by some of them belonging to multiple systems, being fast rotators, or being stars with emission. Therefore, since it was necessary to propose more than one isochrone as a solution, we employed the isochrones of 1 and 3 × 106 years old. A similar effect is observed with the giant and supergiant stars; for these stars the isochrones of 10, 15, and 20 × 106 years old were employed. The fact to be possible to adjust more than one isochrones to the members of the Association could be a consequence of the star belonging to a multiple system or of a lack of precision in the determination of the luminosity class; the star that is farther away from the 20 × 106 year-old isochrone has a LC = Ib–II. The age that we assigned to Cen OB1 is the isochrone corresponding to the best fit to the older stars; it is 20 × 106 years old.

Despite the small number of members found for the cluster and the mass range between them, it is possible to know their age by the use of isochrones. To the four stars that we found to be members of NGC 4755 we added the stars TYC 8989−3110−1 and TYC 8989−1997−1, found to be members of the cluster by Kharchenko et al. (2004). With this total of six members, the age adopted for NGC 4755 is 15 × 106 years old.

thumbnail Fig. 13

CMD of member stars of Cen OB1. The symbols are the same as in Fig. 12. The black curve is the Schmidt-Kaler (1982) HR diagram for early stars; the other curves are Marigo et al. (2008) isochones for z = 0.02. All the reference curves are corrected by an apparent distance modulus of 12.0.

4. Discussion

4.1. Membership

The mean proper motion of NGC 4755 that we found is in good agreement with that reported in other works (Table 1). We compared our members, shown in Table 3, with the result obtained from Humphreys (1978), Baumgardt et al. (2000), and Kharchenko et al. (2004). We found four common member stars with Kharchenko et al. (2004). A similar analysis shows that there are only two member stars of the cluster in common with Baumgardt et al. (2000) and two other stars in common with Humphreys (1978).

Only those astrometric member stars whose distance lay within ±1σ of the mean distance were considered to be member of Cen OB1. The mean spectrophotometric distance of this group turns out to be 2591 ± 458 pc (DM = 12.0 ± 0.4). This result is in good agreement with previous Cen OB1 distance estimates (Humphreys 1978; Humphreys & McElroy 1984). Our listing of 52 stars (see Table 5) has 19 stars in common with the Humphreys & McElroy (1984) list of 106 stars. Within this sub-group of 19 stars, there are 10 stars that are in the Humphreys (1978) paper.

Bearing in mind that the Tycho-2 Catalogue is 90% complete down to a visual (V) magnitude V = 11.5, we should be able to identify all supergiant stars, regardless of their SpT, that may belong to Cen OB1, and all main sequence and giant stars whose SpTs are earlier than B3 V and B6 III, respectively.

In these new spectroscopic and astrometric studies we found 56 members of Cen OB1 and NGC 4755, while in Corti et al. (2012) 54 members of Cen OB1 and NGC 4755 were found, so between both works there are 43 members in common. For this reason the total energy supplied to the interstellar medium by this new group of members of Cen OB1 and NGC 4755 is 17% lower than the energy published in Corti et al. (2012). With the contribution of energy to the Hi shell GS305+04-26 given by the pulsars, it is sufficient to generate this Hi shell, as was stated in Corti et al. (2012).

The stars TYC 8990−2411−1 and TYC 8994−4147−1 with F0 II and M3 II, respectively, were found to be likely members of the association in this present paper. Their proper motions with 0.81 and 0.85 probability of belonging to Cen OB1 and 3.1 ± 0.8 and 2.4 ± 0.8 kpc of distances, respectively, make them probable members of Cen OB1. The problem with these stars is that with their parameters (B − V)o = 0.3 and Vo = 10, and (B − V)o = 1.6 and Vo = 9.3, respectively, locating them in Fig. 13 is impossible. They are located far from the members of the association in the CMD, so it is impossible to determine one isochrone age for them. The difficulty that arises when one wants to locate these stars in an isochrone age, reduces the likelihood of these stars being members of Cen OB1.

