1. Introduction

Three-dimensional magnetic null points have been studied in detail within the last decade in the main context of three-dimensional magnetic reconnection. Their importance in solar and magnetospheric environments have been observationally identified by many authors, for example, in solar flares (Fletcher et al. 2001; Masson et al. 2009), in solar active regions (Ugarte-Urra et al. 2007) or at the Earth’s magnetotail (Xiao et al. 2006). However, a complete understanding of the formation of current layers in three-dimensional magnetic null points through a physical dynamical relaxation, is still to be achieved, either mathematically or phenomenologically.

In two dimensions, current sheet formation and current accumulations have been widely studied around X-points both analytically (e.g. Dungey 1953; Green 1965; Somov & Syrovatskii 1976; Vekstein & Priest 1993; Craig 1994; Bungey & Priest 1995) and numerically, including the effects of plasma pressure (e.g. Rastätter et al. 1994; Craig & Litvinenko 2005; Pontin & Craig 2005; Fuentes-Fernández et al. 2011). For a more comprehensive review of current sheet formation in two dimensions see Priest & Forbes (2000) and Biskamp (2000).

All these studies assumed that the magnetic field is line-tied at the boundaries. This assumption imposes the constraints that energy and flux cannot leave or enter the system, and is reasonable because throughout the solar corona, most of the magnetic field lines are anchored in the photosphere. Furthermore, line-tying, along with ideal relaxation, ensures that helicity must be conserved during the relaxation (Moffatt 1985) and mass is conserved within flux tubes.

In three dimensions, the processes of current accumulation and reconnection in three dimensions are significantly different to, and much more complex than, those in two dimensions at X-type null points (e.g. Hesse & Schindler 1988; Priest et al. 2003). In general, currents can accumulate in three dimensions and magnetic reconnection can occur either at nulls or in the absence of them. Away from magnetic null points, magnetic reconnection may take place in different structures, such as separators (Longcope & Cowley 1996; Longcope 2001; Haynes et al. 2007; Parnell et al. 2008, 2010a,b) and quasi-separatrix layers (Priest & Démoulin 1995; Demoulin et al. 1996, 1997; Aulanier et al. 2006; Restante et al. 2009; Wilmot-Smith et al. 2009). On the other hand, locally at null points in three dimensions, magnetic reconnection can occur in several different regimes (Pontin et al. 2004, 2005; Masson et al. 2009; Al-Hachami & Pontin 2010; Pontin et al. 2011; Priest & Pontin 2009; Masson et al. 2012).

The nature of the reconnection that can take place around a three-dimensional null depends directly on the flows and the boundary disturbances (Rickard & Titov 1996; Priest & Pontin 2009). One particular example of these reconnection regimes is fan-spine reconnection, where a shearing of the spine or the fan drives the collapse of the null point. That is, the resulting Lorentz forces act in the same direction as the initial disturbance, thus increasing it and resulting in a folding of the spine and fan towards each other. The resulting reconnection takes place in the vicinity of the null and implies that magnetic flux is transferred across the different topological regions of the system (see Pontin et al. 2005; Pontin & Galsgaard 2007; Pontin et al. 2007b,a).

Another example of 3D null reconnection, which is the one relevant for this paper, is torsional reconnection, where the flows are such that the spine and fan plane remain perpendicular to each other, and the field lines are twisted around the spine in the same direction above and below the fan (torsional spine reconnection) or in opposite directions above and below the fan (torsional fan reconnection). The resulting reconnection of field lines takes place about the spine or the fan, respectively, causing a slippage of the magnetic field through the plasma in a direction opposite to that of the twist, dissipating the current density. These regimes do not involve flow across the spine or the fan, and hence, the global topology of the field remains unchanged (see Bulanov et al. 2002; Pontin et al. 2004, 2007a; Wyper & Jain 2010; Pontin et al. 2011).

In most cases that focus specifically on the field about the null, it is also assumed that the initial field is symmetric about the axis of the spine. However, this assumption is not necessary (Parnell et al. 1996). Al-Hachami & Pontin (2010) and Pontin et al. (2011) relaxed this assumption, showing that the degree of asymmetry changes the rate of reconnection, but not its nature.

Parnell et al. (1997) proved that the magnetic field locally about a non-potential 3D null point, i.e. the linear field about a non-potential null, produces a Lorentz force that cannot be balanced by a plasma pressure force. Accordingly, there are no static equilibrium models of linear non-potential or force-free nulls. This means that in 3D, the relaxation towards an equilibrium magnetic field very close to a magnetic null point has the same choices that a 2D linear null has, i.e., i) to evolve towards a potential null or ii) to develop a current singularity (current accumulation) at the null. Klapper (1997) proved analytically that in 2D, in the absence of plasma, the collapse of an X-type null results in the current building up at the null forming an infinite-time singularity. Numerical experiments of null collapse in non-zero beta plasmas show that an infinite-time singularity is still found (Craig & Litvinenko 2005; Pontin & Craig 2005; Fuentes-Fernández et al. 2011).

