Fig. 5


[X/Fe] vs. [Fe/H] for the α-elements (Mg, Si, Ca, and Ti), and the Fe-peak elements (Cr, Mn, Co, and Ni): open diamonds represent the thin-disk data (González Hernández et al. 2010, 2013); red diamonds are our stars compatible to within 1 rms with the Fe abundance but not for all elements; blue squares are the candidates selected to become members of the Ursa Major MG. Inverted green triangles show incompatible stars. The reference star, HD 115043, known to be a member of the Ursa Major nucleus, is marked with an orange circle. Also, representative error bars are displayed in each graph.

This figure is made of several images, please see below:
