1. Introduction

Stars form through the gravitational collapse of dense cores within molecular clouds. Because of the angular momentum conservation during the collapse, most young stars are initially surrounded by a disc consisting of gas and dust. These protoplanetary discs are usually treated as unperturbed by their surroundings. However, as most stars do not form in isolation but in star cluster environments (Lada & Lada 2003; Porras et al. 2003) discs tend to be affected by external processes like photoevaporation from massive stars (e.g. Johnstone et al. 1998; Scally & Clarke 2001) or gravitational interactions with other cluster members (e.g. Moeckel & Bally 2006; Craig & Krumholz 2013). In this paper we only concentrate on the effects of the latter.

The consequences of gravitational interactions, in the following also called encounters, on disc parameters, like the disc’s mass, angular momentum, and energy, have been intensively investigated analytically and numerically in the past (e.g. Clarke & Pringle 1993; Ostriker 1994; Heller 1995; Hall et al. 1996; Kobayashi & Ida 2001; Pfalzner 2003; Olczak et al. 2006; Pfalzner & Olczak 2007; Lestrade et al. 2011; Steinhausen et al. 2012). In contrast, the encounter-induced alteration of the size of a protoplanetary disc has not been investigated so thoroughly. The reason is that only for approximately a few hundred objects, have disc sizes been determined so far (for an overview see e.g. Williams & Cieza 2011, and references therein). Deriving correlations between the disc size and the stellar environment seemed impossible to achieve. However, with the advent of ALMA in the near future the sample size is likely to increase considerably and the influence of the environment on the disc size becomes testable.

In the past, theoretical investigations have shown that encounters mainly affect the outer disc material. Clarke & Pringle (1993) investigated the effects of parabolic encounters of equal-mass stars with a periastron distance of 1.25 times the initial radius of the disc, r_init, and varying inclinations. They found that in the most destructive encounter (prograde, coplanar), disc material down to ≈0.5 times the periastron distance, r_peri, becomes unbound. By varying the disc-size to periastron-distance ratio, Hall et al. (1996) found that in parabolic, prograde, and coplanar encounters of equal mass stars the disc inside 0.3 r_peri is almost unperturbed. Kobayashi & Ida (2001) focused on the encounter-induced increase of eccentricity and inclination of the disc material and the size of the largely unperturbed inner part of the disc. They found that many particles become unbound outside of ≈1/3 of periastron distance after a prograde encounter of equal-mass stars on a parabolic orbit.

Almost all previous investigations focused on a small parameter space, which was mostly restricted to encounters between equal-mass stars. Nevertheless, the above results are often generalised as encounters truncating discs to 1/2–1/3 of the periastron distance (e.g. Brasser et al. 2006; Adams et al. 2006; Adams 2010; Jiménez-Torres et al. 2011; Malmberg et al. 2011; Pfalzner 2013). There the dependence of the disc truncation on the mass of the perturbing star and other geometrical properties of the perturber orbit are disregarded.

One typical context where the disc size after an encounter plays an important role is in the formation of the solar system. The size of the solar system, with a density drop at ≈30 AU, is attributed to an encounter of the young solar system with another star at a periastron distance of ≈100 AU. This distance is used to determine the typical cluster environment in which the solar system might have developed.

In addition, the disc size is a crucial parameter for investigating the typical types of planetary systems in a given cluster environment. Therefore, de Juan Ovelar et al. (2012) tried to estimate the sizes of discs after encounters considering both the periastron distance and the mass ratio of the stars. They suggested two different approaches. The first is based on the assumption that disc material is removed in an encounter at least to the point of gravitational force equilibrium between the stars at the time of periastron passage. In the other approach they suggested a transformation of the results for the disc-mass loss in encounters by Olczak et al. (2006) into a reduction of the disc size. Both approaches assume that disc size change and the removal of disc material are strongly correlated.

However, Hall (1997) already showed that during an encounter disc material can be moved inward as a result of loss of angular momentum. That way, the disc size can be reduced even when no mass is lost. More recently, it has been demonstrated that a 3–5% loss of disc angular momentum is common in star clusters similar to the Orion nebula cluster (ONC) and this holds not only for the central high-density regions, but also at the outskirts of clusters (Pfalzner & Olczak 2007). Therefore, it is very likely, that changes of the disc size are a more common effect in clusters than the removal of disc material.

Using an extended data base of star-disc encounters we show here that approaches based on mass loss are not really suitable for determining the resulting disc size. After a short description of our numerical method in Sect. 2, a definition of disc size is given, which is comparable to observational size determinations. In Sect. 3 we present the numerical results as well as a simple fit formula, which are discussed in Sect. 4. We compare our results to previous work in Sect. 5 and give a brief summary and conclusion in Sect. 6.

2. Method

2.1. Numerical method

We performed numerical simulations to investigate the effect of stellar encounters on the size of protoplanetary discs. The mass of a protoplanetary disc is usually much lower than the mass of its host star (on average M_disc ≈ 0.01M_star, e.g. Andrews et al. 2013). Because of the resulting low density, especially in the outer parts of the disc that are relevant to our case, and also the relatively low temperature, the viscous timescale is long enough that the discs survive at least some million years (e.g. Haisch et al. 2001). Since this is typically much longer than the timescale of encounters, we can mostly neglect hydrodynamical effects as well as self-gravity within the disc. The exception are very close penetrating encounters, which we exclude anyway (see below). We also disregard photoevaporation from the stars, as well as radiation transport within the disc. Thus, we only consider gravitational forces from and onto the stars.

For pure gravitational numerical investigations, particle based simulations are most suitable. Since we investigate low-mass discs and neglect the self-gravity, we can even go one step further and use massless tracer particles. This has the advantage that the particle distribution can be chosen independently from the mass distribution within the disc. To obtain a higher spatial resolution at the outskirt of the disc, we use a constant particle surface density (Σ(r) = const.). The particle masses are associated with the tracer particles in the diagnostic step, also making it possible to investigate the effect of different initial mass distributions with one single simulation (Steinhausen et al. 2012).

In dimensionless units, our discs have an initial outer radius of r_init = 1 around a star of mass M₁ = 1. Because the test particles are only affected by gravitational forces, they initially follow Keplerian orbits around their host stars. We assume that all particles are initially on circular orbits (eccentricity e = 0).

Even though hydrodynamical forces are neglected, we set up our discs with a certain thickness for consistency with previous work (e.g. Pfalzner et al. 2005b; Olczak et al. 2006; Pfalzner & Olczak 2007; Steinhausen et al. 2012). Thus, the initial particle distribution in the disc is given by (1)where H(r) = 0.05 r is the vertical half-thickness of the disc (see also Pringle 1981). Since this results in inclinations i ≲ 5° for nearly all particles, the disc can still be regarded as thin.

A standard method when investigating star-disc encounters is to exclude an inner disc region to avoid unnecessary small time steps. Here, this region extends to r_hole = 0.1 r_init. Therefore, encounters resulting in very small final discs with r_final ≲ 0.2 r_init are excluded from further diagnostics because they might be influenced by the missing disc mass within the hole. Particles which approach one of the stars closer than 0.1 r_hole are treated as accreted. As a compromise between spatial resolution and computation time needed for the parameter study, our discs are modelled with 10 000 particles (see also Kobayashi & Ida 2001; Pfalzner 2003; Steinhausen et al. 2012).

Simulations were performed for varying perturber-mass to host-mass ratios m₁₂ = M₂/M₁ and periastron-distances r_peri. The trajectories of the particles were integrated by using a Runge-Kutta Cash-Karp scheme with adaptive time step size.

As parameter space for our study, we have chosen the mass-ratio and periastron-distance range typical for young dense clusters in the solar neighbourhood. A prime example is the ONC, for which the effect of encounters on the protoplanetary discs was already investigated by Pfalzner & Olczak (2007). The mass range in the ONC is given by the mass ratio of the stars at helium burning limit, M ≈ 0.08 M_⊙, and the most massive system θ¹ Ori C with M ≈ 40 M_⊙. Previous studies (e.g. Pfalzner et al. 2005b; Steinhausen et al. 2012) have shown that encounters with very low mass ratios (m₁₂ ≲ 0.1) only have an effect on the discs for very small periastron distance (r_peri ≲ r_init). Additionally, hydrodynamical effects may play a role in these encounters, and the mass of the disc is not much smaller than the mass of the perturber, which would make the application of the method used here questionable. Therefore, we treat only the range m₁₂ = 0.3–500.