In general terms, most of the studies mentioned already considered magnetic reconnection at an initially potential 3D null driven by some external force. Reconnection, however, is likely to occur at the location where current has accumulated. For instance, in the case of spontaneous reconnection initiated by microinstabilities, it can occur in an equilibrium current density structure. The aim of this paper is to investigate the nature of current accumulations at a 3D magnetic null, after a torsional-type disturbance. The current structures will be formed via the ideal magnetohydrodynamic (MHD) evolution of the field and the plasma. The nature of non-force-free equilibrium found after a non-resistive MHD evolution of a stressed 3D null point, and the effects of the plasma pressure in the formation of current layers, to our knowledge, have not been widely studied. Pontin & Craig (2005) analysed the collapse of 3D nulls after a shearing-type perturbation (fan-spine collapse). In particular, they studied the formation of a current singularity at the location of the null in a non-force-free equilibrium, in an equivalent manner to the two-dimensional singularities studied by Craig & Litvinenko (2005). However, the formation of a static non-force-free equilibrium after a torsional-type disturbance has not yet been studied. We carry out such a study here.

Here, we consider the ideal evolution of a spiral null (non-potential) with an initial homogeneous current density parallel to the spine line, which may be thought of as the result of a torsional-spine disturbance. In particular, we are interested in the current accumulations that arise when a non-force-free equilibrium is reached. We evaluate the effects of the plasma pressure in the evolution, as both the initial disturbance and the background plasma pressure are changed systematically. This work is a continuation of the work carried out in Fuentes-Fernández et al. (2010, 2011) on non-resistive MHD relaxation of magnetic fields embedded in non-zero beta plasmas, using viscous forces to drive the relaxation, and allowing heat to be transferred to the plasma via the physical viscous heating term. Departures from axial symmetries are studied, obtaining current accumulations of a different nature, such as the formation of an infinite-time singularity in some cases (which does not exist in the axisymmetric case).

The paper is structured as follows. In Sect. 2, we present the equations that define the initial three-dimensional configuration and in Sect. 3 we present details of the numerical experiments. In Sect. 4 we present the results for 3D axisymmetric nulls with initial spine-aligned current, and, in Sect. 5 we present the results for non-symmetric nulls and evaluate the formation of a current singularity at the location of the null. Finally, we conclude with a general overview of the problem in Sect. 6.

2. Magnetic field configurations

The basic structure of a three-dimensional null point is illustrated in Fig. 1. The topological structure involves the spine line and the fan plane. In a positive 3D null (such as the one in the figure), the field lines approach the null parallel to the spine, and recede parallel to the fan plane. A negative null would show the opposite behaviour.

thumbnail Fig. 1

General topological structure of a 3D null point, including the spine line (thick) and fan plane (dashed). Field lines (thin) on either side of the fan plane run along the spine towards the null and then spread out just above or below the fan plane.

Open with DEXTER

Following the description given in Parnell et al. (1996) for linear 3D nulls, the magnetic field, B, close to a null point may be expressed as (1)where M is a matrix with elements Mi,j = Bi/xj, and r is the position vector (x,y,z)T, which is likely to be small for general nulls where linearity may be weak. For linear nulls the current density is constant, and it can be divided into two components, parallel and perpendicular to the spine line. In the particular cases studied in this paper, the only non-zero component of the initial current density will be the one parallel to the spine, so that (2)Where, we have chosen a coordinate system in which the spine lies along the z-axis (Parnell et al. 1996). In this case, the matrix M can be reduced to (3)where 0 < b < ∞, to ensure that the spine of the null is along the z-axis, and that the null is positive.

For these non-potential nulls, the associated Lorentz force has no z-component and simply acts in planes parallel to the fan plane of the null. Furthermore, j × B = 0 on x = y = 0, hence, in our final non-force-free equilibrium, there will be no flux transferred across the fan, and this will remain perpendicular to the spine, but the geometry of the field lines and the distribution of current density and plasma will change.

3. Numerical scheme

For the numerical experiments studied in this paper, we have used Lare3D, a staggered Lagrangian-remap code, which is second-order accurate in space and time, with user controlled viscosity, which solves the full MHD equations, with the resistivity set to zero (see Arber et al. 2001). The staggered grid is used to build conservation laws and maintains ·B = 0 to machine precision, by using the Evans and Hawley constrained transport method for the magnetic flux (Evans & Hawley 1988). The numerical domain is a 3D box with a uniform grid of 5123 points.

Magnetic field lines are line-tied at the boundaries and all components of the velocity are set to zero on the boundaries. The other quantities have their derivatives perpendicular to each of the boundaries set to zero. Hence, the quantities that are conserved over the whole domain are total energy and total mass. Since the field is frozen to the plasma (there is no diffusion to within numerical limits), the mass in a single flux tube (or along a field line) must be conserved.

thumbnail Fig. 2

Magnetic configuration for the initial non-equilibrium state with homogeneous spine-aligned current, for the case with b = 1, jsp = 1 and p0 = 1, showing a) the 3D configuration with field lines above and below the fan in purple and orange, respectively. The fan plane is outlined in dashed black and the spine is represented in green, with projections onto the xz-plane and yz-plane (dashed green lines). In b), the field lines in the fan plane are plotted.

Open with DEXTER

thumbnail Fig. 3

Magnetic configuration for the final equilibrium state for the spiral null, for the same experiment as in Fig. 2, showing a) the 3D configuration with field lines above and below the fan in purple and orange, respectively. The fan plane is outlined in dashed black and the spine is represented in green, with projections onto the xz-plane and yz-plane in dashed green lines. In b), the field lines in the fan plane are plotted.

Open with DEXTER

thumbnail Fig. 4

Contour plots of the different forces acting in the final equilibrium state in the x = 0 plane, for the same experiment as in Fig. 2. Showing, from left to right, the magnitude of the pressure force ( −  | p | ), of the Lorentz force and of the total force. Values are normalised to the maximum force of the initial state. It can be observed that the pressure and Lorentz forces balance each other and create a non-force-free equilibrium.

Open with DEXTER

The numerical code uses the normalised MHD equations, where the normalised magnetic field, density and lengths, imply that the normalising constants for pressure, internal energy, current density and plasma velocity are The subscripts n indicate the normalising constants, and the hat quantities are the dimensionless variables used in the code. The expression for the plasma beta can be obtained from this normalisation as In this paper, we will work with the normalised quantities, but the hat is removed from the equations for simplicity.

The (normalised) equations governing our ideal MHD dynamical processes are where Fν and Hν are the terms for the viscous force and viscous heating. The internal energy, ϵ, is given by the ideal gas law, p = ρϵ(γ − 1), with γ = 5/3.

Finally, the time-scale in our experiments may be defined as the fast-mode crossing time, tF, i.e. the time for a fast magnetosonic wave to travel from the null to one of the boundaries (for instance in the y-direction), which is calculated as (8)where is the local fast magnetosonic speed.

4. Axisymmetric nulls

4.1. Initial state

We first look at the relaxation of initial configurations of magnetic null points with constant current density everywhere in the direction parallel to the spine, of the form (0,0,jsp), and we assume axial symmetry in the initial field by making b = 1 in Eq. (3). The magnetic field is then given by (9)The fan is perpendicular to the spine and lies in the z = 0 plane. We have run various experiments with different initial pressure. Figure 2 shows the magnetic configuration of the initial state, for jsp = 1 and p0 = 1. The magnetic field lines show a homogeneous twist about the spine, and the field lines lying in the fan define a logarithmic spiral. The only initially non-zero force in the fan plane is the magnetic tension force, which during the relaxation, will act to straighten the magnetic field lines. This force is such that, in principle, the system can evolve towards a potential configuration (a radial null) if energy and helicity is allowed to leave the system.

4.2. Final equilibrium state

We concentrate on the case shown in Fig. 2, which has jsp = 1 and p0 = 1. The final state is achieved after more than 300 fast magnetosonic crossing times. The magnetic field configuration at the end of the simulation is shown in Fig. 3. Owing to the line-tied boundaries, and the restriction of an ideal evolution, the field cannot dissipate the original twist. Instead, the relaxation appears to concentrate it onto the portions of field lines that are about the spine, above and below the null.

As can be seen in Fig. 3b, the field lines expand radially from the null and then bend slightly as they reach the boundaries of the domain. This bending is a consequence of the fact that the magnetic field lines are line-tied in a way that is not axisymmetric. In Sect. 4.3, we consider a 2.5D approximation assuming cylindrical symmetry in a region close to the null point.

The total energy of the evolution is checked and is found to be conserved throughout the relaxation to within an error of 0.03%. This conservation of energy demonstrates that undesirable effects, such as numerical diffusion, do not play a significant role in the relaxation. By the end of the experiment, only 1% of the initial magnetic energy has been transferred into internal energy of the plasma, due to viscous damping. At this point, the velocities are effectively zero in the whole domain.

thumbnail Fig. 5

Contour plots of the final equilibrium current density vector for a vertical cross section in the x = 0 plane, for the same experiment as in Fig. 2. The current has been split into two components: a) parallel and b) perpendicular to the magnetic field.

Open with DEXTER

To establish the nature of the final equilibrium, we evaluated the forces at the end of the relaxation. Figure 4 shows the different forces, namely, the Lorentz force, the pressure force and the total force (the sum of the two) in the final equilibrium state. The system is only force-free locally close to the null (where it is effectively potential) and along the spine line. Everywhere else, non-zero Lorentz forces are balanced by non-zero pressure gradients in a non-force-free equilibrium. This is the result of both the closed boundary conditions, which do not allow magnetic flux to be transferred through the boundaries, and the full MHD relaxation, which allows the different forces to balance each other. Note that the Lorentz force is such that, if the field lines were free to move at the boundaries, they would untwist, expelling their free magnetic energy and helicity out of the system, hence, achieving a potential state.

