1. Introduction

Supernovae have been hypothesized (Ginzburg & Syravotskii 1964; Hayakawa 1969) to be the sources of the cosmic rays, which consist primarily of relativistic protons, ions and electrons. Firm evidence for this hypothesis is lacking because cosmic rays are deflected by intervening magnetic fields and do not trace back to their sources. A distinctive γ-ray signature of cosmic rays results from interactions of cosmic-ray protons and ions with gas and dust in the vicinity of their acceleration sites, making γ rays with a characteristic π0 → 2γ emission feature peaking at 67.5 MeV in a photon number representation (Stecker 1971).

Resolution and sensitivity limitations of previous γ-ray telescopes made it impossible to precisely localize γ-ray sources in the Galaxy and to measure the expected π0-decay spectral signature. This has changed with the new generation of γ-ray telescopes, including AGILE (Astro-rivelatore Gamma a Immagini LEggero; Gamma-ray Light Imaging Detector) and the Fermi Large Area Telescope (LAT). Evidence for a cutoff below several hundreds of MeV from some supernova remnants (SNRs) has been found (Giuliani et al. 2011; Abdo et al. 2010c, 2010e; Ackermann et al. 2013), so this one-hundred year old problem may soon be solved.

While spectral analyses at photon energies Eγ ≲ 100 MeV continue, we can also ask whether the measured γ-ray luminosities of SNRs are consistent with expectations of efficiency for cosmic-ray acceleration at SNR shocks. Furthermore, trends in the γ-ray spectra might reveal a progressive behavior characteristic of cosmic-ray acceleration in these sources.

Here we test the hypothesis that cosmic rays are accelerated at SNRs by calculating the fraction of supernova kinetic energy that must be converted into cosmic-ray particles in order to produce the γ rays that are observed from some of these remnants. We also plot the GeV to TeV energy-flux ratio with age.

2. Particle acceleration at SNR shocks

Supernovae (SNe) are found in two main classes, namely thermonuclear type Ia SNe and core-collapse type II SNe1. The progenitors of type Ia SNe are Solar mass white dwarfs composed of carbon and oxygen. Thermonuclear burning of the material in the white dwarf releases a prodigious amount of energy and creates a shock wave as the burned material expands. For stars more than ≈8 times as massive as the Sun, in contrast, the stellar interior burns until much of it has been converted to an Fe core, which will collapse when electron-degeneracy pressure is no longer sufficient to support the core against gravity. A core bounce sends a shock wave out that expels a portion of the stellar envelope (for a general review, see Burrows 2000). Neutron stars can be formed in type II SNe, but not in type Ia SNe.

In both Types Ia and II SNe, the energy available for nonthermal particle production is derived from the directed bulk kinetic energy of the shell. This energy is dissipated in the form of the random kinetic energy of matter swept up at the SNR shock. The amount of energy that is extracted and transformed into cosmic-ray energy is highly uncertain, and represents a major open question in SNR modeling. Different prescriptions related to the number of swept-up particles or the kinetic energy dissipated at the shock front have been considered (e.g., Sturner et al. 1997; Reynolds 1998; Baring et al. 1999; Tang et al. 2011), but the exact conversion efficiency depends on poorly understood microphysical processes (e.g., Blasi et al. 2005). Here we reconsider this problem using an idealized model of an expanding spherical shell of matter and a uniform surrounding medium (cf. Truelove & McKee 1999; Finke & Dermer 2012).

Let E0 = 1051E51 erg represent the total kinetic energy of the supernova ejecta with mass M0 = mM, where M = 2.0    ×    1033 g is the mass of the Sun. For type Ia and II SNe, m ≅ 1.4 and m ≅ 10, respectively, with E51 ≈ 1 for both types. The SN is here assumed to explode in a medium of uniform density n0 and form an outward moving spherical shell of material with radius r = r(t) at time t after the explosion. As it expands, the shell sweeps up material with mass Msu(t) = 4πr3ρ0/3, where the density ρ0 = mpn0, and the ISM is assumed to be composed of hydrogen. The initial speed of the shell is therefore km s-1.

The Sedov radius rSed is defined by the condition that the swept-up mass equals the explosion mass, that is, , implying rSed = (3M0/4πρ0)1/3 = 6.6 × 1018(m/n0)1/3 cm. The Sedov time tSed is the time when the shell transitions from the coasting phase at r < rSed to the Sedov phase at r > rSed, and is given by yr.

