Properties of the bipolar outflows at t = 3510 d. Shown are the density ρ in (a) and (b), the absolute value of the magnetic field |B| in (c) and (d), the -component of the Maxwell stress tensor normalized by the centrifugal force M r ϕ = B r B ϕ / 4 π ρ v ϕ 2 $ \tilde{M}_{r\phi} = B_rB_\phi/4\pi\rho v_\phi^2 $ in (e) and (f), the absolute ratio between the poloidal and toroidal magnetic field components |Bpol/Btor| in (g) and (h), the poloidal Alfvén Mach number M Alfven , pol = v pol 4 π ρ / B pol $ \mathcal{M}_{\mathrm{Alfven, pol}}=v_{\mathrm{pol}}\sqrt{4\pi \rho}/B_{\mathrm{pol}} $ in (i) and (j), the inverse plasma beta β−1 = |B|2/8πPgas in (k) and (l), and the specific enthalpy h in (m) and (n). The gray contours in the zoomed-in plots in the left column correspond to the transition from sub- to super-Alfvénic flows (i.e., the Alfvén surface).
