Fig. 29.

Upper panel: dipole (ℓ = 1) average of the computed period spacings, , assessed in a range of periods that includes the periods observed in NGC 6905, shown as solid (dashed) curves corresponding to stages before (after) the maximum Teff for different stellar masses. The location of NGC 6905 when we use the effective temperature derived by Ciardullo & Bond (1996), Teff = 141 000 ± 10 000 K, and the period spacing Δ Π = 11.9693 ± 0.0988 s derived in Sect. 3.3 and assumed to be associated with ℓ = 1 modes, is highlighted with a magenta circle. The stellar mass derived from linear extrapolation is M⋆ ∼ 0.818 M⊙ if the star is before the maximum Teff, and it is M⋆ ∼ 0.861 M⊙ if the star is after the maximum Teff. Lower panel: same as in upper panel, but for the case in which the period spacing is assumed to be associated with ℓ = 2 modes (Δ Π = 11.9693 ± 0.0988 s). In this case, the stellar mass is M⋆ = 0.596 ± 0.09 M⊙ and M⋆ = 0.590 ± 0.007 M⊙ if the star is before or after the evolutionary knee, respectively.