For nonrelativistic speeds vo ≪ c and adiabatic shock waves, the kinetic energy (1)is conserved, so that dEke(t)/dt = 0. Introducing dimensionless radius x = r/rSed and time τ = t/tSed in units of Sedov radius and Sedov time, respectively, and noting that v = dr/dt, Eq. (1) leads to the equation of motion (2)for the dimensionless shell radius x. From this, the asymptotes (3)and (4)can be derived.

thumbnail Fig. 1

Top: rate at which kinetic energy is swept into the SNR shell (red curve, labeled “1”), rate at which kinetic energy is lost due to deceleration of the shell (blue curve, labeled “2”), and the net rate of change of kinetic energy in the SNR shell (green curve, labeled “3”). Bottom: integrated kinetic energy corresponding to the three terms shown in the upper panel. Curve 3 gives the accumulated swept-up kinetic energy, Esu(t).

Open with DEXTER

If nonthermal particles extract their energy from the kinetic energy of swept-up matter, then the change of kinetic energy of swept-up matter with time is given by (5)The first term on the right-hand-side of Eq. (5) is the rate at which kinetic energy is swept into the shocked material, and the second term is the rate at which the kinetic energy of the swept-up matter is lost by deceleration of the shell (and is therefore negative). The sum represents the net rate of change of kinetic energy in the SNR shell. These terms are shown in the top panel of Fig. 1, and the integrated energy associated with each term is shown in the bottom panel of Fig. 1. Here we let E51 = 1, m = 1.4, and n0 = 0.1 cm-3. Integrating the swept-up kinetic energy leads to a logarithmically diverging total energy that exceeds the initial kinetic energy of the explosion. By adding the change of energy associated with deceleration, the summed contribution recovers the initial kinetic energy of the explosion at late times.

The process of sweeping up matter from the surrounding medium has transformed the directed kinetic energy into internal thermal and nonthermal kinetic energy of swept-up matter. First-order Fermi acceleration at astrophysical shocks provides a specific mechanism to convert directed kinetic energy into nonthermal particle kinetic energy (e.g., Blandford & Eichler 1987), although here we treat the dissipation mechanism through a hypothetical conversion efficiency. Note how rapidly, ∝τ-2.5, that the total injection rate of kinetic energy decreases in the Sedov phase.

3. Cosmic-ray interactions in the SNR environment

Cosmic-ray ions and electrons can interact with target particles to make γ rays through secondary nuclear production and bremsstrahlung, respectively. Additionally, relativistic electrons will Compton-scatter photons of the ambient radiation fields to the γ-ray regime (see Blumenthal & Gould 1970; and Dermer & Menon 2009, for reviews of high-energy astrophysical radiation processes). There are three targets available for particle-particle interactions, namely from (1) the explosion mass; (2), the swept-up mass; and (3) the ISM gas. The explosion mass density nex(t) = M0/mpVsh(t), where the volume of the expanding shell of width Δ is Vsh(t) = 4π [r3 − (r − Δ)3] /3 → 4πr2Δ in the limit u ≡ Δ/r ≪ 1. Hence (6)The density of the swept-up mass is increased by the compression ratio. For a strong shock, the shell of swept-up matter has density nsu ≅ 4n0.

Cosmic rays accelerated at the forward shock and convecting downstream into the shocked fluid would interact with the compressed ISM with density ≈4n0. The most efficient radiation production occurs when the cosmic rays interact with explosion mass in the coasting phase, and swept-up mass in the Sedov phase. These two regimes can be bridged with a formula for the maximum target density available for interactions, given by (7)For cosmic rays to interact with the dense SNR shell material would require rapid diffusion from the region downstream of the forward shock into the expanding SNR shell. We consider the case where the target is the shocked ISM and where the CRs interact with the densest available target.

Secondary nuclear production makes γ rays from the decay of neutral pions, as well as through emissions from pion-decay electrons and positrons. For cosmic-ray protons with energies Ep = mpc2γp well above the pion-production threshold energy at Ep ≅ 300 MeV, the rate at which the proton Lorentz factor γp changes is given by , where Kp ≈ 0.5 is the mean inelasticity (fraction of energy lost per collision), and σpp ≈ 30 mb is the p-p inelastic cross section, so that the energy-loss time scale associated with secondary production is s. The maximum γ-ray luminosity that can be made by secondary nuclear production is therefore (8)with n(t) replaced by nmax(t), from Eq. (7), in tpp(t). The factor 1/3 represents the mean fraction of energy lost in an inelastic nuclear interaction that emerges as γ rays, and the term ηi is the fraction of accumulated swept-up kinetic energy that is transformed into cosmic-ray protons or electrons, where i = pp,ff, and C stand for nuclear production, electron bremsstrahlung, and electron Compton scattering, respectively.

