Fig. 1.


Download original image

Internal profiles as a function of the radius and the Lagrangian mass coordinate inside 9 M models halfway through the MS (Xc = 0.35) for different initial rotations: υini/υcrit = 0.2 (orange), 0.4 (red) (Murphy et al. 2021a), and 0.7 (green). The grey-shaded zone is the convective core of the moderately rotating model. Left panel: radial component of the meridional circulation velocity, Ur. Middle panel: angular velocity, Ω. Right panel: the solid curve shows the diffusion coefficient due to shear turbulence, Dshear. The dotted curve shows the effective diffusion coefficient, Deff (y-axis in logarithmic scale and in units of cm2 s−1). For clarity, only the curve for Deff corresponding to υini = 0.7 υcrit is shown. In the rest of the radiative zone, Deff is in general much smaller than Dshear.
