Stellar wobble caused by a nearby binary system: eccentric and inclined orbits
^{1}
Department of Physics, I3NUniversity of Aveiro, Campus Universitário de
Santiago,
3810193
Aveiro,
Portugal
email: helena.morais@ua.pt
^{2}
Astronomie et Systèmes Dynamiques, IMCCECNRS UMR 8028,
77 Avenue
DenfertRochereau, 75014
Paris,
France
Received:
16
April
2010
Accepted:
22
October
2010
Most extrasolar planets currently known were discovered by means of an indirect method that measures the stellar wobble caused by the planet. We previously studied a triple system composed of a star and a nearby binary on circular coplanar orbits. We showed that although the effect of the binary on the star can be differentiated from the stellar wobble caused by a planet, because of observational limitations the two effects may often remain indistinguishable. Here, we develop a model that applies to eccentric and inclined orbits. We show that the binary’s effect is more likely to be mistaken by planet(s) in the case of coplanar motion observed equatoron. Moreover, when the orbits are eccentric, the magnitude of the binary’s effect may be larger than in the circular case. Additionally, an eccentric binary can mimic two planets with orbital periods in the ratio 2/1. However, when the star’s orbit around the binary’s center of mass has a high eccentricity and a reasonably wellconstrained period, it should be easier to distinguish the binary’s effect from a planet.
Key words: technique: radial velocities / celestial mechanics / planetary systems / binaries: general
© ESO, 2010
1. Introduction
In Morais & Correia (2008), we studied a triple system consisting of a star perturbed by a binary system. Our aim was to derive an expression for the star’s radial velocity in order to determine whether the binary’s effect could be mistaken for that of a planet companion to the star. This question is relevant if one or even both binary components are unresolved which can happen for instance when these are faint but very common M stars. About 76% of nearby main sequence stars are Mtype (LeDrew 2001). Moreover, in the solar neighborhood, over 50% of G and Kstars (Duquennoy & Mayor 1991; Halbwachs et al. 2003; Eggenberger et al. 2004) and about 30% of Mstars (Fischer & Marcy 1992; Delfosse et al. 2004) belong to binary or even multiple systems.
We previously showed that the binary system’s effect on the star is a sum of two periodic signals with very close frequencies. These signals, if detected, could be associated with two planets on circular orbits around the star. However, these planets would have very close orbits and we should be able to discard them as unstable systems. Moreover, we derived expressions for the frequencies and amplitudes of these signals, thus were able to identify the hidden binary’s parameters. As explained in Morais & Correia (2008), our results do not agree with previous work by Schneider & Cabrera (2006) who studied the case of an equalmass binary and concluded that its effect is a single periodic signal that mimics a planet on an eccentric orbit.
Nevertheless, in Morais & Correia (2008) we saw that there are realistic situations where we can identify one of the periodic signals but not the other. In this case, we may mistake the binary’s effect for that of a planet on a circular orbit around the star. However, we can still apply our theory to compute the hidden binary’s parameters and then try to detect these objects.
Our work was based on a full threebody model but assumed coplanar motion and initial circular orbits for the star and binary. However, general triplestar systems are likely to have noncoplanar motion and eccentric orbits. Therefore, in this article, we extend our study to the case of threedimensional noncircular motion of the star and binary system. In Sect. 2, we present the model and in Sect. 3 we discuss the circumstances that lead to the binary being mistaken by one or more planets. In Sect. 4, we compare the theoretical predictions with results obtained from simulations of hypothetical triple systems, we discuss the triple system HD 188753, and we (re)analyze the exoplanets discovered within binary systems. Finally, in Sect. 5 we present our conclusions.
2. Modeling a star perturbed by a binary system
2.1. Equations of motion and radial velocity
We consider the framework of the general threebody problem: we assume that a star with mass M_{ ⋆ } has a nearby binary system with masses M_{1} and M_{2} (Fig. 1).
Fig. 1 A star with mass M_{ ⋆ } is perturbed by a binary system with masses M_{1} and M_{2}. The Jacobi coordinates r_{b} and r are, respectively, the interbinary distance and the distance of M_{ ⋆ } to the binary’s center of mass. The unperturbed Keplerian described by r is in the plane (x′,y′). The unperturbed Keplerian described by r_{b} is defined with respect to the (x′,y′) plane by the angles Ω (relative node longitude) and i (relative inclination). The observer’s frame (x,y,z) with z being the line of sight is obtained by rotating the auxiliary frame (x′,y′,z′) around the x axis by an angle I (inclination of r’s orbit with respect to (x,y)). Moreover, S = ∠(r,r_{b}), , and .

Open with DEXTER
Following Morais & Correia (2008), we use Jacobi coordinates, which are the interbinary distance, r_{b}, and the distance, r, from the star M_{ ⋆ } to the binary’s center of mass (see Fig. 1). We also assume that ρ = r_{b}/r ≪ 1.
In the auxiliary frame (Fig. 1), r = (x′,y′,z′), where (1)and , where (2)where θ and θ_{b} are the orbits’ true longitudes, Ω is the relative node longitude, and i is the relative inclination.
The transformation from the auxiliary frame (x′,y′,z′) to the observer’s frame (x,y,z) is (3)Moreover, we define the angle S = ∠(r,r_{b}) which is given by (4)where is the versor of r and is the versor of r_{b}.