The bremsstrahlung energy-loss rate for electrons with energy Ee = mec2γe interacting with ions of density nZ and charge Z in a fully ionized medium is given by , where αf and σT are the fine-structure constant and Thomson cross section, respectively. The term , taking γe ≈ 6000 for the typical electron Lorentz factor γe that makes GeV γ rays through this process. The characteristic bremsstrahlung energy-loss time scale is therefore s, and the maximum bremsstrahlung luminosity is (9)again replacing n(t) with nmax(t) in tff(t).

The loss rate of cosmic-ray electrons by Compton scattering is given by , where Uγ is the energy density of the target radiation field. The characteristic energy-loss time scale through Compton scattering in the Thomson limit is therefore tC(s), where we assume that the dominant radiation field is the cosmic microwave background (CMB) radiation with energy density Uγ = UCMB ≅ 4.0 × 10-13 erg cm-3. In the final expression, γe is replaced by the value of the electron Lorentz factor that will scatter a typical CMB photon to a γ ray with energy EGeV GeV. The γ-ray luminosity from Compton scattering is therefore (10)The nonthermal electrons will additionally lose energy through synchrotron losses, with total synchrotron luminosity larger than LC by a factor UB/Uγ, where UB is the magnetic-field energy density. The magnetic field is constrained in SNR spectral modeling, but does not affect the γ-ray emission model presented here.

thumbnail Fig. 2

Top: energy-loss time scales of cosmic-ray protons through secondary nuclear production (tpp; solid curves) and of cosmic-ray electrons through bremsstrahlung (tff; dashed curves) are shown for parameters corresponding to type Ia and type II SNe, as labeled (values for type II SNe are given in parentheses in the legend). Also shown are time scales for Compton energy losses (tC; dotted curves) of cosmic-ray electrons that scatter CMB photons to make γ rays of energy Eγ. Bottom: theoretical estimates of γ-ray luminosities of SNRs through secondary nuclear production (solid curves), bremsstrahlung (dashed curves), and Compton scattering (dotted curves). Data points show the measured >300 MeV γ-ray luminosities for the SNRs listed in Table 1. Thick curves in the two panels are for cosmic-ray interactions with the shocked external medium, and thin curves are for cosmic-ray interactions with the densest available target material. Model curves are plotted only in the weak-cooling regime.

Open with DEXTER

The curves shown in Fig. 2 give results for the energy-loss time scales in the top panel, and the γ-ray luminosities of SNRs in the bottom panel2. For the model results, we assume that type Ia and II SNe involve 1.4 and 10 M of explosion mass, and that the surrounding medium densities are 0.1 and 10 cm-3, respectively. The total kinetic energy of the explosion is assumed to be 1051 erg in both cases, and we let u = 0.1 for the relative width of the shell to the radius. The Sedov time scales for these parameters are 595 yr and 660 yr for the type Ia and type II SNRs, respectively. Also shown are the energy-loss time scales for cosmic-ray electrons that scatter CMB photons to γ rays of energy Eγ. The solid line in the upper panel separates the weak and strong cooling regimes; in the strong-cooling regime our treatment does not apply.

The lower panel of Fig. 2 gives model results for the γ-ray luminosities using the same parameters as shown in the upper panel. The results are plotted only in the slow-cooling regimes where the model applies. The swept-up kinetic energy is assumed to be transformed into cosmic-ray protons and electrons with efficiencies of ηpp = 10%, ηff = 5%, and ηC = 0.1% for the three processes. The efficiency for converting kinetic energy into electrons is small for the latter process, but these electrons have to have , large by comparison with bremsstrahlung γ rays made by electrons with γe ~ 3EGeV/mec2 ~ 6 × 103EGeV.

The injection efficiency should not, however, depend on the γ-ray emission process. In the case of a very soft electron spectrum, the characteristic amount of energy injected into lower-energy, γe ~ 104 electrons making bremsstrahlung would be much greater than the energy injected into the higher-energy, γe ~ 106 electrons that Compton-scatter soft photons to GeV energies, and this could account for the different efficiencies that are implied by the data for the two processes. This would, however, conflict with the hard electron spectra required to model SNRs. At 10 GeV, where Solar modulation effects and energy losses on cosmic-ray protons and electrons are small, the ratio of the cosmic-ray electron to proton fluxes is ≈1%. If SNRs are the sources of the cosmic-ray protons and electrons, then the injection efficiency for electrons should therefore be much less than for protons, and a bremsstrahlung origin of the γ-ray emission could be ruled out (Yuan et al. 2012).