We restrict the periastron distances to the range where the discs are perturbed significantly but not fully destroyed. Cases where the resulting disc sizes are ≲0.2 r_init are excluded from further diagnostics, as they might be influenced by the inner cut-off of the initial discs. For an equal mass perturber the distances range, for example, from 0.7 r_init to 7 r_init. The actual periastron distances depend on the mass ratio and can be found in Table A.1.

In this work, we only consider prograde, coplanar, and parabolic (e = 1) encounters because they are the most destructive ones. Therefore, our resulting disc sizes represent the lower limits for the disc sizes after encounters on inclined and/or hyperbolic orbits (e.g. Clarke & Pringle 1993; Pfalzner et al. 2005b). For this parameter space several hundreds of simulations were performed.

At the onset of our simulations the perturber is placed at a distance d_init, where its gravitational force onto the closest disc particle is only 1% relative to the force from the disc-hosting star. This condition is satisfied, when (2)We end our simulations, when the distance between perturber and disc-hosting star is again at least d_init or a particle at r_init has fulfilled at least 1.5 orbits around the host star after periastron passage.

We investigate here the simplified case of only one star being surrounded by a disc to limit computational costs. This approach is valid, as long as only small fractions of the disc material are captured by the perturbing star (Pfalzner et al. 2005a). For a realistic modelling of close disc-disc encounters hydrodynamical effects would also have to be considered.

2.2. Size determination

During the diagnostic step masses are attributed to the tracer particles so that the initial disc matches (3)where ρ₀ is the mass density in the equatorial plane at the inner rim (r = 0.1r_disc) and p the parameter for the slope of the mass density distribution (see also Steinhausen et al. 2012).

A problem in the determination of the size of a protoplanetary disc after an encounter is that there is no general definition of a disc size at hand. Taking observations as a guide is only of limited help, as even in the unperturbed case there are several methods used for disc size determination. One common method is to fit the observed SED to disc models with radial density and temperature profiles which mostly follow a truncated power law (e.g. Andrews & Williams 2007). The radius of truncation of the density is then taken as size. In the case of resolved images, the size often corresponds to the radius where the luminosity falls below a certain limit (e.g. Vicente & Alves 2005; O’dell 1998). This drop in luminosity is equivalent to a drop in the disc’s surface density. Since both methods rely on a drop in the disc’s volume or surface density we decided to mimic these methods by defining our disc size as the point of strongest contrast in the surface density.

In the determination of the disc’s surface density after an encounter from the simulations, a problem arises from the particles on highly eccentric orbits. While in the viscosity-free case the semi-major axis a and eccentricity e of the particles do not change further after the end of the encounter, their radial distances to the disc-hosting star do change with time. Therefore, global quantities determined from a snapshot of the particle distribution at a certain time would not necessarily be representative.

To avoid this problem and for better comparison of our disc size values with observational data, we use a temporally averaged surface density distribution for the disc size determination. This can be obtained directly from the data of the last time step by applying the radial probability functions of the orbits defined by a and e. The sum of the radial probability functions of all particles yields the time-averaged particle surface density distribution. When weighting the radial probability functions in this sum with the previously associated particle masses according to Eq. (3)one obtains the mass surface density distribution. For our diagnostics we used particle masses according to an initially ∝ r^-1 (p = 1) mass surface density distribution.

The disc size is then determined as the point of strongest mass surface density gradient. Here, the steep inner part of the initial r^-1 mass distribution is excluded. Because of the statistical nature of our data, the surface density distributions have to be smoothed before the size determination algorithm is applied.

Figure 1a shows a disc perturbed by a m₁₂ = 1 perturber on a parabolic orbit with r_peri = 2 r_init. Figure 1b shows the corresponding initial (thin) and final (thick) time averaged surface density distributions for an initially constant particle (solid) and ∝ r^-1 mass (dashed) distribution. The vertical line shows the final disc size as obtained with our disc size definition. It can be seen, that the vertical line matches the points of steepest gradient in both final density distributions.

To determine the statistical deviations of our disc sizes we performed ≈100 simulations of one encounter with different random seeds for the initial particle distribution. Because smaller radial bins for the surface density computation require a longer smoothing length (as mentioned above) and vice versa, we found a bin width of 0.01 r_init to be a good compromise between resolution and smoothing. The statistical deviations are then also of the order of 0.01 r_init.

3. Results

Figure 2 gives an overview of the results of our parameter study. (The actual values can also be found in Table A.1.) For clarity and better comparability to observations we present the numerical results in absolute values, assuming an initial disc size of 100 AU (black squares). For comparison, the diamonds represent some exemplary results for discs with an initial size of 200 AU. As long as an encounter changes the sizes of the discs significantly, the resulting sizes are approximately the same for both initial sizes. Since the discs do not become bigger¹ in our simulations, the final sizes are limited by the initial disc sizes. Therefore, the final disc sizes of the initially 100 AU and 200 AU discs have to deviate after encounters where the final size of the 200 AU disc is ≳100 AU. For example, an encounter with a mass ratio of m₁₂ = 0.3 and a periastron distance of 500 AU reduces the size of a 200 AU disc to ≈ 150 AU while the 100 AU disc is unchanged.

There exists a relatively simple dependence of the disc size on the mass ratio between the encountering and the disc-bearing star (m₁₂) and the periastron distance (r_peri) which can be described by a fit formula of the form (4)Again, the final disc sizes are limited by the initial disc sizes because the discs do not grow. In the plot the fit function is limited by the initial size of the initially 200 AU discs. Close to the sharp upper cut off of the fit function, the numerical values deviate slightly from the fit since the curves bend smoothly.

The deviations of the final disc sizes obtained with Eq. (4)from the results of the simulations are ≲5% of the initial disc size (i.e. 5 AU for an initially 100 AU disc) for mass ratios m₁₂ = 5–500 and ≲10% for mass ratios m₁₂ = 0.3–5. These deviations are still of the order of the uncertainty of the size definition. The validity of our fit formula is also restricted to periastra where r_final > 0.2 r_init.

4. Discussion

Some approximations have been made in the model described above. First, we treated the discs by pure N-body methods while neglecting viscous forces. Viscous forces only play a role in the central areas of the discs. For typical viscosity values the effected area is the region within ≲0.2 r_init. Only in the most violent interactions is the disc size reduced to such low values. In principle, for these cases viscous forces would have to be included. As can be seen in Table A.1, this is, for example, the case for equal-mass stars in penetrating encounters closer than 0.7 r_init. For typical disc sizes of the order of a few 100 AU (e.g. Bally et al. 2000; Andrews et al. 2009), such encounters are relatively rare in ONC-Type clusters (Olczak et al. 2006). In addition, for such destructive encounters the material that remains bound is usually <20% of its initial mass and its structure does not resemble a disc as such. In these cases the definition of a disc size is highly questionable.

An additional approximation is that star-disc encounters, where only one of the stars is surrounded by a disc, were considered. This was done for simplicity of description. In principle, for disc-disc encounters the sizes could be larger because disc material could be transferred from the perturbing star to the disc-hosting star and replenish the disc. Pfalzner et al. (2005a) showed that in case both stars are surrounded by discs, mostly an additive approach can be used as usually captured material is deposited close to the star. In addition, the amount of captured mass is very small compared to the disc mass as such. Therefore, in most cases the final disc size is not influenced greatly by captured material. The exception is again the case where the encounter is very violent and the remnant disc mass very low.

Furthermore, the outcome of a disc-disc encounter could be influenced by the dependence of the disc mass and size on the stellar mass. Observations give no conclusive answer to this question. If the disc size scales in some way with the stellar mass, the situation can occur that the perturber has a much higher mass, and therefore has a bigger and possibly more massive disc (see e.g. Andrews et al. 2013). In this case the amount of material captured by the primary could be comparable to or even higher than that of its remaining disc.

We have chosen the point of highest surface density gradient as the definition of the disc size (see Sect. 2.2). However, after an encounter the region where the disc’s surface density drops significantly, spans some range (see Fig. 1b). The inner boundary of this region would correspond better to the disc sizes obtained by SED fits, where the size is usually defined as the point where the surface density transits from a power-law to something steeper. If we had defined our disc sizes as the inner boundary of the density-drop region, the results would be smaller than with our actual definition. Conversely, if defining the size as the point where the surface density falls below a certain threshold (compare Sect. 2.2), the sizes would be somewhat bigger than our results. However, results obtained with each of these definitions would usually not differ from our results by more than ≈0.1 r_init. Our definition is therefore a robust mean value between several possible disc size definitions for perturbed discs.

Since the problem of star-disc encounters scales with the periastron ratio, one would expect that the results can be normalised to this ratio r_peri/r_init. This is indeed the case, but for a more intuitive comparison with observations we have chosen the absolute presentation of the results. The actual values in Table A.1 are normalised to the periastron ratio.

The differences between the simulation results and the fit formula increase for decreasing mass ratios, becoming significant (≳5%) for m₁₂ ≲ 5. This is because in the close encounters needed to change the disc size for low mass ratios the redistribution of the disc material is non-linear. Therefore, the fit formula with linear dependence on the periastron distance can describe this effect only approximately.

It is also important to note that in contrast to close, penetrating encounters, the change in disc size in distant encounters is not mainly caused by a real truncation of the disc. Mostly, the size change is dominated by the redistribution of disc material towards the host star. This redistribution results in smaller disc sizes even when no material is lost at all.

Figure 3 shows where our fit formula can be applied. The axes are chosen to cover the encounter parameter space typical for an ONC-like star cluster. The grey area shows the parameter space covered by this study. To the right of the solid bent line, encounters have almost no effect on the mass, angular momentum, or size of a disc. To the right of the dashed bent line, it can be assumed that encounters also have a negligible effect. The horizontal dashed line depicts the parameter space of Hall et al. (1996) while the black dot marks the simulations by Kobayashi & Ida (2001). In the black shaded area the remaining discs have sizes below 0.2 r_init or have less than 10% of their initial particles. Since the simulations in this area may be influenced by low resolution or the hole in our discs, we excluded them. The remaining grey area depicts the parameter range for which our fit formula is valid.

Kobayashi & Ida (2001) developed an analytical estimate for the size of the inner disc region where the velocity dispersion of the disc material after an encounter is still low enough to form planets (see their Eq. (31)). They obtained (5)Even though the size of this planet forming region is defined differently to our disc size, the mass dependence is similar to the dependence of Eq. (4). However, the periastron dependence of their analytical approximation is stronger than that of our numerical results.

5. Comparison with previous approximations

Figure 4a shows a comparison of the numerical results (solid line) to the often used approximations (see Sect. 1) (6)where 1/3 r_peri is shown by the short-dashed line and 1/2 r_peri by the dotted line. These approximations can only be applied to encounters with r_peri/r_final < 3 and r_peri/r_final < 2, respectively. Therefore, in Fig. 4a the disc sizes for wider perturber periastra are truncated at r_final/r_disc = 1.

The 1/2 r_peri approach is always much bigger than the numerical results and never a good approximation of the disc size after an encounter. The approach of using a third of the periastron distance works when the size after the encounter lies in the range of 0.2–0.4 r_init, equivalent to penetrating or grazing encounters (r_peri/r_init = 0.6–1.2). This means, that we confirm the result of Kobayashi & Ida (2001) for solar system forming encounters with solar-type stars. However, a generalisation to more distant encounters common in cluster environments yields disc sizes that are much to large. The difference between the simulation results and the 1/3 approximation is up to ≳20%, the difference to the 1/2 approximation up to ≈ 80%. For equal mass stars our fit formula Eq. (4) simplifies to (7)This formula can reproduce the numerical results slightly more accurately with deviations ≲10% (see also the long-dashed grey line in Fig. 4a). Nevertheless, a generalisation of any of these mass-ratio independent approximations to other than equal-mass encounters can obviously lead to tremendous errors.

Recently, de Juan Ovelar et al. (2012) derived an upper limit of the disc size after an encounter as the distance d_eq at which the gravitational force of the perturbing star dominates at the time of pericentre passage. This is given by (8)Figure 4b shows the comparison of the sizes approximated by Eq. (8)(thin grey lines) with the simulation results (thick black lines). For clarity we show only the curves for three mass ratios: 0.3 (solid), 9.0 (dashed), and 90.0 (dotted). Evidently, at least for prograde, coplanar encounters, this analytical approximation can only be regarded as an upper limit, because the actual disc sizes are typically up to a factor of two smaller than this estimate.

In addition, de Juan Ovelar et al. (2012) suggested using the mass loss in an encounter to estimate the resulting disc size. Using the mass-loss expression by Olczak et al. (2006) and assuming that the encounter strips the outer disc layers, they argue that ΔM/M should be equal to Δr/r for a mass surface density within the disc ∝ r^-1. With Eq. (4) from Olczak et al. (2006) one obtains for the disc size after an encounter (9)Figure 4c shows that Eq. (9)is also only an upper limit for the disc sizes after encounters. On the one hand, this can be explained by the fact that in distant encounters, where no mass is removed from the disc, the disc can shrink by angular momentum removal. On the other hand, our size definition via the point of steepest surface density makes it possible that a significant amount of bound mass is located in the low-density regions outside of our defined disc size. However, this low density is unlikely to be detected by observations.

Additionally, both approaches of de Juan Ovelar et al. (2012) suffer from the fact that the disc size change is dominated by the redistribution of disc material (see also Sect. 4) and not by the truncation of the outer disc material as assumed.

In summary, previous approximations and fit formulae are largely unsuitable for describing the disc size after an encounter other than for a narrow range of mass ratios around one.

6. Summary

In the dense stellar environments of young clusters, tidal interactions can change the sizes of protoplanetary discs. Performing N-body simulations of these encounters, we confirm earlier results by Kobayashi & Ida (2001) that close (≤100 AU) encounters between equal-mass solar-type stars lead to the shrinking of initially 100 AU-sized discs to 30–50 AU. Naturally this represents only a special case; in clusters the wide spectrum of encounter partners and periastra has to be taken into account.

In this paper we investigated the disc-size change by encounters for the entire parameter space spanned by mass ratio and periastron distance typically covered in clusters. The central result of our extensive numerical parameter study is that the disc size after a prograde, parabolic encounter is a simple function of the periastron distance r_peri and the mass ratio m₁₂ of the two stars of the form Prograde, parabolic encounters are the most destructive type of encounters. Inclined and/or hyperbolic encounters lead to less mass loss and therefore larger disc sizes. However, the parameter dependencies in these types of encounters span a wide parameter range. We will investigate this extended parameter range in a follow up study (in prep.).

The disc sizes after a star-disc encounter as obtained with the disc-size definition presented here would not necessarily correspond to the final size of a potentially developing planetary system. The reasons are that on long time scales (several Myr) viscosity leads to an increase in disc size. Simultaneously, highly eccentric particles probably become recircularised through viscous processes as they pass the inner parts of the disc while being close to their periastron.

Previous work on disc sizes after encounters was often motivated by the search for the solar birth environment. Here the sudden density drop in the mass distribution at 30–50 AU is interpreted as the result of a close fly-by of another star during the formation phase of the solar system. Considering only encounters between equal mass stars, an encounter distance of 100–150 AU was deduced. However, recent results show that encounters of the early solar system with less or more massive stars are at least just as likely as with another solar-mass star. Our results show now that any parabolic, prograde encounter which fulfils the relation (10)can lead to a solar-system size disc.

So far the dependencies of protoplanetary disc sizes on parameters like stellar mass, etc., are observationally not well constrained. With the advent of ALMA this will quickly change. Thus, it will also be possible to determine whether dense stellar environments have a significant influence on the disc sizes and the forming planetary systems. The dependencies derived here will be a useful tool for determining the corresponding encounter events.

---

References

Online material

Appendix A: Relative disc size changes

Here we present the full numerical results from our parameter study. In contrast to the presentation of the results in the main part of the paper, the values are normalised to the initial disc sizes to allow easier application to arbitrary initial disc sizes. Therefore, r_p is the encounter periastron distance normalised to the initial disc size (r_p = r_peri/r_init) and m₁₂ is the mass of the perturbing star normalised to the mass of the disc-hosting star (m₁₂ = m₂/m₁). The final disc size is obtained by multiplying the initial disc size with the respective value from the table. In the lower-left part of the table, where no values are given, the disc size change is ≲1%, in the upper-right, no values are given, since they may not be reliable (see also discussion in Sect. 2 of the paper).