Jacobi coordinates are useful to this problem because the unperturbed motion is a composition of two Keplerian ellipses. As seen in Morais & Correia (2008), including terms up to first order in ρ, we have (5)where, unless M_{ ⋆ } ≫ M_{1} + M_{2}, (6)and (7)where (8)Thus we can write r_{b} = r_{b0} + ϵ_{b}r_{b1}, where (9)and r = r_{0} + ϵr_{1}, where (10) Therefore the 0th order solution, r_{b0}, is a Keplerian ellipse with constant semimajor axis, a_{b}, and frequency (11)and the 0th order solution, r_{0}, is a Keplerian ellipse with constant semimajor axis, a, and frequency (12)Furthermore, from Eqs. (11) and (12) we see that in general n ≪ n_{b} since a_{b} ≪ a (this is true unless M_{ ⋆ } ≫ M_{1} + M_{2}).
Now, the distance of the star to the triple system’s center of mass is (13)hence from Eq. (7) we have (14)Since , and , we obtain an approximation to the previous equation that is accurate up to O(ϵ), i.e. (15)whose solution, r_{ ⋆ } = r_{ ⋆ 0} + ϵr_{ ⋆ 1}, is thus a combination of a Keplerian ellipse (with frequency n), r_{ ⋆ 0}, and a perturbation term (16)The radial velocity is the projection of the star’s barycentric velocity along the line of sight (defined as the zaxis in Fig. 1), i.e., V_{r} = ż_{ ⋆ }. Therefore, we only need to compute the z component of the first order correction, ϵr_{ ⋆ 1} (Eq. (16)), i.e. (17)Additionally, from Eqs. (1)–(4) we have
2.2. Star and binary on circular orbits
In this case , r_{0} = a, r_{b0} = a_{b}, θ = λ = n t + λ_{0}, θ_{b} = λ_{b} = n_{b} t + λ_{b0}, where λ and λ_{b} are the orbits’ mean longitudes. Thus Eq. (17) becomes (21)where (22)as defined in Morais & Correia (2008).
The righthand side of Eq. (21) is a sum of periodic terms, hence V_{r} = ż_{ ⋆ } is obtained by integrating them with respect to time. Therefore, ż_{ ⋆ } is a linear combination of six periodic terms with frequencies n, 3 n, 2 n_{b} − n, 2 n_{b} + n, 2 n_{b} − 3 n, and 2 n_{b} + 3 n.
In the coplanar case (i = 0), we recover the solution obtained in Morais & Correia (2008)(23)i.e., ż_{ ⋆ } is a composition of three periodic terms with frequencies n, 2 n_{b} − n, and 2 n_{b} − 3 n.
We note that when i = 0 (coplanar case) the angle I defines the projection of the star’s orbit along the line of sight and thus (and ż) scale with sinI. However, when i ≠ 0 the angle that defines the projection of the star’s orbit along the line of sight depends on I, i, and Ω. When i ≠ 0, the amplitudes associated with the frequencies n and 2 n_{b} ± n indeed do not scale with sinI (cf. last three terms in Eq. (21)). In particular, when I = 0 (poleon configuration) and if i ≠ 0 we can still detect these terms (frequencies n and 2 n_{b} ± n), which are due to the binary’s effect on the star.
In Fig. 2, we show the normalized amplitudes (A) associated with the frequencies 2 n_{b} ± n and 2 n_{b} ± 3 n, as a function of i for Ω = 0, I = 90° (Fig. 2, top) and Ω = 90°, I = 90° (Fig. 2, bottom). In Fig. 3, we show the equivalent picture for I = 0. The true amplitudes are A δ n_{b}.
At I = 90° (equatoron configuration) and small i, the term of frequency 2 n_{b} − 3 n is dominant but as i increases its amplitude decreases, while the amplitudes of the terms with frequencies 2 n_{b} + 3 n and 2 n_{b} ± n increase until they are all approximately equal at i = 90°. At I = 0 (poleon configuration), only the terms with frequencies n and 2 n_{b} ± n appear (cf. Eq. (21)), hence we cannot detect the star’s motion around the binary’s center of mass but if i ≠ 0 we can still detect the binary’s effect on the star. Moreover, the amplitudes associated with the frequencies 2 n_{b} ± 3 n are independent of Ω at any value of I while the amplitudes associated with the frequencies 2 n_{b} ± n depend on the orbits’ intersection Ω except when I = 0 (cf. Eq. (21)). The pictures for 90° > i ≥ 0° (star and binary on prograde orbits) and 180° ≥ i > 90° (binary on a retrograde orbit) are symmetrical except that the frequency n is replaced with −n, which corresponds to inverting the star’s (or binary’s) motion.
Fig. 2 Circular case with I = 90° (equatoron configuration). Normalized amplitudes A of periodic terms as function of the relative inclination i. These are obtained by integrating Eq. (21) with respect to time. The true amplitudes are A δ n_{b}.

Open with DEXTER
Fig. 3 Circular case with I = 0 (poleon configuration). Normalized amplitudes A of periodic terms as function of the relative inclination i. These are obtained by integrating Eq. (21) with respect to time. The true amplitudes are A δ n_{b}.

Open with DEXTER
2.3. Star and binary on eccentric orbits
We assume that the Keplerian orbit, r_{0}, has a semimajor axis a, eccentricity e, and true longitude θ = f + ϖ (where f is the true anomaly and ϖ is the longitude of periastron) and that the Keplerian orbit, r_{b0}, has semimajor axis a_{b}, eccentricity e_{b}, and true longitude θ_{b} = f_{b} + ϖ_{b} (where f_{b} is the true anomaly and ϖ_{b} is the longitude of periastron). Thus Eq. (17) becomes (24)where (25)We can express the orbital solutions, r_{0} and r_{b0}, as Fourier series of the mean anomalies M = n t + M_{0} and M_{b} = n_{b} t + M_{b0}, respectively, also known as elliptic expansions. In particular, we obtain expressions for (a/r_{0})^{4} and (r_{b0}/a_{b})^{2} using elliptic expansions for r/a and r_{b}/a_{b} (e.g. Murray & Dermott 1999). We obtain similar expressions for (Eq. (18)), (Eq. (19)), and cosS (Eq. (20)) using elliptic expansions for cos(f), sin(f), cos(f_{b}), and sin(f_{b}) (e.g. Murray & Dermott 1999).
2.3.1. Coplanar motion
In this case, i = 0, thus from Eqs. (18)–(20) where θ = f + ϖ and θ_{b} = f_{b} + ϖ_{b}.
The next step is to replace these expressions into Eq. (24) using elliptic expansions for (a/r_{0})^{4}, (r_{b0}/a_{b})^{2}, sin(θ), sin(θ_{b}), cos(θ_{b} − θ), and cos(2 (θ_{b} − θ)). We start by using elliptic expansions up to first order in the eccentricities.
As in Morais & Correia (2008), our aim is to obtain a solution to Eq. (24) that is a linear combination of periodic terms. However, when e ≠ 0 we have a constant term of the type esin(ϖ) appearing in . We can remove this secular term by rewriting Eq. (16) as (29)where the vector p = (p_{x},p_{y},p_{z}) has radius (3/4) e, and is aligned with the periapse of the unperturbed orbit, r_{0}, i.e. and (33)Now, the first term in Eq. (29) can be interpreted as the slow rotation (frequency ~) of the unperturbed orbit r_{0}’s periapse described by the vector p. Therefore, we can concentrate in obtaining the solution to Eq. (33).
The z component of the first order correction, ϵr^{′}_{ ⋆ 1} given by Eq. (33), becomes (34)where λ_{0} = M_{0} + ϖ and λ_{b0} = M_{b0} + ϖ_{b}.
The righthand side of Eq. (34) is a sum of periodic terms, hence V_{r} = ż_{ ⋆ } is obtained by integrating these with respect to time. Therefore, when including terms up to first order in the eccentricities, ż_{ ⋆ } is a composition of 12 periodic terms with frequencies: n, 2 n_{b} − n and 2 n_{b} − 3 n (zero order); n_{b} − 3 n, 3 n_{b} − n, 3 n_{b} − 3 n, n_{b} + n and n_{b} − n (first order: e_{b}); 2 n, 2 n_{b}, 2 n_{b} − 4 n and 2 n_{b} − 2 n (first order: e). The amplitudes of the terms with frequencies n_{b} − n and 2 n_{b} − 2 n depend on ϖ_{b} and ϖ, respectively.
We can easily extend our theory by including higherorder eccentricity terms in the elliptic expansions^{1} (i.e., Fourier series of the Keplerian orbital solutions r_{0} and r_{b0}). In particular, if we include terms up to second order in the eccentricities, there are additional periodic terms with frequencies: 3 n, 2 n_{b} + n, 4 n_{b} − n, 4 n_{b} − 3 n (second order: ); 3 n, 2 n_{b} + n, 2 n_{b} − 5 n (second order: e^{2}); 3 n_{b} − 2 n, n_{b}, 3 n_{b}, n_{b} − 4 n, n_{b} + 2 n, n_{b} − 2 n, 3 n_{b} − 4 n (second order: e e_{b}). Moreover, the amplitudes associated with the frequencies 2 n_{b} − n and 2 n_{b} − 3 n (zero order) have corrections of second order in the eccentricities.
In Fig. 4, we show the largest normalized amplitudes (A > 2) of the periodic terms that appear up to fourth order in the eccentricities (except harmonics of n) as functions of e_{b} when e = 0.1. The expansion in e_{b} converges rapidly thus it is not necessary to include higher order terms at least up to e_{b} = 0.4. When e_{b} is small, the term with frequency 2 n_{b} − 3 n is dominant but when e_{b} > 0.16, the term with frequency n_{b} − 3 n has the largest amplitude. Other important terms have frequencies 2 n_{b} − 4 n and n_{b} − 4 n.
In Fig. 5, we show the largest normalized amplitudes (A > 2) of the periodic terms that appear up to 10th order in the eccentricities (except harmonics of n) as functions of e when e_{b} = 0. We include corrections in the amplitudes up to 12th order in the eccentricities. These high order expansions are necessary to obtain results valid up to e = 0.4 since the expansion in e converges slowly. When e is small, the term with frequency 2n_{b} − 3 n has the largest amplitude but as e increases, the dominant term becomes 2 n_{b} − 4 n (e > 0.18), 2n_{b} − 5 n (e > 0.28), and 2 n_{b} − 6 n (e > 0.36). As e increases, the number of terms with frequencies near 2 n_{b} and similar amplitudes increases.
Fig. 4 Coplanar case (i = 0) with star on an eccentric orbit (e = 0.1). Normalized amplitudes A of periodic terms, as function of the binary’s eccentricity e_{b}. We show all periodic terms that appear up to fourth order in the eccentricities and reach at least A = 2. The true amplitudes are A δ n_{b} sinI.

Open with DEXTER
Fig. 5 Coplanar case (i = 0) with star on an eccentric orbit (e = 0.1). Normalized amplitudes A of periodic terms, as function of the star’s eccentricity e. We show all periodic terms that appear up to 10th order in the eccentricities and reach at least A = 2. The true amplitudes are A δ n_{b} sinI.