Note that the increase in swept-up kinetic energy competes with the decrease in target density so that the γ-ray luminosity is roughly constant with time for secondary nuclear production and bremsstrahlung when using the target density given by Eq. (7). The γ-ray luminosity through nuclear production and bremsstrahlung declines at early times when cosmic-ray protons interact only with the swept-up ISM with density ≈4n0. The target photon density for Compton scattering is constant, so the γ-ray luminosity through this process tracks the increasing swept-up kinetic energy shown in Fig. 1, and is also therefore smaller at early times.

Table 1

γ-ray SNRs.

4. Comparison with data

We calculated the ≳300 MeV γ-ray luminosities Lγ from the data provided in the references for the SNRs listed in Table 1. The error bars in Lγ reflect both the uncertainties in the γ-ray measurements as well as distance uncertainties. The values of Lγ range from ≈1034 erg s-1 to ≈3 × 1036 erg s-1. The data show an apparent increase in luminosity from young to intermediate-aged (~3 ky) SNRs, followed by a decline for the middle-aged (≳10 kyr) SNRs, but a larger sample of Lγ from SNRs will be needed to confirm this trend. Most of these SNRs are type II, so that if the parameters used to characterize the type II SNRs are reasonable, then we find that η ~ 10% for nuclear processes to account for the γ-ray luminosities of the most luminous SNRs, generally consistent with expectations of production efficiency if SNRs accelerate the cosmic rays. There are, however, sources that deviate significantly from the η = 10% curves, for example, W28. Precise determinations of production efficiency requires an examination of SNRs on a case by case basis, because the surrounding medium density and composition, ejected mass and kinetic energy of the SNR, not to mention the limitations of the simple model, will introduce a wide range of luminosities even in the case that η is constant.

Four young, ≲3000 yr old SNRs have γ-ray luminosities ≲1035 erg s-1. Tycho is a type IA in a region of low density. If cosmic rays interact only with the shocked material, though not with the SNR shell, then the luminosity of Cas A is in accord with this simple model (see Fig. 2). SNRs RX J1713.7-3946 and RX J0852.0-4622, though they may be type II SNRs, also take place in low density regions, which will diminish the relative contribution from nuclear processes.

In our simple model, SNRs from type II SNe formed in dense environments are predicted to be ≈2 orders of magnitude more γ-ray luminous than Type Ia SNe, and therefore more easily detected. Given the greater rate of Type II than type Ia SNe in the Galaxy (e.g., Cappellaro et al. 1999), this would explain the larger number of core-collapse SNRs in our sample. The assumed larger ISM densities in the vicinity of core-collapse SNe are expected because type II and type Ib/c SNe are typically found in star-forming regions. Indeed, OH maser emissions from CTB 37A suggests that it is interacting with a very dense, n0 > 103 cm-3, molecular cloud (Hewitt et al. 2008; Castro & Slane 2010). The ratio of nuclear production and Sedov time scales is ~ for cosmic rays interacting with the swept-up ISM, so Sedov-age SNRs in dense environments would shine more brightly through nuclear interactions than Compton processes (cf. Yuan et al. 2012) than those in low-density surroundings. The SNRs RX J1713.7-3946 and RX J0852.0-4622 are, however, found in tenuous, n0 < 0.1 cm-3 environments (Slane et al. 1999, 2001), which could happen when core-collapse SNe take place in stellar wind cavities. Their hard spectra favors a Compton-origin for the gamma rays.

thumbnail Fig. 3

Ratio of 0.3−3 GeV to 0.3−3 TeV fluxes for the SNRs given in Table 1.

Open with DEXTER

We also plotted the ratio of the 0.3−3 GeV energy flux to the 300 GeV−3 TeV energy flux for the SNRs listed in Table 1. The result is shown in Fig. 3. All of the SNRs except for RX J1713.7-3946 and RX J0852.0-4622 have GeV to TeV flux ratios of order unity or greater. The middle-aged SNRs are more luminous in GeV γ rays than in TeV γ rays by factors of ≳10–100. RX J1713.7-3946 is anomalously low in comparison. There is a weak trend for increasing GeV to TeV flux ratio with age. This might be expected if the dominant processes are Compton scattering and nuclear production, noting from Fig. 2 that cosmic-ray electrons making TeV photons lose their energies on time scales of ~104 yr, leaving the long-lived cosmic-ray protons that would preferentially make GeV radiation.

