Numerical solution of the radiative transfer equation: Xray spectral formation from cylindrical accretion onto a magnetized neutron star
^{1}
INAF, Istituto di Astrofisica Spaziale e Fisica Cosmica, via U. La Malfa
153,
90146
Palermo,
Italy
email: farinelli@ifc.inaf.it
^{2}
Dipartimento di Fisica, Università di Ferrara,
via Saragat 1, 44100
Ferrara,
Italy
^{3}
NASA, Goddard Space Flight Center, Greenbelt, MD
20771,
USA
Received:
2
September
2011
Accepted:
6
November
2011
Context. Predicting the emerging Xray spectra in several astrophysical objects is of great importance, in particular when the observational data are compared with theoretical models. This requires developing numerical routines for the solution of the radiative equation according to the expected physical conditions of the systems under study.
Aims. We have developed an algorithm solving the radiative transfer equation in the FokkerPlanck approximation when both thermal and bulk Comptonization take place. The algorithm is essentially a relaxation method, where stable solutions are obtained when the system has reached its steadystate equilibrium.
Methods. We obtained the solution of the radiative transfer equation in the twodimensional domain defined by the photon energy E and optical depth of the system τ using finitedifferences for the partial derivatives, and imposing specific boundary conditions for the solutions. We treated the case of cylindrical accretion onto a magnetized neutron star.
Results. We considered a blackbody seed spectrum of photons with exponential distribution across the accretion column and for an accretion where the velocity reaches its maximum at the stellar surface and at the top of the accretion column, respectively. In both cases higher values of the electron temperature and of the optical depth τ produce flatter and harder spectra. Other parameters contributing to the spectral formation are the steepness of the vertical velocity profile, the albedo at the star surface, and the radius of the accretion column. The latter parameter modifies the emerging spectra in a specular way for the two assumed accretion profiles.
Conclusions. The algorithm has been implemented in the xspec package for Xray spectral fitting and is specifically dedicated to the physical framework of accretion at the polar cap of a neutron star with a high magnetic field (≳ 10^{12} G). This latter case is expected to be typical of accreting systems such as Xray pulsars and supergiant fast Xray transients.
Key words: methods: numerical / Xrays: binaries / radiative transfer / magnetic fields
© ESO, 2012
1. Introduction
The solution of the radiative transfer equation (RTE) that describes the modification of a seed photon spectrum due to Comptonization in a plasma is a much debated mathematical problem. The equation in its full form is indeed integrodifferential (Pomraning 1973) and allows for analytical solutions under some particular assumptions, such as electron temperature T_{e} = 0 (Titarchuk & Zannias 1998) or in the energy domain when the emerging spectrum is a powerlaw (Titarchuk & Lyubarskij 1995). If the photon energy exchange for scattering is low (Δν/ν ≪ 1), it is possible to perform a Taylor expansion of the Comptonization operator around the photon initial energy, which transforms the RTE from integrodifferential to purely differential (Rybicki & Lightman 1979); this is known as the FokkerPlanck (FP) approximation. The necessary conditions to allow this mathematical approach are that the Comptonscattering process occurs below the KleinNishina regime, namely when the electron temperature kT_{e} is subrelativistic (≲ 100 keV), and that the optical depth of the Comptonization region is τ ≳ 1. The regime of low temperature and high optical depth of the plasma indeed ensures that the spectrum is almost isotropized, so that it is possible to use the Eddington approximation for the specific intensity I(ν) = J(ν) + 3∇·F(ν), where J and F are the zero and first moment of the intensity field, respectively.
Moreover, if the plasma is not static but subject to dynamical (bulk) motion with velocity v(τ), then another condition for using the FP approximation is that v(τ) must be subrelativistic. When all the above restrictions are considered, one obtains by computing the first two moments of the RTE a main equation that describes the shape of the angleaveraged emerging intensity J(ν) of the Comptonization spectrum. The general form of the RTE for the photon occupation number n(ν) = J(ν)/ν^{3} with subrelativistic electron temperature in the presence of bulk motion was first derived by Blandford & Payne (1981, hereafter BP81). Later, Titarchuk et al. (1997, hereafter TMK97) showed that analytical solutions can be found if the velocity profile (assuming spherical symmetry) of the matter follows the freefall law, v_{R} ∝ R^{−1/2}. In this case, the equation can be written as L_{x}n(x,τ) + L_{τ}n(x,τ) = −s(x,τ) and the solution can be obtained using the variableseparation method in the form (1)where c_{k} and R_{k}(τ) are the expansion coefficients and eigenfunctions of the space operator L_{τ}, respectively, while N_{k}(x) is the solution of the differential equation (2)where and is the ktheigenvalue of the space operator.