Open with DEXTER
2.3.2. Noncoplanar motion
When i ≠ 0, we must follow the same procedure described in the previous section, expressing the orbital solutions r_{0} and r_{b0} using elliptic expansions (e.g. Murray & Dermott 1999), but now using the general expressions for , , and cosS (Eqs. (18)–(20)).
We can show that, including terms up to first order in the eccentricities, (and ż_{ ⋆ }) are linear combinations of 21 periodic terms with frequencies n, 2 n, 3 n, 4 n, 2 n_{b}, 2 n_{b} ± n, 2 n_{b} ± 3 n, n_{b} ± n, n_{b} ± 3 n, 3 n_{b} ± n, 3 n_{b} ± 3 n, 2 n_{b} ± 4 n, and 2 n_{b} ± 2 n. We note that, except for the additional harmonics of n, these include the set of frequencies already present in the coplanar eccentric case plus an additional set of frequencies obtained from the previous set by replacing n with − n, which as noted previously corresponds to inverting the star’s (or binary’s) motion.
We already described how the terms with frequencies 2 n_{b} ± n, and 2 n_{b} ± 3 n (circular case) behaved with I, i, and Ω (Figs. 2, 3 and Sect. 2.2). To understand what happens when e and e_{b} are small but nonzero, we now describe the behavior of the terms that appear to first order in the eccentricities.
When e_{b} ≠ 0, the frequencies n_{b} ± 3 n, 3 n_{b} ± n, n_{b} ± n, and 3 n_{b} ± 3 n appear. In Fig. 6, we show the normalized amplitudes (A) as functions of i for I = 90° (equatoron configuration), e_{b} = 0.1, and Ω = 90°. At I = 90° and small i, the term with frequency n_{b} − 3 n has maximum amplitude. As the relative inclination i increases, this amplitude decreases and at i = 90° the terms with frequencies n_{b} ± n have maximum amplitude.
Fig. 6 Eccentric case (e_{b} = 0.1) with I = 90°. Normalized amplitudes A of periodic terms as a function of the relative inclination i. The true amplitudes are A δ n_{b}.

Open with DEXTER
When e ≠ 0, the frequencies 2 n_{b}, 2 n_{b} ± 2 n, and 2 n_{b} ± 4 n appear. In Fig. 7, we show the normalized amplitudes (A) as functions of i for I = 90° (equatoron configuration), e = 0.1, and Ω = 90°. At I = 90° and small i, the term with frequency 2 n_{b} − 4 n has maximum amplitude. As the relative inclination i increases, this amplitude decreases and at i = 90° it matches the amplitudes of the terms with frequency 2 n_{b} ± 2 n.
Fig. 7 Eccentric case (e = 0.1) with I = 90°. Normalized amplitudes A of periodic terms as a function of the relative inclination i. The true amplitudes are A δ n_{b}.

Open with DEXTER
In Figs. 8 and 9, we show the normalized amplitude (A) when I = 0, e_{b} = 0.1, and e = 0.1, respectively. In this configuration (I = 0), only the frequencies 3 n_{b} ± n, n_{b} ± n, 2 n_{b}, and 2 n_{b} ± 2 n have nonzero amplitude. As noted previously, in this case (poleon configuration) we cannot detect the star’s motion around the binary’s center of mass but if i ≠ 0, we can still detect the binary’s effect on the star.
Fig. 8 Eccentric case (e_{b} = 0.1) with I = 0. Normalized amplitudes A of periodic terms as a function of the relative inclination i. The true amplitudes are A δ n_{b}.

Open with DEXTER
Fig. 9 Eccentric case (e = 0.1) with I = 0. Normalized amplitudes A of periodic terms as a function of the relative inclination i. The true amplitudes are A δ n_{b}.

Open with DEXTER
Moreover, when i ≠ 0 only the amplitudes associated with the frequencies n_{b} ± 3 n, 3 n_{b} ± n, n_{b} ± n, 2 n_{b}, and 2 n_{b} ± 2 n depend on the relative node longitude, Ω, since the other frequencies originate from the angles 2 θ_{b} ± 3 θ and 3 θ whose amplitudes are independent of Ω (cf. third, fourth and fifth terms in Eq. (21)). We can also show that the amplitudes associated with the frequencies n_{b} ± 3 n and n_{b} ± n depend on the binary’s longitude of pericenter ϖ_{b}, while the amplitudes associated with the frequencies 2 n_{b} and 2 n_{b} ± 2 n depend on the star’s longitude of pericenter ϖ.
The pictures for 90° > i ≥ 0° (star and binary on prograde orbits) and 180° ≥ i > 90° (binary on a retrograde orbit) are symmetrical except that the frequency n is replaced with −n, which corresponds to inverting the star’s (or binary’s) motion.
3. Can a binary system mimic a planet?
As in Morais & Correia (2008), we wish to identify the circumstances in which we can we mistake the binary’s effect for that of a planet, when we do not know whether a binary is present (one or even both components may be unresolved). We have seen that the star’s radial velocity will have a slow Keplerian term, which can be associated with a mass, M_{1} + M_{2}, located at the binary’s center of mass. Hence, from the radial velocity we can infer the presence of a nearby “star”, M_{1} + M_{2}, except when I = 0 (poleon configuration) where we can nevertheless detect the wobble due to the binary if i ≠ 0. Moreover, the radial velocity of the star, M_{ ⋆ }, that has a planet companion, M_{p}, in a circular orbit with frequency n_{p}, semimajor axis a_{p} and inclination I_{p}, and another nearby “star”, M_{1} + M_{2}, is (35)where V_{0} includes the Keplerian motion around the “star” M_{1} + M_{2}, and we can neglect M_{p} in the denominator of Eq. (35) since the planet’s mass is negligible with respect to the stars.
We saw above that the radial velocity of a star perturbed by a binary system is a composition of several periodic signals. The terms that include harmonics of the frequency n can in principle^{2} be associated with the star’s slow Keplerian motion around the binary’s center of mass (i.e., V_{0}). Therefore, we have (36)where (37)and the factor A is a normalized amplitude that, as explained previously, can be obtained for each frequency n_{p}.
Each of the terms with amplitude K_{p} could be identified as a planet on a circular orbit around the star with frequency n_{p} = p n_{b} ± q n, where p > 0 and q ≥ 0 are integers. However, since we have a limit on the observations’ precision, we can sometimes detect only a few periodic terms with the largest amplitudes. On the other hand, since n_{b} ≫ n, terms of equal p have very close frequencies. Hence, if we can detect these latter terms, we associate them with planets on very close orbits that can be discarded as unstable configurations. However, since we have a limit on the observations’ resolution, we are sometimes unable to distinguish terms with very close frequencies.
The radial velocity method of extrasolar planet’s detection consists of measuring tiny Doppler shifts in the star’s spectral lines caused by the star’s motion. These Doppler shifts are collected over an observation timespan, t_{obs}, in order to obtain the star’s radial velocity curve. The instrument’s precision is the smallest Doppler shift that can be detected, hence the smallest detectable amplitude in the radial velocity’s Fourier transform. On the other hand, the data’s resolution is the smallest frequency difference that can be detected, i.e., δf = 1/t_{obs}. Therefore, to distinguish two terms with frequencies that differ by Δ qn, we must have (38)where T = 2π/n.
Now, if all detected frequencies are well separated (i.e., have different p) we may then be led to believe that the star has one or more planet companions. In that case, we apply Kepler’s third law to derive the fake planets’ semimajor axis, a_{p}, from the signal’s frequencies, n_{p}, i.e. (39)and from Eqs. (35) and (36) we obtain the associated minimum masses, M_{p}sinI_{p}, from the signal’s amplitudes K_{p} (Eq. (37)), i.e. (40)Moreover, from Eq. (37) we see that the binary’s effect is more pronounced (i.e K_{p} is larger) for a large ratio a_{b}/a, small interbinary distance a_{b}, and a massive binary of equal stars (M_{1} = M_{2}).
3.1. Circular coplanar orbits
This was studied in Morais & Correia (2008). In the case of coplanar circular prograde orbits, we recall that the periodic terms due to the binary’s effect have frequencies n_{p} = 2 n_{b} − n and n_{p} = 2 n_{b} − 3 n, and associated amplitudes K_{p} ≈ (3/2)n_{b}δsinI and K_{p} ≈ (15/2)n_{b}δsinI, respectively. As noted previously, these signals may at first sight be identified as two planets orbiting the star with very close frequencies. However, if we could resolve these close frequencies (i.e., if t_{obs} > T/2, cf. Eq. (38)), we should be able to discard the planet’s existence since these systems are most certainly unstable. There are nevertheless situations where we can mistake the effect of a binary system for a planet:

We cannot resolve the two close frequencies (i.e., ift_{obs} < T/2, cf. Eq. (38)), hence we detect only one signal at ~2 n_{b}.

Owing to limited instrument’s precision, we detect the signal at 2 n_{b} − 3 n but not the one at 2 n_{b} − n (these have amplitudes in the ratio 5/1.)
In the latter scenario, from Eq. (39), we obtain the associated fake planet’s semimajor axis (41)and from Eqs. (37) and (40), since the motion is coplanar (I_{p} = I), we obtain the fake planet’s mass (42)In the former scenario, the signal’s amplitude can vary by 20% depending on the unresolved signals’ phases. Nevertheless, these formulae are still approximately valid.
3.2. Noncircular, noncoplanar orbits
The case of inclined and eccentric orbits is similar. We saw that, when including terms up to first order in the eccentricities, the star’s radial velocity is a composition of 21 periodic terms. Four terms are harmonics of the frequency n, hence can in principle be discarded as associated with the slow Keplerian motion around the binary’s center of mass. Four terms have frequencies close to n_{b}, nine terms have frequencies close to 2 n_{b}, and four terms have frequencies close to 3 n_{b}.
Comparing Figs. 2, 3 and 6–9 we see that the maximum radial velocity variations associated with dominant periodic terms occur when I = 90° (equatoron configuration) and the orbits are nearly coplanar (i ≈ 0 or i ≈ 180°). In the case of coplanar prograde motion (i = 0), the dominant term has frequency 2 n_{b} − 3 n (for small e and e_{b}; cf. Figs. 4 and 5) and frequency n_{b} − 3 n (for large e_{b}; cf. Fig. 4). In particular, when the binary’s orbit is eccentric it is possible to detect signals at 2 n_{b} − 3 n and n_{b} − 3 n, which can mimic two planets with orbital periods in the ratio 2/1. However, as e increases the number of terms with frequencies close to 2 n_{b} and similar amplitudes increases (Fig. 5), hence it should be easier to detect signals with very close frequencies.
4. Examples
4.1. Theory versus simulations
To test our model, we performed some numerical simulations of a triple system composed of main sequence stars with different spectral types G, K, and M, and masses M_{ ⋆ } = M_{⊙}, M_{1} = 0.70 M_{⊙}, and M_{2} = 0.35 M_{⊙}, respectively. The smaller K and M stars form a binary system with semimajor axis a_{b} = 1.1 AU, eccentricity e_{b}, and inclination I_{b}. The G star is in a wide orbit with semimajor axis a = 10 AU, eccentricity e, and inclination I around the binary’s center of mass. The M star is much fainter than the K or G stars, hence it represents the unresolved component of the binary.