Compton scattering as a multi-TeV γ-ray emission process for middle-aged SNRs might be ruled out by noting how rapidly the high-energy electrons that scatter CMB photons to TeV energies cool (Fig. 2). If these electrons are powered by swept-up kinetic energy, energetic electrons in the strong cooling regime would not be replenished due to the rapid decrease in the kinetic-energy injection rate shown by curve 3 in Fig. 1. Compton production of 10−100 TeV γ-rays requires electrons with γe ~ 107−108, irrespective of target photon energy. Thus the Compton scattering process can be ruled out by detection of ≫ TeV radiation from SNRs much older than the Sedov age, provided that it can be shown that there is no pulsar wind to inject high-energy electrons. Indeed, a rapid decline in the X-ray synchrotron radiation from electrons shortly after the Sedov phase is found by plotting the nonthermal X-ray luminosity as a function of radius (Nakamura et al. 2012), which is closely related to the remnant age. Reduction in the GeV−TeV γ-ray luminosity in middle-aged SNRs, if made primarily by protons and ions, seems to follow the behavior of the X-ray synchrotron luminosity radiated by high-energy electrons at earlier times. The evidence for the trend is weak, however, given that IC 443, an intermediate-aged SNR, is less luminous than most of the older remnants, in particular, W44 and W41. The decline in the γ-ray luminosity with age in intermediate and middle-aged SNRs, if confirmed, would instead have to be due to escape rather than energy loss as in the case of X-ray emitting electrons, given the long time scale for energy loss of cosmic-ray protons through inelastic nuclear processes. Finally, we note that the assumption of a uniform medium surrounding the SNR is an extreme simplification of the actual environment of SNRs, particularly the core-collapse type found in star-forming regions.

5. Conclusions

Data from the new generation of γ-ray telescopes can be used to test the hypothesis that SNRs are the sources of the cosmic rays. We have constructed a simple model for γ-ray production in SNRs and find that, for parameters that are expected to apply to type Ia and II SNe, ≈10% conversion efficiencies of directed kinetic energy to nonthermal protons or electrons are required to account for the measured γ-ray luminosities of SNRs if the radiation mechanism is secondary nuclear production or bremsstrahlung, respectively. The small γ-ray luminosities in young SNRs compared to intermediate-aged SNRs can be explained if the target material for cosmic-ray interactions is the shocked interstellar medium. Smaller efficiencies can account for the γ rays if the emission process is Compton scattering, but the energy has to be converted to highly relativistic electrons. If the relative acceleration efficiency for electrons and protons is given by the electron-proton ratio in the cosmic rays, of order ~1%, then the electron bremsstrahlung γ-ray luminosity would be too weak to explain the γ-ray luminosity of SNRs.

We also looked for trends in Lγ and the GeV to TeV flux ratios with SNR age. Except for RX J1713.7-3946 and RX J0852.0-4622, SNRs are found to be most γ-ray luminous at ages of ≈103−104 yr. The two anomalous SNRs, RX J1713.7-3946 and RX J0852.0-4622, have the hardest GeV-TeV spectra (Fig. 3) and are found in low-density environments, suggesting a Compton origin for their γ-ray emission. The apparent decline of Lγ at later times might be due to escape of cosmic rays from the acceleration and target interaction sites, but evidence for this trend is weak, and the possible presence of γ-ray emission due to pulsar winds must also be carefully considered. The tendency of the GeV to TeV flux ratio of SNRs to increase with age, or age measured in units of the characteristic Sedov age of the remnant, is suggested by this work, but will require additional analyses and study to establish.


1

Other subclasses of core-collapse SNe subclasses are type Ib and Ic SNe.

2

We calculate a γ-ray luminosity for CTB 37A larger, by an order of magnitude, than Castro & Slane (2010).

Acknowledgments

The work of C.D.D. is supported by the Office of Naval Research and the Fermi Guest Investigator program. The work of G.P. was performed through the Science and Engineering Apprenticeship Program (SEAP) at NRL. We would like to thank T. J. Brandt, D. Horan, J. D. Finke, and R. Yamazaki for comments on this work, and the referee for an illuminating report, suggestions, and corrections.