Around the axis of the spine, away from the null, a non-force-free envelope has formed (Figs. 4a and b). These regions become larger and move further apart as we move away from the null. Also, regions of non-force-freeness appear about the plane of the fan, away from the null. Only small residual forces remain on the fan close to the boundaries (Fig. 4c).

A non-force-free equilibrium implies an inhomogeneous distribution of the current and the plasma pressure. The final distributions of electric current density, parallel and perpendicular to the magnetic field, are shown in Fig. 5. These two components account for the force-free and the non-force-free contributions to the final equilibrium, respectively. The parallel component (Fig. 5a) is one order of magnitude larger than the perpendicular component (Fig. 5b), indicating that the equilibrium is not far from a force-free state.

At the exact location of the null point, the current density remains with its initial value of jsp = 1. This is not inconsistent with Parnell et al. (1997), because the current is zero everywhere else. From the beginning of the experiment, at the location of the null itself, the Lorentz forces are zero, and so are the pressure forces.

The system is potential (i.e. current free) in a very localised region about the null point, where r < 0.1, as expected from Parnell et al. (1997). The parallel current is mainly concentrated along the spine line, forming an hourglass shape centered on the null and lying along this axis (Fig. 5a). As already mentioned the field is force-free in these regions. The perpendicular current is enhanced at the edges of the hourglass cones and about the fan plane (Fig. 5b). Naturally, these are the locations of the non-zero Lorentz and pressure forces (Figs. 4a and b).

Finally, a comparison has been made of results with different background plasma pressures, with p0 = 0.1,0.5,1.0,1.5. In Fig. 6 we show the parallel electric current density through a horizontal cut of Fig. 5a, at z = 0.7, and in a vertical cut along the spine (z-axis). The plots show the results for the four different initial plasma pressures, but because they all overlap, only one line is visible, with the exception of the lowest pressure case (p = 0.1), which shows a slightly smoother profile. Hence, changes in the plasma pressure do not appear to lead to significant changes in the formation of the current concentrations.

thumbnail Fig. 6

Plot of the parallel (to the magnetic field) component of the electric current density a) in a horizontal cut x = 0 plane, at height z = 0.7, and b) along the spine axis (z-axis) for four different experiments with p0 = 0.1 (dotted), p0 = 0.5 (dashed), p0 = 1 (solid) and p0 = 1.5 (dash-dotted).

Open with DEXTER

4.3. The 2.5D approximation

As has been discussed above, close to the null point, the field lines expands radially and the system can be assumed to have cylindrical symmetry about the axis of the spine. This symmetry breaks slightly when we approach the edges of the box because of the squared line-tied boundaries. Under the assumption of cylindrical symmetry, all quantities depend only on two coordinates, namely, the height, z, and the radius, r, and the equilibrium can be described as a 2.5-dimensional state (that is, there are three spatial coordinates, but all quantities only depend on two of them).

Using the solenoidal constraint (i.e. ·B = 0), the magnetic field for a two-dimensional cylindrical system must satisfy, (10)Also, if /∂φ = 0, the magnetic field, B = (Br,Bφ,Bz), may be rewritten as (11)where Ac(r,z) is a function analogous to the flux function in 2D, for systems with cylindrical symmetry, which satisfies (12)where bφ(Ac) is an unknown function that depends uniquely on Ac.

As in the 2D case, in a magnetohydrostatic (MHS) equilibrium that satisfies these conditions, the plasma pressure must be a unique function of Ac, as well as bφ. Therefore, a Grad-Shafranov equation can be derived, which defines the force balance between the plasma and magnetic forces in final equilibrium, as (13)Figure 7 shows the numerical functionality of the poloidal field function bφ(Ac) and the plasma pressure p(Ac) of the final equilibrium state, for all points within a region about the null (to avoid non-cylindrical asymmetries) that reaches from  − 0.5 to 0.5 both in r and z. Both quantities show a good dependence in this region, and the term of the poloidal field, bφ. In particular, it shows that in the region about the null, where the boundaries do not have a strong effect, a non-force-free description is found, where the plasma pressure plays an important role.

thumbnail Fig. 7

Numerical dependence of poloidal field (black) and plasma pressure (blue) with the function Ac. All points of a region about the null that reaches from  − 0.5 to 0.5 both in r and z are plotted here.

Open with DEXTER

The assumption of axial symmetry about the spine is non-generic. It is very likely that some sort of asymmetry in the field would arise in a realistic situation. In the next section, we consider the current structure generation due to the collapse of non-axisymmetric spiral nulls, where the field lines have a preferred direction in the fan plane, and therefore, the 2.5D assumption is not valid even close to the null point.

5. Magnetic field asymmetries

By removing the constraint that b = 1 in Eq. (3), we can introduce axial asymmetries to the initial state. Hence, from Eq. (3) our initial magnetic field is of the form (14)Depending on the value of b relative to the magnitude of the initial current density, jsp, the magnetic field lines can take different shapes. According to Parnell et al. (1996), we can define a threshold for the current density, which for our field is jthresh =  | b − 1 | , above which the fan field lines are spiral, below which they are said to be of skewed improper form. We consider here the case where  | jsp |  >  | b − 1 | . The fan field lines form a spiral null, as in the b = 1 axisymmetric case. If b ≠ 1, this spiral will bend towards a preferred direction (in our case, the preferred direction is the x-axis if 0 < b < 1, or the y-axis if b > 1).

Previous studies on the effect of magnetic field asymmetries in 3D spiral nulls have been conducted by Pontin et al. (2011). They focus on the reconnection rate for both torsional spine and torsional fan reconnection, but do not look at the formation of equilibrium current structures. In the particular torsional spine case, they start with a potential configuration with different values of b, and then introduce a localised magnetic field perturbation in the form of a ring of magnetic flux. They find that the peak current and the reconnection rate do not depend strongly on the degree of asymmetry (given by the value of b). This dependence is shown to be more important for the torsional fan reconnection case (which is not considered here).

Equation (14) gives a generic form for the magnetic field around a 3D magnetic null point with a homogeneous current parallel to the spine line (Parnell et al. 1996). The case of b = 1 yields jthresh = 0, and hence, corresponds to the axisymmetric case studied in Sect. 4, where the two eigenvectors lying on the fan plane are perpendicular to each other, and their eigenvalues are complex conjugates. This is not the case for the asymmetric fields, where the eigenvectors are no longer perpendicular, although their eigenvalues are still complex conjugates. Note, from Eq. (3), that the effect of increasing or decreasing b by the same amount (i.e. multiplying or dividing by the same value) is analogous. The only difference in doing so is the preferred axis that the magnetic field lines will follow, which is either x or y (i.e. a rotation of 90° around the spine axis). Therefore, without loss of generality, we have chosen only values of b lower than 1. We ran relaxation experiments for various values of b < 1, with a fixed current parallel to the spine, jsp = 1. As before, during the relaxation the energy was checked to ensure that it is conserved to within numerical error and we note that a similar amount of viscous dissipation occurs, resulting in a rise in internal energy of about 1%.

thumbnail Fig. 8

Magnetic field lines lying on the fan surface for the initial (top row) and final equilibrium (bottom row) state, for four different experiments, with b = 1,1/2,1/4,1/8, and jsp = 1, from left to right.

Open with DEXTER

thumbnail Fig. 9

Current density on the fan plane for the final state for the same four experiments as in Fig. 8. The central current layer extends along the direction of one of the eigenvectors (the minor axis) associated with the linear analysis of the initial magnetic field (dashed lines), where α is the angle (in degrees) that this eigenvector makes with the y-axis. The maximum current density value in these plots (dark green) is jz = 20, with jz = 0 as the minimum (white).

Open with DEXTER

In Fig. 8 we show the fan plane field lines in the initial non-equilibrium and the final equilibrium state for four different experiments with four different values of b, namely, b = 1,1/2,1/4,1/8, and with jsp = 1 for all of them. As the parameter b is systematically decreased, the fan field lines show a more pronounced bend towards the x-axis, both in the initial and in the final state. Initially, the asymmetry appears as a skewed spiral, and after the dynamical relaxation, the fan field lines show a more complex geometry.

To evaluate the deviations from the potential field in the final state, we look at the current accumulations at the fan plane. The only non-zero component of the current density for all cases is checked to be jz. This implies that the current density at the null is parallel to the spine, and hence, the spine and the fan plane remain perpendicular to each other. In Fig. 9 we show the z-component of the current density for the same four experiments as in Fig. 8. The final state is a non-force free equilibrium, as in the axisymmetric case, but here, a new feature is formed along one of the eigenvectors of the fan plane (known as the minor fan axis). This is formed because the initial forces in the fan plane are not axisymmetric and are weaker along the minor axis. Note that in the symmetric case, the only non-zero initial force is the magnetic tension force, which acts axisymmetrically, while here, there is also a magnetic pressure force. The overall Lorentz force in the fan plane is such that it prevents the field from evolving towards a potential configuration. Instead, it accumulates the current in a current layer through the null itself.

Again, by considering the forces, we find that in the final state the system is in a non-force-free equilibrium everywhere except very close to the null, where tiny residual forces remain on the fan plane. These are shown in Fig. 10 for two cuts along the y and x axes. The Lorentz forces are directed towards the null. The pressure forces act against the Lorentz forces but are not able to balance them. This results in a non-zero net total force that causes the gradual accumulation of current at the null point and is consistent with the formation of a singularity whose nature is discussed below. These results agree with Parnell et al. (1997), who found that the linear field about a non-potential null cannot be balanced by a pressure gradient. Hence, since the field in the vicinity of the null is not potential, an equilibrium cannot be achieved there. Moreover, the magnetic field in the fan plane is weaker along the minor axis of the null, therefore, as already mentioned, the same is true for the Lorentz forces, and therefore that is the axis along which the current density is able to extend.

thumbnail Fig. 10

Forces in the final state in the fan plane for the case b = 0.25, showing a) the y-component along the y-axis (along the current accumulation) and b) the x-component along the x-axis, of the Lorentz forces (dotted), the pressure forces (dashed) and the total forces (solid).