We find that the star WR 48 is not a member of Cen OB1 since its proper motion μαcosδ = −1.9 ± 1.3 mas yr-1 and μδ = 19.0 ± 1.8 mas yr-1 gives a probability of belonging Pi = 0. This result disagrees with the one published by McClure-Griffiths et al. (2001).

4.2. Spectral classification

Among the nine stars observed at CASLEO, there is HD 111973, known as Kappa Crucis. This star was published by Evans et al. (2005) with B3 Iae because of the emission present in the Hα line (λ = 6562.81 Å). The wavelength range covered by our spectra goes up to 6500 Å; so in the two spectra obtained for this star, it was not possible to observe the emission in the Hα line; no emission in any other profile of these spectra was observed. For these reasons, the SpT given for this star in this work is B3-5 Ia (without emission) as Kharchenko & Roeser (2009) and Glebocki & Gnacinski (2005) proposed.

The spectral characteristics observed in HD 112364 (Sect. 3.2.2) are typical of a star with B0.5 Ib-a instead of B1 III (Wright et al. 2003) or B1 Ib (Garrison et al. 1977). There has been a web search on the information presented about the star HD 112364 but it is not presented anywhere as a multiple system. Even the Hipparcos Catalogue with multiple systems (Perryman & ESA 1997) does not have it listed. In the spectra of this star it can be seen that both components are similar, so this is probably a multiple system of supergiant stars. It will be necessary to obtain more HD 112364 spectra to know the different parameters of this system, among these the number of members of this multiple system.

The star HD 111934 was reported as a binary system in the Tycho-2 Catalogue. From the study of the two spectra obtained for this star in CASLEO, it is not possible to confirm that it is a binary system. Perhaps it is a long-period binary system, because of which the radial velocity measured in the spectra obtained with three days of difference is the same. It is also possible that both components were in the same line of sight to the observer (not quadrature) so there was a single set of lines in each spectrum. For these reasons we can’t say that HD 111934 is a binary system.

We can’t comment about the stars HD 112147, HD 111825, and CP−60 4551 whose spectral types are indicated with the peculiarities pe, (N) and (NE), respectively. The SpTs of these stars were obtained from the work of Kharchenko & Roeser (2009). The spectral types of all members of NGC 4755 and Cen OB1 are presented in Tables 3 and 5, respectively.

Table 4

IRAS sources possibly associated with Centaurus OB1.

thumbnail Fig. 14

CMD of member stars of NGC 4755. The symbols are the same as in Fig. 12. The black curve is the Schmidt-Kaler (1982) HR diagram for early stars; the other curves are Marigo et al. (2008) isochones for z = 0.02. All the reference curves are corrected by an apparent distance modulus of 11.4.

thumbnail Fig. 15

AL fit of the galactic rotation model applied to our Galaxy (Fich et al. 1989). The heliocentric radial velocity is shown in Tables 3 and 5, corrected to LSR radial velocity. (1) stars of this paper; (2) stars of Kharchenko et al. (2007); (3) AL fit.

4.3. Stellar radial velocity

Runaway stars are part of the examination of the kinematics of the stellar association; O- and B-type runaway stars are a subset of the O and B stars with Vmin ≤ |Vpr |, taken as Vmin = 30 km s-1 (Cruz-González et al. 1974). The radial component of the peculiar velocity of the star Vpr is defined as the difference between the radial velocity of the star and the radial component of the circular velocity of the star’s position (both with respect to the local standard of rest (LSR); Cruz-González et al. 1974). Knowing this last parameter is necessary to be able to determine if any of these stars is a runaway star. Possible mechanisms for the origin of the OB runaways are dynamical interactions amongst members of a protocluster and as a consequence, after the supernova explosion of the star near this star. In order to know whether any Cen OB1 member is a runaway star, we placed the stars in the schematic diagram shown in Fig. 15. It shows the linear fit (AL) of the galactic rotation model of the galaxy (Fich et al. 1989) (the AL and the power-law fit give the same result) with the distance from the Sun and the LSR radial velocity RVLSR, each parameter with its respective error bar of the possible members of Cen OB1 and NGC 4755. To locate the stars in this figure, the heliocentric radial velocity of each star was converted into the LSR radial velocity, assuming for this reason that the motion of the Sun with respect to the LSR is 13.3 km s-1 ((U,V,W)Sun = (9.96, 5.25, 7.07) km s-1) (Aumer & Binney 2009) towards α = 18h, δ =  +30°.

