Planck early results
Free Access

Fig.6

thumbnail

Left: coupling coefficients of the 1.4 K stage. The thermal emission in the high frequency bands becomes too small to be measured. Right: scaled PSD of the 1.4 K stage thermal fluctuations for the 100-1a and 217-7a bolometers. The horizontal dashed lines indicate 30% of the total noise level of these bolometers.

This figure is made of several images, please see below:
