1. Introduction

One of the most challenging problems in the field of cosmology is to understand the accelerated expansion of the late-time Universe (Riess et al. 1998). The Λ cold dark matter (ΛCDM) model is the most accepted explanation for this expansion and is reached by modifying general relativity (GR) through adding a cosmological constant, dark energy, to the energy-momentum tensor.

An alternative to adding a dark energy component to GR is to modify gravity, by altering the Einstein-Hilbert Lagrangian, which the Einstein tensor is derived from. Many of these modified gravity theories exist (Brans & Dicke 1961; de Felice & Tsujikawa 2010; Sotiriou 2006; Clifton et al. 2012; Boehmer & Mota 2008) and several have previously been studied (Brax et al. 2013; Barreira et al. 2013; Li et al. 2011, 2012; Davis et al. 2012; Barrow & Mota 2003; Mota et al. 2008; Puchwein et al. 2013; Winther et al. 2012). These theories are often implemented by introducing a scalar field to the Einstein tensor, which couples to the matter component of the Universe. This scalar field gives rise to a fifth force, an additional gravitational force, which is negligible at solar system scales and below, according to laboratory experiments (Hoyle et al. 2004; Dimopoulos et al. 2007) and solar system gravity probes (Bertotti et al. 2003; Will 2014).

If we assume that this fifth force acts on larger scales than the solar system, then some mechanism is needed to negate the fifth force on solar system scales. One way to achieve this is to utilise one of the screening mechanisms found in the literature (Khoury 2010; Brax et al. 2012; Hinterbichler & Khoury 2010; Khoury & Weltman 2004; Vainshtein 1972; Koivisto et al. 2012) that screens the fifth force based on a series of different criteria. In this paper, we study the symmetron model (Hinterbichler & Khoury 2010), which screens the fifth force in regions of high density.

With these modified gravity theories comes the challenge of finding methods to test them against observations (Terukina et al. 2014; Wilcox et al. 2015). Theorists in the past have mainly used predictions from models and simulations that only include dark matter due to the simplistic nature of dark matter, when constraining modified gravity theories. Use of models that only include dark matter can be justified by the matter composition of the Universe, which is 84.4% dark matter and 15.6% baryonic matter, according to the Planck Collaboration XIII (2015). However, astronomers observe the electromagnetic spectrum emitted from the baryonic components of the Universe, leaving the community with a disconnect between theories and observables.

Introducing the concept of a bias between the dark matter and baryonic components is one way to rectify this disconnect. The bias assumes that the behaviour of the two components are the same, but that the strength or amplitude of the behaviour might be different. The community generally assumes that the bias of the standard model ΛCDM is equal to one, which justifies studying the Universe and comparing the observations to simulations that only include dark matter. However, if the bias is not unity researchers might greatly underestimate or overestimate their findings.

The bias can deviate from unity even in ΛCDM because of baryonic effects other than a non-universal coupling, such as AGN-feedback (van Daalen et al. 2011) or the hydrodynamic effect observed in the Bullet cluster (Tucker et al. 1998; Clowe et al. 2006). This means that these baryonic processes need to be comprehensively understood before the bias can be used to test a non-universal coupling. Recent work (Schaller et al. 2015) has made progress in studying the differences between galaxies (gas) and dark matter in the ΛCDM model.

In our previous work (Hammami et al. 2015), we studied the effects of adding a hydrodynamic gas to an existing N-body code with the symmetron model implemented (Llinares et al. 2014) with the assumption that the scalar field would couple to the gas and the dark matter to a universal coupling. There are, however, no justifications for assuming that the dark matter and gas have the same coupling to the scalar field. In fact, several known particles, such as neutrinos and baryons, do not interact in the same manner with electromagnetic forces, and it therefore stands to reason that it is worthwhile to study the effects of non-universal coupling between the scalar field and matter components.

In this paper, we study density and temperature profiles and power spectra of dark matter and gas for symmetron models with different values for the coupling strength. The paper starts with an introduction to the symmetron model in Sect. 2, followed by a very brief section on the simulation parameters in Sect. 3, presenting and discussing the power spectra in Sect. 4 and the density and temperature profiles in Sect. 5, and finishes with conclusions in Sect. 6.

We work with some models that are extremely coupled to the scalar field to push any signatures of the non-universal coupling to their limits and possibly reveal signatures that would not immediately be clear from more sensible scalar field couplings.

2. The symmetron model

Introduced by Hinterbichler & Khoury (2010) the symmetron model is a scalar theory of gravity using a symmetric potential, where the action (Sotiriou 2006; Fujii & Maeda 2003) is (1)where ψ is the scalar field¹, R is the Ricci scalar, M_pl is the Planck mass, and g = | g_μν | is the determinant of the metric tensor in the Einstein frame, which can be converted to the Jordan frame by (2)The conformal factor satisfies A ≃ 1 for the symmetron model and we use this approximation throughout. For more on these frames and the transformations between them and possible errors, see Faraoni et al. (1999) and Brown & Hammami (2012).

To preserve the behaviour of gravity, as described by GR, the symmetron model utilises a screening mechanism that triggers based on a set density value ρ_assb at the solar system scale(a region of high density). In regions of low density, the symmetron would produce a modification of order one on the gravity. To accomplish this, the potential in the action above is defined to be symmetric, as in (3)where ψ is the scalar field, μ is a mass scale, and λ a dimensionless parameter. Likewise, the coupling factor is also symmetric,

with M being another mass scale.

To find the stress energy tensor for the symmetron model, we vary the action with respect to the metric (4)where P and ρ are the pressure and density, respectively.

The scalar field component of the stress energy tensor is not covariantly conserved, i.e.

while the total stress energy tensor is (Misner et al. 1973) (5)The equation of motion for the scalar field is found by varying the action again, this time with respect to the scalar field, (6)where T^(m) is the trace of the stress energy tensor .

The right side of Eq. (6) can be recognised as an effective potential, and, using Eq. (4), we write(7)With this potential, the scalar field goes to zero in regions of high density, ρ_m ≫ M²μ², while in regions of low density it reaches a minimum of . The addition to gravity, the fifth force scales with the value of the scalar field, and we see from this that it is suppressed in regions of high density.

We redefine the free parameters μ, M, and λ to β, λ₀, and a_SSB to a set of parameters that are more physical intuitive as described in Winther et al. (2012), where H₀ is the Hubble factor at present day (z = 0) and Ω_m is the matter density parameter.

The relative strength of the fifth force to the gravitational force is represented by β, the moment of breaking symmetry is represented by the expansion factor a_SSB = (Ω_m0ρ_c0/ρ_SSB)^1/3, and the range of the fifth force is represented by λ₀ in units of Mpc/h.

A dimensionless scalar field χ is defined as (11)with an equation of motion in the quasi-static limit (Llinares et al. 2014)² as (12)where is the mean density.

The equation of motion for the position x of the dark matter N-Body particles has been derived from Eq. (1) in Llinares et al. (2014) and takes the form (13)where Φ is the Newtonian gravitational potential.

The fluid equations for the symmetron model is a special case of the general fluid equations for a scalar-tensor theory. Via the action Eq. (1), stress-energy tensor Eq. (4), conservation law Eq. (5), and working in the Newtonian Gauge, (14)the fluid equations are derived, where is the Hubble factor, v is the velocity of the fluid, and E is the internal energy of the fluid.

To remove explicit dependencies on a and H from the equations above, we use a variation of the super-comoving coordinates from Martel & Shapiro (1998), represented by a tilde, all equations from this point on are in comoving coordinates.

By excluding terms of second order and assuming static pressure, the field Eqs. (15)–(17) transform to³With this approach, the symmetron model version of the fifth force is (23)For more on the symmetron model, see Hinterbichler & Khoury (2010).

3. Parameters

The coupling factor defined above is split into two new coupling factors, (24)which replace the coupling factor in the dark matter and fluid equations, respectively.

In order to study the effect, we choose couplings of varying orders of magnitude⁴ and our chosen configurations are shown in Table 1.

The simulations were run using 1024 cores, 256³ dark matter particles, with a box width of 256 Mpc/h, and six levels of refinements. The background cosmology is a standard ΛCDM background, with h = 0.65, Ω_Λ = 0.65, Ω_m = 0.35, and Ω_b = 0.05. The chosen symmetron model has a_SSB = 0.33 and λ₀ = 1 Mpc/h.

Because of the use of extremely coupled models, we ran a set of convergence tests to verify that the errors induced by extreme coupling were not too extensive. The tests showed that the code handled the extreme models well for the most part, however, for the power spectra there were slight errors at the smallest scales k> 4 Mpc/h and for the halo profiles at radius above R> 3R_200c. These errors were not significantly large, but results from the extreme models should be taken with a grain of salt in these regions.

All results in the following sections only focus on the present day epoch, which corresponds to z = 0.

4. Power spectra

With the use of the open POWMES code (Colombi & Novikov 2011), we compute the power spectra for both dark matter and gas. To calculate the gas power spectrum, we treat each cell as a particle with a mass defined as (25)where ρ and V_cell is the gas density and volume of the cell, respectively.

In Fig. 1 we present the power spectra for all our models and the deviations of these power spectra from ΛCDM for both the dark matter and gas components.

At the large scale range of the power spectra, k< 1 Mpc/h, the extreme dark matter models (DM10G10 and DM10G1) show stronger effects of the scalar field in dark matter power spectra than in gas power spectra. This is because the power spectra of a component are most sensitive to changes to that component. The smaller differences between the various models in the gas spectra are due to the simulation, which is strongly dominated by dark matter compared to the gas, so that the extreme gas model (DM1G10) is suppressed by dark matter. This also accounts for that fact that DM1G10 is not clearly distinguishable in dark matter spectra.

On smaller scales, k> 1 Mpc/h, the variations between the models are most noticeable in gas spectra, as is to be expected as the baryonic processes are strong at the smaller scales. Overall, we see a clear example that big deviations in dark matter power spectra do not mean big deviations in the gas power spectra.

4.1. Power spectra deviations

The main difference between DM10G10 and DM10G1 in dark matter power spectra deviations is that the latter is shifted slightly towards smaller scales and has a slightly smaller amplitude. The addition of the extremely coupled gas increases clustering on larger scales, while decreasing clustering on smaller scales.

The gas spectra deviations show that the spectra is greatly influenced by both the dark matter and gas. This is evident because DM10G10 has the strongest deviations, while the second and third largest deviations come from DM1G10 and DM10G1, respectively. The effect of dark matter on the gas spectra is much stronger than the effect of the gas on the dark matter spectra, a consequence of the dominance of dark matter.

DM1G1 and DM1G0.1 show that a minimally coupled gas reduces the amplitude of the power spectra in the range k ∈ [ 0.1,3), with the largest difference from DM1G1 at k ~ 1 Mpc/h. However, at the smallest scales these models end up with the same amplitude, indicating that at this point the gas coupling is irrelevant for dark matter spectra.

The models DM0.1G0.1 and DM0.1G1 reveal that the gas has an impact on dark matter spectra, although not significantly, and the same very minor effect was also evident when comparing DM1G10 to DM10G10 and DM10G1.

The gas spectra is more susceptible to changes to dark matter coupling, however, it is still most dependent on gas coupling, as demonstrated by the increasing amplitude as DM10G1 < DM1G10 < DM10G10. All the models with an extreme coupling have very low amplitude at small scales, and at the very smallest scales, they all end up at more or less the same value regardless of whether the coupling is universal or not. The same effect is seen when comparing DM1G1 to DM0.1G1.

4.2. Bias

The bias is defined as the ratio between the gas power spectrum and the dark matter power spectrum, (26)and is shown in Fig. 2. In the very large scale region, k< 0.3 Mpc/h, the DM1G10 model has a bias that sky rockets to values larger than the ΛCDM bias. On the other hand, DM10G1 exhibits the exact opposite behaviour with a lower bias that rapidly decreases. DM10G10 displays behaviour intermediate between these two models, but much closer to DM10G1.

The remaining large scales, 0.3 <k< 1 Mpc/h, prove a turning point for all models. DM1G10 stops its growing bias and starts to decrease, and DM10G1 slows its rapid decrease and seems to stabilise at a constant value with b_ψ = 0.25b_ΛCDM. Similarly, DM10G10 starts to level out, however, as DM1G10 starts to decrease DM10G10 does as well.

On smaller scales, the biases of these models start to diminish and eventually all are at lower values than the ΛCDM bias. Bias deviations in the smaller, non-linear scales are strongly correlated with gas coupling, while also dependent on the coupling to the dark matter. DM10G10 reveals that the components compound the effect of the deviations so that the DM10G10 deviation is larger than the sum of the DM10G1 and DM1G10 deviations. DM0.1G0.1 exhibits almost no deviations from ΛCDM, as is to be expected. In the final models, the behaviour of the bias deviations act in extremely different manners depending on what components are strongly coupled.

For DM1G0.1, we see that the bias deviations plummet at large, non-linear scales until they reach more or less constant values that are decreasing slightly from k ~ 1 Mpc/h and out. The DM0.1G1 model exhibits the exact opposite behaviour at large, non-linear scales. DM1G1 displays a behaviour intermediate between the other two models at the large scales, and then eventually starts to decrease to much less than the sum of the respective deviations. The power spectrum bias at larger scales shows that models with a universal coupling have fewer deviations from the ΛCDM model than the models with a non-universal coupling.

For observational astronomers the implications of this behaviour is that if the bias deviations are greater than unity, b_ψ>b_ΛCDM, then researchers who infer dark matter properties from baryonic physics features will make predictions with values of the power spectrum that are too high. The opposite is true if the bias deviations are less than unity, b_ψ<b_ΛCDM.

5. Halo profiles

In this section, we present density and temperature profiles for multiple halos identified by using the Rockstar code developed by Behroozi et al. (2013). We study massive halos with mass in the range [1 × 10¹⁴h^-1M_⊙, 5 × 10¹⁴h^-1M_⊙), the high mass of these halos should ensure that the screening mechanism are triggered in dense regions.

In previous works (Hammami et al. 2015; Llinares et al. 2014), the halos that had not yet reached a relaxed state were filtered out following the methods described in Neto et al. (2007) and Shaw et al. (2006). The method used relations between the kinetic and potential energy and surface pressure to determine if a halo was relaxed or not. Gronke et al. (2014) refined the method to take the effects of modified gravity in the virialisation state of the halos into account. However, if we filtered the non-relaxed halos, this would eliminate too many halos in the extreme models and leave almost no remaining halos. For this reason, we do not filter the non-relaxed halos from the relaxed halos.

The halo profiles are calculated by sweeping over all the cells in the simulations, binning dark matter particles and baryonic gas properties in annular bins for each halo⁵, then averaging over all halos. The profiles range from 10% of the virialisation radius, r = 0.1 R_200c, to ten times the virialisation radius, r = 10 R_200c. This range was chosen to properly catch all behaviours of the fifth force on the dark matter and gas halos, while also avoiding the inner regions of the halos where the resolution of our simulations is low. All profiles are calculated at the present epoch z = 0.

5.1. Density profiles

The density halo properties are presented in Fig. 3. An extreme coupling in the dark matter strongly affects both dark matter and gas density profiles. For dark matter profiles, the effect is mostly contained at the exterior of dark matter halos, while the gas profiles show signs of extreme dark matter coupling in all parts of the halo and outside. The diminished clustering at the inner regions of the halos can be explained with an environmental effect from the dark matter on the gas.

The dark matter clusters faster than the gas because of its collisionless nature, in which the gas is prevented from collapsing, due to the pressure, and the dark matter clusters unhindered. This means that the dark matter reaches higher densities at a faster rate than the gas, and from the description of the screening mechanism, we know that the screening is triggered by a combined density, dark matter plus gas, threshold, resulting in the dark matter triggering the screening mechanism before the scalar field has had a chance to work on the gas component as much as on the dark matter.

An extremely coupled gas has a minor, however, not negligible effect on the dark matter profiles, while it has a huge impact on the gas profiles. This is expected as there is much more dark matter than gas, resulting in the effect of the gas not being as strong. Also, DM10G10 is the model with the biggest effect on the gas profiles, while the dark matter profiles seem to prefer DM10G1.

5.2. Density profiles deviations

The deviations from ΛCDM for the halos are found in the lower two rows of Fig. 3. The deviations confirm the conclusions from the total density profiles, and also reveal previously unseen effects. All models without extremely coupled dark matter make dark matter halos cluster less at the inner regions than in those two cases (DM10G10 and DM10G1). The exact opposite occurs in the gas power spectra, where all extremely coupled models (the two previously mentioned and DM1G10) cluster less than the other models. This is due to baryonic physics preventing the gas from collapsing as far inwards as the dark matter, and then the gravitational contribution from the gas on the dark matter also prevents the dark matter from clustering.

The peak of deviations does not occur at the same radius for all the models. For DM1G10, the peak in deviations is closer to the halo centre, while for DM10G10 and DM10G1 the deviations peak further out. This effect is due to the extreme coupling in the gas. The extreme coupling allows the scalar field to affect the gas component to such an extent that it collapses further inwards before the environmental effect of the combined density triggers the screening mechanism.

The bottom row reveals that DM1G10 has a strong effect on dark matter halos throughout the density profiles with higher peak deviation than DM1G1. The gas profiles are under-dense at the inner regions of the halos in the cases where the dark matter is normally (or extremely) coupled to the scalar field. In the cases where the dark matter is minimally coupled, the profiles approach ΛCDM at the centre of the halos. This behaviour further asserts our conclusions about the environmental effect.

To study how deviations from ΛCDM differ in dark matter and gas cases, we introduce the deviation bias δ^DM, defined as the relative difference between the deviations (27)where ρ_ΛGas is the gas ΛCDM density and ρ_ΛCDM is the DM ΛCDM density.

The DM10G1 model represents a model that has an enormous deviation from ΛCDM in the dark matter component of Δ_DM ~ 8.5 at R ~ 4R_200c, and a much smaller deviation of Δ_Gas ~ 2.5 in the gas component, giving a deviation bias of δ^DM ≈ 2.4. The same effect, but now with enourmous deviations in the gas component, is present in DM1G10 where the deviations from ΛCDM are Δ_Gas ~ 1.5 for the gas and Δ_DM ~ 0.5 for the dark matter, giving a deviation ratio of .

5.2.1. Baryon fraction profiles

One of our aims is to find a method of distinguishing between models that have universal coupling and models with non-universal coupling. For this purpose, we use the baryon fraction (Kravtsov et al. 2005), (28)and present the baryon fraction profiles in Fig. 4.

The baryon fraction shows that all the models have the same behaviour as ΛCDM, except the three models DM10G10, DM1G10, and DM10G1. DM10G10 converges with the ΛCDM baryon fraction earlier than DM1G10 and DM10G1, however, in general this model has a higher deviation at the inner region. In fact, the models with a universal coupling seem to deviate less from ΛCDM than the models with a non-universal coupling.

This is the same behaviour displayed by the power spectrum bias at larger scales, and allows us to conclude that significant deviations in the baryon fraction from the ΛCDM model throughout the halos might be an indication of a non-universal coupling.

5.3. Temperature

The temperature is a very interesting component to study due to its close relation observables (Wilcox et al. 2015; Terukina et al. 2014). The temperature is not an output of our code and needs to be reconstructed using the ideal gas law, (29)where p is the thermal pressure, is the specific gas constant, is the mean mass of the gas, m_H is the hydrogen mass, and ρ is the gas density. The temperature profiles are made and analysed in the exact same manner as the density profiles.

5.3.1. Total temperature profiles

The temperature profiles are presented in Fig. 5. The temperature is a product of the baryonic processes and is most sensitive to strong coupling between the gas and scalar field (Hammami et al. 2015).

The stronger the coupling to the scalar field is, the higher the temperature in the halos is. The slope of the profiles outside of the halo, as the temperature starts dropping, is shallower for DM10G10, DM1G10, and DM10G1 than in the other models. DM10G10 gives an even higher temperature than DM1G10, indicating that the dark matter plays a vital role in the temperature of baryonic halos. This is also evident from DM10G1, which has a higher temperature than the less extreme cases.