The Comptonization spectrum is mostly dominated by the first eigenvalue (see Fig. 3 in TMK97), while the terms N_{k}(x) with k ≥ 2 represent the fraction of photons that leave the medium without appreciable energyexchange. Starting from the results of TMK97, Farinelli et al. (2008, hereafter F08) developed a model (comptb) for the Xray spectral fitting package xspec, which computes the emerging spectrum by means of a numerical convolution of the Green’s function of the energy operator with a blackbody (BB)like seed spectrum. The model has been successfully applied to a sample of lowmass Xray binaries hosting a neutron star (NS). The method of the variable separation has also been adopted by Becker & Wolff (2007, hereafter BW07), to find analytical solutions of the RTE in the case of cylindrical accretion onto the polar cap of a magnetized NS. The starting equation in BW07 is formally the same as in BP81: the most significant difference is that the Thomson crosssection is replaced by an angleaveraged crosssection that takes into account the presence of the magnetic field (B ~ 10^{12} G). Following the results of Lyubarskii & Sunyaev (1982), BW07 assumed a velocity profile v(τ) ∝ − τ, which allowed the RTE to be separable in energy and space. Note that the assumed velocity profile implies that the matter flow stagnates at the stellar surface, which is at odds with the solution of TMK97, where the matter velocity is increasing towards the central object, which can be either a NS or a black hole (BH). When the velocity profile is not free falllike (TMK97, F08), or ∝ τ (BW07), the variable separation method can no longer be applied and the solution of the RTE can be obtained only with numerical methods.
We report a numerical algorithm that allows the solution of the RTE in the FP regime using finitedifferences for any desired velocity profile and seed photon spatial and energy distribution. We apply in particular it to cylindrical accretion towards the polar caps of a magnetized NS, following the approach of BW07. The algorithm essentially uses a relaxation method, therefore it finds the asymptotic (stationary) solution of the RTE for a given initial value (at time t = 0) condition. Our work is structured as follows: in Sect. 2 we describe the kernel of the algorithm for generic twovariable elliptic partial differential equations; in Sect. 3 we formulate the problem for the general RTE and appropriate boundary conditions; in Sect. 4 we consider the more specific case of a system configuration with azimuthal symmetry, typical of cylindrical accretion; in Sect. 5 we show the emerging spectra obtained for different sets of the theoretical parameter space; finally, in Sect. 6 we briefly discuss possible astrophysical consequences and implementations (e.g., for xspec) derived from the application of the algorithm.
2. The general elliptic partial differential equations
The algorithm we report is essentially based on the relaxation methods, which allow one to find the solution of a boundary elliptical problem. The differential equation has to be written by finite differences. Once the sparse matrix is defined, it can be split into layers over which an iteration process is applied until a solution is found (Press et al. 1992). The general form of a linear secondorder elliptic partial differential equation with vanishing mixed derivatives and a source term can be written as (3)The solution is numerically obtained by including in the right hand side of Eq. (3) a derivative over a fictitious time ∂u/∂t. Iterating for a sufficient number of steps over t, the initial guess function at t = 0 converges for t → ∞ to the timeindependent solution of Eq. (3).
We define a threedimensional grid of discrete points for the variables x,y and t; (4)where h_{x},h_{y},h_{t} are the grid spacing. The function u(x,y,t) is evaluated at any point of the grid, so we write it as . We write the first and second derivatives over the variables using finite differences: (5)Substituting the above definitions into Eq. (3) and collecting terms, we obtain (6)where (7)The operators over the x and y variables are then defined as (8)The solution procedure consists of dividing Eq. (6) into two equations. The first gives us the solution for an intermediate m−1/2 layer, while the second provides the solution for the mlayer. As starting point we need to establish an initial guess for the function at m = 1. The system of equations to be solved is thus (9)in which we have temporarily dropped the indices i,j. From the system we notice that the intermediate layer m − 1/2 is needed only to build up the solution at the subsequent layer in m. The numerical accuracy of the solution can be estimated by combining both equations in the system (9), which gives (10)The third term on the righthand side of Eq. (10) represents the residual error in the numerical solution. As a first step, we collect the terms with the same index in both Eqs. (9) and obtain (11)Both equations are defined inside a 2D (x,y)domain, with boundary conditions defined according to the specific problem under consideration. First, for any m and j values, we must impose the boundary condition on the lefthand side of the xdomain (i = 0) for the function (12)while the source term is defined at the beginning. Thus, for i = 0, Eq. (6) can be written as (13)where (14)with the coefficients determined in Eq. (7). For i = 1, using Eq. (13) we obtain (15)which can be written as (16)where (17)Iterating the process, we obtain the general form (18)where (19)At the right boundary of the xdomain (i = N_{x}), we impose the second boundary condition (20)Now, using Eq. (18) we can thus build up the solution over the xvariable iteratively as (21)Therefore, the construction of the solution is obtained in two steps: a bottomup process which allows one to build the coefficients and (Eq. (19)) starting from the left boundary condition on (Eq. (12)), followed by a topdown procedure determined by the right boundary condition (Eq. (20)).