We numerically integrated this triple system and computed the radial velocity of the G star (the brightest body in the system) assuming an equatoron configuration (I = 90°). From this, we simulated 100 observational data points for a time span of 4000 days (about 11 years). We assumed that the data were obtained with a precision limit of 0.535 m/s, which corresponds to A = 4.46 (cf. Eq. (37)) and is about the highest precision that can presently be obtained (HARPS, Mayor et al. 2003). We then applied the traditional techniques used to search for planets.
Since t_{obs} = 4000 days and the output step is Δ t ≈ 40 days, the largest detectable frequency is f_{c} = 2/(Δ t) = 1/20 days^{1} and the frequency resolution is Δ f = 1/4000 days^{1}. We present the theoretical predictions versus simulations in Table 1.
In a first step, we can only detect the largeamplitude radial velocity variations due to the star’s slow motion (with period T = 2π/n) around the binary’s center of mass. Once we subtract these longterm variations we are able to detect the signal due to the binary’s motion, which could be mistaken for one or more planet companions to the star.
Example 1 is a circular coplanar system (i = 0) already presented in Morais & Correia (2008), where the binary mimics a planet of approximately 20 Earth masses. Examples 2 and 3 are also circular but inclined systems with i = 30° and i = 60°, respectively. These demonstrate that increasing the relative inclination i leads to a decrease in the planet’s mass M_{p}, as we would expect from Eq. (21) since the amplitude associated with the frequency 2 n_{b} − 3 n is proportional to (1 + cosi)^{2}.
The next four examples are coplanar systems (i = 0) with e = 0.1 and e_{b} = 0.1, 0.2, 0.3, and 0.4, respectively. When e_{b} = 0.1 (Ex. 4), we detect the signals with frequencies 2 n_{b} − 3 n and n_{b} − 3 n (cf. Fig. 4 with A = 4.46). When e_{b} ≥ 0.2 (Exs. 5, 6 and 7), the signal with frequency n_{b} − 4 n is above the detection limit (cf. Fig. 4 with A = 4.46) but we cannot distinguish it from the signal with frequency n_{b} − 3 n since the resolution is not high enough. To resolve a frequency difference of n we would indeed require a resolution of at least Δ f = 2π/n, which corresponds to a time span T = 2π/n, i.e., about 22 years. At present, such a large timespan is not realistic since exoplanet detections started only 15 years ago. This lack of resolution prevents the correct detection of the signal with frequency n_{b} − 3 n in the 5th, 6th, and 7th examples since this is "contaminated" by the close signal with frequency n_{b} − 4 n.
In examples 1, 2, and 3, the binary mimics a planet while in examples 4–7, it mimics two planets with orbital periods in the ratio 2/1. In these cases, the data’s precision and observation timespan do not allow us to distinguish the binary’s effect from planet(s). We now present an example where we detect signals with very close frequencies thus can reject the planet(s) hypothesis.
Example 8 is a coplanar system (i = 0) with e_{b} = 0.05, and e = 0.4. According to Fig. 5, when e = 0.4 the terms with frequencies 2 n_{b} − 6 n, 2 n_{b} − 5 n, 2 n_{b} − 7 n, 2 n_{b} − 8 n, and 2 n_{b} − 9 n are all above the detection level (A = 4.46). However, we only detect signals at approximately 2 n_{b} − 6 n and 2 n_{b} − 8 n as the observation timespan, t_{obs} ≈ T/2, is not long enough to resolve the other frequencies. These nearby unresolved frequencies prevent the correct detection of the signals at 2 n_{b} − 6 n and 2 n_{b} − 8 n. Additional Fourier analysis of the residuals show the presence of a signal at 2 n_{b} − 10 n but the fitting to the signals at 2 n_{b} − 6 n and 2 n_{b} − 8 n deteriorates when including this frequency. The residuals are 1.7 m/s, i.e., above the precision limit (~0.5 m/s), which indicates the presence of unresolved / undetected frequencies.
Finally, we note what happens when e is large but the observation time span is short. We performed a new analysis of example 8 assuming t_{obs} = 2000 days and t_{obs} = 1000 days, i.e., about T/4 and T/8, respectively. In the first case, we detected signals at 243 days (2 n_{b} − 6 n) and 281 days (2 n_{b} − 11 n), with amplitudes 5.0 m/s and 2.7 m/s, respectively. However, the residuals after the fit are still 1.3 m/s. In the second case, we detect only one signal at 257 days (~2 n_{b}) with an amplitude 6.7 m/s„ which corresponds to a 0.3 M_{J} planet at 0.79 AU. Since t_{obs} ≪ T, we cannot resolve the signals at nearby frequencies although these affect the measured amplitude. The residuals after the fit are ~0.4 m/s, hence there is no hint of unresolved/undetected frequencies.
4.2. Scaling of the observables
Parameters of planets mimicked by several triple system configurations when the instrument’s precision is 0.535 m/s and the timespan is 4000 days. Radial velocity Fourier spectrum peak has amplitude K_{p} and frequency n_{p}. Fake associated planet has period T_{p} = 2π/n_{p}, semimajor axis a_{p}, mass M_{p}, and eccentricity e_{p}.