Open with DEXTER

thumbnail Fig. 11

Time evolution, with logarithmic axes, of the null point current current density for four asymmetric experiments, with b = 1/2,1/4,1/8 and 1/16. Dotted lines show fits to jnull = mtn.

Open with DEXTER

The stronger the initial field asymmetry, the larger the amplitude of the null current layer. Note that this current layer is a feature of the asymmetry, and does not appear in the axisymmetric case. Neither is it related to a fan-spine collapse, because the current density about the null remains parallel to the spine. It is noticeable how, for the highest degree of asymmetry, the null current density is the maximum current of the domain.

The creation of a pronounced layer of current density perpendicular to the spine at the location of the magnetic null point and along the minor fan axis, and the associated forces plotted in Fig. 10, suggest the formation of a singularity (Craig & Litvinenko 2005; Pontin & Craig 2005; Fuentes-Fernández et al. 2011). Figure 11 shows the time evolution of the current density at the null point for four different asymmetric experiments. Each of these evolutions is modelled with a function of the form (15)where both m and n are positive and both depend on the degree of asymmetry, defined by b. The null current density seems to have entered an asymptotic regime similar to the one studied by Fuentes-Fernández et al. (2011) for 2D X-points. The results shown in Fig. 11 suggest the formation of an infinite-time singularity at the null point, associated with a creation of the perpendicular current density caused simply by an initial asymmetry of the magnetic configuration. Note that the appearance of such a singularity is strictly linked to the asymmetric nature of the initial state. This singularity does not exist if the field is axisymmetric, because in that case, the field can become potential locally about the null point.

Current singularities at three-dimensional magnetic null points have been found after the fan-spine collapse of a tilted null (Pontin & Craig 2005). The key difference between these singularities and those described in this paper is the direction of the current density vector. In the fan-spine collapse, the current is directed along the tilt axis of the fan, for example, the x-axis (Pontin et al. 2005; Pontin & Galsgaard 2007; Pontin et al. 2007b,a; Masson et al. 2009, 2012). In contrast, our current density is directed along the spine line, i.e. the z-axis. Therefore, our singularity is not due to a collapse of the fan and the spine towards one another, but is a completely new feature that has never been observed in the past. This study is the first signature of a current density singularity at a purely spiral null, and additional studies are needed to show if it is associated with a new regime of 3D null reconnection.

6. Summary and conclusions

The three-dimensional relaxation of spiral magnetic null points with initial spine-aligned current has been investigated under non-resistive conditions, resulting in all cases in a non-force-free equilibrium, where all velocities have been damped out by the viscous forces. In the final states, forces of the plasma pressure and magnetic field, which are of about the same order as the initial non-equilibrium Lorentz forces, balance each other in a genuine non-force-free state.

In the axisymmetric case, the initial field is a spiral null with a uniform twist of the field lines everywhere. During the relaxation, the field evolves by concentrating the initial constant current density around the spine, above and below the fan, and hence, the twist of the field lines also resides there. The fan field lines show a radial configuration, with small departures from the radial field caused by the squared line-tied boundaries. In the final equilibrium, we decomposed the electric current density vector into two components, parallel and perpendicular to the magnetic field, and we found that the parallel component is about ten times higher than the perpendicular component. This means that the field is very close to a force-free field, although it cannot exactly be described as such.

The parallel current, which is the dominant component, is maximum along the spine line, and draws an hourglass shape with two cones that meet at the location of the null. The accumulations of perpendicular current (regions of non-force-free-ness) occur at the edges of the two cones about the spines, above and below the fan. In the axisymmetric case, the field is shown to be potential only for the small region about the null, where r < 0.1. Systematic changes of the initial plasma pressure have been studied, finding the same amplitudes for the current accumulations in all cases. This indicates that changes in the plasma pressure may not play an important role in the evolution of axisymmetric spiral nulls.

Moreover, the magnetic field in the axisymmetric case shows cylindrical symmetry about the spine for r < 0.5. A Grad-Shafranov equation can be used in this case to describe the field analytically, demonstrating the importance of the plasma pressure force to balance the Lorentz force.

Overall, the final equilibrium for the initially axisymmetric null point shows three distinct regions, i) a potential envelope surrounding the null, at r < 0.1, ii) an axisymmetric region where the system is in non-force-free equilibrium (0.1 < r < 0.5), and iii) the region close to the boundaries, where the cylindrical symmetry is broken by the squared line-tied boundaries, but where the system is still able to achieve a non-force-free equilibrium.