Once the solution over the xvariable for the m − 1/2 layer is obtained for any j (the index of the y variable), we then seek the solution of the second equation in the system (9) by following the same procedure described above with initial boundary condition at j = 0 (22)and, similarly to Eq. (19) (23)where (24)depends on the solutions and obtained in the layers m − 1/2 and m − 1.
As required for the procedure over the xvariable, the coefficients and , built from and , are determined by the left boundary condition (j = 0) for the function , and the solution for any j is determined by the right boundary condition : (25)After constructing the solution over the x and y variable, the solution of the top layer m becomes the initial function of the bottom layer related to iteration m + 1 according to the scheme (26)It is also worth mentioning that at the first iteration m = 1 an initial guess function must be assumed, which is needed to find the solutions and in the system (9). The loop over m stops when the same convergence criterion is satisfied, which physically means that the solution has “relaxed” to its stationary value. One possible criterion could be 1 − ε < u^{m−1} / u^{m − 1/2} < 1 + ε and 1 − ε < u^{m−1/2} / u^{m} < 1 + ε, where ε is a userdefined numerical tolerance. In the next section we will show instead another convergence criterion we have chosen for stopping the iteration procedure, for the particular case of the RTE.
3. Application to the radiative transfer equation and boundary conditions
The general form of the RTE in the presence of subrelativistic bulk motion for a plasma with constant temperature T_{e} is given by (see Eq. (18) in BP81) (27)where n(ν,r) is the zeromoment occupation number of the radiation field intensity, V is the plasma bulk velocity vector, σ(ν) is the electron scattering crosssection, n_{e}(r) is the electron density and j(ν,r) is the source term. Because the spectral formation is determined by the optical depth τ of the system, we use the latter quantity as the actual space variable. The solution of Eq. (27) is fulfilled by imposing the boundary condition at the surface defined by τ = 0, (which represents the starting point of the integration domain) for the spectral flux, which is given by (28)Under particular symmetries of the system configuration (e.g., cylindrical or spherical), the problem becomes onedimensional. For constant electron temperature T_{e} it is also more convenient to use the adimensional variable x ≡ hν/kT_{e}; moreover, when performing numerical integration using finitedifference methods, we use a logarithmic binning of the energy through the additional change of variable x → e^{q}. Under these assumptions, Eq. (28) becomes (29)where J ≡ n x^{3} is the specific intensity.
At the inner boundary we impose the condition (30)where A is the albedo at the surface. A fully absorptive surface (A = 0) is appropriate for a BH, while 0 < A ≤ 1 accounts, e.g., for a NS atmosphere. However, the inner boundary condition (30) depends on energy as well as space (see Eqs. (28) and (29)). For mixed boundary value problems, no analytical solutions are possible (see Appendix E in TMK97) and numerical methods prove to be unstable. However, in the energy range where the spectrum is a powerlaw J(x,τ) = R(τ)x^{−α}, Eq. (30) becomes (31)where β_{0} is the bulk velocity at the inner radius (τ = 0), and here the problem is reduced to a standard boundary condition over the space variable τ. Writing the derivative in terms of finitedifference, Eq. (31) then becomes (32)which can be written after collecting terms as (33)where G(A) = 3/2(1 − A)/(1 + A). We then set our problem as follows: first, because the solution of the RTE physically represents a specific intensity, it must by definition be equal to zero in the limits E → 0 and E → ∞, therefore we set (see Eqs. (12) and (20)). For the behavior of the function for τ = 0 (j = 0), Eq. (33) immediately allows us to define (see Eq. (22)) (34)As outer boundary condition over τ, we impose that , which means that the specific intensity goes to zero for τ → τ_{max}.
We emphasize that the condition for any (i,j)value implies a specific restriction in the choice of the step size h_{τ}, which ensures that (as β_{0} ≤ 0). More specifically, we imposed the condition on h_{τ} such that the number of steps over τ be N_{τ} = τ_{max}/h_{τ} ≥ 10.
3.1. The iteration procedure
As already mentioned in Sect. 2, it is necessary to choose a convergence criterion for stopping the iteration over the m variable. We proceeded in the following way: at each iteration m, we computed the spectral index α_{m} of the solution (corresponding to τ = 0) in a given energy range E_{min} − E_{max}. To minimize bias or wrong estimate of α_{m}, the definition of the energy interval for the computation of the spectral slope must be chosen carefully. If the seed photon spectrum is a BB with temperature kT_{bb}, a reasonable choice can be the assumption E_{min} ≈ 7kT_{bb} and E_{max} ≈ 20kT_{bb}, respectively, given that this interval is above the major contribution of the BB component and below the expected highenergy cutoff value.
Once α_{m} is estimated, it is inserted into Eq. (34), which accordingly represents the boundary condition at τ = 0 for the iteration m + 1 (see Eq. (22)). We then computed the new index α_{m + 1} for , and again inserted it into Eq. (34) at iteration m + 2, and so on. The routine is stopped when α_{m} and α_{m + 1} differ less than 10^{5} provided that the condition holds for a sufficiently high number of iterations (>100). Note that the same criterion is adopted also if β_{0} = 0, even if then of course remains constant across the iteration. We have also verified that this criterion automatically also satisfies the convergence of the norms u^{m − 1}, u^{m − 1/2}, and u^{m}.
4. Cylindrical accretion onto a magnetized neutron star
We applied our algorithm to solve the RTE for accretion towards the polar cap of a magnetized NS, whose mathematical formalism was developed by BW07 in the framework of the spectral formation of accretionpowered Xray pulsars. The relatively strong magnetic field (B ≳ 10^{12} G) of the NS is expected to channel the accretion flow towards the polar caps, and for low values of the altitude above the star surface, the problem can be treated in a axissymmetric approximation where the space variable is defined by the vertical coordinate Z. The magnetic field moreover forces the medium to become birefringent as the effect of vacuum polarization, and birefringence entails the formation of two linearly polarized modes (ordinary and extraordinary) of the photons, each having a characteristic scattering crosssection. For ordinary mode photons with energy below the first cyclotron harmonic at E_{c} ≈ 11.57 B_{12} keV (where B_{12} ≡ B/10^{12} G), BW07 defined angleaveraged crosssections parallel and perpendicular to the lines of the magnetic field as σ_{∥} = 10^{3}σ_{T} and σ_{⊥} = σ_{T}, respectively, where σ_{T} is the Thomson scattering crosssection. This is indeed the only approximation that allows to treat the problem analytically or numerically. We note that Ferrigno et al. (2009), starting from the analytical solutions reported in BW07, developed a model that was later almost successfully tested on the accreting pulsar 4U 0115+63. Their model is based essentially on the convolution of the columnintegrated Green’s function of the thermal plus bulk scattering operator with a given seed photon distribution. The basic assumption of this derivation is that the velocity profile of the accreting matter is assumed to be v(τ) ∝ − τ, which allows one to find analytical solutions through the variable separation method (Eqs. (36) and (37) in BW07). The numerical algorithm we developed directly solves the RTE, without the need of this prescription for the dynamical configuration of the accreting matter field, and we included some modifications with respect to the approach of BW07 and Ferrigno et al. (2009).
Fig. 1
Emerging spectra obtained from the solution of Eq. (37) for different values of the electron temperature kT_{e} and velocity profile defined in Eq. (45). In both cases the fixed parameters are kT_{bb} = 1 keV, τ = 0.2, η = 0.5, r_{0} = 0.25, A = 1. Left panel: β_{0} = 0.1. Right panel: β_{0} = 0.64.

Open with DEXTER
Fig. 2
Same as Fig. 1 but for different values of the optical depth τ. Fixed parameters are kT_{bb} = 1 keV, η = 0.5, β_{0} = 0.64, r_{0} = 0.25, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
First, following TMK97, we include in Eq. (27) a second term in the thermal Comptonization operator that accounts for the contribution of the bulk motion velocity of electrons in addition to their thermal (Maxwellian) component. With this prescription in mind, Eq. (27) becomes (35)where ϵ ≡ hν, , while t_{esc} is the photon mean escape timescale (see Eq. (17) in BW07) (36)Now, using the relation dτ = n_{e}σ_{∥}dZ and the logarithmic binning of the adimensional energy x ≡ hν/kT_{e}, Eq. (35) becomes (37)where we have defined the quantities (38)and (39)where β(τ) = v(τ)/c, while the dimensionless parameter ξ is given by (see Eq. (26) in BW07) (40)Equation (37) is given in the general form (3) and for this particular case, we have (41)To solve Eq. (37), it is necessary to define the behavior of the velocity profile β(τ). We considered two possibilities: in the first one, we assumed a general form (42)where the normalization constant is defined A = β_{0}(Z_{0}/Z_{s})^{η}, and β_{0} is the terminal velocity at the altitude Z_{0}.
