Fig. 11.

NAOMI control loop model. The incident wavefront W is compensated for by the command C applied on the DM. The residual wavefront R is averaged over the integration time Ti by the WFS, delayed by Td, integrated by a controller with a gain KI, and converted into commands C by an digital-to-analog converter (DAC). The cycle time Tc is the inverse of the loop frequency. The pure delay Td includes contributions from the camera frame transfer and readout time, the RTC computation time, and the DM response time. The Laplace transform of each idealised operation is shown above its respective block.