In the previous section, we presented examples of several configurations of a triple star system where the binary is at a = 10 AU from the target star. However, if the binary’s stars are not both faint, it may be difficult to obtain precise radial velocity measurements because the target star’s spectrum is likely to be contaminated by light received from the binary’s stars. This will cause spectral line blending and it may be very difficult to separate the target star’s motion from the binary’s motion. Therefore, a realistic scenario would be a distant binary system (e.g. 50 or 100 AU) or a close binary (e.g. 10 AU) composed of faint stars (e.g. Mtype).
Triple system of solar mass star and binary on circular coplanar orbits: parameters of planets mimicked by the binary.
In Table 2, we show some examples of triple systems composed of a solar mass star and a binary system on circular coplanar orbits. In examples 1 and 2, the planets could be detected by the current most precise instruments (e.g. HARPS, Mayor et al. 2003). On the other hand, the effect of the binaries in examples 3 and 5 is slightly below the current detection limit but the long periods imply that we would need a long observation timespan to constraint the orbits. Finally, the planets mimicked by the binaries in examples 4 and 6 are not detectable by the current techniques but could be accessible to the planned exoplanet search program EXPRESS0/CODEX (D’Odorico & CODEX/ESPRESSO Team 2007).
Our results can be easily scaled:

If we increase a and a_{b} by a factor γ, then the ratio a_{b}/a does not change, K_{p} decreases by γ^{−1/2} (Eq. (37)), a_{p} increases by a factor γ (Eq. (39)), and M_{p} remains unchanged (Eq. (40)), while the periods increase by γ^{3/2}.

If we decrease M _{1} and M _{2} by a factor γ, then K _{p} decreases by γ ^{1/2} (Eq. (37)), T _{p} increases by γ ^{−1/2}, a _{p} increases by a factor γ ^{−1/3} (Eq. (39)), and M _{p} decreases by γ ^{1/3} (Eq. (40)), while T remains unchanged.
4.3. The triple system HD 188753
The system HD 188753 is composed of a star (A) and a close binary (Ba+Bb) with an orbital period of 155 days that orbits the star (A) with a 25.7 year period (Konacki 2005). A hot Jupiter with a 3.35 day period orbit around the A star was announced by Konacki (2005) but this was later challenged by Eggenberger et al. (2007) who claimed they could not find evidence for this planet. This shows the difficulty in identifying planets of stars with a nearby binary system. As noted previously, when observing the target star to obtain its spectrum we are likely to also detect light from the nearby stars. In the case of HD 188753, the contribution of Bb is modest since this star is faint but we cannot ignore the contribution of Ba, which is blended within the target star A’s spectrum (Eggenberger et al. 2007).
The parameters of this triple system are M_{ ⋆ } = 1.06 M_{⊙}, M_{1} = 0.96 M_{⊙}, M_{2} = 0.67 M_{⊙}, a = 12.3 AU, a_{b} = 0.67 AU, e = 0.5, e_{b} = 0.1, and I = 34° (Konacki 2005). We can apply our theory to estimate the effect of the binary on the star assuming 50 data points and t_{obs} = 500 days, which are approximately the parameters reported in Eggenberger et al. (2007). Assuming that the triple system is coplanar, we obtain radial velocity oscillations with an 85 day period (frequency ~2 n_{b}) and amplitude 0.5 m/s (i.e., 5.5 times the value obtained with a circular coplanar model). This can be interpreted as a fake planet of 4 Earth masses located at 0.38 AU. As t_{obs} ≪ T = 25.7 years, we cannot resolve additional frequencies near 2 n_{b}. However, the predictions made here will change for different values of the angle variables (phases and relative inclination) and if we increase the observation time span. Nevertheless, the precision obtained for this system is currently only 60 m/s (Eggenberger et al. 2007), hence this effect is not detectable.
4.4. Planets in binaries
In Morais & Correia (2008), we reviewed all currently known planets of stars which are part of a moderately close binary system (a ≲ 100 AU). Our aim was to see whether these could be fake planets due to a binary composed of the companion star, M_{1}, and another unresolved star, M_{2}. We computed the parameters of the hidden binary component (M_{2} and a_{b}) that could mimic these planets (Table 1, Morais & Correia 2008) and saw that M_{2} would either be too massive to be realistic or at least too massive to be unreported.
The results in Morais & Correia (2008) are only valid in the context of triple star systems on circular coplanar orbits. Here, we saw that when the triple system’s orbits are eccentric, the magnitude of the binary’s effect can increase with respect to the circular case (Sects. 4.1 and 4.3). Therefore, in the eccentric case a planet can be mimicked by a less massive binary than in the circular case.
The most interesting cases in Table 1 (Morais & Correia 2008), namely γ Cep and HD 196885, are binary systems with eccentric orbits. The star γ Cep A orbits γ Cep B with e = 0.41 and I = 119° (Neuhäuser et al. 2007; Mugrauer et al. 2007), while t_{obs} ≈ T/2 (Torres 2007). The star HD 196885 A orbits HD 196885 B with e = 0.46 but I is unknown while t_{obs} ≈ T/4 (Correia et al. 2008). However, extrapolating from the results in Sect. 4.1, if there were hidden companion stars close to γ Cep B or HD 196885 B, we would expect to be able to detect, in each case, several nearby peaks and not single peaks at the planets’ orbital frequencies.
Moreover, the stars γ Cep A+B have been directly imaged and γ Cep B’s brightness is consistent with that of a single M4type dwarf (Neuhäuser et al. 2007). Additionally, we performed some 3body fits to the data using a model with HD 196885 A+B and an unresolved star nearby HD 196885 B. We saw that these fits were worse (residuals at least 31 m/s and poorly constrained orbital elements) than fits using a model with the binary star system (HD 196885 A+B) and a planet companion to HD 196885 A (residuals of 11 m/s in agreement with Correia et al. 2008). Therefore, the planets around γ Cep A and HD 196885 A, respectively, are not likely to be due to hidden star companions to γ Cep B or HD 196885 B.