The continuity equation for the system here considered gives the electron number density (43)where ṁ ≡ Ṁ/Ṁ_{E} is the mass accretion rate in Eddington units and R_{0} is the radius of the accretion column.
We then define the adimensional quantities z and r_{0} through the change of variables Z → R_{S ⊙ }mz and R_{0} → R_{S ⊙ }mr_{0}, where m ≡ M/M_{⊙}, while M_{S ⊙ } and R_{S ⊙ } are the Sun mass and Schwarzschild radius, respectively. The effective vertical optical depth of the accretion column is then given by (44)where C = 2.2 × 10^{3}, and z_{0} is the vertical coordinate at the NS surface.
Inverting relation (44), we also define the velocity profile of the accreting matter as a function of the optical depth τ instead of the space variable z(45)As a second possibility, following BW07, we considered the velocity profile (46)where Ψ = 0.67ξ/z_{0} (see Eq. (32) in BW07).
Given that in our model the optical depth τ represents one of the free parameters, once it is provided in input together with adimensional accretion column radius r_{0}, the accretion rate ṁ must be first computed either from Eq. (44), if β(τ) is defined as in Eq. (45), or from Eq. (28) in BW07 if β(τ) belongs to Eq. (46). This step is necessary to determine the ξ parameter (Eq. (40)), and requires fixing the maximum altitude of the accretion column z_{max}. We assumed z_{max} = 2z_{0}, and all emerging spectra (see next section) were computed with this choice.
5. Results
In this section we report some examples of the theoretical spectra obtained by the numerical solution of Eq. (37) for different sets of the physical quantities that define the system. We consider a BB seed photon spectrum at given temperature kT_{bb} with exponential spatial distribution across the vertical direction, according to
(47)with the normalization constant defined as , where R_{km} and D_{10} are the BB emitting area in kilometers and the source distance in units of 10 kpc, respectively. The spectra were computed using the velocity profiles defined in Eqs. (45) and (46), respectively. The common parameters for both cases are consequently the BB temperature kT_{bb}, the electron temperature kT_{e}, the optical depth τ, the albedo at the inner surface A and the radius of the accreting column r_{0}. On the other hand, for β(τ) belonging to Eq. (45), additional parameters are the index η and the terminal velocity at the star surface β_{0}. We first present the results for this second physical case.
Fig. 3
Same as Fig. 1 but for different values of the index of the velocity profile. Fixed parameters are kT_{bb} = 1 keV, τ = 0.2, β_{0} = 0.64, r_{0} = 0.25, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
Fig. 4
Same as Fig. 1 but for different values of the inner velocity β_{0}. Fixed parameters are kT_{bb} = 1 keV, τ = 0.2, η = 0.5, r_{0} = 0.25, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
In Fig. 1 we show the emerging spectra for different values of the electron temperature kT_{e} and two terminal velocities β_{0} = 0.1 and β_{0} = 0.64. As expected, both times higher values of kT_{e} produce flatter spectra and push the cutoff energy E_{c} to higher energies; on the other hand, the bulk contribution as a second channel of Comptonization depends on the value of kT_{e}. The two extreme temperature values reported here, kT_{e} = 5 keV and kT_{e} = 50 keV, are particularly instructive: for low electron temperatures the spectrum changes from BBlike when β_{0} = 0.1 to a cutoff power law with E_{c} ≳ 30 keV when β_{0} = 0.64, while the spectral change is much less enhanced for a hot plasma. These can be considered as typical examples of bulkdominated and thermaldominated Comptonization spectra, respectively.
Together with the electron temperature, the optical depth τ is an important parameter that plays a key role in determining the spectral slope and cutoff energy, as clearly shown in Fig. 2. We note that in Figs. 1 and 2 the index of the velocity profile was chosen to be η = 0.5, typical of accretion onto a compact object where gravity and radiation pressure are the only force terms that determine the dynamical configuration. Here, the terminal value of the matter velocity β_{0} depends on the ratio of the radiative and gravitational forces, provided the condition F_{r} / F_{g} ≲ 1 is satisfied. This relatively simple approach is valid for low values of optical depth τ, while when τ > 1 radiative transfer becomes important and the problem requires in principle a more accurate radiationhydrodynamics treatment.