The star farthest from the rotation model of the Galaxy is SB2 HD 112364. It is not yet possible to say anything about this star, because with the two spectra that we have it is impossible to know the barycentric radial velocity of the system. The other stars that are not coincident with the rotation model of the Galaxy are the B1 supergiants HD 113422, HD 114213, and HD 114478. In order to explain this situation we shall follow the procedure outlined by van der Sluys & Lamers (2003) (after correcting the sign of the w⊙ term in their Eq. (19)) and Cichowolski et al. (2008) (all of this is explained in Corti et al. 2012). Using the distance from the Sun and the RVLSR of each star previously mentioned, it was possible to know the Vpr of each star. HD 113422, Vpr = −30 ± 8 km s-1; HD 114213, Vpr = 25 ± 9 km s-1; and HD 114478, Vpr = 27 ± 8 km s-1. Considering one or two sigmas of each Vpr for each star, it is not possible to say that these stars are runaway stars. That is, it is possible that these stars, just like the other stars members of Cen OB1, are multiple systems or have spectra with profiles that are not well defined. In the particular case of supergiant stars, they may have instabilities in the outer atmosphere that can cause variations in the observed stellar velocity (Cruz-González et al. 1974).

In the fourth quadrant of our alaxy there is an ambiguity with the kinematic distance that corresponds to the LSR radial velocity of the object under study. We take as kinematic distances of Cen OB1 and NGC 4755 those obtained with the use of Eq. (14). The distance of Cen OB1 coincides with the kinematic distance of 2.5 ± 0.9 kpc from the Hi shell GS305+04-26 which is associated with (Corti et al. 2012). Inserting this distance value for Cen OB1 and the average star distance module of DM = 11.4 (1.9 kpc) for NGC 4755 to the galactic rotation model of the Galaxy (Fich et al. 1989), it is possible to obtain an LSR radial velocity of −26 km s-1 and −21 km s-1, respectively. These velocities, correspond to about −22 km s-1 and −17 km s-1 velocity in the heliocentric system, respectively. The latter is in good agreement with the heliocentric radial velocity value found for Cen OB1 according to Sect. 3.2.3 and the value found for NGC 4755 making the average of the information presented in Table 3.

4.4. Age

There are two pulsars located near the Hi shell GS305+04-26, PSRJ 1253−5820 is located inside the shell, and PSRJ 1254−6150 is located on the edge of the shell. Both pulsars could have been generated as a result of the explosion as SNe of two stars possible members of Cen OB1, which should be in the group of older members of the association (Corti et al. 2012). Several factors support this hypothesis, the age of 5 × 106 years old and the distance of 2.24 kpc for PSRJ 1254−6150 (Manchester et al. 2005), and the age of 2 × 106 years old (Manchester et al. 2005) and the distance of 2.2 kpc (Noutsos et al. 2008) for PSRJ 1253−5820.

We have also investigated the possible existence of IRAS sources in the area of the galaxy where Cen OB1 is present. For this, we consulted the paper of Walsh et al. (1997), which lists 215 candidates as UC HII regions, obtained as a result of Methanol maser of IRAS-selected sources. It consists of IRAS sources associated with early stars. They associated the LSR radial velocity of these stars with IRAS sources. Table 4 shows the LSR radial velocities of these stars (Col. 4) and the minimal distance of these stars from the Sun, obtained with the galactic rotation model of the Galaxy (Fich et al. 1989) (Col. 5). The weight of the individual distance determinations stems from the assumption of an uncertainty of ±10 km s-1 caused by non-circular motion (Burton 1988), from which we can infer that the value of the distance obtained in this way has an error of 1 kpc, approximately. This makes it possible for all IRAS sources studied by Walsh et al. (1997) to share their location in the galaxy with the association.