By breaking the initial axial symmetry of the field lines, we obtained new features that were not present in the axisymmetric case. The fan field lines are not radial any more. Instead, they bend towards a preferred direction, and they build a pronounced perpendicular current accumulation at the null, elongated along the direction of the minor axis, about which the magnetic field strength is smaller. In these cases, locally about the null, the plasma pressure forces are not able to balance the Lorentz forces, which are directed towards the null and form an infinite-time singularity. This is not present in the axisymmetric case, since it can reach a potential equilibrium very close to the null, save exactly at the null itself. The current at the null is directed along the spine axis and the spine and fan remain perpendicular, therefore, it is not caused by a fan-spine collapse, like the commonly known current singularities previously found at three-dimensional null points (Pontin & Craig 2005). The kind of singularity observed in this paper for the asymmetric spiral nulls has, to our knowledge, never been observed in the past. It is proposed that this new singularity, which arises naturally from the non-symmetric character of our initial state, may be linked to a new regime of magnetic reconnection at 3D magnetic nulls.

The MHD evolution of tilted nulls with initial fan-aligned current, the effects of plasma pressure, and the formation of a current accumulations such as the one studied by Pontin & Craig (2005), will be studied in a follow-up paper from the series of dynamical relaxation of coronal magnetic fields.

Acknowledgments

The authors would like to thank the referee for many useful comments, which helped to understand the details of the experiments carried out in this paper. This work has been partly supported by SOLAIRE European training network. Computations were carried out on the UKMHD consortium cluster funded by STFC and SRIF. J.F.F. is funded from the St Andrews Rolling Grant (ST/H001964/1).

References

  1. Al-Hachami, A. K., & Pontin, D. I. 2010, A&A, 512, A84 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  2. Arber, T. D., Longbottom, A. W., Gerrard, C. L., & Milne, A. M. 2001, J. Comput. Phys., 171, 151 [NASA ADS] [CrossRef] [Google Scholar]
  3. Aulanier, G., Pariat, E., Démoulin, P., & Devore, C. R. 2006, Sol. Phys., 238, 347 [NASA ADS] [CrossRef] [Google Scholar]
  4. Biskamp, D. 2000, Magnetic Reconnection in Plasmas [Google Scholar]
  5. Bulanov, S. V., Echkina, E. Y., Inovenkov, I. N., & Pegoraro, F. 2002, Phys. Plasmas, 9, 3835 [NASA ADS] [CrossRef] [Google Scholar]
  6. Bungey, T. N., & Priest, E. R. 1995, A&A, 293, 215 [NASA ADS] [Google Scholar]
  7. Craig, I. J. D. 1994, A&A, 283, 331 [NASA ADS] [Google Scholar]
  8. Craig, I. J. D., & Litvinenko, Y. E. 2005, Phys. Plasmas, 12 [Google Scholar]
  9. Demoulin, P., Henoux, J. C., Priest, E. R., & Mandrini, C. H. 1996, A&A, 308, 643 [NASA ADS] [Google Scholar]
  10. Demoulin, P., Bagala, L. G., Mandrini, C. H., Henoux, J. C., & Rovira, M. G. 1997, A&A, 325, 305 [NASA ADS] [Google Scholar]
  11. Dungey, J. W. 1953, Philos. Mag. Ser. 7, 44, 725 [Google Scholar]
  12. Evans, C. R., & Hawley, J. F. 1988, ApJ, 332, 659 [NASA ADS] [CrossRef] [Google Scholar]
  13. Fletcher, L., Metcalf, T. R., Alexander, D., Brown, D. S., & Ryder, L. A. 2001, ApJ, 554, 451 [NASA ADS] [CrossRef] [Google Scholar]
  14. Fuentes-Fernández, J., Parnell, C. E., & Hood, A. W. 2010, A&A, 514, A90 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  15. Fuentes-Fernández, J., Parnell, C. E., & Hood, A. W. 2011, A&A, 536, A32 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  16. Green, R. M. 1965, in Stellar and Solar Magnetic Fields, ed. R. LustI, AU Symp., 22, 389 [Google Scholar]
  17. Haynes, A. L., Parnell, C. E., Galsgaard, K., & Priest, E. R. 2007, Roy. Soc. London Proc. Ser. A, 463, 1097 [NASA ADS] [CrossRef] [Google Scholar]
  18. Hesse, M., & Schindler, K. 1988, J. Geophys. Res., 93, 5559 [NASA ADS] [CrossRef] [Google Scholar]
  19. Klapper, I. 1997, Phys. Plasmas, 5, 910 [NASA ADS] [CrossRef] [Google Scholar]
  20. Longcope, D. W. 2001, Phys. Plasmas, 8, 5277 [NASA ADS] [CrossRef] [Google Scholar]
  21. Longcope, D. W., & Cowley, S. C. 1996, Phys. Plasmas, 3, 2885 [NASA ADS] [CrossRef] [Google Scholar]
  22. Masson, S., Pariat, E., Aulanier, G., & Schrijver, C. J. 2009, ApJ, 700, 559 [NASA ADS] [CrossRef] [Google Scholar]
  23. Masson, S., Aulanier, G., Pariat, E., & Klein, K.-L. 2012, Sol. Phys., 276, 199 [NASA ADS] [CrossRef] [Google Scholar]
  24. Moffatt, H. K. 1985, J. Fluid Mech., 159, 359 [NASA ADS] [CrossRef] [Google Scholar]
  25. Parnell, C. E., Smith, J. M., Neukirch, T., & Priest, E. R. 1996, Phys. Plasmas, 3, 759 [NASA ADS] [CrossRef] [Google Scholar]
  26. Parnell, C. E., Neukirch, T., Smith, J. M., & Priest, E. R. 1997, Geophys. Astrophys. Fluid Dyn., 84, 245 [NASA ADS] [CrossRef] [Google Scholar]
  27. Parnell, C. E., Haynes, A. L., & Galsgaard, K. 2008, ApJ, 675, 1656 [NASA ADS] [CrossRef] [Google Scholar]
  28. Parnell, C. E., Haynes, A. L., & Galsgaard, K. 2010a, J. Geophys. Res. (Space Physics), 115, 2102 [NASA ADS] [CrossRef] [Google Scholar]
  29. Parnell, C. E., Maclean, R. C., & Haynes, A. L. 2010b, ApJ, 725, L214 [NASA ADS] [CrossRef] [Google Scholar]
  30. Pontin, D. I., & Craig, I. J. D. 2005, Phys. Plasmas, 12, 072112 [NASA ADS] [CrossRef] [Google Scholar]
  31. Pontin, D. I., & Galsgaard, K. 2007, J. Geophys. Res. (Space Physics), 112, 3103 [NASA ADS] [CrossRef] [Google Scholar]
  32. Pontin, D. I., Hornig, G., & Priest, E. R. 2004, Geophys. Astrophys. Fluid Dyn., 98, 407 [NASA ADS] [CrossRef] [Google Scholar]
  33. Pontin, D. I., Hornig, G., & Priest, E. R. 2005, Geophys. Astrophys. Fluid Dyn., 99, 77 [NASA ADS] [CrossRef] [Google Scholar]
  34. Pontin, D. I., Bhattacharjee, A., & Galsgaard, K. 2007a, Phys. Plasmas, 14, 052106 [NASA ADS] [CrossRef] [Google Scholar]
  35. Pontin, D. I., Bhattacharjee, A., & Galsgaard, K. 2007b, Phys. Plasmas, 14, 052109 [NASA ADS] [CrossRef] [Google Scholar]
  36. Pontin, D. I., Al-Hachami, A. K., & Galsgaard, K. 2011, A&A, 533, A78 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  37. Priest, E. R., & Démoulin, P. 1995, J. Geophys. Res., 100, 23443 [NASA ADS] [CrossRef] [Google Scholar]
  38. Priest, E., & Forbes, T. 2000, Magnetic Reconnection [Google Scholar]
  39. Priest, E. R., & Pontin, D. I. 2009, Phys. Plasmas, 16, 122101 [NASA ADS] [CrossRef] [Google Scholar]
  40. Priest, E. R., Hornig, G., & Pontin, D. I. 2003, J. Geophys. Res., 108, 1285 [NASA ADS] [CrossRef] [Google Scholar]
  41. Rastätter, L., Voge, A., & Schindler, K. 1994, Phys. Plasmas, 1, 3414 [NASA ADS] [CrossRef] [Google Scholar]
  42. Restante, A. L., Aulanier, G., & Parnell, C. E. 2009, A&A, 508, 433 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
  43. Rickard, G. J., & Titov, V. S. 1996, ApJ, 472, 840 [NASA ADS] [CrossRef] [Google Scholar]
  44. Somov, B. V., & Syrovatskii, S. I. 1976, Neutral Current Sheets on Plasmas, 13 [Google Scholar]
  45. Ugarte-Urra, I., Warren, H. P., & Winebarger, A. R. 2007, ApJ, 662, 1293 [NASA ADS] [CrossRef] [Google Scholar]
  46. Vekstein, G., & Priest, E. R. 1993, Sol. Phys., 146, 119 [NASA ADS] [CrossRef] [Google Scholar]
  47. Wilmot-Smith, A. L., Hornig, G., & Pontin, D. I. 2009, ApJ, 704, 1288 [NASA ADS] [CrossRef] [Google Scholar]
  48. Wyper, P., & Jain, R. 2010, Phys. Plasmas, 17, 092902 [NASA ADS] [CrossRef] [Google Scholar]
  49. Xiao, C. J., Wang, X. G., Pu, Z. Y., et al. 2006, Nature Phys., 2, 478 [NASA ADS] [CrossRef] [Google Scholar]