Fig. 5
Same as Fig. 1 but for different values of the albedo A, with the velocity profile of Eq. (45). Fixed parameters are kT_{bb} = 1 keV, τ = 0.4, η = 0.5, β_{0} = 0.64, r_{0} = 0.25. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
Fig. 6
Same as Fig. 1 but for different values of the accretion column radius r_{0}, with the velocity profile of Eq. (45). Fixed parameters are kT_{bb} = 1 keV, τ = 0.2, η = 0.5, β_{0} = 0.64, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
It is outside the scope of this paper to compute the exact velocity profile for accreting matter under the presence of a strong radiation field in a high optical depth environment. We merely introduced a simple parametrization for modifying the velocity field by changing the index η, with the results shown in Fig. 3, for two different values of the electron temperature kT_{e}. As Fig. 3 shows, the lower the value of η, the harder the spectrum: this behavior can be explained in a quantitative and a qualitative way. Indeed, as η increases, the velocity profile β(z) becomes sharper, and for a fixed terminal velocity β_{0}, electron temperature kT_{e}, and optical depth τ, while photons diffuse through the bounded medium, on average the energy of the electrons (caused by their Maxwellian plus bulk motion) will be lower, and consequently the net energy gain of the photons due to inverse Compton will be less. From the mathematical point of view, it is worth mentioning that Mastichiadis & Kylafis (1992, hereafter MK92) reported the analytical solution of the RTE in the FokkerPlanck approximation with the variable separation method for spherical accretion without magnetic field in the limit T_{e} = 0. Assuming a general velocity profile β_{r} ∝ r^{−η}, the authors showed that the spectral index of the kthComptonization order emerging spectrum yields α_{k} = 3 + 3λ_{k}/(2 − η) (see Eq. (1)), where λ_{k} is the ktheigenvalue of the space operator. Using Eq. (B12) of MK92, it follows immediately that as η increases, the spectral index α_{k} increases as well. This mathematical result in terms of spectral formation can be considered as general in the framework of the FP treatment, and is accordingly qualitatively meaningful for our research.
We also emphasize that analytical solutions for η ≠ 0.5 have been possible for MK92 only because of the condition T_{e} = 0, which drops the thermal Comptonization operator in the RTE, while when T_{e} > 0 this is possible only for η = 0.5 (TMK97, F08).
In Fig. 4 we show results for different terminal bulk velocities β_{0} for two electron temperature values. The figure can be considered an extension and completion of Fig. 1 because more values of β_{0} are shown to better appreciate the induced changes in the emerging spectra.
The spectral modifications as a result of different values of the albedo A at the inner surface are instead shown in Fig. 5, where we explored full absorption (A = 0) and full reflection (A = 1), together with other intermediate values. In the framework of a physical link to astrophysical objects it would be natural to associate a BH to the condition A = 0 and a NS to the condition A = 1, respectively (Titarchuk & Fiorito 2004; Farinelli & Titarchuk 2011), even though this latter assumption may be considered an oversimplification of the problem. A most realistic approach would consist indeed in an energydependent treatment of the albedo, a problem that could be faced only with Montecarlo simulations, with the additional complications arising from a detailed treatment of the star photosphere (surface) properties.
Fig. 7
Emerging spectra obtained from the solution of Eq. (37) for different values of the electron temperature kT_{e}, with the velocity profile of Eq. (46). In both cases the fixed parameters are kT_{bb} = 1 keV, r_{0} = 0.25, A = 1. Left panel: τ = 0.2. Right panel: τ = 0.4.

Open with DEXTER
Fig. 8
Same as Fig. 1 but for different values of the optical depth τ, with the velocity profile of Eq. (46). Fixed parameters are kT_{bb} = 1 keV, r_{0} = 0.25, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
Fig. 9
Same as Fig. 1 but for different values of the albedo A, with the velocity profile of Eq. (46). Fixed parameters are kT_{bb} = 1 keV, τ = 0.4, r_{0} = 0.25. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
For our unavoidably simplified assumptions, the net effect of increasing values of A is a progressive flattening of the emerging spectra. This is physically explained because when A > 0, a fraction of photons (which becomes 100% when A = 1) suffers on average more scattering with respect to A = 0. Qualitatively, the spectral modification leads in the same direction as an enhanced optical depth of the system.