5. Conclusion
We have studied a triple system composed of a star and a binary system. The star and binary system have eccentric and inclined orbits. This is an extension of earlier work where we assumed that the star and binary system are on circular coplanar orbits (Morais & Correia 2008).
We demonstrated that if we are unaware of the binary systems presence (one or even both components may be unresolved for instance because they are faint M stars) we may then be led to believe that the star has one or even two planet companions. Although the radial velocity variations due to a binary are distinct from those due to planet(s), in practice, the measured effect depends on the instrument’s precision and the observation time span.
We have shown that because of the limited instrumental precision, we may only detect periodic terms with well separated frequencies hence we mistake these for planet(s). We also saw that, if the observation time span is shorter than the star’s longperiod motion around the binary’s center of mass, we may not be able to resolve terms with nearby frequencies, which means that we cannot distinguish fake planet(s) from a binary.
We have also demonstrated that the binary’s effect is more likely to be mistaken for planet(s) when the radial velocity oscillations are composed of large dominant periodic terms with well separated frequencies. This is more likely to happen in the case of coplanar orbits observed equatoron. Moreover, we have seen that when the orbits are eccentric, the magnitude of the binary’s effect can increase with respect to the circular case. Nevertheless, our model is valid for any triple system’s configuration.
We have presented an example of a binary system that affects a nearby star’s motion. When the star’s longperiod motion has low to medium eccentricity, the binary can mimic planet(s) of 10 to 50 Earth masses, which are near the current detection limit. However, if the longperiod motion has a high eccentricity we are more likely to detect multiple signals with very close frequencies and therefore reject the planet hypothesis. An exception occurs when the long period motion has a high eccentricity but its period is poorly constrained (due to a short observational time span) in which case we may mistake the binary for a planet of about 100 Earth masses.
We showed that when the binary has an eccentric orbit it can mimic two planets with periods approximately in the ratio 2/1. Therefore we may be misled to think that we found planets in the 2/1 orbital resonance when we have an eccentric hidden binary. This is somehow analogous to the case studied by AngladaEscudé et al. (2010) where two planets on circular orbits in the
2/1 orbital resonance can be mistaken for a single planet with an eccentric orbit. However, our scenario is probably more realistic since planets in orbital resonances are not likely to have circular orbits.
We propose that new planet detections in close binary systems, especially Earthsized objects that are the targets of the planned search program EXPRESSO/CODEX (D’Odorico & CODEX/ESPRESSO Team 2007), be checked carefully because they could indeed be artifacts caused by a hidden binary. This could be done by comparing fits to the data using (1) a model composed of the binary star system and a planet with (2) those obtained for a model composed of a hierarchical triple star system. If the fits of (2) are at least as good as (1), then the hidden binary hypothesis should be considered.
Acknowledgments
We acknowledge financial support from FCTPortugal (grant PTDC/CTEAST/098528/2008).
References
 AngladaEscudé, G., LópezMorales, M., & Chambers, J. E. 2010, ApJ, 709, 168 [NASA ADS] [CrossRef] (In the text)
 Correia, A. C. M., Udry, S., Mayor, M., et al. 2008, A&A, 479, 271 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Delfosse, X., Beuzit, J., Marchal, L., et al. 2004, in Spectroscopically and Spatially Resolving the Components of the Close Binary Stars, ed. R. W. Hilditch, H. Hensberge, & K. Pavlovski, ASP Conf. Ser., 318, 166 (In the text)
 D’Odorico, V., & CODEX/ESPRESSO Team. 2007, Mem. Soc. Astron. Ital., 78, 712 [NASA ADS] (In the text)
 Duquennoy, A., & Mayor, M. 1991, 248, 485 (In the text)
 Eggenberger, A., Halbwachs, J., Udry, S., & Mayor, M. 2004, in Rev. Mex. Astron. Astrofis. Conf. Ser., ed. C. Allen & C. Scarfe, 21, 28 (In the text)
 Eggenberger, A., Udry, S., Mazeh, T., Segal, Y., & Mayor, M. 2007, A&A, 466, 1179 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Fischer, D. A., & Marcy, G. W. 1992, ApJ, 396, 178 [NASA ADS] [CrossRef] (In the text)
 Halbwachs, J. L., Mayor, M., Udry, S., & Arenou, F. 2003, A&A, 397, 159 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Konacki, M. 2005, Nature, 436, 230 [NASA ADS] [CrossRef] [PubMed] (In the text)
 LeDrew, G. 2001, Journal of the Royal Astronomical Society of Canada, 95, 32 [NASA ADS] (In the text)
 Mayor, M., Pepe, F., Queloz, D., et al. 2003, The Messenger, 114, 20 [NASA ADS] (In the text)
 Morais, M. H. M., & Correia, A. C. M. 2008, A&A, 491, 899 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Mugrauer, M., Neuhäuser, R., & Mazeh, T. 2007, A&A, 469, 755 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Murray, C. D., & Dermott, S. F. 1999, Solar system dynamics (Cambridge University Press) (In the text)
 Neuhäuser, R., Mugrauer, M., Fukagawa, M., Torres, G., & Schmidt, T. 2007, A&A, 462, 777 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Schneider, J., & Cabrera, J. 2006, A&A, 445, 1159 [NASA ADS] [CrossRef] [EDP Sciences] (In the text)
 Torres, G. 2007, ApJ, 654, 1095 [NASA ADS] [CrossRef] (In the text)
