Table B.2: Deprojected temperature profile results, with $3 \sigma$ errors. MOS and pn spectra are fitted as described in Sect. 5.3.
Annulus kT Abundance

( ' ) (keV) $Z/Z_{\odot}$

0.00-0.50 6.40^+0.47_-0.47 0.34^+0.06_-0.06

0.50-0.69 7.83^+1.97_-1.47 0.38^+0.21_-0.20

0.69-0.97 6.69^+1.20_-0.95 0.29^+0.15_-0.13

0.97-1.35 7.70^+1.29_-1.00 0.24^+0.12_-0.11

1.35-1.89 6.39^+0.67_-0.59 0.52^+0.10_-0.10

1.89-2.64 6.89^+0.81_-0.68 0.17^+0.08_-0.07

2.64-3.68 6.35^+0.84_-0.71 0.34^+0.10_-0.10

3.68-5.13 6.09^+1.20_-0.87 0.11^+0.24_-0.11

5.13-7.16 6.89^+4.35_-2.06 0.3 frozen

7.16-9.00 4.13^+4.61_-2.08 0.3 frozen

Annulus	kT	Abundance
( ' )	(keV)	$Z/Z_{\odot}$
0.00-0.50	6.40^+0.47_-0.47	0.34^+0.06_-0.06
0.50-0.69	7.83^+1.97_-1.47	0.38^+0.21_-0.20
0.69-0.97	6.69^+1.20_-0.95	0.29^+0.15_-0.13
0.97-1.35	7.70^+1.29_-1.00	0.24^+0.12_-0.11
1.35-1.89	6.39^+0.67_-0.59	0.52^+0.10_-0.10
1.89-2.64	6.89^+0.81_-0.68	0.17^+0.08_-0.07
2.64-3.68	6.35^+0.84_-0.71	0.34^+0.10_-0.10
3.68-5.13	6.09^+1.20_-0.87	0.11^+0.24_-0.11
5.13-7.16	6.89^+4.35_-2.06	0.3 frozen
7.16-9.00	4.13^+4.61_-2.08	0.3 frozen

Appendix B: Table