Referring to the IRAS infrared survey published in the Narrow-band Hα data retrieved from the SuperCOSMOS H-alpha Survey (SHS)4 (Parker et al. 2005), we have found the IRAS sources 13120−6310 and 13024−6158, whose radial velocity data were obtained from Mottram et al. (2007) and Bronfman et al. (1996), respectively. Correcting their heliocentric radial velocities to the LSR system, a radial velocity of VLSR = −25 km s-1 and VLSR = −27 km s-1, respectively, was obtained for them. By employing the galactic rotation model of the Galaxy (Fich et al. 1989), we estimated a minimal distance to the Sun of 2.6 kpc and 2.8 kpc, respectively.

In Sect. 3.2.4 we studied the age of the members of Cen OB1 and the result was a distribution of ages. The older stars of the association would be those that originated the pulsars that we see today. Likewise, the age of Cen OB1 is determined by the older stars to which one isochrone can be fitted, and is also about 2 × 107 years old. In this subsection, we have seen that near Cen OB1, IRAS sources are found, which show the youngest star formation. For all the above reasons we can think of the possibility that the region under study is a sequential star formation region. The latter may be because the Milky Way arm Carina-Sagittarius, where this association is located, is an area rich in hydrogen.

5. Conclusions

This work enables us to appreciate how powerful it is to investigate members of a stellar association, by employing astrometric and astrophysical techniques simultaneously. This paper shows the first and unique astrometric research about the membership of the Cen OB1. With our own data and catalogue data, new spectroscopic and astrometric studies of members of the association Cen OB1 and the open cluster NGC 4755 have been made. The result of this investigation is that Cen OB1 has 52 members and NGC 4755 has 4 members, and that it is an open cluster integrated into the Cen OB1. The latter centred at (l, b) = (303 7, 04) is approximately circular in shape with 270 pc of diameter. It is at 2591 ± 458 pc from the Sun and the heliocentric radial velocity is ~−20 km s-1. The components of the mean proper motion of Cen OB1 are μαcosδ = −4.78 ± 0.10 mas yr-1 and μδ = −0.93 ± 0.10 mas yr-1. The age of the association is ~20 × 106 years old. The open cluster NGC 4755 centred at (l, b) = (3032, 25) is at 1888 ± 481 pc from the Sun and the heliocentric radial velocity is −18 ± 2 km s-1. The components of its mean proper motion are μαcosδ = −4.14 ± 0.19 mas yr-1 and μδ = −1.09 ± 0.12 mas yr-1. The age of the cluster is ~15 × 106 years old. There is good agreement between the distances and characteristic ages of the pulsars PSR J1253−5820 and PSR J1254−6150 with the idea that they were born as the result of SNe undergone in the past by massive members of Cen OB1. We have seen IRAS sources near Cen OB1 showing that even star formation is occurring. The age gradient observed between the different members of Cen OB1 makes it likely that the association and IRAS sources represent different stages of sequential formation process.

Online material

Table 5

Possible members of Centaurus OB1.

1

Operated under agreement among CONICET, SeCyT, and the Universities of La Plata, Córdoba and San Juan, Argentina.

2

IRAF is distributed by NOAO, operated by AURA, Inc. under an agreement with NSF.

Acknowledgments

This work was partially supported by Consejo Nacional de Investigaciones Científicas y Técnicas CONICET under projects PIP 01299 and 01359, and by Universidad Nacional de La Plata (UNLP) under projects 11/G091 and 11/G096. We would like to thank Dr. Gustavo, Baume and Dr E. Marcelo, Arnal for helping us to prepare and to interpret the CMD (Figs. 13 and 14) and Fig. 15, respectively. One of us would like to thank Dr. Roberto, Gamen for helping with one IRAF task. We thank the referee for many helpful comments that significantly improved the manuscript.