5.3.2. Temperature profiles deviations

The temperature deviations from the ΛCDM temperature are found in the bottom two rows of Fig. 5. DM0.1G1 and DM0.1G0.1 are two similar models in which one has universal coupling and the other does not. These two models display no signatures that can be interpreted as a trait of non-universal coupling. DM1G0.1 and DM0.1G0.1, on the other hand, display an increase in temperature outside of the virialisation radius.

Both of these effects come from the fact that these halos are so massive that they are most likely screened from the scalar field. The difference between DM1G0.1 and DM0.1G0.1 is that the regions outside of the halos are non-screened, and the stronger coupling to dark matter allows DM1G0.1 to be influenced by the scalar field to a larger extent than DM0.1G0.1.

6. Conclusions

We investigate scalar-tensor theories of gravity, which present a non-universal coupling. That is, baryons and dark matter are coupled with the scalar degree of freedom with different coupling strengths. The models we investigate utilise a screening mechanism to suppress the deviations from GR at small (solar system) and large cosmological scales: the symmetron screening mechanism, specifically.

As a result of the screening mechanism, the strongest signatures in these models are expected to occur at the non-linear regime of structure formation. Therefore, in order to unveil the imprints of these theories at astrophysical scales, we ran several hydrodynamic cosmological N-body simulations. We compared models with and without a universal coupling to the symmetron scalar field, and showed that several astrophysical observables (density profiles, temperature profiles and power spectra) show significant differences between the dark matter and gas components when the coupling is non-universal.

The deviations from ΛCDM are typically larger in the gas than in the dark matter near the centre of the halo. The opposite holds true at larger radii, where the dark matter deviates more strongly from ΛCDM. However, this is not the case for models in which coupling of the gas is significantly stronger than that of the dark matter.

For power spectra, dark matter deviations are larger than that of the gas in models with universal coupling or in models in which dark matter coupling is stronger than gas coupling.

Our attempt to find signatures in density profiles and power spectra, which would reveal whether coupling to the scalar field is universal or not, revealed one signature: in the cases of universal coupling, the deviations in the baryon fraction and bias from ΛCDM are smaller than in the cases of non-universal couplings throughout the halos. This is expected, since GR is a universally coupled theory. If observers find the baryon fraction or power spectrum bias to deviate from the calculated ΛCDM bias, then this might very well be a sign of a non-universal coupling, and therefore a breaking of the equivalence principle.

Separating the dark matter and gas will prove to be a challenge for observers intending to compare their results with theories, since the dark matter is not a direct observable, while the gas is observable. To work around this, we propose to use the baryon fraction as presented in this paper. To measure this baryon fraction, first we suggest the constructing of the total density profile, ρ_Tot = ρ_DM + ρ_gas, using rotational velocity profiles of individual galaxies to measure the dynamical mass, and then constructing the gas density profile ρ_gas, using X-ray surface brightness and X-ray temperature profiles.

A caveat with the above mentioned method is that the calculated dynamical mass is dependent on the particular gravity model used. An alternative option is to calculate the lensing mass using gravitational lenses as the path of light that is independent for all conformal scalar gravity theories (Bekenstein & Sanders 1994; Carroll 2004) and generally ideal for studying modified gravity theories (Zhao et al. 2011).

The above method for detecting non-universal couplings may not be possible with the current state of observational and theoretical limits. The deviations we found from ΛCDM are all quite small, when we exclude the extreme models, and also contain large uncertainties depending on the modelling of feedback physics.

Furthermore the observational baryon census of galaxies contains significant errors and may still be incomplete, i.e. the halo missing baryon problem (Werk et al. 2014), while the baryon consensus in galaxy clusters is less challenging as the majority of the gas is hot enough to be visible in X-rays. The above method is therefore more likely, yet still very challenging, to work in galaxy structures than in galaxies.

If one takes seriously the possibility of matter components with a non-universal coupling to a gravity scalar degree of freedom, then our work shows the bias will be greatly affected. Therefore, attempts to rule out or constrain modified gravity theories by comparing dark matter predictions to the observed quantities based on baryonic properties may be misleading, and one must consider the possibility of a non-universal coupling that might skew the conclusions and dark matter properties that are inferred from baryons.

---