The last parameter that strongly influences the spectral formation is the radius of the accretion column r_{0}, whose effects are shown in Fig. 6. Indeed, following the BW07 prescription, the mean escape time for photons using the diffusion approximation (see Eq. (36)). On the other hand, both the bulk and thermal Comptonization parameters (y_{bulk} and y_{th}, respectively) are related to the mean number of scatterings that photons experience in the medium via (48)where , ζ_{bulk}, and ζ_{th} are the averaged number of scatterings and the fraction energy gain per scattering for bulk and thermal Comptonization, respectively. Both and are of course also proportional to t_{esc} (see Eqs. (94)–(97) in BW07).
Evidently therefore, for fixed velocity profile parameters A and η (see Eq. (42)), once the optical depth τ is defined (see Eq. (44)), to keep its value constant for increasing r_{0} (as reported in Fig. 6), the accretion rate ṁ must also increase in a way to keep the ratio constant. Combining Eq. (36) and (43) yields t_{esc} ∝ ṁ, which in turn leads to an enhancement of the Comptonization parameters y_{bulk} and y_{th} in Eq. (48) with a hardening of the spectral shape.
Fig. 10
Same as Fig. 1 but for different values of the accretion column radius r_{0}, with the velocity profile of Eq. (46). Fixed parameters are kT_{bb} = 1 keV, τ = 0.2, A = 1. Left panel: kT_{e} = 5 keV. Right panel: kT_{e} = 15 keV.

Open with DEXTER
Considering now the velocity profile defined in Eq. (46), we see that the results are qualitatively the same as in Eq. (45) as far as the spectral modifications induced by variations of kT_{e} are concerned (Fig. 7), τ (Fig. 8) and A (Fig. 9), respectively. But there are opposite effects that are induced in the emerging spectra by different values of the accretion column radius r_{0} for the velocity profile here considered. Indeed, using Eq. (40) and the definition of τ in Eq. (28) of BW07, which allows us to express the accreting matter velocity in terms of the zcoordinate, in spite of the optical depth τ, it is straightforward to see that . In particular, if z_{0} = 2.42 and z_{max} = 2z_{0} we have β_{max} = 0.60 for r_{0} = 0.1, β_{max} = 0.38 for r_{0} = 0.25, β_{max} = 0.27 for r_{0} = 0.5 and β_{max} = 0.2 for r_{0} = 1, respectively. Note that because Eq. (46) describes matter that stagnates at the star surface, here β_{max} represents the velocity at the accretion column altitude z_{max}. In other words, while using Eq. (45), the choice of r_{0} does not modify the velocity field of the accreting matter, which is only determined by the choice of β_{0} and η, for (46) as r_{0} increases the bulk contribution to the spectral formation becomes less important, and this drop is not compensated for by the increase of the photon mean escape time t_{esc}, which, as explained above, would instead contribute to spectral hardening.
6. Implementation in the XSPEC package
Parameter description of the xspec model compmag.
Our model will be publically available and distributed as a contributed model to the official xspec^{1} web page.
In Table 1 we report a summary of the free parameters of the model with their physical meaning. The code is written using Clanguage, and can be easily installed following the standard procedure reported in the official xspec manual and in the brief cookbook, which will be delivered together with the source code. As a general concern for users, we point out that usually the emerging spectrum obtained from the Comptonization of a seed photon population with any given energy distribution S(E) can be presented as the sum of the seed spectrum and its convolution with the scattering Green’s function G(E,E_{0}) of the electron plasma, each with their relative weight, according to the general formalism (49)where C_{n} is a normalization constant. The ratio A/(A + 1) is the Comptonization fraction, and its value qualitatively determines the contribution to the total spectrum of the Comptonized photons. The value of A, here not to be confused with the albedo, may depend on several geometrical and physical factors, such as the spatial seed photon distribution inside the system configuration (see Fig. 4 in TMK97). The lower the value of A, the more enhanced the direct seed photon spectrum S(E). Examples of xspec models that use the definition in Eq. (49) are bmc (TMK97) and comptb (F08). Either model, however, does not solve the full RTE including the photon spatial diffusion and distribution, the latter of which is an unknown quantity that is phenomenologically described through the continuum parameter log(A). On the other hand, it is not possible to change the value of log(A) arbitrarily in our present model, i.e., according to the observed spectra. Its value is implicitly determined once the seed photon spatial distribution is fixed.
We presented the results of simulated spectra assuming an exponential distribution over τ for S(E), which was assumed to be a BB; then, the transition from the lowenergy part of the spectrum (the Rayleigh regime for E ≲ 3kT_{bb}) to the highenergy (Comptonized) powerlaw shape is almost smooth, which corresponds approximately to A ≫ 1 in Eq. (49). Other seed photons spatial distributions can produce a different onset between the BB peak and the powerlawlike regime. In general, for observed spectra where a direct and enhanced BBlike component is required by the fit, our claim is to model the source continuum with modelization of the type bb + compmag by preferably keeping equal to each other the temperatures of the direct and Comptonized BB component.
7. Conclusions
We have developed a numerical code for solving elliptic partial differential equations based on a relaxation method with finite differences. In particular, we reported a specific application of the algorithm to the radiative transfer equation in the FokkerPlanck approximation, which is of particular interest for highenergy astrophysical applications. We considered cylindrical accretion onto the polar cap of a magnetized neutron star, using the mathematical formulation of the problem reported in Becker & Wolff (2007) with some modifications. Specifically, we included the secondorder bulk Comptonization term in the scattering operator and we considered different velocity profiles for the accreting matter.
The code for the computation of the emerging spectra in this configuration has been written with the aim to implement it in the xspec package and will be delivered to the scientific community. Because angleaveraged crosssections caused by the magnetic field were included, the model is suitable to be applied to the observed spectra of sources where most of spectral formation is claimed to form close to a NS with high magnetic field (B ≳ 10^{12} G), such as accreting Xray pulsars and supergiant fast Xray transients. Of course there are some unavoidable simplifications in the model, such as the assumption of constant electron temperature of the accretion column. We note, however, that the isothermal condition is typical of any Comptonization model implemented in XSPEC because it is fundamental for users to reach a compromise between the accuracy of the physical treatment and the computational speed. More accurate theoretical investigations of the accretion processes can be performed only with MHD simulations performed through PC clustercomputing resources, which are beyond the scope of the present work.
As in many theoretical models, the number of available free parameters is higher than the number of the observable ones.
Therefore a correct working approach is to keep some parameters fixed during the Xray spectral fitting procedure to avoid degeneracy.
If this model is used in any publication, we kindly ask the authors to cite this paper in the reference list.
Acknowledgments
We acknowledge financial contribution from the agreement ASIINAF I/009/10/0.
References
 Becker, P. A., & Wolff, M. T. 2007, ApJ, 654, 435 (BW07) [NASA ADS] [CrossRef] [Google Scholar]
 Blandford, R. D., & Payne, D. G. 1981, MNRAS, 194, 1041 (BP81) [NASA ADS] [Google Scholar]
 Farinelli, R., & Titarchuk, L. 2011, A&A, 525, A102 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Farinelli, R., Titarchuk, L., Paizis, A., & Frontera, F. 2008, ApJ, 680, 602 (F08) [NASA ADS] [CrossRef] [Google Scholar]
 Ferrigno, C., Becker, P. A., Segreto, A., Mineo, T., & Santangelo, A. 2009, A&A, 498, 825 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
 Lyubarskii, Y. E., & Sunyaev, R. A. 1982, Soviet Astron. Lett., 8, 330 [NASA ADS] [Google Scholar]
 Mastichiadis, A., & Kylafis, N. D. 1992, ApJ, 384, 136 (MK92) [NASA ADS] [CrossRef] [Google Scholar]
 Pomraning, G. C. 1973, The equations of radiation hydrodynamics, ed. G. C. Pomraning [Google Scholar]
 Press, W. H., Teukolsky, S. A., Vetterling, W. T., & Flannery, B. P. 1992, Numerical recipes in C, The art of scientific computing (Cambridge: University Press) [Google Scholar]
 Rybicki, G. B., & Lightman, A. P. 1979, Rad. processes Astrophys., ed. G. B. Rybicki, & A. P. Lightman [Google Scholar]
 Titarchuk, L., & Fiorito, R. 2004, ApJ, 612, 988 [NASA ADS] [CrossRef] [Google Scholar]
 Titarchuk, L., & Lyubarskij, Y. 1995, ApJ, 450, 876 [NASA ADS] [CrossRef] [Google Scholar]
 Titarchuk, L., & Zannias, T. 1998, ApJ, 493, 863 [NASA ADS] [CrossRef] [Google Scholar]
 Titarchuk, L., Mastichiadis, A., & Kylafis, N. D. 1997, ApJ, 487, 834 (TMK97) [NASA ADS] [CrossRef] [Google Scholar]
